Merge branch 'dygraph' into bm_dyg

configs/rec/ch_ppocr_v2.1/rec_chinese_lite_train_distillation_v2.1.yml

+Global:
+  debug: false
+  use_gpu: true
+  epoch_num: 800
+  log_smooth_window: 20
+  print_batch_step: 10
+  save_model_dir: ./output/rec_chinese_lite_distillation_v2.1
+  save_epoch_step: 3
+  eval_batch_step: [0, 2000]
+  cal_metric_during_train: true
+  pretrained_model:
+  checkpoints:
+  save_inference_dir:
+  use_visualdl: false
+  infer_img: doc/imgs_words/ch/word_1.jpg
+  character_dict_path: ppocr/utils/ppocr_keys_v1.txt
+  character_type: ch
+  max_text_length: 25
+  infer_mode: false
+  use_space_char: false
+  distributed: true
+  save_res_path: ./output/rec/predicts_chinese_lite_distillation_v2.1.txt
+
+
+Optimizer:
+  name: Adam
+  beta1: 0.9
+  beta2: 0.999
+  lr:
+    name: Cosine
+    learning_rate: 0.0005
+    warmup_epoch: 5
+  regularizer:
+    name: L2
+    factor: 1.0e-05
+Architecture:
+  name: DistillationModel
+  algorithm: Distillation
+  Models:
+    Student:
+      pretrained:
+      freeze_params: false
+      return_all_feats: true
+      model_type: rec
+      algorithm: CRNN
+      Transform:
+      Backbone:
+        name: MobileNetV3
+        scale: 0.5
+        model_name: small
+        small_stride: [1, 2, 2, 2]
+      Neck:
+        name: SequenceEncoder
+        encoder_type: rnn
+        hidden_size: 64
+      Head:
+        name: CTCHead
+        mid_channels: 96
+        fc_decay: 0.00001
+    Teacher:
+      pretrained:
+      freeze_params: false
+      return_all_feats: true
+      model_type: rec
+      algorithm: CRNN
+      Transform:
+      Backbone:
+        name: MobileNetV3
+        scale: 0.5
+        model_name: small
+        small_stride: [1, 2, 2, 2]
+      Neck:
+        name: SequenceEncoder
+        encoder_type: rnn
+        hidden_size: 64
+      Head:
+        name: CTCHead
+        mid_channels: 96
+        fc_decay: 0.00001
+
+
+Loss:
+  name: CombinedLoss
+  loss_config_list:
+  - DistillationCTCLoss:
+      weight: 1.0
+      model_name_list: ["Student", "Teacher"]
+      key: head_out
+  - DistillationDMLLoss:
+      weight: 1.0
+      act: "softmax"
+      model_name_pairs:
+      - ["Student", "Teacher"]
+      key: head_out
+  - DistillationDistanceLoss:
+      weight: 1.0
+      mode: "l2"
+      model_name_pairs:
+      - ["Student", "Teacher"]
+      key: backbone_out
+
+PostProcess:
+  name: DistillationCTCLabelDecode
+  model_name: ["Student", "Teacher"]
+  key: head_out
+
+Metric:
+  name: DistillationMetric
+  base_metric_name: RecMetric
+  main_indicator: acc
+  key: "Student"
+
+Train:
+  dataset:
+    name: SimpleDataSet
+    data_dir: ./train_data/
+    label_file_list:
+    - ./train_data/train_list.txt
+    transforms:
+    - DecodeImage:
+        img_mode: BGR
+        channel_first: false
+    - RecAug:
+    - CTCLabelEncode:
+    - RecResizeImg:
+        image_shape: [3, 32, 320]
+    - KeepKeys:
+        keep_keys:
+        - image
+        - label
+        - length
+  loader:
+    shuffle: true
+    batch_size_per_card: 128
+    drop_last: true
+    num_sections: 1
+    num_workers: 8
+Eval:
+  dataset:
+    name: SimpleDataSet
+    data_dir: ./train_data
+    label_file_list:
+    - ./train_data/val_list.txt
+    transforms:
+    - DecodeImage:
+        img_mode: BGR
+        channel_first: false
+    - CTCLabelEncode:
+    - RecResizeImg:
+        image_shape: [3, 32, 320]
+    - KeepKeys:
+        keep_keys:
+        - image
+        - label
+        - length
+  loader:
+    shuffle: false
+    drop_last: false
+    batch_size_per_card: 128
+    num_workers: 8

configs/table/table_mv3.yml

+Global:
+  use_gpu: true
+  epoch_num: 50
+  log_smooth_window: 20
+  print_batch_step: 5
+  save_model_dir: ./output/table_mv3/
+  save_epoch_step: 5
+  # evaluation is run every 400 iterations after the 0th iteration
+  eval_batch_step: [0, 400]
+  cal_metric_during_train: True
+  pretrained_model:
+  checkpoints:
+  save_inference_dir:
+  use_visualdl: False
+  infer_img: doc/imgs_words/ch/word_1.jpg
+  # for data or label process
+  character_dict_path: ppocr/utils/dict/table_structure_dict.txt
+  character_type: en
+  max_text_length: 100
+  max_elem_length: 500
+  max_cell_num: 500
+  infer_mode: False
+  process_total_num: 0
+  process_cut_num: 0
+
+
+Optimizer:
+  name: Adam
+  beta1: 0.9
+  beta2: 0.999
+  clip_norm: 5.0
+  lr:
+    learning_rate: 0.001
+  regularizer:
+    name: 'L2'
+    factor: 0.00000
+
+Architecture:
+  model_type: table
+  algorithm: TableAttn
+  Backbone:
+    name: MobileNetV3
+    scale: 1.0
+    model_name: small
+    disable_se: True
+  Head:
+    name: TableAttentionHead
+    hidden_size: 256
+    l2_decay: 0.00001
+    loc_type: 2
+
+Loss:
+  name: TableAttentionLoss
+  structure_weight: 100.0
+  loc_weight: 10000.0
+
+PostProcess:
+  name: TableLabelDecode
+
+Metric:
+  name: TableMetric
+  main_indicator: acc
+
+Train:
+  dataset:
+    name: PubTabDataSet
+    data_dir: train_data/table/pubtabnet/train/
+    label_file_path: train_data/table/pubtabnet/PubTabNet_2.0.0_train.jsonl
+    transforms:
+      - DecodeImage: # load image
+          img_mode: BGR
+          channel_first: False
+      - ResizeTableImage:
+          max_len: 488
+      - TableLabelEncode:
+      - NormalizeImage:
+          scale: 1./255.
+          mean: [0.485, 0.456, 0.406]
+          std: [0.229, 0.224, 0.225]
+          order: 'hwc'
+      - PaddingTableImage:
+      - ToCHWImage:
+      - KeepKeys:
+          keep_keys: ['image', 'structure', 'bbox_list', 'sp_tokens', 'bbox_list_mask']
+  loader:
+    shuffle: True
+    batch_size_per_card: 32
+    drop_last: True
+    num_workers: 1
+
+Eval:
+  dataset:
+    name: PubTabDataSet
+    data_dir: train_data/table/pubtabnet/val/
+    label_file_path: train_data/table/pubtabnet/PubTabNet_2.0.0_val.jsonl
+    transforms:
+      - DecodeImage: # load image
+          img_mode: BGR
+          channel_first: False
+      - ResizeTableImage:
+          max_len: 488
+      - TableLabelEncode:
+      - NormalizeImage:
+          scale: 1./255.
+          mean: [0.485, 0.456, 0.406]
+          std: [0.229, 0.224, 0.225]
+          order: 'hwc'
+      - PaddingTableImage:
+      - ToCHWImage:
+      - KeepKeys:
+          keep_keys: ['image', 'structure', 'bbox_list', 'sp_tokens', 'bbox_list_mask']
+  loader:
+    shuffle: False
+    drop_last: False
+    batch_size_per_card: 16
+    num_workers: 1

deploy/cpp_infer/src/preprocess_op.cpp

@@ -47,16 +47,13 @@ void Normalize::Run(cv::Mat *im, const std::vector<float> &mean,
     e /= 255.0;
   }
   (*im).convertTo(*im, CV_32FC3, e);
-  for (int h = 0; h < im->rows; h++) {
-    for (int w = 0; w < im->cols; w++) {
-      im->at<cv::Vec3f>(h, w)[0] =
-          (im->at<cv::Vec3f>(h, w)[0] - mean[0]) * scale[0];
-      im->at<cv::Vec3f>(h, w)[1] =
-          (im->at<cv::Vec3f>(h, w)[1] - mean[1]) * scale[1];
-      im->at<cv::Vec3f>(h, w)[2] =
-          (im->at<cv::Vec3f>(h, w)[2] - mean[2]) * scale[2];
-    }
+  std::vector<cv::Mat> bgr_channels(3);
+  cv::split(*im, bgr_channels);
+  for (auto i = 0; i < bgr_channels.size(); i++) {
+    bgr_channels[i].convertTo(bgr_channels[i], CV_32FC1, 1.0 * scale[i],
+                              (0.0 - mean[i]) * scale[i]);
   }
+  cv::merge(bgr_channels, *im);
 }

 void ResizeImgType0::Run(const cv::Mat &img, cv::Mat &resize_img,

deploy/hubserving/readme.md

@@ -29,7 +29,7 @@ deploy/hubserving/ocr_system/
 ### 1. 准备环境
 ```shell
 # 安装paddlehub
-pip3 install paddlehub --upgrade -i https://pypi.tuna.tsinghua.edu.cn/simple
+pip3 install paddlehub==1.8.3 --upgrade -i https://pypi.tuna.tsinghua.edu.cn/simple
 ```

 ### 2. 下载推理模型

deploy/hubserving/readme_en.md

@@ -30,7 +30,7 @@ The following steps take the 2-stage series service as an example. If only the d
 ### 1. Prepare the environment
 ```shell
 # Install paddlehub
-pip3 install paddlehub --upgrade -i https://pypi.tuna.tsinghua.edu.cn/simple
+pip3 install paddlehub==1.8.3 --upgrade -i https://pypi.tuna.tsinghua.edu.cn/simple
 ```

 ### 2. Download inference model

doc/doc_ch/whl.md

@@ -355,3 +355,4 @@ im_show.save('result.jpg')
 | det                     | 前向时使用启动检测                                                                                                                                                                                                   | TRUE                    |
 | rec                     | 前向时是否启动识别                                                                                                                                                                                                   | TRUE                    |
 | cls                     | 前向时是否启动分类 (命令行模式下使用use_angle_cls控制前向是否启动分类)                                                                                                                                                                                                | FALSE                    |
+| show_log                     | 是否打印det和rec等信息                                                                                                                                                                                                | FALSE                    |

doc/doc_en/whl_en.md

@@ -362,3 +362,5 @@ im_show.save('result.jpg')
 | det                     | Enable detction when `ppocr.ocr` func exec                                                                                                                                                                                                   | TRUE                    |
 | rec                     | Enable recognition when `ppocr.ocr` func exec                                                                                                                                                                                                   | TRUE                    |
 | cls                     | Enable classification when `ppocr.ocr` func exec((Use use_angle_cls in command line mode to control whether to start classification in the forward direction)                                                                                                                                                                                                   | FALSE                    |
+| show_log                     | Whether to print log in det and rec
+                                                                                                                                                                                               | FALSE                    |
\ No newline at end of file

paddleocr.py

@@ -28,7 +28,7 @@ from ppocr.utils.logging import get_logger

 logger = get_logger()
 from ppocr.utils.utility import check_and_read_gif, get_image_file_list
-from ppocr.utils.network import maybe_download, download_with_progressbar
+from ppocr.utils.network import maybe_download, download_with_progressbar, is_link, confirm_model_dir_url
 from tools.infer.utility import draw_ocr, init_args, str2bool

 __all__ = ['PaddleOCR']
@@ -151,8 +151,8 @@ class PaddleOCR(predict_system.TextSystem):
         """
         params = parse_args(mMain=False)
         params.__dict__.update(**kwargs)
-        if params.show_log:
-            logger.setLevel(logging.DEBUG)
+        if not params.show_log:
+            logger.setLevel(logging.INFO)
         self.use_angle_cls = params.use_angle_cls
         lang = params.lang
         latin_lang = [
@@ -192,20 +192,19 @@ class PaddleOCR(predict_system.TextSystem):
                 'dict_path']

         # init model dir
-        if params.det_model_dir is None:
-            params.det_model_dir = os.path.join(BASE_DIR, VERSION,
-                                                            'det', det_lang)
-        if params.rec_model_dir is None:
-            params.rec_model_dir = os.path.join(BASE_DIR, VERSION,
-                                                            'rec', lang)
-        if params.cls_model_dir is None:
-            params.cls_model_dir = os.path.join(BASE_DIR, 'cls')
+        params.det_model_dir, det_url = confirm_model_dir_url(params.det_model_dir,
+                                                              os.path.join(BASE_DIR, VERSION, 'det', det_lang),
+                                                              model_urls['det'][det_lang])
+        params.rec_model_dir, rec_url = confirm_model_dir_url(params.rec_model_dir,
+                                                              os.path.join(BASE_DIR, VERSION, 'rec', lang),
+                                                              model_urls['rec'][lang]['url'])
+        params.cls_model_dir, cls_url = confirm_model_dir_url(params.cls_model_dir,
+                                                              os.path.join(BASE_DIR, VERSION, 'cls'),
+                                                              model_urls['cls'])
         # download model
-        maybe_download(params.det_model_dir,
-                       model_urls['det'][det_lang])
-        maybe_download(params.rec_model_dir,
-                       model_urls['rec'][lang]['url'])
-        maybe_download(params.cls_model_dir, model_urls['cls'])
+        maybe_download(params.det_model_dir, det_url)
+        maybe_download(params.rec_model_dir, rec_url)
+        maybe_download(params.cls_model_dir, cls_url)

         if params.det_algorithm not in SUPPORT_DET_MODEL:
             logger.error('det_algorithm must in {}'.format(SUPPORT_DET_MODEL))
@@ -277,7 +276,7 @@ def main():
     # for cmd
     args = parse_args(mMain=True)
     image_dir = args.image_dir
-    if image_dir.startswith('http'):
+    if is_link(image_dir):
         download_with_progressbar(image_dir, 'tmp.jpg')
         image_file_list = ['tmp.jpg']
     else:

ppocr/data/__init__.py

@@ -35,6 +35,7 @@ from ppocr.data.imaug import transform, create_operators
 from ppocr.data.simple_dataset import SimpleDataSet
 from ppocr.data.lmdb_dataset import LMDBDataSet
 from ppocr.data.pgnet_dataset import PGDataSet
+from ppocr.data.pubtab_dataset import PubTabDataSet

 __all__ = ['build_dataloader', 'transform', 'create_operators']

@@ -55,7 +56,7 @@ signal.signal(signal.SIGTERM, term_mp)
 def build_dataloader(config, mode, device, logger, seed=None):
     config = copy.deepcopy(config)

-    support_dict = ['SimpleDataSet', 'LMDBDataSet', 'PGDataSet']
+    support_dict = ['SimpleDataSet', 'LMDBDataSet', 'PGDataSet', 'PubTabDataSet']
     module_name = config[mode]['dataset']['name']
     assert module_name in support_dict, Exception(
         'DataSet only support {}'.format(support_dict))

ppocr/data/imaug/__init__.py

@@ -29,6 +29,7 @@ from .label_ops import *
 from .east_process import *
 from .sast_process import *
 from .pg_process import *
+from .gen_table_mask import *


 def transform(data, ops=None):

ppocr/data/imaug/gen_table_mask.py

+"""
+# Copyright (c) 2020 PaddlePaddle Authors. All Rights Reserved
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+"""
+
+from __future__ import absolute_import
+from __future__ import division
+from __future__ import print_function
+from __future__ import unicode_literals
+
+import sys
+import six
+import cv2
+import numpy as np
+
+
+class GenTableMask(object):
+    """ gen table mask """
+
+    def __init__(self, shrink_h_max, shrink_w_max, mask_type=0, **kwargs):
+        self.shrink_h_max = 5
+        self.shrink_w_max = 5
+        self.mask_type = mask_type
+
+    def projection(self, erosion, h, w, spilt_threshold=0):
+        # 水平投影
+        projection_map = np.ones_like(erosion)
+        project_val_array = [0 for _ in range(0, h)]
+
+        for j in range(0, h):
+            for i in range(0, w):
+                if erosion[j, i] == 255:
+                    project_val_array[j] += 1
+        # 根据数组，获取切割点
+        start_idx = 0  # 记录进入字符区的索引
+        end_idx = 0  # 记录进入空白区域的索引
+        in_text = False  # 是否遍历到了字符区内
+        box_list = []
+        for i in range(len(project_val_array)):
+            if in_text == False and project_val_array[i] > spilt_threshold:  # 进入字符区了
+                in_text = True
+                start_idx = i
+            elif project_val_array[i] <= spilt_threshold and in_text == True:  # 进入空白区了
+                end_idx = i
+                in_text = False
+                if end_idx - start_idx <= 2:
+                    continue
+                box_list.append((start_idx, end_idx + 1))
+
+        if in_text:
+            box_list.append((start_idx, h - 1))
+        # 绘制投影直方图
+        for j in range(0, h):
+            for i in range(0, project_val_array[j]):
+                projection_map[j, i] = 0
+        return box_list, projection_map
+
+    def projection_cx(self, box_img):
+        box_gray_img = cv2.cvtColor(box_img, cv2.COLOR_BGR2GRAY)
+        h, w = box_gray_img.shape
+        # 灰度图片进行二值化处理
+        ret, thresh1 = cv2.threshold(box_gray_img, 200, 255, cv2.THRESH_BINARY_INV)
+        # 纵向腐蚀
+        if h < w:
+            kernel = np.ones((2, 1), np.uint8)
+            erode = cv2.erode(thresh1, kernel, iterations=1)
+        else:
+            erode = thresh1
+        # 水平膨胀
+        kernel = np.ones((1, 5), np.uint8)
+        erosion = cv2.dilate(erode, kernel, iterations=1)
+        # 水平投影
+        projection_map = np.ones_like(erosion)
+        project_val_array = [0 for _ in range(0, h)]
+
+        for j in range(0, h):
+            for i in range(0, w):
+                if erosion[j, i] == 255:
+                    project_val_array[j] += 1
+        # 根据数组，获取切割点
+        start_idx = 0  # 记录进入字符区的索引
+        end_idx = 0  # 记录进入空白区域的索引
+        in_text = False  # 是否遍历到了字符区内
+        box_list = []
+        spilt_threshold = 0
+        for i in range(len(project_val_array)):
+            if in_text == False and project_val_array[i] > spilt_threshold:  # 进入字符区了
+                in_text = True
+                start_idx = i
+            elif project_val_array[i] <= spilt_threshold and in_text == True:  # 进入空白区了
+                end_idx = i
+                in_text = False
+                if end_idx - start_idx <= 2:
+                    continue
+                box_list.append((start_idx, end_idx + 1))
+
+        if in_text:
+            box_list.append((start_idx, h - 1))
+        # 绘制投影直方图
+        for j in range(0, h):
+            for i in range(0, project_val_array[j]):
+                projection_map[j, i] = 0
+        split_bbox_list = []
+        if len(box_list) > 1:
+            for i, (h_start, h_end) in enumerate(box_list):
+                if i == 0:
+                    h_start = 0
+                if i == len(box_list):
+                    h_end = h
+                word_img = erosion[h_start:h_end + 1, :]
+                word_h, word_w = word_img.shape
+                w_split_list, w_projection_map = self.projection(word_img.T, word_w, word_h)
+                w_start, w_end = w_split_list[0][0], w_split_list[-1][1]
+                if h_start > 0:
+                    h_start -= 1
+                h_end += 1
+                word_img = box_img[h_start:h_end + 1:, w_start:w_end + 1, :]
+                split_bbox_list.append([w_start, h_start, w_end, h_end])
+        else:
+            split_bbox_list.append([0, 0, w, h])
+        return split_bbox_list
+
+    def shrink_bbox(self, bbox):
+        left, top, right, bottom = bbox
+        sh_h = min(max(int((bottom - top) * 0.1), 1), self.shrink_h_max)
+        sh_w = min(max(int((right - left) * 0.1), 1), self.shrink_w_max)
+        left_new = left + sh_w
+        right_new = right - sh_w
+        top_new = top + sh_h
+        bottom_new = bottom - sh_h
+        if left_new >= right_new:
+            left_new = left
+            right_new = right
+        if top_new >= bottom_new:
+            top_new = top
+            bottom_new = bottom
+        return [left_new, top_new, right_new, bottom_new]
+
+    def __call__(self, data):
+        img = data['image']
+        cells = data['cells']
+        height, width = img.shape[0:2]
+        if self.mask_type == 1:
+            mask_img = np.zeros((height, width), dtype=np.float32)
+        else:
+            mask_img = np.zeros((height, width, 3), dtype=np.float32)
+        cell_num = len(cells)
+        for cno in range(cell_num):
+            if "bbox" in cells[cno]:
+                bbox = cells[cno]['bbox']
+                left, top, right, bottom = bbox
+                box_img = img[top:bottom, left:right, :].copy()
+                split_bbox_list = self.projection_cx(box_img)
+                for sno in range(len(split_bbox_list)):
+                    split_bbox_list[sno][0] += left
+                    split_bbox_list[sno][1] += top
+                    split_bbox_list[sno][2] += left
+                    split_bbox_list[sno][3] += top
+
+                for sno in range(len(split_bbox_list)):
+                    left, top, right, bottom = split_bbox_list[sno]
+                    left, top, right, bottom = self.shrink_bbox([left, top, right, bottom])
+                    if self.mask_type == 1:
+                        mask_img[top:bottom, left:right] = 1.0
+                        data['mask_img'] = mask_img
+                    else:
+                        mask_img[top:bottom, left:right, :] = (255, 255, 255)
+                        data['image'] = mask_img
+        return data
+
+class ResizeTableImage(object):
+    def __init__(self, max_len, **kwargs):
+        super(ResizeTableImage, self).__init__()
+        self.max_len = max_len
+
+    def get_img_bbox(self, cells):
+        bbox_list = []
+        if len(cells) == 0:
+            return bbox_list
+        cell_num = len(cells)
+        for cno in range(cell_num):
+            if "bbox" in cells[cno]:
+                bbox = cells[cno]['bbox']
+                bbox_list.append(bbox)
+        return bbox_list
+
+    def resize_img_table(self, img, bbox_list, max_len):
+        height, width = img.shape[0:2]
+        ratio = max_len / (max(height, width) * 1.0)
+        resize_h = int(height * ratio)
+        resize_w = int(width * ratio)
+        img_new = cv2.resize(img, (resize_w, resize_h))
+        bbox_list_new = []
+        for bno in range(len(bbox_list)):
+            left, top, right, bottom = bbox_list[bno].copy()
+            left = int(left * ratio)
+            top = int(top * ratio)
+            right = int(right * ratio)
+            bottom = int(bottom * ratio)
+            bbox_list_new.append([left, top, right, bottom])
+        return img_new, bbox_list_new
+
+    def __call__(self, data):
+        img = data['image']
+        if 'cells' not in data:
+            cells = []
+        else:
+            cells = data['cells']
+        bbox_list = self.get_img_bbox(cells)
+        img_new, bbox_list_new = self.resize_img_table(img, bbox_list, self.max_len)
+        data['image'] = img_new
+        cell_num = len(cells)
+        bno = 0
+        for cno in range(cell_num):
+            if "bbox" in data['cells'][cno]:
+                data['cells'][cno]['bbox'] = bbox_list_new[bno]
+                bno += 1
+        data['max_len'] = self.max_len
+        return data
+
+class PaddingTableImage(object):
+    def __init__(self, **kwargs):
+        super(PaddingTableImage, self).__init__()
+
+    def __call__(self, data):
+        img = data['image']
+        max_len = data['max_len']
+        padding_img = np.zeros((max_len, max_len, 3), dtype=np.float32)
+        height, width = img.shape[0:2]
+        padding_img[0:height, 0:width, :] = img.copy()
+        data['image'] = padding_img
+        return data
+
\ No newline at end of file

ppocr/data/imaug/label_ops.py

@@ -351,3 +351,162 @@ class SRNLabelEncode(BaseRecLabelEncode):
             assert False, "Unsupport type %s in get_beg_end_flag_idx" \
                           % beg_or_end
         return idx
+
+class TableLabelEncode(object):
+    """ Convert between text-label and text-index """
+    def __init__(self,
+        max_text_length,
+        max_elem_length,
+        max_cell_num,
+        character_dict_path,
+        span_weight = 1.0,
+        **kwargs):
+        self.max_text_length = max_text_length
+        self.max_elem_length = max_elem_length
+        self.max_cell_num = max_cell_num
+        list_character, list_elem = self.load_char_elem_dict(character_dict_path)
+        list_character = self.add_special_char(list_character)
+        list_elem = self.add_special_char(list_elem)
+        self.dict_character = {}
+        for i, char in enumerate(list_character):
+            self.dict_character[char] = i
+        self.dict_elem = {}
+        for i, elem in enumerate(list_elem):
+            self.dict_elem[elem] = i
+        self.span_weight = span_weight
+
+    def load_char_elem_dict(self, character_dict_path):
+        list_character = []
+        list_elem = []
+        with open(character_dict_path, "rb") as fin:
+            lines = fin.readlines()
+            substr = lines[0].decode('utf-8').strip("\n").split("\t")
+            character_num = int(substr[0])
+            elem_num = int(substr[1])
+            for cno in range(1, 1+character_num):
+                character = lines[cno].decode('utf-8').strip("\n")
+                list_character.append(character)
+            for eno in range(1+character_num, 1+character_num+elem_num):
+                elem = lines[eno].decode('utf-8').strip("\n")
+                list_elem.append(elem)
+        return list_character, list_elem
+
+    def add_special_char(self, list_character):
+        self.beg_str = "sos"
+        self.end_str = "eos"
+        list_character = [self.beg_str] + list_character + [self.end_str]
+        return list_character
+
+    def get_span_idx_list(self):
+        span_idx_list = []
+        for elem in self.dict_elem:
+            if 'span' in elem:
+                span_idx_list.append(self.dict_elem[elem])
+        return span_idx_list
+
+    def __call__(self, data):
+        cells = data['cells']
+        structure = data['structure']['tokens']
+        structure = self.encode(structure, 'elem')
+        if structure is None:
+            return None
+        elem_num = len(structure)
+        structure = [0] + structure + [len(self.dict_elem) - 1]
+        structure = structure + [0] * (self.max_elem_length + 2 - len(structure))
+        structure = np.array(structure)
+        data['structure'] = structure
+        elem_char_idx1 = self.dict_elem['<td>']
+        elem_char_idx2 = self.dict_elem['<td']
+        span_idx_list = self.get_span_idx_list()
+        td_idx_list = np.logical_or(structure == elem_char_idx1, structure == elem_char_idx2)
+        td_idx_list = np.where(td_idx_list)[0]
+
+        structure_mask = np.ones((self.max_elem_length + 2, 1), dtype=np.float32)
+        bbox_list = np.zeros((self.max_elem_length + 2, 4), dtype=np.float32)
+        bbox_list_mask = np.zeros((self.max_elem_length + 2, 1), dtype=np.float32)
+        img_height, img_width, img_ch = data['image'].shape
+        if len(span_idx_list) > 0:
+            span_weight = len(td_idx_list) * 1.0 / len(span_idx_list)
+            span_weight = min(max(span_weight, 1.0), self.span_weight)
+        for cno in range(len(cells)):
+            if 'bbox' in cells[cno]:
+                bbox = cells[cno]['bbox'].copy()
+                bbox[0] = bbox[0] * 1.0 / img_width
+                bbox[1] = bbox[1] * 1.0 / img_height
+                bbox[2] = bbox[2] * 1.0 / img_width
+                bbox[3] = bbox[3] * 1.0 / img_height
+                td_idx = td_idx_list[cno]
+                bbox_list[td_idx] = bbox
+                bbox_list_mask[td_idx] = 1.0
+                cand_span_idx = td_idx + 1
+                if cand_span_idx < (self.max_elem_length + 2):
+                    if structure[cand_span_idx] in span_idx_list:
+                        structure_mask[cand_span_idx] = span_weight
+
+        data['bbox_list'] = bbox_list
+        data['bbox_list_mask'] = bbox_list_mask
+        data['structure_mask'] = structure_mask
+        char_beg_idx = self.get_beg_end_flag_idx('beg', 'char')
+        char_end_idx = self.get_beg_end_flag_idx('end', 'char')
+        elem_beg_idx = self.get_beg_end_flag_idx('beg', 'elem')
+        elem_end_idx = self.get_beg_end_flag_idx('end', 'elem')
+        data['sp_tokens'] = np.array([char_beg_idx, char_end_idx, elem_beg_idx,
+            elem_end_idx, elem_char_idx1, elem_char_idx2, self.max_text_length,
+            self.max_elem_length, self.max_cell_num, elem_num])
+        return data
+
+    def encode(self, text, char_or_elem):
+        """convert text-label into text-index.
+        """
+        if char_or_elem == "char":
+            max_len = self.max_text_length
+            current_dict = self.dict_character
+        else:
+            max_len = self.max_elem_length
+            current_dict = self.dict_elem
+        if len(text) > max_len:
+            return None
+        if len(text) == 0:
+            if char_or_elem == "char":
+                return [self.dict_character['space']]
+            else:
+                return None
+        text_list = []
+        for char in text:
+            if char not in current_dict:
+                return None
+            text_list.append(current_dict[char])
+        if len(text_list) == 0:
+            if char_or_elem == "char":
+                return [self.dict_character['space']]
+            else:
+                return None
+        return text_list
+
+    def get_ignored_tokens(self, char_or_elem):
+        beg_idx = self.get_beg_end_flag_idx("beg", char_or_elem)
+        end_idx = self.get_beg_end_flag_idx("end", char_or_elem)
+        return [beg_idx, end_idx]
+
+    def get_beg_end_flag_idx(self, beg_or_end, char_or_elem):
+        if char_or_elem == "char":
+            if beg_or_end == "beg":
+                idx = np.array(self.dict_character[self.beg_str])
+            elif beg_or_end == "end":
+                idx = np.array(self.dict_character[self.end_str])
+            else:
+                assert False, "Unsupport type %s in get_beg_end_flag_idx of char" \
+                              % beg_or_end
+        elif char_or_elem == "elem":
+            if beg_or_end == "beg":
+                idx = np.array(self.dict_elem[self.beg_str])
+            elif beg_or_end == "end":
+                idx = np.array(self.dict_elem[self.end_str])
+            else:
+                assert False, "Unsupport type %s in get_beg_end_flag_idx of elem" \
+                              % beg_or_end
+        else:
+            assert False, "Unsupport type %s in char_or_elem" \
+                              % char_or_elem
+        return idx
+
\ No newline at end of file

ppocr/data/pubtab_dataset.py

+# copyright (c) 2021 PaddlePaddle Authors. All Rights Reserve.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#    http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+import numpy as np
+import os
+import random
+from paddle.io import Dataset
+import json
+
+from .imaug import transform, create_operators
+
+
+class PubTabDataSet(Dataset):
+    def __init__(self, config, mode, logger, seed=None):
+        super(PubTabDataSet, self).__init__()
+        self.logger = logger
+
+        global_config = config['Global']
+        dataset_config = config[mode]['dataset']
+        loader_config = config[mode]['loader']
+
+        label_file_path = dataset_config.pop('label_file_path')
+
+        self.data_dir = dataset_config['data_dir']
+        self.do_shuffle = loader_config['shuffle']
+        self.do_hard_select = False
+        if 'hard_select' in loader_config:
+            self.do_hard_select = loader_config['hard_select']
+            self.hard_prob = loader_config['hard_prob']
+        if self.do_hard_select:
+            self.img_select_prob = self.load_hard_select_prob()
+        self.table_select_type = None
+        if 'table_select_type' in loader_config:
+            self.table_select_type = loader_config['table_select_type']
+            self.table_select_prob = loader_config['table_select_prob']
+
+        self.seed = seed
+        logger.info("Initialize indexs of datasets:%s" % label_file_path)
+        with open(label_file_path, "rb") as f:
+            self.data_lines = f.readlines()
+        self.data_idx_order_list = list(range(len(self.data_lines)))
+        if mode.lower() == "train":
+            self.shuffle_data_random()
+        self.ops = create_operators(dataset_config['transforms'], global_config)
+
+    def shuffle_data_random(self):
+        if self.do_shuffle:
+            random.seed(self.seed)
+            random.shuffle(self.data_lines)
+        return
+
+    def __getitem__(self, idx):
+        try:
+            data_line = self.data_lines[idx]
+            data_line = data_line.decode('utf-8').strip("\n")
+            info = json.loads(data_line)
+            file_name = info['filename']
+            select_flag = True
+            if self.do_hard_select:
+                prob = self.img_select_prob[file_name]
+                if prob < random.uniform(0, 1):
+                    select_flag = False
+
+            if self.table_select_type:
+                structure = info['html']['structure']['tokens'].copy()
+                structure_str = ''.join(structure)
+                table_type = "simple"
+                if 'colspan' in structure_str or 'rowspan' in structure_str:
+                    table_type = "complex"
+                if table_type == "complex":
+                    if self.table_select_prob < random.uniform(0, 1):
+                        select_flag = False
+
+            if select_flag:
+                cells = info['html']['cells'].copy()
+                structure = info['html']['structure'].copy()
+                img_path = os.path.join(self.data_dir, file_name)
+                data = {'img_path': img_path, 'cells': cells, 'structure':structure}
+                if not os.path.exists(img_path):
+                    raise Exception("{} does not exist!".format(img_path))
+                with open(data['img_path'], 'rb') as f:
+                    img = f.read()
+                    data['image'] = img
+                outs = transform(data, self.ops)
+            else:
+                outs = None
+        except Exception as e:
+            self.logger.error(
+                "When parsing line {}, error happened with msg: {}".format(
+                    data_line, e))
+            outs = None
+        if outs is None:
+            return self.__getitem__(np.random.randint(self.__len__()))
+        return outs
+
+    def __len__(self):
+        return len(self.data_idx_order_list)
