agents/ui_agent/util/box_annotator.py

+from typing import List, Optional, Union, Tuple
+
+import cv2
+import numpy as np
+
+from supervision.detection.core import Detections
+from supervision.draw.color import Color, ColorPalette
+
+
+class BoxAnnotator:
+    """
+    A class for drawing bounding boxes on an image using detections provided.
+
+    Attributes:
+        color (Union[Color, ColorPalette]): The color to draw the bounding box,
+            can be a single color or a color palette
+        thickness (int): The thickness of the bounding box lines, default is 2
+        text_color (Color): The color of the text on the bounding box, default is white
+        text_scale (float): The scale of the text on the bounding box, default is 0.5
+        text_thickness (int): The thickness of the text on the bounding box,
+            default is 1
+        text_padding (int): The padding around the text on the bounding box,
+            default is 5
+
+    """
+
+    def __init__(
+        self,
+        color: Union[Color, ColorPalette] = ColorPalette.DEFAULT,
+        thickness: int = 3, # 1 for seeclick 2 for mind2web and 3 for demo
+        text_color: Color = Color.BLACK,
+        text_scale: float = 0.5, # 0.8 for mobile/web, 0.3 for desktop # 0.4 for mind2web
+        text_thickness: int = 2, #1, # 2 for demo
+        text_padding: int = 10,
+        avoid_overlap: bool = True,
+    ):
+        self.color: Union[Color, ColorPalette] = color
+        self.thickness: int = thickness
+        self.text_color: Color = text_color
+        self.text_scale: float = text_scale
+        self.text_thickness: int = text_thickness
+        self.text_padding: int = text_padding
+        self.avoid_overlap: bool = avoid_overlap
+
+    def annotate(
+        self,
+        scene: np.ndarray,
+        detections: Detections,
+        labels: Optional[List[str]] = None,
+        skip_label: bool = False,
+        image_size: Optional[Tuple[int, int]] = None,
+    ) -> np.ndarray:
+        """
+        Draws bounding boxes on the frame using the detections provided.
+
+        Args:
+            scene (np.ndarray): The image on which the bounding boxes will be drawn
+            detections (Detections): The detections for which the
+                bounding boxes will be drawn
+            labels (Optional[List[str]]): An optional list of labels
+                corresponding to each detection. If `labels` are not provided,
+                corresponding `class_id` will be used as label.
+            skip_label (bool): Is set to `True`, skips bounding box label annotation.
+        Returns:
+            np.ndarray: The image with the bounding boxes drawn on it
+
+        Example:
+            ```python
+            import supervision as sv
+
+            classes = ['person', ...]
+            image = ...
+            detections = sv.Detections(...)
+
+            box_annotator = sv.BoxAnnotator()
+            labels = [
+                f"{classes[class_id]} {confidence:0.2f}"
+                for _, _, confidence, class_id, _ in detections
+            ]
+            annotated_frame = box_annotator.annotate(
+                scene=image.copy(),
+                detections=detections,
+                labels=labels
+            )
+            ```
+        """
+        font = cv2.FONT_HERSHEY_SIMPLEX
+        for i in range(len(detections)):
+            x1, y1, x2, y2 = detections.xyxy[i].astype(int)
+            class_id = (
+                detections.class_id[i] if detections.class_id is not None else None
+            )
+            idx = class_id if class_id is not None else i
+            color = (
+                self.color.by_idx(idx)
+                if isinstance(self.color, ColorPalette)
+                else self.color
+            )
+            cv2.rectangle(
+                img=scene,
+                pt1=(x1, y1),
+                pt2=(x2, y2),
+                color=color.as_bgr(),
+                thickness=self.thickness,
+            )
+            if skip_label:
+                continue
+
+            text = (
+                f"{class_id}"
+                if (labels is None or len(detections) != len(labels))
+                else labels[i]
+            )
+
+            text_width, text_height = cv2.getTextSize(
+                text=text,
+                fontFace=font,
+                fontScale=self.text_scale,
+                thickness=self.text_thickness,
+            )[0]
+
+            if not self.avoid_overlap:
+                text_x = x1 + self.text_padding
+                text_y = y1 - self.text_padding
+
+                text_background_x1 = x1
+                text_background_y1 = y1 - 2 * self.text_padding - text_height
+
+                text_background_x2 = x1 + 2 * self.text_padding + text_width
+                text_background_y2 = y1
+                # text_x = x1 - self.text_padding - text_width
+                # text_y = y1 + self.text_padding + text_height
+                # text_background_x1 = x1 - 2 * self.text_padding - text_width
+                # text_background_y1 = y1
+                # text_background_x2 = x1
+                # text_background_y2 = y1 + 2 * self.text_padding + text_height
+            else:
+                text_x, text_y, text_background_x1, text_background_y1, text_background_x2, text_background_y2 = get_optimal_label_pos(self.text_padding, text_width, text_height, x1, y1, x2, y2, detections, image_size)
+
+            cv2.rectangle(
+                img=scene,
+                pt1=(text_background_x1, text_background_y1),
+                pt2=(text_background_x2, text_background_y2),
+                color=color.as_bgr(),
+                thickness=cv2.FILLED,
+            )
+            # import pdb; pdb.set_trace()
+            box_color = color.as_rgb()
+            luminance = 0.299 * box_color[0] + 0.587 * box_color[1] + 0.114 * box_color[2]
+            text_color = (0,0,0) if luminance > 160 else (255,255,255)
+            cv2.putText(
+                img=scene,
+                text=text,
+                org=(text_x, text_y),
+                fontFace=font,
+                fontScale=self.text_scale,
+                # color=self.text_color.as_rgb(),
+                color=text_color,
+                thickness=self.text_thickness,
+                lineType=cv2.LINE_AA,
+            )
+        return scene
+
+
+def box_area(box):
+        return (box[2] - box[0]) * (box[3] - box[1])
+
+def intersection_area(box1, box2):
+    x1 = max(box1[0], box2[0])
+    y1 = max(box1[1], box2[1])
+    x2 = min(box1[2], box2[2])
+    y2 = min(box1[3], box2[3])
+    return max(0, x2 - x1) * max(0, y2 - y1)
+
+def IoU(box1, box2, return_max=True):
+    intersection = intersection_area(box1, box2)
+    union = box_area(box1) + box_area(box2) - intersection
+    if box_area(box1) > 0 and box_area(box2) > 0:
+        ratio1 = intersection / box_area(box1)
+        ratio2 = intersection / box_area(box2)
+    else:
+        ratio1, ratio2 = 0, 0
+    if return_max:
+        return max(intersection / union, ratio1, ratio2)
+    else:
+        return intersection / union
+
+
+def get_optimal_label_pos(text_padding, text_width, text_height, x1, y1, x2, y2, detections, image_size):
+    """ check overlap of text and background detection box, and get_optimal_label_pos,
+        pos: str, position of the text, must be one of 'top left', 'top right', 'outer left', 'outer right' TODO: if all are overlapping, return the last one, i.e. outer right
+        Threshold: default to 0.3
+    """
+
+    def get_is_overlap(detections, text_background_x1, text_background_y1, text_background_x2, text_background_y2, image_size):
+        is_overlap = False
+        for i in range(len(detections)):
+            detection = detections.xyxy[i].astype(int)
+            if IoU([text_background_x1, text_background_y1, text_background_x2, text_background_y2], detection) > 0.3:
+                is_overlap = True
+                break
+        # check if the text is out of the image
+        if text_background_x1 < 0 or text_background_x2 > image_size[0] or text_background_y1 < 0 or text_background_y2 > image_size[1]:
+            is_overlap = True
+        return is_overlap
+
+    # if pos == 'top left':
+    text_x = x1 + text_padding
+    text_y = y1 - text_padding
+
+    text_background_x1 = x1
+    text_background_y1 = y1 - 2 * text_padding - text_height
+
+    text_background_x2 = x1 + 2 * text_padding + text_width
+    text_background_y2 = y1
+    is_overlap = get_is_overlap(detections, text_background_x1, text_background_y1, text_background_x2, text_background_y2, image_size)
+    if not is_overlap:
+        return text_x, text_y, text_background_x1, text_background_y1, text_background_x2, text_background_y2
+
+    # elif pos == 'outer left':
+    text_x = x1 - text_padding - text_width
+    text_y = y1 + text_padding + text_height
+
+    text_background_x1 = x1 - 2 * text_padding - text_width
+    text_background_y1 = y1
+
+    text_background_x2 = x1
+    text_background_y2 = y1 + 2 * text_padding + text_height
+    is_overlap = get_is_overlap(detections, text_background_x1, text_background_y1, text_background_x2, text_background_y2, image_size)
+    if not is_overlap:
+        return text_x, text_y, text_background_x1, text_background_y1, text_background_x2, text_background_y2
+
+
+    # elif pos == 'outer right':
+    text_x = x2 + text_padding
+    text_y = y1 + text_padding + text_height
+
+    text_background_x1 = x2
+    text_background_y1 = y1
+
+    text_background_x2 = x2 + 2 * text_padding + text_width
+    text_background_y2 = y1 + 2 * text_padding + text_height
+
+    is_overlap = get_is_overlap(detections, text_background_x1, text_background_y1, text_background_x2, text_background_y2, image_size)
+    if not is_overlap:
+        return text_x, text_y, text_background_x1, text_background_y1, text_background_x2, text_background_y2
+
+    # elif pos == 'top right':
+    text_x = x2 - text_padding - text_width
+    text_y = y1 - text_padding
+
+    text_background_x1 = x2 - 2 * text_padding - text_width
+    text_background_y1 = y1 - 2 * text_padding - text_height
+
+    text_background_x2 = x2
+    text_background_y2 = y1
+
+    is_overlap = get_is_overlap(detections, text_background_x1, text_background_y1, text_background_x2, text_background_y2, image_size)
+    if not is_overlap:
+        return text_x, text_y, text_background_x1, text_background_y1, text_background_x2, text_background_y2
+
+    return text_x, text_y, text_background_x1, text_background_y1, text_background_x2, text_background_y2

agents/ui_agent/util/omniparser.py

+from util.utils import get_som_labeled_img, get_caption_model_processor, get_yolo_model, check_ocr_box
+import torch
+from PIL import Image
+import io
+import base64
+from typing import Dict
+class Omniparser(object):
+    def __init__(self, config: Dict):
+        self.config = config
+        device = 'cuda' if torch.cuda.is_available() else 'cpu'
+
+        self.som_model = get_yolo_model(model_path=config['som_model_path'])
+        self.caption_model_processor = get_caption_model_processor(model_name=config['caption_model_name'], model_name_or_path=config['caption_model_path'], device=device)
+        print('Omniparser initialized!!!')
+
+    def parse(self, image_base64: str):
+        image_bytes = base64.b64decode(image_base64)
+        image = Image.open(io.BytesIO(image_bytes))
+        print('image size:', image.size)
+
+        box_overlay_ratio = max(image.size) / 3200
+        draw_bbox_config = {
+            'text_scale': 0.8 * box_overlay_ratio,
+            'text_thickness': max(int(2 * box_overlay_ratio), 1),
+            'text_padding': max(int(3 * box_overlay_ratio), 1),
+            'thickness': max(int(3 * box_overlay_ratio), 1),
+        }
+
+        (text, ocr_bbox), _ = check_ocr_box(image, display_img=False, output_bb_format='xyxy', easyocr_args={'text_threshold': 0.8}, use_paddleocr=False)
+        dino_labled_img, label_coordinates, parsed_content_list = get_som_labeled_img(image, self.som_model, BOX_TRESHOLD = self.config['BOX_TRESHOLD'], output_coord_in_ratio=True, ocr_bbox=ocr_bbox,draw_bbox_config=draw_bbox_config, caption_model_processor=self.caption_model_processor, ocr_text=text,use_local_semantics=True, iou_threshold=0.7, scale_img=False, batch_size=128)
+
+        return dino_labled_img, parsed_content_list
\ No newline at end of file

agents/ui_agent/util/process_utils.py

+import re
+
+# is instruction English
+def is_english_simple(text):
+    try:
+        text.encode(encoding='utf-8').decode('ascii')
+    except UnicodeDecodeError:
+        return False
+    else:
+        return True
+
+# bbox -> point (str)
+def bbox_2_point(bbox, dig=2):
+    # bbox [left, top, right, bottom]
+    point = [(bbox[0]+bbox[2])/2, (bbox[1]+bbox[3])/2]
+    point = [f"{item:.2f}" for item in point]
+    point_str = "({},{})".format(point[0], point[1])
+    return point_str
+
+# bbox -> bbox (str)
+def bbox_2_bbox(bbox, dig=2):
+    bbox = [f"{item:.2f}" for item in bbox]
+    bbox_str = "({},{},{},{})".format(bbox[0], bbox[1], bbox[2], bbox[3])
+    return bbox_str
+
+# point (str) -> point
+def pred_2_point(s):
+    floats = re.findall(r'-?\d+\.?\d*', s)
+    floats = [float(num) for num in floats]
+    if len(floats) == 2:
+        click_point = floats
+    elif len(floats) == 4:
+        click_point = [(floats[0]+floats[2])/2, (floats[1]+floats[3])/2]
+    return click_point
+
+# bbox (qwen str) -> bbox
+def extract_bbox(s):
+    # Regular expression to find the content inside <box> and </box>
+    pattern = r"<box>\((\d+,\d+)\),\((\d+,\d+)\)</box>"
+    matches = re.findall(pattern, s)
+    # Convert the tuples of strings into tuples of integers
+    return [(int(x.split(',')[0]), int(x.split(',')[1])) for x in sum(matches, ())]
+
+def extract_mark_id(s):
+    match = re.search(r'Mark: (\d+)', s)
+    if match:
+        return int(match.group(1))
+    return None
\ No newline at end of file

agents/ui_agent/util/som.py

+import torch
+from ultralytics import YOLO
+from PIL import Image
+import io
+import base64
+device = 'cuda'
+
+from PIL import Image, ImageDraw, ImageFont
+import numpy as np
+import networkx as nx
+# import cv2
+
+font_path = "agents/ui_agent/util/arial.ttf"
+class MarkHelper:
+    def __init__(self):
+        self.markSize_dict = {}
+        self.font_dict = {}
+        self.min_font_size = 20 # 1 in v1
+        self.max_font_size = 30
+        self.max_font_proportion = 0.04 # 0.032 in v1
+
+    def __get_markSize(self, text, image_height, image_width, font):
+        im = Image.new('RGB', (image_width, image_height))
+        draw = ImageDraw.Draw(im)
+        _, _, width, height = draw.textbbox((0, 0), text=text, font=font)
+        return height, width
+
+    def _setup_new_font(self, image_height, image_width):
+        key = f"{image_height}_{image_width}"
+        # print(f"Setting up new font for image size: {key}")
+
+        # setup the font
+        fontsize = self.min_font_size
+        font = ImageFont.truetype(font_path, fontsize)
+        # font = ImageFont.load_default(size=fontsize)
+        while min(self.__get_markSize("555", image_height, image_width, font)) < min(self.max_font_size, self.max_font_proportion * min(image_height, image_width)):
+            # iterate until the text size is just larger than the criteria
+            fontsize += 1
+            font = ImageFont.truetype(font_path, fontsize)
+            # font = ImageFont.load_default(size=fontsize)
+        self.font_dict[key] = font
+
+        # setup the markSize dict
+        markSize_3digits = self.__get_markSize('555', image_height, image_width, font)
+        markSize_2digits = self.__get_markSize('55', image_height, image_width, font)
+        markSize_1digit = self.__get_markSize('5', image_height, image_width, font)
+        self.markSize_dict[key] = {
+            1: markSize_1digit,
+            2: markSize_2digits,
+            3: markSize_3digits
+        }
+
+    def get_font(self, image_height, image_width):
+        key = f"{image_height}_{image_width}"
+        if key not in self.font_dict:
+            self._setup_new_font(image_height, image_width)
+        return self.font_dict[key]
+
+    def get_mark_size(self, text_str, image_height, image_width):
+        """Get the font size for the given image dimensions."""
+        key = f"{image_height}_{image_width}"
+        if key not in self.markSize_dict:
+            self._setup_new_font(image_height, image_width)
+
+        largest_size = self.markSize_dict[key].get(3, None)
+        text_h, text_w = self.markSize_dict[key].get(len(text_str), largest_size) # default to the largest size if the text is too long
+        return text_h, text_w
+
+def __calculate_iou(box1, box2, return_area=False):
+    """
+    Calculate the Intersection over Union (IoU) of two bounding boxes.
+    :param box1: Tuple of (y, x, h, w) for the first bounding box
+    :param box2: Tuple of (y, x, h, w) for the second bounding box
+    :return: IoU value
+    """
+    y1, x1, h1, w1 = box1
+    y2, x2, h2, w2 = box2
+
+    # Calculate the intersection area
+    y_min = max(y1, y2)
+    x_min = max(x1, x2)
+    y_max = min(y1 + h1, y2 + h2)
+    x_max = min(x1 + w1, x2 + w2)
+
+    intersection_area = max(0, y_max - y_min) * max(0, x_max - x_min)
+
+    # Compute the area of both bounding boxes
+    box1_area = h1 * w1
+    box2_area = h2 * w2
+
+    # Calculate the IoU
+    # iou = intersection_area / box1_area + box2_area - intersection_area
+    iou = intersection_area / (min(box1_area, box2_area) + 0.0001)
+
+    if return_area:
+        return iou, intersection_area
+    return iou
+
+def __calculate_nearest_corner_distance(box1, box2):
+    """Calculate the distance between the nearest edge or corner of two bounding boxes."""
+    y1, x1, h1, w1 = box1
+    y2, x2, h2, w2 = box2
+    corners1 = np.array([
+        [y1, x1],
+        [y1, x1 + w1],
+        [y1 + h1, x1],
+        [y1 + h1, x1 + w1]
+    ])
+    corners2 = np.array([
+        [y2, x2],
+        [y2, x2 + w2],
+        [y2 + h2, x2],
+        [y2 + h2, x2 + w2]
+    ])
+    # Calculate pairwise distances between corners
+    distances = np.linalg.norm(corners1[:, np.newaxis] - corners2, axis=2)
+
+    # Find the minimum distance
+    min_distance = np.min(distances)
+    return min_distance
+
+def _find_least_overlapping_corner(bbox, bboxes, drawn_boxes, text_size, image_size):
+    """Find the corner with the least overlap with other bboxes.
+    Args:
+        bbox: (y, x, h, w) The bounding box to place the text on.
+        bboxes: [(y, x, h, w)] The list of bounding boxes to compare against.
+        drawn_boxes: [(y, x, h, w)] The list of bounding boxes that have already been drawn on.
+        text_size: (height, width) The size of the text to be drawn.
+        image_size: (height, width) The size of the image.
+    """
+    y, x, h, w = bbox
+    h_text, w_text = text_size
+    image_height, image_width = image_size
+    corners = [
+        # top-left
+        (y - h_text, x),
+        # top-right
+        (y - h_text, x + w - w_text),
+        # right-top
+        (y, x + w),
+        # right-bottom
+        (y + h - h_text, x + w),
+        # bottom-right
+        (y + h, x + w - w_text),
+        # bottom-left
+        (y + h, x),
+        # left-bottom
+        (y + h - h_text, x - w_text),
+        # left-top
+        (y, x - w_text),
+        ]
+    best_corner = corners[0]
+    max_flag = float('inf')
+
+    for corner in corners:
+        corner_bbox = (corner[0], corner[1], h_text, w_text)
+        # if the corner is out of the image, skip
+        if corner[0] < 0 or corner[1] < 0 or corner[0] + h_text > image_height or corner[1] + w_text > image_width:
+            continue
+        max_iou = - (image_width + image_height)
+        # 找到关于这个角最差的 case
+        # given the current corner, find the larget iou with other bboxes.
+        for other_bbox in bboxes + drawn_boxes:
+            if np.array_equal(bbox, other_bbox):
+                continue
+            iou = __calculate_iou(corner_bbox, other_bbox, return_area=True)[1]
+            max_iou = max(max_iou, iou - 0.0001 * __calculate_nearest_corner_distance(corner_bbox, other_bbox))
+        # the smaller the max_IOU, the better the corner
+        # 取最差的值 相对最好的那个角
+        if max_iou < max_flag:
+            max_flag = max_iou
+            best_corner = corner
+
+    return best_corner
+
+def plot_boxes_with_marks(
+    image: Image.Image,
+    bboxes, # (y, x, h, w)
+    mark_helper: MarkHelper,
+    linewidth=2,
+    alpha=0,
+    edgecolor=None,
+    fn_save=None,
+    normalized_to_pixel=True,
+    add_mark=True
+) -> np.ndarray:
+    """Plots bounding boxes on an image with marks attached to the edges of the boxes where no overlap with other boxes occurs.
+    Args:
+        image: The image to plot the bounding boxes on.
+        bboxes: A 2D int array of shape (num_boxes, 4), where each row represents a bounding box: (y_top_left, x_top_left, box_height, box_width). If normalized_to_pixel is True, the values are float and are normalized with the image size. If normalized_to_pixel is False, the values are int and are in pixel.
+    """
+    # Then modify the drawing code
+    draw = ImageDraw.Draw(image)
+
+    # draw boxes on the image
+    image_width, image_height = image.size
+
+    if normalized_to_pixel:
+        bboxes = [(int(y * image_height), int(x * image_width), int(h * image_height), int(w * image_width)) for y, x, h, w in bboxes]
+
+    for box in bboxes:
+        y, x, h, w = box
+        draw.rectangle([x, y, x + w, y + h], outline=edgecolor, width=linewidth)
+
+    # Draw the bounding boxes with index at the least overlapping corner
+    drawn_boxes = []
+    for idx, bbox in enumerate(bboxes):
+        text = str(idx)
+        text_h, text_w = mark_helper.get_mark_size(text, image_height, image_width)
+        corner_y, corner_x = _find_least_overlapping_corner(
+            bbox, bboxes, drawn_boxes, (text_h, text_w), (image_height, image_width))
+
+        # Define the index box (y, x, y + h, x + w)
+        text_box = (corner_y, corner_x, text_h, text_w)
+
+        if add_mark:
+            # Draw the filled index box and text
+            draw.rectangle([corner_x, corner_y, corner_x + text_w, corner_y + text_h], # (x, y, x + w, y + h)
+                        fill="red")
+            font = mark_helper.get_font(image_height, image_width)
+            draw.text((corner_x, corner_y), text, fill='white', font=font)
+
+        # Update the list of drawn boxes
+        drawn_boxes.append(np.array(text_box))
+
+    if fn_save is not None: # PIL image
+        image.save(fn_save)
+    return image
+
+def plot_circles_with_marks(
+    image: Image.Image,
+    points, # (x, y)
+    mark_helper: MarkHelper,
+    linewidth=2,
+    edgecolor=None,
+    fn_save=None,
+    normalized_to_pixel=True,
+    add_mark=True
+) -> np.ndarray:
+    """Plots bounding boxes on an image with marks attached to the edges of the boxes where no overlap with other boxes occurs.
+    Args:
+        image: The image to plot the bounding boxes on.
+        bboxes: A 2D int array of shape (num_boxes, 4), where each row represents a bounding box: (y_top_left, x_top_left, box_height, box_width). If normalized_to_pixel is True, the values are float and are normalized with the image size. If normalized_to_pixel is False, the values are int and are in pixel.
+    """
+    # draw boxes on the image
+    image_width, image_height = image.size
+
+    if normalized_to_pixel:
+        bboxes = [(int(y * image_height), int(x * image_width), int(h * image_height), int(w * image_width)) for y, x, h, w in bboxes]
+
+    draw = ImageDraw.Draw(image)
+    for point in points:
+        x, y = point
+        draw.circle((x, y), radius=5, outline=edgecolor, width=linewidth)
+
+    if fn_save is not None: # PIL image
+        image.save(fn_save)
+    return image
+
+markhelper = MarkHelper()
+
+BBOX_DEDUPLICATION_IOU_PROPORTION = 0.5
+BBOX_GROUPING_VERTICAL_THRESHOLD = 20
+BBOX_GROUPING_HORIZONTAL_THRESHOLD = 20
+BBOX_AUG_TARGET = 2.0
+
+def _is_boxes_same_line_or_near(bbox1, bbox2, vertical_threshold, horizontal_threshold):
+    """check if two boxes are in the same line or close enough to be considered together"""
+    y1, x1, h1, w1 = bbox1
+    y2, x2, h2, w2 = bbox2
+
+    # Check if the boxes are close horizontally (consider the edge case where the boxes are touching)
+    horizontally_close = (x1 <= x2 and x2 - x1 <= w1 + horizontal_threshold) or (x2 <= x1 and x1 - x2 <= w2 + horizontal_threshold)
+
+    # Check if the boxes are close vertically (consider the edge case where the boxes are touching)
+    vertically_close = (y1 <= y2 and y2 - y1 <= h1 + vertical_threshold) or (y2 <= y1 and y1 - y2 <= h2 + vertical_threshold)
+
+    # Consider the boxes to be in the same line if they are vertically close and either overlap or are close horizontally
+    return vertically_close and horizontally_close
+
+def _build_adjacency_matrix(bboxes, vertical_threshold, horizontal_threshold):
+    """Build the adjacency matrix based on the merging criteria."""
+    num_boxes = len(bboxes)
+    A = np.zeros((num_boxes, num_boxes), dtype=int)
+
+    for i in range(num_boxes):
+        for j in range(i + 1, num_boxes):
+            if _is_boxes_same_line_or_near(bboxes[i], bboxes[j], vertical_threshold, horizontal_threshold):
+                A[i, j] = 1
+                A[j, i] = 1  # Symmetric matrix
+
+    return A
+
+def merge_connected_bboxes(bboxes, text_details,
+    vertical_threshold=BBOX_GROUPING_VERTICAL_THRESHOLD,
+    horizontal_threshold=BBOX_GROUPING_HORIZONTAL_THRESHOLD
+):
+    """Merge bboxes based on the adjacency matrix and return merged bboxes.
+    Args:
+        bboxes: A 2D array of shape (num_boxes, 4), where each row represents a bounding box: (y, x, height, width).
+        text_details: A list of text details for each bounding box.
+        vertical_threshold: The maximum vertical distance between two boxes to be considered in the same line.
+        horizontal_threshold: The maximum horizontal distance between two boxes to be considered close.
+    """
+    # return if there are no bboxes
+    if len(bboxes) <= 1:
+        return bboxes, text_details
+
+    # Convert bboxes (x1, y1, x2, y2) to (y, x, height, width) format
+    bboxes = np.array(bboxes)
+    bboxes = np.array([bboxes[:, 1], bboxes[:, 0], bboxes[:, 3] - bboxes[:, 1], bboxes[:, 2] - bboxes[:, 0]]).T
+
+    # Build adjacency matrix
+    A = _build_adjacency_matrix(bboxes, vertical_threshold, horizontal_threshold)
+
+    # Create graph from adjacency matrix
+    G = nx.from_numpy_array(A)
+
+    # Find connected components
+    components = list(nx.connected_components(G))
+
+    # Convert bboxes to (y_min, x_min, y_max, x_max) format
+    corners = np.copy(bboxes)
+    corners_y, corners_x, corners_h, corners_w = corners[:, 0], corners[:, 1], corners[:, 2], corners[:, 3]
+
+    corners_y_max = corners_y + corners_h
+    corners_x_max = corners_x + corners_w
+
+    # Merge bboxes for each connected component
+    merged_bboxes = []
+    merged_text_details = []
+    for component in components:
+        indices = list(component) # e.g., [32, 33, 34, 30, 31]
+        indices = sorted(indices)
+
+        # merge the text details
+        merged_text_details.append(' '.join([text_details[i] for i in indices]))
+
+        # merge the bboxes
+        y_min = min(corners_y[i] for i in indices)
+        x_min = min(corners_x[i] for i in indices)
+        y_max = max(corners_y_max[i] for i in indices)
+        x_max = max(corners_x_max[i] for i in indices)
+        merged_bboxes.append((y_min, x_min, y_max - y_min, x_max - x_min)) # Convert merged_bbox back to (y, x, height, width) format
+
+    # convert (y, x, height, width) to (x1, y1, x2, y2) format without np.array
+    merged_bboxes = [(bbox[1], bbox[0], bbox[1] + bbox[3], bbox[0] + bbox[2]) for bbox in merged_bboxes]
+    return merged_bboxes, merged_text_details
\ No newline at end of file

data/__init__.py

+# datasets
+from .epic import epic
+from .ego4d import ego4d
+from .openx import openx
+from .openx_magma import openx_magma
+from .magma import magma
+from .llava import llava
+from .seeclick import seeclick
+
+# (joint) datasets
+from .dataset import build_joint_dataset
+
+# data collators
+from .data_collator import DataCollatorForSupervisedDataset
+from .data_collator import DataCollatorForHFDataset
