Merge branch 'develop' of github.com:ROCmSoftwarePlatform/AMDMIGraphX into...

Merge branch 'develop' of github.com:ROCmSoftwarePlatform/AMDMIGraphX into split_multiple_same_dyn_dim

.github/workflows/ci.yaml

@@ -465,7 +465,7 @@ jobs:
     - name: Upload code coverage
       if: "matrix.configuration == 'codecov'"
       env:
-        CODECOV_TOKEN: "8545af1c-f90b-4345-92a5-0d075503ca56"
+        CODECOV_TOKEN: "f5d5a10b-3177-4c76-b25f-9b1c2f165e8b"
       run: |
         sudo apt-get install -y lcov
         cd build

Jenkinsfile

@@ -22,6 +22,8 @@ def rocmtestnode(Map conf) {
         def cmd = """
             ulimit -c unlimited
             echo "leak:dnnl::impl::malloc" > suppressions.txt
+            echo "leak:libtbb.so" >> suppressions.txt
+            cat suppressions.txt
             export LSAN_OPTIONS="suppressions=\$(pwd)/suppressions.txt"
             export MIGRAPHX_GPU_DEBUG=${gpu_debug}
             export CXX=${compiler}

examples/README.md

@@ -6,4 +6,5 @@ This directory contains examples of common use cases for MIGraphX.
 ## Examples:
 - [MIGraphX usage and utilities](./migraphx)
 - [Vision inference examples](./vision)
-- [Natural language inference examples](./nlp)
\ No newline at end of file
+- [Natural language inference examples](./nlp)
+- [Diffusion inference examples](./diffusion)

examples/diffusion/README.md

+# Diffusion Inference Examples
+
+- [Python Stable Diffusion 2.1](./python_stable_diffusion_21)

examples/diffusion/python_stable_diffusion_21/README.md

+# Stable Diffusion 2.1
+
+This version was tested with [rocm 5.7](https://github.com/ROCmSoftwarePlatform/AMDMIGraphX/tree/rocm-5.7.0) revision.
+
+## Jupyter notebook
+
+There is a dedicated step-by-step notebook. See [sd21.ipynb](./sd21.ipynb)
+
+## Console application
+
+To run the console application, follow these steps below.
+
+Setup python environment
+
+```bash
+# this will require the python venv to installed (e.g. apt install python3.8-venv)
+python3 -m venv sd_venv
+. sd_venv/bin/activate
+```
+
+Install dependencies
+
+```bash
+pip install -r requirements.txt
+```
+
+Use MIGraphX Python Module
+
+```bash
+export PYTHONPATH=/opt/rocm/lib:$PYTHONPATH
+```
+
+Get models with optimum
+
+```bash
+optimum-cli export onnx --model stabilityai/stable-diffusion-2-1 models/sd21-onnx
+```
+*Note: `models/sd21-onnx` will be used in the scripts.*
+
+Run the text-to-image script with the following example prompt and seed:
+
+```bash
+python txt2img.py --prompt "a photograph of an astronaut riding a horse" --seed 13 --output astro_horse.jpg
+```
+*Note: The first run will compile the models and cache them to make subsequent runs faster.*
+
+The result should look like this:
+
+![example_output.jpg](./example_output.jpg)
+
+## Gradio application
+
+Note: requires `Console application` to work
+
+Install gradio dependencies
+
+```bash
+pip install -r gradio_requirements.txt
+```
+
+Usage
+
+```bash
+python gradio_app.py
+```
+
+This will load the models (which can take several minutes), and when the setup is ready, starts a server on `http://127.0.0.1:7860`.

examples/diffusion/python_stable_diffusion_21/gradio_app.py

+#####################################################################################
+# The MIT License (MIT)
+#
+# Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+#
+# Permission is hereby granted, free of charge, to any person obtaining a copy
+# of this software and associated documentation files (the "Software"), to deal
+# in the Software without restriction, including without limitation the rights
+# to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+# copies of the Software, and to permit persons to whom the Software is
+# furnished to do so, subject to the following conditions:
+#
+# The above copyright notice and this permission notice shall be included in
+# all copies or substantial portions of the Software.
+#
+# THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+# IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+# FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+# AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+# LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+# OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+# THE SOFTWARE.
+#####################################################################################
+
+from txt2img import StableDiffusionMGX
+import gradio as gr
+
+
+def main():
+    # Note: This will load the models, which can take several minutes
+    sd = StableDiffusionMGX()
+
+    def gr_wrapper(prompt, negative_prompt, steps, seed, scale):
+        result = sd.run(str(prompt), str(negative_prompt), int(steps),
+                        int(seed), float(scale))
+        return StableDiffusionMGX.convert_to_rgb_image(result)
+
+    demo = gr.Interface(
+        gr_wrapper,
+        [
+            gr.Textbox(value="a photograph of an astronaut riding a horse",
+                       label="Prompt"),
+            gr.Textbox(value="", label="Negative prompt (Optional)"),
+            gr.Slider(1, 100, step=1, value=20, label="Number of steps"),
+            gr.Textbox(value=13, label="Random seed"),
+            gr.Slider(1, 20, step=0.1, value=7.0, label="Guidance scale"),
+        ],
+        "image",
+    )
+    demo.launch()
+
+
+if __name__ == "__main__":
+    main()

examples/diffusion/python_stable_diffusion_21/gradio_reqirements.txt

+#####################################################################################
+# The MIT License (MIT)
+#
+# Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+#
+# Permission is hereby granted, free of charge, to any person obtaining a copy
+# of this software and associated documentation files (the "Software"), to deal
+# in the Software without restriction, including without limitation the rights
+# to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+# copies of the Software, and to permit persons to whom the Software is
+# furnished to do so, subject to the following conditions:
+#
+# The above copyright notice and this permission notice shall be included in
+# all copies or substantial portions of the Software.
+#
+# THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+# IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+# FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+# AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+# LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+# OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+# THE SOFTWARE.
+#####################################################################################
+-f requirements.txt
+gradio
\ No newline at end of file

examples/diffusion/python_stable_diffusion_21/requirements.txt

+#####################################################################################
+# The MIT License (MIT)
+#
+# Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+#
+# Permission is hereby granted, free of charge, to any person obtaining a copy
+# of this software and associated documentation files (the "Software"), to deal
+# in the Software without restriction, including without limitation the rights
+# to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+# copies of the Software, and to permit persons to whom the Software is
+# furnished to do so, subject to the following conditions:
+#
+# The above copyright notice and this permission notice shall be included in
+# all copies or substantial portions of the Software.
+#
+# THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+# IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+# FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+# AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+# LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+# OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+# THE SOFTWARE.
+#####################################################################################
+accelerate
+diffusers
+optimum[onnxruntime]
+transformers
\ No newline at end of file

examples/diffusion/python_stable_diffusion_21/sd21.ipynb

+{
+ "cells": [
+  {
+   "cell_type": "code",
+   "execution_count": 2,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "#  The MIT License (MIT)\n",
+    "#\n",
+    "#  Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.\n",
+    "#\n",
+    "#  Permission is hereby granted, free of charge, to any person obtaining a copy\n",
+    "#  of this software and associated documentation files (the 'Software'), to deal\n",
+    "#  in the Software without restriction, including without limitation the rights\n",
+    "#  to use, copy, modify, merge, publish, distribute, sublicense, and/or sell\n",
+    "#  copies of the Software, and to permit persons to whom the Software is\n",
+    "#  furnished to do so, subject to the following conditions:\n",
+    "#\n",
+    "#  The above copyright notice and this permission notice shall be included in\n",
+    "#  all copies or substantial portions of the Software.\n",
+    "#\n",
+    "#  THE SOFTWARE IS PROVIDED 'AS IS', WITHOUT WARRANTY OF ANY KIND, EXPRESS OR\n",
+    "#  IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,\n",
+    "#  FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE\n",
+    "#  AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER\n",
+    "#  LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,\n",
+    "#  OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN\n",
+    "#  THE SOFTWARE."
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "# Stable Diffusion 2.1\n",
+    "\n",
+    "The following example will show how to run `Stable Diffusion 2.1` with `MIGraphX`."
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Install the required dependencies."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Install dependencies\n",
+    "!pip install optimum[onnxruntime] transformers diffusers accelerate"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "We will use optimum to generate the onnx files."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# export models\n",
+    "!optimum-cli export onnx --model stabilityai/stable-diffusion-2-1 models/sd21-onnx"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Now it is time to load these models with python.\n",
+    "\n",
+    "First, we make sure that MIGraphX module is found in the python path."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "import sys\n",
+    "mgx_lib_path = \"/opt/rocm/lib/\" # or \"/code/AMDMIGraphX/build/lib/\"\n",
+    "if mgx_lib_path not in sys.path:\n",
+    "    sys.path.append(mgx_lib_path)\n",
+    "import migraphx as mgx"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Next, a helper method to load and cache the models.\n",
+    "\n",
+    "This will use the `models/sd21-onnx` path. If you changed it, make sure to update here as well."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "import os\n",
+    "# helper for model loading\n",
+    "def load_mgx_model(name, shapes):\n",
+    "    file = f\"models/sd21-onnx/{name}/model\"\n",
+    "    print(f\"Loading {name} model from {file}\")\n",
+    "    if os.path.isfile(f\"{file}.mxr\"):\n",
+    "        print(f\"Found mxr, loading it...\")\n",
+    "        model = mgx.load(f\"{file}.mxr\", format=\"msgpack\")\n",
+    "    elif os.path.isfile(f\"{file}.onnx\"):\n",
+    "        print(f\"Parsing from onnx file...\")\n",
+    "        model = mgx.parse_onnx(f\"{file}.onnx\", map_input_dims=shapes)\n",
+    "        model.compile(mgx.get_target(\"gpu\"))\n",
+    "        print(f\"Saving {name} model to mxr file...\")\n",
+    "        mgx.save(model, f\"{file}.mxr\", format=\"msgpack\")\n",
+    "    else:\n",
+    "        print(f\"No {name} model found. Please verify the path is correct and re-try, or re-download model.\")\n",
+    "        os.exit(1)\n",
+    "    return model"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "With that, we can load the models. This could take several minutes."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "text_encoder = load_mgx_model(\"text_encoder\", {\"input_ids\": [1, 77]})"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "unet = load_mgx_model(\n",
+    "        \"unet\", {\n",
+    "            \"sample\": [1, 4, 64, 64],\n",
+    "            \"encoder_hidden_states\": [1, 77, 1024],\n",
+    "            \"timestep\": [1],\n",
+    "        })"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "vae = load_mgx_model(\"vae_decoder\", {\"latent_sample\": [1, 4, 64, 64]})"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Import the remaining packages."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "from diffusers import EulerDiscreteScheduler\n",
+    "from transformers import CLIPTokenizer\n",
+    "import torch\n",
+    "import numpy as np\n",
+    "from tqdm.auto import tqdm\n",
+    "from PIL import Image"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Time to load the scheduler and tokenizer from the original source."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "model_id = \"stabilityai/stable-diffusion-2-1\"\n",
+    "scheduler = EulerDiscreteScheduler.from_pretrained(model_id,\n",
+    "                                                   subfolder=\"scheduler\")\n",
+    "tokenizer = CLIPTokenizer.from_pretrained(model_id, subfolder=\"tokenizer\")"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Next, we will define all the steps one by one, to make the last step short and simple.\n",
+    "\n",
+    "The first step will be to tokenize the user prompt. It will make a `(1, 77)` shaped `input_ids`."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def tokenize(input):\n",
+    "    return tokenizer([input],\n",
+    "                     padding=\"max_length\",\n",
+    "                     max_length=tokenizer.model_max_length,\n",
+    "                     truncation=True,\n",
+    "                     return_tensors=\"np\")"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "test_tk = tokenize(\"test tokenizer to see the tokens\")\n",
+    "test_tk.input_ids.shape"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "We run the tokenized prompt through the `Text Encoder` model. It expects the `(1, 77)` data as `int32`."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "text_encoder.get_parameter_shapes()"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def get_embeddings(input):\n",
+    "    return np.array(\n",
+    "        text_encoder.run({\"input_ids\": input.input_ids.astype(np.int32)\n",
+    "                          })[0]).astype(np.float32)"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "test_emb = get_embeddings(tokenize(\"test tokenizer to see the tokens\"))\n",
+    "test_emb.shape"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "The other input of the model is latent representation (pure noise). It will be transformed into a 512x512 image later.\n",
+    "The last input will be the timestep."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def generate_latents(seed):\n",
+    "    return torch.randn(\n",
+    "        (1, 4, 64, 64),\n",
+    "        generator=torch.manual_seed(seed),\n",
+    "    )"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "test_latents = generate_latents(42)\n",
+    "latents.shape"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Now we add two helpers to access and convert from torch to numpy with the proper datatype."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def get_scaled_sample(latents, t):\n",
+    "    return scheduler.scale_model_input(latents, t).numpy().astype(np.float32)\n",
+    "\n",
+    "\n",
+    "def get_timestep(t):\n",
+    "    return np.atleast_1d(t.numpy().astype(np.int64))  # convert 0D -> 1D"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "The UNet model will be run in a loop. It will predict the noise residual."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "# Optional\n",
+    "unet.get_parameter_shapes()"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def denoise(sample, embeddings, timestep):\n",
+    "    return np.array(\n",
+    "        unet.run({\n",
+    "            \"sample\": sample,\n",
+    "            \"encoder_hidden_states\": embeddings,\n",
+    "            \"timestep\": timestep\n",
+    "        })[0])"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Helpers to do the classifier-free guidance and computing the previous noisy sample."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def perform_guidance(noise_pred_uncond, noise_pred_text, scale):\n",
+    "    return noise_pred_uncond + scale * (noise_pred_text - noise_pred_uncond)\n",
+    "\n",
+    "def compute_previous(noise_pred, t, latents):\n",
+    "    # compute the previous noisy sample x_t -> x_t-1\n",
+    "    return scheduler.step(noise_pred, t, latents).prev_sample\n"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Scale and decode the image latents with VAE."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def scale_denoised(latents):\n",
+    "    return 1 / 0.18215 * latents\n",
+    "\n",
+    "\n",
+    "def decode(latents):\n",
+    "    return np.array(\n",
+    "        vae.run({\"latent_sample\": latents.numpy().astype(np.float32)})[0])"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "And lastly, we need to convert it to an image to display or save."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "def convert_to_rgb_image(image):\n",
+    "    image = np.clip(image / 2 + 0.5, 0, 1)\n",
+    "    image = np.transpose(image, (0, 2, 3, 1))\n",
+    "    images = (image * 255).round().astype(\"uint8\")\n",
+    "    return Image.fromarray(images[0])\n",
+    "\n",
+    "def save_image(pil_image, filename=\"output.png\"):\n",
+    "    pil_image.save(filename, format=\"png\")"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "Feel free to play around with these params."
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "prompt = \"a photograph of an astronaut riding a horse\"\n",
+    "negative_prompt = \"\"\n",
+    "steps = 20\n",
+    "seed = 13\n",
+    "scale = 7.0"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "And now, to put everything together and run the whole pipeline:"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "scheduler.set_timesteps(steps)\n",
+    "\n",
+    "text_input, uncond_input = tokenize(prompt), tokenize(negative_prompt)\n",
+    "text_embeddings, uncond_embeddings = get_embeddings(\n",
+    "    text_input), get_embeddings(uncond_input)\n",
+    "latents = generate_latents(seed) * scheduler.init_noise_sigma\n",
+    "\n",
+    "for t in tqdm(scheduler.timesteps):\n",
+    "    sample = get_scaled_sample(latents, t)\n",
+    "    timestep = get_timestep(t)\n",
+    "\n",
+    "    noise_pred_uncond = denoise(sample, uncond_embeddings, timestep)\n",
+    "    noise_pred_text = denoise(sample, text_embeddings, timestep)\n",
+    "\n",
+    "    noise_pred = perform_guidance(noise_pred_uncond, noise_pred_text, scale)\n",
+    "    latents = compute_previous(torch.from_numpy(noise_pred), t, latents)\n",
+    "\n",
+    "latents = scale_denoised(latents)\n",
+    "result = decode(latents)\n",
+    "image = convert_to_rgb_image(result)\n",
+    "\n",
+    "# show the image\n",
+    "image"
+   ]
+  },
+  {
+   "cell_type": "markdown",
+   "metadata": {},
+   "source": [
+    "If you like the generated image, save it with the following:"
+   ]
+  },
+  {
+   "cell_type": "code",
+   "execution_count": null,
+   "metadata": {},
+   "outputs": [],
+   "source": [
+    "save_image(image, \"output.png\")"
+   ]
+  }
+ ],
+ "metadata": {
+  "kernelspec": {
+   "display_name": "sd_venv",
+   "language": "python",
+   "name": "python3"
+  },
+  "language_info": {
+   "codemirror_mode": {
+    "name": "ipython",
+    "version": 3
+   },
+   "file_extension": ".py",
+   "mimetype": "text/x-python",
+   "name": "python",
+   "nbconvert_exporter": "python",
+   "pygments_lexer": "ipython3",
+   "version": "3.10.12"
+  }
+ },
+ "nbformat": 4,
+ "nbformat_minor": 2
+}

examples/diffusion/python_stable_diffusion_21/txt2img.py

+#  The MIT License (MIT)
+#
+#  Copyright (c) 2015-2023 Advanced Micro Devices, Inc. All rights reserved.
+#
+#  Permission is hereby granted, free of charge, to any person obtaining a copy
+#  of this software and associated documentation files (the 'Software'), to deal
+#  in the Software without restriction, including without limitation the rights
+#  to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+#  copies of the Software, and to permit persons to whom the Software is
+#  furnished to do so, subject to the following conditions:
+#
+#  The above copyright notice and this permission notice shall be included in
+#  all copies or substantial portions of the Software.
+#
+#  THE SOFTWARE IS PROVIDED 'AS IS', WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+#  IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+#  FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+#  AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+#  LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+#  OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+#  THE SOFTWARE.
+
+from argparse import ArgumentParser
+from diffusers import EulerDiscreteScheduler
+from transformers import CLIPTokenizer
+from PIL import Image
+
+import migraphx as mgx
+import numpy as np
+import os
+import torch
+import time
+from functools import wraps
+
+
+# measurement helper
+def measure(fn):
+    @wraps(fn)
+    def measure_ms(*args, **kwargs):
+        start_time = time.perf_counter_ns()
+        result = fn(*args, **kwargs)
+        end_time = time.perf_counter_ns()
+        print(f"Elapsed time: {(end_time - start_time) * 1e-6:.4f} ms\n")
+        return result
+
+    return measure_ms
+
+
+def get_args():
+    parser = ArgumentParser()
+    parser.add_argument(
+        "-s",
+        "--seed",
+        type=int,
+        default=42,
+        help="Random seed",
+    )
+
+    parser.add_argument(
+        "-t",
+        "--steps",
+        type=int,
+        default=20,
+        help="Number of steps",
+    )
+
+    parser.add_argument(
+        "-p",
+        "--prompt",
+        type=str,
+        required=True,
+        help="Prompt",
+    )
+
+    parser.add_argument(
+        "-n",
+        "--negative-prompt",
+        type=str,
+        default="",
+        help="Negative prompt",
+    )
+
+    parser.add_argument(
+        "--scale",
+        type=float,
+        default=7.0,
+        help="Guidance scale",
+    )
+
+    parser.add_argument(
+        "-o",
+        "--output",
+        type=str,
+        default=None,
+        help="Output name",
+    )
+    return parser.parse_args()
+
+
+class StableDiffusionMGX():
+    def __init__(self):
+        model_id = "stabilityai/stable-diffusion-2-1"
+        print(f"Using {model_id}")
+
+        print("Creating EulerDiscreteScheduler scheduler")
+        self.scheduler = EulerDiscreteScheduler.from_pretrained(
+            model_id, subfolder="scheduler")
+
+        print("Creating CLIPTokenizer tokenizer...")
+        self.tokenizer = CLIPTokenizer.from_pretrained(model_id,
+                                                       subfolder="tokenizer")
+
+        print("Load models...")
+        self.vae = StableDiffusionMGX.load_mgx_model(
+            "vae_decoder", {"latent_sample": [1, 4, 64, 64]})
+        self.text_encoder = StableDiffusionMGX.load_mgx_model(
+            "text_encoder", {"input_ids": [1, 77]})
+        self.unet = StableDiffusionMGX.load_mgx_model(
+            "unet", {
+                "sample": [1, 4, 64, 64],
+                "encoder_hidden_states": [1, 77, 1024],
+                "timestep": [1],
+            })
+
+    def run(self, prompt, negative_prompt, steps, seed, scale):
+        # need to set this for each run
+        self.scheduler.set_timesteps(steps)
+
+        print("Tokenizing prompt...")
+        text_input = self.tokenize(prompt)
+
+        print("Creating text embeddings for prompt...")
+        text_embeddings = self.get_embeddings(text_input)
+
+        print("Tokenizing negative prompt...")
+        uncond_input = self.tokenize(negative_prompt)
+
+        print("Creating text embeddings for negative prompt...")
+        uncond_embeddings = self.get_embeddings(uncond_input)
+
+        print(
+            f"Creating random input data ({1}x{4}x{64}x{64}) (latents) with seed={seed}..."
+        )
+        latents = torch.randn((1, 4, 64, 64),
+                              generator=torch.manual_seed(seed))
+
+        print("Apply initial noise sigma\n")
+        latents = latents * self.scheduler.init_noise_sigma
+
+        print("Running denoising loop...")
+        for step, t in enumerate(self.scheduler.timesteps):
+            print(f"#{step}/{len(self.scheduler.timesteps)} step")
+            latents = self.denoise_step(text_embeddings, uncond_embeddings,
+                                        latents, t, scale)
+
+        print("Scale denoised result...")
+        latents = 1 / 0.18215 * latents
+
+        print("Decode denoised result...")
+        image = self.decode(latents)
+
+        return image
+
+    @staticmethod
+    @measure
+    def load_mgx_model(name, shapes):
+        file = f"models/sd21-onnx/{name}/model"
+        print(f"Loading {name} model from {file}")
+        if os.path.isfile(f"{file}.mxr"):
+            print("Found mxr, loading it...")
+            model = mgx.load(f"{file}.mxr", format="msgpack")
+        elif os.path.isfile(f"{file}.onnx"):
+            print("Parsing from onnx file...")
+            model = mgx.parse_onnx(f"{file}.onnx", map_input_dims=shapes)
+            model.compile(mgx.get_target("gpu"))
+            print(f"Saving {name} model to mxr file...")
+            mgx.save(model, f"{file}.mxr", format="msgpack")
+        else:
+            print(f"No {name} model found. Please download it and re-try.")
+            os.exit(1)
+        return model
+
+    @measure
+    def tokenize(self, input):
+        return self.tokenizer([input],
+                              padding="max_length",
+                              max_length=self.tokenizer.model_max_length,
+                              truncation=True,
+                              return_tensors="np")
+
+    @measure
+    def get_embeddings(self, input):
+        return np.array(
+            self.text_encoder.run(
+                {"input_ids":
+                 input.input_ids.astype(np.int32)})[0]).astype(np.float32)
+
+    @staticmethod
+    def convert_to_rgb_image(image):
+        image = np.clip(image / 2 + 0.5, 0, 1)
+        image = np.transpose(image, (0, 2, 3, 1))
+        images = (image * 255).round().astype("uint8")
+        return Image.fromarray(images[0])
+
+    @staticmethod
+    def save_image(pil_image, filename="output.png"):
+        pil_image.save(filename)
+
+    @measure
+    def denoise_step(self, text_embeddings, uncond_embeddings, latents, t,
+                     scale):
+        sample = self.scheduler.scale_model_input(latents,
+                                                  t).numpy().astype(np.float32)
+        timestep = np.atleast_1d(t.numpy().astype(
+            np.int64))  # convert 0D -> 1D
+
+        noise_pred_uncond = np.array(
+            self.unet.run({
+                "sample": sample,
+                "encoder_hidden_states": uncond_embeddings,
+                "timestep": timestep
+            })[0])
+
+        noise_pred_text = np.array(
+            self.unet.run({
+                "sample": sample,
+                "encoder_hidden_states": text_embeddings,
+                "timestep": timestep
+            })[0])
+
+        # perform guidance
+        noise_pred = noise_pred_uncond + scale * (noise_pred_text -
+                                                  noise_pred_uncond)
+
+        # compute the previous noisy sample x_t -> x_t-1
+        return self.scheduler.step(torch.from_numpy(noise_pred), t,
+                                   latents).prev_sample
+
+    @measure
+    def decode(self, latents):
+        return np.array(
+            self.vae.run({"latent_sample":
+                          latents.numpy().astype(np.float32)})[0])
+
+
+if __name__ == "__main__":
+    args = get_args()
+
+    sd = StableDiffusionMGX()
+    result = sd.run(args.prompt, args.negative_prompt, args.steps, args.seed,
+                    args.scale)
+
+    print("Convert result to rgb image...")
+    image = StableDiffusionMGX.convert_to_rgb_image(result)
+    filename = args.output if args.output else f"output_s{args.seed}_t{args.steps}.png"
+    StableDiffusionMGX.save_image(image, args.output)
+    print(f"Image saved to {filename}")

src/CMakeLists.txt

@@ -28,6 +28,7 @@ include(ROCMInstallTargets)
 include(ROCMPackageConfigHelpers)
 include(RegisterOp)
 include(CheckCXXLinkerFlag)
+include(CheckCXXSourceCompiles)

 add_library(migraphx
     adjust_allocation.cpp
@@ -263,6 +264,50 @@ endif()
 target_include_directories(migraphx SYSTEM PUBLIC $<BUILD_INTERFACE:${HALF_INCLUDE_DIR}>)
 target_link_libraries(migraphx PUBLIC Threads::Threads)

+function(check_execution_par RESULT)
+    set(CMAKE_REQUIRED_LIBRARIES ${ARGN})
+    set(CMAKE_REQUIRED_FLAGS)
+    if(NOT MSVC)
+        set(CMAKE_REQUIRED_FLAGS "-std=c++17")
+    endif()
+    string(MD5 _flags_hash "${CMAKE_REQUIRED_FLAGS} ${CMAKE_REQUIRED_LIBRARIES}")
+    set(_source "
+#include <execution>
+
+int main() {
+    int* i = nullptr;
+    std::sort(std::execution::par, i, i);
+}
+")
+    check_cxx_source_compiles("${_source}" _has_execution_${_flags_hash})
+    set(${RESULT} ${_has_execution_${_flags_hash}} PARENT_SCOPE)
+endfunction()
+
+set(MIGRAPHX_HAS_EXECUTORS_DEFAULT Off)
+find_package(TBB QUIET)
+if(TBB_FOUND)
+    check_execution_par(TBB_HAS_EXECUTION_PAR TBB::tbb)
+    if(TBB_HAS_EXECUTION_PAR)
+        target_link_libraries(migraphx PUBLIC TBB::tbb)
+        set(MIGRAPHX_HAS_EXECUTORS_DEFAULT On)
+        message(STATUS "Using TBB for parallel execution")
+    endif()
+else()
+    check_execution_par(HAS_EXECUTION_PAR)
+    if(HAS_EXECUTION_PAR)
+        set(MIGRAPHX_HAS_EXECUTORS_DEFAULT On)
+    endif()
+endif()
+
+option(MIGRAPHX_HAS_EXECUTORS "C++ supports parallel executors" ${MIGRAPHX_HAS_EXECUTORS_DEFAULT})
+if(MIGRAPHX_HAS_EXECUTORS)
+    message("Parallel STL enabled")
+    target_compile_definitions(migraphx PUBLIC MIGRAPHX_HAS_EXECUTORS=1)
+else()
+    message("Parallel STL disabled")
+    target_compile_definitions(migraphx PUBLIC MIGRAPHX_HAS_EXECUTORS=0)
+endif()
+
 find_package(nlohmann_json 3.8.0 REQUIRED)
 target_link_libraries(migraphx PRIVATE nlohmann_json::nlohmann_json)
 migraphx_generate_export_header(migraphx)

src/include/migraphx/op/binary.hpp

@@ -29,6 +29,7 @@
 #include <migraphx/argument.hpp>
 #include <migraphx/value.hpp>
 #include <migraphx/dyn_output.hpp>
+#include <migraphx/par.hpp>

 namespace migraphx {
 inline namespace MIGRAPHX_INLINE_NS {
@@ -95,11 +96,11 @@ struct binary : op_name<Derived>
     {
         argument result{dyn_out.computed_shape};
         visit_all(result, args[0], args[1])([&](auto output, auto input1, auto input2) {
-            std::transform(input1.begin(),
-                           input1.end(),
-                           input2.begin(),
-                           output.begin(),
-                           static_cast<const Derived&>(*this).apply());
+            par_transform(input1.begin(),
+                          input1.end(),
+                          input2.begin(),
+                          output.begin(),
+                          static_cast<const Derived&>(*this).apply());
         });
         return result;
     }

src/include/migraphx/op/pooling.hpp

@@ -70,7 +70,8 @@ struct pooling
     // 2 smaller than the input tensor rank (NCHW layout)
     std::vector<std::size_t> lengths = {1, 1};

-    // Dilations are not supported at this time.
+    // Spacing between the elements of the pooling kernel. Must be the same ndim as lengths.
+    std::vector<std::size_t> dilations = {1, 1};

     // ceiling mode is a flag affecting output size
     // or equivalently, placements of the pooling kernel.
@@ -99,6 +100,7 @@ struct pooling
                     f(self.padding_mode, "padding_mode"),
                     f(self.stride, "stride"),
                     f(self.lengths, "lengths"),
+                    f(self.dilations, "dilations"),
                     f(self.ceil_mode, "ceil_mode"),
                     f(self.lp_order, "lp_order"),
                     f(self.dyn_global, "dyn_global"));
@@ -112,14 +114,17 @@ struct pooling
             return;
         if((padding_mode != default_ and padding.size() != stride.size() and
             (padding.size()) != stride.size() * 2) or
-           stride.size() != lengths.size())
+           stride.size() != lengths.size() or dilations.size() != lengths.size())
         {
             MIGRAPHX_THROW("POOLING: inconsistent attribute sizes");
         }
-        if(std::any_of(lengths.begin(), lengths.end(), [&](auto i) { return (i == 0); }) or
-           std::any_of(stride.begin(), stride.end(), [&](auto i) { return (i == 0); }))
+
+        const auto is_zero = [](auto el) { return el == 0; };
+        if(std::any_of(lengths.begin(), lengths.end(), is_zero) or
+           std::any_of(stride.begin(), stride.end(), is_zero) or
+           std::any_of(dilations.begin(), dilations.end(), is_zero))
         {
-            MIGRAPHX_THROW("POOLING: size 0 pooling kernel or stride");
+            MIGRAPHX_THROW("POOLING: size 0 pooling kernel or stride or dilations");
         }

         // TODO:  update lowering to run the reference
@@ -142,6 +147,11 @@ struct pooling

     value attributes() const { return {{"normalize_padding", "padding"}}; }

+    inline std::size_t dilate_dim(std::size_t dim, std::size_t dilation) const
+    {
+        return 1 + dilation * (dim - 1);
+    }
+
     std::vector<std::size_t> calc_spatial_dim_out(const std::vector<std::size_t>& input_lens,
                                                   std::size_t kdims) const
     {
@@ -151,8 +161,9 @@ struct pooling
             std::size_t padding_factor = 2 * padding[i];
             if(padding.size() == 2 * kdims)
                 padding_factor = padding[i] + padding[i + kdims];
+            std::size_t dilated_length = dilate_dim(lengths[i], dilations[i]);
             std::size_t dim_size;
-            if(input_lens[i + 2] + padding_factor < lengths[i])
+            if(input_lens[i + 2] + padding_factor < dilated_length)
             {
                 if(padding_mode == default_)
                     MIGRAPHX_THROW("POOLING: not enough padding for the given kernel size");
@@ -162,7 +173,7 @@ struct pooling
             }
             else
             {
-                dim_size = input_lens[i + 2] + padding_factor - lengths[i];
+                dim_size = input_lens[i + 2] + padding_factor - dilated_length;
             }
             std::size_t len =
                 (ceil_mode)
@@ -331,6 +342,7 @@ struct pooling
                 int start = static_cast<int>(idx_o[dim] * stride[d_2]) -
                             static_cast<int>(padding_vals[d_2]);
                 int end;
+                std::size_t dilated_kernel_dim = dilate_dim(kernel_dims[d_2], dilations[d_2]);
                 // NOLINT
                 if(count_include_pad and ceil_mode and (mode != pooling_mode::max))
                 {
@@ -340,15 +352,14 @@ struct pooling
                     // padding.  Clip out-of-bounds indexes but not padding.

                     // Check if this kernel extends beyond the padding at end of dimension
-                    end = std::min(start + kernel_dims[d_2],
+                    end = std::min(start + dilated_kernel_dim,
                                    in_lens[dim] + static_cast<int>(padding_vals[d_2]));
                 }
                 else
                 {
                     // In non-ceiling mode, when
                     // count_include_pad is false, or for max pooling, clip off padding.
-                    end   = std::min(start + kernel_dims[d_2], in_lens[dim]);
-                    start = std::max(start, 0);
+                    end = std::min(start + dilated_kernel_dim, in_lens[dim]);
                 }
                 win_start.push_back(start);
                 if(end < start)
@@ -366,6 +377,16 @@ struct pooling

             // for each element in the window...
             shape_for_each(win_shape, [&](const auto& idx_w) {
+                // Skip elements that belong to the dilated area
+                for(size_t axis = 0; axis < idx_w.size(); ++axis)
+                {
+                    if(idx_w[axis] % dilations[axis])
+                    {
+                        pool_size -= 1;
+                        return;
+                    }
+                }
+
                 // the coordinates of this element
                 auto idx = idx_o;

@@ -390,7 +411,15 @@ struct pooling
                     // this is a padding element.  Padding locations
                     // don't contribute to average or max pooling total but can play in
                     // lpnorm pooling.
-                    output_val = op(output_val, 0);
+                    if(mode == pooling_mode::lpnorm)
+                    {
+                        output_val = op(output_val, op.template init<Type>());
+                    }
+                    if(mode == pooling_mode::average)
+                    {
+                        // Ignore padding
+                        pool_size -= 1;
+                    }
                 }
             });
             output[i] = Type(op.final(output_val, pool_size));

src/include/migraphx/op/unary.hpp

@@ -31,6 +31,7 @@
 #include <migraphx/stringutils.hpp>
 #include <migraphx/value.hpp>
 #include <migraphx/dyn_output.hpp>
+#include <migraphx/par.hpp>

 namespace migraphx {
 inline namespace MIGRAPHX_INLINE_NS {
@@ -84,10 +85,10 @@ struct unary : op_name<Derived>
         argument result{dyn_out.computed_shape};
         result.visit([&](auto output) {
             args[0].visit([&](auto input) {
-                std::transform(input.begin(),
-                               input.end(),
-                               output.begin(),
-                               static_cast<const Derived&>(*this).apply());
+                par_transform(input.begin(),
+                              input.end(),
+                              output.begin(),
+                              static_cast<const Derived&>(*this).apply());
             });
         });
         return result;

src/include/migraphx/par.hpp

+/*
+ * The MIT License (MIT)
+ *
+ * Copyright (c) 2015-2022 Advanced Micro Devices, Inc. All rights reserved.
+ *
+ * Permission is hereby granted, free of charge, to any person obtaining a copy
+ * of this software and associated documentation files (the "Software"), to deal
+ * in the Software without restriction, including without limitation the rights
+ * to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+ * copies of the Software, and to permit persons to whom the Software is
+ * furnished to do so, subject to the following conditions:
+ *
+ * The above copyright notice and this permission notice shall be included in
+ * all copies or substantial portions of the Software.
+ *
+ * THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+ * IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+ * FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+ * AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+ * LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+ * OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+ * THE SOFTWARE.
+ */
+#ifndef MIGRAPHX_GUARD_MIGRAPHX_PAR_HPP
+#define MIGRAPHX_GUARD_MIGRAPHX_PAR_HPP
+
+#include <migraphx/config.hpp>
+#if MIGRAPHX_HAS_EXECUTORS
+#include <execution>
+#else
+#include <migraphx/simple_par_for.hpp>
+#endif
+#include <algorithm>
+#include <mutex>
+#include <vector>
+
+namespace migraphx {
+inline namespace MIGRAPHX_INLINE_NS {
+
+namespace detail {
+
+struct exception_list
+{
+    std::vector<std::exception_ptr> exceptions;
+    std::mutex m;
+    void add_exception()
+    {
+        std::lock_guard<std::mutex> guard(m);
+        exceptions.push_back(std::current_exception());
+    }
+    template <class F>
+    auto collect(F f)
+    {
+        return [f, this](auto&&... xs) {
+            try
+            {
+                f(std::forward<decltype(xs)>(xs)...);
+            }
+            catch(...)
+            {
+                this->add_exception();
+            }
+        };
+    }
+    void throw_if_exception() const
+    {
+        if(not exceptions.empty())
+            std::rethrow_exception(exceptions.front());
+    }
+};
+
+} // namespace detail
+
+template <class InputIt, class OutputIt, class UnaryOperation>
+OutputIt par_transform(InputIt first1, InputIt last1, OutputIt d_first, UnaryOperation unary_op)
+{
+#if MIGRAPHX_HAS_EXECUTORS
+    return std::transform(std::execution::par, first1, last1, d_first, std::move(unary_op));
+#else
+    simple_par_for(last1 - first1, [&](auto i) { d_first[i] = unary_op(first1[i]); });
+    return d_first + (last1 - first1);
+#endif
+}
+
+template <class InputIt1, class InputIt2, class OutputIt, class BinaryOperation>
+OutputIt par_transform(
+    InputIt1 first1, InputIt1 last1, InputIt2 first2, OutputIt d_first, BinaryOperation binary_op)
+{
+#if MIGRAPHX_HAS_EXECUTORS
+    return std::transform(
+        std::execution::par, first1, last1, first2, d_first, std::move(binary_op));
+#else
+    simple_par_for(last1 - first1, [&](auto i) { d_first[i] = binary_op(first1[i], first2[i]); });
+    return d_first + (last1 - first1);
+#endif
+}
+
+template <class InputIt, class UnaryFunction>
+void par_for_each(InputIt first, InputIt last, UnaryFunction f)
+{
+#if MIGRAPHX_HAS_EXECUTORS
+    // Propagate the exception
+    detail::exception_list ex;
+    std::for_each(std::execution::par, first, last, ex.collect(std::move(f)));
+    ex.throw_if_exception();
+#else
+    simple_par_for(last - first, [&](auto i) { f(first[i]); });
+#endif
+}
+
+template <class... Ts>
+auto par_copy_if(Ts&&... xs)
+{
+#if MIGRAPHX_HAS_EXECUTORS
+    return std::copy_if(std::execution::par, std::forward<Ts>(xs)...);
+#else
+    return std::copy_if(std::forward<Ts>(xs)...);
+#endif
+}
+
+template <class... Ts>
+auto par_sort(Ts&&... xs)
+{
+#if MIGRAPHX_HAS_EXECUTORS
+    return std::sort(std::execution::par, std::forward<Ts>(xs)...);
+#else
+    return std::sort(std::forward<Ts>(xs)...);
+#endif
+}
+
+} // namespace MIGRAPHX_INLINE_NS
+} // namespace migraphx
+#endif // MIGRAPHX_GUARD_MIGRAPHX_PAR_HPP

src/include/migraphx/par_for.hpp

@@ -24,93 +24,23 @@
 #ifndef MIGRAPHX_GUARD_RTGLIB_PAR_FOR_HPP
 #define MIGRAPHX_GUARD_RTGLIB_PAR_FOR_HPP

-#include <thread>
-#include <cmath>
-#include <algorithm>
-#include <vector>
-#include <cassert>
+#include <migraphx/par.hpp>
+#include <migraphx/ranges.hpp>

 namespace migraphx {
 inline namespace MIGRAPHX_INLINE_NS {

-struct joinable_thread : std::thread
-{
-    template <class... Xs>
-    joinable_thread(Xs&&... xs) : std::thread(std::forward<Xs>(xs)...) // NOLINT
-    {
-    }
-
-    joinable_thread& operator=(joinable_thread&& other) = default;
-    joinable_thread(joinable_thread&& other)            = default;
-
-    ~joinable_thread()
-    {
-        if(this->joinable())
-            this->join();
-    }
-};
-
-template <class F>
-auto thread_invoke(std::size_t i, std::size_t tid, F f) -> decltype(f(i, tid))
-{
-    f(i, tid);
-}
-
-template <class F>
-auto thread_invoke(std::size_t i, std::size_t, F f) -> decltype(f(i))
-{
-    f(i);
-}
-
-template <class F>
-void par_for_impl(std::size_t n, std::size_t threadsize, F f)
-{
-    if(threadsize <= 1)
-    {
-        for(std::size_t i = 0; i < n; i++)
-            thread_invoke(i, 0, f);
-    }
-    else
-    {
-        std::vector<joinable_thread> threads(threadsize);
-// Using const here causes gcc 5 to ICE
-#if(!defined(__GNUC__) || __GNUC__ != 5)
-        const
-#endif
-            std::size_t grainsize = std::ceil(static_cast<double>(n) / threads.size());
-
-        std::size_t work = 0;
-        std::size_t tid  = 0;
-        std::generate(threads.begin(), threads.end(), [=, &work, &tid] {
-            auto result = joinable_thread([=] {
-                std::size_t start = work;
-                std::size_t last  = std::min(n, work + grainsize);
-                for(std::size_t i = start; i < last; i++)
-                {
-                    thread_invoke(i, tid, f);
-                }
-            });
-            work += grainsize;
-            ++tid;
-            return result;
-        });
-        assert(work >= n);
-    }
-}
-
 template <class F>
-void par_for(std::size_t n, std::size_t min_grain, F f)
+void par_for(std::size_t n, F f)
 {
-    const auto threadsize = std::min<std::size_t>(std::thread::hardware_concurrency(),
-                                                  n / std::max<std::size_t>(1, min_grain));
-    par_for_impl(n, threadsize, f);
+    using iterator = basic_iota_iterator<id, std::size_t>;
+    par_for_each(iterator{0, {}}, iterator{n, {}}, f);
 }

 template <class F>
-void par_for(std::size_t n, F f)
+void par_for(std::size_t n, std::size_t, F f)
 {
-    const int min_grain = 8;
-    par_for(n, min_grain, f);
+    par_for(n, f);
 }

 } // namespace MIGRAPHX_INLINE_NS

src/include/migraphx/rewrite_pooling.hpp

@@ -26,6 +26,7 @@

 #include <string>
 #include <migraphx/config.hpp>
+#include <migraphx/instruction_ref.hpp>

 namespace migraphx {
 inline namespace MIGRAPHX_INLINE_NS {

src/include/migraphx/simple_par_for.hpp

+/*
+ * The MIT License (MIT)
+ *
+ * Copyright (c) 2015-2022 Advanced Micro Devices, Inc. All rights reserved.
+ *
+ * Permission is hereby granted, free of charge, to any person obtaining a copy
+ * of this software and associated documentation files (the "Software"), to deal
+ * in the Software without restriction, including without limitation the rights
+ * to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
+ * copies of the Software, and to permit persons to whom the Software is
+ * furnished to do so, subject to the following conditions:
+ *
+ * The above copyright notice and this permission notice shall be included in
+ * all copies or substantial portions of the Software.
+ *
+ * THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
+ * IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
+ * FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.  IN NO EVENT SHALL THE
+ * AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
+ * LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
+ * OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
+ * THE SOFTWARE.
+ */
+#ifndef MIGRAPHX_GUARD_RTGLIB_SIMPLE_PAR_FOR_HPP
+#define MIGRAPHX_GUARD_RTGLIB_SIMPLE_PAR_FOR_HPP
+
+#include <thread>
+#include <cmath>
+#include <algorithm>
+#include <vector>
+#include <cassert>
+
+namespace migraphx {
+inline namespace MIGRAPHX_INLINE_NS {
+
+struct joinable_thread : std::thread
+{
+    template <class... Xs>
+    joinable_thread(Xs&&... xs) : std::thread(std::forward<Xs>(xs)...) // NOLINT
+    {
+    }
+
+    joinable_thread& operator=(joinable_thread&& other) = default;
+    joinable_thread(joinable_thread&& other)            = default;
+
+    ~joinable_thread()
+    {
+        if(this->joinable())
+            this->join();
+    }
+};
+
+template <class F>
+auto thread_invoke(std::size_t i, std::size_t tid, F f) -> decltype(f(i, tid))
+{
+    f(i, tid);
+}
+
+template <class F>
+auto thread_invoke(std::size_t i, std::size_t, F f) -> decltype(f(i))
+{
+    f(i);
+}
+
+template <class F>
+void simple_par_for_impl(std::size_t n, std::size_t threadsize, F f)
+{
+    if(threadsize <= 1)
+    {
+        for(std::size_t i = 0; i < n; i++)
+            thread_invoke(i, 0, f);
+    }
+    else
+    {
+        std::vector<joinable_thread> threads(threadsize);
+// Using const here causes gcc 5 to ICE
+#if(!defined(__GNUC__) || __GNUC__ != 5)
+        const
+#endif
+            std::size_t grainsize = std::ceil(static_cast<double>(n) / threads.size());
+
+        std::size_t work = 0;
+        std::size_t tid  = 0;
+        std::generate(threads.begin(), threads.end(), [=, &work, &tid] {
+            auto result = joinable_thread([=] {
+                std::size_t start = work;
+                std::size_t last  = std::min(n, work + grainsize);
+                for(std::size_t i = start; i < last; i++)
+                {
+                    thread_invoke(i, tid, f);
+                }
+            });
+            work += grainsize;
+            ++tid;
+            return result;
+        });
+        assert(work >= n);
+    }
+}
+
+template <class F>
+void simple_par_for(std::size_t n, std::size_t min_grain, F f)
+{
+    const auto threadsize = std::min<std::size_t>(std::thread::hardware_concurrency(),
+                                                  n / std::max<std::size_t>(1, min_grain));
+    simple_par_for_impl(n, threadsize, f);
+}
+
+template <class F>
+void simple_par_for(std::size_t n, F f)
+{
+    const int min_grain = 8;
+    simple_par_for(n, min_grain, f);
+}
+
+} // namespace MIGRAPHX_INLINE_NS
+} // namespace migraphx
+
+#endif

src/onnx/parse_pooling.cpp

@@ -91,6 +91,14 @@ struct parse_pooling : op_parser<parse_pooling>
                 kdims, values["lengths"].size(), "PARSE_POOLING: inconsistent lengths");
         }

+        if(contains(info.attributes, "dilations"))
+        {
+            values["dilations"].clear();
+            copy(info.attributes["dilations"].ints(), std::back_inserter(values["dilations"]));
+            check_attr_sizes(
+                kdims, values["dilations"].size(), "PARSE_POOLING: inconsistent dilations");
+        }
+
         // lp_order attribute
         if(contains(info.attributes, "p"))
         {
@@ -169,10 +177,15 @@ struct parse_pooling : op_parser<parse_pooling>
             std::fill_n(values["stride"].begin(), kdims, 1);
         }

+        if(values["dilations"].size() != kdims)
+        {
+            values["dilations"].resize(kdims);
+            std::fill_n(values["dilations"].begin(), kdims, 1);
+        }
+
         // used to calculate the supposed output shape
         std::vector<int64_t> orig_padding = paddings;

-        // TODO:  add parsing for dilations
         if(contains(info.attributes, "auto_pad") and
            to_upper(info.attributes["auto_pad"].s()) != "NOTSET")
         {
@@ -189,11 +202,10 @@ struct parse_pooling : op_parser<parse_pooling>
             else
             {
                 // Calculate auto padding
-                // dilations (argument 4) not supported; default to all 1's
                 cal_auto_padding_size(info,
                                       values,
                                       values["lengths"].to_vector<std::size_t>(),
-                                      std::vector<size_t>(in_shape.ndim() - 2, 1),
+                                      values["dilations"].to_vector<std::size_t>(),
                                       in_shape.lens(),
                                       paddings);
                 values["padding"] = paddings;
