## DATASET
This is a collection of commonly used Chinese datasets, which is being updated continuously. You are welcome to contribute to this list～
- [ICDAR2019-LSVT](#ICDAR2019-LSVT)
- [ICDAR2017-RCTW-17](#ICDAR2017-RCTW-17)
- [Chinese Street View Text Recognition](#中文街景文字识别)
- [Chinese Document Text Recognition](#中文文档文字识别)
- [ICDAR2019-ArT](#ICDAR2019-ArT)
In addition to opensource data, users can also use synthesis tools to synthesize data themselves. Current available synthesis tools include [text_renderer](https://github.com/Sanster/text_renderer), [SynthText](https://github.com/ankush-me/SynthText), [TextRecognitionDataGenerator](https://github.com/Belval/TextRecognitionDataGenerator), etc.
<a name="ICDAR2019-LSVT"></a>
#### 1. ICDAR2019-LSVT
- **Data sources**：https://ai.baidu.com/broad/introduction?dataset=lsvt
- **Introduction**： A total of 45w Chinese street view images, including 5w (2w test + 3w training) fully labeled data (text coordinates + text content), 40w weakly labeled data (text content only), as shown in the following figure:
![](../datasets/LSVT_1.jpg)
(a) Fully labeled data
![](../datasets/LSVT_2.jpg)
(b) Weakly labeled data
- **Download link**：https://ai.baidu.com/broad/download?dataset=lsvt
<a name="ICDAR2017-RCTW-17"></a>
#### 2. ICDAR2017-RCTW-17
- **Data sources**：https://rctw.vlrlab.net/
- **Introduction**：It contains 12000 + images, most of them are collected in the wild through mobile camera. Some are screenshots. These images show a variety of scenes, including street views, posters, menus, indoor scenes and screenshots of mobile applications.
![](../datasets/rctw.jpg)
- **Download link**：https://rctw.vlrlab.net/dataset/
<a name="中文街景文字识别"></a>
#### 3. Chinese Street View Text Recognition
- **Data sources**：https://aistudio.baidu.com/aistudio/competition/detail/8
- **Introduction**：A total of 290000 pictures are included, of which 210000 are used as training sets (with labels) and 80000 are used as test sets (without labels). The dataset is collected from the Chinese street view, and is formed by by cutting out the text line area (such as shop signs, landmarks, etc.) in the street view picture. All the images are preprocessed: by using affine transform, the text area is proportionally mapped to a picture with a height of 48 pixels, as shown in the figure:
![](../datasets/ch_street_rec_1.png)
(a) Label: 魅派集成吊顶
![](../datasets/ch_street_rec_2.png)
(b) Label: 母婴用品连锁
- **Download link**
https://aistudio.baidu.com/aistudio/datasetdetail/8429
<a name="中文文档文字识别"></a>
#### 4. Chinese Document Text Recognition
- **Data sources**：https://github.com/YCG09/chinese_ocr
- **Introduction**：
- A total of 3.64 million pictures are divided into training set and validation set according to 99:1.
- Using Chinese corpus (news + classical Chinese), the data is randomly generated through changes in font, size, grayscale, blur, perspective, stretching, etc.
- 5990 characters including Chinese characters, English letters, numbers and punctuation（Characters set: https://github.com/YCG09/chinese_ocr/blob/master/train/char_std_5990.txt ）
- Each sample is fixed with 10 characters, and the characters are randomly intercepted from the sentences in the corpus
- Image resolution is 280x32
![](../datasets/ch_doc1.jpg)
![](../datasets/ch_doc2.jpg)
![](../datasets/ch_doc3.jpg)
- **Download link**：https://pan.baidu.com/s/1QkI7kjah8SPHwOQ40rS1Pw (Password: lu7m)
<a name="ICDAR2019-ArT"></a>
#### 5、ICDAR2019-ArT
- **Data source**：https://ai.baidu.com/broad/introduction?dataset=art
- **Introduction**：It includes 10166 images, 5603 in training sets and 4563 in test sets. It is composed of three parts: total text, scut-ctw1500 and Baidu curved scene text, including text with various shapes such as horizontal, multi-directional and curved.
![](../datasets/ArT.jpg)
- **Download link**：https://ai.baidu.com/broad/download?dataset=art
doc/doc_en/detection_en.md 0 → 100644
View file @ c1d19ce2
# TEXT DETECTION
This section uses the icdar15 dataset as an example to introduce the training, evaluation, and testing of the detection model in PaddleOCR.
## DATA PREPARATION
The icdar2015 dataset can be obtained from [official website](https://rrc.cvc.uab.es/?ch=4&com=downloads). Registration is required for downloading.
Decompress the downloaded dataset to the working directory, assuming it is decompressed under PaddleOCR/train_data/. In addition, PaddleOCR organizes many scattered annotation files into two separate annotation files for train and test respectively, which can be downloaded by wget:
```
# Under the PaddleOCR path
cd PaddleOCR/
wget -P ./train_data/ https://paddleocr.bj.bcebos.com/dataset/train_icdar2015_label.txt
wget -P ./train_data/ https://paddleocr.bj.bcebos.com/dataset/test_icdar2015_label.txt
```
After decompressing the data set and downloading the annotation file, PaddleOCR/train_data/ has two folders and two files, which are:
```
/PaddleOCR/train_data/icdar2015/text_localization/
└─ icdar_c4_train_imgs/ Training data of icdar dataset
└─ ch4_test_images/ Testing data of icdar dataset
└─ train_icdar2015_label.txt Training annotation of icdar dataset
└─ test_icdar2015_label.txt Test annotation of icdar dataset
```
The provided annotation file format is as follow, seperated by "\t":
```
" Image file name Image annotation information encoded by json.dumps"
ch4_test_images/img_61.jpg [{"transcription": "MASA", "points": [[310, 104], [416, 141], [418, 216], [312, 179]]}, {...}]
```
The image annotation after json.dumps() encoding is a list containing multiple dictionaries. The `points` in the dictionary represent the coordinates (x, y) of the four points of the text box, arranged clockwise from the point at the upper left corner.
`transcription` represents the text of the current text box, and this information is not needed in the text detection task.
If you want to train PaddleOCR on other datasets, you can build the annotation file according to the above format.
## TRAINING
First download the pretrained model. The detection model of PaddleOCR currently supports two backbones, namely MobileNetV3 and ResNet50_vd. You can use the model in [PaddleClas](https://github.com/PaddlePaddle/PaddleClas/tree/master/ppcls/modeling/architectures) to replace backbone according to your needs.
```
cd PaddleOCR/
# Download the pre-trained model of MobileNetV3
wget -P ./pretrain_models/ https://paddle-imagenet-models-name.bj.bcebos.com/MobileNetV3_large_x0_5_pretrained.tar
# Download the pre-trained model of ResNet50
wget -P ./pretrain_models/ https://paddle-imagenet-models-name.bj.bcebos.com/ResNet50_vd_ssld_pretrained.tar
# decompressing the pre-training model file, take MobileNetV3 as an example
tar xf ./pretrain_models/MobileNetV3_large_x0_5_pretrained.tar ./pretrain_models/
# Note: After decompressing the backbone pre-training weight file correctly, the file list in the folder is as follows:
./pretrain_models/MobileNetV3_large_x0_5_pretrained/
└─ conv_last_bn_mean
└─ conv_last_bn_offset
└─ conv_last_bn_scale
└─ conv_last_bn_variance
└─ ......
```
**START TRAINING**
*If CPU version installed, please set the parameter `use_gpu` to `false` in the configuration.*
```
python3 tools/train.py -c configs/det/det_mv3_db.yml
```
In the above instruction, use `-c` to select the training to use the `configs/det/det_db_mv3.yml` configuration file.
For a detailed explanation of the configuration file, please refer to [config](./config_en.md).
You can also use `-o` to change the training parameters without modifying the yml file. For example, adjust the training learning rate to 0.0001
```
python3 tools/train.py -c configs/det/det_mv3_db.yml -o Optimizer.base_lr=0.0001
```
**load trained model and conntinue training**
If you expect to load trained model and continue the training again, you can specify the parameter `Global.checkpoints` as the model path to be loaded.
For example:
```
python3 tools/train.py -c configs/det/det_mv3_db.yml -o Global.checkpoints=./your/trained/model
```
**Note**:The priority of `Global.checkpoints` is higher than that of `Global.pretrain_weights`, that is, when two parameters are specified at the same time, the model specified by Global.checkpoints will be loaded first. If the model path specified by `Global.checkpoints` is wrong, the one specified by `Global.pretrain_weights` will be loaded.
## EVALUATION
PaddleOCR calculates three indicators for evaluating performance of OCR detection task: Precision, Recall, and Hmean.
Run the following code to calculate the evaluation indicators. The result will be saved in the test result file specified by `save_res_path` in the configuration file `det_db_mv3.yml`
When evaluating, set post-processing parameters `box_thresh=0.6`, `unclip_ratio=1.5`. If you use different datasets, different models for training, these two parameters should be adjusted for better result.
```
python3 tools/eval.py -c configs/det/det_mv3_db.yml -o Global.checkpoints="{path/to/weights}/best_accuracy" PostProcess.box_thresh=0.6 PostProcess.unclip_ratio=1.5
```
The model parameters during training are saved in the `Global.save_model_dir` directory by default. When evaluating indicators, you need to set `Global.checkpoints` to point to the saved parameter file.
Such as:
```shell
python3 tools/eval.py -c configs/det/det_mv3_db.yml -o Global.checkpoints="./output/det_db/best_accuracy" PostProcess.box_thresh=0.6 PostProcess.unclip_ratio=1.5
```
* Note: `box_thresh` and `unclip_ratio` are parameters required for DB post-processing, and not need to be set when evaluating the EAST model.
## TEST
Test the detection result on a single image:
```shell
python3 tools/infer_det.py -c configs/det/det_mv3_db.yml -o TestReader.infer_img="./doc/imgs_en/img_10.jpg" Global.checkpoints="./output/det_db/best_accuracy"
```
When testing the DB model, adjust the post-processing threshold:
```shell
python3 tools/infer_det.py -c configs/det/det_mv3_db.yml -o TestReader.infer_img="./doc/imgs_en/img_10.jpg" Global.checkpoints="./output/det_db/best_accuracy" PostProcess.box_thresh=0.6 PostProcess.unclip_ratio=1.5
```
Test the detection result on all images in the folder:
```shell
python3 tools/infer_det.py -c configs/det/det_mv3_db.yml -o TestReader.infer_img="./doc/imgs_en/" Global.checkpoints="./output/det_db/best_accuracy"
```
doc/doc_en/handwritten_datasets_en.md 0 → 100644
View file @ c1d19ce2
# Handwritten OCR dataset
Here we have sorted out the commonly used handwritten OCR dataset datasets, which are being updated continuously. We welcome you to contribute datasets ~
- [Institute of automation, Chinese Academy of Sciences - handwritten Chinese dataset](#Institute of automation, Chinese Academy of Sciences - handwritten Chinese dataset)
- [NIST handwritten single character dataset - English](#NIST handwritten single character dataset - English)
<a name="Institute of automation, Chinese Academy of Sciences - handwritten Chinese dataset"></a>
## Institute of automation, Chinese Academy of Sciences - handwritten Chinese dataset
- **Data source**:http://www.nlpr.ia.ac.cn/databases/handwriting/Download.html
- **Data introduction**:
* It includes online and offline handwritten data,`HWDB1.0~1.2` has totally 3895135 handwritten single character samples, which belong to 7356 categories (7185 Chinese characters and 171 English letters, numbers and symbols);`HWDB2.0~2.2` has totally 5091 pages of images, which are divided into 52230 text lines and 1349414 words. All text and text samples are stored as grayscale images. Some sample words are shown below.
![](../datasets/CASIA_0.jpg)
- **Download address**:http://www.nlpr.ia.ac.cn/databases/handwriting/Download.html
- **使用建议**:Data for single character, white background, can form a large number of text lines for training. White background can be processed into transparent state, which is convenient to add various backgrounds. For the case of semantic needs, it is suggested to extract single character from real corpus to form text lines.
<a name="NIST handwritten single character dataset - English"></a>
## NIST handwritten single character dataset - English(NIST Handprinted Forms and Characters Database)
- **Data source**: [https://www.nist.gov/srd/nist-special-database-19](https://www.nist.gov/srd/nist-special-database-19)
- **Data introduction**: NIST19 dataset is suitable for handwritten document and character recognition model training. It is extracted from the handwritten sample form of 3600 authors and contains 810000 character images in total. Nine of them are shown below.
![](../datasets/nist_demo.png)
- **Download address**: [https://www.nist.gov/srd/nist-special-database-19](https://www.nist.gov/srd/nist-special-database-19)
doc/doc_en/inference_en.md 0 → 100644
View file @ c1d19ce2
# Reasoning based on Python prediction engine
The inference model (the model saved by fluid.io.save_inference_model) is generally a solidified model saved after the model training is completed, and is mostly used to give prediction in deployment.
The model saved during the training process is the checkpoints model, which saves the parameters of the model and is mostly used to resume training.
Compared with the checkpoints model, the inference model will additionally save the structural information of the model. It has superior performance in predicting in deployment and accelerating inferencing, is flexible and convenient, and is suitable for integration with actual systems. For more details, please refer to the document [Classification Framework](https://paddleclas.readthedocs.io/zh_CN/latest/extension/paddle_inference.html).
Next, we first introduce how to convert a trained model into an inference model, and then we will introduce text detection, text recognition, and the concatenation of them based on inference model.
## CONVERT TRAINING MODEL TO INFERENCE MODEL
### Convert detection model to inference model
Download the lightweight Chinese detection model:
```
wget -P ./ch_lite/ https://paddleocr.bj.bcebos.com/ch_models/ch_det_mv3_db.tar && tar xf ./ch_lite/ch_det_mv3_db.tar -C ./ch_lite/
```
The above model is a DB algorithm trained with MobileNetV3 as the backbone. To convert the trained model into an inference model, just run the following command:
```
# -c Set the training algorithm yml configuration file
# -o Set optional parameters
# Global.checkpoints parameter Set the training model address to be converted without adding the file suffix .pdmodel, .pdopt or .pdparams.
# Global.save_inference_dir Set the address where the converted model will be saved.
python3 tools/export_model.py -c configs/det/det_mv3_db.yml -o Global.checkpoints=./ch_lite/det_mv3_db/best_accuracy \
Global.save_inference_dir=./inference/det_db/
```
When converting to an inference model, the configuration file used is the same as the configuration file used during training. In addition, you also need to set the `Global.checkpoints` and `Global.save_inference_dir` parameters in the configuration file.
`Global.checkpoints` points to the model parameter file saved during training, and `Global.save_inference_dir` is the directory where the generated inference model is saved.
After the conversion is successful, there are two files in the `save_inference_dir` directory:
```
inference/det_db/
└─ model Check the program file of inference model
└─ params Check the parameter file of the inference model
```
### Convert recognition model to inference model
Download the lightweight Chinese recognition model:
```
wget -P ./ch_lite/ https://paddleocr.bj.bcebos.com/ch_models/ch_rec_mv3_crnn.tar && tar xf ./ch_lite/ch_rec_mv3_crnn.tar -C ./ch_lite/
```
The recognition model is converted to the inference model in the same way as the detection, as follows:
```
# -c Set the training algorithm yml configuration file
# -o Set optional parameters
# Global.checkpoints parameter Set the training model address to be converted without adding the file suffix .pdmodel, .pdopt or .pdparams.
# Global.save_inference_dir Set the address where the converted model will be saved.
python3 tools/export_model.py -c configs/rec/rec_chinese_lite_train.yml -o Global.checkpoints=./ch_lite/rec_mv3_crnn/best_accuracy \
Global.save_inference_dir=./inference/rec_crnn/
```
If you have a model trained on your own dataset with a different dictionary file, please make sure that you modify the `character_dict_path` in the configuration file to your dictionary file path.
After the conversion is successful, there are two files in the directory:
```
/inference/rec_crnn/
└─ model Identify the saved model files
└─ params Identify the parameter files of the inference model
```
## TEXT DETECTION MODEL INFERENCE
The following will introduce the lightweight Chinese detection model inference, DB text detection model inference and EAST text detection model inference. The default configuration is based on the inference setting of the DB text detection model.
Because EAST and DB algorithms are very different, when inference, it is necessary to **adapt the EAST text detection algorithm by passing in corresponding parameters**.
### 1. LIGHTWEIGHT CHINESE DETECTION MODEL INFERENCE
For lightweight Chinese detection model inference, you can execute the following commands:
```
python3 tools/infer/predict_det.py --image_dir="./doc/imgs/2.jpg" --det_model_dir="./inference/det_db/"
```
The visual text detection results are saved to the ./inference_results folder by default, and the name of the result file is prefixed with'det_res'. Examples of results are as follows:
![](../imgs_results/det_res_2.jpg)
By setting the size of the parameter `det_max_side_len`, the maximum value of picture normalization in the detection algorithm is changed. When the length and width of the picture are less than det_max_side_len, the original picture is used for prediction, otherwise the picture is scaled to the maximum value for prediction. This parameter is set to det_max_side_len=960 by default. If the resolution of the input picture is relatively large and you want to use a larger resolution for prediction, you can execute the following command:
```
python3 tools/infer/predict_det.py --image_dir="./doc/imgs/2.jpg" --det_model_dir="./inference/det_db/" --det_max_side_len=1200
```
If you want to use the CPU for prediction, execute the command as follows
```
python3 tools/infer/predict_det.py --image_dir="./doc/imgs/2.jpg" --det_model_dir="./inference/det_db/" --use_gpu=False
```
### 2. DB TEXT DETECTION MODEL INFERENCE
First, convert the model saved in the DB text detection training process into an inference model. Taking the model based on the Resnet50_vd backbone network and trained on the ICDAR2015 English dataset as an example ([model download link](https://paddleocr.bj.bcebos.com/det_r50_vd_db.tar)), you can use the following command to convert:
```
# Set the yml configuration file of the training algorithm after -c
# The Global.checkpoints parameter sets the address of the training model to be converted without adding the file suffix .pdmodel, .pdopt or .pdparams.
# The Global.save_inference_dir parameter sets the address where the converted model will be saved.
python3 tools/export_model.py -c configs/det/det_r50_vd_db.yml -o Global.checkpoints="./models/det_r50_vd_db/best_accuracy" Global.save_inference_dir="./inference/det_db"
```
DB text detection model inference, you can execute the following command:
```
python3 tools/infer/predict_det.py --image_dir="./doc/imgs_en/img_10.jpg" --det_model_dir="./inference/det_db/"
```
The visualized text detection results are saved to the `./inference_results` folder by default, and the name of the result file is prefixed with 'det_res'. Examples of results are as follows:
![](../imgs_results/det_res_img_10_db.jpg)
**Note**: Since the ICDAR2015 dataset has only 1,000 training images, mainly for English scenes, the above model has very poor detection result on Chinese text images.
### 3. EAST TEXT DETECTION MODEL INFERENCE
First, convert the model saved in the EAST text detection training process into an inference model. Taking the model based on the Resnet50_vd backbone network and trained on the ICDAR2015 English dataset as an example ([model download link](https://paddleocr.bj.bcebos.com/det_r50_vd_east.tar)), you can use the following command to convert:
```
# Set the yml configuration file of the training algorithm after -c
# The Global.checkpoints parameter sets the address of the training model to be converted without adding the file suffix .pdmodel, .pdopt or .pdparams.
# The Global.save_inference_dir parameter sets the address where the converted model will be saved.
python3 tools/export_model.py -c configs/det/det_r50_vd_east.yml -o Global.checkpoints="./models/det_r50_vd_east/best_accuracy" Global.save_inference_dir="./inference/det_east"
```
For EAST text detection model inference, you need to set the parameter det_algorithm, specify the detection algorithm type to EAST, run the following command:
```
python3 tools/infer/predict_det.py --image_dir="./doc/imgs_en/img_10.jpg" --det_model_dir="./inference/det_east/" --det_algorithm="EAST"
```
The visualized text detection results are saved to the `./inference_results` folder by default, and the name of the result file is prefixed with 'det_res'. Examples of results are as follows:
![](../imgs_results/det_res_img_10_east.jpg)
**Note**: The Python version of NMS in EAST post-processing used in this codebase so the prediction speed is quite slow. If you use the C++ version, there will be a significant speedup.
## TEXT RECOGNITION MODEL INFERENCE
The following will introduce the lightweight Chinese recognition model inference, other CTC-based and Attention-based text recognition models inference. For Chinese text recognition, it is recommended to choose the recognition model based on CTC loss. In practice, it is also found that the result of the model based on Attention loss is not as good as the one based on CTC loss. In addition, if the characters dictionary is modified during training, make sure that you use the same characters set during inferencing. Please check below for details.
### 1. LIGHTWEIGHT CHINESE TEXT RECOGNITION MODEL REFERENCE
For lightweight Chinese recognition model inference, you can execute the following commands:
```
python3 tools/infer/predict_rec.py --image_dir="./doc/imgs_words/ch/word_4.jpg" --rec_model_dir="./inference/rec_crnn/"
```
![](../imgs_words/ch/word_4.jpg)
After executing the command, the prediction results (recognized text and score) of the above image will be printed on the screen.
Predicts of ./doc/imgs_words/ch/word_4.jpg:['实力活力', 0.89552695]
### 2. CTC-BASED TEXT RECOGNITION MODEL INFERENCE
Taking STAR-Net as an example, we introduce the recognition model inference based on CTC loss. CRNN and Rosetta are used in a similar way, by setting the recognition algorithm parameter `rec_algorithm`.
First, convert the model saved in the STAR-Net text recognition training process into an inference model. Taking the model based on Resnet34_vd backbone network, using MJSynth and SynthText (two English text recognition synthetic datasets) for training, as an example ([model download address](https://paddleocr.bj.bcebos.com/rec_r34_vd_tps_bilstm_ctc.tar)). It can be converted as follow:
```
# Set the yml configuration file of the training algorithm after -c
# The Global.checkpoints parameter sets the address of the training model to be converted without adding the file suffix .pdmodel, .pdopt or .pdparams.
# The Global.save_inference_dir parameter sets the address where the converted model will be saved.
python3 tools/export_model.py -c configs/rec/rec_r34_vd_tps_bilstm_ctc.yml -o Global.checkpoints="./models/rec_r34_vd_tps_bilstm_ctc/best_accuracy" Global.save_inference_dir="./inference/starnet"
```
For STAR-Net text recognition model inference, execute the following commands:
```
python3 tools/infer/predict_rec.py --image_dir="./doc/imgs_words_en/word_336.png" --rec_model_dir="./inference/starnet/" --rec_image_shape="3, 32, 100" --rec_char_type="en"
```
### 3. ATTENTION-BASED TEXT RECOGNITION MODEL INFERENCE
![](../imgs_words_en/word_336.png)
After executing the command, the recognition result of the above image is as follows:
Predicts of ./doc/imgs_words_en/word_336.png:['super', 0.9999555]
**Note**：Since the above model refers to [DTRB](https://arxiv.org/abs/1904.01906) text recognition training and evaluation process, it is different from the training of lightweight Chinese recognition model in two aspects:
- The image resolution used in training is different: the image resolution used in training the above model is [3，32，100], while during our Chinese model training, in order to ensure the recognition effect of long text, the image resolution used in training is [3, 32, 320]. The default shape parameter of the inference stage is the image resolution used in training phase, that is [3, 32, 320]. Therefore, when running inference of the above English model here, you need to set the shape of the recognition image through the parameter `rec_image_shape`.
- Character list: the experiment in the DTRB paper is only for 26 lowercase English characters and 10 numbers, a total of 36 characters. All upper and lower case characters are converted to lower case characters, and characters not in the above list are ignored and considered as spaces. Therefore, no characters dictionary file is used here, but a dictionary is generated by the below command. Therefore, the parameter `rec_char_type` needs to be set during inference, which is specified as "en" in English.
```
self.character_str = "0123456789abcdefghijklmnopqrstuvwxyz"
dict_character = list(self.character_str)
```
### 4. TEXT RECOGNITION MODEL INFERENCE USING CUSTOM CHARACTERS DICTIONARY
If the chars dictionary is modified during training, you need to specify the new dictionary path by setting the parameter `rec_char_dict_path` when using your inference model to predict.
```
python3 tools/infer/predict_rec.py --image_dir="./doc/imgs_words_en/word_336.png" --rec_model_dir="./your inference model" --rec_image_shape="3, 32, 100" --rec_char_type="en" --rec_char_dict_path="your text dict path"
```
## TEXT DETECTION AND RECOGNITION INFERENCE CONCATENATION
### 1. LIGHTWEIGHT CHINESE MODEL
When performing prediction, you need to specify the path of a single image or a folder of images through the parameter `image_dir`, the parameter `det_model_dir` specifies the path to detect the inference model, and the parameter `rec_model_dir` specifies the path to identify the inference model. The visualized recognition results are saved to the `./inference_results` folder by default.
```
python3 tools/infer/predict_system.py --image_dir="./doc/imgs/2.jpg" --det_model_dir="./inference/det_db/" --rec_model_dir="./inference/rec_crnn/"
```
After executing the command, the recognition result image is as follows:
![](../imgs_results/2.jpg)
### 2. OTHER MODELS
If you want to try other detection algorithms or recognition algorithms, please refer to the above text detection model inference and text recognition model inference, update the corresponding configuration and model, the following command uses the combination of the EAST text detection and STAR-Net text recognition:
```
python3 tools/infer/predict_system.py --image_dir="./doc/imgs_en/img_10.jpg" --det_model_dir="./inference/det_east/" --det_algorithm="EAST" --rec_model_dir="./inference/starnet/" --rec_image_shape="3, 32, 100" --rec_char_type="en"
```
After executing the command, the recognition result image is as follows:
![](../imgs_results/img_10.jpg)
doc/doc_en/installation_en.md 0 → 100644
View file @ c1d19ce2
## QUICK INSTALLATION
After testing, paddleocr can run on glibc 2.23. You can also test other glibc versions or install glic 2.23 for the best compatibility.
PaddleOCR working environment:
- PaddlePaddle1.7
- python3.7
- glibc 2.23
It is recommended to use the docker provided by us to run PaddleOCR, please refer to the use of docker [link](https://docs.docker.com/get-started/).
*If you want to directly run the prediction code on mac or windows, you can start from step 2.*
**1. (Recommended) Prepare a docker environment. The first time you use this image, it will be downloaded automatically. Please be patient.**
```
# Switch to the working directory
cd /home/Projects
# You need to create a docker container for the first run, and do not need to run the current command when you run it again
# Create a docker container named ppocr and map the current directory to the /paddle directory of the container
#If using CPU, use docker instead of nvidia-docker to create docker
sudo docker run --name ppocr -v $PWD:/paddle --network=host -it hub.baidubce.com/paddlepaddle/paddle:latest-gpu-cuda9.0-cudnn7-dev /bin/bash
```
If using CUDA9, please run the following command to create a container:
```
sudo nvidia-docker run --name ppocr -v $PWD:/paddle --network=host -it hub.baidubce.com/paddlepaddle/paddle:latest-gpu-cuda9.0-cudnn7-dev /bin/bash
```
If using CUDA10, please run the following command to create a container:
```
sudo nvidia-docker run --name ppocr -v $PWD:/paddle --network=host -it hub.baidubce.com/paddlepaddle/paddle:latest-gpu-cuda10.0-cudnn7-dev /bin/bash
```
You can also visit [DockerHub](https://hub.docker.com/r/paddlepaddle/paddle/tags/) to get the image that fits your machine.
```
# ctrl+P+Q to exit docker, to re-enter docker using the following command:
sudo docker container exec -it ppocr /bin/bash
```
Note: If the docker pull is too slow, you can download and load the docker image manually according to the following steps. Take cuda9 docker for example, you only need to change cuda9 to cuda10 to use cuda10 docker:
```
# Download the CUDA9 docker compressed file and unzip it
wget https://paddleocr.bj.bcebos.com/docker/docker_pdocr_cuda9.tar.gz
# To reduce download time, the uploaded docker image is compressed and needs to be decompressed
tar zxf docker_pdocr_cuda9.tar.gz
# Create image
docker load < docker_pdocr_cuda9.tar
# After completing the above steps, check whether the downloaded image is loaded through docker images
docker images
# If you have the following output after executing docker images, you can follow step 1 to create a docker environment.
hub.baidubce.com/paddlepaddle/paddle latest-gpu-cuda9.0-cudnn7-dev f56310dcc829
```
**2. Install PaddlePaddle Fluid v1.7 (the higher version is not supported yet, the adaptation work is in progress)**
```
pip3 install --upgrade pip
# If you have cuda9 installed on your machine, please run the following command to install
python3 -m pip install paddlepaddle-gpu==1.7.2.post97 -i https://pypi.tuna.tsinghua.edu.cn/simple
# If you have cuda10 installed on your machine, please run the following command to install
python3 -m pip install paddlepaddle-gpu==1.7.2.post107 -i https://pypi.tuna.tsinghua.edu.cn/simple
# If you only have cpu on your machine, please run the following command to install
python3 -m pip install paddlepaddle==1.7.2 -i https://pypi.tuna.tsinghua.edu.cn/simple
```
For more software version requirements, please refer to the instructions in [Installation Document](https://www.paddlepaddle.org.cn/install/quick) for operation.
**3. Clone PaddleOCR repo**
```
# Recommend
git clone https://github.com/PaddlePaddle/PaddleOCR
# If you cannot pull successfully due to network problems, you can also choose to use the code hosting on the cloud:
git clone https://gitee.com/paddlepaddle/PaddleOCR
# Note: The cloud-hosting code may not be able to synchronize the update with this GitHub project in real time. There might be a delay of 3-5 days. Please give priority to the recommended method.
```
**4. Install third-party libraries**
```
cd PaddleOCR
pip3 install -r requirments.txt
```
If you getting this error `OSError: [WinError 126] The specified module could not be found` when you install shapely on windows.
Please try to download Shapely whl file using [http://www.lfd.uci.edu/~gohlke/pythonlibs/#shapely](http://www.lfd.uci.edu/~gohlke/pythonlibs/#shapely).
Reference: [Solve shapely installation on windows](https://stackoverflow.com/questions/44398265/install-shapely-oserror-winerror-126-the-specified-module-could-not-be-found)
doc/doc_en/quickstart_en.md 0 → 100644
View file @ c1d19ce2
# Quick start of Chinese OCR model
## 1. Prepare for the environment
Please refer to [quick installation](./installation_en.md) to configure the PaddleOCR operating environment.
## 2.inference models
| Name | Introduction | Detection model | Recognition model | Recognition model with space support |
|-|-|-|-|-|
|chinese_db_crnn_mobile| Ultra-lightweight Chinese OCR model |[inference model](https://paddleocr.bj.bcebos.com/ch_models/ch_det_mv3_db_infer.tar) / [pretrained model](https://paddleocr.bj.bcebos.com/ch_models/ch_det_mv3_db.tar)|[inference model](https://paddleocr.bj.bcebos.com/ch_models/ch_rec_mv3_crnn_infer.tar) / [pretrained model](https://paddleocr.bj.bcebos.com/ch_models/ch_rec_mv3_crnn.tar)|[inference model](https://paddleocr.bj.bcebos.com/ch_models/ch_rec_mv3_crnn_enhance_infer.tar) / [pretrained model](https://paddleocr.bj.bcebos.com/ch_models/ch_rec_mv3_crnn_enhance.tar)
|chinese_db_crnn_server| Universal Chinese OCR model |[inference model](https://paddleocr.bj.bcebos.com/ch_models/ch_det_r50_vd_db_infer.tar) / [pretrained model](https://paddleocr.bj.bcebos.com/ch_models/ch_det_r50_vd_db.tar)|[inference model](https://paddleocr.bj.bcebos.com/ch_models/ch_rec_r34_vd_crnn_infer.tar) / [pretrained model](https://paddleocr.bj.bcebos.com/ch_models/ch_rec_r34_vd_crnn.tar)|[inference model](https://paddleocr.bj.bcebos.com/ch_models/ch_rec_r34_vd_crnn_enhance_infer.tar) / [pretrained model](https://paddleocr.bj.bcebos.com/ch_models/ch_rec_r34_vd_crnn_enhance.tar)
* If wget is not installed in the windows environment, you can copy the link to the browser to download when downloading the model, and uncompress it and place it in the corresponding directory.
Copy the download address of the `inference model` for detection and recognition in the table above, and uncompress them.
```
mkdir inference && cd inference
# Download the detection model and unzip
wget {url/of/detection/inference_model} && tar xf {name/of/detection/inference_model/package}
# Download the recognition model and unzip
wget {url/of/recognition/inference_model} && tar xf {name/of/recognition/inference_model/package}
cd ..
```
Take the ultra-lightweight model as an example:
```
mkdir inference && cd inference
# Download the detection model of the ultra-lightweight Chinese OCR model and uncompress it
wget https://paddleocr.bj.bcebos.com/ch_models/ch_det_mv3_db_infer.tar && tar xf ch_det_mv3_db_infer.tar
# Download the recognition model of the ultra-lightweight Chinese OCR model and uncompress it
wget https://paddleocr.bj.bcebos.com/ch_models/ch_rec_mv3_crnn_infer.tar && tar xf ch_rec_mv3_crnn_infer.tar
cd ..
```
After decompression, the file structure should be as follows:
```
|-inference
|-ch_rec_mv3_crnn
|- model
|- params
|-ch_det_mv3_db
|- model
|- params
...
```
## 3. Single image or image set prediction
* The following code implements text detection and recognition process. When performing prediction, you need to specify the path of a single image or image set through the parameter `image_dir`, the parameter `det_model_dir` specifies the path to detect the inference model, and the parameter `rec_model_dir` specifies the path to identify the inference model. The visual results are saved to the `./inference_results` folder by default.
```bash
# Predict a single image specified by image_dir
python3 tools/infer/predict_system.py --image_dir="./doc/imgs/11.jpg" --det_model_dir="./inference/ch_det_mv3_db/" --rec_model_dir="./inference/ch_rec_mv3_crnn/"
# Predict imageset specified by image_dir
python3 tools/infer/predict_system.py --image_dir="./doc/imgs/" --det_model_dir="./inference/ch_det_mv3_db/" --rec_model_dir="./inference/ch_rec_mv3_crnn/"
# If you want to use the CPU for prediction, you need to set the use_gpu parameter to False
python3 tools/infer/predict_system.py --image_dir="./doc/imgs/11.jpg" --det_model_dir="./inference/ch_det_mv3_db/" --rec_model_dir="./inference/ch_rec_mv3_crnn/" --use_gpu=False
```
- Universal Chinese OCR model
Please follow the above steps to download the corresponding models and update the relevant parameters, The example is as follows.
```
# Predict a single image specified by image_dir
python3 tools/infer/predict_system.py --image_dir="./doc/imgs/11.jpg" --det_model_dir="./inference/ch_det_r50_vd_db/" --rec_model_dir="./inference/ch_rec_r34_vd_crnn/"
```
- Universal Chinese OCR model with the support of space
Please follow the above steps to download the corresponding models and update the relevant parameters, The example is as follows.
* Note: Please update the source code to the latest version and add parameters `--use_space_char=True`
```
# Predict a single image specified by image_dir
python3 tools/infer/predict_system.py --image_dir="./doc/imgs_en/img_12.jpg" --det_model_dir="./inference/ch_det_r50_vd_db/" --rec_model_dir="./inference/ch_rec_r34_vd_crnn_enhance/" --use_space_char=True
```
For more text detection and recognition tandem reasoning, please refer to the document tutorial
: [Inference with Python inference engine](./inference_en.md)。
In addition, the tutorial also provides other deployment methods for the Chinese OCR model:
- [Server-side C++ inference](../../deploy/cpp_infer/readme_en.md)
- [Service deployment](./serving_en.md)
- [End-to-end deployment](../../deploy/lite/readme_en.md)
doc/doc_en/recognition_en.md 0 → 100644
View file @ c1d19ce2
## TEXT RECOGNITION
### DATA PREPARATION
PaddleOCR supports two data formats: `LMDB` is used to train public data and evaluation algorithms; `general data` is used to train your own data:
Please organize the dataset as follows:
The default storage path for training data is `PaddleOCR/train_data`, if you already have a dataset on your disk, just create a soft link to the dataset directory:
```
ln -sf <path/to/dataset> <path/to/paddle_ocr>/train_data/dataset
```
* Dataset download
If you do not have a dataset locally, you can download it on the official website [icdar2015](http://rrc.cvc.uab.es/?ch=4&com=downloads). Also refer to [DTRB](https://github.com/clovaai/deep-text-recognition-benchmark#download-lmdb-dataset-for-traininig-and-evaluation-from-here)，download the lmdb format dataset required for benchmark
* Use your own dataset:
If you want to use your own data for training, please refer to the following to organize your data.
- Training set
First put the training images in the same folder (train_images), and use a txt file (rec_gt_train.txt) to store the image path and label.
* Note: by default, the image path and image label are split with \t, if you use other methods to split, it will cause training error
```
" Image file name Image annotation "
train_data/train_0001.jpg 简单可依赖
train_data/train_0002.jpg 用科技让复杂的世界更简单
```
PaddleOCR provides label files for training the icdar2015 dataset, which can be downloaded in the following ways:
```
# Training set label
wget -P ./train_data/ic15_data https://paddleocr.bj.bcebos.com/dataset/rec_gt_train.txt
# Test Set Label
wget -P ./train_data/ic15_data https://paddleocr.bj.bcebos.com/dataset/rec_gt_test.txt
```
The final training set should have the following file structure:
```
|-train_data
|-ic15_data
|- rec_gt_train.txt
|- train
|- word_001.png
|- word_002.jpg
|- word_003.jpg
| ...
```
- Test set
Similar to the training set, the test set also needs to be provided a folder containing all images (test) and a rec_gt_test.txt. The structure of the test set is as follows:
```
|-train_data
|-ic15_data
|- rec_gt_test.txt
|- test
|- word_001.jpg
|- word_002.jpg
|- word_003.jpg
| ...
```
- Dictionary
Finally, a dictionary ({word_dict_name}.txt) needs to be provided so that when the model is trained, all the characters that appear can be mapped to the dictionary index.
Therefore, the dictionary needs to contain all the characters that you want to be recognized correctly. {word_dict_name}.txt needs to be written in the following format and saved in the `utf-8` encoding format:
```
l
d
a
d
r
n
```
In `word_dict.txt`, there is a single word in each line, which maps characters and numeric indexes together, e.g "and" will be mapped to [2 5 1]
`ppocr/utils/ppocr_keys_v1.txt` is a Chinese dictionary with 6623 characters.
`ppocr/utils/ic15_dict.txt` is an English dictionary with 36 characters.
You can use them if needed.
To customize the dict file, please modify the `character_dict_path` field in `configs/rec/rec_icdar15_train.yml` and set `character_type` to `ch`.
- Custom dictionary
If you need to customize dic file, please add character_dict_path field in configs/rec/rec_icdar15_train.yml to point to your dictionary path. And set character_type to ch.
- Add space category
If you want to support the recognition of the `space` category, please set the `use_space_char` field in the yml file to `true`.
**Note: use_space_char only takes effect when character_type=ch**
### TRAINING
PaddleOCR provides training scripts, evaluation scripts, and prediction scripts. In this section, the CRNN recognition model will be used as an example:
First download the pretrain model, you can download the trained model to finetune on the icdar2015 data:
```
cd PaddleOCR/
# Download the pre-trained model of MobileNetV3
wget -P ./pretrain_models/ https://paddleocr.bj.bcebos.com/rec_mv3_none_bilstm_ctc.tar
# Decompress model parameters
cd pretrain_models
tar -xf rec_mv3_none_bilstm_ctc.tar && rm -rf rec_mv3_none_bilstm_ctc.tar
```
Start training:
```
# Set PYTHONPATH path
export PYTHONPATH=$PYTHONPATH:.
# GPU training Support single card and multi-card training, specify the card number through CUDA_VISIBLE_DEVICES
export CUDA_VISIBLE_DEVICES=0,1,2,3
# Training icdar15 English data
python3 tools/train.py -c configs/rec/rec_icdar15_train.yml
```
- Data Augmentation
PaddleOCR provides a variety of data augmentation methods. If you want to add disturbance during training, please set `distort: true` in the configuration file.
The default perturbation methods are: cvtColor, blur, jitter, Gasuss noise, random crop, perspective, color reverse.
Each disturbance method is selected with a 50% probability during the training process. For specific code implementation, please refer to: [img_tools.py](https://github.com/PaddlePaddle/PaddleOCR/blob/develop/ppocr/data/rec/img_tools.py)
- Training
PaddleOCR supports alternating training and evaluation. You can modify `eval_batch_step` in `configs/rec/rec_icdar15_train.yml` to set the evaluation frequency. By default, it is evaluated every 500 iter and the best acc model is saved under `output/rec_CRNN/best_accuracy` during the evaluation process.
If the evaluation set is large, the test will be time-consuming. It is recommended to reduce the number of evaluations, or evaluate after training.
* Tip: You can use the `-c` parameter to select multiple model configurations under the `configs/rec/` path for training. The recognition algorithms supported by PaddleOCR are:
| Configuration file | Algorithm | backbone | trans | seq | pred |
| :--------: | :-------: | :-------: | :-------: | :-----: | :-----: |
| rec_chinese_lite_train.yml | CRNN | Mobilenet_v3 small 0.5 | None | BiLSTM | ctc |
| rec_icdar15_train.yml | CRNN | Mobilenet_v3 large 0.5 | None | BiLSTM | ctc |
| rec_mv3_none_bilstm_ctc.yml | CRNN | Mobilenet_v3 large 0.5 | None | BiLSTM | ctc |
| rec_mv3_none_none_ctc.yml | Rosetta | Mobilenet_v3 large 0.5 | None | None | ctc |
| rec_mv3_tps_bilstm_ctc.yml | STARNet | Mobilenet_v3 large 0.5 | tps | BiLSTM | ctc |
| rec_mv3_tps_bilstm_attn.yml | RARE | Mobilenet_v3 large 0.5 | tps | BiLSTM | attention |
| rec_r34_vd_none_bilstm_ctc.yml | CRNN | Resnet34_vd | None | BiLSTM | ctc |
| rec_r34_vd_none_none_ctc.yml | Rosetta | Resnet34_vd | None | None | ctc |
| rec_r34_vd_tps_bilstm_attn.yml | RARE | Resnet34_vd | tps | BiLSTM | attention |
| rec_r34_vd_tps_bilstm_ctc.yml | STARNet | Resnet34_vd | tps | BiLSTM | ctc |
For training Chinese data, it is recommended to use `rec_chinese_lite_train.yml`. If you want to try the result of other algorithms on the Chinese data set, please refer to the following instructions to modify the configuration file:
co
Take `rec_mv3_none_none_ctc.yml` as an example:
```
Global:
...
# Modify image_shape to fit long text
image_shape: [3, 32, 320]
...
# Modify character type
character_type: ch
# Add a custom dictionary, such as modify the dictionary, please point the path to the new dictionary
character_dict_path: ./ppocr/utils/ppocr_keys_v1.txt
...
# Modify reader type
reader_yml: ./configs/rec/rec_chinese_reader.yml
# Whether to use data augmentation
distort: true
# Whether to recognize spaces
use_space_char: true
...
...
Optimizer:
...
# Add learning rate decay strategy
decay:
function: cosine_decay
# Each epoch contains iter number
step_each_epoch: 20
# Total epoch number
total_epoch: 1000
```
**Note that the configuration file for prediction/evaluation must be consistent with the training.**
### EVALUATION
The evaluation data set can be modified via `configs/rec/rec_icdar15_reader.yml` setting of `label_file_path` in EvalReader.
```
export CUDA_VISIBLE_DEVICES=0
# GPU evaluation, Global.checkpoints is the weight to be tested
python3 tools/eval.py -c configs/rec/rec_chinese_lite_train.yml -o Global.checkpoints={path/to/weights}/best_accuracy
```
### PREDICTION
* Training engine prediction
Using the model trained by paddleocr, you can quickly get prediction through the following script.
The default prediction picture is stored in `infer_img`, and the weight is specified via `-o Global.checkpoints`:
```
# Predict English results
python3 tools/infer_rec.py -c configs/rec/rec_chinese_lite_train.yml -o Global.checkpoints={path/to/weights}/best_accuracy TestReader.infer_img=doc/imgs_words/en/word_1.jpg
```
Input image:
![](../imgs_words/en/word_1.png)
Get the prediction result of the input image:
```
infer_img: doc/imgs_words/en/word_1.png
index: [19 24 18 23 29]
word : joint
```
The configuration file used for prediction must be consistent with the training. For example, you completed the training of the Chinese model with `python3 tools/train.py -c configs/rec/rec_chinese_lite_train.yml`, you can use the following command to predict the Chinese model:
```
# Predict Chinese results
python3 tools/infer_rec.py -c configs/rec/rec_chinese_lite_train.yml -o Global.checkpoints={path/to/weights}/best_accuracy TestReader.infer_img=doc/imgs_words/ch/word_1.jpg
```
Input image:
![](../imgs_words/ch/word_1.jpg)
Get the prediction result of the input image:
```
infer_img: doc/imgs_words/ch/word_1.jpg
index: [2092 177 312 2503]
word : 韩国小馆
```
doc/doc_en/reference_en.md 0 → 100644
View file @ c1d19ce2
# REFERENCE
```
1. EAST:
@inproceedings{zhou2017east,
title={EAST: an efficient and accurate scene text detector},
author={Zhou, Xinyu and Yao, Cong and Wen, He and Wang, Yuzhi and Zhou, Shuchang and He, Weiran and Liang, Jiajun},
booktitle={Proceedings of the IEEE conference on Computer Vision and Pattern Recognition},
pages={5551--5560},
year={2017}
}
2. DB:
@article{liao2019real,
title={Real-time Scene Text Detection with Differentiable Binarization},
author={Liao, Minghui and Wan, Zhaoyi and Yao, Cong and Chen, Kai and Bai, Xiang},
journal={arXiv preprint arXiv:1911.08947},
year={2019}
}
3. DTRB:
@inproceedings{baek2019wrong,
title={What is wrong with scene text recognition model comparisons? dataset and model analysis},
author={Baek, Jeonghun and Kim, Geewook and Lee, Junyeop and Park, Sungrae and Han, Dongyoon and Yun, Sangdoo and Oh, Seong Joon and Lee, Hwalsuk},
booktitle={Proceedings of the IEEE International Conference on Computer Vision},
pages={4715--4723},
year={2019}
}
4. SAST:
@inproceedings{wang2019single,
title={A Single-Shot Arbitrarily-Shaped Text Detector based on Context Attended Multi-Task Learning},
author={Wang, Pengfei and Zhang, Chengquan and Qi, Fei and Huang, Zuming and En, Mengyi and Han, Junyu and Liu, Jingtuo and Ding, Errui and Shi, Guangming},
booktitle={Proceedings of the 27th ACM International Conference on Multimedia},
pages={1277--1285},
year={2019}
}
5. SRN:
@article{yu2020towards,
title={Towards Accurate Scene Text Recognition with Semantic Reasoning Networks},
author={Yu, Deli and Li, Xuan and Zhang, Chengquan and Han, Junyu and Liu, Jingtuo and Ding, Errui},
journal={arXiv preprint arXiv:2003.12294},
year={2020}
}
6. end2end-psl:
@inproceedings{sun2019chinese,
title={Chinese Street View Text: Large-scale Chinese Text Reading with Partially Supervised Learning},
author={Sun, Yipeng and Liu, Jiaming and Liu, Wei and Han, Junyu and Ding, Errui and Liu, Jingtuo},
booktitle={Proceedings of the IEEE International Conference on Computer Vision},
pages={9086--9095},
year={2019}
}
```
\ No newline at end of file
doc/doc_en/serving_en.md 0 → 100644
View file @ c1d19ce2
# Service deployment
PaddleOCR provides 2 service deployment methods:：
- Based on **HubServing**：Has been integrated into PaddleOCR ([code](https://github.com/PaddlePaddle/PaddleOCR/tree/develop/deploy/hubserving)). Please follow this tutorial.
- Based on **PaddleServing**：See PaddleServing official website for details ([demo](https://github.com/PaddlePaddle/Serving/tree/develop/python/examples/ocr)). Follow-up will also be integrated into PaddleOCR.
The service deployment directory includes three service packages: detection, recognition, and two-stage series connection. Select the corresponding service package to install and start service according to your needs. The directory is as follows:
```
deploy/hubserving/
└─ ocr_det detection module service package
└─ ocr_rec recognition module service package
└─ ocr_system two-stage series connection service package
```
Each service pack contains 3 files. Take the 2-stage series connection service package as an example, the directory is as follows:
```
deploy/hubserving/ocr_system/
└─ __init__.py Empty file, required
└─ config.json Configuration file, optional, passed in as a parameter when using configuration to start the service
└─ module.py Main module file, required, contains the complete logic of the service
└─ params.py Parameter file, required, including parameters such as model path, pre- and post-processing parameters
```
## Quick start service
The following steps take the 2-stage series service as an example. If only the detection service or recognition service is needed, replace the corresponding file path.
### 1. Prepare the environment
```shell
# Install paddlehub
pip3 install paddlehub --upgrade -i https://pypi.tuna.tsinghua.edu.cn/simple
# Set environment variables on Linux
export PYTHONPATH=.
# Set environment variables on Windows
SET PYTHONPATH=.
```
### 2. Install Service Module
PaddleOCR provides 3 kinds of service modules, install the required modules according to your needs.
* On Linux platform, the examples are as follows.
```shell
# Install the detection service module:
hub install deploy/hubserving/ocr_det/
# Or, install the recognition service module:
hub install deploy/hubserving/ocr_rec/
# Or, install the 2-stage series service module:
hub install deploy/hubserving/ocr_system/
```
* On Windows platform, the examples are as follows.
```shell
# Install the detection service module:
hub install deploy\hubserving\ocr_det\
# Or, install the recognition service module:
hub install deploy\hubserving\ocr_rec\
# Or, install the 2-stage series service module:
hub install deploy\hubserving\ocr_system\
```
### 3. Start service
#### Way 1. Start with command line parameters (CPU only)
**start command：**
```shell
$ hub serving start --modules [Module1==Version1, Module2==Version2, ...] \
--port XXXX \
--use_multiprocess \
--workers \
```
**parameters：**
|parameters|usage|
|-|-|
|--modules/-m|PaddleHub Serving pre-installed model, listed in the form of multiple Module==Version key-value pairs<br>*`When Version is not specified, the latest version is selected by default`*|
|--port/-p|Service port, default is 8866|
|--use_multiprocess|Enable concurrent mode, the default is single-process mode, this mode is recommended for multi-core CPU machines<br>*`Windows operating system only supports single-process mode`*|
|--workers|The number of concurrent tasks specified in concurrent mode, the default is `2*cpu_count-1`, where `cpu_count` is the number of CPU cores|
For example, start the 2-stage series service:
```shell
hub serving start -m ocr_system
```
This completes the deployment of a service API, using the default port number 8866.
#### Way 2. Start with configuration file（CPU、GPU）
**start command：**
```shell
hub serving start --config/-c config.json
```
Wherein, the format of `config.json` is as follows:
```python
{
"modules_info": {
"ocr_system": {
"init_args": {
"version": "1.0.0",
"use_gpu": true
},
"predict_args": {
}
}
},
"port": 8868,
"use_multiprocess": false,
"workers": 2
}
```
- The configurable parameters in `init_args` are consistent with the `_initialize` function interface in `module.py`. Among them, **when `use_gpu` is `true`, it means that the GPU is used to start the service**.
- The configurable parameters in `predict_args` are consistent with the `predict` function interface in `module.py`.
**Note:**
- When using the configuration file to start the service, other parameters will be ignored.
- If you use GPU prediction (that is, `use_gpu` is set to `true`), you need to set the environment variable CUDA_VISIBLE_DEVICES before starting the service, such as: ```export CUDA_VISIBLE_DEVICES=0```, otherwise you do not need to set it.
- **`use_gpu` and `use_multiprocess` cannot be `true` at the same time.**
For example, use GPU card No. 3 to start the 2-stage series service:
```shell
export CUDA_VISIBLE_DEVICES=3
hub serving start -c deploy/hubserving/ocr_system/config.json
```
## Send prediction requests
After the service starts, you can use the following command to send a prediction request to obtain the prediction result:
```shell
python tools/test_hubserving.py server_url image_path
```
Two parameters need to be passed to the script:
- **server_url**：service address，format of which is
`http://[ip_address]:[port]/predict/[module_name]`
For example, if the detection, recognition and 2-stage serial services are started with provided configuration files, the respective `server_url` would be:
`http://127.0.0.1:8866/predict/ocr_det`
`http://127.0.0.1:8867/predict/ocr_rec`
`http://127.0.0.1:8868/predict/ocr_system`
- **image_path**：Test image path, can be a single image path or an image directory path
**Eg.**
```shell
python tools/test_hubserving.py http://127.0.0.1:8868/predict/ocr_system ./doc/imgs/
```
## Returned result format
The returned result is a list. Each item in the list is a dict. The dict may contain three fields. The information is as follows:
|field name|data type|description|
|-|-|-|
|text|str|text content|
|confidence|float|text recognition confidence|
|text_region|list|text location coordinates|
The fields returned by different modules are different. For example, the results returned by the text recognition service module do not contain `text_region`. The details are as follows:
|field name/module name|ocr_det|ocr_rec|ocr_system|
|-|-|-|-|
|text||✔|✔|
|confidence||✔|✔|
|text_region|✔||✔|
**Note：** If you need to add, delete or modify the returned fields, you can modify the file `module.py` of the corresponding module. For the complete process, refer to the user-defined modification service module in the next section.
## User defined service module modification
If you need to modify the service logic, the following steps are generally required (take the modification of `ocr_system` for example):
- 1. Stop service
```shell
hub serving stop --port/-p XXXX
```
- 2. Modify the code in the corresponding files, like `module.py` and `params.py`, according to the actual needs.
For example, if you need to replace the model used by the deployed service, you need to modify model path parameters `det_model_dir` and `rec_model_dir` in `params.py`. Of course, other related parameters may need to be modified at the same time. Please modify and debug according to the actual situation. It is suggested to run `module.py` directly for debugging after modification before starting the service test.
- 3. Uninstall old service module
```shell
hub uninstall ocr_system
```
- 4. Install modified service module
```shell
hub install deploy/hubserving/ocr_system/
```
- 5. Restart service
```shell
hub serving start -m ocr_system
```
doc/doc_en/tricks_en.md 0 → 100644
View file @ c1d19ce2
## Tricks
Here we have sorted out some Chinese OCR training and prediction tricks, which are being updated continuously. You are welcome to contribute more OCR tricks ~
- [Replace Backbone Network](#ReplaceBackboneNetwork)
- [Long Chinese Text Recognition](#LongChineseTextRecognition)
- [Space Recognition](#SpaceRecognition)
<a name="ReplaceBackboneNetwork"></a>
#### 1、Replace Backbone Network
- **Problem Description**
At present, ResNet_vd series and MobileNetV3 series are the backbone networks used in PaddleOCR, whether replacing the other backbone networks will help to improve the accuracy? What should be paid attention to when replacing?
- **Tips**
- Whether text detection or text recognition, the choice of backbone network is a trade-off between prediction effect and prediction efficiency. Generally, a larger backbone network is selected, e.g. ResNet101_vd, then the performance of the detection or recognition is more accurate, but the time cost will increase accordingly. And a smaller backbone network is selected, e.g. MobileNetV3_small_x0_35, the prediction speed is faster, but the accuracy of detection or recognition will be reduced. Fortunately, the detection or recognition effect of different backbone networks is positively correlated with the performance of ImageNet 1000 classification task. [**PaddleClas**](https://github.com/PaddlePaddle/PaddleClas/blob/master/README_en.md) have sorted out the 23 series of classification network structures, such as ResNet_vd、Res2Net、HRNet、MobileNetV3、GhostNet. It provides the top1 accuracy of classification, the time cost of GPU(V100 and T4) and CPU(SD 855), and the 117 pretrained models [**download addresses**](https://paddleclas-en.readthedocs.io/en/latest/models/models_intro_en.html).
- Similar as the 4 stages of ResNet, the replacement of text detection backbone network is to determine those four stages to facilitate the integration of FPN like the object detection heads. In addition, for the text detection problem, the pre trained model in ImageNet1000 can accelerate the convergence and improve the accuracy.
- In order to replace the backbone network of text recognition, we need to pay attention to the descending position of network width and height stride. Since the ratio between width and height is large in chinese text recognition, the frequency of height decrease is less and the frequency of width decrease is more. You can refer the [modifies of MobileNetV3](https://github.com/PaddlePaddle/PaddleOCR/blob/develop/ppocr/modeling/backbones/rec_mobilenet_v3.py) in PaddleOCR.
<a name="LongChineseTextRecognition"></a>
#### 2、Long Chinese Text Recognition
- **Problem Description**
The maximum resolution of Chinese recognition model during training is [3,32,320], if the text image to be recognized is too long, as shown in the figure below, how to adapt?
<div align="center">
<img src="../tricks/long_text_examples.jpg" width="600">
</div>
- **Tips**
During the training, the training samples are not directly resized to [3,32,320]. At first, the height of samples are resized to 32 and keep the ratio between the width and the height. When the width is less than 320, the excess parts are padding 0. Besides, when the ratio between the width and the height of the samples is larger than 10, these samples will be ignored. When the prediction for one image, do as above, but do not limit the max ratio between the width and the height. When the prediction for an images batch, do as training, but the resized target width is the longest width of the images in the batch. [Code as following](https://github.com/PaddlePaddle/PaddleOCR/blob/develop/tools/infer/predict_rec.py)：
```
def resize_norm_img(self, img, max_wh_ratio):
imgC, imgH, imgW = self.rec_image_shape
assert imgC == img.shape[2]
if self.character_type == "ch":
imgW = int((32 * max_wh_ratio))
h, w = img.shape[:2]
ratio = w / float(h)
if math.ceil(imgH * ratio) > imgW:
resized_w = imgW
else:
resized_w = int(math.ceil(imgH * ratio))
resized_image = cv2.resize(img, (resized_w, imgH))
resized_image = resized_image.astype('float32')
resized_image = resized_image.transpose((2, 0, 1)) / 255
resized_image -= 0.5
resized_image /= 0.5
padding_im = np.zeros((imgC, imgH, imgW), dtype=np.float32)
padding_im[:, :, 0:resized_w] = resized_image
return padding_im
```
<a name="SpaceRecognition"></a>
#### 3、Space Recognition
- **Problem Description**
As shown in the figure below, for Chinese and English mixed scenes, in order to facilitate reading and using the recognition results, it is often necessary to recognize the spaces between words. How can this situation be adapted?
<div align="center">
<img src="../imgs_results/chinese_db_crnn_server/en_paper.jpg" width="600">
</div>
- **Tips**
There are two possible methods for space recognition. (1) Optimize the text detection. For spliting the text at the space in detection results, it needs to divide the text line with space into many segments when label the data for detection. (2) Optimize the text recognition. The space character is introduced into the recognition dictionary. Label the blank line in the training data for text recognition. In addition, we can also concat multiple word lines to synthesize the training data with spaces. PaddleOCR currently uses the second method.
doc/doc_en/update_en.md 0 → 100644
View file @ c1d19ce2
# RECENT UPDATES
- 2020.7.23, Release the playback and PPT of live class on BiliBili station, PaddleOCR Introduction, [address](https://aistudio.baidu.com/aistudio/course/introduce/1519)
- 2020.7.15, Add mobile App demo , support both iOS and Android ( based on easyedge and Paddle Lite)
- 2020.7.15, Improve the deployment ability, add the C + + inference , serving deployment. In addtion, the benchmarks of the ultra-lightweight Chinese OCR model are provided.
- 2020.7.15, Add several related datasets, data annotation and synthesis tools.
- 2020.7.9 Add a new model to support recognize the character "space".
- 2020.7.9 Add the data augument and learning rate decay strategies during training.
- 2020.6.8 Add [datasets](./doc/doc_en/datasets_en.md) and keep updating
- 2020.6.5 Support exporting `attention` model to `inference_model`
- 2020.6.5 Support separate prediction and recognition, output result score
- 2020.6.5 Support exporting `attention` model to `inference_model`
- 2020.6.5 Support separate prediction and recognition, output result score
- 2020.5.30 Provide Lightweight Chinese OCR online experience
- 2020.5.30 Model prediction and training support on Windows system
- 2020.5.30 Open source general Chinese OCR model
- 2020.5.14 Release [PaddleOCR Open Class](https://www.bilibili.com/video/BV1nf4y1U7RX?p=4)
- 2020.5.14 Release [PaddleOCR Practice Notebook](https://aistudio.baidu.com/aistudio/projectdetail/467229)
- 2020.5.14 Open source 8.6M lightweight Chinese OCR model
doc/doc_en/vertical_and_multilingual_datasets_en.md 0 → 100644
View file @ c1d19ce2
# Vertical multi-language OCR dataset
Here we have sorted out the commonly used vertical multi-language OCR dataset datasets, which are being updated continuously. We welcome you to contribute datasets ～
- [Chinese urban license plate dataset](#Chinese urban license plate dataset)
- [Bank credit card dataset](#Bank credit card dataset)
- [Captcha dataset-Captcha](#Captcha dataset-Captcha)
- [multi-language dataset](#multi-language dataset)
<a name="Chinese urban license plate dataset"></a>
## Chinese urban license plate dataset
- **Data source**：[https://github.com/detectRecog/CCPD](https://github.com/detectRecog/CCPD)
- **Data introduction**: It contains more than 250000 vehicle license plate images and vehicle license plate detection and recognition information labeling. It contains the following license plate image information in different scenes.
* CCPD-Base: General license plate picture
* CCPD-DB: The brightness of license plate area is bright, dark or uneven
* CCPD-FN: The license plate is farther or closer to the camera location
* CCPD-Rotate: License plate includes rotation (horizontal 20\~50 degrees, vertical-10\~10 degrees)
* CCPD-Tilt: License plate includes rotation (horizontal 15\~45 degrees, vertical 15\~45 degrees)
* CCPD-Blur: The license plate contains blurring due to camera lens jitter
* CCPD-Weather: The license plate is photographed on rainy, snowy or foggy days
* CCPD-Challenge: So far, some of the most challenging images in license plate detection and recognition tasks
* CCPD-NP: Pictures of new cars without license plates.
![](../datasets/ccpd_demo.png)
- **Download address**
* Baidu cloud download address (extracted code is hm0U): [https://pan.baidu.com/s/1i5AOjAbtkwb17Zy-NQGqkw](https://pan.baidu.com/s/1i5AOjAbtkwb17Zy-NQGqkw)
* Google drive download address:[https://drive.google.com/file/d/1rdEsCUcIUaYOVRkx5IMTRNA7PcGMmSgc/view](https://drive.google.com/file/d/1rdEsCUcIUaYOVRkx5IMTRNA7PcGMmSgc/view)
<a name="Bank credit card dataset"></a>
## Bank credit card dataset
- **Data source**: [https://www.kesci.com/home/dataset/5954cf1372ead054a5e25870](https://www.kesci.com/home/dataset/5954cf1372ead054a5e25870)
- **Data introduction**: There are three types of training data
* 1.Sample card data of China Merchants Bank: including card image data and annotation data, a total of 618 pictures
* 2.Single character data: including pictures and annotation data, 37 pictures in total.
* 3.There are only other bank cards, no more detailed information, a total of 50 pictures.
* The demo image is shown as follows. The annotation information is stored in excel, and the demo image below is marked as
* Top 8 card number: 62257583
* Card type: card of our bank
* End of validity: 07/41
* Chinese phonetic alphabet of card users: MICHAEL
![](../datasets/cmb_demo.jpg)
- **Download address**: [https://cdn.kesci.com/cmb2017-2.zip](https://cdn.kesci.com/cmb2017-2.zip)
<a name="Captcha dataset-Captcha"></a>
## Captcha dataset-Captcha
- **Data source**: [https://github.com/lepture/captcha](https://github.com/lepture/captcha)
- **Data introduction**: This is a toolkit for data synthesis. You can output captcha images according to the input text. Use the toolkit to generate several demo images as follows.
![](../datasets/captcha_demo.png)
- **Download address**: The dataset is generated and has no download address.
<a name="multi-language dataset"></a>
## multi-language dataset(Multi-lingual scene text detection and recognition)
- **Data source**: [https://rrc.cvc.uab.es/?ch=15&com=downloads](https://rrc.cvc.uab.es/?ch=15&com=downloads)
- **Data introduction**: Multi language detection dataset MLT contains both language recognition and detection tasks.
* In the detection task, the training set contains 10000 images in 10 languages, and each language contains 1000 training images. The test set contains 10000 images.
* In the recognition task, the training set contains 111998 samples.
- **Download address**: The training set is large and can be downloaded in two parts. It can only be downloaded after registering on the website:
[https://rrc.cvc.uab.es/?ch=15&com=downloads](https://rrc.cvc.uab.es/?ch=15&com=downloads)
doc/doc_en/visualization_en.md 0 → 100644
View file @ c1d19ce2
# Visualization
- [Chinese/English OCR Visualization (Space_support )](#Space_support)
- [Ultra-lightweight Chinese/English OCR Visualization](#Ultra-lightweight)
- [General Chinese/English OCR Visualization](#General)
<a name="Space_support"></a>
## Chinese/English OCR Visualization (Space_support )
### Ultra-lightweight Model
<div align="center">
<img src="../imgs_results/img_11.jpg" width="800">
</div>
### General OCR Model
<div align="center">
<img src="../imgs_results/chinese_db_crnn_server/en_paper.jpg" width="800">
</div>
<a name="Ultra-lightweight"></a>
## Ultra-lightweight Chinese/English OCR Visualization
<div align="center">
<img src="../imgs_results/1.jpg" width="800">
</div>
<div align="center">
<img src="../imgs_results/7.jpg" width="800">
</div>
<div align="center">
<img src="../imgs_results/12.jpg" width="800">
</div>
<div align="center">
<img src="../imgs_results/4.jpg" width="800">
</div>
<div align="center">
<img src="../imgs_results/6.jpg" width="800">
</div>
<div align="center">
<img src="../imgs_results/9.jpg" width="800">
</div>
<div align="center">
<img src="../imgs_results/16.png" width="800">
</div>
<div align="center">
<img src="../imgs_results/22.jpg" width="800">
</div>
<a name="General"></a>
## General Chinese/English OCR Visualization
<div align="center">
<img src="../imgs_results/chinese_db_crnn_server/11.jpg" width="800">
</div>
<div align="center">
<img src="../imgs_results/chinese_db_crnn_server/2.jpg" width="800">
</div>
<div align="center">
<img src="../imgs_results/chinese_db_crnn_server/8.jpg" width="800">
</div>
Markdown is supported
0% or .
You are about to add 0 people to the discussion. Proceed with caution.
Finish editing this message first!
Please register or to comment
