提交RetinaFace推理示例

README.md

-# RetinaFace_MIGraphX
+# RetinaFace

-构建RetinaFace推理示例
+## 模型介绍
\ No newline at end of file
+
+RetinaFace是一个经典的人脸检测模型(https://arxiv.org/abs/1905.00641)，采用了SSD架构。
+
+## 模型结构
+
+RetinaFace模型 有几个主要特点：
+
+- 采用 FPN 特征金字塔提取多尺度特征；
+- 引入 SSH 算法的 Context Modeling；
+- 多任务训练，提供额外的监督信息。
+
+## 推理
+
+### 环境配置
+
+在[光源](https://www.sourcefind.cn/#/image/dcu/custom)可拉取用于推理的docker镜像，RetinaFace 模型推理推荐的镜像如下：
+
+```
+docker pull image.sourcefind.cn:5000/dcu/admin/base/custom:ort_dcu_1.14.0_migraphx2.5.2_dtk22.10.1
+```
+
+在[光合开发者社区](https://cancon.hpccube.com:65024/4/main/)可下载MIGraphX安装包，python依赖安装：
+
+```
+pip install -r requirements.txt
+```
+
+安装DTK版的Pytorch和torchvision，下载地址：https://cancon.hpccube.com:65024/4/main/pytorch，https://cancon.hpccube.com:65024/4/main/vision
+
+### 运行示例
+
+RetinaFace模型的推理示例程序是RetinaFace_infer_migraphx.py，使用如下命令运行该推理示例：
+
+```
+python RetinaFace_infer_migraphx.py
+```
+
+程序运行结束会在当前目录生成RetinaFace检测结果图像。
+
+<img src="./curve/Result.jpg" alt="Result" style="zoom: 50%;" />
+
+## 历史版本
+
+​		https://developer.hpccube.com/codes/modelzoo/retinaface_migraphx
+
+## 参考
+
+​		https://github.com/biubug6/Pytorch_Retinaface

RetinaFace_infer_migraphx.py

+from __future__ import print_function
+import os
+import argparse
+import torch
+import torch.backends.cudnn as cudnn
+import numpy as np
+from data import cfg_mnet, cfg_re50
+from layers.functions.prior_box import PriorBox
+from utils.nms.py_cpu_nms import py_cpu_nms
+import cv2
+from utils.box_utils import decode, decode_landm
+import time
+import migraphx
+
+parser = argparse.ArgumentParser(description='Retinaface')
+
+parser.add_argument('-m', '--trained_model', default='./weights/mobilenet0.25_Final.pth',
+                    type=str, help='Trained state_dict file path to open')
+parser.add_argument('--network', default='mobile0.25', help='Backbone network mobile0.25 or resnet50')
+parser.add_argument('--cpu', action="store_true", default=False, help='Use cpu inference')
+parser.add_argument('--confidence_threshold', default=0.85, type=float, help='confidence_threshold')
+parser.add_argument('--top_k', default=5000, type=int, help='top_k')
+parser.add_argument('--nms_threshold', default=0.4, type=float, help='nms_threshold')
+parser.add_argument('--keep_top_k', default=750, type=int, help='keep_top_k')
+parser.add_argument('-s', '--save_image', action="store_true", default=True, help='show detection results')
+parser.add_argument('--vis_thres', default=0.6, type=float, help='visualization_threshold')
+args = parser.parse_args()
+
+def migraphx_run(model,cpu,data_tensor):
+    # 将输入的tensor数据转换为numpy
+    if cpu:
+        data_numpy=data_tensor.cpu().numpy()
+        device = torch.device("cpu")
+    else:
+        data_numpy=data_tensor.detach().cpu().numpy()
+        device = torch.device("cuda")
+
+    img_data = np.zeros(data_numpy.shape).astype("float32")
+    for i in range(data_numpy.shape[0]):
+        img_data[i, :, :, :] = data_numpy[i, :, :, :]
+
+    # 执行推理
+    result = model.run({model.get_parameter_names()[0]: migraphx.argument(img_data)})
+
+    # 将结果转换为tensor
+    result0=torch.from_numpy(np.array(result[0], copy=False)).to(device)
+    result1=torch.from_numpy(np.array(result[1], copy=False)).to(device)
+    result2=torch.from_numpy(np.array(result[2], copy=False)).to(device)
+
+    return (result0,result1,result2)
+
+
+if __name__ == '__main__':
+    # 加载模型
+    cfg = None
+    if args.network == "mobile0.25":
+        cfg = cfg_mnet
+    elif args.network == "resnet50":
+        cfg = cfg_re50
+    device = torch.device("cpu" if args.cpu else "cuda")
+    model = migraphx.parse_onnx("./FaceDetector.onnx")
+    inputName=model.get_parameter_names()[0]
+    inputShape=model.get_parameter_shapes()[inputName].lens()
+    print("inputName:{0} \ninputShape:{1}".format(inputName,inputShape))
+
+    # FP16
+    # migraphx.quantize_fp16(model)
+
+    # 编译
+    model.compile(t=migraphx.get_target("gpu"),device_id=0) # device_id: 设置GPU设备，默认为0号设备
+
+    resize = 1
+
+    # testing begin
+    for i in range(100):
+        # resize到onnx模型输入大小
+        image_path = "./curve/test.jpg"
+        img_raw = cv2.imread(image_path, cv2.IMREAD_COLOR)
+        img_raw = cv2.resize(img_raw, (640,640))
+
+        img = np.float32(img_raw)
+
+        im_height, im_width, _ = img.shape
+        scale = torch.Tensor([img.shape[1], img.shape[0], img.shape[1], img.shape[0]])
+        img -= (104, 117, 123)
+        img = img.transpose(2, 0, 1)
+        img = torch.from_numpy(img).unsqueeze(0)
+        img = img.to(device)
+        scale = scale.to(device)
+
+        tic = time.time()
+        loc, conf, landms = migraphx_run(model,args.cpu,img)  # forward pass
+        print('net forward time: {:.4f}'.format(time.time() - tic))
+
+        priorbox = PriorBox(cfg, image_size=(im_height, im_width))
+        priors = priorbox.forward()
+        priors = priors.to(device)
+        prior_data = priors.data
+        boxes = decode(loc.data.squeeze(0), prior_data, cfg['variance'])
+        boxes = boxes * scale / resize
+        boxes = boxes.cpu().numpy()
+        scores = conf.squeeze(0).data.cpu().numpy()[:, 1]
+        landms = decode_landm(landms.data.squeeze(0), prior_data, cfg['variance'])
+        scale1 = torch.Tensor([img.shape[3], img.shape[2], img.shape[3], img.shape[2],
+                               img.shape[3], img.shape[2], img.shape[3], img.shape[2],
+                               img.shape[3], img.shape[2]])
+        scale1 = scale1.to(device)
+        landms = landms * scale1 / resize
+        landms = landms.cpu().numpy()
+
+        # ignore low scores
+        inds = np.where(scores > args.confidence_threshold)[0]
+        boxes = boxes[inds]
+        landms = landms[inds]
+        scores = scores[inds]
+
+        # keep top-K before NMS
+        order = scores.argsort()[::-1][:args.top_k]
+        boxes = boxes[order]
+        landms = landms[order]
+        scores = scores[order]
+
+        # do NMS
+        dets = np.hstack((boxes, scores[:, np.newaxis])).astype(np.float32, copy=False)
+        keep = py_cpu_nms(dets, args.nms_threshold)
+        # keep = nms(dets, args.nms_threshold,force_cpu=args.cpu)
+        dets = dets[keep, :]
+        landms = landms[keep]
+
+        # keep top-K faster NMS
+        dets = dets[:args.keep_top_k, :]
+        landms = landms[:args.keep_top_k, :]
+
+        dets = np.concatenate((dets, landms), axis=1)
+
+        # show image
+        if args.save_image:
+            for b in dets:
+                if b[4] < args.vis_thres:
+                    continue
+                text = "{:.4f}".format(b[4])
+                b = list(map(int, b))
+                cv2.rectangle(img_raw, (b[0], b[1]), (b[2], b[3]), (0, 0, 255), 2)
+                cx = b[0]
+                cy = b[1] + 12
+                cv2.putText(img_raw, text, (cx, cy),
+                            cv2.FONT_HERSHEY_DUPLEX, 0.5, (255, 255, 255))
+
+                # landms
+                cv2.circle(img_raw, (b[5], b[6]), 1, (0, 0, 255), 4)
+                cv2.circle(img_raw, (b[7], b[8]), 1, (0, 255, 255), 4)
+                cv2.circle(img_raw, (b[9], b[10]), 1, (255, 0, 255), 4)
+                cv2.circle(img_raw, (b[11], b[12]), 1, (0, 255, 0), 4)
+                cv2.circle(img_raw, (b[13], b[14]), 1, (255, 0, 0), 4)
+            # save image
+
+            name = "test.jpg"
+            cv2.imwrite(name, img_raw)
+

convert_to_onnx.py

+from __future__ import print_function
+import os
+import argparse
+import torch
+import torch.backends.cudnn as cudnn
+import numpy as np
+from data import cfg_mnet, cfg_re50
+from layers.functions.prior_box import PriorBox
+from utils.nms.py_cpu_nms import py_cpu_nms
+import cv2
+from models.retinaface import RetinaFace
+from utils.box_utils import decode, decode_landm
+from utils.timer import Timer
+
+
+parser = argparse.ArgumentParser(description='Test')
+parser.add_argument('-m', '--trained_model', default='./weights/mobilenet0.25_Final.pth',
+                    type=str, help='Trained state_dict file path to open')
+parser.add_argument('--network', default='mobile0.25', help='Backbone network mobile0.25 or resnet50')
+parser.add_argument('--long_side', default=640, help='when origin_size is false, long_side is scaled size(320 or 640 for long side)')
+parser.add_argument('--cpu', action="store_true", default=True, help='Use cpu inference')
+
+args = parser.parse_args()
+
+
+def check_keys(model, pretrained_state_dict):
+    ckpt_keys = set(pretrained_state_dict.keys())
+    model_keys = set(model.state_dict().keys())
+    used_pretrained_keys = model_keys & ckpt_keys
+    unused_pretrained_keys = ckpt_keys - model_keys
+    missing_keys = model_keys - ckpt_keys
+    print('Missing keys:{}'.format(len(missing_keys)))
+    print('Unused checkpoint keys:{}'.format(len(unused_pretrained_keys)))
+    print('Used keys:{}'.format(len(used_pretrained_keys)))
+    assert len(used_pretrained_keys) > 0, 'load NONE from pretrained checkpoint'
+    return True
+
+
+def remove_prefix(state_dict, prefix):
+    ''' Old style model is stored with all names of parameters sharing common prefix 'module.' '''
+    print('remove prefix \'{}\''.format(prefix))
+    f = lambda x: x.split(prefix, 1)[-1] if x.startswith(prefix) else x
+    return {f(key): value for key, value in state_dict.items()}
+
+
+def load_model(model, pretrained_path, load_to_cpu):
+    print('Loading pretrained model from {}'.format(pretrained_path))
+    if load_to_cpu:
+        pretrained_dict = torch.load(pretrained_path, map_location=lambda storage, loc: storage)
+    else:
+        device = torch.cuda.current_device()
+        pretrained_dict = torch.load(pretrained_path, map_location=lambda storage, loc: storage.cuda(device))
+    if "state_dict" in pretrained_dict.keys():
+        pretrained_dict = remove_prefix(pretrained_dict['state_dict'], 'module.')
+    else:
+        pretrained_dict = remove_prefix(pretrained_dict, 'module.')
+    check_keys(model, pretrained_dict)
+    model.load_state_dict(pretrained_dict, strict=False)
+    return model
+
+
+if __name__ == '__main__':
+    torch.set_grad_enabled(False)
+    cfg = None
+    if args.network == "mobile0.25":
+        cfg = cfg_mnet
+    elif args.network == "resnet50":
+        cfg = cfg_re50
+    # net and model
+    net = RetinaFace(cfg=cfg, phase = 'test')
+    net = load_model(net, args.trained_model, args.cpu)
+    net.eval()
+    print('Finished loading model!')
+    print(net)
+    device = torch.device("cpu" if args.cpu else "cuda")
+    net = net.to(device)
+
+    # ------------------------ export -----------------------------
+    output_onnx = 'FaceDetector.onnx'
+    print("==> Exporting model to ONNX format at '{}'".format(output_onnx))
+    input_names = ["input0"]
+    output_names = ["output0"]
+    inputs = torch.randn(1, 3, args.long_side, args.long_side).to(device)
+
+    torch_out = torch.onnx._export(net, inputs, output_onnx, export_params=True, verbose=False,
+                                   input_names=input_names, output_names=output_names)
+
+

data/__init__.py

+from .wider_face import WiderFaceDetection, detection_collate
+from .data_augment import *
+from .config import *

data/config.py

+# config.py
+
+cfg_mnet = {
+    'name': 'mobilenet0.25',
+    'min_sizes': [[16, 32], [64, 128], [256, 512]],
+    'steps': [8, 16, 32],
+    'variance': [0.1, 0.2],
+    'clip': False,
+    'loc_weight': 2.0,
+    'gpu_train': True,
+    'batch_size': 32,
+    'ngpu': 1,
+    'epoch': 250,
+    'decay1': 190,
+    'decay2': 220,
+    'image_size': 640,
+    'pretrain': False,
+    'return_layers': {'stage1': 1, 'stage2': 2, 'stage3': 3},
+    'in_channel': 32,
+    'out_channel': 64
+}
+
+cfg_re50 = {
+    'name': 'Resnet50',
+    'min_sizes': [[16, 32], [64, 128], [256, 512]],
+    'steps': [8, 16, 32],
+    'variance': [0.1, 0.2],
+    'clip': False,
+    'loc_weight': 2.0,
+    'gpu_train': True,
+    'batch_size': 24,
+    'ngpu': 4,
+    'epoch': 100,
+    'decay1': 70,
+    'decay2': 90,
+    'image_size': 840,
+    'pretrain': True,
+    'return_layers': {'layer2': 1, 'layer3': 2, 'layer4': 3},
+    'in_channel': 256,
+    'out_channel': 256
+}
+

data/data_augment.py

+import cv2
+import numpy as np
+import random
+from utils.box_utils import matrix_iof
+
+
+def _crop(image, boxes, labels, landm, img_dim):
+    height, width, _ = image.shape
+    pad_image_flag = True
+
+    for _ in range(250):
+        """
+        if random.uniform(0, 1) <= 0.2:
+            scale = 1.0
+        else:
+            scale = random.uniform(0.3, 1.0)
+        """
+        PRE_SCALES = [0.3, 0.45, 0.6, 0.8, 1.0]
+        scale = random.choice(PRE_SCALES)
+        short_side = min(width, height)
+        w = int(scale * short_side)
+        h = w
+
+        if width == w:
+            l = 0
+        else:
+            l = random.randrange(width - w)
+        if height == h:
+            t = 0
+        else:
+            t = random.randrange(height - h)
+        roi = np.array((l, t, l + w, t + h))
+
+        value = matrix_iof(boxes, roi[np.newaxis])
+        flag = (value >= 1)
+        if not flag.any():
+            continue
+
+        centers = (boxes[:, :2] + boxes[:, 2:]) / 2
+        mask_a = np.logical_and(roi[:2] < centers, centers < roi[2:]).all(axis=1)
+        boxes_t = boxes[mask_a].copy()
+        labels_t = labels[mask_a].copy()
+        landms_t = landm[mask_a].copy()
+        landms_t = landms_t.reshape([-1, 5, 2])
+
+        if boxes_t.shape[0] == 0:
+            continue
+
+        image_t = image[roi[1]:roi[3], roi[0]:roi[2]]
+
+        boxes_t[:, :2] = np.maximum(boxes_t[:, :2], roi[:2])
+        boxes_t[:, :2] -= roi[:2]
+        boxes_t[:, 2:] = np.minimum(boxes_t[:, 2:], roi[2:])
+        boxes_t[:, 2:] -= roi[:2]
+
+        # landm
+        landms_t[:, :, :2] = landms_t[:, :, :2] - roi[:2]
+        landms_t[:, :, :2] = np.maximum(landms_t[:, :, :2], np.array([0, 0]))
+        landms_t[:, :, :2] = np.minimum(landms_t[:, :, :2], roi[2:] - roi[:2])
+        landms_t = landms_t.reshape([-1, 10])
+
+
+	# make sure that the cropped image contains at least one face > 16 pixel at training image scale
+        b_w_t = (boxes_t[:, 2] - boxes_t[:, 0] + 1) / w * img_dim
+        b_h_t = (boxes_t[:, 3] - boxes_t[:, 1] + 1) / h * img_dim
+        mask_b = np.minimum(b_w_t, b_h_t) > 0.0
+        boxes_t = boxes_t[mask_b]
+        labels_t = labels_t[mask_b]
+        landms_t = landms_t[mask_b]
+
+        if boxes_t.shape[0] == 0:
+            continue
+
+        pad_image_flag = False
+
+        return image_t, boxes_t, labels_t, landms_t, pad_image_flag
+    return image, boxes, labels, landm, pad_image_flag
+
+
+def _distort(image):
+
+    def _convert(image, alpha=1, beta=0):
+        tmp = image.astype(float) * alpha + beta
+        tmp[tmp < 0] = 0
+        tmp[tmp > 255] = 255
+        image[:] = tmp
+
+    image = image.copy()
+
+    if random.randrange(2):
+
+        #brightness distortion
+        if random.randrange(2):
+            _convert(image, beta=random.uniform(-32, 32))
+
+        #contrast distortion
+        if random.randrange(2):
+            _convert(image, alpha=random.uniform(0.5, 1.5))
+
+        image = cv2.cvtColor(image, cv2.COLOR_BGR2HSV)
+
+        #saturation distortion
+        if random.randrange(2):
+            _convert(image[:, :, 1], alpha=random.uniform(0.5, 1.5))
+
+        #hue distortion
+        if random.randrange(2):
+            tmp = image[:, :, 0].astype(int) + random.randint(-18, 18)
+            tmp %= 180
+            image[:, :, 0] = tmp
+
+        image = cv2.cvtColor(image, cv2.COLOR_HSV2BGR)
+
+    else:
+
+        #brightness distortion
+        if random.randrange(2):
+            _convert(image, beta=random.uniform(-32, 32))
+
+        image = cv2.cvtColor(image, cv2.COLOR_BGR2HSV)
+
+        #saturation distortion
+        if random.randrange(2):
+            _convert(image[:, :, 1], alpha=random.uniform(0.5, 1.5))
+
+        #hue distortion
+        if random.randrange(2):
+            tmp = image[:, :, 0].astype(int) + random.randint(-18, 18)
+            tmp %= 180
+            image[:, :, 0] = tmp
+
+        image = cv2.cvtColor(image, cv2.COLOR_HSV2BGR)
+
+        #contrast distortion
+        if random.randrange(2):
+            _convert(image, alpha=random.uniform(0.5, 1.5))
+
+    return image
+
+
+def _expand(image, boxes, fill, p):
+    if random.randrange(2):
+        return image, boxes
+
+    height, width, depth = image.shape
+
+    scale = random.uniform(1, p)
+    w = int(scale * width)
+    h = int(scale * height)
+
+    left = random.randint(0, w - width)
+    top = random.randint(0, h - height)
+
+    boxes_t = boxes.copy()
+    boxes_t[:, :2] += (left, top)
+    boxes_t[:, 2:] += (left, top)
+    expand_image = np.empty(
+        (h, w, depth),
+        dtype=image.dtype)
+    expand_image[:, :] = fill
+    expand_image[top:top + height, left:left + width] = image
+    image = expand_image
+
+    return image, boxes_t
+
+
+def _mirror(image, boxes, landms):
+    _, width, _ = image.shape
+    if random.randrange(2):
+        image = image[:, ::-1]
+        boxes = boxes.copy()
+        boxes[:, 0::2] = width - boxes[:, 2::-2]
+
+        # landm
+        landms = landms.copy()
+        landms = landms.reshape([-1, 5, 2])
+        landms[:, :, 0] = width - landms[:, :, 0]
+        tmp = landms[:, 1, :].copy()
+        landms[:, 1, :] = landms[:, 0, :]
+        landms[:, 0, :] = tmp
+        tmp1 = landms[:, 4, :].copy()
+        landms[:, 4, :] = landms[:, 3, :]
+        landms[:, 3, :] = tmp1
+        landms = landms.reshape([-1, 10])
+
+    return image, boxes, landms
+
+
+def _pad_to_square(image, rgb_mean, pad_image_flag):
+    if not pad_image_flag:
+        return image
+    height, width, _ = image.shape
+    long_side = max(width, height)
+    image_t = np.empty((long_side, long_side, 3), dtype=image.dtype)
+    image_t[:, :] = rgb_mean
+    image_t[0:0 + height, 0:0 + width] = image
+    return image_t
+
+
+def _resize_subtract_mean(image, insize, rgb_mean):
+    interp_methods = [cv2.INTER_LINEAR, cv2.INTER_CUBIC, cv2.INTER_AREA, cv2.INTER_NEAREST, cv2.INTER_LANCZOS4]
+    interp_method = interp_methods[random.randrange(5)]
+    image = cv2.resize(image, (insize, insize), interpolation=interp_method)
+    image = image.astype(np.float32)
+    image -= rgb_mean
+    return image.transpose(2, 0, 1)
+
+
+class preproc(object):
+
+    def __init__(self, img_dim, rgb_means):
+        self.img_dim = img_dim
+        self.rgb_means = rgb_means
+
+    def __call__(self, image, targets):
+        assert targets.shape[0] > 0, "this image does not have gt"
+
+        boxes = targets[:, :4].copy()
+        labels = targets[:, -1].copy()
+        landm = targets[:, 4:-1].copy()
+
+        image_t, boxes_t, labels_t, landm_t, pad_image_flag = _crop(image, boxes, labels, landm, self.img_dim)
+        image_t = _distort(image_t)
+        image_t = _pad_to_square(image_t,self.rgb_means, pad_image_flag)
+        image_t, boxes_t, landm_t = _mirror(image_t, boxes_t, landm_t)
+        height, width, _ = image_t.shape
+        image_t = _resize_subtract_mean(image_t, self.img_dim, self.rgb_means)
+        boxes_t[:, 0::2] /= width
+        boxes_t[:, 1::2] /= height
+
+        landm_t[:, 0::2] /= width
+        landm_t[:, 1::2] /= height
+
+        labels_t = np.expand_dims(labels_t, 1)
+        targets_t = np.hstack((boxes_t, landm_t, labels_t))
+
+        return image_t, targets_t

data/wider_face.py

+import os
+import os.path
+import sys
+import torch
+import torch.utils.data as data
+import cv2
+import numpy as np
+
+class WiderFaceDetection(data.Dataset):
+    def __init__(self, txt_path, preproc=None):
+        self.preproc = preproc
+        self.imgs_path = []
+        self.words = []
+        f = open(txt_path,'r')
+        lines = f.readlines()
+        isFirst = True
+        labels = []
+        for line in lines:
+            line = line.rstrip()
+            if line.startswith('#'):
+                if isFirst is True:
+                    isFirst = False
+                else:
+                    labels_copy = labels.copy()
+                    self.words.append(labels_copy)
+                    labels.clear()
+                path = line[2:]
+                path = txt_path.replace('label.txt','images/') + path
+                self.imgs_path.append(path)
+            else:
+                line = line.split(' ')
+                label = [float(x) for x in line]
+                labels.append(label)
+
+        self.words.append(labels)
+
+    def __len__(self):
+        return len(self.imgs_path)
+
+    def __getitem__(self, index):
+        img = cv2.imread(self.imgs_path[index])
+        height, width, _ = img.shape
+
+        labels = self.words[index]
+        annotations = np.zeros((0, 15))
+        if len(labels) == 0:
+            return annotations
+        for idx, label in enumerate(labels):
+            annotation = np.zeros((1, 15))
+            # bbox
+            annotation[0, 0] = label[0]  # x1
+            annotation[0, 1] = label[1]  # y1
+            annotation[0, 2] = label[0] + label[2]  # x2
+            annotation[0, 3] = label[1] + label[3]  # y2
+
+            # landmarks
+            annotation[0, 4] = label[4]    # l0_x
+            annotation[0, 5] = label[5]    # l0_y
+            annotation[0, 6] = label[7]    # l1_x
+            annotation[0, 7] = label[8]    # l1_y
+            annotation[0, 8] = label[10]   # l2_x
+            annotation[0, 9] = label[11]   # l2_y
+            annotation[0, 10] = label[13]  # l3_x
+            annotation[0, 11] = label[14]  # l3_y
+            annotation[0, 12] = label[16]  # l4_x
+            annotation[0, 13] = label[17]  # l4_y
+            if (annotation[0, 4]<0):
+                annotation[0, 14] = -1
+            else:
+                annotation[0, 14] = 1
+
+            annotations = np.append(annotations, annotation, axis=0)
+        target = np.array(annotations)
+        if self.preproc is not None:
+            img, target = self.preproc(img, target)
+
+        return torch.from_numpy(img), target
+
+def detection_collate(batch):
+    """Custom collate fn for dealing with batches of images that have a different
+    number of associated object annotations (bounding boxes).
+
+    Arguments:
+        batch: (tuple) A tuple of tensor images and lists of annotations
+
+    Return:
+        A tuple containing:
+            1) (tensor) batch of images stacked on their 0 dim
+            2) (list of tensors) annotations for a given image are stacked on 0 dim
+    """
+    targets = []
+    imgs = []
+    for _, sample in enumerate(batch):
+        for _, tup in enumerate(sample):
+            if torch.is_tensor(tup):
+                imgs.append(tup)
+            elif isinstance(tup, type(np.empty(0))):
+                annos = torch.from_numpy(tup).float()
+                targets.append(annos)
+
+    return (torch.stack(imgs, 0), targets)

layers/__init__.py

+from .functions import *
+from .modules import *

layers/functions/prior_box.py

+import torch
+from itertools import product as product
+import numpy as np
+from math import ceil
+
+
+class PriorBox(object):
+    def __init__(self, cfg, image_size=None, phase='train'):
+        super(PriorBox, self).__init__()
+        self.min_sizes = cfg['min_sizes']
+        self.steps = cfg['steps']
+        self.clip = cfg['clip']
+        self.image_size = image_size
+        self.feature_maps = [[ceil(self.image_size[0]/step), ceil(self.image_size[1]/step)] for step in self.steps]
+        self.name = "s"
+
+    def forward(self):
+        anchors = []
+        for k, f in enumerate(self.feature_maps):
+            min_sizes = self.min_sizes[k]
+            for i, j in product(range(f[0]), range(f[1])):
+                for min_size in min_sizes:
+                    s_kx = min_size / self.image_size[1]
+                    s_ky = min_size / self.image_size[0]
+                    dense_cx = [x * self.steps[k] / self.image_size[1] for x in [j + 0.5]]
+                    dense_cy = [y * self.steps[k] / self.image_size[0] for y in [i + 0.5]]
+                    for cy, cx in product(dense_cy, dense_cx):
+                        anchors += [cx, cy, s_kx, s_ky]
+
+        # back to torch land
+        output = torch.Tensor(anchors).view(-1, 4)
+        if self.clip:
+            output.clamp_(max=1, min=0)
+        return output

layers/modules/__init__.py

+from .multibox_loss import MultiBoxLoss
+
+__all__ = ['MultiBoxLoss']

layers/modules/multibox_loss.py

+import torch
+import torch.nn as nn
+import torch.nn.functional as F
+from torch.autograd import Variable
+from utils.box_utils import match, log_sum_exp
+from data import cfg_mnet
+GPU = cfg_mnet['gpu_train']
+
+class MultiBoxLoss(nn.Module):
+    """SSD Weighted Loss Function
+    Compute Targets:
+        1) Produce Confidence Target Indices by matching  ground truth boxes
+           with (default) 'priorboxes' that have jaccard index > threshold parameter
+           (default threshold: 0.5).
+        2) Produce localization target by 'encoding' variance into offsets of ground
+           truth boxes and their matched  'priorboxes'.
+        3) Hard negative mining to filter the excessive number of negative examples
+           that comes with using a large number of default bounding boxes.
+           (default negative:positive ratio 3:1)
+    Objective Loss:
+        L(x,c,l,g) = (Lconf(x, c) + αLloc(x,l,g)) / N
+        Where, Lconf is the CrossEntropy Loss and Lloc is the SmoothL1 Loss
+        weighted by α which is set to 1 by cross val.
+        Args:
+            c: class confidences,
+            l: predicted boxes,
+            g: ground truth boxes
+            N: number of matched default boxes
+        See: https://arxiv.org/pdf/1512.02325.pdf for more details.
+    """
+
+    def __init__(self, num_classes, overlap_thresh, prior_for_matching, bkg_label, neg_mining, neg_pos, neg_overlap, encode_target):
+        super(MultiBoxLoss, self).__init__()
+        self.num_classes = num_classes
+        self.threshold = overlap_thresh
+        self.background_label = bkg_label
+        self.encode_target = encode_target
+        self.use_prior_for_matching = prior_for_matching
+        self.do_neg_mining = neg_mining
+        self.negpos_ratio = neg_pos
+        self.neg_overlap = neg_overlap
+        self.variance = [0.1, 0.2]
+
+    def forward(self, predictions, priors, targets):
+        """Multibox Loss
+        Args:
+            predictions (tuple): A tuple containing loc preds, conf preds,
+            and prior boxes from SSD net.
+                conf shape: torch.size(batch_size,num_priors,num_classes)
+                loc shape: torch.size(batch_size,num_priors,4)
+                priors shape: torch.size(num_priors,4)
+
+            ground_truth (tensor): Ground truth boxes and labels for a batch,
+                shape: [batch_size,num_objs,5] (last idx is the label).
+        """
+
+        loc_data, conf_data, landm_data = predictions
+        priors = priors
+        num = loc_data.size(0)
+        num_priors = (priors.size(0))
+
+        # match priors (default boxes) and ground truth boxes
+        loc_t = torch.Tensor(num, num_priors, 4)
+        landm_t = torch.Tensor(num, num_priors, 10)
+        conf_t = torch.LongTensor(num, num_priors)
+        for idx in range(num):
+            truths = targets[idx][:, :4].data
+            labels = targets[idx][:, -1].data
+            landms = targets[idx][:, 4:14].data
+            defaults = priors.data
+            match(self.threshold, truths, defaults, self.variance, labels, landms, loc_t, conf_t, landm_t, idx)
+        if GPU:
+            loc_t = loc_t.cuda()
+            conf_t = conf_t.cuda()
+            landm_t = landm_t.cuda()
+
+        zeros = torch.tensor(0).cuda()
+        # landm Loss (Smooth L1)
+        # Shape: [batch,num_priors,10]
+        pos1 = conf_t > zeros
+        num_pos_landm = pos1.long().sum(1, keepdim=True)
+        N1 = max(num_pos_landm.data.sum().float(), 1)
+        pos_idx1 = pos1.unsqueeze(pos1.dim()).expand_as(landm_data)
+        landm_p = landm_data[pos_idx1].view(-1, 10)
+        landm_t = landm_t[pos_idx1].view(-1, 10)
+        loss_landm = F.smooth_l1_loss(landm_p, landm_t, reduction='sum')
+
+
+        pos = conf_t != zeros
+        conf_t[pos] = 1
+
+        # Localization Loss (Smooth L1)
+        # Shape: [batch,num_priors,4]
+        pos_idx = pos.unsqueeze(pos.dim()).expand_as(loc_data)
+        loc_p = loc_data[pos_idx].view(-1, 4)
+        loc_t = loc_t[pos_idx].view(-1, 4)
+        loss_l = F.smooth_l1_loss(loc_p, loc_t, reduction='sum')
+
+        # Compute max conf across batch for hard negative mining
+        batch_conf = conf_data.view(-1, self.num_classes)
+        loss_c = log_sum_exp(batch_conf) - batch_conf.gather(1, conf_t.view(-1, 1))
+
+        # Hard Negative Mining
+        loss_c[pos.view(-1, 1)] = 0 # filter out pos boxes for now
+        loss_c = loss_c.view(num, -1)
+        _, loss_idx = loss_c.sort(1, descending=True)
+        _, idx_rank = loss_idx.sort(1)
+        num_pos = pos.long().sum(1, keepdim=True)
+        num_neg = torch.clamp(self.negpos_ratio*num_pos, max=pos.size(1)-1)
+        neg = idx_rank < num_neg.expand_as(idx_rank)
+
+        # Confidence Loss Including Positive and Negative Examples
+        pos_idx = pos.unsqueeze(2).expand_as(conf_data)
+        neg_idx = neg.unsqueeze(2).expand_as(conf_data)
+        conf_p = conf_data[(pos_idx+neg_idx).gt(0)].view(-1,self.num_classes)
+        targets_weighted = conf_t[(pos+neg).gt(0)]
+        loss_c = F.cross_entropy(conf_p, targets_weighted, reduction='sum')
+
+        # Sum of losses: L(x,c,l,g) = (Lconf(x, c) + αLloc(x,l,g)) / N
+        N = max(num_pos.data.sum().float(), 1)
+        loss_l /= N
+        loss_c /= N
+        loss_landm /= N1
+
+        return loss_l, loss_c, loss_landm

models/net.py

+import time
+import torch
+import torch.nn as nn
+import torchvision.models._utils as _utils
+import torchvision.models as models
+import torch.nn.functional as F
+from torch.autograd import Variable
+
+def conv_bn(inp, oup, stride = 1, leaky = 0):
+    return nn.Sequential(
+        nn.Conv2d(inp, oup, 3, stride, 1, bias=False),
+        nn.BatchNorm2d(oup),
+        nn.LeakyReLU(negative_slope=leaky, inplace=True)
+    )
+
+def conv_bn_no_relu(inp, oup, stride):
+    return nn.Sequential(
+        nn.Conv2d(inp, oup, 3, stride, 1, bias=False),
+        nn.BatchNorm2d(oup),
+    )
+
+def conv_bn1X1(inp, oup, stride, leaky=0):
+    return nn.Sequential(
+        nn.Conv2d(inp, oup, 1, stride, padding=0, bias=False),
+        nn.BatchNorm2d(oup),
+        nn.LeakyReLU(negative_slope=leaky, inplace=True)
+    )
+
+def conv_dw(inp, oup, stride, leaky=0.1):
+    return nn.Sequential(
+        nn.Conv2d(inp, inp, 3, stride, 1, groups=inp, bias=False),
+        nn.BatchNorm2d(inp),
+        nn.LeakyReLU(negative_slope= leaky,inplace=True),
+
+        nn.Conv2d(inp, oup, 1, 1, 0, bias=False),
+        nn.BatchNorm2d(oup),
+        nn.LeakyReLU(negative_slope= leaky,inplace=True),
+    )
+
+class SSH(nn.Module):
+    def __init__(self, in_channel, out_channel):
+        super(SSH, self).__init__()
+        assert out_channel % 4 == 0
+        leaky = 0
+        if (out_channel <= 64):
+            leaky = 0.1
+        self.conv3X3 = conv_bn_no_relu(in_channel, out_channel//2, stride=1)
+
+        self.conv5X5_1 = conv_bn(in_channel, out_channel//4, stride=1, leaky = leaky)
+        self.conv5X5_2 = conv_bn_no_relu(out_channel//4, out_channel//4, stride=1)
+
+        self.conv7X7_2 = conv_bn(out_channel//4, out_channel//4, stride=1, leaky = leaky)
+        self.conv7x7_3 = conv_bn_no_relu(out_channel//4, out_channel//4, stride=1)
+
+    def forward(self, input):
+        conv3X3 = self.conv3X3(input)
+
+        conv5X5_1 = self.conv5X5_1(input)
+        conv5X5 = self.conv5X5_2(conv5X5_1)
+
+        conv7X7_2 = self.conv7X7_2(conv5X5_1)
+        conv7X7 = self.conv7x7_3(conv7X7_2)
+
+        out = torch.cat([conv3X3, conv5X5, conv7X7], dim=1)
+        out = F.relu(out)
+        return out
+
+class FPN(nn.Module):
+    def __init__(self,in_channels_list,out_channels):
+        super(FPN,self).__init__()
+        leaky = 0
+        if (out_channels <= 64):
+            leaky = 0.1
+        self.output1 = conv_bn1X1(in_channels_list[0], out_channels, stride = 1, leaky = leaky)
+        self.output2 = conv_bn1X1(in_channels_list[1], out_channels, stride = 1, leaky = leaky)
+        self.output3 = conv_bn1X1(in_channels_list[2], out_channels, stride = 1, leaky = leaky)
+
+        self.merge1 = conv_bn(out_channels, out_channels, leaky = leaky)
+        self.merge2 = conv_bn(out_channels, out_channels, leaky = leaky)
+
+    def forward(self, input):
+        # names = list(input.keys())
+        input = list(input.values())
+
+        output1 = self.output1(input[0])
+        output2 = self.output2(input[1])
+        output3 = self.output3(input[2])
+
+        up3 = F.interpolate(output3, size=[output2.size(2), output2.size(3)], mode="nearest")
+        output2 = output2 + up3
+        output2 = self.merge2(output2)
+
+        up2 = F.interpolate(output2, size=[output1.size(2), output1.size(3)], mode="nearest")
+        output1 = output1 + up2
+        output1 = self.merge1(output1)
+
+        out = [output1, output2, output3]
+        return out
+
+
+
+class MobileNetV1(nn.Module):
+    def __init__(self):
+        super(MobileNetV1, self).__init__()
+        self.stage1 = nn.Sequential(
+            conv_bn(3, 8, 2, leaky = 0.1),    # 3
+            conv_dw(8, 16, 1),   # 7
+            conv_dw(16, 32, 2),  # 11
+            conv_dw(32, 32, 1),  # 19
+            conv_dw(32, 64, 2),  # 27
+            conv_dw(64, 64, 1),  # 43
+        )
+        self.stage2 = nn.Sequential(
+            conv_dw(64, 128, 2),  # 43 + 16 = 59
+            conv_dw(128, 128, 1), # 59 + 32 = 91
+            conv_dw(128, 128, 1), # 91 + 32 = 123
+            conv_dw(128, 128, 1), # 123 + 32 = 155
+            conv_dw(128, 128, 1), # 155 + 32 = 187
+            conv_dw(128, 128, 1), # 187 + 32 = 219
+        )
+        self.stage3 = nn.Sequential(
+            conv_dw(128, 256, 2), # 219 +3 2 = 241
+            conv_dw(256, 256, 1), # 241 + 64 = 301
+        )
+        self.avg = nn.AdaptiveAvgPool2d((1,1))
+        self.fc = nn.Linear(256, 1000)
+
+    def forward(self, x):
+        x = self.stage1(x)
+        x = self.stage2(x)
+        x = self.stage3(x)
+        x = self.avg(x)
+        # x = self.model(x)
+        x = x.view(-1, 256)
+        x = self.fc(x)
+        return x
+
