feat: add [figure | table] match [caption | footnote] match algorithm v2

feat: add Data api

magic_pdf/data/io/base.py

+from abc import ABC, abstractmethod
+
+
+class IOReader(ABC):
+    @abstractmethod
+    def read(self, path: str) -> bytes:
+        """Read the file.
+
+        Args:
+            path (str): file path to read
+
+        Returns:
+            bytes: the content of the file
+        """
+        pass
+
+    @abstractmethod
+    def read_at(self, path: str, offset: int = 0, limit: int = -1) -> bytes:
+        """Read at offset and limit.
+
+        Args:
+            path (str): the path of file, if the path is relative path, it will be joined with parent_dir.
+            offset (int, optional): the number of bytes skipped. Defaults to 0.
+            limit (int, optional): the length of bytes want to read. Defaults to -1.
+
+        Returns:
+            bytes: the content of file
+        """
+        pass
+
+
+class IOWriter:
+
+    @abstractmethod
+    def write(self, path: str, data: bytes) -> None:
+        """Write file with data.
+
+        Args:
+            path (str): the path of file, if the path is relative path, it will be joined with parent_dir.
+            data (bytes): the data want to write
+        """
+        pass

magic_pdf/data/io/http.py

+
+import io
+
+import requests
+
+from magic_pdf.data.io.base import IOReader, IOWriter
+
+
+class HttpReader(IOReader):
+
+    def read(self, url: str) -> bytes:
+        """Read the file.
+
+        Args:
+            path (str): file path to read
+
+        Returns:
+            bytes: the content of the file
+        """
+        return requests.get(url).content
+
+    def read_at(self, path: str, offset: int = 0, limit: int = -1) -> bytes:
+        """Not Implemented."""
+        raise NotImplementedError
+
+
+class HttpWriter(IOWriter):
+    def write(self, url: str, data: bytes) -> None:
+        """Write file with data.
+
+        Args:
+            path (str): the path of file, if the path is relative path, it will be joined with parent_dir.
+            data (bytes): the data want to write
+        """
+        files = {'file': io.BytesIO(data)}
+        response = requests.post(url, files=files)
+        assert 300 > response.status_code and response.status_code > 199

magic_pdf/data/io/s3.py

+import boto3
+from botocore.config import Config
+
+from magic_pdf.data.io.base import IOReader, IOWriter
+
+
+class S3Reader(IOReader):
+    def __init__(
+        self,
+        bucket: str,
+        ak: str,
+        sk: str,
+        endpoint_url: str,
+        addressing_style: str = 'auto',
+    ):
+        """s3 reader client.
+
+        Args:
+            bucket (str): bucket name
+            ak (str): access key
+            sk (str): secret key
+            endpoint_url (str): endpoint url of s3
+            addressing_style (str, optional): Defaults to 'auto'. Other valid options here are 'path' and 'virtual'
+            refer to https://boto3.amazonaws.com/v1/documentation/api/1.9.42/guide/s3.html
+        """
+        self._bucket = bucket
+        self._ak = ak
+        self._sk = sk
+        self._s3_client = boto3.client(
+            service_name='s3',
+            aws_access_key_id=ak,
+            aws_secret_access_key=sk,
+            endpoint_url=endpoint_url,
+            config=Config(
+                s3={'addressing_style': addressing_style},
+                retries={'max_attempts': 5, 'mode': 'standard'},
+            ),
+        )
+
+    def read(self, key: str) -> bytes:
+        """Read the file.
+
+        Args:
+            path (str): file path to read
+
+        Returns:
+            bytes: the content of the file
+        """
+        return self.read_at(key)
+
+    def read_at(self, key: str, offset: int = 0, limit: int = -1) -> bytes:
+        """Read at offset and limit.
+
+        Args:
+            path (str): the path of file, if the path is relative path, it will be joined with parent_dir.
+            offset (int, optional): the number of bytes skipped. Defaults to 0.
+            limit (int, optional): the length of bytes want to read. Defaults to -1.
+
+        Returns:
+            bytes: the content of file
+        """
+        if limit > -1:
+            range_header = f'bytes={offset}-{offset+limit-1}'
+            res = self._s3_client.get_object(
+                Bucket=self._bucket, Key=key, Range=range_header
+            )
+        else:
+            res = self._s3_client.get_object(
+                Bucket=self._bucket, Key=key, Range=f'bytes={offset}-'
+            )
+        return res['Body'].read()
+
+
+class S3Writer(IOWriter):
+    def __init__(
+        self,
+        bucket: str,
+        ak: str,
+        sk: str,
+        endpoint_url: str,
+        addressing_style: str = 'auto',
+    ):
+        """s3 reader client.
+
+        Args:
+            bucket (str): bucket name
+            ak (str): access key
+            sk (str): secret key
+            endpoint_url (str): endpoint url of s3
+            addressing_style (str, optional): Defaults to 'auto'. Other valid options here are 'path' and 'virtual'
+            refer to https://boto3.amazonaws.com/v1/documentation/api/1.9.42/guide/s3.html
+        """
+        self._bucket = bucket
+        self._ak = ak
+        self._sk = sk
+        self._s3_client = boto3.client(
+            service_name='s3',
+            aws_access_key_id=ak,
+            aws_secret_access_key=sk,
+            endpoint_url=endpoint_url,
+            config=Config(
+                s3={'addressing_style': addressing_style},
+                retries={'max_attempts': 5, 'mode': 'standard'},
+            ),
+        )
+
+    def write(self, key: str, data: bytes):
+        """Write file with data.
+
+        Args:
+            path (str): the path of file, if the path is relative path, it will be joined with parent_dir.
+            data (bytes): the data want to write
+        """
+        self._s3_client.put_object(Bucket=self._bucket, Key=key, Body=data)

magic_pdf/data/read_api.py

+import json
+import os
+from pathlib import Path
+
+from magic_pdf.config.exceptions import EmptyData, InvalidParams
+from magic_pdf.data.data_reader_writer import (FileBasedDataReader,
+                                               MultiBucketS3DataReader)
+from magic_pdf.data.dataset import ImageDataset, PymuDocDataset
+
+
+def read_jsonl(
+    s3_path_or_local: str, s3_client: MultiBucketS3DataReader | None = None
+) -> list[PymuDocDataset]:
+    """Read the jsonl file and return the list of PymuDocDataset.
+
+    Args:
+        s3_path_or_local (str): local file or s3 path
+        s3_client (MultiBucketS3DataReader | None, optional): s3 client that support multiple bucket. Defaults to None.
+
+    Raises:
+        InvalidParams: if s3_path_or_local is s3 path but s3_client is not provided.
+        EmptyData: if no pdf file location is provided in some line of jsonl file.
+        InvalidParams: if the file location is s3 path but s3_client is not provided
+
+    Returns:
+        list[PymuDocDataset]: each line in the jsonl file will be converted to a PymuDocDataset
+    """
+    bits_arr = []
+    if s3_path_or_local.startswith('s3://'):
+        if s3_client is None:
+            raise InvalidParams('s3_client is required when s3_path is provided')
+        jsonl_bits = s3_client.read(s3_path_or_local)
+    else:
+        jsonl_bits = FileBasedDataReader('').read(s3_path_or_local)
+    jsonl_d = [
+        json.loads(line) for line in jsonl_bits.decode().split('\n') if line.strip()
+    ]
+    for d in jsonl_d[:5]:
+        pdf_path = d.get('file_location', '') or d.get('path', '')
+        if len(pdf_path) == 0:
+            raise EmptyData('pdf file location is empty')
+        if pdf_path.startswith('s3://'):
+            if s3_client is None:
+                raise InvalidParams('s3_client is required when s3_path is provided')
+            bits_arr.append(s3_client.read(pdf_path))
+        else:
+            bits_arr.append(FileBasedDataReader('').read(pdf_path))
+    return [PymuDocDataset(bits) for bits in bits_arr]
+
+
+def read_local_pdfs(path: str) -> list[PymuDocDataset]:
+    """Read pdf from path or directory.
+
+    Args:
+        path (str): pdf file path or directory that contains pdf files
+
+    Returns:
+        list[PymuDocDataset]: each pdf file will converted to a PymuDocDataset
+    """
+    if os.path.isdir(path):
+        reader = FileBasedDataReader(path)
+        return [
+            PymuDocDataset(reader.read(doc_path.name))
+            for doc_path in Path(path).glob('*.pdf')
+        ]
+    else:
+        reader = FileBasedDataReader()
+        bits = reader.read(path)
+        return [PymuDocDataset(bits)]
+
+
+def read_local_images(path: str, suffixes: list[str]) -> list[ImageDataset]:
+    """Read images from path or directory.
+
+    Args:
+        path (str): image file path or directory that contains image files
+        suffixes (list[str]): the suffixes of the image files used to filter the files. Example: ['jpg', 'png']
+
+    Returns:
+        list[ImageDataset]: each image file will converted to a ImageDataset
+    """
+    if os.path.isdir(path):
+        imgs_bits = []
+        s_suffixes = set(suffixes)
+        reader = FileBasedDataReader(path)
+        for root, _, files in os.walk(path):
+            for file in files:
+                suffix = file.split('.')
+                if suffix[-1] in s_suffixes:
+                    imgs_bits.append(reader.read(file))
+        return [ImageDataset(bits) for bits in imgs_bits]
+    else:
+        reader = FileBasedDataReader()
+        bits = reader.read(path)
+        return [ImageDataset(bits)]

magic_pdf/data/schemas.py

+
+from pydantic import BaseModel, Field
+
+
+class S3Config(BaseModel):
+    bucket_name: str = Field(description='s3 bucket name', min_length=1)
+    access_key: str = Field(description='s3 access key', min_length=1)
+    secret_key: str = Field(description='s3 secret key', min_length=1)
+    endpoint_url: str = Field(description='s3 endpoint url', min_length=1)
+    addressing_style: str = Field(description='s3 addressing style', default='auto', min_length=1)
+
+
+class PageInfo(BaseModel):
+    w: float = Field(description='the width of page')
+    h: float = Field(description='the height of page')

magic_pdf/data/utils.py

+
+import fitz
+import numpy as np
+
+from magic_pdf.utils.annotations import ImportPIL
+
+
+@ImportPIL
+def fitz_doc_to_image(doc, dpi=200) -> dict:
+    """Convert fitz.Document to image, Then convert the image to numpy array.
+
+    Args:
+        doc (_type_): pymudoc page
+        dpi (int, optional): reset the dpi of dpi. Defaults to 200.
+
+    Returns:
+        dict:  {'img': numpy array, 'width': width, 'height': height }
+    """
+    from PIL import Image
+    mat = fitz.Matrix(dpi / 72, dpi / 72)
+    pm = doc.get_pixmap(matrix=mat, alpha=False)
+
+    # If the width or height exceeds 9000 after scaling, do not scale further.
+    if pm.width > 9000 or pm.height > 9000:
+        pm = doc.get_pixmap(matrix=fitz.Matrix(1, 1), alpha=False)
+
+    img = Image.frombytes('RGB', (pm.width, pm.height), pm.samples)
+    img = np.array(img)
+
+    img_dict = {'img': img, 'width': pm.width, 'height': pm.height}
+
+    return img_dict

magic_pdf/libs/config_reader.py

-"""
-根据bucket的名字返回对应的s3 AK， SK，endpoint三元组
-
-"""
+"""根据bucket的名字返回对应的s3 AK， SK，endpoint三元组."""

 import json
 import os
@@ -12,36 +9,36 @@ from magic_pdf.libs.Constants import MODEL_NAME
 from magic_pdf.libs.commons import parse_bucket_key

 # 定义配置文件名常量
-CONFIG_FILE_NAME = "magic-pdf.json"
+CONFIG_FILE_NAME = os.getenv('MINERU_TOOLS_CONFIG_JSON', 'magic-pdf.json')


 def read_config():
-    home_dir = os.path.expanduser("~")
-
-    config_file = os.path.join(home_dir, CONFIG_FILE_NAME)
+    if os.path.isabs(CONFIG_FILE_NAME):
+        config_file = CONFIG_FILE_NAME
+    else:
+        home_dir = os.path.expanduser('~')
+        config_file = os.path.join(home_dir, CONFIG_FILE_NAME)

     if not os.path.exists(config_file):
-        raise FileNotFoundError(f"{config_file} not found")
+        raise FileNotFoundError(f'{config_file} not found')

-    with open(config_file, "r", encoding="utf-8") as f:
+    with open(config_file, 'r', encoding='utf-8') as f:
         config = json.load(f)
     return config


 def get_s3_config(bucket_name: str):
-    """
-    ~/magic-pdf.json 读出来
-    """
+    """~/magic-pdf.json 读出来."""
     config = read_config()

-    bucket_info = config.get("bucket_info")
+    bucket_info = config.get('bucket_info')
     if bucket_name not in bucket_info:
-        access_key, secret_key, storage_endpoint = bucket_info["[default]"]
+        access_key, secret_key, storage_endpoint = bucket_info['[default]']
     else:
         access_key, secret_key, storage_endpoint = bucket_info[bucket_name]

     if access_key is None or secret_key is None or storage_endpoint is None:
-        raise Exception(f"ak, sk or endpoint not found in {CONFIG_FILE_NAME}")
+        raise Exception(f'ak, sk or endpoint not found in {CONFIG_FILE_NAME}')

     # logger.info(f"get_s3_config: ak={access_key}, sk={secret_key}, endpoint={storage_endpoint}")

@@ -50,7 +47,7 @@ def get_s3_config(bucket_name: str):

 def get_s3_config_dict(path: str):
     access_key, secret_key, storage_endpoint = get_s3_config(get_bucket_name(path))
-    return {"ak": access_key, "sk": secret_key, "endpoint": storage_endpoint}
+    return {'ak': access_key, 'sk': secret_key, 'endpoint': storage_endpoint}


 def get_bucket_name(path):
@@ -60,20 +57,20 @@ def get_bucket_name(path):

 def get_local_models_dir():
     config = read_config()
-    models_dir = config.get("models-dir")
+    models_dir = config.get('models-dir')
     if models_dir is None:
         logger.warning(f"'models-dir' not found in {CONFIG_FILE_NAME}, use '/tmp/models' as default")
-        return "/tmp/models"
+        return '/tmp/models'
     else:
         return models_dir


 def get_local_layoutreader_model_dir():
     config = read_config()
-    layoutreader_model_dir = config.get("layoutreader-model-dir")
+    layoutreader_model_dir = config.get('layoutreader-model-dir')
     if layoutreader_model_dir is None or not os.path.exists(layoutreader_model_dir):
-        home_dir = os.path.expanduser("~")
-        layoutreader_at_modelscope_dir_path = os.path.join(home_dir, ".cache/modelscope/hub/ppaanngggg/layoutreader")
+        home_dir = os.path.expanduser('~')
+        layoutreader_at_modelscope_dir_path = os.path.join(home_dir, '.cache/modelscope/hub/ppaanngggg/layoutreader')
         logger.warning(f"'layoutreader-model-dir' not exists, use {layoutreader_at_modelscope_dir_path} as default")
         return layoutreader_at_modelscope_dir_path
     else:
@@ -82,17 +79,17 @@ def get_local_layoutreader_model_dir():

 def get_device():
     config = read_config()
-    device = config.get("device-mode")
+    device = config.get('device-mode')
     if device is None:
         logger.warning(f"'device-mode' not found in {CONFIG_FILE_NAME}, use 'cpu' as default")
-        return "cpu"
+        return 'cpu'
     else:
         return device


 def get_table_recog_config():
     config = read_config()
-    table_config = config.get("table-config")
+    table_config = config.get('table-config')
     if table_config is None:
         logger.warning(f"'table-config' not found in {CONFIG_FILE_NAME}, use 'False' as default")
         return json.loads(f'{{"model": "{MODEL_NAME.TABLE_MASTER}","enable": false, "max_time": 400}}')

magic_pdf/libs/draw_bbox.py

+from magic_pdf.data.dataset import PymuDocDataset
 from magic_pdf.libs.commons import fitz  # PyMuPDF
 from magic_pdf.libs.Constants import CROSS_PAGE
 from magic_pdf.libs.ocr_content_type import BlockType, CategoryId, ContentType
@@ -62,7 +63,7 @@ def draw_bbox_with_number(i, bbox_list, page, rgb_config, fill_config, draw_bbox
                     overlay=True,
                 )  # Draw the rectangle
         page.insert_text(
-            (x1+2, y0 + 10), str(j + 1), fontsize=10, color=new_rgb
+            (x1 + 2, y0 + 10), str(j + 1), fontsize=10, color=new_rgb
         )  # Insert the index in the top left corner of the rectangle


@@ -86,7 +87,7 @@ def draw_layout_bbox(pdf_info, pdf_bytes, out_path, filename):
         texts = []
         interequations = []
         lists = []
-        indexs = []
+        indices = []

         for dropped_bbox in page['discarded_blocks']:
             page_dropped_list.append(dropped_bbox['bbox'])
@@ -122,7 +123,7 @@ def draw_layout_bbox(pdf_info, pdf_bytes, out_path, filename):
             elif block['type'] == BlockType.List:
                 lists.append(bbox)
             elif block['type'] == BlockType.Index:
-                indexs.append(bbox)
+                indices.append(bbox)

         tables_list.append(tables)
         tables_body_list.append(tables_body)
@@ -136,7 +137,7 @@ def draw_layout_bbox(pdf_info, pdf_bytes, out_path, filename):
         texts_list.append(texts)
         interequations_list.append(interequations)
         lists_list.append(lists)
-        indexs_list.append(indexs)
+        indexs_list.append(indices)

     layout_bbox_list = []

@@ -151,30 +152,24 @@ def draw_layout_bbox(pdf_info, pdf_bytes, out_path, filename):

     for i, page in enumerate(pdf_docs):

-        draw_bbox_without_number(i, dropped_bbox_list, page, [158, 158, 158],
-                                 True)
-        draw_bbox_without_number(i, tables_list, page, [153, 153, 0],
-                                 True)  # color !
-        draw_bbox_without_number(i, tables_body_list, page, [204, 204, 0],
-                                 True)
-        draw_bbox_without_number(i, tables_caption_list, page, [255, 255, 102],
-                                 True)
-        draw_bbox_without_number(i, tables_footnote_list, page,
-                                 [229, 255, 204], True)
+        draw_bbox_without_number(i, dropped_bbox_list, page, [158, 158, 158], True)
+        draw_bbox_without_number(i, tables_list, page, [153, 153, 0], True)  # color !
+        draw_bbox_without_number(i, tables_body_list, page, [204, 204, 0], True)
+        draw_bbox_without_number(i, tables_caption_list, page, [255, 255, 102], True)
+        draw_bbox_without_number(i, tables_footnote_list, page, [229, 255, 204], True)
         draw_bbox_without_number(i, imgs_list, page, [51, 102, 0], True)
         draw_bbox_without_number(i, imgs_body_list, page, [153, 255, 51], True)
-        draw_bbox_without_number(i, imgs_caption_list, page, [102, 178, 255],
-                                 True)
-        draw_bbox_without_number(i, imgs_footnote_list, page, [255, 178, 102],
-                              True),
+        draw_bbox_without_number(i, imgs_caption_list, page, [102, 178, 255], True)
+        draw_bbox_without_number(i, imgs_footnote_list, page, [255, 178, 102], True),
         draw_bbox_without_number(i, titles_list, page, [102, 102, 255], True)
         draw_bbox_without_number(i, texts_list, page, [153, 0, 76], True)
-        draw_bbox_without_number(i, interequations_list, page, [0, 255, 0],
-                                 True)
+        draw_bbox_without_number(i, interequations_list, page, [0, 255, 0], True)
         draw_bbox_without_number(i, lists_list, page, [40, 169, 92], True)
         draw_bbox_without_number(i, indexs_list, page, [40, 169, 92], True)

-        draw_bbox_with_number(i, layout_bbox_list, page, [255, 0, 0], False, draw_bbox=False)
+        draw_bbox_with_number(
+            i, layout_bbox_list, page, [255, 0, 0], False, draw_bbox=False
+        )

     # Save the PDF
     pdf_docs.save(f'{out_path}/{filename}_layout.pdf')
@@ -275,7 +270,7 @@ def draw_model_bbox(model_list: list, pdf_bytes, out_path, filename):
     texts_list = []
     interequations_list = []
     pdf_docs = fitz.open('pdf', pdf_bytes)
-    magic_model = MagicModel(model_list, pdf_docs)
+    magic_model = MagicModel(model_list, PymuDocDataset(pdf_bytes))
     for i in range(len(model_list)):
         page_dropped_list = []
         tables_body, tables_caption, tables_footnote = [], [], []
@@ -301,8 +296,7 @@ def draw_model_bbox(model_list: list, pdf_bytes, out_path, filename):
                 imgs_body.append(bbox)
             elif layout_det['category_id'] == CategoryId.ImageCaption:
                 imgs_caption.append(bbox)
-            elif layout_det[
-                'category_id'] == CategoryId.InterlineEquation_YOLO:
+            elif layout_det['category_id'] == CategoryId.InterlineEquation_YOLO:
                 interequations.append(bbox)
             elif layout_det['category_id'] == CategoryId.Abandon:
                 page_dropped_list.append(bbox)
@@ -321,18 +315,15 @@ def draw_model_bbox(model_list: list, pdf_bytes, out_path, filename):
         imgs_footnote_list.append(imgs_footnote)

     for i, page in enumerate(pdf_docs):
-        draw_bbox_with_number(i, dropped_bbox_list, page, [158, 158, 158],
-                              True)  # color !
+        draw_bbox_with_number(
+            i, dropped_bbox_list, page, [158, 158, 158], True
+        )  # color !
         draw_bbox_with_number(i, tables_body_list, page, [204, 204, 0], True)
-        draw_bbox_with_number(i, tables_caption_list, page, [255, 255, 102],
-                              True)
-        draw_bbox_with_number(i, tables_footnote_list, page, [229, 255, 204],
-                              True)
+        draw_bbox_with_number(i, tables_caption_list, page, [255, 255, 102], True)
+        draw_bbox_with_number(i, tables_footnote_list, page, [229, 255, 204], True)
         draw_bbox_with_number(i, imgs_body_list, page, [153, 255, 51], True)
-        draw_bbox_with_number(i, imgs_caption_list, page, [102, 178, 255],
-                              True)
-        draw_bbox_with_number(i, imgs_footnote_list, page, [255, 178, 102],
-                              True)
+        draw_bbox_with_number(i, imgs_caption_list, page, [102, 178, 255], True)
+        draw_bbox_with_number(i, imgs_footnote_list, page, [255, 178, 102], True)
         draw_bbox_with_number(i, titles_list, page, [102, 102, 255], True)
         draw_bbox_with_number(i, texts_list, page, [153, 0, 76], True)
         draw_bbox_with_number(i, interequations_list, page, [0, 255, 0], True)

magic_pdf/model/magic_model.py

 import json

+from magic_pdf.data.dataset import Dataset
 from magic_pdf.libs.boxbase import (_is_in, _is_part_overlap, bbox_distance,
                                     bbox_relative_pos, box_area, calculate_iou,
                                     calculate_overlap_area_in_bbox1_area_ratio,
@@ -24,7 +25,7 @@ class MagicModel:
             need_remove_list = []
             page_no = model_page_info['page_info']['page_no']
             horizontal_scale_ratio, vertical_scale_ratio = get_scale_ratio(
-                model_page_info, self.__docs[page_no]
+                model_page_info, self.__docs.get_page(page_no)
             )
             layout_dets = model_page_info['layout_dets']
             for layout_det in layout_dets:
@@ -99,7 +100,7 @@ class MagicModel:
             for need_remove in need_remove_list:
                 layout_dets.remove(need_remove)

-    def __init__(self, model_list: list, docs: fitz.Document):
+    def __init__(self, model_list: list, docs: Dataset):
         self.__model_list = model_list
         self.__docs = docs
         """为所有模型数据添加bbox信息(缩放，poly->bbox)"""
@@ -123,7 +124,8 @@ class MagicModel:
             l1 = bbox1[2] - bbox1[0]
             l2 = bbox2[2] - bbox2[0]

-        if l2 > l1 and (l2 - l1) / l1 > 0.5:
+        min_l, max_l = min(l1, l2), max(l1, l2)
+        if (max_l - min_l) * 1.0 / max_l > 0.4:
             return float('inf')

         return bbox_distance(bbox1, bbox2)
@@ -213,9 +215,8 @@ class MagicModel:
         筛选出所有和 merged bbox 有 overlap 且 overlap 面积大于 object 的面积的 subjects。
         再求出筛选出的 subjects 和 object 的最短距离
         """
-        def search_overlap_between_boxes(
-            subject_idx, object_idx
-        ):
+
+        def search_overlap_between_boxes(subject_idx, object_idx):
             idxes = [subject_idx, object_idx]
             x0s = [all_bboxes[idx]['bbox'][0] for idx in idxes]
             y0s = [all_bboxes[idx]['bbox'][1] for idx in idxes]
@@ -243,9 +244,9 @@ class MagicModel:
             for other_object in other_objects:
                 ratio = max(
                     ratio,
-                    get_overlap_area(
-                        merged_bbox, other_object['bbox']
-                    ) * 1.0 / box_area(all_bboxes[object_idx]['bbox'])
+                    get_overlap_area(merged_bbox, other_object['bbox'])
+                    * 1.0
+                    / box_area(all_bboxes[object_idx]['bbox']),
                 )
                 if ratio >= MERGE_BOX_OVERLAP_AREA_RATIO:
                     break
@@ -363,12 +364,17 @@ class MagicModel:
                 if all_bboxes[j]['category_id'] == subject_category_id:
                     subject_idx, object_idx = j, i

-                if search_overlap_between_boxes(subject_idx, object_idx) >= MERGE_BOX_OVERLAP_AREA_RATIO:
+                if (
+                    search_overlap_between_boxes(subject_idx, object_idx)
+                    >= MERGE_BOX_OVERLAP_AREA_RATIO
+                ):
                     dis[i][j] = float('inf')
                     dis[j][i] = dis[i][j]
                     continue

-                dis[i][j] = self._bbox_distance(all_bboxes[subject_idx]['bbox'], all_bboxes[object_idx]['bbox'])
+                dis[i][j] = self._bbox_distance(
+                    all_bboxes[subject_idx]['bbox'], all_bboxes[object_idx]['bbox']
+                )
                 dis[j][i] = dis[i][j]

         used = set()
@@ -584,6 +590,99 @@ class MagicModel:
                 with_caption_subject.add(j)
         return ret, total_subject_object_dis

+    def __tie_up_category_by_distance_v2(
+        self, page_no, subject_category_id, object_category_id
+    ):
+
+        subjects = self.__reduct_overlap(
+            list(
+                map(
+                    lambda x: {'bbox': x['bbox'], 'score': x['score']},
+                    filter(
+                        lambda x: x['category_id'] == subject_category_id,
+                        self.__model_list[page_no]['layout_dets'],
+                    ),
+                )
+            )
+        )
+
+        objects = self.__reduct_overlap(
+            list(
+                map(
+                    lambda x: {'bbox': x['bbox'], 'score': x['score']},
+                    filter(
+                        lambda x: x['category_id'] == object_category_id,
+                        self.__model_list[page_no]['layout_dets'],
+                    ),
+                )
+            )
+        )
+
+        print(len(subjects), len(objects))
+
+        subjects.sort(key=lambda x: x['bbox'][0] ** 2 + x['bbox'][1] ** 2)
+        objects.sort(key=lambda x: x['bbox'][0] ** 2 + x['bbox'][1] ** 2)
+        dis = [[float('inf')] * len(subjects) for _ in range(len(objects))]
+        for i, obj in enumerate(objects):
+            for j, sub in enumerate(subjects):
+                dis[i][j] = self._bbox_distance(sub['bbox'], obj['bbox'])
+
+        sub_obj_map_h = {i: [] for i in range(len(subjects))}
+        for i in range(len(objects)):
+            min_l_idx = 0
+            for j in range(1, len(subjects)):
+                if dis[i][j] == float('inf'):
+                    continue
+                if dis[i][j] < dis[i][min_l_idx]:
+                    min_l_idx = j
+
+            if dis[i][min_l_idx] < float('inf'):
+                sub_obj_map_h[min_l_idx].append(i)
+            else:
+                print(i, 'no nearest')
+        ret = []
+        for i in sub_obj_map_h.keys():
+            ret.append(
+                {
+                    'sub_bbox': subjects[i]['bbox'],
+                    'obj_bboxes': [objects[j]['bbox'] for j in sub_obj_map_h[i]],
+                    'sub_idx': i,
+                }
+            )
+        return ret
+
+    def get_imgs_v2(self, page_no: int):
+        with_captions = self.__tie_up_category_by_distance_v2(page_no, 3, 4)
+        with_footnotes = self.__tie_up_category_by_distance_v2(
+            page_no, 3, CategoryId.ImageFootnote
+        )
+        ret = []
+        for v in with_captions:
+            record = {
+                'image_bbox': v['sub_bbox'],
+                'image_caption_bbox_list': v['obj_bboxes'],
+            }
+            filter_idx = v['sub_idx']
+            d = next(filter(lambda x: x['sub_idx'] == filter_idx, with_footnotes))
+            record['image_footnote_bbox_list'] = d['obj_bboxes']
+            ret.append(record)
+        return ret
+
+    def get_tables_v2(self, page_no: int) -> list:
+        with_captions = self.__tie_up_category_by_distance_v2(page_no, 5, 6)
+        with_footnotes = self.__tie_up_category_by_distance_v2(page_no, 5, 7)
+        ret = []
+        for v in with_captions:
+            record = {
+                'table_bbox': v['sub_bbox'],
+                'table_caption_bbox_list': v['obj_bboxes'],
+            }
+            filter_idx = v['sub_idx']
+            d = next(filter(lambda x: x['sub_idx'] == filter_idx, with_footnotes))
+            record['table_footnote_bbox_list'] = d['obj_bboxes']
+            ret.append(record)
+        return ret
+
     def get_imgs(self, page_no: int):
         with_captions, _ = self.__tie_up_category_by_distance(page_no, 3, 4)
         with_footnotes, _ = self.__tie_up_category_by_distance(
@@ -717,10 +816,10 @@ class MagicModel:

     def get_page_size(self, page_no: int):  # 获取页面宽高
         # 获取当前页的page对象
-        page = self.__docs[page_no]
+        page = self.__docs.get_page(page_no).get_page_info()
         # 获取当前页的宽高
-        page_w = page.rect.width
-        page_h = page.rect.height
+        page_w = page.w
+        page_h = page.h
         return page_w, page_h

     def __get_blocks_by_type(

magic_pdf/pdf_parse_by_ocr.py

+from magic_pdf.config.enums import SupportedPdfParseMethod
+from magic_pdf.data.dataset import PymuDocDataset
 from magic_pdf.pdf_parse_union_core_v2 import pdf_parse_union


@@ -8,10 +10,11 @@ def parse_pdf_by_ocr(pdf_bytes,
                      end_page_id=None,
                      debug_mode=False,
                      ):
-    return pdf_parse_union(pdf_bytes,
+    dataset = PymuDocDataset(pdf_bytes)
+    return pdf_parse_union(dataset,
                            model_list,
                            imageWriter,
-                           "ocr",
+                           SupportedPdfParseMethod.OCR,
                            start_page_id=start_page_id,
                            end_page_id=end_page_id,
                            debug_mode=debug_mode,

magic_pdf/pdf_parse_by_txt.py

+from magic_pdf.config.enums import SupportedPdfParseMethod
+from magic_pdf.data.dataset import PymuDocDataset
 from magic_pdf.pdf_parse_union_core_v2 import pdf_parse_union


@@ -9,10 +11,11 @@ def parse_pdf_by_txt(
     end_page_id=None,
     debug_mode=False,
 ):
-    return pdf_parse_union(pdf_bytes,
+    dataset = PymuDocDataset(pdf_bytes)
+    return pdf_parse_union(dataset,
                            model_list,
                            imageWriter,
-                           "txt",
+                           SupportedPdfParseMethod.TXT,
                            start_page_id=start_page_id,
                            end_page_id=end_page_id,
                            debug_mode=debug_mode,

magic_pdf/tools/common.py

@@ -6,8 +6,8 @@ import click
 from loguru import logger

 import magic_pdf.model as model_config
-from magic_pdf.libs.draw_bbox import (draw_layout_bbox, draw_span_bbox,
-                                      draw_model_bbox, draw_line_sort_bbox)
+from magic_pdf.libs.draw_bbox import (draw_layout_bbox, draw_line_sort_bbox,
+                                      draw_model_bbox, draw_span_bbox)
 from magic_pdf.libs.MakeContentConfig import DropMode, MakeMode
 from magic_pdf.pipe.OCRPipe import OCRPipe
 from magic_pdf.pipe.TXTPipe import TXTPipe

magic_pdf/utils/annotations.py

+
+from loguru import logger
+
+
+def ImportPIL(f):
+    try:
+        import PIL  # noqa: F401
+    except ImportError:
+        logger.error('Pillow not installed, please install by pip.')
+        exit(1)
+    return f

tests/test_data/assets/jsonl/test_01.jsonl

+{"track_id":"e8824f5a-9fcb-4ee5-b2d4-6bf2c67019dc","path":"s3://sci-hub/enbook-scimag/78800000/libgen.scimag78872000-78872999/10.1017/cbo9780511770425.012.pdf","file_type":"pdf","content_type":"application/pdf","content_length":80078,"title":"German Idealism and the Concept of Punishment || Conclusion","remark":{"file_id":"scihub_78800000/libgen.scimag78872000-78872999.zip_10.1017/cbo9780511770425.012","file_source_type":"paper","original_file_id":"10.1017/cbo9780511770425.012","file_name":"10.1017/cbo9780511770425.012.pdf","author":"Merle, Jean-Christophe"}}

tests/test_data/assets/jsonl/test_02.jsonl

+{"track_id":"e8824f5a-9fcb-4ee5-b2d4-6bf2c67019dc","path":"tests/test_data/assets/pdfs/test_02.pdf","file_type":"pdf","content_type":"application/pdf","content_length":80078,"title":"German Idealism and the Concept of Punishment || Conclusion","remark":{"file_id":"scihub_78800000/libgen.scimag78872000-78872999.zip_10.1017/cbo9780511770425.012","file_source_type":"paper","original_file_id":"10.1017/cbo9780511770425.012","file_name":"10.1017/cbo9780511770425.012.pdf","author":"Merle, Jean-Christophe"}}
