Merge branch 'develop' into doc-standard

Jenkinsfile

@@ -136,12 +136,14 @@ rocmtest clang_debug: rocmnode('mi100+') { cmake_build ->
     }
 }, mlir_debug: rocmnode('mi100+') { cmake_build ->
     stage('MLIR Debug') {
-        withEnv(['MIGRAPHX_ENABLE_EXTRA_MLIR=1']) {
+        withEnv(['MIGRAPHX_ENABLE_EXTRA_MLIR=1', 'MIGRAPHX_MLIR_USE_SPECIFIC_OPS=fused,attention,convolution,dot']) {
             def sanitizers = "undefined"
             // Note: the -fno-sanitize= is copied from upstream LLVM_UBSAN_FLAGS.
             def debug_flags_cxx = "-g -O2 -fsanitize=${sanitizers} -fno-sanitize=vptr,function -fno-sanitize-recover=${sanitizers}"
             def debug_flags = "-g -O2 -fsanitize=${sanitizers} -fno-sanitize=vptr -fno-sanitize-recover=${sanitizers}"
             def gpu_targets = getgputargets()
+            // Since the purpose of this run verify all things MLIR supports,
+            // enabling all possible types of offloads
             cmake_build(flags: "-DCMAKE_BUILD_TYPE=debug -DMIGRAPHX_ENABLE_PYTHON=Off -DMIGRAPHX_ENABLE_MLIR=On -DCMAKE_CXX_FLAGS_DEBUG='${debug_flags_cxx}' -DCMAKE_C_FLAGS_DEBUG='${debug_flags}' -DGPU_TARGETS='${gpu_targets}'")
         }
     }

docs/dev/env_vars.rst

@@ -4,13 +4,13 @@ Environment Variables
 For parsing
 ---------------

-**MIGRAPHX_TRACE_ONNX_PARSER**
+.. envvar:: MIGRAPHX_TRACE_ONNX_PARSER

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print debugging traces for the onnx parser.
 Prints: initializers (if used), ONNX node operators, added MIGraphX instructions

-**MIGRAPHX_DISABLE_FP16_INSTANCENORM_CONVERT**
+.. envvar:: MIGRAPHX_DISABLE_FP16_INSTANCENORM_CONVERT

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Disables the conversion from fp16 to fp32 for the InstanceNormalization ONNX operator that MIGX does as a workaround for accuracy issues with reduce_mean/variance.
@@ -20,16 +20,16 @@ See ``parse_instancenorm.cpp`` for more details.
 Matchers
 ------------

-**MIGRAPHX_TRACE_MATCHES**
+.. envvar:: MIGRAPHX_TRACE_MATCHES

 Set to "1" to print the matcher that matches an instruction and the matched instruction.
 Set to "2" and use the ``MIGRAPHX_TRACE_MATHCES_FOR`` flag to filter out results.

-**MIGRAPHX_TRACE_MATCHES_FOR**
+.. envvar:: MIGRAPHX_TRACE_MATCHES_FOR

 Set to the name of any matcher and only traces for that matcher will be printed out.

-**MIGRAPHX_VALIDATE_MATCHES**
+.. envvar:: MIGRAPHX_VALIDATE_MATCHES

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Validate the module after finding the matches (runs ``module.validate()``).
@@ -37,7 +37,7 @@ Validate the module after finding the matches (runs ``module.validate()``).
 Program Execution
 ---------------------

-**MIGRAPHX_TRACE_EVAL**
+.. envvar:: MIGRAPHX_TRACE_EVAL

 Set to "1", "2", or "3" to use.
 "1" prints the instruction run and the time taken.
@@ -48,7 +48,7 @@ Set to "1", "2", or "3" to use.
 Program Verification
 ------------------------

-**MIGRAPHX_VERIFY_ENABLE_ALLCLOSE**
+.. envvar:: MIGRAPHX_VERIFY_ENABLE_ALLCLOSE

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Uses ``allclose`` with the given ``atol`` and ``rtol`` for verifying ranges with ``driver verify`` or the tests that use ``migraphx/verify.hpp``.
@@ -57,76 +57,76 @@ Uses ``allclose`` with the given ``atol`` and ``rtol`` for verifying ranges with
 Pass debugging or Pass controls
 -----------------------------------

-**MIGRAPHX_TRACE_ELIMINATE_CONTIGUOUS**
+.. envvar:: MIGRAPHX_TRACE_ELIMINATE_CONTIGUOUS

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Debug print the instructions that have input ``contiguous`` instructions removed.

-**MIGRAPHX_DISABLE_POINTWISE_FUSION**
+.. envvar:: MIGRAPHX_DISABLE_POINTWISE_FUSION

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Disables the ``fuse_pointwise`` compile pass.

-**MIGRAPHX_DEBUG_MEMORY_COLORING**
+.. envvar:: MIGRAPHX_DEBUG_MEMORY_COLORING

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print debug statements for the ``memory_coloring`` pass.

-**MIGRAPHX_TRACE_SCHEDULE**
+.. envvar:: MIGRAPHX_TRACE_SCHEDULE

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print debug statements for the ``schedule`` pass.

-**MIGRAPHX_TRACE_PROPAGATE_CONSTANT**
+.. envvar:: MIGRAPHX_TRACE_PROPAGATE_CONSTANT

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Traces instructions replaced with a constant.

-**MIGRAPHX_INT8_QUANTIZATION_PARAMS**
+.. envvar:: MIGRAPHX_INT8_QUANTIZATION_PARAMS

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print the quantization parameters in only the main module.

-**MIGRAPHX_DISABLE_DNNL_POST_OPS_WORKAROUND**
+.. envvar:: MIGRAPHX_DISABLE_DNNL_POST_OPS_WORKAROUND

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Disable the DNNL post ops workaround.

-**MIGRAPHX_DISABLE_MIOPEN_FUSION**
+.. envvar:: MIGRAPHX_DISABLE_MIOPEN_FUSION

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Disable MIOpen fusions.

-**MIGRAPHX_DISABLE_SCHEDULE_PASS**
+.. envvar:: MIGRAPHX_DISABLE_SCHEDULE_PASS

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Disable the ``schedule`` pass.

-**MIGRAPHX_DISABLE_REDUCE_FUSION**
+.. envvar:: MIGRAPHX_DISABLE_REDUCE_FUSION

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Disable the ``fuse_reduce`` pass.

-**MIGRAPHX_ENABLE_NHWC**
+.. envvar:: MIGRAPHX_ENABLE_NHWC

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Enable the ``layout_nhwc`` pass.

-**MIGRAPHX_ENABLE_CK**
+.. envvar:: MIGRAPHX_ENABLE_CK

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Enable using the Composable Kernels library.
 Should be used in conjunction with ``MIGRAPHX_DISABLE_MLIR=1``.

-**MIGRAPHX_DISABLE_MLIR**
+.. envvar:: MIGRAPHX_DISABLE_MLIR*
 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Disable using the rocMLIR library.

-**MIGRAPHX_ENABLE_EXTRA_MLIR**
+.. envvar:: MIGRAPHX_ENABLE_EXTRA_MLIR
 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Enables additional opportunities to use MLIR that may improve performance.

-**MIGRAPHX_COPY_LITERALS**
+.. envvar:: MIGRAPHX_COPY_LITERALS

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Use ``hip_copy_to_gpu`` with a new ``literal`` instruction rather than use ``hip_copy_literal{}``.
@@ -134,22 +134,22 @@ Use ``hip_copy_to_gpu`` with a new ``literal`` instruction rather than use ``hip
 Compilation traces
 ----------------------

-**MIGRAPHX_TRACE_FINALIZE**
+.. envvar:: MIGRAPHX_TRACE_FINALIZE

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Debug print instructions during the ``module.finalize()`` step.

-**MIGRAPHX_TRACE_COMPILE**
+.. envvar:: MIGRAPHX_TRACE_COMPILE

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print trace information for the graph compilation process.

-**MIGRAPHX_TRACE_PASSES**
+.. envvar:: MIGRAPHX_TRACE_PASSES

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print the compile pass and the program after the pass.

-**MIGRAPHX_TIME_PASSES**
+.. envvar:: MIGRAPHX_TIME_PASSES

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Time the compile passes.
@@ -158,77 +158,77 @@ Time the compile passes.
 GPU Kernels JIT compilation debugging (applicable for both hiprtc and hipclang)
 -----------------------------------------

-**MIGRAPHX_TRACE_CMD_EXECUTE**
+.. envvar:: MIGRAPHX_TRACE_CMD_EXECUTE

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print commands executed by the MIGraphX ``process``.

-**MIGRAPHX_TRACE_HIPRTC**
+.. envvar:: MIGRAPHX_TRACE_HIPRTC

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print HIPRTC options and C++ file executed.

-**MIGRAPHX_DEBUG_SAVE_TEMP_DIR**
+.. envvar:: MIGRAPHX_DEBUG_SAVE_TEMP_DIR

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Make it so the created temporary directories are not deleted.

-**MIGRAPHX_GPU_DEBUG**
+.. envvar:: MIGRAPHX_GPU_DEBUG

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Internally, this adds the option ``-DMIGRAPHX_DEBUG`` when compiling GPU kernels. It enables assertions and capture of source locations for the errors.

-**MIGRAPHX_GPU_DEBUG_SYM**
+.. envvar:: MIGRAPHX_GPU_DEBUG_SYM

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Adds the option ``-g`` when compiling HIPRTC.

-**MIGRAPHX_GPU_DUMP_SRC**
+.. envvar:: MIGRAPHX_GPU_DUMP_SRC

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Dump the HIPRTC source files compiled.

-**MIGRAPHX_GPU_DUMP_ASM**
+.. envvar:: MIGRAPHX_GPU_DUMP_ASM

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Dump the hip-clang assembly.

-**MIGRAPHX_GPU_OPTIMIZE**
+.. envvar:: MIGRAPHX_GPU_OPTIMIZE

 Set the optimization mode for GPU compile (``-O`` option).
 Defaults to ``-O3``.

-**MIGRAPHX_GPU_COMPILE_PARALLEL**
+.. envvar:: MIGRAPHX_GPU_COMPILE_PARALLEL

 Set to the number of threads to use.
 Compile GPU code in parallel with the given number of threads.

-**MIGRAPHX_TRACE_NARY**
+.. envvar:: MIGRAPHX_TRACE_NARY

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print the ``nary`` device functions used.

-**MIGRAPHX_ENABLE_HIPRTC_WORKAROUNDS**
+.. envvar:: MIGRAPHX_ENABLE_HIPRTC_WORKAROUNDS

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Enable HIPRTC workarounds for bugs in HIPRTC.

-**MIGRAPHX_USE_FAST_SOFTMAX**
+.. envvar:: MIGRAPHX_USE_FAST_SOFTMAX

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Use the fast softmax optimization.

-**MIGRAPHX_ENABLE_NULL_STREAM**
+.. envvar:: MIGRAPHX_ENABLE_NULL_STREAM

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Allow using null stream for miopen and hipStream.

-**MIGRAPHX_NSTREAMS**
+.. envvar:: MIGRAPHX_NSTREAMS

 Set to the number of streams to use.
 Defaults to 1.

-**MIGRAPHX_TRACE_BENCHMARKING**
+.. envvar:: MIGRAPHX_TRACE_BENCHMARKING

 Set to "1" to print benchmarching trace.
 Set to "2" to print benchmarching trace with more detail.
@@ -236,45 +236,49 @@ Set to "2" to print benchmarching trace with more detail.
 MLIR vars
 -------------

-**MIGRAPHX_TRACE_MLIR**
+.. envvar:: MIGRAPHX_TRACE_MLIR

 Set to "1" to trace MLIR and print any failures.
 Set to "2" to additionally print all MLIR operations.

-**MIGRAPHX_MLIR_USE_SPECIFIC_OPS**
+.. envvar:: MIGRAPHX_MLIR_USE_SPECIFIC_OPS

 Set to the name of the operations you want to always use MLIR regardless of GPU architecture.
 Accepts a list of operators separated by commas (ex: "fused", "convolution", "dot").

-**MIGRAPHX_MLIR_TUNING_DB**
+.. envvar:: MIGRAPHX_MLIR_TUNING_DB

 Set to the path of the MLIR tuning database to load.

-**MIGRAPHX_MLIR_TUNING_CFG**
+.. envvar:: MIGRAPHX_MLIR_TUNING_CFG

 Set to the path of the tuning configuration.
 Appends to tuning cfg file that could be used with rocMLIR tuning scripts.

-**MIGRAPHX_MLIR_TUNE_EXHAUSTIVE**
+.. envvar:: MIGRAPHX_MLIR_TUNE_EXHAUSTIVE

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Do exhaustive tuning for MLIR.

+.. envvar:: MIGRAPHX_MLIR_TUNE_LIMIT
+
+Set to an integer greater than 1.
+Limits the number of solutions that MLIR will use for tuning.

 CK vars
 -----------

-**MIGRAPHX_LOG_CK_GEMM**
+.. envvar:: MIGRAPHX_LOG_CK_GEMM

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Print Composable Kernels GEMM traces.

-**MIGRAPHX_CK_DEBUG**
+.. envvar:: MIGRAPHX_CK_DEBUG

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Always add the ``-DMIGRAPHX_CK_CHECK=1`` for compiling Composable Kernels operators.

-**MIGRAPHX_TUNE_CK**
+.. envvar:: MIGRAPHX_TUNE_CK

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Use tuning for Composable Kernels.
@@ -282,19 +286,19 @@ Use tuning for Composable Kernels.
 Testing
 ------------

-**MIGRAPHX_TRACE_TEST_COMPILE**
+.. envvar:: MIGRAPHX_TRACE_TEST_COMPILE

 Set to the target that you want to trace the compilation of (ex. "gpu", "cpu").
 Prints the compile trace for the given target for the verify tests.
 This flag shouldn't be used in conjunction with ``MIGRAPHX_TRACE_COMPILE``.
 For the verify tests only use ``MIGRAPHX_TRACE_TEST_COMPILE``.

-**MIGRAPHX_TRACE_TEST**
+.. envvar:: MIGRAPHX_TRACE_TEST

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Prints the reference and target programs even if the verify passed successfully.

-**MIGRAPHX_DUMP_TEST**
+.. envvar:: MIGRAPHX_DUMP_TEST

 Set to "1", "enable", "enabled", "yes", or "true" to use.
 Dumps verify tests to ``.mxr`` files.

docs/sphinx/requirements.in

-rocm-docs-core==0.29.0
+rocm-docs-core==0.30.0

docs/sphinx/requirements.txt

@@ -49,7 +49,7 @@ charset-normalizer==3.1.0
     # via requests
 click==8.1.3
     # via sphinx-external-toc
-cryptography==41.0.4
+cryptography==41.0.6
     # via pyjwt
 deprecated==1.2.13
     # via pygithub
@@ -121,7 +121,7 @@ requests==2.28.2
     # via
     #   pygithub
     #   sphinx
-rocm-docs-core==0.29.0
+rocm-docs-core==0.30.0
     # via -r requirements.in
 smmap==5.0.0
     # via gitdb

examples/README.md

@@ -6,4 +6,5 @@ This directory contains examples of common use cases for MIGraphX.
 ## Examples:
 - [MIGraphX usage and utilities](./migraphx)
 - [Vision inference examples](./vision)
-- [Natural language inference examples](./nlp)
+- [Natural language inference examples](./nlp)
\ No newline at end of file
+- [Diffusion inference examples](./diffusion)

examples/diffusion/README.md

+# Diffusion Inference Examples
+
+- [Python Stable Diffusion 2.1](./python_stable_diffusion_21)

examples/diffusion/python_stable_diffusion_21/README.md

+# Stable Diffusion 2.1
+
+This version was tested with [rocm 5.7](https://github.com/ROCmSoftwarePlatform/AMDMIGraphX/tree/rocm-5.7.0) revision.
+
+## Jupyter notebook
+
+There is a dedicated step-by-step notebook. See [sd21.ipynb](./sd21.ipynb)
+
+## Console application
+
+To run the console application, follow these steps below.
+
+Setup python environment
+
+```bash
+# this will require the python venv to installed (e.g. apt install python3.8-venv)
+python3 -m venv sd_venv
+. sd_venv/bin/activate
+```
+
+Install dependencies
+
+```bash
+pip install -r requirements.txt
+```
+
+Use MIGraphX Python Module
+
+```bash
+export PYTHONPATH=/opt/rocm/lib:$PYTHONPATH
+```
+
+Get models with optimum
+
+```bash
+optimum-cli export onnx --model stabilityai/stable-diffusion-2-1 models/sd21-onnx
+```
+*Note: `models/sd21-onnx` will be used in the scripts.*
+
+Run the text-to-image script with the following example prompt and seed:
+
+```bash
+python txt2img.py --prompt "a photograph of an astronaut riding a horse" --seed 13 --output astro_horse.jpg
+```
+*Note: The first run will compile the models and cache them to make subsequent runs faster.*
+
+The result should look like this:
+
+![example_output.jpg](./example_output.jpg)
+
+## Gradio application
+
+Note: requires `Console application` to work
+
+Install gradio dependencies
+
+```bash
+pip install -r gradio_requirements.txt
+```
+
+Usage
+
+```bash
+python gradio_app.py
+```
+
+This will load the models (which can take several minutes), and when the setup is ready, starts a server on `http://127.0.0.1:7860`.

examples/diffusion/python_stable_diffusion_21/gradio_app.py

+#####################################################################################
+# The MIT License (MIT)
+#
+# Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+#
+# Permission is hereby granted, free of charge, to any person obtaining a copy
+# of this software and associated documentation files (the "Software"), to deal
+# in the Software without restriction, including without limitation the rights
+# to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+# copies of the Software, and to permit persons to whom the Software is
+# furnished to do so, subject to the following conditions:
+#
+# The above copyright notice and this permission notice shall be included in
+# all copies or substantial portions of the Software.
+#
+# THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+# IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+# FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+# AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+# LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+# OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+# THE SOFTWARE.
+#####################################################################################
+
+from txt2img import StableDiffusionMGX
+import gradio as gr
+
+
+def main():
+    # Note: This will load the models, which can take several minutes
+    sd = StableDiffusionMGX()
+
+    def gr_wrapper(prompt, negative_prompt, steps, seed, scale):
+        result = sd.run(str(prompt), str(negative_prompt), int(steps),
+                        int(seed), float(scale))
+        return StableDiffusionMGX.convert_to_rgb_image(result)
+
+    demo = gr.Interface(
+        gr_wrapper,
+        [
+            gr.Textbox(value="a photograph of an astronaut riding a horse",
+                       label="Prompt"),
+            gr.Textbox(value="", label="Negative prompt (Optional)"),
+            gr.Slider(1, 100, step=1, value=20, label="Number of steps"),
+            gr.Textbox(value=13, label="Random seed"),
+            gr.Slider(1, 20, step=0.1, value=7.0, label="Guidance scale"),
+        ],
+        "image",
+    )
+    demo.launch()
+
+
+if __name__ == "__main__":
+    main()

examples/diffusion/python_stable_diffusion_21/gradio_reqirements.txt

+#####################################################################################
+# The MIT License (MIT)
+#
+# Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+#
+# Permission is hereby granted, free of charge, to any person obtaining a copy
+# of this software and associated documentation files (the "Software"), to deal
+# in the Software without restriction, including without limitation the rights
+# to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+# copies of the Software, and to permit persons to whom the Software is
+# furnished to do so, subject to the following conditions:
+#
+# The above copyright notice and this permission notice shall be included in
+# all copies or substantial portions of the Software.
+#
+# THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+# IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+# FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+# AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+# LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+# OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+# THE SOFTWARE.
+#####################################################################################
+-f requirements.txt
+gradio
\ No newline at end of file

examples/diffusion/python_stable_diffusion_21/requirements.txt

+#####################################################################################
+# The MIT License (MIT)
+#
+# Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+#
+# Permission is hereby granted, free of charge, to any person obtaining a copy
+# of this software and associated documentation files (the "Software"), to deal
+# in the Software without restriction, including without limitation the rights
+# to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+# copies of the Software, and to permit persons to whom the Software is
+# furnished to do so, subject to the following conditions:
+#
+# The above copyright notice and this permission notice shall be included in
+# all copies or substantial portions of the Software.
+#
+# THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+# IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+# FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+# AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+# LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+# OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+# THE SOFTWARE.
+#####################################################################################
+accelerate
+diffusers
+optimum[onnxruntime]
+transformers
\ No newline at end of file

examples/diffusion/python_stable_diffusion_21/sd21.ipynb

+{
+ "cells": [
+  {
+   "cell_type": "code",
+   "execution_count": 2,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "#  The MIT License (MIT)\n",
+    "#\n",
+    "#  Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.\n",
+    "#\n",
+    "#  Permission is hereby granted, free of charge, to any person obtaining a copy\n",
+    "#  of this software and associated documentation files (the 'Software'), to deal\n",
+    "#  in the Software without restriction, including without limitation the rights\n",
+    "#  to use, copy, modify, merge, publish, distribute, sublicense, and/or sell\n",
+    "#  copies of the Software, and to permit persons to whom the Software is\n",
+    "#  furnished to do so, subject to the following conditions:\n",
+    "#\n",
+    "#  The above copyright notice and this permission notice shall be included in\n",
+    "#  all copies or substantial portions of the Software.\n",
+    "#\n",
+    "#  THE SOFTWARE IS PROVIDED 'AS IS', WITHOUT WARRANTY OF ANY KIND, EXPRESS OR\n",
+    "#  IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,\n",
+    "#  FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE\n",
+    "#  AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER\n",
+    "#  LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,\n",
+    "#  OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN\n",
+    "#  THE SOFTWARE."
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "# Stable Diffusion 2.1\n",
+    "\n",
+    "The following example will show how to run `Stable Diffusion 2.1` with `MIGraphX`."
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Install the required dependencies."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Install dependencies\n",
+    "!pip install optimum[onnxruntime] transformers diffusers accelerate"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "We will use optimum to generate the onnx files."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# export models\n",
+    "!optimum-cli export onnx --model stabilityai/stable-diffusion-2-1 models/sd21-onnx"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Now it is time to load these models with python.\n",
+    "\n",
+    "First, we make sure that MIGraphX module is found in the python path."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "import sys\n",
+    "mgx_lib_path = \"/opt/rocm/lib/\" # or \"/code/AMDMIGraphX/build/lib/\"\n",
+    "if mgx_lib_path not in sys.path:\n",
+    "    sys.path.append(mgx_lib_path)\n",
+    "import migraphx as mgx"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Next, a helper method to load and cache the models.\n",
+    "\n",
+    "This will use the `models/sd21-onnx` path. If you changed it, make sure to update here as well."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "import os\n",
+    "# helper for model loading\n",
+    "def load_mgx_model(name, shapes):\n",
+    "    file = f\"models/sd21-onnx/{name}/model\"\n",
+    "    print(f\"Loading {name} model from {file}\")\n",
+    "    if os.path.isfile(f\"{file}.mxr\"):\n",
+    "        print(f\"Found mxr, loading it...\")\n",
+    "        model = mgx.load(f\"{file}.mxr\", format=\"msgpack\")\n",
+    "    elif os.path.isfile(f\"{file}.onnx\"):\n",
+    "        print(f\"Parsing from onnx file...\")\n",
+    "        model = mgx.parse_onnx(f\"{file}.onnx\", map_input_dims=shapes)\n",
+    "        model.compile(mgx.get_target(\"gpu\"))\n",
+    "        print(f\"Saving {name} model to mxr file...\")\n",
+    "        mgx.save(model, f\"{file}.mxr\", format=\"msgpack\")\n",
+    "    else:\n",
+    "        print(f\"No {name} model found. Please verify the path is correct and re-try, or re-download model.\")\n",
+    "        os.exit(1)\n",
+    "    return model"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "With that, we can load the models. This could take several minutes."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "text_encoder = load_mgx_model(\"text_encoder\", {\"input_ids\": [1, 77]})"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "unet = load_mgx_model(\n",
+    "        \"unet\", {\n",
+    "            \"sample\": [1, 4, 64, 64],\n",
+    "            \"encoder_hidden_states\": [1, 77, 1024],\n",
+    "            \"timestep\": [1],\n",
+    "        })"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "vae = load_mgx_model(\"vae_decoder\", {\"latent_sample\": [1, 4, 64, 64]})"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Import the remaining packages."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "from diffusers import EulerDiscreteScheduler\n",
+    "from transformers import CLIPTokenizer\n",
+    "import torch\n",
+    "import numpy as np\n",
+    "from tqdm.auto import tqdm\n",
+    "from PIL import Image"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Time to load the scheduler and tokenizer from the original source."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "model_id = \"stabilityai/stable-diffusion-2-1\"\n",
+    "scheduler = EulerDiscreteScheduler.from_pretrained(model_id,\n",
+    "                                                   subfolder=\"scheduler\")\n",
+    "tokenizer = CLIPTokenizer.from_pretrained(model_id, subfolder=\"tokenizer\")"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Next, we will define all the steps one by one, to make the last step short and simple.\n",
+    "\n",
+    "The first step will be to tokenize the user prompt. It will make a `(1, 77)` shaped `input_ids`."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def tokenize(input):\n",
+    "    return tokenizer([input],\n",
+    "                     padding=\"max_length\",\n",
+    "                     max_length=tokenizer.model_max_length,\n",
+    "                     truncation=True,\n",
+    "                     return_tensors=\"np\")"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "test_tk = tokenize(\"test tokenizer to see the tokens\")\n",
+    "test_tk.input_ids.shape"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "We run the tokenized prompt through the `Text Encoder` model. It expects the `(1, 77)` data as `int32`."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "text_encoder.get_parameter_shapes()"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def get_embeddings(input):\n",
+    "    return np.array(\n",
+    "        text_encoder.run({\"input_ids\": input.input_ids.astype(np.int32)\n",
+    "                          })[0]).astype(np.float32)"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "test_emb = get_embeddings(tokenize(\"test tokenizer to see the tokens\"))\n",
+    "test_emb.shape"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "The other input of the model is latent representation (pure noise). It will be transformed into a 512x512 image later.\n",
+    "The last input will be the timestep."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def generate_latents(seed):\n",
+    "    return torch.randn(\n",
+    "        (1, 4, 64, 64),\n",
+    "        generator=torch.manual_seed(seed),\n",
+    "    )"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "test_latents = generate_latents(42)\n",
+    "latents.shape"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Now we add two helpers to access and convert from torch to numpy with the proper datatype."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def get_scaled_sample(latents, t):\n",
+    "    return scheduler.scale_model_input(latents, t).numpy().astype(np.float32)\n",
+    "\n",
+    "\n",
+    "def get_timestep(t):\n",
+    "    return np.atleast_1d(t.numpy().astype(np.int64))  # convert 0D -> 1D"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "The UNet model will be run in a loop. It will predict the noise residual."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "unet.get_parameter_shapes()"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def denoise(sample, embeddings, timestep):\n",
+    "    return np.array(\n",
+    "        unet.run({\n",
+    "            \"sample\": sample,\n",
+    "            \"encoder_hidden_states\": embeddings,\n",
+    "            \"timestep\": timestep\n",
+    "        })[0])"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Helpers to do the classifier-free guidance and computing the previous noisy sample."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def perform_guidance(noise_pred_uncond, noise_pred_text, scale):\n",
+    "    return noise_pred_uncond + scale * (noise_pred_text - noise_pred_uncond)\n",
+    "\n",
+    "def compute_previous(noise_pred, t, latents):\n",
+    "    # compute the previous noisy sample x_t -> x_t-1\n",
+    "    return scheduler.step(noise_pred, t, latents).prev_sample\n"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Scale and decode the image latents with VAE."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def scale_denoised(latents):\n",
+    "    return 1 / 0.18215 * latents\n",
+    "\n",
+    "\n",
+    "def decode(latents):\n",
+    "    return np.array(\n",
+    "        vae.run({\"latent_sample\": latents.numpy().astype(np.float32)})[0])"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "And lastly, we need to convert it to an image to display or save."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def convert_to_rgb_image(image):\n",
+    "    image = np.clip(image / 2 + 0.5, 0, 1)\n",
+    "    image = np.transpose(image, (0, 2, 3, 1))\n",
+    "    images = (image * 255).round().astype(\"uint8\")\n",
+    "    return Image.fromarray(images[0])\n",
+    "\n",
+    "def save_image(pil_image, filename=\"output.png\"):\n",
+    "    pil_image.save(filename, format=\"png\")"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Feel free to play around with these params."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "prompt = \"a photograph of an astronaut riding a horse\"\n",
+    "negative_prompt = \"\"\n",
+    "steps = 20\n",
+    "seed = 13\n",
+    "scale = 7.0"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "And now, to put everything together and run the whole pipeline:"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "scheduler.set_timesteps(steps)\n",
+    "\n",
+    "text_input, uncond_input = tokenize(prompt), tokenize(negative_prompt)\n",
+    "text_embeddings, uncond_embeddings = get_embeddings(\n",
+    "    text_input), get_embeddings(uncond_input)\n",
+    "latents = generate_latents(seed) * scheduler.init_noise_sigma\n",
+    "\n",
+    "for t in tqdm(scheduler.timesteps):\n",
+    "    sample = get_scaled_sample(latents, t)\n",
+    "    timestep = get_timestep(t)\n",
+    "\n",
+    "    noise_pred_uncond = denoise(sample, uncond_embeddings, timestep)\n",
+    "    noise_pred_text = denoise(sample, text_embeddings, timestep)\n",
+    "\n",
+    "    noise_pred = perform_guidance(noise_pred_uncond, noise_pred_text, scale)\n",
+    "    latents = compute_previous(torch.from_numpy(noise_pred), t, latents)\n",
+    "\n",
+    "latents = scale_denoised(latents)\n",
+    "result = decode(latents)\n",
+    "image = convert_to_rgb_image(result)\n",
+    "\n",
+    "# show the image\n",
+    "image"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "If you like the generated image, save it with the following:"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "save_image(image, \"output.png\")"
+   ]
+  }
+ ],
+ "metadata": {
+  "kernelspec": {
+   "display_name": "sd_venv",
+   "language": "python",
+   "name": "python3"
+  },
+  "language_info": {
+   "codemirror_mode": {
+    "name": "ipython",
+    "version": 3
+   },
+   "file_extension": ".py",
+   "mimetype": "text/x-python",
+   "name": "python",
+   "nbconvert_exporter": "python",
+   "pygments_lexer": "ipython3",
+   "version": "3.10.12"
+  }
+ },
+ "nbformat": 4,
+ "nbformat_minor": 2
+}

examples/diffusion/python_stable_diffusion_21/txt2img.py

+#  The MIT License (MIT)
+#
+#  Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+#
+#  Permission is hereby granted, free of charge, to any person obtaining a copy
+#  of this software and associated documentation files (the 'Software'), to deal
+#  in the Software without restriction, including without limitation the rights
+#  to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+#  copies of the Software, and to permit persons to whom the Software is
+#  furnished to do so, subject to the following conditions:
+#
+#  The above copyright notice and this permission notice shall be included in
+#  all copies or substantial portions of the Software.
+#
+#  THE SOFTWARE IS PROVIDED 'AS IS', WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+#  IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+#  FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+#  AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+#  LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+#  OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+#  THE SOFTWARE.
+
+from argparse import ArgumentParser
+from diffusers import EulerDiscreteScheduler
+from transformers import CLIPTokenizer
+from PIL import Image
+
+import migraphx as mgx
+import numpy as np
+import os
+import torch
+import time
+from functools import wraps
+
+
+# measurement helper
+def measure(fn):
+    @wraps(fn)
+    def measure_ms(*args, **kwargs):
+        start_time = time.perf_counter_ns()
+        result = fn(*args, **kwargs)
+        end_time = time.perf_counter_ns()
+        print(f"Elapsed time: {(end_time - start_time) * 1e-6:.4f} ms\n")
+        return result
+
+    return measure_ms
+
+
+def get_args():
+    parser = ArgumentParser()
+    parser.add_argument(
+        "-s",
+        "--seed",
+        type=int,
+        default=42,
+        help="Random seed",
+    )
+
+    parser.add_argument(
+        "-t",
+        "--steps",
+        type=int,
+        default=20,
+        help="Number of steps",
+    )
+
+    parser.add_argument(
+        "-p",
+        "--prompt",
+        type=str,
+        required=True,
+        help="Prompt",
+    )
+
+    parser.add_argument(
+        "-n",
+        "--negative-prompt",
+        type=str,
+        default="",
+        help="Negative prompt",
+    )
+
+    parser.add_argument(
+        "--scale",
+        type=float,
+        default=7.0,
+        help="Guidance scale",
+    )
+
+    parser.add_argument(
+        "-o",
+        "--output",
+        type=str,
+        default=None,
+        help="Output name",
+    )
+    return parser.parse_args()
+
+
+class StableDiffusionMGX():
+    def __init__(self):
+        model_id = "stabilityai/stable-diffusion-2-1"
+        print(f"Using {model_id}")
+
+        print("Creating EulerDiscreteScheduler scheduler")
+        self.scheduler = EulerDiscreteScheduler.from_pretrained(
+            model_id, subfolder="scheduler")
+
+        print("Creating CLIPTokenizer tokenizer...")
+        self.tokenizer = CLIPTokenizer.from_pretrained(model_id,
+                                                       subfolder="tokenizer")
+
+        print("Load models...")
+        self.vae = StableDiffusionMGX.load_mgx_model(
+            "vae_decoder", {"latent_sample": [1, 4, 64, 64]})
+        self.text_encoder = StableDiffusionMGX.load_mgx_model(
+            "text_encoder", {"input_ids": [1, 77]})
+        self.unet = StableDiffusionMGX.load_mgx_model(
+            "unet", {
+                "sample": [1, 4, 64, 64],
+                "encoder_hidden_states": [1, 77, 1024],
+                "timestep": [1],
+            })
+
+    def run(self, prompt, negative_prompt, steps, seed, scale):
+        # need to set this for each run
+        self.scheduler.set_timesteps(steps)
+
+        print("Tokenizing prompt...")
+        text_input = self.tokenize(prompt)
+
+        print("Creating text embeddings for prompt...")
+        text_embeddings = self.get_embeddings(text_input)
+
+        print("Tokenizing negative prompt...")
+        uncond_input = self.tokenize(negative_prompt)
+
+        print("Creating text embeddings for negative prompt...")
+        uncond_embeddings = self.get_embeddings(uncond_input)
+
+        print(
+            f"Creating random input data ({1}x{4}x{64}x{64}) (latents) with seed={seed}..."
+        )
+        latents = torch.randn((1, 4, 64, 64),
+                              generator=torch.manual_seed(seed))
+
+        print("Apply initial noise sigma\n")
+        latents = latents * self.scheduler.init_noise_sigma
+
+        print("Running denoising loop...")
+        for step, t in enumerate(self.scheduler.timesteps):
+            print(f"#{step}/{len(self.scheduler.timesteps)} step")
+            latents = self.denoise_step(text_embeddings, uncond_embeddings,
+                                        latents, t, scale)
+
+        print("Scale denoised result...")
+        latents = 1 / 0.18215 * latents
+
+        print("Decode denoised result...")
+        image = self.decode(latents)
+
+        return image
+
+    @staticmethod
+    @measure
+    def load_mgx_model(name, shapes):
+        file = f"models/sd21-onnx/{name}/model"
+        print(f"Loading {name} model from {file}")
+        if os.path.isfile(f"{file}.mxr"):
+            print("Found mxr, loading it...")
+            model = mgx.load(f"{file}.mxr", format="msgpack")
+        elif os.path.isfile(f"{file}.onnx"):
+            print("Parsing from onnx file...")
+            model = mgx.parse_onnx(f"{file}.onnx", map_input_dims=shapes)
+            model.compile(mgx.get_target("gpu"))
+            print(f"Saving {name} model to mxr file...")
+            mgx.save(model, f"{file}.mxr", format="msgpack")
+        else:
+            print(f"No {name} model found. Please download it and re-try.")
+            os.exit(1)
+        return model
+
+    @measure
+    def tokenize(self, input):
+        return self.tokenizer([input],
+                              padding="max_length",
+                              max_length=self.tokenizer.model_max_length,
+                              truncation=True,
+                              return_tensors="np")
+
+    @measure
+    def get_embeddings(self, input):
+        return np.array(
+            self.text_encoder.run(
+                {"input_ids":
+                 input.input_ids.astype(np.int32)})[0]).astype(np.float32)
+
+    @staticmethod
+    def convert_to_rgb_image(image):
+        image = np.clip(image / 2 + 0.5, 0, 1)
+        image = np.transpose(image, (0, 2, 3, 1))
+        images = (image * 255).round().astype("uint8")
+        return Image.fromarray(images[0])
+
+    @staticmethod
+    def save_image(pil_image, filename="output.png"):
+        pil_image.save(filename)
+
+    @measure
+    def denoise_step(self, text_embeddings, uncond_embeddings, latents, t,
+                     scale):
+        sample = self.scheduler.scale_model_input(latents,
+                                                  t).numpy().astype(np.float32)
+        timestep = np.atleast_1d(t.numpy().astype(
+            np.int64))  # convert 0D -> 1D
+
+        noise_pred_uncond = np.array(
+            self.unet.run({
+                "sample": sample,
+                "encoder_hidden_states": uncond_embeddings,
+                "timestep": timestep
+            })[0])
+
+        noise_pred_text = np.array(
+            self.unet.run({
+                "sample": sample,
+                "encoder_hidden_states": text_embeddings,
+                "timestep": timestep
+            })[0])
+
+        # perform guidance
+        noise_pred = noise_pred_uncond + scale * (noise_pred_text -
+                                                  noise_pred_uncond)
+
+        # compute the previous noisy sample x_t -> x_t-1
+        return self.scheduler.step(torch.from_numpy(noise_pred), t,
+                                   latents).prev_sample
+
+    @measure
+    def decode(self, latents):
+        return np.array(
+            self.vae.run({"latent_sample":
+                          latents.numpy().astype(np.float32)})[0])
+
+
+if __name__ == "__main__":
+    args = get_args()
+
+    sd = StableDiffusionMGX()
+    result = sd.run(args.prompt, args.negative_prompt, args.steps, args.seed,
+                    args.scale)
+
+    print("Convert result to rgb image...")
+    image = StableDiffusionMGX.convert_to_rgb_image(result)
+    filename = args.output if args.output else f"output_s{args.seed}_t{args.steps}.png"
+    StableDiffusionMGX.save_image(image, args.output)
+    print(f"Image saved to {filename}")

requirements.txt

@@ -29,4 +29,4 @@ pybind/pybind11@d159a563383d10c821ba7b2a71905d1207db6de4 --build
 msgpack/msgpack-c@cpp-3.3.0 -DMSGPACK_BUILD_TESTS=Off
 sqlite3@3.43.2 -DCMAKE_POSITION_INDEPENDENT_CODE=On
 ROCmSoftwarePlatform/composable_kernel@70eefcf4f263aa5c25f3c9ff0db8f6f199ef0fb9 -DCK_BUILD_JIT_LIB=On -DCMAKE_POSITION_INDEPENDENT_CODE=On
-ROCmSoftwarePlatform/rocMLIR@13f6c2a69cfe80a575c6b241ec7353d1e953cb12 -DBUILD_FAT_LIBROCKCOMPILER=On
+ROCmSoftwarePlatform/rocMLIR@9e66e8050209f03349a41b6b497f0da2b285a53b -DBUILD_FAT_LIBROCKCOMPILER=On

src/CMakeLists.txt

@@ -221,6 +221,8 @@ register_migraphx_ops(
     scatternd_add
     scatternd_mul
     scatternd_none
+    scatternd_max
+    scatternd_min
     select_module
     sigmoid
     sign
@@ -239,6 +241,7 @@ register_migraphx_ops(
     transpose
     unary_not
     undefined
+    unique
     unknown
     unsqueeze
     where
@@ -288,6 +291,7 @@ find_package(TBB QUIET)
 if(TBB_FOUND)
     check_execution_par(TBB_HAS_EXECUTION_PAR TBB::tbb)
     if(TBB_HAS_EXECUTION_PAR)
+        list(APPEND PACKAGE_DEPENDS PACKAGE TBB)
         target_link_libraries(migraphx PUBLIC TBB::tbb)
         set(MIGRAPHX_HAS_EXECUTORS_DEFAULT On)
         message(STATUS "Using TBB for parallel execution")

src/include/migraphx/bit_cast.hpp

@@ -21,10 +21,13 @@
  * ************************************************************************ */
 #ifndef MIGRAPHX_GUARD_RTGLIB_BITCAST_HPP
 #define MIGRAPHX_GUARD_RTGLIB_BITCAST_HPP
+#include <type_traits>
 #if defined(__GNUC__) && !defined(__clang__)
 #pragma GCC diagnostic push
 #pragma GCC diagnostic ignored "-Wstrict-aliasing"
 #endif
+
+#include <migraphx/requires.hpp>
 #include <migraphx/config.hpp>

 // NOLINTNEXTLINE(cppcoreguidelines-macro-usage)
@@ -32,7 +35,10 @@

 namespace migraphx {
 inline namespace MIGRAPHX_INLINE_NS {
-template <typename To, typename From>
+template <typename To,
+          typename From,
+          MIGRAPHX_REQUIRES(std::is_trivially_copyable<To>{} and
+                            std::is_trivially_copyable<From>{})>
 inline constexpr To bit_cast(From fr) noexcept
 {
     static_assert(sizeof(To) == sizeof(From));

src/include/migraphx/op/scatternd_max.hpp

+/*
+ * The MIT License (MIT)
+ *
+ * Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+ *
+ * Permission is hereby granted, free of charge, to any person obtaining a copy
+ * of this software and associated documentation files (the "Software"), to deal
+ * in the Software without restriction, including without limitation the rights
+ * to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+ * copies of the Software, and to permit persons to whom the Software is
+ * furnished to do so, subject to the following conditions:
+ *
+ * The above copyright notice and this permission notice shall be included in
+ * all copies or substantial portions of the Software.
+ *
+ * THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+ * IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+ * FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+ * AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+ * LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+ * OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+ * THE SOFTWARE.
+ */
+#ifndef MIGRAPHX_GUARD_OPERATORS_SCATTERND_MAX_HPP
+#define MIGRAPHX_GUARD_OPERATORS_SCATTERND_MAX_HPP
+
+#include <migraphx/op/scatternd_op.hpp>
+
+namespace migraphx {
+inline namespace MIGRAPHX_INLINE_NS {
+namespace op {
+
+struct scatternd_max : scatternd_op<scatternd_max>
+{
+    scatternd_max() {}
+
+    auto reduction() const
+    {
+        return [](auto& x, const auto& y) { x = std::max(x, y); };
+    }
+};
+
+} // namespace op
+} // namespace MIGRAPHX_INLINE_NS
+} // namespace migraphx
+
+#endif

src/include/migraphx/op/scatternd_min.hpp

+/*
+ * The MIT License (MIT)
+ *
+ * Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+ *
+ * Permission is hereby granted, free of charge, to any person obtaining a copy
+ * of this software and associated documentation files (the "Software"), to deal
+ * in the Software without restriction, including without limitation the rights
+ * to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+ * copies of the Software, and to permit persons to whom the Software is
+ * furnished to do so, subject to the following conditions:
+ *
+ * The above copyright notice and this permission notice shall be included in
+ * all copies or substantial portions of the Software.
+ *
+ * THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+ * IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+ * FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+ * AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+ * LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+ * OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+ * THE SOFTWARE.
+ */
+#ifndef MIGRAPHX_GUARD_OPERATORS_SCATTERND_MIN_HPP
+#define MIGRAPHX_GUARD_OPERATORS_SCATTERND_MIN_HPP
+
+#include <migraphx/op/scatternd_op.hpp>
+
+namespace migraphx {
+inline namespace MIGRAPHX_INLINE_NS {
+namespace op {
+
+struct scatternd_min : scatternd_op<scatternd_min>
+{
+    scatternd_min() {}
+
+    auto reduction() const
+    {
+        return [](auto& x, const auto& y) { x = std::min(x, y); };
+    }
+};
+
+} // namespace op
+} // namespace MIGRAPHX_INLINE_NS
+} // namespace migraphx
+
+#endif

src/include/migraphx/op/scatternd_op.hpp

@@ -121,7 +121,8 @@ struct scatternd_op : op_name<Derived>
                 auto k             = indices_shape.lens().back();
                 auto q             = indices_shape.ndim();
                 auto r             = dyn_out.computed_shape.ndim();
-                par_for(updates_shape.elements(), [&](const auto i) {
+                for(auto i = 0u; i < updates_shape.elements(); ++i)
+                {
                     auto updates_idx = updates_std.multi(i);
                     std::vector<std::size_t> indices_idx(q, 0);
                     std::copy(
@@ -135,7 +136,7 @@ struct scatternd_op : op_name<Derived>
                     std::copy(updates_idx.begin() + q - 1, updates_idx.end(), out_idx.begin() + k);

                     self.reduction()(output[dyn_out.computed_shape.index(out_idx)], updates[i]);
-                });
+                }
             });
         });


src/include/migraphx/op/unique.hpp

+/*
+ * The MIT License (MIT)
+ *
+ * Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+ *
+ * Permission is hereby granted, free of charge, to any person obtaining a copy
+ * of this software and associated documentation files (the "Software"), to deal
+ * in the Software without restriction, including without limitation the rights
+ * to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+ * copies of the Software, and to permit persons to whom the Software is
+ * furnished to do so, subject to the following conditions:
+ *
+ * The above copyright notice and this permission notice shall be included in
+ * all copies or substantial portions of the Software.
+ *
+ * THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+ * IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+ * FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+ * AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+ * LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+ * OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+ * THE SOFTWARE.
+ */
+
+#ifndef MIGRAPHX_GUARD_OPERATORS_UNIQUE_HPP
+#define MIGRAPHX_GUARD_OPERATORS_UNIQUE_HPP
+
+#include <migraphx/shape_for_each.hpp>
+#include <migraphx/check_shapes.hpp>
+#include <migraphx/config.hpp>
+#include <migraphx/argument.hpp>
+#include <migraphx/tune_axis.hpp>
+#include <utility>
+#include <map>
+#include <limits>
+#include <optional>
+
+namespace migraphx {
+inline namespace MIGRAPHX_INLINE_NS {
+namespace op {
+
+// https://onnx.ai/onnx/operators/onnx__Unique.html
+// The Onnx spec refers to numpy specification, used as a reference:
+// https://numpy.org/doc/stable/reference/generated/numpy.unique.html
+
+// Input : Given an array of elements : X.
+
+// Output(s) :
+// 1. Find the unique elements (Y) of input (X).
+//
+// There are three outputs in addition to the unique elements in Y:
+// 2. the indices of the input array that give the unique values
+// 3. the indices of the unique array that reconstruct the input array
+// 4. the number of times each unique value comes up in the input array
+
+// Optional Attribute: 'Sorted' = 1 for sorted; = 0 for unsorted.
+// Onnx specification makes 'sorted' a default, while Numpy always sorts.
+//
+// Optional Attribute: 'Axis' is 'None' (default) or a valid int < rank(X).
+// Negative values are allowed.
+//
+// Numpy has the following important note on Axis:
+// ------------------------------------------------------------------
+// When an axis is specified the subarrays indexed by the axis are
+// sorted. This is done by making the specified axis the first
+// dimension of the array (move the axis to the first dimension to
+// keep the order of the other axes) and then flattening the subarrays
+// in C order. The flattened subarrays are then viewed as a structured
+// type with each element given a label, with the effect that we end
+// up with a 1-D array of structured types that can be treated in the
+// same way as any other 1-D array. The result is that the flattened
+// subarrays are sorted in lexicographic order starting with the first
+// element.
+// ------------------------------------------------------------------
+
+struct unique
+{
+
+    template <class T>
+    auto make_idx_less_fn(const T& data, size_t chunk_sz) const
+    {
+        return [&data, chunk_sz](auto idx1, auto idx2) {
+            return std::lexicographical_compare(data.begin() + idx1,
+                                                data.begin() + idx1 + chunk_sz,
+                                                data.begin() + idx2,
+                                                data.begin() + idx2 + chunk_sz);
+        };
+    }
+
+    // CASE SORTED:
+    //
+    // To process into a sorted unique series of elements/chunks:
+    // Chunk size == 1 means a simple element; >1 means a flat representation.
+    // Steps: first go through the input elements/chunks for uniqueness.
+    // At the end of this processing, per the sorted sequence of unique elements:
+    // update/create data structures: y, y_indices, x_rev_indices, y_count
+    //
+    // INPUT x: [2, 1, 1, 3, 4, 3], attr_sorted = 1;
+
+    // OUTPUT(s): indices..
+    // y_indices: [1, 0, 3, 4]  --- first incidence, in terms of index in sequence x
+    // x_rev_indices: [1, 0, 0, 2, 3, 2] --- x seen in terms of indices of unique sequence y
+    // y_count: [2, 1, 2, 1] -- count at each y_index. sum = len(x)
+
+    // NOTE: y [1, 2, 3, 4]   --- the unique output is constructed from x[y_indices[...]]
+
+    template <class T>
+    auto sorted_uniq_indices(const T& input_data, size_t chunk_sz) const
+    {
+        struct y_info
+        {
+            size_t y_idx;
+            size_t x_idx;
+            size_t ct = 0;
+        };
+
+        auto idx_less_fn = make_idx_less_fn(input_data, chunk_sz);
+        std::map<size_t, y_info, decltype(idx_less_fn)> uniq_val_map(idx_less_fn);
+
+        std::tuple<std::vector<std::size_t>, std::vector<std::size_t>, std::vector<std::size_t>> rv;
+        auto& [y_indices, x_rev_indices, y_count] = rv;
+
+        // go through all the elements and find the unique elements..
+        size_t count_x = input_data.size();
+        for(size_t f_idx = 0, x_idx = 0; f_idx < count_x; f_idx += chunk_sz, x_idx++)
+        {
+            y_info entry          = {.y_idx = uniq_val_map.size(), .x_idx = x_idx};
+            auto [itr, added_new] = uniq_val_map.insert({f_idx, entry});
+            itr->second.ct++;
+            x_rev_indices.push_back(itr->second.y_idx);
+        }
+
+        std::vector<std::size_t> y2x_indices(uniq_val_map.size());
+        y_indices.resize(uniq_val_map.size());
+        y_count.resize(uniq_val_map.size());
+        size_t idx = 0;
+        // the unique elements are now sorted:
+        // post-processing for all the return indices.
+        for(const auto& v : uniq_val_map)
+        {
+            y2x_indices[v.second.y_idx] = idx;
+            y_indices[idx]              = v.second.x_idx;
+            y_count[idx]                = v.second.ct;
+            idx++;
+        }
+        // update x_rev_indices as per the sorted order of y_indices
+        for(auto& i : x_rev_indices)
+            i = y2x_indices[i];
+
+        return rv;
+    }
+
+    // CASE UNSORTED:
+    //
+    // To process into an un-sorted unique series of elements/chunks:
+    // For chunk size = 1 is a simple element, else use a flat representation of a tensor obj
+    // Go through the input elements/chunks one by one with inline processing of indices..
+
+    // INPUT x: [2, 1, 1, 3, 4, 3], attr_sorted = 0;
+
+    // OUTPUT(s): indices..
+    // y_indices: [0, 1, 3, 4]  --- first incidence, in terms of index in sequence x
+    // x_rev_indices: [0, 1, 1, 2, 3, 2] --- x seen in terms of indices of unique sequence y
+    // y_count: [1, 2, 2, 1] -- count at each y_index. sum = len(x)
+
+    // NOTE: y [2, 1, 3, 4]   --- the unique output is constructed from x[y_indices[...]]
+    // Output data structures: y_indices, x_rev_indices, y_count are processed inline.
+
+    template <class T>
+    auto unsorted_uniq_indices(const T& input_data, size_t chunk_sz) const
+    {
+        auto idx_less_fn = make_idx_less_fn(input_data, chunk_sz);
+        std::map<size_t, size_t, decltype(idx_less_fn)> uniq_val_map(idx_less_fn);
+
+        // rv is used for NVRO below..
+        std::tuple<std::vector<std::size_t>, std::vector<std::size_t>, std::vector<std::size_t>> rv;
+        auto& [y_indices, x_rev_indices, y_count] = rv;
+
+        // go through all the elements and add the unique elements into the map..
+        // inline processing for outputs: y_indices, x_rev_indices, y_count
+        size_t count_x = input_data.size();
+        for(size_t f_idx = 0; f_idx < count_x; f_idx += chunk_sz)
+        {
+            auto [itr, added_new] = uniq_val_map.insert({f_idx, y_indices.size()});
+            if(added_new)
+            {
+                y_count.push_back(0);
+                y_indices.push_back(x_rev_indices.size());
+            }
+            y_count[itr->second]++;
+            x_rev_indices.push_back(itr->second);
+        }
+
+        return rv;
+    }
+
+    // Axis. Default: none. Range: [-rank, rank-1]
+    std::optional<int64_t> axis;
+
+    // Sorted, Default: 1= sorted. 0 = unsorted.
+    bool sorted = true;
+
+    template <class Self, class F>
+    static auto reflect(Self& self, F f)
+    {
+        return pack(f(self.axis, "axis"), f(self.sorted, "sorted"));
+    }
+
+    std::string name() const { return "unique"; }
+
+    shape compute_shape(std::vector<shape> inputs) const
+    {
+        check_shapes{inputs, *this}.has(1);
+
+        auto& sh_x         = inputs[0];
+        auto lens_x        = sh_x.lens();
+        size_t dim_x       = sh_x.ndim();
+        size_t max_uniq_ct = sh_x.elements();
+        std::vector<shape::dynamic_dimension> d_out;
+
+        if(axis)
+        {
+            int64_t t_axis = migraphx::tune_axis(dim_x, *axis, name());
+            if(t_axis != 0)
+                MIGRAPHX_THROW("Unique: Only supports axis = 0 or None");
+
+            d_out = sh_x.to_dynamic().dyn_dims();
+            // only axis = 0 is supported:
+            max_uniq_ct = lens_x[0];
+            // min = 1 unique element; max = full dimension along axis 0
+            d_out[0] = {1, max_uniq_ct};
+        }
+        else
+        {
+            d_out.push_back({1, max_uniq_ct});
+        }
+
+        shape sh_y = {sh_x.type(), d_out};
+        // The three outputted Indices are just 1-D:
+        shape sh_idx{shape::int64_type, {d_out[0]}};
+
+        return {{sh_y, sh_idx, sh_idx, sh_idx}};
+    }
+
+    argument compute(const dyn_output& dyn_out, std::vector<argument> args) const
+    {
+        auto sh_x          = args.front().get_shape();
+        auto lens_x        = sh_x.lens();
+        shape output_shape = dyn_out.computed_shape;
+        auto vec_ss        = output_shape.sub_shapes();
+        auto ct_x          = sh_x.elements();
+        shape sh_y         = {vec_ss[0].type(), {ct_x}};
+        shape sh_idx       = {vec_ss[1].type(), {ct_x}};
+        shape sh_x_idx     = {vec_ss[1].type(), {ct_x}};
+
+        argument res_y{sh_y};
+        argument res_y_idx{sh_idx};
+        argument res_x_rev_idx{sh_idx};
+        argument res_y_ct_idx{sh_idx};
+
+        std::vector<size_t> out_y_idx;
+        std::vector<size_t> out_x_rev_idx;
+        std::vector<size_t> out_y_ct;
+
+        // If axis is not none, for >1D tensors, we have to consider
+        // then, the uniqueness of chunks of sub-tensors: a subsequence of built-ins..
+        // For a built-in type, chunk_sz is of course = 1
+        size_t chunk_sz = 1;
+        if(axis)
+            chunk_sz = ct_x / lens_x[0]; // axis = 0 is supported.
+
+        visit_all(args.front(), res_y)([&](auto x, auto y_flat) {
+            using o_type = typename decltype(x)::value_type;
+            std::vector<o_type> x_in(x.begin(), x.end());
+
+            std::tie(out_y_idx, out_x_rev_idx, out_y_ct) =
+                sorted ? sorted_uniq_indices(x_in, chunk_sz)
+                       : unsorted_uniq_indices(x_in, chunk_sz);
+
+            const auto uniq_ct = out_y_idx.size();
+
+            // construct y from x[indices] in flattened form
+            // later we reshape y to the final shape..
+            auto y_dst = y_flat.begin();
+            for(size_t idx = 0; idx < uniq_ct; idx++)
+                y_dst = copy_n(x_in.begin() + out_y_idx[idx] * chunk_sz, chunk_sz, y_dst);
+
+            std::vector<size_t> lens_y;
+            // if axis is specified:
+            // the output shape keeps the n-1 dimensions of x
+            if(axis)
+            {
+                lens_y    = lens_x;
+                lens_y[0] = uniq_ct;
+            }
+            else
+            {
+                lens_y = {uniq_ct};
+            }
+            sh_y   = {sh_y.type(), lens_y};
+            sh_idx = {sh_idx.type(), {uniq_ct}};
+        });
+
+        visit_all(res_y_idx, res_x_rev_idx, res_y_ct_idx)(
+            [&](auto y_indices, auto x_rev_indices, auto y_count) {
+                std::copy(out_y_idx.begin(), out_y_idx.end(), y_indices.begin());
+                std::copy(out_x_rev_idx.begin(), out_x_rev_idx.end(), x_rev_indices.begin());
+                std::copy(out_y_ct.begin(), out_y_ct.end(), y_count.begin());
+                sh_x_idx = {sh_idx.type(), {out_x_rev_idx.size()}};
+            });
+
+        return {{res_y.reshape(sh_y),
+                 res_y_idx.reshape(sh_idx),
+                 res_x_rev_idx.reshape(sh_x_idx),
+                 res_y_ct_idx.reshape(sh_idx)}};
+    }
+};
+
+} // namespace op
+} // namespace MIGRAPHX_INLINE_NS
+} // namespace migraphx
+
+#endif
