docs/en/faq/index.md 0 → 100644
View file @ a565fa3a
# Frequently Asked Questions
If your question is not listed, try using [DeepWiki](https://deepwiki.com/opendatalab/MinerU)'s AI assistant for common issues.
For unresolved problems, join our [Discord](https://discord.gg/Tdedn9GTXq) or [WeChat](https://mineru.net/community-portal/?aliasId=3c430f94) community for support.
??? question "Encountered the error `ImportError: libGL.so.1: cannot open shared object file: No such file or directory` in Ubuntu 22.04 on WSL2"
The `libgl` library is missing in Ubuntu 22.04 on WSL2. You can install the `libgl` library with the following command to resolve the issue:
```bash
sudo apt-get install libgl1-mesa-glx
```
Reference: [#388](https://github.com/opendatalab/MinerU/issues/388)
??? question "Missing text information in parsing results when installing and using on Linux systems."
MinerU uses `pypdfium2` instead of `pymupdf` as the PDF page rendering engine in versions >=2.0 to resolve AGPLv3 license issues. On some Linux distributions, due to missing CJK fonts, some text may be lost during the process of rendering PDFs to images.
To solve this problem, you can install the noto font package with the following commands, which are effective on Ubuntu/Debian systems:
```bash
sudo apt update
sudo apt install fonts-noto-core
sudo apt install fonts-noto-cjk
fc-cache -fv
```
You can also directly use our [Docker deployment](../quick_start/docker_deployment.md) method to build the image, which includes the above font packages by default.
Reference: [#2915](https://github.com/opendatalab/MinerU/issues/2915)
docs/en/index.md 0 → 100644
View file @ a565fa3a
<div align="center" xmlns="http://www.w3.org/1999/html">
<!-- logo -->
<p align="center">
<img src="https://opendatalab.github.io/MinerU/images/MinerU-logo.png" width="300px" style="vertical-align:middle;">
</p>
</div>
<!-- icon -->
[![stars](https://img.shields.io/github/stars/opendatalab/MinerU.svg)](https://github.com/opendatalab/MinerU)
[![forks](https://img.shields.io/github/forks/opendatalab/MinerU.svg)](https://github.com/opendatalab/MinerU)
[![open issues](https://img.shields.io/github/issues-raw/opendatalab/MinerU)](https://github.com/opendatalab/MinerU/issues)
[![issue resolution](https://img.shields.io/github/issues-closed-raw/opendatalab/MinerU)](https://github.com/opendatalab/MinerU/issues)
[![PyPI version](https://img.shields.io/pypi/v/mineru)](https://pypi.org/project/mineru/)
[![PyPI - Python Version](https://img.shields.io/pypi/pyversions/mineru)](https://pypi.org/project/mineru/)
[![Downloads](https://static.pepy.tech/badge/mineru)](https://pepy.tech/project/mineru)
[![Downloads](https://static.pepy.tech/badge/mineru/month)](https://pepy.tech/project/mineru)
[![Colab](https://colab.research.google.com/assets/colab-badge.svg)](https://colab.research.google.com/gist/myhloli/a3cb16570ab3cfeadf9d8f0ac91b4fca/mineru_demo.ipynb)
[![arXiv](https://img.shields.io/badge/arXiv-2409.18839-b31b1b.svg?logo=arXiv)](https://arxiv.org/abs/2409.18839)
[![Ask DeepWiki](https://deepwiki.com/badge.svg)](https://deepwiki.com/opendatalab/MinerU)
<div align="center">
<a href="https://trendshift.io/repositories/11174" target="_blank"><img src="https://trendshift.io/api/badge/repositories/11174" alt="opendatalab%2FMinerU | Trendshift" style="width: 250px; height: 55px;" width="250" height="55"/></a>
<!-- hot link -->
<p align="center">
🚀<a href="https://mineru.net/?source=github">MinerU Official Website→✅ Zero-Install Online Version ✅ Full-Featured Client ✅ Developer API Online Access, skip deployment hassles, get all product formats with one click, go fast!</a>
</p>
<!-- join us -->
<p align="center">
👋 join us on <a href="https://discord.gg/Tdedn9GTXq" target="_blank">Discord</a> and <a href="https://mineru.net/community-portal/?aliasId=3c430f94" target="_blank">WeChat</a>
</p>
</div>
## Project Introduction
MinerU is a tool that converts PDFs into machine-readable formats (e.g., markdown, JSON), allowing for easy extraction into any format.
MinerU was born during the pre-training process of [InternLM](https://github.com/InternLM/InternLM). We focus on solving symbol conversion issues in scientific literature and hope to contribute to technological development in the era of large models.
Compared to well-known commercial products domestically and internationally, MinerU is still young. If you encounter any issues or if the results are not as expected, please submit an issue on [GitHub Issues](https://github.com/opendatalab/MinerU/issues) and **attach the relevant PDF**.
![type:video](https://github.com/user-attachments/assets/4bea02c9-6d54-4cd6-97ed-dff14340982c)
## Key Features
- Remove headers, footers, footnotes, page numbers and other elements to ensure semantic coherence
- Output text in human reading order, suitable for single-column, multi-column and complex layouts
- Retain the original document structure, including titles, paragraphs, lists, etc.
- Extract images, image descriptions, tables, table titles and footnotes
- Automatically identify and convert formulas in documents to LaTeX format
- Automatically identify and convert tables in documents to HTML format
- Automatically detect scanned PDFs and garbled PDFs, and enable OCR functionality
- OCR supports detection and recognition of 84 languages
- Support multiple output formats, such as multimodal and NLP Markdown, reading-order-sorted JSON, and information-rich intermediate formats
- Support multiple visualization results, including layout visualization, span visualization, etc., for efficient confirmation of output effects and quality inspection
- Support pure CPU environment operation, and support GPU(CUDA)/NPU(CANN)/MPS acceleration
- Compatible with Windows, Linux and Mac platforms
## User Guide
- [Quick Start Guide](./quick_start/index.md)
- [Detailed Usage Instructions](./usage/index.md)
docs/en/quick_start/docker_deployment.md 0 → 100644
View file @ a565fa3a
# Deploying MinerU with Docker
MinerU provides a convenient Docker deployment method, which helps quickly set up the environment and solve some tricky environment compatibility issues.
## Build Docker Image using Dockerfile
```bash
wget https://gcore.jsdelivr.net/gh/opendatalab/MinerU@master/docker/global/Dockerfile
docker build -t mineru-vllm:latest -f Dockerfile .
```
> [!TIP]
> The [Dockerfile](https://github.com/opendatalab/MinerU/blob/master/docker/global/Dockerfile) uses `vllm/vllm-openai:v0.10.1.1` as the base image by default, supporting Turing/Ampere/Ada Lovelace/Hopper/Blackwell platforms.
## Docker Description
MinerU's Docker uses `vllm/vllm-openai` as the base image, so it includes the `vllm` inference acceleration framework and necessary dependencies by default. Therefore, on compatible devices, you can directly use `vllm` to accelerate VLM model inference.
> [!NOTE]
> Requirements for using `vllm` to accelerate VLM model inference:
>
> - Device must have Turing architecture or later graphics cards with 8GB+ available VRAM.
> - The host machine's graphics driver should support CUDA 12.8 or higher; You can check the driver version using the `nvidia-smi` command.
> - Docker container must have access to the host machine's graphics devices.
## Start Docker Container
```bash
docker run --gpus all \
--shm-size 32g \
-p 30000:30000 -p 7860:7860 -p 8000:8000 \
--ipc=host \
-it mineru-vllm:latest \
/bin/bash
```
After executing this command, you will enter the Docker container's interactive terminal with some ports mapped for potential services. You can directly run MinerU-related commands within the container to use MinerU's features.
You can also directly start MinerU services by replacing `/bin/bash` with service startup commands. For detailed instructions, please refer to the [Start the service via command](https://opendatalab.github.io/MinerU/usage/quick_usage/#advanced-usage-via-api-webui-http-clientserver).
## Start Services Directly with Docker Compose
We provide a [compose.yaml](https://github.com/opendatalab/MinerU/blob/master/docker/compose.yaml) file that you can use to quickly start MinerU services.
```bash
# Download compose.yaml file
wget https://gcore.jsdelivr.net/gh/opendatalab/MinerU@master/docker/compose.yaml
```
>[!NOTE]
>
>- The `compose.yaml` file contains configurations for multiple services of MinerU, you can choose to start specific services as needed.
>- Different services might have additional parameter configurations, which you can view and edit in the `compose.yaml` file.
>- Due to the pre-allocation of GPU memory by the `vllm` inference acceleration framework, you may not be able to run multiple `vllm` services simultaneously on the same machine. Therefore, ensure that other services that might use GPU memory have been stopped before starting the `vlm-vllm-server` service or using the `vlm-vllm-engine` backend.
---
### Start vllm-server service
connect to `vllm-server` via `vlm-http-client` backend
```bash
docker compose -f compose.yaml --profile vllm-server up -d
```
>[!TIP]
>In another terminal, connect to vllm server via http client (only requires CPU and network, no vllm environment needed)
> ```bash
> mineru -p <input_path> -o <output_path> -b vlm-http-client -u http://<server_ip>:30000
> ```
---
### Start Web API service
```bash
docker compose -f compose.yaml --profile api up -d
```
>[!TIP]
>Access `http://<server_ip>:8000/docs` in your browser to view the API documentation.
---
### Start Gradio WebUI service
```bash
docker compose -f compose.yaml --profile gradio up -d
```
>[!TIP]
>
>- Access `http://<server_ip>:7860` in your browser to use the Gradio WebUI.
>- Access `http://<server_ip>:7860/?view=api` to use the Gradio API.
docs/en/quick_start/extension_modules.md 0 → 100644
View file @ a565fa3a
# MinerU Extension Modules Installation Guide
MinerU supports installing extension modules on demand based on different needs to enhance functionality or support specific model backends.
## Common Scenarios
### Core Functionality Installation
The `core` module is the core dependency of MinerU, containing all functional modules except `vllm`. Installing this module ensures the basic functionality of MinerU works properly.
```bash
uv pip install mineru[core]
```
---
### Using `vllm` to Accelerate VLM Model Inference
The `vllm` module provides acceleration support for VLM model inference, suitable for graphics cards with Turing architecture and later (8GB+ VRAM). Installing this module can significantly improve model inference speed.
In the configuration, `all` includes both `core` and `vllm` modules, so `mineru[all]` and `mineru[core,vllm]` are equivalent.
```bash
uv pip install mineru[all]
```
> [!TIP]
> If exceptions occur during installation of the complete package including vllm, please refer to the [vllm official documentation](https://docs.vllm.ai/en/latest/getting_started/installation/index.html) to try to resolve the issue, or directly use the [Docker](./docker_deployment.md) deployment method.
---
### Installing Lightweight Client to Connect to vllm-server
If you need to install a lightweight client on edge devices to connect to `vllm-server`, you can install the basic mineru package, which is very lightweight and suitable for devices with only CPU and network connectivity.
```bash
uv pip install mineru
```
docs/en/quick_start/index.md 0 → 100644
View file @ a565fa3a
# Quick Start
If you encounter any installation issues, please check the [FAQ](../faq/index.md) first.
## Online Experience
### Official online web application
The official online version has the same functionality as the client, with a beautiful interface and rich features, requires login to use
### Gradio-based online demo
A WebUI developed based on Gradio, with a simple interface and only core parsing functionality, no login required
## Local Deployment
> [!WARNING]
> **Prerequisites - Hardware and Software Environment Support**
>
> To ensure the stability and reliability of the project, we have optimized and tested only specific hardware and software environments during development. This ensures that users can achieve optimal performance and encounter the fewest compatibility issues when deploying and running the project on recommended system configurations.
>
> By concentrating our resources and efforts on mainstream environments, our team can more efficiently resolve potential bugs and timely develop new features.
>
> In non-mainstream environments, due to the diversity of hardware and software configurations, as well as compatibility issues with third-party dependencies, we cannot guarantee 100% usability of the project. Therefore, for users who wish to use this project in non-recommended environments, we suggest carefully reading the documentation and FAQ first, as most issues have corresponding solutions in the FAQ. Additionally, we encourage community feedback on issues so that we can gradually expand our support range.
<table border="1">
<tr>
<td>Parsing Backend</td>
<td>pipeline</td>
<td>vlm-transformers</td>
<td>vlm-vllm</td>
</tr>
<tr>
<td>Operating System</td>
<td>Linux / Windows / macOS</td>
<td>Linux / Windows</td>
<td>Linux / Windows (via WSL2)</td>
</tr>
<tr>
<td>CPU Inference Support</td>
<td>✅</td>
<td colspan="2">❌</td>
</tr>
<tr>
<td>GPU Requirements</td>
<td>Turing architecture and later, 6GB+ VRAM or Apple Silicon</td>
<td colspan="2">Turing architecture and later, 8GB+ VRAM</td>
</tr>
<tr>
<td>Memory Requirements</td>
<td colspan="3">Minimum 16GB+, recommended 32GB+</td>
</tr>
<tr>
<td>Disk Space Requirements</td>
<td colspan="3">20GB+, SSD recommended</td>
</tr>
<tr>
<td>Python Version</td>
<td colspan="3">3.10-3.13</td>
</tr>
</table>
### Install MinerU
#### Install MinerU using pip or uv
```bash
pip install --upgrade pip
pip install uv
uv pip install -U "mineru[core]"
```
#### Install MinerU from source code
```bash
git clone https://github.com/opendatalab/MinerU.git
cd MinerU
uv pip install -e .[core]
```
> [!TIP]
> `mineru[core]` includes all core features except `vllm` acceleration, compatible with Windows / Linux / macOS systems, suitable for most users.
> If you need to use `vllm` acceleration for VLM model inference or install a lightweight client on edge devices, please refer to the documentation [Extension Modules Installation Guide](./extension_modules.md).
---
#### Deploy MinerU using Docker
MinerU provides a convenient Docker deployment method, which helps quickly set up the environment and solve some tricky environment compatibility issues.
You can get the [Docker Deployment Instructions](./docker_deployment.md) in the documentation.
---
### Using MinerU
The simplest command line invocation is:
```bash
mineru -p <input_path> -o <output_path>
```
You can use MinerU for PDF parsing through various methods such as command line, API, and WebUI. For detailed instructions, please refer to the [Usage Guide](../usage/index.md).
\ No newline at end of file
docs/en/reference/output_files.md 0 → 100644
View file @ a565fa3a
This diff is collapsed.
docs/en/usage/advanced_cli_parameters.md 0 → 100644
View file @ a565fa3a
# Advanced Command Line Parameters
## vllm Acceleration Parameter Optimization
### Performance Optimization Parameters
> [!TIP]
> If you can already use vllm normally for accelerated VLM model inference but still want to further improve inference speed, you can try the following parameters:
>
> - If you have multiple graphics cards, you can use vllm's multi-card parallel mode to increase throughput: `--data-parallel-size 2`
### Parameter Passing Instructions
> [!TIP]
> - All officially supported vllm parameters can be passed to MinerU through command line arguments, including the following commands: `mineru`, `mineru-vllm-server`, `mineru-gradio`, `mineru-api`
> - If you want to learn more about `vllm` parameter usage, please refer to the [vllm official documentation](https://docs.vllm.ai/en/latest/cli/serve.html)
## GPU Device Selection and Configuration
### CUDA_VISIBLE_DEVICES Basic Usage
> [!TIP]
> - In any situation, you can specify visible GPU devices by adding the `CUDA_VISIBLE_DEVICES` environment variable at the beginning of the command line. For example:
> ```bash
> CUDA_VISIBLE_DEVICES=1 mineru -p <input_path> -o <output_path>
> ```
> - This specification method is effective for all command line calls, including `mineru`, `mineru-vllm-server`, `mineru-gradio`, and `mineru-api`, and applies to both `pipeline` and `vlm` backends.
### Common Device Configuration Examples
> [!TIP]
> Here are some common `CUDA_VISIBLE_DEVICES` setting examples:
> ```bash
> CUDA_VISIBLE_DEVICES=1 # Only device 1 will be seen
> CUDA_VISIBLE_DEVICES=0,1 # Devices 0 and 1 will be visible
> CUDA_VISIBLE_DEVICES="0,1" # Same as above, quotation marks are optional
> CUDA_VISIBLE_DEVICES=0,2,3 # Devices 0, 2, 3 will be visible; device 1 is masked
> CUDA_VISIBLE_DEVICES="" # No GPU will be visible
> ```
## Practical Application Scenarios
> [!TIP]
> Here are some possible usage scenarios:
>
> - If you have multiple graphics cards and need to specify cards 0 and 1, using multi-card parallelism to start `vllm-server`, you can use the following command:
> ```bash
> CUDA_VISIBLE_DEVICES=0,1 mineru-vllm-server --port 30000 --data-parallel-size 2
> ```
>
> - If you have multiple graphics cards and need to start two `fastapi` services on cards 0 and 1, listening on different ports respectively, you can use the following commands:
> ```bash
> # In terminal 1
> CUDA_VISIBLE_DEVICES=0 mineru-api --host 127.0.0.1 --port 8000
> # In terminal 2
> CUDA_VISIBLE_DEVICES=1 mineru-api --host 127.0.0.1 --port 8001
> ```
docs/en/usage/cli_tools.md 0 → 100644
View file @ a565fa3a
# Command Line Tools Usage Instructions
## View Help Information
To view help information for MinerU command line tools, you can use the `--help` parameter. Here are help information examples for various command line tools:
```bash
mineru --help
Usage: mineru [OPTIONS]
Options:
-v, --version Show version and exit
-p, --path PATH Input file path or directory (required)
-o, --output PATH Output directory (required)
-m, --method [auto|txt|ocr] Parsing method: auto (default), txt, ocr (pipeline backend only)
-b, --backend [pipeline|vlm-transformers|vlm-vllm-engine|vlm-http-client]
Parsing backend (default: pipeline)
-l, --lang [ch|ch_server|ch_lite|en|korean|japan|chinese_cht|ta|te|ka|th|el|latin|arabic|east_slavic|cyrillic|devanagari]
Specify document language (improves OCR accuracy, pipeline backend only)
-u, --url TEXT Service address when using http-client
-s, --start INTEGER Starting page number for parsing (0-based)
-e, --end INTEGER Ending page number for parsing (0-based)
-f, --formula BOOLEAN Enable formula parsing (default: enabled)
-t, --table BOOLEAN Enable table parsing (default: enabled)
-d, --device TEXT Inference device (e.g., cpu/cuda/cuda:0/npu/mps, pipeline backend only)
--vram INTEGER Maximum GPU VRAM usage per process (GB) (pipeline backend only)
--source [huggingface|modelscope|local]
Model source, default: huggingface
--help Show help information
```
```bash
mineru-api --help
Usage: mineru-api [OPTIONS]
Options:
--host TEXT Server host (default: 127.0.0.1)
--port INTEGER Server port (default: 8000)
--reload Enable auto-reload (development mode)
--help Show this message and exit.
```
```bash
mineru-gradio --help
Usage: mineru-gradio [OPTIONS]
Options:
--enable-example BOOLEAN Enable example files for input. The example
files to be input need to be placed in the
`example` folder within the directory where
the command is currently executed.
--enable-vllm-engine BOOLEAN Enable vllm engine backend for faster
processing.
--enable-api BOOLEAN Enable gradio API for serving the
application.
--max-convert-pages INTEGER Set the maximum number of pages to convert
from PDF to Markdown.
--server-name TEXT Set the server name for the Gradio app.
--server-port INTEGER Set the server port for the Gradio app.
--latex-delimiters-type [a|b|all]
Set the type of LaTeX delimiters to use in
Markdown rendering: 'a' for type '$', 'b' for
type '()[]', 'all' for both types.
--help Show this message and exit.
```
## Environment Variables Description
Some parameters of MinerU command line tools have equivalent environment variable configurations. Generally, environment variable configurations have higher priority than command line parameters and take effect across all command line tools.
Here are the environment variables and their descriptions:
- `MINERU_DEVICE_MODE`:
* Used to specify inference device
* supports device types like `cpu/cuda/cuda:0/npu/mps`
* only effective for `pipeline` backend.
- `MINERU_VIRTUAL_VRAM_SIZE`:
* Used to specify maximum GPU VRAM usage per process (GB)
* only effective for `pipeline` backend.
- `MINERU_MODEL_SOURCE`:
* Used to specify model source
* supports `huggingface/modelscope/local`
* defaults to `huggingface`, can be switched to `modelscope` or local models through environment variables.
- `MINERU_TOOLS_CONFIG_JSON`:
* Used to specify configuration file path
* defaults to `mineru.json` in user directory, can specify other configuration file paths through environment variables.
- `MINERU_FORMULA_ENABLE`:
* Used to enable formula parsing
* defaults to `true`, can be set to `false` through environment variables to disable formula parsing.
- `MINERU_TABLE_ENABLE`:
* Used to enable table parsing
* defaults to `true`, can be set to `false` through environment variables to disable table parsing.
docs/en/usage/index.md 0 → 100644
View file @ a565fa3a
# Usage Guide
This section provides comprehensive usage instructions for the project. We will help you progressively master the project's usage from basic to advanced through the following sections:
## Table of Contents
- [Quick Usage](./quick_usage.md) - Quick setup and basic usage
- [Model Source Configuration](./model_source.md) - Detailed configuration instructions for model sources
- [Command Line Tools](./cli_tools.md) - Detailed parameter descriptions for command line tools
- [Advanced Optimization Parameters](./advanced_cli_parameters.md) - Advanced parameter descriptions for command line tool adaptation
## Getting Started
We recommend reading the documentation in the order listed above, which will help you better understand and use the project features.
If you encounter issues during usage, please check the [FAQ](../faq/index.md)
\ No newline at end of file
docs/en/usage/model_source.md 0 → 100644
View file @ a565fa3a
# Model Source Documentation
MinerU uses `HuggingFace` and `ModelScope` as model repositories. Users can switch model sources or use local models as needed.
- `HuggingFace` is the default model source, providing excellent loading speed and high stability globally.
- `ModelScope` is the best choice for users in mainland China, providing seamlessly compatible `hf` SDK modules, suitable for users who cannot access HuggingFace.
## Methods to Switch Model Sources
### Switch via Command Line Parameters
Currently, only the `mineru` command line tool supports switching model sources through command line parameters. Other command line tools such as `mineru-api`, `mineru-gradio`, etc., do not support this yet.
```bash
mineru -p <input_path> -o <output_path> --source modelscope
```
### Switch via Environment Variables
You can switch model sources by setting environment variables in any situation. This applies to all command line tools and API calls.
```bash
export MINERU_MODEL_SOURCE=modelscope
```
or
```python
import os
os.environ["MINERU_MODEL_SOURCE"] = "modelscope"
```
>[!TIP]
> Model sources set through environment variables will take effect in the current terminal session until the terminal is closed or the environment variable is modified. They have higher priority than command line parameters - if both command line parameters and environment variables are set, the command line parameters will be ignored.
## Using Local Models
### 1. Download Models to Local Storage
```bash
mineru-models-download --help
```
or use the interactive command line tool to select model downloads:
```bash
mineru-models-download
```
> [!NOTE]
>- After download completion, the model path will be output in the current terminal window and automatically written to `mineru.json` in the user directory.
>- You can also create it by copying the [configuration template file](https://github.com/opendatalab/MinerU/blob/master/mineru.template.json) to your user directory and renaming it to `mineru.json`.
>- After downloading models locally, you can freely move the model folder to other locations while updating the model path in `mineru.json`.
>- If you deploy the model folder to another server, please ensure you move the `mineru.json` file to the user directory of the new device and configure the model path correctly.
>- If you need to update model files, you can run the `mineru-models-download` command again. Model updates do not support custom paths currently - if you haven't moved the local model folder, model files will be incrementally updated; if you have moved the model folder, model files will be re-downloaded to the default location and `mineru.json` will be updated.
### 2. Use Local Models for Parsing
```bash
mineru -p <input_path> -o <output_path> --source local
```
or enable through environment variables:
```bash
export MINERU_MODEL_SOURCE=local
mineru -p <input_path> -o <output_path>
```
docs/en/usage/quick_usage.md 0 → 100644
View file @ a565fa3a
# Using MinerU
## Quick Model Source Configuration
MinerU uses `huggingface` as the default model source. If users cannot access `huggingface` due to network restrictions, they can conveniently switch the model source to `modelscope` through environment variables:
```bash
export MINERU_MODEL_SOURCE=modelscope
```
For more information about model source configuration and custom local model paths, please refer to the [Model Source Documentation](./model_source.md) in the documentation.
## Quick Usage via Command Line
MinerU has built-in command line tools that allow users to quickly use MinerU for PDF parsing through the command line:
```bash
# Default parsing using pipeline backend
mineru -p <input_path> -o <output_path>
```
> [!TIP]
>- `<input_path>`: Local PDF/image file or directory
>- `<output_path>`: Output directory
>
> For more information about output files, please refer to [Output File Documentation](../reference/output_files.md).
> [!NOTE]
> The command line tool will automatically attempt cuda/mps acceleration on Linux and macOS systems.
> Windows users who need cuda acceleration should visit the [PyTorch official website](https://pytorch.org/get-started/locally/) to select the appropriate command for their cuda version to install acceleration-enabled `torch` and `torchvision`.
```bash
# Or specify vlm backend for parsing
mineru -p <input_path> -o <output_path> -b vlm-transformers
```
> [!TIP]
> The vlm backend additionally supports `vllm` acceleration. Compared to the `transformers` backend, `vllm` can achieve 20-30x speedup. You can check the installation method for the complete package supporting `vllm` acceleration in the [Extension Modules Installation Guide](../quick_start/extension_modules.md).
If you need to adjust parsing options through custom parameters, you can also check the more detailed [Command Line Tools Usage Instructions](./cli_tools.md) in the documentation.
## Advanced Usage via API, WebUI, http-client/server
- Direct Python API calls: [Python Usage Example](https://github.com/opendatalab/MinerU/blob/master/demo/demo.py)
- FastAPI calls:
```bash
mineru-api --host 0.0.0.0 --port 8000
```
>[!TIP]
>Access `http://127.0.0.1:8000/docs` in your browser to view the API documentation.
- Start Gradio WebUI visual frontend:
```bash
# Using pipeline/vlm-transformers/vlm-http-client backends
mineru-gradio --server-name 0.0.0.0 --server-port 7860
# Or using vlm-vllm-engine/pipeline backends (requires vllm environment)
mineru-gradio --server-name 0.0.0.0 --server-port 7860 --enable-vllm-engine true
```
>[!TIP]
>
>- Access `http://127.0.0.1:7860` in your browser to use the Gradio WebUI.
>- Access `http://127.0.0.1:7860/?view=api` to use the Gradio API.
- Using `http-client/server` method:
```bash
# Start vllm server (requires vllm environment)
mineru-vllm-server --port 30000
```
>[!TIP]
>In another terminal, connect to vllm server via http client (only requires CPU and network, no vllm environment needed)
> ```bash
> mineru -p <input_path> -o <output_path> -b vlm-http-client -u http://127.0.0.1:30000
> ```
> [!NOTE]
> All officially supported vllm parameters can be passed to MinerU through command line arguments, including the following commands: `mineru`, `mineru-vllm-server`, `mineru-gradio`, `mineru-api`.
> We have compiled some commonly used parameters and usage methods for `vllm`, which can be found in the documentation [Advanced Command Line Parameters](./advanced_cli_parameters.md).
## Extending MinerU Functionality with Configuration Files
MinerU is now ready to use out of the box, but also supports extending functionality through configuration files. You can edit `mineru.json` file in your user directory to add custom configurations.
>[!IMPORTANT]
>The `mineru.json` file will be automatically generated when you use the built-in model download command `mineru-models-download`, or you can create it by copying the [configuration template file](https://github.com/opendatalab/MinerU/blob/master/mineru.template.json) to your user directory and renaming it to `mineru.json`.
Here are some available configuration options:
- `latex-delimiter-config`:
* Used to configure LaTeX formula delimiters
* Defaults to `$` symbol, can be modified to other symbols or strings as needed.
- `llm-aided-config`:
* Used to configure parameters for LLM-assisted title hierarchy
* Compatible with all LLM models supporting `openai protocol`, defaults to using Alibaba Cloud Bailian's `qwen2.5-32b-instruct` model.
* You need to configure your own API key and set `enable` to `true` to enable this feature.
- `models-dir`:
* Used to specify local model storage directory
* Please specify model directories for `pipeline` and `vlm` backends separately.
* After specifying the directory, you can use local models by configuring the environment variable `export MINERU_MODEL_SOURCE=local`.
docs/images/logo.svg 0 → 100644
View file @ a565fa3a
<svg width="24" height="24" viewBox="0 0 24 24" fill="none" xmlns="http://www.w3.org/2000/svg">
<path d="M19.7238 3.86898C19.7238 4.57597 19.1502 5.1491 18.4427 5.1491C17.7352 5.1491 17.1616 4.57597 17.1616 3.86898C17.1616 3.16199 17.7352 2.58887 18.4427 2.58887C19.1502 2.58887 19.7238 3.16199 19.7238 3.86898Z" fill="url(#paint0_linear_8609_1645)"/>
<path d="M19.7238 3.86898C19.7238 4.57597 19.1502 5.1491 18.4427 5.1491C17.7352 5.1491 17.1616 4.57597 17.1616 3.86898C17.1616 3.16199 17.7352 2.58887 18.4427 2.58887C19.1502 2.58887 19.7238 3.16199 19.7238 3.86898Z" fill="#010101"/>
<path d="M15.3681 5.1491C15.3681 5.85609 14.7945 6.42921 14.087 6.42921C13.3794 6.42921 12.8059 5.85609 12.8059 5.1491C12.8059 4.44211 13.3794 3.86898 14.087 3.86898C14.7945 3.86898 15.3681 4.44211 15.3681 5.1491Z" fill="url(#paint1_linear_8609_1645)"/>
<path d="M15.3681 5.1491C15.3681 5.85609 14.7945 6.42921 14.087 6.42921C13.3794 6.42921 12.8059 5.85609 12.8059 5.1491C12.8059 4.44211 13.3794 3.86898 14.087 3.86898C14.7945 3.86898 15.3681 4.44211 15.3681 5.1491Z" fill="#010101"/>
<path fill-rule="evenodd" clip-rule="evenodd" d="M8.05175 11.2368C8.05175 13.4605 9.14375 15.4293 10.8211 16.6371C11.8241 15.7389 12.4551 14.4345 12.4551 12.9828V9.39673C12.4551 8.85661 12.8197 8.38448 13.3426 8.24757L19.8924 6.53265C20.6459 6.33534 21.3826 6.90341 21.3826 7.6818L21.3826 12.0452C21.3826 17.2179 17.1861 21.4111 12.0095 21.4111L11.9942 21.4111C6.81758 21.4111 2.62109 17.2179 2.62109 12.0452V9.03388C2.62109 8.49175 2.9884 8.01839 3.51385 7.88336L6.56677 7.09882C7.31904 6.9055 8.05175 7.47318 8.05175 8.24934V11.2368ZM3.9798 12.0452C3.9798 13.8476 4.57565 15.5108 5.58124 16.849C6.04996 17.4728 6.7655 17.8884 7.54573 17.8884V17.8884C8.28848 17.8884 8.9927 17.7236 9.62376 17.4286C7.83439 15.9596 6.69304 13.7314 6.69304 11.2368V8.46821L3.9798 9.16546V12.0452Z" fill="url(#paint2_linear_8609_1645)"/>
<path fill-rule="evenodd" clip-rule="evenodd" d="M8.05175 11.2368C8.05175 13.4605 9.14375 15.4293 10.8211 16.6371C11.8241 15.7389 12.4551 14.4345 12.4551 12.9828V9.39673C12.4551 8.85661 12.8197 8.38448 13.3426 8.24757L19.8924 6.53265C20.6459 6.33534 21.3826 6.90341 21.3826 7.6818L21.3826 12.0452C21.3826 17.2179 17.1861 21.4111 12.0095 21.4111L11.9942 21.4111C6.81758 21.4111 2.62109 17.2179 2.62109 12.0452V9.03388C2.62109 8.49175 2.9884 8.01839 3.51385 7.88336L6.56677 7.09882C7.31904 6.9055 8.05175 7.47318 8.05175 8.24934V11.2368ZM3.9798 12.0452C3.9798 13.8476 4.57565 15.5108 5.58124 16.849C6.04996 17.4728 6.7655 17.8884 7.54573 17.8884V17.8884C8.28848 17.8884 8.9927 17.7236 9.62376 17.4286C7.83439 15.9596 6.69304 13.7314 6.69304 11.2368V8.46821L3.9798 9.16546V12.0452Z" fill="#010101"/>
<defs>
<linearGradient id="paint0_linear_8609_1645" x1="14.3898" y1="8.36821" x2="13.1876" y2="19.4461" gradientUnits="userSpaceOnUse">
<stop stop-color="white"/>
<stop offset="1" stop-color="#2E2E2E"/>
</linearGradient>
<linearGradient id="paint1_linear_8609_1645" x1="14.3898" y1="8.36821" x2="13.1876" y2="19.4461" gradientUnits="userSpaceOnUse">
<stop stop-color="white"/>
<stop offset="1" stop-color="#2E2E2E"/>
</linearGradient>
<linearGradient id="paint2_linear_8609_1645" x1="14.3898" y1="8.36821" x2="13.1876" y2="19.4461" gradientUnits="userSpaceOnUse">
<stop stop-color="white"/>
<stop offset="1" stop-color="#2E2E2E"/>
</linearGradient>
</defs>
</svg>
Markdown is supported
0% or .
You are about to add 0 people to the discussion. Proceed with caution.
Finish editing this message first!
Please register or to comment
