deploy/third_engine/demo_mnn_kpts/keypoint_detector.h 0 → 100644
View file @ fccfdfa5
// Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
#pragma once
#include <ctime>
#include <memory>
#include <string>
#include <utility>
#include <vector>
#include <opencv2/core/core.hpp>
#include <opencv2/highgui/highgui.hpp>
#include <opencv2/imgproc/imgproc.hpp>
#include "Interpreter.hpp"
#include "ImageProcess.hpp"
#include "MNNDefine.h"
#include "Tensor.hpp"
#include "keypoint_postprocess.h"
using namespace MNN;
namespace PaddleDetection {
// Object KeyPoint Result
struct KeyPointResult {
// Keypoints: shape(N x 3); N: number of Joints; 3: x,y,conf
std::vector<float> keypoints;
int num_joints = -1;
};
// Visualiztion KeyPoint Result
cv::Mat VisualizeKptsResult(const cv::Mat& img,
const std::vector<KeyPointResult>& results,
const std::vector<int>& colormap,
float threshold = 0.2);
class KeyPointDetector {
public:
explicit KeyPointDetector(const std::string& model_path,
int num_thread = 4,
int input_height = 256,
int input_width = 192,
float score_threshold = 0.3,
const int batch_size = 1,
bool use_dark = true) {
printf("config path: %s",
model_path.substr(0, model_path.find_last_of('/') + 1).c_str());
use_dark_ = use_dark;
in_w = input_width;
in_h = input_height;
threshold_ = score_threshold;
KeyPointDet_interpreter = std::shared_ptr<MNN::Interpreter>(
MNN::Interpreter::createFromFile(model_path.c_str()));
MNN::ScheduleConfig config;
config.type = MNN_FORWARD_CPU;
/*modeNum means gpuMode for GPU usage, Or means numThread for CPU usage.*/
config.numThread = num_thread;
// If type not fount, let it failed
config.backupType = MNN_FORWARD_CPU;
BackendConfig backendConfig;
backendConfig.precision = static_cast<MNN::BackendConfig::PrecisionMode>(1);
config.backendConfig = &backendConfig;
KeyPointDet_session = KeyPointDet_interpreter->createSession(config);
input_tensor =
KeyPointDet_interpreter->getSessionInput(KeyPointDet_session, nullptr);
}
~KeyPointDetector() {
KeyPointDet_interpreter->releaseModel();
KeyPointDet_interpreter->releaseSession(KeyPointDet_session);
}
// Load Paddle inference model
void LoadModel(std::string model_file, int num_theads);
// Run predictor
void Predict(const std::vector<cv::Mat> imgs,
std::vector<std::vector<float>>& center,
std::vector<std::vector<float>>& scale,
std::vector<KeyPointResult>* result = nullptr);
bool use_dark() { return this->use_dark_; }
inline float get_threshold() { return threshold_; };
// const float mean_vals[3] = { 103.53f, 116.28f, 123.675f };
// const float norm_vals[3] = { 0.017429f, 0.017507f, 0.017125f };
const float mean_vals[3] = {0.f, 0.f, 0.f};
const float norm_vals[3] = {1.f, 1.f, 1.f};
int in_w = 128;
int in_h = 256;
private:
// Postprocess result
void Postprocess(std::vector<float>& output,
std::vector<int>& output_shape,
std::vector<int>& idxout,
std::vector<int>& idx_shape,
std::vector<KeyPointResult>* result,
std::vector<std::vector<float>>& center,
std::vector<std::vector<float>>& scale);
std::vector<float> output_data_;
std::vector<int> idx_data_;
float threshold_;
bool use_dark_;
std::shared_ptr<MNN::Interpreter> KeyPointDet_interpreter;
MNN::Session* KeyPointDet_session = nullptr;
MNN::Tensor* input_tensor = nullptr;
};
} // namespace PaddleDetection
deploy/third_engine/demo_mnn_kpts/keypoint_postprocess.cpp 0 → 100644
View file @ fccfdfa5
// Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
#include "keypoint_postprocess.h"
#define PI 3.1415926535
#define HALF_CIRCLE_DEGREE 180
cv::Point2f get_3rd_point(cv::Point2f& a, cv::Point2f& b) {
cv::Point2f direct{a.x - b.x, a.y - b.y};
return cv::Point2f(a.x - direct.y, a.y + direct.x);
}
std::vector<float> get_dir(float src_point_x,
float src_point_y,
float rot_rad) {
float sn = sin(rot_rad);
float cs = cos(rot_rad);
std::vector<float> src_result{0.0, 0.0};
src_result[0] = src_point_x * cs - src_point_y * sn;
src_result[1] = src_point_x * sn + src_point_y * cs;
return src_result;
}
void affine_tranform(
float pt_x, float pt_y, cv::Mat& trans, std::vector<float>& preds, int p) {
double new1[3] = {pt_x, pt_y, 1.0};
cv::Mat new_pt(3, 1, trans.type(), new1);
cv::Mat w = trans * new_pt;
preds[p * 3 + 1] = static_cast<float>(w.at<double>(0, 0));
preds[p * 3 + 2] = static_cast<float>(w.at<double>(1, 0));
}
void get_affine_transform(std::vector<float>& center,
std::vector<float>& scale,
float rot,
std::vector<int>& output_size,
cv::Mat& trans,
int inv) {
float src_w = scale[0];
float dst_w = static_cast<float>(output_size[0]);
float dst_h = static_cast<float>(output_size[1]);
float rot_rad = rot * PI / HALF_CIRCLE_DEGREE;
std::vector<float> src_dir = get_dir(-0.5 * src_w, 0, rot_rad);
std::vector<float> dst_dir{static_cast<float>(-0.5) * dst_w, 0.0};
cv::Point2f srcPoint2f[3], dstPoint2f[3];
srcPoint2f[0] = cv::Point2f(center[0], center[1]);
srcPoint2f[1] = cv::Point2f(center[0] + src_dir[0], center[1] + src_dir[1]);
srcPoint2f[2] = get_3rd_point(srcPoint2f[0], srcPoint2f[1]);
dstPoint2f[0] = cv::Point2f(dst_w * 0.5, dst_h * 0.5);
dstPoint2f[1] =
cv::Point2f(dst_w * 0.5 + dst_dir[0], dst_h * 0.5 + dst_dir[1]);
dstPoint2f[2] = get_3rd_point(dstPoint2f[0], dstPoint2f[1]);
if (inv == 0) {
trans = cv::getAffineTransform(srcPoint2f, dstPoint2f);
} else {
trans = cv::getAffineTransform(dstPoint2f, srcPoint2f);
}
}
void transform_preds(std::vector<float>& coords,
std::vector<float>& center,
std::vector<float>& scale,
std::vector<int>& output_size,
std::vector<int>& dim,
std::vector<float>& target_coords) {
cv::Mat trans(2, 3, CV_64FC1);
get_affine_transform(center, scale, 0, output_size, trans, 1);
for (int p = 0; p < dim[1]; ++p) {
affine_tranform(coords[p * 2], coords[p * 2 + 1], trans, target_coords, p);
}
}
// only for batchsize == 1
void get_max_preds(std::vector<float>& heatmap,
std::vector<int>& dim,
std::vector<float>& preds,
std::vector<float>& maxvals,
int batchid,
int joint_idx) {
int num_joints = dim[1];
int width = dim[3];
std::vector<int> idx;
idx.resize(num_joints * 2);
for (int j = 0; j < dim[1]; j++) {
float* index = &(
heatmap[batchid * num_joints * dim[2] * dim[3] + j * dim[2] * dim[3]]);
float* end = index + dim[2] * dim[3];
float* max_dis = std::max_element(index, end);
auto max_id = std::distance(index, max_dis);
maxvals[j] = *max_dis;
if (*max_dis > 0) {
preds[j * 2] = static_cast<float>(max_id % width);
preds[j * 2 + 1] = static_cast<float>(max_id / width);
}
}
}
void dark_parse(std::vector<float>& heatmap,
std::vector<int>& dim,
std::vector<float>& coords,
int px,
int py,
int index,
int ch) {
/*DARK postpocessing, Zhang et al. Distribution-Aware Coordinate
Representation for Human Pose Estimation (CVPR 2020).
1) offset = - hassian.inv() * derivative
2) dx = (heatmap[x+1] - heatmap[x-1])/2.
3) dxx = (dx[x+1] - dx[x-1])/2.
4) derivative = Mat([dx, dy])
5) hassian = Mat([[dxx, dxy], [dxy, dyy]])
*/
std::vector<float>::const_iterator first1 = heatmap.begin() + index;
std::vector<float>::const_iterator last1 =
heatmap.begin() + index + dim[2] * dim[3];
std::vector<float> heatmap_ch(first1, last1);
cv::Mat heatmap_mat = cv::Mat(heatmap_ch).reshape(0, dim[2]);
heatmap_mat.convertTo(heatmap_mat, CV_32FC1);
cv::GaussianBlur(heatmap_mat, heatmap_mat, cv::Size(3, 3), 0, 0);
heatmap_mat = heatmap_mat.reshape(1, 1);
heatmap_ch = std::vector<float>(heatmap_mat.reshape(1, 1));
float epsilon = 1e-10;
// sample heatmap to get values in around target location
float xy = log(fmax(heatmap_ch[py * dim[3] + px], epsilon));
float xr = log(fmax(heatmap_ch[py * dim[3] + px + 1], epsilon));
float xl = log(fmax(heatmap_ch[py * dim[3] + px - 1], epsilon));
float xr2 = log(fmax(heatmap_ch[py * dim[3] + px + 2], epsilon));
float xl2 = log(fmax(heatmap_ch[py * dim[3] + px - 2], epsilon));
float yu = log(fmax(heatmap_ch[(py + 1) * dim[3] + px], epsilon));
float yd = log(fmax(heatmap_ch[(py - 1) * dim[3] + px], epsilon));
float yu2 = log(fmax(heatmap_ch[(py + 2) * dim[3] + px], epsilon));
float yd2 = log(fmax(heatmap_ch[(py - 2) * dim[3] + px], epsilon));
float xryu = log(fmax(heatmap_ch[(py + 1) * dim[3] + px + 1], epsilon));
float xryd = log(fmax(heatmap_ch[(py - 1) * dim[3] + px + 1], epsilon));
float xlyu = log(fmax(heatmap_ch[(py + 1) * dim[3] + px - 1], epsilon));
float xlyd = log(fmax(heatmap_ch[(py - 1) * dim[3] + px - 1], epsilon));
// compute dx/dy and dxx/dyy with sampled values
float dx = 0.5 * (xr - xl);
float dy = 0.5 * (yu - yd);
float dxx = 0.25 * (xr2 - 2 * xy + xl2);
float dxy = 0.25 * (xryu - xryd - xlyu + xlyd);
float dyy = 0.25 * (yu2 - 2 * xy + yd2);
// finally get offset by derivative and hassian, which combined by dx/dy and
// dxx/dyy
if (dxx * dyy - dxy * dxy != 0) {
float M[2][2] = {dxx, dxy, dxy, dyy};
float D[2] = {dx, dy};
cv::Mat hassian(2, 2, CV_32F, M);
cv::Mat derivative(2, 1, CV_32F, D);
cv::Mat offset = -hassian.inv() * derivative;
coords[ch * 2] += offset.at<float>(0, 0);
coords[ch * 2 + 1] += offset.at<float>(1, 0);
}
}
void get_final_preds(std::vector<float>& heatmap,
std::vector<int>& dim,
std::vector<int>& idxout,
std::vector<int>& idxdim,
std::vector<float>& center,
std::vector<float> scale,
std::vector<float>& preds,
int batchid,
bool DARK) {
std::vector<float> coords;
coords.resize(dim[1] * 2);
int heatmap_height = dim[2];
int heatmap_width = dim[3];
for (int j = 0; j < dim[1]; ++j) {
int index = (batchid * dim[1] + j) * dim[2] * dim[3];
int idx = idxout[batchid * dim[1] + j];
preds[j * 3] = heatmap[index + idx];
coords[j * 2] = idx % heatmap_width;
coords[j * 2 + 1] = idx / heatmap_width;
int px = int(coords[j * 2] + 0.5);
int py = int(coords[j * 2 + 1] + 0.5);
if (DARK && px > 1 && px < heatmap_width - 2 && py > 1 &&
py < heatmap_height - 2) {
dark_parse(heatmap, dim, coords, px, py, index, j);
} else {
if (px > 0 && px < heatmap_width - 1) {
float diff_x = heatmap[index + py * dim[3] + px + 1] -
heatmap[index + py * dim[3] + px - 1];
coords[j * 2] += diff_x > 0 ? 1 : -1 * 0.25;
}
if (py > 0 && py < heatmap_height - 1) {
float diff_y = heatmap[index + (py + 1) * dim[3] + px] -
heatmap[index + (py - 1) * dim[3] + px];
coords[j * 2 + 1] += diff_y > 0 ? 1 : -1 * 0.25;
}
}
}
std::vector<int> img_size{heatmap_width, heatmap_height};
transform_preds(coords, center, scale, img_size, dim, preds);
}
void CropImg(cv::Mat& img,
cv::Mat& crop_img,
std::vector<int>& area,
std::vector<float>& center,
std::vector<float>& scale,
float expandratio) {
int crop_x1 = std::max(0, area[0]);
int crop_y1 = std::max(0, area[1]);
int crop_x2 = std::min(img.cols - 1, area[2]);
int crop_y2 = std::min(img.rows - 1, area[3]);
int center_x = (crop_x1 + crop_x2) / 2.;
int center_y = (crop_y1 + crop_y2) / 2.;
int half_h = (crop_y2 - crop_y1) / 2.;
int half_w = (crop_x2 - crop_x1) / 2.;
if (half_h * 3 > half_w * 4) {
half_w = static_cast<int>(half_h * 0.75);
} else {
half_h = static_cast<int>(half_w * 4 / 3);
}
crop_x1 =
std::max(0, center_x - static_cast<int>(half_w * (1 + expandratio)));
crop_y1 =
std::max(0, center_y - static_cast<int>(half_h * (1 + expandratio)));
crop_x2 = std::min(img.cols - 1,
static_cast<int>(center_x + half_w * (1 + expandratio)));
crop_y2 = std::min(img.rows - 1,
static_cast<int>(center_y + half_h * (1 + expandratio)));
crop_img =
img(cv::Range(crop_y1, crop_y2 + 1), cv::Range(crop_x1, crop_x2 + 1));
center.clear();
center.emplace_back((crop_x1 + crop_x2) / 2);
center.emplace_back((crop_y1 + crop_y2) / 2);
scale.clear();
scale.emplace_back((crop_x2 - crop_x1));
scale.emplace_back((crop_y2 - crop_y1));
}
deploy/third_engine/demo_mnn_kpts/keypoint_postprocess.h 0 → 100644
View file @ fccfdfa5
// Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
#pragma once
#include <opencv2/core/core.hpp>
#include <opencv2/highgui/highgui.hpp>
#include <opencv2/imgproc/imgproc.hpp>
#include <vector>
std::vector<float> get_3rd_point(std::vector<float>& a, std::vector<float>& b);
std::vector<float> get_dir(float src_point_x, float src_point_y, float rot_rad);
void affine_tranform(float pt_x,
float pt_y,
cv::Mat& trans,
std::vector<float>& x,
int p,
int num);
cv::Mat get_affine_transform(std::vector<float>& center,
std::vector<float>& scale,
float rot,
std::vector<int>& output_size,
int inv);
void transform_preds(std::vector<float>& coords,
std::vector<float>& center,
std::vector<float>& scale,
std::vector<int>& output_size,
std::vector<int>& dim,
std::vector<float>& target_coords);
void box_to_center_scale(std::vector<int>& box,
int width,
int height,
std::vector<float>& center,
std::vector<float>& scale);
void get_max_preds(std::vector<float>& heatmap,
std::vector<int>& dim,
std::vector<float>& preds,
std::vector<float>& maxvals,
int batchid,
int joint_idx);
void get_final_preds(std::vector<float>& heatmap,
std::vector<int>& dim,
std::vector<int>& idxout,
std::vector<int>& idxdim,
std::vector<float>& center,
std::vector<float> scale,
std::vector<float>& preds,
int batchid,
bool DARK = true);
void CropImg(cv::Mat& img,
cv::Mat& crop_img,
std::vector<int>& area,
std::vector<float>& center,
std::vector<float>& scale,
float expandratio = 0.25);
deploy/third_engine/demo_mnn_kpts/main.cpp 0 → 100644
View file @ fccfdfa5
// Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// reference from https://github.com/RangiLyu/nanodet/tree/main/demo_mnn
#include <iostream>
#include <opencv2/core/core.hpp>
#include <opencv2/highgui/highgui.hpp>
#include <opencv2/imgproc/imgproc.hpp>
#include "keypoint_detector.h"
#include "picodet_mnn.h"
#define __SAVE_RESULT__ // if defined save drawed results to ../results, else
// show it in windows
using namespace PaddleDetection;
struct object_rect {
int x;
int y;
int width;
int height;
};
int resize_uniform(cv::Mat& src,
cv::Mat& dst,
cv::Size dst_size,
object_rect& effect_area) {
int w = src.cols;
int h = src.rows;
int dst_w = dst_size.width;
int dst_h = dst_size.height;
dst = cv::Mat(cv::Size(dst_w, dst_h), CV_8UC3, cv::Scalar(0));
float ratio_src = w * 1.0 / h;
float ratio_dst = dst_w * 1.0 / dst_h;
int tmp_w = 0;
int tmp_h = 0;
if (ratio_src > ratio_dst) {
tmp_w = dst_w;
tmp_h = floor((dst_w * 1.0 / w) * h);
} else if (ratio_src < ratio_dst) {
tmp_h = dst_h;
tmp_w = floor((dst_h * 1.0 / h) * w);
} else {
cv::resize(src, dst, dst_size);
effect_area.x = 0;
effect_area.y = 0;
effect_area.width = dst_w;
effect_area.height = dst_h;
return 0;
}
cv::Mat tmp;
cv::resize(src, tmp, cv::Size(tmp_w, tmp_h));
if (tmp_w != dst_w) {
int index_w = floor((dst_w - tmp_w) / 2.0);
for (int i = 0; i < dst_h; i++) {
memcpy(dst.data + i * dst_w * 3 + index_w * 3,
tmp.data + i * tmp_w * 3,
tmp_w * 3);
}
effect_area.x = index_w;
effect_area.y = 0;
effect_area.width = tmp_w;
effect_area.height = tmp_h;
} else if (tmp_h != dst_h) {
int index_h = floor((dst_h - tmp_h) / 2.0);
memcpy(dst.data + index_h * dst_w * 3, tmp.data, tmp_w * tmp_h * 3);
effect_area.x = 0;
effect_area.y = index_h;
effect_area.width = tmp_w;
effect_area.height = tmp_h;
} else {
printf("error\n");
}
return 0;
}
const int color_list[80][3] = {
{216, 82, 24}, {236, 176, 31}, {125, 46, 141}, {118, 171, 47},
{76, 189, 237}, {238, 19, 46}, {76, 76, 76}, {153, 153, 153},
{255, 0, 0}, {255, 127, 0}, {190, 190, 0}, {0, 255, 0},
{0, 0, 255}, {170, 0, 255}, {84, 84, 0}, {84, 170, 0},
{84, 255, 0}, {170, 84, 0}, {170, 170, 0}, {170, 255, 0},
{255, 84, 0}, {255, 170, 0}, {255, 255, 0}, {0, 84, 127},
{0, 170, 127}, {0, 255, 127}, {84, 0, 127}, {84, 84, 127},
{84, 170, 127}, {84, 255, 127}, {170, 0, 127}, {170, 84, 127},
{170, 170, 127}, {170, 255, 127}, {255, 0, 127}, {255, 84, 127},
{255, 170, 127}, {255, 255, 127}, {0, 84, 255}, {0, 170, 255},
{0, 255, 255}, {84, 0, 255}, {84, 84, 255}, {84, 170, 255},
{84, 255, 255}, {170, 0, 255}, {170, 84, 255}, {170, 170, 255},
{170, 255, 255}, {255, 0, 255}, {255, 84, 255}, {255, 170, 255},
{42, 0, 0}, {84, 0, 0}, {127, 0, 0}, {170, 0, 0},
{212, 0, 0}, {255, 0, 0}, {0, 42, 0}, {0, 84, 0},
{0, 127, 0}, {0, 170, 0}, {0, 212, 0}, {0, 255, 0},
{0, 0, 42}, {0, 0, 84}, {0, 0, 127}, {0, 0, 170},
{0, 0, 212}, {0, 0, 255}, {0, 0, 0}, {36, 36, 36},
{72, 72, 72}, {109, 109, 109}, {145, 145, 145}, {182, 182, 182},
{218, 218, 218}, {0, 113, 188}, {80, 182, 188}, {127, 127, 0},
};
void draw_bboxes(const cv::Mat& bgr,
const std::vector<BoxInfo>& bboxes,
object_rect effect_roi,
std::string save_path = "None") {
static const char* class_names[] = {
"person", "bicycle", "car",
"motorcycle", "airplane", "bus",
"train", "truck", "boat",
"traffic light", "fire hydrant", "stop sign",
"parking meter", "bench", "bird",
"cat", "dog", "horse",
"sheep", "cow", "elephant",
"bear", "zebra", "giraffe",
"backpack", "umbrella", "handbag",
"tie", "suitcase", "frisbee",
"skis", "snowboard", "sports ball",
"kite", "baseball bat", "baseball glove",
"skateboard", "surfboard", "tennis racket",
"bottle", "wine glass", "cup",
"fork", "knife", "spoon",
"bowl", "banana", "apple",
"sandwich", "orange", "broccoli",
"carrot", "hot dog", "pizza",
"donut", "cake", "chair",
"couch", "potted plant", "bed",
"dining table", "toilet", "tv",
"laptop", "mouse", "remote",
"keyboard", "cell phone", "microwave",
"oven", "toaster", "sink",
"refrigerator", "book", "clock",
"vase", "scissors", "teddy bear",
"hair drier", "toothbrush"};
cv::Mat image = bgr.clone();
int src_w = image.cols;
int src_h = image.rows;
int dst_w = effect_roi.width;
int dst_h = effect_roi.height;
float width_ratio = (float)src_w / (float)dst_w;
float height_ratio = (float)src_h / (float)dst_h;
for (size_t i = 0; i < bboxes.size(); i++) {
const BoxInfo& bbox = bboxes[i];
cv::Scalar color = cv::Scalar(color_list[bbox.label][0],
color_list[bbox.label][1],
color_list[bbox.label][2]);
cv::rectangle(image,
cv::Rect(cv::Point((bbox.x1 - effect_roi.x) * width_ratio,
(bbox.y1 - effect_roi.y) * height_ratio),
cv::Point((bbox.x2 - effect_roi.x) * width_ratio,
(bbox.y2 - effect_roi.y) * height_ratio)),
color);
char text[256];
sprintf(text, "%s %.1f%%", class_names[bbox.label], bbox.score * 100);
int baseLine = 0;
cv::Size label_size =
cv::getTextSize(text, cv::FONT_HERSHEY_SIMPLEX, 0.4, 1, &baseLine);
int x = (bbox.x1 - effect_roi.x) * width_ratio;
int y =
(bbox.y1 - effect_roi.y) * height_ratio - label_size.height - baseLine;
if (y < 0) y = 0;
if (x + label_size.width > image.cols) x = image.cols - label_size.width;
cv::rectangle(
image,
cv::Rect(cv::Point(x, y),
cv::Size(label_size.width, label_size.height + baseLine)),
color,
-1);
cv::putText(image,
text,
cv::Point(x, y + label_size.height),
cv::FONT_HERSHEY_SIMPLEX,
0.4,
cv::Scalar(255, 255, 255));
}
if (save_path == "None") {
cv::imshow("image", image);
} else {
cv::imwrite(save_path, image);
std::cout << save_path << std::endl;
}
}
std::vector<BoxInfo> coordsback(const cv::Mat image,
const object_rect effect_roi,
const std::vector<BoxInfo>& bboxes) {
int src_w = image.cols;
int src_h = image.rows;
int dst_w = effect_roi.width;
int dst_h = effect_roi.height;
float width_ratio = (float)src_w / (float)dst_w;
float height_ratio = (float)src_h / (float)dst_h;
std::vector<BoxInfo> bboxes_oimg;
for (int i = 0; i < bboxes.size(); i++) {
auto bbox = bboxes[i];
bbox.x1 = (bbox.x1 - effect_roi.x) * width_ratio;
bbox.y1 = (bbox.y1 - effect_roi.y) * height_ratio;
bbox.x2 = (bbox.x2 - effect_roi.x) * width_ratio;
bbox.y2 = (bbox.y2 - effect_roi.y) * height_ratio;
bboxes_oimg.emplace_back(bbox);
}
return bboxes_oimg;
}
void image_infer_kpts(KeyPointDetector* kpts_detector,
cv::Mat image,
const object_rect effect_roi,
const std::vector<BoxInfo>& results,
std::string img_name = "kpts_vis",
bool save_img = true) {
std::vector<cv::Mat> cropimgs;
std::vector<std::vector<float>> center_bs;
std::vector<std::vector<float>> scale_bs;
std::vector<KeyPointResult> kpts_results;
auto results_oimg = coordsback(image, effect_roi, results);
for (int i = 0; i < results_oimg.size(); i++) {
auto rect = results_oimg[i];
if (rect.label == 0) {
cv::Mat cropimg;
std::vector<float> center, scale;
std::vector<int> area = {static_cast<int>(rect.x1),
static_cast<int>(rect.y1),
static_cast<int>(rect.x2),
static_cast<int>(rect.y2)};
CropImg(image, cropimg, area, center, scale);
// cv::imwrite("./test_crop_"+std::to_string(i)+".jpg", cropimg);
cropimgs.emplace_back(cropimg);
center_bs.emplace_back(center);
scale_bs.emplace_back(scale);
}
if (cropimgs.size() == 1 ||
(cropimgs.size() > 0 && i == results_oimg.size() - 1)) {
kpts_detector->Predict(cropimgs, center_bs, scale_bs, &kpts_results);
cropimgs.clear();
center_bs.clear();
scale_bs.clear();
}
}
std::vector<int> compression_params;
compression_params.push_back(cv::IMWRITE_JPEG_QUALITY);
compression_params.push_back(95);
std::string kpts_savepath =
"keypoint_" + img_name.substr(img_name.find_last_of('/') + 1);
cv::Mat kpts_vis_img =
VisualizeKptsResult(image, kpts_results, {0, 255, 0}, 0.3);
if (save_img) {
cv::imwrite(kpts_savepath, kpts_vis_img, compression_params);
printf("Visualized output saved as %s\n", kpts_savepath.c_str());
} else {
cv::imshow("image", kpts_vis_img);
}
}
int image_demo(PicoDet& detector,
KeyPointDetector* kpts_detector,
const char* imagepath) {
std::vector<cv::String> filenames;
cv::glob(imagepath, filenames, false);
for (auto img_name : filenames) {
cv::Mat image = cv::imread(img_name);
if (image.empty()) {
fprintf(stderr, "cv::imread %s failed\n", img_name.c_str());
return -1;
}
object_rect effect_roi;
cv::Mat resized_img;
resize_uniform(image, resized_img, cv::Size(320, 320), effect_roi);
std::vector<BoxInfo> results;
detector.detect(resized_img, results);
if (kpts_detector) {
image_infer_kpts(kpts_detector, image, effect_roi, results, img_name);
}
}
return 0;
}
int webcam_demo(PicoDet& detector,
KeyPointDetector* kpts_detector,
int cam_id) {
cv::Mat image;
cv::VideoCapture cap(cam_id);
while (true) {
cap >> image;
object_rect effect_roi;
cv::Mat resized_img;
resize_uniform(image, resized_img, cv::Size(320, 320), effect_roi);
std::vector<BoxInfo> results;
detector.detect(resized_img, results);
if (kpts_detector) {
image_infer_kpts(kpts_detector, image, effect_roi, results, "", false);
}
}
return 0;
}
int video_demo(PicoDet& detector,
KeyPointDetector* kpts_detector,
const char* path) {
cv::Mat image;
cv::VideoCapture cap(path);
while (true) {
cap >> image;
object_rect effect_roi;
cv::Mat resized_img;
resize_uniform(image, resized_img, cv::Size(320, 320), effect_roi);
std::vector<BoxInfo> results;
detector.detect(resized_img, results);
if (kpts_detector) {
image_infer_kpts(kpts_detector, image, effect_roi, results, "", false);
}
}
return 0;
}
int benchmark(KeyPointDetector* kpts_detector) {
int loop_num = 100;
int warm_up = 8;
double time_min = DBL_MAX;
double time_max = -DBL_MAX;
double time_avg = 0;
cv::Mat image(256, 192, CV_8UC3, cv::Scalar(1, 1, 1));
std::vector<float> center = {128, 96};
std::vector<float> scale = {256, 192};
std::vector<cv::Mat> cropimgs = {image};
std::vector<std::vector<float>> center_bs = {center};
std::vector<std::vector<float>> scale_bs = {scale};
std::vector<KeyPointResult> kpts_results;
for (int i = 0; i < warm_up + loop_num; i++) {
auto start = std::chrono::steady_clock::now();
std::vector<BoxInfo> results;
kpts_detector->Predict(cropimgs, center_bs, scale_bs, &kpts_results);
auto end = std::chrono::steady_clock::now();
std::chrono::duration<double> elapsed = end - start;
double time = elapsed.count();
if (i >= warm_up) {
time_min = (std::min)(time_min, time);
time_max = (std::max)(time_max, time);
time_avg += time;
}
}
time_avg /= loop_num;
fprintf(stderr,
"%20s min = %7.2f max = %7.2f avg = %7.2f\n",
"tinypose",
time_min,
time_max,
time_avg);
return 0;
}
int main(int argc, char** argv) {
if (argc != 3) {
fprintf(stderr,
"usage: %s [mode] [path]. \n For webcam mode=0, path is cam id; \n "
"For image demo, mode=1, path=xxx/xxx/*.jpg; \n For video, mode=2; "
"\n For benchmark, mode=3 path=0.\n",
argv[0]);
return -1;
}
PicoDet detector =
PicoDet("../weight/picodet_m_416.mnn", 416, 416, 4, 0.45, 0.3);
KeyPointDetector* kpts_detector =
new KeyPointDetector("../weight/tinypose256.mnn", 4, 256, 192);
int mode = atoi(argv[1]);
switch (mode) {
case 0: {
int cam_id = atoi(argv[2]);
webcam_demo(detector, kpts_detector, cam_id);
break;
}
case 1: {
const char* images = argv[2];
image_demo(detector, kpts_detector, images);
break;
}
case 2: {
const char* path = argv[2];
video_demo(detector, kpts_detector, path);
break;
}
case 3: {
benchmark(kpts_detector);
break;
}
default: {
fprintf(stderr,
"usage: %s [mode] [path]. \n For webcam mode=0, path is cam id; "
"\n For image demo, mode=1, path=xxx/xxx/*.jpg; \n For video, "
"mode=2; \n For benchmark, mode=3 path=0.\n",
argv[0]);
break;
}
}
delete kpts_detector;
kpts_detector = nullptr;
}
deploy/third_engine/demo_mnn_kpts/picodet_mnn.cpp 0 → 100644
View file @ fccfdfa5
// Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// reference from https://github.com/RangiLyu/nanodet/tree/main/demo_mnn
#include "picodet_mnn.h"
using namespace std;
PicoDet::PicoDet(const std::string &mnn_path,
int input_width,
int input_length,
int num_thread_,
float score_threshold_,
float nms_threshold_) {
num_thread = num_thread_;
in_w = input_width;
in_h = input_length;
score_threshold = score_threshold_;
nms_threshold = nms_threshold_;
PicoDet_interpreter = std::shared_ptr<MNN::Interpreter>(
MNN::Interpreter::createFromFile(mnn_path.c_str()));
MNN::ScheduleConfig config;
config.numThread = num_thread;
MNN::BackendConfig backendConfig;
backendConfig.precision = (MNN::BackendConfig::PrecisionMode)2;
config.backendConfig = &backendConfig;
PicoDet_session = PicoDet_interpreter->createSession(config);
input_tensor = PicoDet_interpreter->getSessionInput(PicoDet_session, nullptr);
}
PicoDet::~PicoDet() {
PicoDet_interpreter->releaseModel();
PicoDet_interpreter->releaseSession(PicoDet_session);
}
int PicoDet::detect(cv::Mat &raw_image, std::vector<BoxInfo> &result_list) {
if (raw_image.empty()) {
std::cout << "image is empty ,please check!" << std::endl;
return -1;
}
image_h = raw_image.rows;
image_w = raw_image.cols;
cv::Mat image;
cv::resize(raw_image, image, cv::Size(in_w, in_h));
PicoDet_interpreter->resizeTensor(input_tensor, {1, 3, in_h, in_w});
PicoDet_interpreter->resizeSession(PicoDet_session);
std::shared_ptr<MNN::CV::ImageProcess> pretreat(MNN::CV::ImageProcess::create(
MNN::CV::BGR, MNN::CV::BGR, mean_vals, 3, norm_vals, 3));
pretreat->convert(image.data, in_w, in_h, image.step[0], input_tensor);
auto start = chrono::steady_clock::now();
// run network
PicoDet_interpreter->runSession(PicoDet_session);
// get output data
std::vector<std::vector<BoxInfo>> results;
results.resize(num_class);
for (const auto &head_info : heads_info) {
MNN::Tensor *tensor_scores = PicoDet_interpreter->getSessionOutput(
PicoDet_session, head_info.cls_layer.c_str());
MNN::Tensor *tensor_boxes = PicoDet_interpreter->getSessionOutput(
PicoDet_session, head_info.dis_layer.c_str());
MNN::Tensor tensor_scores_host(tensor_scores,
tensor_scores->getDimensionType());
tensor_scores->copyToHostTensor(&tensor_scores_host);
MNN::Tensor tensor_boxes_host(tensor_boxes,
tensor_boxes->getDimensionType());
tensor_boxes->copyToHostTensor(&tensor_boxes_host);
decode_infer(&tensor_scores_host,
&tensor_boxes_host,
head_info.stride,
score_threshold,
results);
}
auto end = chrono::steady_clock::now();
chrono::duration<double> elapsed = end - start;
cout << "inference time:" << elapsed.count() << " s, ";
for (int i = 0; i < (int)results.size(); i++) {
nms(results[i], nms_threshold);
for (auto box : results[i]) {
box.x1 = box.x1 / in_w * image_w;
box.x2 = box.x2 / in_w * image_w;
box.y1 = box.y1 / in_h * image_h;
box.y2 = box.y2 / in_h * image_h;
result_list.push_back(box);
}
}
cout << "detect " << result_list.size() << " objects." << std::endl;
;
return 0;
}
void PicoDet::decode_infer(MNN::Tensor *cls_pred,
MNN::Tensor *dis_pred,
int stride,
float threshold,
std::vector<std::vector<BoxInfo>> &results) {
int feature_h = in_h / stride;
int feature_w = in_w / stride;
for (int idx = 0; idx < feature_h * feature_w; idx++) {
const float *scores = cls_pred->host<float>() + (idx * num_class);
int row = idx / feature_w;
int col = idx % feature_w;
float score = 0;
int cur_label = 0;
for (int label = 0; label < num_class; label++) {
if (scores[label] > score) {
score = scores[label];
cur_label = label;
}
}
if (score > threshold) {
const float *bbox_pred =
dis_pred->host<float>() + (idx * 4 * (reg_max + 1));
results[cur_label].push_back(
disPred2Bbox(bbox_pred, cur_label, score, col, row, stride));
}
}
}
BoxInfo PicoDet::disPred2Bbox(
const float *&dfl_det, int label, float score, int x, int y, int stride) {
float ct_x = (x + 0.5) * stride;
float ct_y = (y + 0.5) * stride;
std::vector<float> dis_pred;
dis_pred.resize(4);
for (int i = 0; i < 4; i++) {
float dis = 0;
float *dis_after_sm = new float[reg_max + 1];
activation_function_softmax(
dfl_det + i * (reg_max + 1), dis_after_sm, reg_max + 1);
for (int j = 0; j < reg_max + 1; j++) {
dis += j * dis_after_sm[j];
}
dis *= stride;
dis_pred[i] = dis;
delete[] dis_after_sm;
}
float xmin = (std::max)(ct_x - dis_pred[0], .0f);
float ymin = (std::max)(ct_y - dis_pred[1], .0f);
float xmax = (std::min)(ct_x + dis_pred[2], (float)in_w);
float ymax = (std::min)(ct_y + dis_pred[3], (float)in_h);
return BoxInfo{xmin, ymin, xmax, ymax, score, label};
}
void PicoDet::nms(std::vector<BoxInfo> &input_boxes, float NMS_THRESH) {
std::sort(input_boxes.begin(), input_boxes.end(), [](BoxInfo a, BoxInfo b) {
return a.score > b.score;
});
std::vector<float> vArea(input_boxes.size());
for (int i = 0; i < int(input_boxes.size()); ++i) {
vArea[i] = (input_boxes.at(i).x2 - input_boxes.at(i).x1 + 1) *
(input_boxes.at(i).y2 - input_boxes.at(i).y1 + 1);
}
for (int i = 0; i < int(input_boxes.size()); ++i) {
for (int j = i + 1; j < int(input_boxes.size());) {
float xx1 = (std::max)(input_boxes[i].x1, input_boxes[j].x1);
float yy1 = (std::max)(input_boxes[i].y1, input_boxes[j].y1);
float xx2 = (std::min)(input_boxes[i].x2, input_boxes[j].x2);
float yy2 = (std::min)(input_boxes[i].y2, input_boxes[j].y2);
float w = (std::max)(float(0), xx2 - xx1 + 1);
float h = (std::max)(float(0), yy2 - yy1 + 1);
float inter = w * h;
float ovr = inter / (vArea[i] + vArea[j] - inter);
if (ovr >= NMS_THRESH) {
input_boxes.erase(input_boxes.begin() + j);
vArea.erase(vArea.begin() + j);
} else {
j++;
}
}
}
}
string PicoDet::get_label_str(int label) { return labels[label]; }
inline float fast_exp(float x) {
union {
uint32_t i;
float f;
} v{};
v.i = (1 << 23) * (1.4426950409 * x + 126.93490512f);
return v.f;
}
inline float sigmoid(float x) { return 1.0f / (1.0f + fast_exp(-x)); }
template <typename _Tp>
int activation_function_softmax(const _Tp *src, _Tp *dst, int length) {
const _Tp alpha = *std::max_element(src, src + length);
_Tp denominator{0};
for (int i = 0; i < length; ++i) {
dst[i] = fast_exp(src[i] - alpha);
denominator += dst[i];
}
for (int i = 0; i < length; ++i) {
dst[i] /= denominator;
}
return 0;
}
deploy/third_engine/demo_mnn_kpts/picodet_mnn.h 0 → 100644
View file @ fccfdfa5
// Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// reference from https://github.com/RangiLyu/nanodet/tree/main/demo_mnn
#ifndef __PicoDet_H__
#define __PicoDet_H__
#pragma once
#include "Interpreter.hpp"
#include <algorithm>
#include <chrono>
#include <iostream>
#include <memory>
#include <opencv2/opencv.hpp>
#include <string>
#include <vector>
#include "ImageProcess.hpp"
#include "MNNDefine.h"
#include "Tensor.hpp"
typedef struct HeadInfo_ {
std::string cls_layer;
std::string dis_layer;
int stride;
} HeadInfo;
typedef struct BoxInfo_ {
float x1;
float y1;
float x2;
float y2;
float score;
int label;
} BoxInfo;
class PicoDet {
public:
PicoDet(const std::string &mnn_path,
int input_width,
int input_length,
int num_thread_ = 4,
float score_threshold_ = 0.5,
float nms_threshold_ = 0.3);
~PicoDet();
int detect(cv::Mat &img, std::vector<BoxInfo> &result_list);
std::string get_label_str(int label);
private:
void decode_infer(MNN::Tensor *cls_pred,
MNN::Tensor *dis_pred,
int stride,
float threshold,
std::vector<std::vector<BoxInfo>> &results);
BoxInfo disPred2Bbox(
const float *&dfl_det, int label, float score, int x, int y, int stride);
void nms(std::vector<BoxInfo> &input_boxes, float NMS_THRESH);
private:
std::shared_ptr<MNN::Interpreter> PicoDet_interpreter;
MNN::Session *PicoDet_session = nullptr;
MNN::Tensor *input_tensor = nullptr;
int num_thread;
int image_w;
int image_h;
int in_w = 320;
int in_h = 320;
float score_threshold;
float nms_threshold;
const float mean_vals[3] = {103.53f, 116.28f, 123.675f};
const float norm_vals[3] = {0.017429f, 0.017507f, 0.017125f};
const int num_class = 80;
const int reg_max = 7;
std::vector<HeadInfo> heads_info{
// cls_pred|dis_pred|stride
{"save_infer_model/scale_0.tmp_1", "save_infer_model/scale_4.tmp_1", 8},
{"save_infer_model/scale_1.tmp_1", "save_infer_model/scale_5.tmp_1", 16},
{"save_infer_model/scale_2.tmp_1", "save_infer_model/scale_6.tmp_1", 32},
{"save_infer_model/scale_3.tmp_1", "save_infer_model/scale_7.tmp_1", 64},
};
std::vector<std::string> labels{
"person", "bicycle", "car",
"motorcycle", "airplane", "bus",
"train", "truck", "boat",
"traffic light", "fire hydrant", "stop sign",
"parking meter", "bench", "bird",
"cat", "dog", "horse",
"sheep", "cow", "elephant",
"bear", "zebra", "giraffe",
"backpack", "umbrella", "handbag",
"tie", "suitcase", "frisbee",
"skis", "snowboard", "sports ball",
"kite", "baseball bat", "baseball glove",
"skateboard", "surfboard", "tennis racket",
"bottle", "wine glass", "cup",
"fork", "knife", "spoon",
"bowl", "banana", "apple",
"sandwich", "orange", "broccoli",
"carrot", "hot dog", "pizza",
"donut", "cake", "chair",
"couch", "potted plant", "bed",
"dining table", "toilet", "tv",
"laptop", "mouse", "remote",
"keyboard", "cell phone", "microwave",
"oven", "toaster", "sink",
"refrigerator", "book", "clock",
"vase", "scissors", "teddy bear",
"hair drier", "toothbrush"};
};
template <typename _Tp>
int activation_function_softmax(const _Tp *src, _Tp *dst, int length);
inline float fast_exp(float x);
inline float sigmoid(float x);
#endif
deploy/third_engine/demo_ncnn/CMakeLists.txt 0 → 100644
View file @ fccfdfa5
cmake_minimum_required(VERSION 3.9)
set(CMAKE_CXX_STANDARD 17)
project(picodet_demo)
find_package(OpenMP REQUIRED)
if(OPENMP_FOUND)
message("OPENMP FOUND")
set(CMAKE_C_FLAGS "${CMAKE_C_FLAGS} ${OpenMP_C_FLAGS}")
set(CMAKE_CXX_FLAGS "${CMAKE_CXX_FLAGS} ${OpenMP_CXX_FLAGS}")
set(CMAKE_EXE_LINKER_FLAGS "${CMAKE_EXE_LINKER_FLAGS} ${OpenMP_EXE_LINKER_FLAGS}")
endif()
# find_package(OpenCV REQUIRED)
find_package(OpenCV REQUIRED PATHS "/path/to/opencv-3.4.16_gcc8.2_ffmpeg")
# find_package(ncnn REQUIRED)
find_package(ncnn REQUIRED PATHS "/path/to/ncnn/build/install/lib/cmake/ncnn")
if(NOT TARGET ncnn)
message(WARNING "ncnn NOT FOUND! Please set ncnn_DIR environment variable")
else()
message("ncnn FOUND ")
endif()
include_directories(
${OpenCV_INCLUDE_DIRS}
${CMAKE_CURRENT_SOURCE_DIR}
${CMAKE_CURRENT_BINARY_DIR}
)
add_executable(picodet_demo main.cpp picodet.cpp)
target_link_libraries(
picodet_demo
ncnn
${OpenCV_LIBS}
)
deploy/third_engine/demo_ncnn/README.md 0 → 100644
View file @ fccfdfa5
# PicoDet NCNN Demo
该Demo提供的预测代码是根据[Tencent's NCNN framework](https://github.com/Tencent/ncnn)推理库预测的。
# 第一步：编译
## Windows
### Step1.
Download and Install Visual Studio from https://visualstudio.microsoft.com/vs/community/
### Step2.
Download and install OpenCV from https://github.com/opencv/opencv/releases
为了方便，如果环境是gcc8.2 x86环境，可直接下载以下库：
```shell
wget https://paddledet.bj.bcebos.com/data/opencv-3.4.16_gcc8.2_ffmpeg.tar.gz
tar -xf opencv-3.4.16_gcc8.2_ffmpeg.tar.gz
```
### Step3(可选).
Download and install Vulkan SDK from https://vulkan.lunarg.com/sdk/home
### Step4：编译NCNN
``` shell script
git clone --recursive https://github.com/Tencent/ncnn.git
```
Build NCNN following this tutorial: [Build for Windows x64 using VS2017](https://github.com/Tencent/ncnn/wiki/how-to-build#build-for-windows-x64-using-visual-studio-community-2017)
### Step5.
增加 `ncnn_DIR` = `YOUR_NCNN_PATH/build/install/lib/cmake/ncnn` 到系统变量中
Build project: Open x64 Native Tools Command Prompt for VS 2019 or 2017
``` cmd
cd <this-folder>
mkdir -p build
cd build
cmake ..
msbuild picodet_demo.vcxproj /p:configuration=release /p:platform=x64
```
## Linux
### Step1.
Build and install OpenCV from https://github.com/opencv/opencv
### Step2(可选).
Download Vulkan SDK from https://vulkan.lunarg.com/sdk/home
### Step3：编译NCNN
Clone NCNN repository
``` shell script
git clone --recursive https://github.com/Tencent/ncnn.git
```
Build NCNN following this tutorial: [Build for Linux / NVIDIA Jetson / Raspberry Pi](https://github.com/Tencent/ncnn/wiki/how-to-build#build-for-linux)
### Step4：编译可执行文件
``` shell script
cd <this-folder>
mkdir build
cd build
cmake ..
make
```
# Run demo
- 准备模型
```shell
modelName=picodet_s_320_coco_lcnet
# 导出Inference model
python tools/export_model.py \
-c configs/picodet/${modelName}.yml \
-o weights=${modelName}.pdparams \
--output_dir=inference_model
# 转换到ONNX
paddle2onnx --model_dir inference_model/${modelName} \
--model_filename model.pdmodel \
--params_filename model.pdiparams \
--opset_version 11 \
--save_file ${modelName}.onnx
# 简化模型
python -m onnxsim ${modelName}.onnx ${modelName}_processed.onnx
# 将模型转换至NCNN格式
Run onnx2ncnn in ncnn tools to generate ncnn .param and .bin file.
```
转NCNN模型可以利用在线转换工具 [https://convertmodel.com](https://convertmodel.com/)
为了快速测试，可直接下载：[picodet_s_320_coco_lcnet-opt.bin](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_s_320_coco_lcnet-opt.bin)/ [picodet_s_320_coco_lcnet-opt.param](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_s_320_coco_lcnet-opt.param)（不带后处理）。
**注意：**由于带后处理后，NCNN预测会出NAN，暂时使用不带后处理Demo即可，带后处理的Demo正在升级中，很快发布。
## 开始运行
首先新建预测结果存放目录：
```shell
cp -r ../demo_onnxruntime/imgs .
cd build
mkdir ../results
```
- 预测一张图片
``` shell
./picodet_demo 0 ../picodet_s_320_coco_lcnet.bin ../picodet_s_320_coco_lcnet.param 320 320 ../imgs/dog.jpg 0
```
具体参数解析可参考`main.cpp`。
-测试速度Benchmark
``` shell
./picodet_demo 1 ../picodet_s_320_lcnet.bin ../picodet_s_320_lcnet.param 320 320 0
```
## FAQ
- 预测结果精度不对：
请先确认模型输入shape是否对齐，并且模型输出name是否对齐，不带后处理的PicoDet增强版模型输出name如下：
```shell
# 分类分支 | 检测分支
{"transpose_0.tmp_0", "transpose_1.tmp_0"},
{"transpose_2.tmp_0", "transpose_3.tmp_0"},
{"transpose_4.tmp_0", "transpose_5.tmp_0"},
{"transpose_6.tmp_0", "transpose_7.tmp_0"},
```
可使用[netron](https://netron.app)查看具体name，并修改`picodet_mnn.hpp`中相应`non_postprocess_heads_info`数组。
deploy/third_engine/demo_ncnn/main.cpp 0 → 100644
View file @ fccfdfa5
// Copyright (c) 2021 PaddlePaddle Authors. All Rights Reserved.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// reference from https://github.com/RangiLyu/nanodet/tree/main/demo_ncnn
#include "picodet.h"
#include <benchmark.h>
#include <iostream>
#include <net.h>
#include <opencv2/core/core.hpp>
#include <opencv2/highgui/highgui.hpp>
#include <opencv2/imgproc/imgproc.hpp>
#define __SAVE_RESULT__ // if defined save drawed results to ../results, else
// show it in windows
struct object_rect {
int x;
int y;
int width;
int height;
};
std::vector<int> GenerateColorMap(int num_class) {
auto colormap = std::vector<int>(3 * num_class, 0);
for (int i = 0; i < num_class; ++i) {
int j = 0;
int lab = i;
while (lab) {
colormap[i * 3] |= (((lab >> 0) & 1) << (7 - j));
colormap[i * 3 + 1] |= (((lab >> 1) & 1) << (7 - j));
colormap[i * 3 + 2] |= (((lab >> 2) & 1) << (7 - j));
++j;
lab >>= 3;
}
}
return colormap;
}
void draw_bboxes(const cv::Mat &im, const std::vector<BoxInfo> &bboxes,
std::string save_path = "None") {
static const char *class_names[] = {
"person", "bicycle", "car",
"motorcycle", "airplane", "bus",
"train", "truck", "boat",
"traffic light", "fire hydrant", "stop sign",
"parking meter", "bench", "bird",
"cat", "dog", "horse",
"sheep", "cow", "elephant",
"bear", "zebra", "giraffe",
"backpack", "umbrella", "handbag",
"tie", "suitcase", "frisbee",
"skis", "snowboard", "sports ball",
"kite", "baseball bat", "baseball glove",
"skateboard", "surfboard", "tennis racket",
"bottle", "wine glass", "cup",
"fork", "knife", "spoon",
"bowl", "banana", "apple",
"sandwich", "orange", "broccoli",
"carrot", "hot dog", "pizza",
"donut", "cake", "chair",
"couch", "potted plant", "bed",
"dining table", "toilet", "tv",
"laptop", "mouse", "remote",
"keyboard", "cell phone", "microwave",
"oven", "toaster", "sink",
"refrigerator", "book", "clock",
"vase", "scissors", "teddy bear",
"hair drier", "toothbrush"};
cv::Mat image = im.clone();
int src_w = image.cols;
int src_h = image.rows;
int thickness = 2;
auto colormap = GenerateColorMap(sizeof(class_names));
for (size_t i = 0; i < bboxes.size(); i++) {
const BoxInfo &bbox = bboxes[i];
std::cout << bbox.x1 << ". " << bbox.y1 << ". " << bbox.x2 << ". "
<< bbox.y2 << ". " << std::endl;
int c1 = colormap[3 * bbox.label + 0];
int c2 = colormap[3 * bbox.label + 1];
int c3 = colormap[3 * bbox.label + 2];
cv::Scalar color = cv::Scalar(c1, c2, c3);
// cv::Scalar color = cv::Scalar(0, 0, 255);
cv::rectangle(image, cv::Rect(cv::Point(bbox.x1, bbox.y1),
cv::Point(bbox.x2, bbox.y2)),
color, 1);
char text[256];
sprintf(text, "%s %.1f%%", class_names[bbox.label], bbox.score * 100);
int baseLine = 0;
cv::Size label_size =
cv::getTextSize(text, cv::FONT_HERSHEY_SIMPLEX, 0.4, 1, &baseLine);
int x = bbox.x1;
int y = bbox.y1 - label_size.height - baseLine;
if (y < 0)
y = 0;
if (x + label_size.width > image.cols)
x = image.cols - label_size.width;
cv::rectangle(image, cv::Rect(cv::Point(x, y),
cv::Size(label_size.width,
label_size.height + baseLine)),
color, -1);
cv::putText(image, text, cv::Point(x, y + label_size.height),
cv::FONT_HERSHEY_SIMPLEX, 0.4, cv::Scalar(255, 255, 255), 1);
}
if (save_path == "None") {
cv::imshow("image", image);
} else {
cv::imwrite(save_path, image);
std::cout << "Result save in: " << save_path << std::endl;
}
}
int image_demo(PicoDet &detector, const char *imagepath,
int has_postprocess = 0) {
std::vector<cv::String> filenames;
cv::glob(imagepath, filenames, false);
bool is_postprocess = has_postprocess > 0 ? true : false;
for (auto img_name : filenames) {
cv::Mat image = cv::imread(img_name, cv::IMREAD_COLOR);
if (image.empty()) {
fprintf(stderr, "cv::imread %s failed\n", img_name.c_str());
return -1;
}
std::vector<BoxInfo> results;
detector.detect(image, results, is_postprocess);
std::cout << "detect done." << std::endl;
#ifdef __SAVE_RESULT__
std::string save_path = img_name;
draw_bboxes(image, results, save_path.replace(3, 4, "results"));
#else
draw_bboxes(image, results);
cv::waitKey(0);
#endif
}
return 0;
}
int benchmark(PicoDet &detector, int width, int height,
int has_postprocess = 0) {
int loop_num = 100;
int warm_up = 8;
double time_min = DBL_MAX;
double time_max = -DBL_MAX;
double time_avg = 0;
cv::Mat image(width, height, CV_8UC3, cv::Scalar(1, 1, 1));
bool is_postprocess = has_postprocess > 0 ? true : false;
for (int i = 0; i < warm_up + loop_num; i++) {
double start = ncnn::get_current_time();
std::vector<BoxInfo> results;
detector.detect(image, results, is_postprocess);
double end = ncnn::get_current_time();
double time = end - start;
if (i >= warm_up) {
time_min = (std::min)(time_min, time);
time_max = (std::max)(time_max, time);
time_avg += time;
}
}
time_avg /= loop_num;
fprintf(stderr, "%20s min = %7.2f max = %7.2f avg = %7.2f\n", "picodet",
time_min, time_max, time_avg);
return 0;
}
int main(int argc, char **argv) {
int mode = atoi(argv[1]);
char *bin_model_path = argv[2];
char *param_model_path = argv[3];
int height = 320;
int width = 320;
if (argc == 5) {
height = atoi(argv[4]);
width = atoi(argv[5]);
}
PicoDet detector =
PicoDet(param_model_path, bin_model_path, width, height, true, 0.45, 0.3);
if (mode == 1) {
benchmark(detector, width, height, atoi(argv[6]));
} else {
if (argc != 6) {
std::cout << "Must set image file, such as ./picodet_demo 0 "
"../picodet_s_320_lcnet.bin ../picodet_s_320_lcnet.param "
"320 320 img.jpg"
<< std::endl;
}
const char *images = argv[6];
image_demo(detector, images, atoi(argv[7]));
}
}
deploy/third_engine/demo_ncnn/picodet.cpp 0 → 100644
View file @ fccfdfa5
// Copyright (c) 2021 PaddlePaddle Authors. All Rights Reserved.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// reference from https://github.com/RangiLyu/nanodet/tree/main/demo_ncnn
#include "picodet.h"
#include <benchmark.h>
#include <iostream>
inline float fast_exp(float x) {
union {
uint32_t i;
float f;
} v{};
v.i = (1 << 23) * (1.4426950409 * x + 126.93490512f);
return v.f;
}
inline float sigmoid(float x) { return 1.0f / (1.0f + fast_exp(-x)); }
template <typename _Tp>
int activation_function_softmax(const _Tp *src, _Tp *dst, int length) {
const _Tp alpha = *std::max_element(src, src + length);
_Tp denominator{0};
for (int i = 0; i < length; ++i) {
dst[i] = fast_exp(src[i] - alpha);
denominator += dst[i];
}
for (int i = 0; i < length; ++i) {
dst[i] /= denominator;
}
return 0;
}
bool PicoDet::hasGPU = false;
PicoDet *PicoDet::detector = nullptr;
PicoDet::PicoDet(const char *param, const char *bin, int input_width,
int input_hight, bool useGPU, float score_threshold_ = 0.5,
float nms_threshold_ = 0.3) {
this->Net = new ncnn::Net();
#if NCNN_VULKAN
this->hasGPU = ncnn::get_gpu_count() > 0;
#endif
this->Net->opt.use_vulkan_compute = this->hasGPU && useGPU;
this->Net->opt.use_fp16_arithmetic = true;
this->Net->load_param(param);
this->Net->load_model(bin);
this->in_w = input_width;
this->in_h = input_hight;
this->score_threshold = score_threshold_;
this->nms_threshold = nms_threshold_;
}
PicoDet::~PicoDet() { delete this->Net; }
void PicoDet::preprocess(cv::Mat &image, ncnn::Mat &in) {
// cv::resize(image, image, cv::Size(this->in_w, this->in_h), 0.f, 0.f);
int img_w = image.cols;
int img_h = image.rows;
in = ncnn::Mat::from_pixels_resize(image.data, ncnn::Mat::PIXEL_BGR, img_w,
img_h, this->in_w, this->in_h);
const float mean_vals[3] = {103.53f, 116.28f, 123.675f};
const float norm_vals[3] = {0.017429f, 0.017507f, 0.017125f};
in.substract_mean_normalize(mean_vals, norm_vals);
}
int PicoDet::detect(cv::Mat image, std::vector<BoxInfo> &result_list,
bool has_postprocess) {
ncnn::Mat input;
preprocess(image, input);
auto ex = this->Net->create_extractor();
ex.set_light_mode(false);
ex.set_num_threads(4);
#if NCNN_VULKAN
ex.set_vulkan_compute(this->hasGPU);
#endif
ex.input("image", input); // picodet
this->image_h = image.rows;
this->image_w = image.cols;
std::vector<std::vector<BoxInfo>> results;
results.resize(this->num_class);
if (has_postprocess) {
ncnn::Mat dis_pred;
ncnn::Mat cls_pred;
ex.extract(this->nms_heads_info[0].c_str(), dis_pred);
ex.extract(this->nms_heads_info[1].c_str(), cls_pred);
std::cout << dis_pred.h << " " << dis_pred.w << std::endl;
std::cout << cls_pred.h << " " << cls_pred.w << std::endl;
this->nms_boxes(cls_pred, dis_pred, this->score_threshold, results);
} else {
for (const auto &head_info : this->non_postprocess_heads_info) {
ncnn::Mat dis_pred;
ncnn::Mat cls_pred;
ex.extract(head_info.dis_layer.c_str(), dis_pred);
ex.extract(head_info.cls_layer.c_str(), cls_pred);
this->decode_infer(cls_pred, dis_pred, head_info.stride,
this->score_threshold, results);
}
}
for (int i = 0; i < (int)results.size(); i++) {
this->nms(results[i], this->nms_threshold);
for (auto box : results[i]) {
box.x1 = box.x1 / this->in_w * this->image_w;
box.x2 = box.x2 / this->in_w * this->image_w;
box.y1 = box.y1 / this->in_h * this->image_h;
box.y2 = box.y2 / this->in_h * this->image_h;
result_list.push_back(box);
}
}
return 0;
}
void PicoDet::nms_boxes(ncnn::Mat &cls_pred, ncnn::Mat &dis_pred,
float score_threshold,
std::vector<std::vector<BoxInfo>> &result_list) {
BoxInfo bbox;
int i, j;
for (i = 0; i < dis_pred.h; i++) {
bbox.x1 = dis_pred.row(i)[0];
bbox.y1 = dis_pred.row(i)[1];
bbox.x2 = dis_pred.row(i)[2];
bbox.y2 = dis_pred.row(i)[3];
const float *scores = cls_pred.row(i);
float score = 0;
int cur_label = 0;
for (int label = 0; label < this->num_class; label++) {
float score_ = cls_pred.row(label)[i];
if (score_ > score) {
score = score_;
cur_label = label;
}
}
bbox.score = score;
bbox.label = cur_label;
result_list[cur_label].push_back(bbox);
}
}
void PicoDet::decode_infer(ncnn::Mat &cls_pred, ncnn::Mat &dis_pred, int stride,
float threshold,
std::vector<std::vector<BoxInfo>> &results) {
int feature_h = ceil((float)this->in_w / stride);
int feature_w = ceil((float)this->in_h / stride);
for (int idx = 0; idx < feature_h * feature_w; idx++) {
const float *scores = cls_pred.row(idx);
int row = idx / feature_w;
int col = idx % feature_w;
float score = 0;
int cur_label = 0;
for (int label = 0; label < this->num_class; label++) {
if (scores[label] > score) {
score = scores[label];
cur_label = label;
}
}
if (score > threshold) {
const float *bbox_pred = dis_pred.row(idx);
results[cur_label].push_back(
this->disPred2Bbox(bbox_pred, cur_label, score, col, row, stride));
}
}
}
BoxInfo PicoDet::disPred2Bbox(const float *&dfl_det, int label, float score,
int x, int y, int stride) {
float ct_x = (x + 0.5) * stride;
float ct_y = (y + 0.5) * stride;
std::vector<float> dis_pred;
dis_pred.resize(4);
for (int i = 0; i < 4; i++) {
float dis = 0;
float *dis_after_sm = new float[this->reg_max + 1];
activation_function_softmax(dfl_det + i * (this->reg_max + 1), dis_after_sm,
this->reg_max + 1);
for (int j = 0; j < this->reg_max + 1; j++) {
dis += j * dis_after_sm[j];
}
dis *= stride;
dis_pred[i] = dis;
delete[] dis_after_sm;
}
float xmin = (std::max)(ct_x - dis_pred[0], .0f);
float ymin = (std::max)(ct_y - dis_pred[1], .0f);
float xmax = (std::min)(ct_x + dis_pred[2], (float)this->in_w);
float ymax = (std::min)(ct_y + dis_pred[3], (float)this->in_w);
return BoxInfo{xmin, ymin, xmax, ymax, score, label};
}
void PicoDet::nms(std::vector<BoxInfo> &input_boxes, float NMS_THRESH) {
std::sort(input_boxes.begin(), input_boxes.end(),
[](BoxInfo a, BoxInfo b) { return a.score > b.score; });
std::vector<float> vArea(input_boxes.size());
for (int i = 0; i < int(input_boxes.size()); ++i) {
vArea[i] = (input_boxes.at(i).x2 - input_boxes.at(i).x1 + 1) *
(input_boxes.at(i).y2 - input_boxes.at(i).y1 + 1);
}
for (int i = 0; i < int(input_boxes.size()); ++i) {
for (int j = i + 1; j < int(input_boxes.size());) {
float xx1 = (std::max)(input_boxes[i].x1, input_boxes[j].x1);
float yy1 = (std::max)(input_boxes[i].y1, input_boxes[j].y1);
float xx2 = (std::min)(input_boxes[i].x2, input_boxes[j].x2);
float yy2 = (std::min)(input_boxes[i].y2, input_boxes[j].y2);
float w = (std::max)(float(0), xx2 - xx1 + 1);
float h = (std::max)(float(0), yy2 - yy1 + 1);
float inter = w * h;
float ovr = inter / (vArea[i] + vArea[j] - inter);
if (ovr >= NMS_THRESH) {
input_boxes.erase(input_boxes.begin() + j);
vArea.erase(vArea.begin() + j);
} else {
j++;
}
}
}
}
deploy/third_engine/demo_ncnn/picodet.h 0 → 100644
View file @ fccfdfa5
// Copyright (c) 2021 PaddlePaddle Authors. All Rights Reserved.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// reference from https://github.com/RangiLyu/nanodet/tree/main/demo_ncnn
#ifndef PICODET_H
#define PICODET_H
#include <net.h>
#include <opencv2/core/core.hpp>
typedef struct NonPostProcessHeadInfo {
std::string cls_layer;
std::string dis_layer;
int stride;
} NonPostProcessHeadInfo;
typedef struct BoxInfo {
float x1;
float y1;
float x2;
float y2;
float score;
int label;
} BoxInfo;
class PicoDet {
public:
PicoDet(const char *param, const char *bin, int input_width, int input_hight,
bool useGPU, float score_threshold_, float nms_threshold_);
~PicoDet();
static PicoDet *detector;
ncnn::Net *Net;
static bool hasGPU;
int detect(cv::Mat image, std::vector<BoxInfo> &result_list,
bool has_postprocess);
private:
void preprocess(cv::Mat &image, ncnn::Mat &in);
void decode_infer(ncnn::Mat &cls_pred, ncnn::Mat &dis_pred, int stride,
float threshold,
std::vector<std::vector<BoxInfo>> &results);
BoxInfo disPred2Bbox(const float *&dfl_det, int label, float score, int x,
int y, int stride);
static void nms(std::vector<BoxInfo> &result, float nms_threshold);
void nms_boxes(ncnn::Mat &cls_pred, ncnn::Mat &dis_pred,
float score_threshold,
std::vector<std::vector<BoxInfo>> &result_list);
int image_w;
int image_h;
int in_w = 320;
int in_h = 320;
int num_class = 80;
int reg_max = 7;
float score_threshold;
float nms_threshold;
std::vector<float> bbox_output_data_;
std::vector<float> class_output_data_;
std::vector<std::string> nms_heads_info{"tmp_16", "concat_4.tmp_0"};
// If not export post-process, will use non_postprocess_heads_info
std::vector<NonPostProcessHeadInfo> non_postprocess_heads_info{
// cls_pred|dis_pred|stride
{"transpose_0.tmp_0", "transpose_1.tmp_0", 8},
{"transpose_2.tmp_0", "transpose_3.tmp_0", 16},
{"transpose_4.tmp_0", "transpose_5.tmp_0", 32},
{"transpose_6.tmp_0", "transpose_7.tmp_0", 64},
};
};
#endif
deploy/third_engine/demo_onnx_trt/README.md 0 → 100644
View file @ fccfdfa5
# PP-YOLOE 转ONNX-TRT教程
本教程内容为：使用PP-YOLOE模型导出转换为ONNX格式，并定制化修改网络，使用[EfficientNMS_TRT](https://github.com/NVIDIA/TensorRT/tree/main/plugin/efficientNMSPlugin) OP，
可成功运行在[TensorRT](https://github.com/NVIDIA/TensorRT)上，示例仅供参考
## 1. 环境依赖
CUDA 10.2 + [cudnn 8.2.1](https://docs.nvidia.com/deeplearning/cudnn/install-guide/index.html) + [TensorRT 8.2](https://docs.nvidia.com/deeplearning/tensorrt/archives/tensorrt-821/install-guide/index.htm)
```commandline
onnx
onnxruntime
paddle2onnx
```
## 2. Paddle模型导出
```commandline
python tools/export_model.py -c configs/ppyoloe/ppyoloe_crn_l_300e_coco.yml -o weights=https://paddledet.bj.bcebos.com/models/ppyoloe_crn_l_300e_coco.pdparams trt=True exclude_nms=True
```
## 3. ONNX模型转换 + 定制化修改EfficientNMS_TRT
```commandline
python deploy/third_engine/demo_onnx_trt/onnx_custom.py --onnx_file=output_inference/ppyoloe_crn_l_300e_coco/ppyoloe_crn_l_300e_coco.onnx --model_dir=output_inference/ppyoloe_crn_l_300e_coco/ --opset_version=11
```
## 4. TensorRT Engine
```commandline
trtexec --onnx=output_inference/ppyoloe_crn_l_300e_coco/ppyoloe_crn_l_300e_coco.onnx --saveEngine=ppyoloe_crn_l_300e_coco.engine
```
**注意**：若运行报错，可尝试添加`--tacticSources=-cublasLt,+cublas`参数解决
## 5. 运行TensorRT推理
```commandline
python deploy/third_engine/demo_onnx_trt/trt_infer.py --infer_cfg=output_inference/ppyoloe_crn_l_300e_coco/infer_cfg.yml --trt_engine=ppyoloe_crn_l_300e_coco.engine --image_file=demo/000000014439.jpg
```
deploy/third_engine/demo_onnx_trt/onnx_custom.py 0 → 100644
View file @ fccfdfa5
# Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
# http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
import argparse
import os
import onnx
import onnx_graphsurgeon
import numpy as np
from collections import OrderedDict
from paddle2onnx.command import program2onnx
parser = argparse.ArgumentParser(description=__doc__)
parser.add_argument(
'--onnx_file', required=True, type=str, help='onnx model path')
parser.add_argument(
'--model_dir',
type=str,
default=None,
help=("Directory include:'model.pdiparams', 'model.pdmodel', "
"'infer_cfg.yml', created by tools/export_model.py."))
parser.add_argument(
"--opset_version",
type=int,
default=11,
help="set onnx opset version to export")
parser.add_argument(
'--topk_all', type=int, default=300, help='topk objects for every images')
parser.add_argument(
'--iou_thres', type=float, default=0.7, help='iou threshold for NMS')
parser.add_argument(
'--conf_thres', type=float, default=0.01, help='conf threshold for NMS')
def main(FLAGS):
assert os.path.exists(FLAGS.onnx_file)
onnx_model = onnx.load(FLAGS.onnx_file)
graph = onnx_graphsurgeon.import_onnx(onnx_model)
graph.toposort()
graph.fold_constants()
graph.cleanup()
num_anchors = graph.outputs[1].shape[2]
num_classes = graph.outputs[1].shape[1]
scores = onnx_graphsurgeon.Variable(
name='scores', shape=[-1, num_anchors, num_classes], dtype=np.float32)
graph.layer(
op='Transpose',
name='lastTranspose',
inputs=[graph.outputs[1]],
outputs=[scores],
attrs=OrderedDict(perm=[0, 2, 1]))
attrs = OrderedDict(
plugin_version="1",
background_class=-1,
max_output_boxes=FLAGS.topk_all,
score_threshold=FLAGS.conf_thres,
iou_threshold=FLAGS.iou_thres,
score_activation=False,
box_coding=0, )
outputs = [
onnx_graphsurgeon.Variable("num_dets", np.int32, [-1, 1]),
onnx_graphsurgeon.Variable("det_boxes", np.float32,
[-1, FLAGS.topk_all, 4]),
onnx_graphsurgeon.Variable("det_scores", np.float32,
[-1, FLAGS.topk_all]),
onnx_graphsurgeon.Variable("det_classes", np.int32,
[-1, FLAGS.topk_all])
]
graph.layer(
op='EfficientNMS_TRT',
name="batched_nms",
inputs=[graph.outputs[0], scores],
outputs=outputs,
attrs=attrs)
graph.outputs = outputs
graph.cleanup().toposort()
onnx.save(onnx_graphsurgeon.export_onnx(graph), FLAGS.onnx_file)
print(f"The modified onnx model is saved in {FLAGS.onnx_file}")
if __name__ == '__main__':
FLAGS = parser.parse_args()
if FLAGS.model_dir is not None:
assert os.path.exists(FLAGS.model_dir)
program2onnx(
model_dir=FLAGS.model_dir,
save_file=FLAGS.onnx_file,
model_filename="model.pdmodel",
params_filename="model.pdiparams",
opset_version=FLAGS.opset_version,
enable_onnx_checker=True)
main(FLAGS)
deploy/third_engine/demo_onnx_trt/preprocess.py 0 → 100644
View file @ fccfdfa5
import numpy as np
import cv2
import copy
def decode_image(img_path):
with open(img_path, 'rb') as f:
im_read = f.read()
data = np.frombuffer(im_read, dtype='uint8')
im = cv2.imdecode(data, 1) # BGR mode, but need RGB mode
im = cv2.cvtColor(im, cv2.COLOR_BGR2RGB)
img_info = {
"im_shape": np.array(
im.shape[:2], dtype=np.float32),
"scale_factor": np.array(
[1., 1.], dtype=np.float32)
}
return im, img_info
class Resize(object):
"""resize image by target_size and max_size
Args:
target_size (int): the target size of image
keep_ratio (bool): whether keep_ratio or not, default true
interp (int): method of resize
"""
def __init__(self, target_size, keep_ratio=True, interp=cv2.INTER_LINEAR):
if isinstance(target_size, int):
target_size = [target_size, target_size]
self.target_size = target_size
self.keep_ratio = keep_ratio
self.interp = interp
def __call__(self, im, im_info):
"""
Args:
im (np.ndarray): image (np.ndarray)
im_info (dict): info of image
Returns:
im (np.ndarray): processed image (np.ndarray)
im_info (dict): info of processed image
"""
assert len(self.target_size) == 2
assert self.target_size[0] > 0 and self.target_size[1] > 0
im_channel = im.shape[2]
im_scale_y, im_scale_x = self.generate_scale(im)
im = cv2.resize(
im,
None,
None,
fx=im_scale_x,
fy=im_scale_y,
interpolation=self.interp)
im_info['im_shape'] = np.array(im.shape[:2]).astype('float32')
im_info['scale_factor'] = np.array(
[im_scale_y, im_scale_x]).astype('float32')
return im, im_info
def generate_scale(self, im):
"""
Args:
im (np.ndarray): image (np.ndarray)
Returns:
im_scale_x: the resize ratio of X
im_scale_y: the resize ratio of Y
"""
origin_shape = im.shape[:2]
im_c = im.shape[2]
if self.keep_ratio:
im_size_min = np.min(origin_shape)
im_size_max = np.max(origin_shape)
target_size_min = np.min(self.target_size)
target_size_max = np.max(self.target_size)
im_scale = float(target_size_min) / float(im_size_min)
if np.round(im_scale * im_size_max) > target_size_max:
im_scale = float(target_size_max) / float(im_size_max)
im_scale_x = im_scale
im_scale_y = im_scale
else:
resize_h, resize_w = self.target_size
im_scale_y = resize_h / float(origin_shape[0])
im_scale_x = resize_w / float(origin_shape[1])
return im_scale_y, im_scale_x
class NormalizeImage(object):
"""normalize image
Args:
mean (list): im - mean
std (list): im / std
is_scale (bool): whether need im / 255
norm_type (str): type in ['mean_std', 'none']
"""
def __init__(self, mean, std, is_scale=True, norm_type='mean_std'):
self.mean = mean
self.std = std
self.is_scale = is_scale
self.norm_type = norm_type
def __call__(self, im, im_info):
"""
Args:
im (np.ndarray): image (np.ndarray)
im_info (dict): info of image
Returns:
im (np.ndarray): processed image (np.ndarray)
im_info (dict): info of processed image
"""
im = im.astype(np.float32, copy=False)
if self.is_scale:
scale = 1.0 / 255.0
im *= scale
if self.norm_type == 'mean_std':
mean = np.array(self.mean)[np.newaxis, np.newaxis, :]
std = np.array(self.std)[np.newaxis, np.newaxis, :]
im -= mean
im /= std
return im, im_info
class Permute(object):
"""permute image
Args:
to_bgr (bool): whether convert RGB to BGR
channel_first (bool): whether convert HWC to CHW
"""
def __init__(self, ):
super(Permute, self).__init__()
def __call__(self, im, im_info):
"""
Args:
im (np.ndarray): image (np.ndarray)
im_info (dict): info of image
Returns:
im (np.ndarray): processed image (np.ndarray)
im_info (dict): info of processed image
"""
im = im.transpose((2, 0, 1)).copy()
return im, im_info
class PadStride(object):
""" padding image for model with FPN, instead PadBatch(pad_to_stride) in original config
Args:
stride (bool): model with FPN need image shape % stride == 0
"""
def __init__(self, stride=0):
self.coarsest_stride = stride
def __call__(self, im, im_info):
"""
Args:
im (np.ndarray): image (np.ndarray)
im_info (dict): info of image
Returns:
im (np.ndarray): processed image (np.ndarray)
im_info (dict): info of processed image
"""
coarsest_stride = self.coarsest_stride
if coarsest_stride <= 0:
return im, im_info
im_c, im_h, im_w = im.shape
pad_h = int(np.ceil(float(im_h) / coarsest_stride) * coarsest_stride)
pad_w = int(np.ceil(float(im_w) / coarsest_stride) * coarsest_stride)
padding_im = np.zeros((im_c, pad_h, pad_w), dtype=np.float32)
padding_im[:, :im_h, :im_w] = im
return padding_im, im_info
class LetterBoxResize(object):
def __init__(self, target_size):
"""
Resize image to target size, convert normalized xywh to pixel xyxy
format ([x_center, y_center, width, height] -> [x0, y0, x1, y1]).
Args:
target_size (int|list): image target size.
"""
super(LetterBoxResize, self).__init__()
if isinstance(target_size, int):
target_size = [target_size, target_size]
self.target_size = target_size
def letterbox(self, img, height, width, color=(127.5, 127.5, 127.5)):
# letterbox: resize a rectangular image to a padded rectangular
shape = img.shape[:2] # [height, width]
ratio_h = float(height) / shape[0]
ratio_w = float(width) / shape[1]
ratio = min(ratio_h, ratio_w)
new_shape = (round(shape[1] * ratio),
round(shape[0] * ratio)) # [width, height]
padw = (width - new_shape[0]) / 2
padh = (height - new_shape[1]) / 2
top, bottom = round(padh - 0.1), round(padh + 0.1)
left, right = round(padw - 0.1), round(padw + 0.1)
img = cv2.resize(
img, new_shape, interpolation=cv2.INTER_AREA) # resized, no border
img = cv2.copyMakeBorder(
img, top, bottom, left, right, cv2.BORDER_CONSTANT,
value=color) # padded rectangular
return img, ratio, padw, padh
def __call__(self, im, im_info):
"""
Args:
im (np.ndarray): image (np.ndarray)
im_info (dict): info of image
Returns:
im (np.ndarray): processed image (np.ndarray)
im_info (dict): info of processed image
"""
assert len(self.target_size) == 2
assert self.target_size[0] > 0 and self.target_size[1] > 0
height, width = self.target_size
h, w = im.shape[:2]
im, ratio, padw, padh = self.letterbox(im, height=height, width=width)
new_shape = [round(h * ratio), round(w * ratio)]
im_info['im_shape'] = np.array(new_shape, dtype=np.float32)
im_info['scale_factor'] = np.array([ratio, ratio], dtype=np.float32)
return im, im_info
class Pad(object):
def __init__(self, size, fill_value=[114.0, 114.0, 114.0]):
"""
Pad image to a specified size.
Args:
size (list[int]): image target size
fill_value (list[float]): rgb value of pad area, default (114.0, 114.0, 114.0)
"""
super(Pad, self).__init__()
if isinstance(size, int):
size = [size, size]
self.size = size
self.fill_value = fill_value
def __call__(self, im, im_info):
im_h, im_w = im.shape[:2]
h, w = self.size
if h == im_h and w == im_w:
im = im.astype(np.float32)
return im, im_info
canvas = np.ones((h, w, 3), dtype=np.float32)
canvas *= np.array(self.fill_value, dtype=np.float32)
canvas[0:im_h, 0:im_w, :] = im.astype(np.float32)
im = canvas
return im, im_info
def rotate_point(pt, angle_rad):
"""Rotate a point by an angle.
Args:
pt (list[float]): 2 dimensional point to be rotated
angle_rad (float): rotation angle by radian
Returns:
list[float]: Rotated point.
"""
assert len(pt) == 2
sn, cs = np.sin(angle_rad), np.cos(angle_rad)
new_x = pt[0] * cs - pt[1] * sn
new_y = pt[0] * sn + pt[1] * cs
rotated_pt = [new_x, new_y]
return rotated_pt
def _get_3rd_point(a, b):
"""To calculate the affine matrix, three pairs of points are required. This
function is used to get the 3rd point, given 2D points a & b.
The 3rd point is defined by rotating vector `a - b` by 90 degrees
anticlockwise, using b as the rotation center.
Args:
a (np.ndarray): point(x,y)
b (np.ndarray): point(x,y)
Returns:
np.ndarray: The 3rd point.
"""
assert len(a) == 2
assert len(b) == 2
direction = a - b
third_pt = b + np.array([-direction[1], direction[0]], dtype=np.float32)
return third_pt
def get_affine_transform(center,
input_size,
rot,
output_size,
shift=(0., 0.),
inv=False):
"""Get the affine transform matrix, given the center/scale/rot/output_size.
Args:
center (np.ndarray[2, ]): Center of the bounding box (x, y).
scale (np.ndarray[2, ]): Scale of the bounding box
wrt [width, height].
rot (float): Rotation angle (degree).
output_size (np.ndarray[2, ]): Size of the destination heatmaps.
shift (0-100%): Shift translation ratio wrt the width/height.
Default (0., 0.).
inv (bool): Option to inverse the affine transform direction.
(inv=False: src->dst or inv=True: dst->src)
Returns:
np.ndarray: The transform matrix.
"""
assert len(center) == 2
assert len(output_size) == 2
assert len(shift) == 2
if not isinstance(input_size, (np.ndarray, list)):
input_size = np.array([input_size, input_size], dtype=np.float32)
scale_tmp = input_size
shift = np.array(shift)
src_w = scale_tmp[0]
dst_w = output_size[0]
dst_h = output_size[1]
rot_rad = np.pi * rot / 180
src_dir = rotate_point([0., src_w * -0.5], rot_rad)
dst_dir = np.array([0., dst_w * -0.5])
src = np.zeros((3, 2), dtype=np.float32)
src[0, :] = center + scale_tmp * shift
src[1, :] = center + src_dir + scale_tmp * shift
src[2, :] = _get_3rd_point(src[0, :], src[1, :])
dst = np.zeros((3, 2), dtype=np.float32)
dst[0, :] = [dst_w * 0.5, dst_h * 0.5]
dst[1, :] = np.array([dst_w * 0.5, dst_h * 0.5]) + dst_dir
dst[2, :] = _get_3rd_point(dst[0, :], dst[1, :])
if inv:
trans = cv2.getAffineTransform(np.float32(dst), np.float32(src))
else:
trans = cv2.getAffineTransform(np.float32(src), np.float32(dst))
return trans
class WarpAffine(object):
"""Warp affine the image
"""
def __init__(self,
keep_res=False,
pad=31,
input_h=512,
input_w=512,
scale=0.4,
shift=0.1):
self.keep_res = keep_res
self.pad = pad
self.input_h = input_h
self.input_w = input_w
self.scale = scale
self.shift = shift
def __call__(self, im, im_info):
"""
Args:
im (np.ndarray): image (np.ndarray)
im_info (dict): info of image
Returns:
im (np.ndarray): processed image (np.ndarray)
im_info (dict): info of processed image
"""
img = cv2.cvtColor(im, cv2.COLOR_RGB2BGR)
h, w = img.shape[:2]
if self.keep_res:
input_h = (h | self.pad) + 1
input_w = (w | self.pad) + 1
s = np.array([input_w, input_h], dtype=np.float32)
c = np.array([w // 2, h // 2], dtype=np.float32)
else:
s = max(h, w) * 1.0
input_h, input_w = self.input_h, self.input_w
c = np.array([w / 2., h / 2.], dtype=np.float32)
trans_input = get_affine_transform(c, s, 0, [input_w, input_h])
img = cv2.resize(img, (w, h))
inp = cv2.warpAffine(
img, trans_input, (input_w, input_h), flags=cv2.INTER_LINEAR)
return inp, im_info
# keypoint preprocess
def get_warp_matrix(theta, size_input, size_dst, size_target):
"""This code is based on
https://github.com/open-mmlab/mmpose/blob/master/mmpose/core/post_processing/post_transforms.py
Calculate the transformation matrix under the constraint of unbiased.
Paper ref: Huang et al. The Devil is in the Details: Delving into Unbiased
Data Processing for Human Pose Estimation (CVPR 2020).
Args:
theta (float): Rotation angle in degrees.
size_input (np.ndarray): Size of input image [w, h].
size_dst (np.ndarray): Size of output image [w, h].
size_target (np.ndarray): Size of ROI in input plane [w, h].
Returns:
matrix (np.ndarray): A matrix for transformation.
"""
theta = np.deg2rad(theta)
matrix = np.zeros((2, 3), dtype=np.float32)
scale_x = size_dst[0] / size_target[0]
scale_y = size_dst[1] / size_target[1]
matrix[0, 0] = np.cos(theta) * scale_x
matrix[0, 1] = -np.sin(theta) * scale_x
matrix[0, 2] = scale_x * (
-0.5 * size_input[0] * np.cos(theta) + 0.5 * size_input[1] *
np.sin(theta) + 0.5 * size_target[0])
matrix[1, 0] = np.sin(theta) * scale_y
matrix[1, 1] = np.cos(theta) * scale_y
matrix[1, 2] = scale_y * (
-0.5 * size_input[0] * np.sin(theta) - 0.5 * size_input[1] *
np.cos(theta) + 0.5 * size_target[1])
return matrix
class TopDownEvalAffine(object):
"""apply affine transform to image and coords
Args:
trainsize (list): [w, h], the standard size used to train
use_udp (bool): whether to use Unbiased Data Processing.
records(dict): the dict contained the image and coords
Returns:
records (dict): contain the image and coords after tranformed
"""
def __init__(self, trainsize, use_udp=False):
self.trainsize = trainsize
self.use_udp = use_udp
def __call__(self, image, im_info):
rot = 0
imshape = im_info['im_shape'][::-1]
center = im_info['center'] if 'center' in im_info else imshape / 2.
scale = im_info['scale'] if 'scale' in im_info else imshape
if self.use_udp:
trans = get_warp_matrix(
rot, center * 2.0,
[self.trainsize[0] - 1.0, self.trainsize[1] - 1.0], scale)
image = cv2.warpAffine(
image,
trans, (int(self.trainsize[0]), int(self.trainsize[1])),
flags=cv2.INTER_LINEAR)
else:
trans = get_affine_transform(center, scale, rot, self.trainsize)
image = cv2.warpAffine(
image,
trans, (int(self.trainsize[0]), int(self.trainsize[1])),
flags=cv2.INTER_LINEAR)
return image, im_info
class Compose:
def __init__(self, transforms):
self.transforms = []
for op_info in transforms:
new_op_info = op_info.copy()
op_type = new_op_info.pop('type')
self.transforms.append(eval(op_type)(**new_op_info))
def __call__(self, img_path):
img, im_info = decode_image(img_path)
for t in self.transforms:
img, im_info = t(img, im_info)
inputs = copy.deepcopy(im_info)
inputs['image'] = np.ascontiguousarray(img.astype('float32'))
return inputs
coco_clsid2catid = {
0: 1,
1: 2,
2: 3,
3: 4,
4: 5,
5: 6,
6: 7,
7: 8,
8: 9,
9: 10,
10: 11,
11: 13,
12: 14,
13: 15,
14: 16,
15: 17,
16: 18,
17: 19,
18: 20,
19: 21,
20: 22,
21: 23,
22: 24,
23: 25,
24: 27,
25: 28,
26: 31,
27: 32,
28: 33,
29: 34,
30: 35,
31: 36,
32: 37,
33: 38,
34: 39,
35: 40,
36: 41,
37: 42,
38: 43,
39: 44,
40: 46,
41: 47,
42: 48,
43: 49,
44: 50,
45: 51,
46: 52,
47: 53,
48: 54,
49: 55,
50: 56,
51: 57,
52: 58,
53: 59,
54: 60,
55: 61,
56: 62,
57: 63,
58: 64,
59: 65,
60: 67,
61: 70,
62: 72,
63: 73,
64: 74,
65: 75,
66: 76,
67: 77,
68: 78,
69: 79,
70: 80,
71: 81,
72: 82,
73: 84,
74: 85,
75: 86,
76: 87,
77: 88,
78: 89,
79: 90
}
deploy/third_engine/demo_onnx_trt/trt_infer.py 0 → 100644
View file @ fccfdfa5
# Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
# http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
import time
import numpy as np
import pycuda.autoinit
import pycuda.driver as cuda
import tensorrt as trt
from collections import OrderedDict
import os
import yaml
import json
import glob
import argparse
from preprocess import Compose
from preprocess import coco_clsid2catid
parser = argparse.ArgumentParser(description=__doc__)
parser.add_argument("--infer_cfg", type=str, help="infer_cfg.yml")
parser.add_argument(
"--trt_engine", required=True, type=str, help="trt engine path")
parser.add_argument("--image_dir", type=str)
parser.add_argument("--image_file", type=str)
parser.add_argument(
"--repeats",
type=int,
default=1,
help="Repeat the running test `repeats` times in benchmark")
parser.add_argument(
"--save_coco",
action='store_true',
default=False,
help="Whether to save coco results")
parser.add_argument(
"--coco_file", type=str, default="results.json", help="coco results path")
TRT_LOGGER = trt.Logger()
trt.init_libnvinfer_plugins(TRT_LOGGER, namespace="")
# Global dictionary
SUPPORT_MODELS = {
'YOLO', 'PPYOLOE', 'YOLOX', 'YOLOv5', 'YOLOv6', 'YOLOv7', 'YOLOv8', 'RTMDet'
}
def get_test_images(infer_dir, infer_img):
"""
Get image path list in TEST mode
"""
assert infer_img is not None or infer_dir is not None, \
"--image_file or --image_dir should be set"
assert infer_img is None or os.path.isfile(infer_img), \
"{} is not a file".format(infer_img)
assert infer_dir is None or os.path.isdir(infer_dir), \
"{} is not a directory".format(infer_dir)
# infer_img has a higher priority
if infer_img and os.path.isfile(infer_img):
return [infer_img]
images = set()
infer_dir = os.path.abspath(infer_dir)
assert os.path.isdir(infer_dir), \
"infer_dir {} is not a directory".format(infer_dir)
exts = ['jpg', 'jpeg', 'png', 'bmp']
exts += [ext.upper() for ext in exts]
for ext in exts:
images.update(glob.glob('{}/*.{}'.format(infer_dir, ext)))
images = list(images)
assert len(images) > 0, "no image found in {}".format(infer_dir)
print("Found {} inference images in total.".format(len(images)))
return images
class PredictConfig(object):
"""set config of preprocess, postprocess and visualize
Args:
infer_config (str): path of infer_cfg.yml
"""
def __init__(self, infer_config):
# parsing Yaml config for Preprocess
with open(infer_config) as f:
yml_conf = yaml.safe_load(f)
self.check_model(yml_conf)
self.arch = yml_conf['arch']
self.preprocess_infos = yml_conf['Preprocess']
self.min_subgraph_size = yml_conf['min_subgraph_size']
self.label_list = yml_conf['label_list']
self.use_dynamic_shape = yml_conf['use_dynamic_shape']
self.draw_threshold = yml_conf.get("draw_threshold", 0.5)
self.mask = yml_conf.get("mask", False)
self.tracker = yml_conf.get("tracker", None)
self.nms = yml_conf.get("NMS", None)
self.fpn_stride = yml_conf.get("fpn_stride", None)
if self.arch == 'RCNN' and yml_conf.get('export_onnx', False):
print(
'The RCNN export model is used for ONNX and it only supports batch_size = 1'
)
self.print_config()
def check_model(self, yml_conf):
"""
Raises:
ValueError: loaded model not in supported model type
"""
for support_model in SUPPORT_MODELS:
if support_model in yml_conf['arch']:
return True
raise ValueError("Unsupported arch: {}, expect {}".format(yml_conf[
'arch'], SUPPORT_MODELS))
def print_config(self):
print('----------- Model Configuration -----------')
print('%s: %s' % ('Model Arch', self.arch))
print('%s: ' % ('Transform Order'))
for op_info in self.preprocess_infos:
print('--%s: %s' % ('transform op', op_info['type']))
print('--------------------------------------------')
def load_trt_engine(engine_path):
assert os.path.exists(engine_path)
print("Reading engine from file {}".format(engine_path))
with open(engine_path, "rb") as f, trt.Runtime(TRT_LOGGER) as runtime:
return runtime.deserialize_cuda_engine(f.read())
def predict_image(infer_config, engine, img_list, save_coco=False, repeats=1):
# load preprocess transforms
transforms = Compose(infer_config.preprocess_infos)
stream = cuda.Stream()
coco_results = []
num_data = len(img_list)
avg_time = []
with engine.create_execution_context() as context:
# Allocate host and device buffers
bindings = create_trt_bindings(engine, context)
# warmup
run_trt_context(context, bindings, stream, repeats=10)
# predict image
for i, img_path in enumerate(img_list):
inputs = transforms(img_path)
inputs_name = [k for k, v in bindings.items() if v['is_input']]
inputs = {
k: inputs[k][None, ]
for k in inputs.keys() if k in inputs_name
}
# run infer
for k, v in inputs.items():
bindings[k]['cpu_data'][...] = v
output = run_trt_context(context, bindings, stream, repeats=repeats)
print(f"{i + 1}/{num_data} infer time: {output['infer_time']} ms.")
avg_time.append(output['infer_time'])
# get output
for k, v in output.items():
if k in bindings.keys():
output[k] = np.reshape(v, bindings[k]['shape'])
if save_coco:
coco_results.extend(
format_coco_results(os.path.split(img_path)[-1], output))
avg_time = np.mean(avg_time)
print(
f"Run on {num_data} data, repeats {repeats} times, avg time: {avg_time} ms."
)
if save_coco:
with open(FLAGS.coco_file, 'w') as f:
json.dump(coco_results, f)
print(f"save coco json to {FLAGS.coco_file}")
def create_trt_bindings(engine, context):
bindings = OrderedDict()
for name in engine:
binding_idx = engine.get_binding_index(name)
size = trt.volume(context.get_binding_shape(binding_idx))
dtype = trt.nptype(engine.get_binding_dtype(name))
shape = list(engine.get_binding_shape(binding_idx))
if shape[0] == -1:
shape[0] = 1
bindings[name] = {
"idx": binding_idx,
"size": size,
"dtype": dtype,
"shape": shape,
"cpu_data": None,
"cuda_ptr": None,
"is_input": True if engine.binding_is_input(name) else False
}
if engine.binding_is_input(name):
bindings[name]['cpu_data'] = np.random.randn(*shape).astype(
np.float32)
bindings[name]['cuda_ptr'] = cuda.mem_alloc(bindings[name][
'cpu_data'].nbytes)
else:
bindings[name]['cpu_data'] = cuda.pagelocked_empty(size, dtype)
bindings[name]['cuda_ptr'] = cuda.mem_alloc(bindings[name][
'cpu_data'].nbytes)
return bindings
def run_trt_context(context, bindings, stream, repeats=1):
# Transfer input data to the GPU.
for k, v in bindings.items():
if v['is_input']:
cuda.memcpy_htod_async(v['cuda_ptr'], v['cpu_data'], stream)
in_bindings = [int(v['cuda_ptr']) for k, v in bindings.items()]
output_data = {}
avg_time = []
for _ in range(repeats):
# Run inference
t1 = time.time()
context.execute_async_v2(
bindings=in_bindings, stream_handle=stream.handle)
# Transfer prediction output from the GPU.
for k, v in bindings.items():
if not v['is_input']:
cuda.memcpy_dtoh_async(v['cpu_data'], v['cuda_ptr'], stream)
output_data[k] = v['cpu_data']
# Synchronize the stream
stream.synchronize()
t2 = time.time()
avg_time.append(t2 - t1)
output_data['infer_time'] = np.mean(avg_time) * 1000
return output_data
def format_coco_results(file_name, result):
try:
image_id = int(os.path.splitext(file_name)[0])
except:
image_id = file_name
num_dets = result['num_dets'].tolist()
det_classes = result['det_classes'].tolist()
det_scores = result['det_scores'].tolist()
det_boxes = result['det_boxes'].tolist()
per_result = [
{
'image_id': image_id,
'category_id': coco_clsid2catid[int(det_classes[0][idx])],
'file_name': file_name,
'bbox': [
det_boxes[0][idx][0], det_boxes[0][idx][1],
det_boxes[0][idx][2] - det_boxes[0][idx][0],
det_boxes[0][idx][3] - det_boxes[0][idx][1]
], # xyxy -> xywh
'score': det_scores[0][idx]
} for idx in range(num_dets[0][0])
]
return per_result
if __name__ == '__main__':
FLAGS = parser.parse_args()
# load image list
img_list = get_test_images(FLAGS.image_dir, FLAGS.image_file)
# load trt engine
engine = load_trt_engine(FLAGS.trt_engine)
# load infer config
infer_config = PredictConfig(FLAGS.infer_cfg)
predict_image(infer_config, engine, img_list, FLAGS.save_coco,
FLAGS.repeats)
print('Done!')
deploy/third_engine/demo_onnxruntime/README.md 0 → 100644
View file @ fccfdfa5
# PicoDet ONNX Runtime Demo
本文件夹提供利用[ONNX Runtime](https://onnxruntime.ai/docs/)进行 PicoDet 部署与Inference images 的 Demo。
## 安装 ONNX Runtime
本demo采用的是 ONNX Runtime 1.10.0，可直接运行如下指令安装：
```shell
pip install onnxruntime
```
详细安装步骤，可参考 [Install ONNX Runtime](https://onnxruntime.ai/docs/install/)。
## Inference images
- 准备测试模型：根据[PicoDet](https://github.com/PaddlePaddle/PaddleDetection/tree/develop/configs/picodet)中【导出及转换模型】步骤，采用包含后处理的方式导出模型（`-o export.benchmark=False` ），并生成待测试模型简化后的onnx模型（可在下文链接中直接下载）。同时在本目录下新建```onnx_file```文件夹，将导出的onnx模型放在该目录下。
- 准备测试所用图片：将待测试图片放在```./imgs```文件夹下，本demo已提供了两张测试图片。
- 在本目录下直接运行：
```shell
python infer_demo.py --modelpath ./onnx_file/picodet_s_320_lcnet_postprocessed.onnx
```
将会对```./imgs```文件夹下所有图片进行识别，并将识别结果保存在```./results```文件夹下。
- 结果：
<div align="center">
<img src="../../../docs/images/bus.jpg" height="300px" ><img src="../../../docs/images/dog.jpg" height="300px" >
</div>
## 模型下载
| 模型 | 输入尺寸 | ONNX( w/ 后处理) |
| :-------- | :--------: | :---------------------: |
| PicoDet-XS | 320*320 | [model](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_xs_320_lcnet_postprocessed.onnx) |
| PicoDet-XS | 416*416 | [model](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_xs_416_lcnet_postprocessed.onnx) |
| PicoDet-S | 320*320 | [model](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_s_320_lcnet_postprocessed.onnx) |
| PicoDet-S | 416*416 | [model](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_s_416_lcnet_postprocessed.onnx) |
| PicoDet-M | 320*320 | [model](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_m_320_lcnet_postprocessed.onnx) |
| PicoDet-M | 416*416 | [model](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_m_416_lcnet_postprocessed.onnx) |
| PicoDet-L | 320*320 | [model](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_l_320_lcnet_postprocessed.onnx) |
| PicoDet-L | 416*416 | [model](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_l_416_lcnet_postprocessed.onnx) |
| PicoDet-L | 640*640 | [model](https://paddledet.bj.bcebos.com/deploy/third_engine/picodet_l_640_lcnet_postprocessed.onnx) |
deploy/third_engine/demo_onnxruntime/coco_label.txt 0 → 100644
View file @ fccfdfa5
person
bicycle
car
motorbike
aeroplane
bus
train
truck
boat
traffic light
fire hydrant
stop sign
parking meter
bench
bird
cat
dog
horse
sheep
cow
elephant
bear
zebra
giraffe
backpack
umbrella
handbag
tie
suitcase
frisbee
skis
snowboard
sports ball
kite
baseball bat
baseball glove
skateboard
surfboard
tennis racket
bottle
wine glass
cup
fork
knife
spoon
bowl
banana
apple
sandwich
orange
broccoli
carrot
hot dog
pizza
donut
cake
chair
sofa
pottedplant
bed
diningtable
toilet
tvmonitor
laptop
mouse
remote
keyboard
cell phone
microwave
oven
toaster
sink
refrigerator
book
clock
vase
scissors
teddy bear
hair drier
toothbrush
deploy/third_engine/demo_onnxruntime/infer_demo.py 0 → 100644
View file @ fccfdfa5
# Copyright (c) 2022 PaddlePaddle Authors. All Rights Reserved.
#
# Licensed under the Apache License, Version 2.0 (the "License");
# you may not use this file except in compliance with the License.
# You may obtain a copy of the License at
#
# http://www.apache.org/licenses/LICENSE-2.0
#
# Unless required by applicable law or agreed to in writing, software
# distributed under the License is distributed on an "AS IS" BASIS,
# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
# See the License for the specific language governing permissions and
# limitations under the License.
import cv2
import numpy as np
import argparse
import onnxruntime as ort
from pathlib import Path
from tqdm import tqdm
class PicoDet():
def __init__(self,
model_pb_path,
label_path,
prob_threshold=0.4,
iou_threshold=0.3):
self.classes = list(
map(lambda x: x.strip(), open(label_path, 'r').readlines()))
self.num_classes = len(self.classes)
self.prob_threshold = prob_threshold
self.iou_threshold = iou_threshold
self.mean = np.array(
[103.53, 116.28, 123.675], dtype=np.float32).reshape(1, 1, 3)
self.std = np.array(
[57.375, 57.12, 58.395], dtype=np.float32).reshape(1, 1, 3)
so = ort.SessionOptions()
so.log_severity_level = 3
self.net = ort.InferenceSession(model_pb_path, so)
inputs_name = [a.name for a in self.net.get_inputs()]
inputs_shape = {
k: v.shape
for k, v in zip(inputs_name, self.net.get_inputs())
}
self.input_shape = inputs_shape['image'][2:]
def _normalize(self, img):
img = img.astype(np.float32)
img = (img / 255.0 - self.mean / 255.0) / (self.std / 255.0)
return img
def resize_image(self, srcimg, keep_ratio=False):
top, left, newh, neww = 0, 0, self.input_shape[0], self.input_shape[1]
origin_shape = srcimg.shape[:2]
im_scale_y = newh / float(origin_shape[0])
im_scale_x = neww / float(origin_shape[1])
img_shape = np.array([
[float(self.input_shape[0]), float(self.input_shape[1])]
]).astype('float32')
scale_factor = np.array([[im_scale_y, im_scale_x]]).astype('float32')
if keep_ratio and srcimg.shape[0] != srcimg.shape[1]:
hw_scale = srcimg.shape[0] / srcimg.shape[1]
if hw_scale > 1:
newh, neww = self.input_shape[0], int(self.input_shape[1] /
hw_scale)
img = cv2.resize(
srcimg, (neww, newh), interpolation=cv2.INTER_AREA)
left = int((self.input_shape[1] - neww) * 0.5)
img = cv2.copyMakeBorder(
img,
0,
0,
left,
self.input_shape[1] - neww - left,
cv2.BORDER_CONSTANT,
value=0) # add border
else:
newh, neww = int(self.input_shape[0] *
hw_scale), self.input_shape[1]
img = cv2.resize(
srcimg, (neww, newh), interpolation=cv2.INTER_AREA)
top = int((self.input_shape[0] - newh) * 0.5)
img = cv2.copyMakeBorder(
img,
top,
self.input_shape[0] - newh - top,
0,
0,
cv2.BORDER_CONSTANT,
value=0)
else:
img = cv2.resize(
srcimg, self.input_shape, interpolation=cv2.INTER_LINEAR)
return img, img_shape, scale_factor
def get_color_map_list(self, num_classes):
color_map = num_classes * [0, 0, 0]
for i in range(0, num_classes):
j = 0
lab = i
while lab:
color_map[i * 3] |= (((lab >> 0) & 1) << (7 - j))
color_map[i * 3 + 1] |= (((lab >> 1) & 1) << (7 - j))
color_map[i * 3 + 2] |= (((lab >> 2) & 1) << (7 - j))
j += 1
lab >>= 3
color_map = [color_map[i:i + 3] for i in range(0, len(color_map), 3)]
return color_map
def detect(self, srcimg):
img, im_shape, scale_factor = self.resize_image(srcimg)
img = self._normalize(img)
blob = np.expand_dims(np.transpose(img, (2, 0, 1)), axis=0)
inputs_dict = {
'im_shape': im_shape,
'image': blob,
'scale_factor': scale_factor
}
inputs_name = [a.name for a in self.net.get_inputs()]
net_inputs = {k: inputs_dict[k] for k in inputs_name}
outs = self.net.run(None, net_inputs)
outs = np.array(outs[0])
expect_boxes = (outs[:, 1] > 0.5) & (outs[:, 0] > -1)
np_boxes = outs[expect_boxes, :]
color_list = self.get_color_map_list(self.num_classes)
clsid2color = {}
for i in range(np_boxes.shape[0]):
classid, conf = int(np_boxes[i, 0]), np_boxes[i, 1]
xmin, ymin, xmax, ymax = int(np_boxes[i, 2]), int(np_boxes[
i, 3]), int(np_boxes[i, 4]), int(np_boxes[i, 5])
if classid not in clsid2color:
clsid2color[classid] = color_list[classid]
color = tuple(clsid2color[classid])
cv2.rectangle(
srcimg, (xmin, ymin), (xmax, ymax), color, thickness=2)
print(self.classes[classid] + ': ' + str(round(conf, 3)))
cv2.putText(
srcimg,
self.classes[classid] + ':' + str(round(conf, 3)), (xmin,
ymin - 10),
cv2.FONT_HERSHEY_SIMPLEX,
0.8, (0, 255, 0),
thickness=2)
return srcimg
def detect_folder(self, img_fold, result_path):
img_fold = Path(img_fold)
result_path = Path(result_path)
result_path.mkdir(parents=True, exist_ok=True)
img_name_list = filter(
lambda x: str(x).endswith(".png") or str(x).endswith(".jpg"),
img_fold.iterdir(), )
img_name_list = list(img_name_list)
print(f"find {len(img_name_list)} images")
for img_path in tqdm(img_name_list):
img = cv2.imread(str(img_path), 1)
img = cv2.cvtColor(img, cv2.COLOR_BGR2RGB)
srcimg = net.detect(img)
save_path = str(result_path / img_path.name.replace(".png", ".jpg"))
cv2.imwrite(save_path, srcimg)
if __name__ == '__main__':
parser = argparse.ArgumentParser()
parser.add_argument(
'--modelpath',
type=str,
default='onnx_file/picodet_s_320_lcnet_postprocessed.onnx',
help="onnx filepath")
parser.add_argument(
'--classfile',
type=str,
default='coco_label.txt',
help="classname filepath")
parser.add_argument(
'--confThreshold', default=0.5, type=float, help='class confidence')
parser.add_argument(
'--nmsThreshold', default=0.6, type=float, help='nms iou thresh')
parser.add_argument(
"--img_fold", dest="img_fold", type=str, default="./imgs")
parser.add_argument(
"--result_fold", dest="result_fold", type=str, default="results")
args = parser.parse_args()
net = PicoDet(
args.modelpath,
args.classfile,
prob_threshold=args.confThreshold,
iou_threshold=args.nmsThreshold)
net.detect_folder(args.img_fold, args.result_fold)
print(
f'infer results in ./deploy/third_engine/demo_onnxruntime/{args.result_fold}'
)
Markdown is supported
0% or .
You are about to add 0 people to the discussion. Proceed with caution.
Finish editing this message first!
Please register or to comment
