NST Blogpost (#4886)

* nst colab

* downloaded py filed

* Removed text. Use gdoc for reviewing text, py for code

* update ipynb

* Removed google3 imports and added images

* nst update images

* final updates

research/nst_blogpost/4_Neural_Style_Transfer_with_Eager_Execution.py

+import matplotlib.pyplot as plt
+import numpy as np
+from PIL import Image
+import time
+import functools
+
+
+import google3
+import google3.third_party.tensorflow.python as tf
+import google3.third_party.tensorflow.contrib.eager as tfe
+
+from google3.third_party.tensorflow.python.keras.preprocessing import image
+from google3.third_party.tensorflow.python.keras import models
+from google3.third_party.tensorflow.python.keras import losses
+from google3.third_party.tensorflow.python.keras import layers
+from google3.third_party.tensorflow.python.keras import backend as K
+
+
+tf.enable_eager_execution()
+print("Eager execution: {}".format(tf.executing_eagerly()))
+
+
+img_shape = (512, 512, 3)
+content_path = '/tmp/nst/dancing.png'
+style_path = '/tmp/nst/picasso.png'
+
+
+# # Let's begin by visualizing our input
+
+# In[ ]:
+
+
+def load_img(path_to_img):
+  img = image.load_img(path_to_img, target_size=(img_shape[0], img_shape[1]))
+  img = image.img_to_array(img)
+  # We need to broadcast the image array such that it has a batch dimension
+  img = np.expand_dims(img, axis=0)
+  return img
+
+
+# In[ ]:
+
+
+def imshow(img, title=None):
+  # Remove the batch dimension
+  out = np.squeeze(img, axis=0)
+  # Normalize for display
+  out = out.astype('uint8')
+  plt.imshow(out)
+  if title is not None:
+    plt.title(title)
+  plt.imshow(out)
+
+
+# These are input content and style images. We hope to "create" an image with
+# the content of our content image, but with the style of the style image.
+
+# In[7]:
+
+
+plt.figure(figsize=(10,10))
+
+content = load_img(content_path).astype('uint8')
+style = load_img(style_path)
+
+plt.subplot(1, 2, 1)
+imshow(content, 'Content Image')
+
+plt.subplot(1, 2, 2)
+imshow(style, 'Style Image')
+plt.show()
+
+
+
+
+def load_and_process_img(path_to_img):
+  img = load_img(path_to_img)
+  img = tf.keras.applications.vgg19.preprocess_input(img)
+  return img
+
+
+
+
+def deprocess_img(processed_img):
+  x = processed_img.copy()
+  if len(x.shape) == 4:
+    x = x.reshape(img_shape)
+  assert len(x.shape) == 3, ("Input to deprocess image must be an image of "
+                             "dimension [batch, height, width, channel] or [height_width_channel]")
+  if len(x.shape) != 3:
+    raise ValueError("Invalid input to deprocessing image")
+
+  # perform the inverse of the preprocessiing step
+  x[:, :, 0] += 103.939
+  x[:, :, 1] += 116.779
+  x[:, :, 2] += 123.68
+  x = x[:, :, ::-1]
+
+  x = np.clip(x, 0, 255).astype('uint8')
+  return x
+
+
+
+# Content layer where will pull our feature maps
+content_layers = ['block5_conv2']
+
+# Style layer we are interested in
+style_layers = ['block1_conv1',
+                'block2_conv1',
+                'block3_conv1',
+                'block4_conv1',
+                'block5_conv1'
+               ]
+
+num_content_layers = len(content_layers)
+num_style_layers = len(style_layers)
+
+
+
+
+def get_model():
+  """ Creates our model with access to intermediate layers.
+
+  This function will load the VGG19 model and access the intermediate layers.
+  These layers will then be used to create a new model that will take input image
+  and return the outputs from these intermediate layers from the VGG model.
+
+  Returns:
+    returns a keras model that takes image inputs and outputs the style and
+      content intermediate layers.
+  """
+  # Load our model. We load pretrained VGG, trained on imagenet data
+  vgg = tf.keras.applications.vgg19.VGG19(include_top=False, weights='imagenet')
+  vgg.trainable = False
+  # Get output layers corresponding to style and content layers
+  style_outputs = [vgg.get_layer(name).output for name in style_layers]
+  content_outputs = [vgg.get_layer(name).output for name in content_layers]
+  model_outputs = style_outputs + content_outputs
+  # Build model
+  return models.Model(vgg.input, model_outputs)
+
+
+
+
+
+def get_content_loss(base_content, target):
+  return tf.reduce_mean(tf.square(base_content - target))
+
+
+
+
+def gram_matrix(input_tensor):
+  # We make the image channels first
+  channels = int(input_tensor.shape[-1])
+  a = tf.reshape(input_tensor, [-1, channels])
+  n = tf.shape(a)[0]
+  gram = tf.matmul(a, a, transpose_a=True)
+  return gram / tf.cast(n, tf.float32)
+
+def get_style_loss(base_style, gram_target):
+  """Expects two images of dimension h, w, c"""
+  # height, width, num filters of each layer
+  # We scale the loss at a given layer by the size of the feature map and the number of filters
+  height, width, channels = base_style.get_shape().as_list()
+  gram_style = gram_matrix(base_style)
+
+  return tf.reduce_mean(tf.square(gram_style - gram_target))# / (4. * (channels ** 2) * (width * height) ** 2)
+
+
+
+
+
+def get_feature_representations(model, content_path, style_path):
+  """Helper function to compute our content and style feature representations.
+
+  This function will simply load and preprocess both the content and style
+  images from their path. Then it will feed them through the network to obtain
+  the outputs of the intermediate layers.
+
+  Arguments:
+    model: The model that we are using.
+    content_path: The path to the content image.
+    style_path: The path to the style image
+
+  Returns:
+    returns the style features and the content features.
+  """
+  # Load our images in
+  content_image = load_and_process_img(content_path)
+  style_image = load_and_process_img(style_path)
+
+  # batch compute content and style features
+  stack_images = np.concatenate([style_image, content_image], axis=0)
+  model_outputs = model(stack_images)
+
+  # Get the style and content feature representations from our model
+  style_features = [style_layer[0] for style_layer in model_outputs[:num_style_layers]]
+  content_features = [content_layer[1] for content_layer in model_outputs[num_style_layers:]]
+  return style_features, content_features
+
+
+
+
+def compute_loss(model, loss_weights, init_image, gram_style_features, content_features):
+  """This function will compute the loss total loss.
+
+  Arguments:
+    model: The model that will give us access to the intermediate layers
+    loss_weights: The weights of each contribution of each loss function.
+      (style weight, content weight, and total variation weight)
+    init_image: Our initial base image. This image is what we are updating with
+      our optimization process. We apply the gradients wrt the loss we are
+      calculating to this image.
+    gram_style_features: Precomputed gram matrices corresponding to the
+      defined style layers of interest.
+    content_features: Precomputed outputs from defined content layers of
+      interest.
+
+  Returns:
+    returns the total loss, style loss, content loss, and total variational loss
+  """
+  style_weight, content_weight = loss_weights
+
+  # Feed our init image through our model. This will give us the content and
+  # style representations at our desired layers. Since we're using eager
+  # our model is callable just like any other function!
+  model_outputs = model(init_image)
+
+  style_output_features = model_outputs[:num_style_layers]
+  content_output_features = model_outputs[num_style_layers:]
+
+  style_score = 0
+  content_score = 0
+
+  # Accumulate style losses from all layers
+  # Here, we equally weight each contribution of each loss layer
+  weight_per_style_layer = 1.0 / float(num_style_layers)
+  for target_style, comb_style in zip(gram_style_features, style_output_features):
+    style_score += weight_per_style_layer * get_style_loss(comb_style[0], target_style)
+
+  # Accumulate content losses from all layers
+  weight_per_content_layer = 1.0 / float(num_content_layers)
+  for target_content, comb_content in zip(content_features, content_output_features):
+    content_score += weight_per_content_layer* get_content_loss(comb_content[0], target_content)
+
+  style_score *= style_weight
+  content_score *= content_weight
+
+  # Get total loss
+  loss = style_score + content_score
+  return loss, style_score, content_score
+
+
+
+def compute_grads(cfg):
+  with tf.GradientTape() as tape:
+    all_loss = compute_loss(**cfg)
+  # Compute gradients wrt input image
+  total_loss = all_loss[0]
+  return tape.gradient(total_loss, cfg['init_image']), all_loss
+
+
+# ## Apply and run the style transfer process
+
+
+
+
+def run_style_transfer(content_path,
+                       style_path,
+                       num_iterations=1000,
+                       content_weight=1e3,
+                       style_weight=1e-2):
+  display_num = 100
+  # We don't need to (or want to) train any layers of our model, so we set their
+  # trainable to false.
+  model = get_model()
+  for layer in model.layers:
+    layer.trainable = False
+
+  # Get the style and content feature representations (from our specified intermediate layers)
+  style_features, content_features = get_feature_representations(model, content_path, style_path)
+  gram_style_features = [gram_matrix(style_feature) for style_feature in style_features]
+
+  # Set initial image
+  init_image = load_and_process_img(content_path)
+  init_image = tfe.Variable(init_image, dtype=tf.float32)
+  # Create our optimizer
+  opt = tf.train.AdamOptimizer(learning_rate=5, beta1=0.99, epsilon=1e-1)
+
+  # For displaying intermediate images
+  iter_count = 1
+
+  # Store our best result
+  best_loss, best_img = float('inf'), None
+
+  # Create a nice config
+  loss_weights = (style_weight, content_weight)
+  cfg = {
+      'model': model,
+      'loss_weights': loss_weights,
+      'init_image': init_image,
+      'gram_style_features': gram_style_features,
+      'content_features': content_features
+  }
+
+  # For displaying
+  plt.figure(figsize=(14, 7))
+  num_rows = (num_iterations / display_num) // 5
+  start_time = time.time()
+  global_start = time.time()
+
+  norm_means = np.array([103.939, 116.779, 123.68])
+  min_vals = -norm_means
+  max_vals = 255 - norm_means
+  for i in range(num_iterations):
+    grads, all_loss = compute_grads(cfg)
+    loss, style_score, content_score = all_loss
+    # grads, _ = tf.clip_by_global_norm(grads, 5.0)
+    opt.apply_gradients([(grads, init_image)])
+    clipped = tf.clip_by_value(init_image, min_vals, max_vals)
+    init_image.assign(clipped)
+    end_time = time.time()
+
+    if loss < best_loss:
+      # Update best loss and best image from total loss.
+      best_loss = loss
+      best_img = init_image.numpy()
+
+    if i % display_num == 0:
+      print('Iteration: {}'.format(i))
+      print('Total loss: {:.4e}, '
+            'style loss: {:.4e}, '
+            'content loss: {:.4e}, '
+            'time: {:.4f}s'.format(loss, style_score, content_score, time.time() - start_time))
+      start_time = time.time()
+
+      # Display intermediate images
+      if iter_count > num_rows * 5: continue
+      plt.subplot(num_rows, 5, iter_count)
+      # Use the .numpy() method to get the concrete numpy array
+      plot_img = init_image.numpy()
+      plot_img = deprocess_img(plot_img)
+
+      plt.imshow(plot_img)
+      plt.title('Iteration {}'.format(i + 1))
+      iter_count += 1
+  print('Total time: {:.4f}s'.format(time.time() - global_start))
+
+  return best_img, best_loss
+
+
+# In[18]:
+
+
+best, best_loss = run_style_transfer(content_path,
+                                     style_path)
+
+
+# # Visualize outputs
+# We "deprocess" the output image in order to remove the processing that was applied to it.
+
+# In[ ]:
+
+
+def show_results(best_img, content_path, style_path, show_large_final=True):
+  plt.figure(figsize=(15, 15))
+  x = deprocess_img(best_img)
+  content = load_img(content_path)
+  style = load_img(style_path)
+
+  plt.subplot(1, 3, 1)
+  imshow(content, 'Content Image')
+
+  plt.subplot(1, 3, 2)
+  imshow(style, 'Style Image')
+
+  plt.subplot(1, 3, 3)
+  plt.imshow(x)
+  plt.title('Output Image')
+  plt.show()
+
+  if show_large_final:
+    plt.figure(figsize=(10, 10))
+
+    plt.imshow(x)
+    plt.title('Output Image')
+    plt.show()
+
+
+# In[20]:
+
+
+show_results(best, content_path, style_path)
+
+
+# ## Let's see some other applications!
+
+# ## Starry night + Tubingen
+
+# In[21]:
+
+
+best_starry_night, best_loss = run_style_transfer('/tmp/nst/tubingen.png',
+                                                  '/tmp/nst/starry_night.png')
+
+
+# In[22]:
+
+
+show_results(best_starry_night, '/tmp/nst/tubingen.png', '/tmp/nst/starry_night.png')
+
+
+# ## Picasso + Tubingen
+
+# In[23]:
+
+
+best_picasso, best_loss = run_style_transfer('/tmp/nst/tubingen.png',
+                                             '/tmp/nst/picasso.png')
+
+
+# In[24]:
+
+
+show_results(best_picasso, '/tmp/nst/tubingen.png', '/tmp/nst/picasso.png')
+
+
+# ## Dancer + Starry Night
+
+# In[25]:
+
+
+best_starry_dance, best_loss = run_style_transfer('/tmp/nst/dancing.png',
+                                                  '/tmp/nst/Pillars_of_creation_2014_HST_WFC3-UVIS_full-res_denoised.jpg')
+
+
+# In[26]:
+
+
+show_results(best_starry_dance, '/tmp/nst/dancing.png', '/tmp/nst/Pillars_of_creation_2014_HST_WFC3-UVIS_full-res_denoised.jpg')
+
+
+# In[27]:
+
+
+best_poc_tubingen, best_loss = run_style_transfer('/tmp/nst/tubingen.png',
+                                                  '/tmp/nst/Pillars_of_creation_2014_HST_WFC3-UVIS_full-res_denoised.jpg')
+
+
+# In[28]:
+
+
+show_results(best_poc_tubingen,
+             '/tmp/nst/tubingen.png',
+             '/tmp/nst/Pillars_of_creation_2014_HST_WFC3-UVIS_full-res_denoised.jpg')
+
