Merge remote-tracking branch 'origin/lite' into lite

paddleocr.py

@@ -146,7 +146,8 @@ def parse_args(mMain=True, add_help=True):
         # DB parmas
         parser.add_argument("--det_db_thresh", type=float, default=0.3)
         parser.add_argument("--det_db_box_thresh", type=float, default=0.5)
-        parser.add_argument("--det_db_unclip_ratio", type=float, default=2.0)
+        parser.add_argument("--det_db_unclip_ratio", type=float, default=1.6)
+        parser.add_argument("--use_dilation", type=bool, default=False)

         # EAST parmas
         parser.add_argument("--det_east_score_thresh", type=float, default=0.8)
@@ -193,7 +194,8 @@ def parse_args(mMain=True, add_help=True):
             det_limit_type='max',
             det_db_thresh=0.3,
             det_db_box_thresh=0.5,
-            det_db_unclip_ratio=2.0,
+            det_db_unclip_ratio=1.6,
+            use_dilation=False,
             det_east_score_thresh=0.8,
             det_east_cover_thresh=0.1,
             det_east_nms_thresh=0.2,

ppocr/data/__init__.py

@@ -33,7 +33,7 @@ import paddle.distributed as dist

 from ppocr.data.imaug import transform, create_operators
 from ppocr.data.simple_dataset import SimpleDataSet
-from ppocr.data.lmdb_dataset import LMDBDateSet
+from ppocr.data.lmdb_dataset import LMDBDataSet

 __all__ = ['build_dataloader', 'transform', 'create_operators']

@@ -51,20 +51,21 @@ signal.signal(signal.SIGINT, term_mp)
 signal.signal(signal.SIGTERM, term_mp)


-def build_dataloader(config, mode, device, logger):
+def build_dataloader(config, mode, device, logger, seed=None):
     config = copy.deepcopy(config)

-    support_dict = ['SimpleDataSet', 'LMDBDateSet']
+    support_dict = ['SimpleDataSet', 'LMDBDataSet']
     module_name = config[mode]['dataset']['name']
     assert module_name in support_dict, Exception(
         'DataSet only support {}'.format(support_dict))
     assert mode in ['Train', 'Eval', 'Test'
                     ], "Mode should be Train, Eval or Test."

-    dataset = eval(module_name)(config, mode, logger)
+    dataset = eval(module_name)(config, mode, logger, seed)
     loader_config = config[mode]['loader']
     batch_size = loader_config['batch_size_per_card']
     drop_last = loader_config['drop_last']
+    shuffle = loader_config['shuffle']
     num_workers = loader_config['num_workers']
     if 'use_shared_memory' in loader_config.keys():
         use_shared_memory = loader_config['use_shared_memory']
@@ -75,14 +76,14 @@ def build_dataloader(config, mode, device, logger):
         batch_sampler = DistributedBatchSampler(
             dataset=dataset,
             batch_size=batch_size,
-            shuffle=False,
+            shuffle=shuffle,
             drop_last=drop_last)
     else:
         #Distribute data to single card
         batch_sampler = BatchSampler(
             dataset=dataset,
             batch_size=batch_size,
-            shuffle=False,
+            shuffle=shuffle,
             drop_last=drop_last)

     data_loader = DataLoader(

ppocr/data/imaug/__init__.py

@@ -21,7 +21,7 @@ from .make_border_map import MakeBorderMap
 from .make_shrink_map import MakeShrinkMap
 from .random_crop_data import EastRandomCropData, PSERandomCrop

-from .rec_img_aug import RecAug, RecResizeImg, ClsResizeImg
+from .rec_img_aug import RecAug, RecResizeImg, ClsResizeImg, SRNRecResizeImg
 from .randaugment import RandAugment
 from .operators import *
 from .label_ops import *

ppocr/data/imaug/label_ops.py

@@ -18,6 +18,7 @@ from __future__ import print_function
 from __future__ import unicode_literals

 import numpy as np
+import string


 class ClsLabelEncode(object):
@@ -92,18 +93,28 @@ class BaseRecLabelEncode(object):
                  character_type='ch',
                  use_space_char=False):
         support_character_type = [
-            'ch', 'en', 'en_sensitive', 'french', 'german', 'japan', 'korean'
+            'ch', 'en', 'EN_symbol', 'french', 'german', 'japan', 'korean',
+            'EN', 'it', 'xi', 'pu', 'ru', 'ar', 'ta', 'ug', 'fa', 'ur', 'rs',
+            'oc', 'rsc', 'bg', 'uk', 'be', 'te', 'ka', 'chinese_cht', 'hi',
+            'mr', 'ne'
         ]
         assert character_type in support_character_type, "Only {} are supported now but get {}".format(
             support_character_type, character_type)

         self.max_text_len = max_text_length
+        self.beg_str = "sos"
+        self.end_str = "eos"
         if character_type == "en":
             self.character_str = "0123456789abcdefghijklmnopqrstuvwxyz"
             dict_character = list(self.character_str)
-        elif character_type in ["ch", "french", "german", "japan", "korean"]:
+        elif character_type == "EN_symbol":
+            # same with ASTER setting (use 94 char).
+            self.character_str = string.printable[:-6]
+            dict_character = list(self.character_str)
+        elif character_type in support_character_type:
             self.character_str = ""
-            assert character_dict_path is not None, "character_dict_path should not be None when character_type is ch"
+            assert character_dict_path is not None, "character_dict_path should not be None when character_type is {}".format(
+                character_type)
             with open(character_dict_path, "rb") as fin:
                 lines = fin.readlines()
                 for line in lines:
@@ -112,11 +123,6 @@ class BaseRecLabelEncode(object):
             if use_space_char:
                 self.character_str += " "
             dict_character = list(self.character_str)
-        elif character_type == "en_sensitive":
-            # same with ASTER setting (use 94 char).
-            import string
-            self.character_str = string.printable[:-6]
-            dict_character = list(self.character_str)
         self.character_type = character_type
         dict_character = self.add_special_char(dict_character)
         self.dict = {}
@@ -193,16 +199,76 @@ class AttnLabelEncode(BaseRecLabelEncode):
         super(AttnLabelEncode,
               self).__init__(max_text_length, character_dict_path,
                              character_type, use_space_char)
+
+    def add_special_char(self, dict_character):
         self.beg_str = "sos"
         self.end_str = "eos"
+        dict_character = [self.beg_str] + dict_character + [self.end_str]
+        return dict_character
+
+    def __call__(self, data):
+        text = data['label']
+        text = self.encode(text)
+        if text is None:
+            return None
+        if len(text) >= self.max_text_len:
+            return None
+        data['length'] = np.array(len(text))
+        text = [0] + text + [len(self.character) - 1] + [0] * (self.max_text_len
+                                                               - len(text) - 2)
+        data['label'] = np.array(text)
+        return data
+
+    def get_ignored_tokens(self):
+        beg_idx = self.get_beg_end_flag_idx("beg")
+        end_idx = self.get_beg_end_flag_idx("end")
+        return [beg_idx, end_idx]
+
+    def get_beg_end_flag_idx(self, beg_or_end):
+        if beg_or_end == "beg":
+            idx = np.array(self.dict[self.beg_str])
+        elif beg_or_end == "end":
+            idx = np.array(self.dict[self.end_str])
+        else:
+            assert False, "Unsupport type %s in get_beg_end_flag_idx" \
+                          % beg_or_end
+        return idx
+
+
+class SRNLabelEncode(BaseRecLabelEncode):
+    """ Convert between text-label and text-index """
+
+    def __init__(self,
+                 max_text_length=25,
+                 character_dict_path=None,
+                 character_type='en',
+                 use_space_char=False,
+                 **kwargs):
+        super(SRNLabelEncode,
+              self).__init__(max_text_length, character_dict_path,
+                             character_type, use_space_char)

     def add_special_char(self, dict_character):
-        dict_character = [self.beg_str, self.end_str] + dict_character
+        dict_character = dict_character + [self.beg_str, self.end_str]
         return dict_character

-    def __call__(self, text):
+    def __call__(self, data):
+        text = data['label']
         text = self.encode(text)
-        return text
+        char_num = len(self.character)
+        if text is None:
+            return None
+        if len(text) > self.max_text_len:
+            return None
+        data['length'] = np.array(len(text))
+        text = text + [char_num - 1] * (self.max_text_len - len(text))
+        data['label'] = np.array(text)
+        return data
+
+    def get_ignored_tokens(self):
+        beg_idx = self.get_beg_end_flag_idx("beg")
+        end_idx = self.get_beg_end_flag_idx("end")
+        return [beg_idx, end_idx]

     def get_beg_end_flag_idx(self, beg_or_end):
         if beg_or_end == "beg":

ppocr/data/imaug/make_shrink_map.py

@@ -32,7 +32,6 @@ class MakeShrinkMap(object):
         text_polys, ignore_tags = self.validate_polygons(text_polys,
                                                          ignore_tags, h, w)
         gt = np.zeros((h, w), dtype=np.float32)
-        # gt = np.zeros((1, h, w), dtype=np.float32)
         mask = np.ones((h, w), dtype=np.float32)
         for i in range(len(text_polys)):
             polygon = text_polys[i]
@@ -44,21 +43,34 @@ class MakeShrinkMap(object):
                 ignore_tags[i] = True
             else:
                 polygon_shape = Polygon(polygon)
-                distance = polygon_shape.area * (
-                    1 - np.power(self.shrink_ratio, 2)) / polygon_shape.length
-                subject = [tuple(l) for l in text_polys[i]]
+                subject = [tuple(l) for l in polygon]
                 padding = pyclipper.PyclipperOffset()
                 padding.AddPath(subject, pyclipper.JT_ROUND,
                                 pyclipper.ET_CLOSEDPOLYGON)
-                shrinked = padding.Execute(-distance)
+                shrinked = []
+
+                # Increase the shrink ratio every time we get multiple polygon returned back
+                possible_ratios = np.arange(self.shrink_ratio, 1,
+                                            self.shrink_ratio)
+                np.append(possible_ratios, 1)
+                # print(possible_ratios)
+                for ratio in possible_ratios:
+                    # print(f"Change shrink ratio to {ratio}")
+                    distance = polygon_shape.area * (
+                        1 - np.power(ratio, 2)) / polygon_shape.length
+                    shrinked = padding.Execute(-distance)
+                    if len(shrinked) == 1:
+                        break
+
                 if shrinked == []:
                     cv2.fillPoly(mask,
                                  polygon.astype(np.int32)[np.newaxis, :, :], 0)
                     ignore_tags[i] = True
                     continue
-                shrinked = np.array(shrinked[0]).reshape(-1, 2)
-                cv2.fillPoly(gt, [shrinked.astype(np.int32)], 1)
-                # cv2.fillPoly(gt[0], [shrinked.astype(np.int32)], 1)
+
+                for each_shirnk in shrinked:
+                    shirnk = np.array(each_shirnk).reshape(-1, 2)
+                    cv2.fillPoly(gt, [shirnk.astype(np.int32)], 1)

         data['shrink_map'] = gt
         data['shrink_mask'] = mask
@@ -84,11 +96,12 @@ class MakeShrinkMap(object):
         return polygons, ignore_tags

     def polygon_area(self, polygon):
-        # return cv2.contourArea(polygon.astype(np.float32))
-        edge = 0
-        for i in range(polygon.shape[0]):
-            next_index = (i + 1) % polygon.shape[0]
-            edge += (polygon[next_index, 0] - polygon[i, 0]) * (
-                polygon[next_index, 1] - polygon[i, 1])
-
-        return edge / 2.
+        """
+        compute polygon area
+        """
+        area = 0
+        q = polygon[-1]
+        for p in polygon:
+            area += p[0] * q[1] - p[1] * q[0]
+            q = p
+        return area / 2.0

ppocr/data/imaug/operators.py

@@ -185,8 +185,8 @@ class DetResizeForTest(object):
         resize_h = int(h * ratio)
         resize_w = int(w * ratio)

-        resize_h = int(round(resize_h / 32) * 32)
-        resize_w = int(round(resize_w / 32) * 32)
+        resize_h = max(int(round(resize_h / 32) * 32), 32)
+        resize_w = max(int(round(resize_w / 32) * 32), 32)

         try:
             if int(resize_w) <= 0 or int(resize_h) <= 0:
