v1.0

direct3d.egg-info/PKG-INFO

+Metadata-Version: 2.2
+Name: direct3d
+Version: 1.0.0
+Summary: Direct3D: Scalable Image-to-3D Generation via 3D Latent Diffusion Transformer
+Requires-Python: >=3.10
+License-File: LICENSE
+Requires-Dist: torch
+Requires-Dist: numpy
+Requires-Dist: cython
+Requires-Dist: trimesh
+Requires-Dist: diffusers
+Dynamic: requires-dist
+Dynamic: requires-python
+Dynamic: summary

direct3d.egg-info/SOURCES.txt

+LICENSE
+README.md
+setup.py
+direct3d.egg-info/PKG-INFO
+direct3d.egg-info/SOURCES.txt
+direct3d.egg-info/dependency_links.txt
+direct3d.egg-info/requires.txt
+direct3d.egg-info/top_level.txt
\ No newline at end of file

direct3d.egg-info/dependency_links.txt

+

direct3d.egg-info/requires.txt

+torch
+numpy
+cython
+trimesh
+diffusers

direct3d.egg-info/top_level.txt

+

direct3d/models/condition.py

+import torch.nn as nn
+from transformers import CLIPModel, AutoModel
+from torchvision import transforms as T
+
+class ClipImageEncoder(nn.Module):
+
+    def __init__(self, version="openai/clip-vit-large-patch14", img_size=224):
+        super().__init__()
+
+        encoder = CLIPModel.from_pretrained(version)
+        encoder = encoder.eval()
+        self.encoder = encoder
+        self.transform = T.Compose(
+            [
+                T.Resize(img_size, antialias=True),
+                T.Normalize(
+                    mean=[0.48145466, 0.4578275, 0.40821073],
+                    std=[0.26862954, 0.26130258, 0.27577711],
+                ),
+            ]
+        )
+
+    def forward(self, image):
+        image = self.transform(image)
+        embbed = self.encoder.vision_model(image).last_hidden_state
+        return embbed
+
+
+class DinoEncoder(nn.Module):
+
+    def __init__(self, version="facebook/dinov2-large", img_size=224):
+        super().__init__()
+
+        encoder = AutoModel.from_pretrained(version)
+        encoder = encoder.eval()
+        self.encoder = encoder
+        self.transform = T.Compose(
+            [
+                T.Resize(img_size, antialias=True),
+                T.Normalize(
+                    mean=[0.485, 0.456, 0.406],
+                    std=[0.229, 0.224, 0.225],
+                ),
+            ]
+        )
+
+    def forward(self, image):
+        image = self.transform(image)
+        embbed = self.encoder(image).last_hidden_state
+        return embbed
+

direct3d/models/dit.py

+# Modified from https://github.com/huggingface/diffusers/blob/main/src/diffusers/models/transformers/transformer_2d.py
+
+from typing import Optional
+
+import numpy as np
+
+import torch
+import torch.nn.functional as F
+from torch import nn
+
+from diffusers.models.embeddings import PatchEmbed, PixArtAlphaTextProjection, get_2d_sincos_pos_embed_from_grid
+from diffusers.models.embeddings import TimestepEmbedding, Timesteps
+from diffusers.models.attention import FeedForward
+
+
+class ClassCombinedTimestepSizeEmbeddings(nn.Module):
+
+    def __init__(self, embedding_dim, class_emb_dim):
+        super().__init__()
+
+        self.time_proj = Timesteps(num_channels=256, flip_sin_to_cos=True, downscale_freq_shift=0)
+        self.timestep_embedder = TimestepEmbedding(in_channels=256,
+                                                   time_embed_dim=embedding_dim,
+                                                   cond_proj_dim=class_emb_dim)
+
+    def forward(self, timestep, hidden_dtype, class_embedding=None):
+        timesteps_proj = self.time_proj(timestep)
+        timesteps_emb = self.timestep_embedder(timesteps_proj.to(dtype=hidden_dtype),
+                                               condition=class_embedding)  # (N, D)
+        return timesteps_emb
+
+
+class AdaLayerNormClassEmb(nn.Module):
+
+    def __init__(self, embedding_dim: int, class_emb_dim: int):
+        super().__init__()
+
+        self.emb = ClassCombinedTimestepSizeEmbeddings(
+            embedding_dim, class_emb_dim
+        )
+        self.silu = nn.SiLU()
+        self.linear = nn.Linear(embedding_dim, 6 * embedding_dim, bias=True)
+
+    def forward(
+        self,
+        timestep: torch.Tensor,
+        class_embedding: torch.Tensor = None,
+        hidden_dtype: Optional[torch.dtype] = None,
+    ):
+        embedded_timestep = self.emb(timestep,
+                                     class_embedding=class_embedding,
+                                     hidden_dtype=hidden_dtype)
+        return self.linear(self.silu(embedded_timestep)), embedded_timestep
+
+
+def get_2d_sincos_pos_embed(
+    embed_dim, grid_size, cls_token=False, extra_tokens=0, interpolation_scale=1.0, base_size=16
+):
+    if isinstance(grid_size, int):
+        grid_size = (grid_size, grid_size)
+
+    if isinstance(base_size, int):
+        base_size = (base_size, base_size)
+
+    grid_h = np.arange(grid_size[0], dtype=np.float32) / (grid_size[0] / base_size[0]) / interpolation_scale
+    grid_w = np.arange(grid_size[1], dtype=np.float32) / (grid_size[1] / base_size[1]) / interpolation_scale
+    grid = np.meshgrid(grid_w, grid_h)
+    grid = np.stack(grid, axis=0)
+
+    grid = grid.reshape([2, 1, grid_size[0], grid_size[1]])
+    pos_embed = get_2d_sincos_pos_embed_from_grid(embed_dim, grid)
+    if cls_token and extra_tokens > 0:
+        pos_embed = np.concatenate([np.zeros([extra_tokens, embed_dim]), pos_embed], axis=0)
+    return pos_embed
+
+
+class PatchEmbed(nn.Module):
+
+    def __init__(
+        self,
+        height=224,
+        width=224,
+        patch_size=16,
+        in_channels=3,
+        embed_dim=768,
+        layer_norm=False,
+        flatten=True,
+        bias=True,
+        interpolation_scale=1,
+    ):
+        super().__init__()
+
+        self.flatten = flatten
+        self.layer_norm = layer_norm
+
+        self.proj = nn.Conv2d(
+            in_channels, embed_dim, kernel_size=(patch_size, patch_size), stride=patch_size, bias=bias
+        )
+        if layer_norm:
+            self.norm = nn.LayerNorm(embed_dim, elementwise_affine=False, eps=1e-6)
+        else:
+            self.norm = None
+
+        self.patch_size = patch_size
+        # See:
+        # https://github.com/PixArt-alpha/PixArt-alpha/blob/0f55e922376d8b797edd44d25d0e7464b260dcab/diffusion/model/nets/PixArtMS.py#L161
+        self.height, self.width = height // patch_size, width // patch_size
+        self.base_size = height // patch_size
+        self.interpolation_scale = interpolation_scale
+        pos_embed = get_2d_sincos_pos_embed(
+            embed_dim, (self.height, self.width), base_size=(self.height, self.width), interpolation_scale=self.interpolation_scale
+        )
+        self.register_buffer("pos_embed", torch.from_numpy(pos_embed).float().unsqueeze(0), persistent=False)
+
+    def forward(self, latent):
+        height, width = latent.shape[-2] // self.patch_size, latent.shape[-1] // self.patch_size
+
+        latent = self.proj(latent)
+        if self.flatten:
+            latent = latent.flatten(2).transpose(1, 2)  # BCHW -> BNC
+        if self.layer_norm:
+            latent = self.norm(latent)
+
+        # Interpolate positional embeddings if needed.
+        # (For PixArt-Alpha: https://github.com/PixArt-alpha/PixArt-alpha/blob/0f55e922376d8b797edd44d25d0e7464b260dcab/diffusion/model/nets/PixArtMS.py#L162C151-L162C160)
+        if self.height != height or self.width != width:
+            pos_embed = get_2d_sincos_pos_embed(
+                embed_dim=self.pos_embed.shape[-1],
+                grid_size=(height, width),
+                base_size=(height, width),
+                interpolation_scale=self.interpolation_scale,
+            )
+            pos_embed = torch.from_numpy(pos_embed)
+            pos_embed = pos_embed.float().unsqueeze(0).to(latent.device)
+        else:
+            pos_embed = self.pos_embed
+
+        return (latent + pos_embed).to(latent.dtype)
+
+
+class Attention(nn.Module):
+
+    def __init__(
+        self,
+        heads: int = 8,
+        dim_head: int = 64,
+        dropout: float = 0.0,
+        bias: bool = False,
+        out_bias: bool = True,
+    ):
+        super().__init__()
+
+        self.inner_dim = dim_head * heads
+        self.use_bias = bias
+        self.dropout = dropout
+        self.heads = heads
+
+        self.to_q = nn.Linear(self.inner_dim, self.inner_dim, bias=bias)
+        self.to_k = nn.Linear(self.inner_dim, self.inner_dim, bias=bias)
+        self.to_v = nn.Linear(self.inner_dim, self.inner_dim, bias=bias)
+
+        self.to_out = nn.ModuleList([
+            nn.Linear(self.inner_dim, self.inner_dim, bias=out_bias),
+            nn.Dropout(dropout)
+        ])
+
+    def forward(
+        self,
+        hidden_states: torch.Tensor,
+        encoder_hidden_states: Optional[torch.Tensor] = None,
+    ):
+
+        input_ndim = hidden_states.ndim
+
+        if input_ndim == 4:
+            batch_size, channel, height, width = hidden_states.shape
+            hidden_states = hidden_states.view(batch_size, channel, height * width).transpose(1, 2)
+
+        batch_size = hidden_states.shape[0] if encoder_hidden_states is None else encoder_hidden_states.shape[0]
+
+        query = self.to_q(hidden_states)
+
+        if encoder_hidden_states is None:
+            encoder_hidden_states = hidden_states
+
+        key = self.to_k(encoder_hidden_states)
+        value = self.to_v(encoder_hidden_states)
+
+        inner_dim = key.shape[-1]
+        head_dim = inner_dim // self.heads
+
+        query = query.view(batch_size, -1, self.heads, head_dim).transpose(1, 2)
+        key = key.view(batch_size, -1, self.heads, head_dim).transpose(1, 2)
+        value = value.view(batch_size, -1, self.heads, head_dim).transpose(1, 2)
+
+        hidden_states = F.scaled_dot_product_attention(
+            query, key, value, dropout_p=0.0, is_causal=False
+        )
+
+        hidden_states = hidden_states.transpose(1, 2).reshape(batch_size, -1, self.heads * head_dim)
+        hidden_states = hidden_states.to(query.dtype)
+
+        hidden_states = self.to_out[0](hidden_states)
+        hidden_states = self.to_out[1](hidden_states)
+
+        if input_ndim == 4:
+            hidden_states = hidden_states.transpose(-1, -2).reshape(batch_size, channel, height, width)
+
+        return hidden_states
+
+
+class DiTBlock(nn.Module):
+
+    def __init__(
+        self,
+        dim: int,
+        num_attention_heads: int,
+        attention_head_dim: int,
+        dropout=0.0,
+        activation_fn: str = "geglu",
+        attention_bias: bool = False,
+        norm_elementwise_affine: bool = True,
+        norm_eps: float = 1e-5,
+        final_dropout: bool = False,
+        ff_inner_dim: Optional[int] = None,
+        ff_bias: bool = True,
+        attention_out_bias: bool = True,
+    ):
+        super().__init__()
+
+        self.norm1 = nn.LayerNorm(dim, elementwise_affine=norm_elementwise_affine, eps=norm_eps)
+
+        self.attn1 = Attention(
+            heads=num_attention_heads,
+            dim_head=attention_head_dim,
+            dropout=dropout,
+            bias=attention_bias,
+            out_bias=attention_out_bias,
+        )
+
+        self.norm2 = nn.LayerNorm(dim, norm_eps, norm_elementwise_affine)
+
+        self.attn2 = Attention(
+            heads=num_attention_heads,
+            dim_head=attention_head_dim,
+            dropout=dropout,
+            bias=attention_bias,
+            out_bias=attention_out_bias,
+        )
+
+        self.ff = FeedForward(
+            dim,
+            dropout=dropout,
+            activation_fn=activation_fn,
+            final_dropout=final_dropout,
+            inner_dim=ff_inner_dim,
+            bias=ff_bias,
+        )
+
+        self.scale_shift_table = nn.Parameter(torch.randn(6, dim) / dim**0.5)
+
+    def forward(
+        self,
+        hidden_states: torch.FloatTensor,
+        encoder_hidden_states: Optional[torch.FloatTensor] = None,
+        timestep: Optional[torch.LongTensor] = None,
+        pixel_hidden_states: Optional[torch.FloatTensor] = None,
+    ):
+        batch_size = hidden_states.shape[0]
+
+        shift_msa, scale_msa, gate_msa, shift_mlp, scale_mlp, gate_mlp = (
+            self.scale_shift_table[None] + timestep.reshape(batch_size, 6, -1)
+        ).chunk(6, dim=1)
+        norm_hidden_states = self.norm1(hidden_states)
+        norm_hidden_states = norm_hidden_states * (1 + scale_msa) + shift_msa
+        norm_hidden_states = norm_hidden_states.squeeze(1)
+        hidden_states_len = norm_hidden_states.shape[1]
+        attn_output = self.attn1(
+            torch.cat([pixel_hidden_states, norm_hidden_states], dim=1),
+        )[:, -hidden_states_len:]
+        attn_output = gate_msa * attn_output
+
+        hidden_states = attn_output + hidden_states
+        if hidden_states.ndim == 4:
+            hidden_states = hidden_states.squeeze(1)
+
+        norm_hidden_states = hidden_states
+
+        attn_output = self.attn2(
+            norm_hidden_states,
+            encoder_hidden_states=encoder_hidden_states,
+        )
+        hidden_states = attn_output + hidden_states
+
+        norm_hidden_states = self.norm2(hidden_states)
+        norm_hidden_states = norm_hidden_states * (1 + scale_mlp) + shift_mlp
+
+        ff_output = self.ff(norm_hidden_states)
+
+        ff_output = gate_mlp * ff_output
+
+        hidden_states = ff_output + hidden_states
+        if hidden_states.ndim == 4:
+            hidden_states = hidden_states.squeeze(1)
+
+        return hidden_states
+
+
+class D3D_DiT(nn.Module):
+
+    def __init__(
+        self,
+        num_attention_heads: int = 16,
+        attention_head_dim: int = 72,
+        in_channels: Optional[int] = None,
+        out_channels: Optional[int] = None,
+        num_layers: int = 1,
+        dropout: float = 0.0,
+        attention_bias: bool = False,
+        sample_size: Optional[int] = None,
+        patch_size: Optional[int] = None,
+        activation_fn: str = "gelu-approximate",
+        norm_elementwise_affine: bool = False,
+        norm_eps: float = 1e-6,
+        semantic_channels: int = None,
+        pixel_channels: int = None,
+        interpolation_scale: float = 1.0,
+        gradient_checkpointing: bool = False,
+    ):
+        super().__init__()
+
+        self.num_attention_heads = num_attention_heads
+        self.attention_head_dim = attention_head_dim
+        inner_dim = num_attention_heads * attention_head_dim
+
+        if isinstance(sample_size, int):
+            sample_size = (sample_size, sample_size)
+        self.height = sample_size[0]
+        self.width = sample_size[1]
+
+        self.patch_size = patch_size
+        interpolation_scale = (
+            interpolation_scale if interpolation_scale is not None else max(min(self.config.sample_size) // 32, 1)
+        )
+        self.pos_embed = PatchEmbed(
+            height=sample_size[0],
+            width=sample_size[1],
+            patch_size=patch_size,
+            in_channels=in_channels,
+            embed_dim=inner_dim,
+            interpolation_scale=interpolation_scale,
+        )
+
+        self.transformer_blocks = nn.ModuleList(
+            [
+                DiTBlock(
+                    inner_dim,
+                    num_attention_heads,
+                    attention_head_dim,
+                    dropout=dropout,
+                    activation_fn=activation_fn,
+                    attention_bias=attention_bias,
+                    norm_elementwise_affine=norm_elementwise_affine,
+                    norm_eps=norm_eps,
+                )
+                for d in range(num_layers)
+            ]
+        )
+
+        self.out_channels = in_channels if out_channels is None else out_channels
+        self.norm_out = nn.LayerNorm(inner_dim, elementwise_affine=False, eps=1e-6)
+        self.scale_shift_table = nn.Parameter(torch.randn(2, inner_dim) / inner_dim**0.5)
+        self.proj_out = nn.Linear(inner_dim, patch_size * patch_size * self.out_channels)
+
+        self.adaln_single = AdaLayerNormClassEmb(inner_dim, semantic_channels)
+
+        self.semantic_projection = PixArtAlphaTextProjection(in_features=semantic_channels, hidden_size=inner_dim)
+        self.pixel_projection = PixArtAlphaTextProjection(in_features=pixel_channels, hidden_size=inner_dim)
+
+        self.gradient_checkpointing = gradient_checkpointing
+
+    def forward(
+        self,
+        hidden_states: torch.Tensor,
+        encoder_hidden_states: Optional[torch.Tensor] = None,
+        timestep: Optional[torch.LongTensor] = None,
+        pixel_hidden_states: Optional[torch.Tensor] = None,
+    ):
+        height, width = hidden_states.shape[-2] // self.patch_size, hidden_states.shape[-1] // self.patch_size
+        hidden_states = self.pos_embed(hidden_states)
+
+        timestep, embedded_timestep = self.adaln_single(
+            timestep, class_embedding=encoder_hidden_states[:, 0], hidden_dtype=hidden_states.dtype
+        )
+
+        batch_size = hidden_states.shape[0]
+        encoder_hidden_states = self.semantic_projection(encoder_hidden_states)
+        encoder_hidden_states = encoder_hidden_states.view(batch_size, -1, hidden_states.shape[-1])
+
+        pixel_hidden_states = self.pixel_projection(pixel_hidden_states)
+        pixel_hidden_states = pixel_hidden_states.view(batch_size, -1, hidden_states.shape[-1])
+
+        for block in self.transformer_blocks:
+            if self.training and self.gradient_checkpointing:
+                hidden_states = torch.utils.checkpoint.checkpoint(
+                    block,
+                    hidden_states,
+                    encoder_hidden_states,
+                    timestep,
+                    pixel_hidden_states,
+                )
+            else:
+                hidden_states = block(
+                    hidden_states,
+                    encoder_hidden_states=encoder_hidden_states,
+                    timestep=timestep,
+                    pixel_hidden_states=pixel_hidden_states,
+                )
+
+        shift, scale = (self.scale_shift_table[None] + embedded_timestep[:, None]).chunk(2, dim=1)
+        hidden_states = self.norm_out(hidden_states)
+        hidden_states = hidden_states * (1 + scale) + shift
+        hidden_states = self.proj_out(hidden_states)
+        hidden_states = hidden_states.squeeze(1)
+
+        hidden_states = hidden_states.reshape(
+            shape=(-1, height, width, self.patch_size, self.patch_size, self.out_channels)
+        )
+        hidden_states = torch.einsum("nhwpqc->nchpwq", hidden_states)
+        output = hidden_states.reshape(
+            shape=(-1, self.out_channels, height * self.patch_size, width * self.patch_size)
+        )
+
+        return output
+

direct3d/models/vae.py

+# Modified from https://github.com/huggingface/diffusers/blob/main/src/diffusers/models/autoencoders/vae.py
+
+import trimesh
+import itertools
+import numpy as np
+from tqdm import tqdm
+from einops import rearrange, repeat
+from skimage import measure
+from typing import List, Tuple, Optional, Union
+
+import torch
+import torch.nn as nn
+import torch.nn.functional as F
+
+from direct3d.utils.triplane import sample_from_planes, generate_planes
+from diffusers.models.autoencoders.vae import UNetMidBlock2D
+from diffusers.models.unets.unet_2d_blocks import UpDecoderBlock2D
+
+
+class DiagonalGaussianDistribution(object):
+    def __init__(self, parameters: torch.Tensor, deterministic: bool=False):
+        self.parameters = parameters
+        self.mean, self.logvar = torch.chunk(parameters, 2, dim=1)
+        self.logvar = torch.clamp(self.logvar, -30.0, 20.0)
+        self.deterministic = deterministic
+        self.std = torch.exp(0.5 * self.logvar)
+        self.var = torch.exp(self.logvar)
+        if self.deterministic:
+            self.var = self.std = torch.zeros_like(
+                self.mean, device=self.parameters.device, dtype=self.parameters.dtype
+            )
+
+    def sample(self):
+        x = self.mean + self.std * torch.randn_like(self.mean)
+        return x
+
+    def kl(self, other=None):
+        if self.deterministic:
+            return torch.Tensor([0.])
+        else:
+            if other is None:
+                return 0.5 * torch.mean(torch.pow(self.mean, 2)
+                                        + self.var - 1.0 - self.logvar,
+                                        dim=[1, 2, 3])
+            else:
+                return 0.5 * torch.mean(
+                    torch.pow(self.mean - other.mean, 2) / other.var
+                    + self.var / other.var - 1.0 - self.logvar + other.logvar,
+                    dim=[1, 2, 3])
+
+    def nll(self, sample, dims=(1, 2, 3)):
+        if self.deterministic:
+            return torch.Tensor([0.])
+        logtwopi = np.log(2.0 * np.pi)
+        return 0.5 * torch.sum(
+            logtwopi + self.logvar + torch.pow(sample - self.mean, 2) / self.var,
+            dim=dims)
+
+    def mode(self):
+        return self.mean
+
+
+class FourierEmbedder(nn.Module):
+
+    def __init__(self,
+                 num_freqs: int = 6,
+                 input_dim: int = 3):
+
+        super().__init__()
+        freq = 2.0 ** torch.arange(num_freqs)
+        self.register_buffer("freq", freq, persistent=False)
+        self.num_freqs = num_freqs
+        self.out_dim = input_dim * (num_freqs * 2 + 1)
+
+    def forward(self, x: torch.Tensor):
+        embed = (x[..., None].contiguous() * self.freq).view(*x.shape[:-1], -1)
+        return torch.cat((x, embed.sin(), embed.cos()), dim=-1)
+
+
+class OccDecoder(nn.Module):
+
+    def __init__(self,
+                 n_features: int,
+                 hidden_dim: int = 64,
+                 num_layers: int = 4,
+                 activation: nn.Module = nn.ReLU,
+                 final_activation: str = None):
+        super().__init__()
+
+        self.net = nn.Sequential(
+            nn.Linear(3 * n_features, hidden_dim),
+            activation(),
+            *itertools.chain(*[[
+                nn.Linear(hidden_dim, hidden_dim),
+                activation(),
+            ] for _ in range(num_layers - 2)]),
+            nn.Linear(hidden_dim, 1),
+        )
+        self.final_activation = final_activation
+
+    def forward(self, sampled_features):
+
+        x = rearrange(sampled_features, "N_b N_t N_s C -> N_b N_s (N_t C)")
+        x = self.net(x)
+
+        if self.final_activation is None:
+            pass
+        elif self.final_activation == 'tanh':
+            x = torch.tanh(x)
+        elif self.final_activation == 'sigmoid':
+            x = torch.sigmoid(x)
+        else:
+            raise ValueError(f"Unknown final activation: {self.final_activation}")
+
+        return x[..., 0]
+
+
+class Attention(nn.Module):
+
+    def __init__(self,
+                 dim: int,
+                 heads: int = 8,
+                 dim_head: int = 64):
+        super().__init__()
+        inner_dim = dim_head * heads
+        self.heads = heads
+        self.to_q = nn.Linear(dim, inner_dim, bias=False)
+        self.to_k = nn.Linear(dim, inner_dim, bias=False)
+        self.to_v = nn.Linear(dim, inner_dim, bias=False)
+        self.to_out = nn.Linear(inner_dim, inner_dim)
+
+    def forward(self,
+                hidden_states: torch.Tensor,
+                encoder_hidden_states: Optional[torch.Tensor] = None,
+    ):
+        batch_size = hidden_states.shape[0]
+        if encoder_hidden_states is None:
+            encoder_hidden_states = hidden_states
+        key = self.to_k(encoder_hidden_states)
+        value = self.to_v(encoder_hidden_states)
+        query = self.to_q(hidden_states)
+
+        inner_dim = key.shape[-1]
+        head_dim = inner_dim // self.heads
+
+        query = query.view(batch_size, -1, self.heads, head_dim).transpose(1, 2)
+
+        key = key.view(batch_size, -1, self.heads, head_dim).transpose(1, 2)
+        value = value.view(batch_size, -1, self.heads, head_dim).transpose(1, 2)
+
+        hidden_states = F.scaled_dot_product_attention(
+            query, key, value
+        )
+        hidden_states = hidden_states.transpose(1, 2).reshape(batch_size, -1, self.heads * head_dim)
+        hidden_states = self.to_out(hidden_states)
+
+        return hidden_states
+
+
+class TransformerBlock(nn.Module):
+
+    def __init__(self,
+                 num_attention_heads: int,
+                 attention_head_dim: int,
+                 cross_attention: bool = False):
+        super().__init__()
+        inner_dim = attention_head_dim * num_attention_heads
+        self.norm1 = nn.LayerNorm(inner_dim)
+        if cross_attention:
+            self.norm1_c = nn.LayerNorm(inner_dim)
+        else:
+            self.norm1_c = None
+        self.attn = Attention(inner_dim, num_attention_heads, attention_head_dim)
+        self.norm2 = nn.LayerNorm(inner_dim)
+        self.mlp = nn.Sequential(
+            nn.Linear(inner_dim, 4 * inner_dim),
+            nn.GELU(),
+            nn.Linear(4 * inner_dim, inner_dim),
+        )
+
+    def forward(self, x: torch.Tensor, y: Optional[torch.Tensor] = None):
+        if self.norm1_c is not None:
+            x = self.attn(self.norm1(x), self.norm1_c(y)) + x
+        else:
+            x = self.attn(self.norm1(x)) + x
+        x = x + self.mlp(self.norm2(x))
+        return x
+
+
+class PointEncoder(nn.Module):
+
+    def __init__(self,
+                 num_latents: int,
+                 in_channels: int,
+                 num_attention_heads: int,
+                 attention_head_dim: int,
+                 num_layers: int,
+                 gradient_checkpointing: bool = False):
+
+        super().__init__()
+
+        self.gradient_checkpointing = gradient_checkpointing
+        self.num_latents = num_latents
+        inner_dim = attention_head_dim * num_attention_heads
+
+        self.learnable_token = nn.Parameter(torch.randn((num_latents, inner_dim)) * 0.01)
+
+        self.proj_in = nn.Linear(in_channels, inner_dim)
+        self.cross_attn = TransformerBlock(num_attention_heads, attention_head_dim, cross_attention=True)
+
+        self.self_attn = nn.ModuleList([
+            TransformerBlock(num_attention_heads, attention_head_dim) for _ in range(num_layers)
+        ])
+
+        self.norm_out = nn.LayerNorm(inner_dim)
+
+    def forward(self, pc):
+
+        bs = pc.shape[0]
+        pc = self.proj_in(pc)
+
+        learnable_token = repeat(self.learnable_token, "m c -> b m c", b=bs)
+
+        if self.training and self.gradient_checkpointing:
+            latents = torch.utils.checkpoint.checkpoint(self.cross_attn, learnable_token, pc)
+            for block in self.self_attn:
+                latents = torch.utils.checkpoint.checkpoint(block, latents)
+        else:
+            latents = self.cross_attn(learnable_token, pc)
+            for block in self.self_attn:
+                latents = block(latents)
+
+        latents = self.norm_out(latents)
+
+        return latents
+
+
+class TriplaneDecoder(nn.Module):
+
+    def __init__(
+        self,
+        in_channels: int = 3,
+        out_channels: int = 3,
+        block_out_channels: Tuple[int, ...] = (64,),
+        layers_per_block: int = 2,
+        norm_num_groups: int = 32,
+        act_fn: str = "silu",
+        norm_type: str = "group",
+        mid_block_add_attention=True,
+        gradient_checkpointing: bool = False,
+    ):
+        super().__init__()
+        self.layers_per_block = layers_per_block
+
+        self.conv_in = nn.Conv2d(
+            in_channels,
+            block_out_channels[-1],
+            kernel_size=3,
+            stride=1,
+            padding=1,
+        )
+
+        self.up_blocks = nn.ModuleList([])
+
+        temb_channels = in_channels if norm_type == "spatial" else None
+
+        # mid
+        self.mid_block = UNetMidBlock2D(
+            in_channels=block_out_channels[-1],
+            resnet_eps=1e-6,
+            resnet_act_fn=act_fn,
+            output_scale_factor=1,
+            resnet_time_scale_shift="default" if norm_type == "group" else norm_type,
+            attention_head_dim=block_out_channels[-1],
+            resnet_groups=norm_num_groups,
+            temb_channels=temb_channels,
+            add_attention=mid_block_add_attention,
+        )
+
+        # up
+        reversed_block_out_channels = list(reversed(block_out_channels))
+        output_channel = reversed_block_out_channels[0]
+        for i in range(len(block_out_channels)):
+            prev_output_channel = output_channel
+            output_channel = reversed_block_out_channels[i]
+
+            is_final_block = i == len(block_out_channels) - 1
+            up_block = UpDecoderBlock2D(
+                num_layers=self.layers_per_block + 1,
+                in_channels=prev_output_channel,
+                out_channels=output_channel,
+                add_upsample=not is_final_block,
+                resnet_eps=1e-6,
+                resnet_act_fn=act_fn,
+                resnet_groups=norm_num_groups,
+                resnet_time_scale_shift=norm_type,
+                temb_channels=temb_channels,
+            )
+            self.up_blocks.append(up_block)
+            prev_output_channel = output_channel
+
+        # out
+        if norm_type == "group":
+            self.conv_norm_out = nn.GroupNorm(num_channels=block_out_channels[0], num_groups=norm_num_groups, eps=1e-6)
+        else:
+            raise ValueError(f"Unsupported norm type: {norm_type}")
+
+        self.conv_act = nn.SiLU()
+        self.conv_out = nn.Conv2d(block_out_channels[0], out_channels, 3, padding=1)
+
+        self.gradient_checkpointing = gradient_checkpointing
+
+    def forward(self, sample: torch.Tensor):
+        r"""The forward method of the `Decoder` class."""
+
+        sample = self.conv_in(sample)
+
+        upscale_dtype = next(iter(self.up_blocks.parameters())).dtype
+        if self.training and self.gradient_checkpointing:
+            # middle
+            sample = torch.utils.checkpoint.checkpoint(
+                self.mid_block, sample
+            )
+            sample = sample.to(upscale_dtype)
+
+            # up
+            for up_block in self.up_blocks:
+                sample = torch.utils.checkpoint.checkpoint(up_block, sample)
+        else:
+            # middle
+            sample = self.mid_block(sample)
+            sample = sample.to(upscale_dtype)
+
+            # up
+            for up_block in self.up_blocks:
+                sample = up_block(sample)
+
+        # post-process
+        sample = self.conv_norm_out(sample)
+        sample = self.conv_act(sample)
+        sample = self.conv_out(sample)
+
+        return sample
+
+
+class D3D_VAE(nn.Module):
+    def __init__(self,
+                 triplane_res: int,
+                 latent_dim: int = 0,
+                 triplane_dim: int = 32,
+                 num_freqs: int = 8,
+                 num_attention_heads: int = 12,
+                 attention_head_dim: int = 64,
+                 num_encoder_layers: int = 8,
+                 num_geodecoder_layers: int = 5,
+                 final_activation: str = None,
+                 block_out_channels=[128, 256, 512, 512],
+                 mid_block_add_attention=True,
+                 gradient_checkpointing: bool = False,
+                 latents_scale: float = 1.0,
+                 latents_shift: float = 0.0):
+
+        super().__init__()
+
+        self.gradient_checkpointing = gradient_checkpointing
+
+        self.triplane_res = triplane_res
+        self.num_latents = triplane_res ** 2 * 3
+        self.latent_shape = (latent_dim, triplane_res, 3 * triplane_res)
+        self.latents_scale = latents_scale
+        self.latents_shift = latents_shift
+
+        self.fourier_embedder = FourierEmbedder(num_freqs=num_freqs)
+
+        inner_dim = attention_head_dim * num_attention_heads
+        self.encoder = PointEncoder(
+            num_latents=self.num_latents,
+            in_channels=self.fourier_embedder.out_dim + 3,
+            num_attention_heads=num_attention_heads,
+            attention_head_dim=attention_head_dim,
+            num_layers=num_encoder_layers,
+            gradient_checkpointing=gradient_checkpointing,
+        )
+
+        self.latent_dim = latent_dim
+
+        self.pre_latent = nn.Conv2d(inner_dim, 2 * latent_dim, 1)
+        self.post_latent = nn.Conv2d(latent_dim, inner_dim, 1)
+
+        self.decoder = TriplaneDecoder(
+            in_channels=inner_dim,
+            out_channels=triplane_dim,
+            block_out_channels=block_out_channels,
+            mid_block_add_attention=mid_block_add_attention,
+            gradient_checkpointing=gradient_checkpointing,
+        )
+
+        self.plane_axes = generate_planes()
+        self.occ_decoder = OccDecoder(
+            n_features=triplane_dim,
+            num_layers=num_geodecoder_layers,
+            final_activation=final_activation,
+        )
+
+    def rollout(self, triplane):
+        triplane = rearrange(triplane, "N_b (N_t C) H_t W_t -> N_b C H_t (N_t W_t)", N_t=3)
+        return triplane
+
+    def unrollout(self, triplane):
+        triplane = rearrange(triplane, "N_b C H_t (N_t W_t) -> N_b N_t C H_t W_t", N_t=3)
+        return triplane
+
+    def encode(self,
+               pc: torch.FloatTensor,
+               feats: Optional[torch.FloatTensor] = None):
+
+        x = self.fourier_embedder(pc)
+        if feats is not None:
+            x = torch.cat((x, feats), dim=-1)
+        x = self.encoder(x)
+        x = rearrange(x, "N_b (N_t H_t W_t) C -> N_b (N_t C) H_t W_t",
+                             N_t=3, H_t=self.triplane_res, W_t=self.triplane_res)
+        x = self.rollout(x)
+        moments = self.pre_latent(x)
+
+        posterior = DiagonalGaussianDistribution(moments)
+        latents = posterior.sample()
+
+        return latents, posterior
+
+    def decode(self, z, unrollout=False):
+        z = self.post_latent(z)
+        dec = self.decoder(z)
+        if unrollout:
+            dec = self.unrollout(dec)
+        return dec
+
+    def decode_mesh(self,
+                    latents,
+                    bounds: Union[Tuple[float], List[float], float] = 1.0,
+                    voxel_resolution: int = 512,
+                    mc_threshold: float = 0.0):
+        triplane = self.decode(latents, unrollout=True)
+        mesh = self.triplane2mesh(triplane,
+                                     bounds=bounds,
+                                     voxel_resolution=voxel_resolution,
+                                     mc_threshold=mc_threshold)
+        return mesh
+
+    def triplane2mesh(self,
+                    latents: torch.FloatTensor,
+                    bounds: Union[Tuple[float], List[float], float] = 1.0,
+                    voxel_resolution: int = 512,
+                    mc_threshold: float = 0.0,
+                    chunk_size: int = 50000):
+
+        batch_size = len(latents)
+
+        if isinstance(bounds, float):
+            bounds = [-bounds, -bounds, -bounds, bounds, bounds, bounds]
+        bbox_min, bbox_max = np.array(bounds[0:3]), np.array(bounds[3:6])
+        bbox_length = bbox_max - bbox_min
+
+        x = torch.linspace(bbox_min[0], bbox_max[0], steps=int(voxel_resolution) + 1)
+        y = torch.linspace(bbox_min[1], bbox_max[1], steps=int(voxel_resolution) + 1)
+        z = torch.linspace(bbox_min[2], bbox_max[2], steps=int(voxel_resolution) + 1)
+        xs, ys, zs = torch.meshgrid(x, y, z, indexing='ij')
+        xyz = torch.stack((xs, ys, zs), dim=-1)
+        xyz = xyz.reshape(-1, 3)
+        grid_size = [int(voxel_resolution) + 1, int(voxel_resolution) + 1, int(voxel_resolution) + 1]
+
+        logits_total = []
+        for start in tqdm(range(0, xyz.shape[0], chunk_size), desc="Triplane Sampling:"):
+            positions = xyz[start:start + chunk_size].to(latents.device)
+            positions = repeat(positions, "p d -> b p d", b=batch_size)
+
+            triplane_features = sample_from_planes(self.plane_axes.to(latents.device),
+                                                   latents, positions,
+                                                   box_warp=2.0)
+            logits = self.occ_decoder(triplane_features)
+            logits_total.append(logits)
+
+        logits_total = torch.cat(logits_total, dim=1).view(
+            (batch_size, grid_size[0], grid_size[1], grid_size[2])).cpu().numpy()
+
+        meshes = []
+        for i in range(batch_size):
+            vertices, faces, _, _ = measure.marching_cubes(
+                logits_total[i],
+                mc_threshold,
+                method="lewiner"
+            )
+            vertices = vertices / grid_size * bbox_length + bbox_min
+            faces = faces[:, ::-1]
+            meshes.append(trimesh.Trimesh(vertices, faces))
+        return meshes
+

direct3d/pipeline.py

+# Modified from https://github.com/huggingface/diffusers/blob/main/src/diffusers/pipelines/stable_diffusion/pipeline_stable_diffusion.py
+
+import os
+from tqdm import tqdm
+from PIL import Image
+from omegaconf import OmegaConf
+from huggingface_hub import hf_hub_download
+from typing import Union, List, Optional
+
+import torch
+from direct3d.utils import instantiate_from_config, preprocess
+from diffusers.utils.torch_utils import randn_tensor
+
+
+class Direct3dPipeline(object):
+
+    def __init__(self,
+                 vae,
+                 dit,
+                 semantic_encoder,
+                 pixel_encoder,
+                 scheduler):
+        self.vae = vae
+        self.dit = dit
+        self.semantic_encoder = semantic_encoder
+        self.pixel_encoder = pixel_encoder
+        self.scheduler = scheduler
+
+    def to(self, device):
+        self.device = torch.device(device)
+        self.vae.to(device)
+        self.dit.to(device)
+        self.semantic_encoder.to(device)
+        self.pixel_encoder.to(device)
+
+    @classmethod
+    def from_pretrained(cls,
+                        pipeline_path):
+
+        if os.path.isdir(pipeline_path):
+            config_path = os.path.join(pipeline_path, 'config.yaml')
+            model_path = os.path.join(pipeline_path, 'model.ckpt')
+        else:
+            config_path = hf_hub_download(repo_id=pipeline_path, filename="config.yaml", repo_type="model")
+            model_path = hf_hub_download(repo_id=pipeline_path, filename="model.ckpt", repo_type="model")
+
+        cfg = OmegaConf.load(config_path)
+        state_dict = torch.load(model_path, map_location='cpu')
+
+        vae = instantiate_from_config(cfg.vae)
+        vae.load_state_dict(state_dict["vae"], strict=True)
+        dit = instantiate_from_config(cfg.dit)
+        dit.load_state_dict(state_dict["dit"], strict=True)
+
+        semantic_encoder = instantiate_from_config(cfg.semantic_encoder)
+        pixel_encoder = instantiate_from_config(cfg.pixel_encoder)
+
+        scheduler = instantiate_from_config(cfg.scheduler)
+
+        return cls(
+            vae=vae,
+            dit=dit,
+            semantic_encoder=semantic_encoder,
+            pixel_encoder=pixel_encoder,
+            scheduler=scheduler)
+
+    def prepare_image(self, image: Union[str, List[str], Image.Image, List[Image.Image]], rmbg: bool = True):
+        if not isinstance(image, list):
+            image = [image]
+        if isinstance(image[0], str):
+            image = [Image.open(img) for img in image]
+        image = [preprocess(img, rmbg=rmbg) for img in image]
+        image = torch.stack([img for img in image]).to(self.device)
+        return image
+
+    def encode_image(self, image: torch.Tensor, do_classifier_free_guidance: bool = True):
+        semantic_cond = self.semantic_encoder(image)
+        pixel_cond = self.pixel_encoder(image)
+        if do_classifier_free_guidance:
+            semantic_uncond = torch.zeros_like(semantic_cond)
+            pixel_uncond = torch.zeros_like(pixel_cond)
+            semantic_cond = torch.cat([semantic_uncond, semantic_cond], dim=0)
+            pixel_cond = torch.cat([pixel_uncond, pixel_cond], dim=0)
+
+        return semantic_cond, pixel_cond
+
+    def prepare_latents(self, batch_size, num_channels_latents, height, width, dtype, device, generator):
+        shape = (
+            batch_size,
+            num_channels_latents,
+            height,
+            width,
+        )
+        if isinstance(generator, list) and len(generator) != batch_size:
+            raise ValueError(
+                f"You have passed a list of generators of length {len(generator)}, but requested an effective batch"
+                f" size of {batch_size}. Make sure the batch size matches the length of the generators."
+            )
+
+        latents = randn_tensor(shape, generator=generator, device=device, dtype=dtype)
+        return latents
+
+    @torch.no_grad()
+    def __call__(
+        self,
+        image: Union[str, List[str], Image.Image, List[Image.Image]] = None,
+        num_inference_steps: int = 50,
+        guidance_scale: float = 4.0,
+        generator: Optional[torch.Generator] = None,
+        mc_threshold: float = -2.0,
+        remove_background: bool = True,):
+
+        batch_size = len(image) if isinstance(image, list) else 1
+        do_classifier_free_guidance = guidance_scale > 0
+
+        self.scheduler.set_timesteps(num_inference_steps, device=self.device)
+        timesteps = self.scheduler.timesteps
+
+        image = self.prepare_image(image, remove_background)
+        semantic_cond, pixel_cond = self.encode_image(image, do_classifier_free_guidance)
+        latents = self.prepare_latents(
+            batch_size=batch_size,
+            num_channels_latents=self.vae.latent_shape[0],
+            height=self.vae.latent_shape[1],
+            width=self.vae.latent_shape[2],
+            dtype=image.dtype,
+            device=self.device,
+            generator=generator,
+        )
+
+        extra_step_kwargs = {
+            "generator": generator
+        }
+
+        for i, t in enumerate(tqdm(timesteps, desc="Diffusion Sampling:")):
+            latent_model_input = torch.cat([latents] * 2) if do_classifier_free_guidance else latents
+            latent_model_input = self.scheduler.scale_model_input(latent_model_input, t)
+
+            t = t.expand(latent_model_input.shape[0])
+
+            noise_pred = self.dit(
+                hidden_states=latent_model_input,
+                timestep=t,
+                encoder_hidden_states=semantic_cond,
+                pixel_hidden_states=pixel_cond,
+            )
+
+            if do_classifier_free_guidance:
+                noise_pred_uncond, noise_pred_text = noise_pred.chunk(2)
+                noise_pred = noise_pred_uncond + guidance_scale * (noise_pred_text - noise_pred_uncond)
+
+            latents = self.scheduler.step(noise_pred, t, latents, **extra_step_kwargs, return_dict=False)[0]
+
+        latents = 1. / self.vae.latents_scale * latents + self.vae.latents_shift
+        meshes = self.vae.decode_mesh(latents, mc_threshold=mc_threshold)
+        outputs = {"meshes": meshes, "latents": latents}
+
+        return outputs
+
\ No newline at end of file

direct3d/utils/__init__.py

+from .util import instantiate_from_config, get_obj_from_str
+from .image import preprocess
\ No newline at end of file
