Implementation of SuperPoint and AutoModelForKeypointDetection (#28966)

* Added SuperPoint docs

* Added tests

* Removed commented part

* Commit to create and fix add_superpoint branch with a new branch

* Fixed dummy_pt_objects

* Committed missing files

* Fixed README.md

* Apply suggestions from code review

Fixed small changes
Co-authored-by: amyeroberts <22614925+amyeroberts@users.noreply.github.com>

* Moved ImagePointDescriptionOutput from modeling_outputs.py to modeling_superpoint.py

* Removed AutoModelForKeypointDetection and related stuff

* Fixed inconsistencies in image_processing_superpoint.py

* Moved infer_on_model logic simply in test_inference

* Fixed bugs, added labels to forward method with checks whether it is properly a None value, also added tests about this logic in test_modeling_superpoint.py

* Added tests to SuperPointImageProcessor to ensure that images are properly converted to grayscale

* Removed remaining mentions of MODEL_FOR_KEYPOINT_DETECTION_MAPPING

* Apply suggestions from code review
Co-authored-by: amyeroberts <22614925+amyeroberts@users.noreply.github.com>

* Fixed from (w, h) to (h, w) as input for tests

* Removed unnecessary condition

* Moved last_hidden_state to be the first returned

* Moved last_hidden_state to be the first returned (bis)

* Moved last_hidden_state to be the first returned (ter)

* Switched image_width and image_height in tests to match recent changes

* Added config as first SuperPointConvBlock init argument

* Reordered README's after merge

* Added missing first config argument to SuperPointConvBlock instantiations

* Removed formatting error

* Added SuperPoint to README's de, pt-br, ru, te and vi

* Checked out README_fr.md

* Fixed README_fr.md

* Test fix README_fr.md

* Test fix README_fr.md

* Last make fix-copies !

* Updated checkpoint path

* Removed unused SuperPoint doc

* Added missing image

* Update src/transformers/models/superpoint/modeling_superpoint.py
Co-authored-by: amyeroberts <22614925+amyeroberts@users.noreply.github.com>

* Removed unnecessary import

* Update src/transformers/models/superpoint/modeling_superpoint.py
Co-authored-by: amyeroberts <22614925+amyeroberts@users.noreply.github.com>

* Added SuperPoint to _toctree.yml

---------
Co-authored-by: steven <steven.bucaillle@gmail.com>
Co-authored-by: amyeroberts <22614925+amyeroberts@users.noreply.github.com>
Co-authored-by: Steven Bucaille <steven.bucaille@buawei.com>

src/transformers/models/auto/modeling_auto.py

@@ -207,6 +207,7 @@ MODEL_MAPPING_NAMES = OrderedDict(
         ("squeezebert", "SqueezeBertModel"),
         ("stablelm", "StableLmModel"),
         ("starcoder2", "Starcoder2Model"),
+        ("superpoint", "SuperPointModel"),
         ("swiftformer", "SwiftFormerModel"),
         ("swin", "SwinModel"),
         ("swin2sr", "Swin2SRModel"),

src/transformers/models/superpoint/__init__.py

+# Copyright 2024 The HuggingFace Team. All rights reserved.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+from typing import TYPE_CHECKING
+
+# rely on isort to merge the imports
+from ...utils import OptionalDependencyNotAvailable, _LazyModule, is_torch_available, is_vision_available
+
+
+_import_structure = {
+    "configuration_superpoint": [
+        "SUPERPOINT_PRETRAINED_CONFIG_ARCHIVE_MAP",
+        "SuperPointConfig",
+    ]
+}
+
+try:
+    if not is_vision_available():
+        raise OptionalDependencyNotAvailable()
+except OptionalDependencyNotAvailable:
+    pass
+else:
+    _import_structure["image_processing_superpoint"] = ["SuperPointImageProcessor"]
+
+try:
+    if not is_torch_available():
+        raise OptionalDependencyNotAvailable()
+except OptionalDependencyNotAvailable:
+    pass
+else:
+    _import_structure["modeling_superpoint"] = [
+        "SUPERPOINT_PRETRAINED_MODEL_ARCHIVE_LIST",
+        "SuperPointModel",
+        "SuperPointPreTrainedModel",
+    ]
+
+
+if TYPE_CHECKING:
+    from .configuration_superpoint import (
+        SUPERPOINT_PRETRAINED_CONFIG_ARCHIVE_MAP,
+        SuperPointConfig,
+    )
+
+    try:
+        if not is_vision_available():
+            raise OptionalDependencyNotAvailable()
+    except OptionalDependencyNotAvailable:
+        pass
+    else:
+        from .image_processing_superpoint import SuperPointImageProcessor
+
+    try:
+        if not is_torch_available():
+            raise OptionalDependencyNotAvailable()
+    except OptionalDependencyNotAvailable:
+        pass
+    else:
+        from .modeling_superpoint import (
+            SUPERPOINT_PRETRAINED_MODEL_ARCHIVE_LIST,
+            SuperPointModel,
+            SuperPointPreTrainedModel,
+        )
+
+else:
+    import sys
+
+    sys.modules[__name__] = _LazyModule(__name__, globals()["__file__"], _import_structure)

src/transformers/models/superpoint/configuration_superpoint.py

+# Copyright 2024 The HuggingFace Team. All rights reserved.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+from typing import List
+
+from ...configuration_utils import PretrainedConfig
+from ...utils import logging
+
+
+logger = logging.get_logger(__name__)
+
+SUPERPOINT_PRETRAINED_CONFIG_ARCHIVE_MAP = {
+    "magic-leap-community/superpoint": "https://huggingface.co/magic-leap-community/superpoint/blob/main/config.json"
+}
+
+
+class SuperPointConfig(PretrainedConfig):
+    r"""
+    This is the configuration class to store the configuration of a [`SuperPointModel`]. It is used to instantiate a
+    SuperPoint model according to the specified arguments, defining the model architecture. Instantiating a
+    configuration with the defaults will yield a similar configuration to that of the SuperPoint
+    [magic-leap-community/superpoint](https://huggingface.co/magic-leap-community/superpoint) architecture.
+
+    Configuration objects inherit from [`PretrainedConfig`] and can be used to control the model outputs. Read the
+    documentation from [`PretrainedConfig`] for more information.
+
+    Args:
+        encoder_hidden_sizes (`List`, *optional*, defaults to `[64, 64, 128, 128]`):
+            The number of channels in each convolutional layer in the encoder.
+        decoder_hidden_size (`int`, *optional*, defaults to 256): The hidden size of the decoder.
+        keypoint_decoder_dim (`int`, *optional*, defaults to 65): The output dimension of the keypoint decoder.
+        descriptor_decoder_dim (`int`, *optional*, defaults to 256): The output dimension of the descriptor decoder.
+        keypoint_threshold (`float`, *optional*, defaults to 0.005):
+            The threshold to use for extracting keypoints.
+        max_keypoints (`int`, *optional*, defaults to -1):
+            The maximum number of keypoints to extract. If `-1`, will extract all keypoints.
+        nms_radius (`int`, *optional*, defaults to 4):
+            The radius for non-maximum suppression.
+        border_removal_distance (`int`, *optional*, defaults to 4):
+            The distance from the border to remove keypoints.
+        initializer_range (`float`, *optional*, defaults to 0.02):
+            The standard deviation of the truncated_normal_initializer for initializing all weight matrices.
+
+    Example:
+    ```python
+    >>> from transformers import SuperPointConfig, SuperPointModel
+
+    >>> # Initializing a SuperPoint superpoint style configuration
+    >>> configuration = SuperPointConfig()
+    >>> # Initializing a model from the superpoint style configuration
+    >>> model = SuperPointModel(configuration)
+    >>> # Accessing the model configuration
+    >>> configuration = model.config
+    ```"""
+
+    model_type = "superpoint"
+
+    def __init__(
+        self,
+        encoder_hidden_sizes: List[int] = [64, 64, 128, 128],
+        decoder_hidden_size: int = 256,
+        keypoint_decoder_dim: int = 65,
+        descriptor_decoder_dim: int = 256,
+        keypoint_threshold: float = 0.005,
+        max_keypoints: int = -1,
+        nms_radius: int = 4,
+        border_removal_distance: int = 4,
+        initializer_range=0.02,
+        **kwargs,
+    ):
+        self.encoder_hidden_sizes = encoder_hidden_sizes
+        self.decoder_hidden_size = decoder_hidden_size
+        self.keypoint_decoder_dim = keypoint_decoder_dim
+        self.descriptor_decoder_dim = descriptor_decoder_dim
+        self.keypoint_threshold = keypoint_threshold
+        self.max_keypoints = max_keypoints
+        self.nms_radius = nms_radius
+        self.border_removal_distance = border_removal_distance
+        self.initializer_range = initializer_range
+
+        super().__init__(**kwargs)

src/transformers/models/superpoint/convert_superpoint_to_pytorch.py

+# Copyright 2024 The HuggingFace Team. All rights reserved.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+import argparse
+import os
+
+import requests
+import torch
+from PIL import Image
+
+from transformers import SuperPointConfig, SuperPointImageProcessor, SuperPointModel
+
+
+def get_superpoint_config():
+    config = SuperPointConfig(
+        encoder_hidden_sizes=[64, 64, 128, 128],
+        decoder_hidden_size=256,
+        keypoint_decoder_dim=65,
+        descriptor_decoder_dim=256,
+        keypoint_threshold=0.005,
+        max_keypoints=-1,
+        nms_radius=4,
+        border_removal_distance=4,
+        initializer_range=0.02,
+    )
+
+    return config
+
+
+def create_rename_keys(config, state_dict):
+    rename_keys = []
+
+    # Encoder weights
+    rename_keys.append(("conv1a.weight", "encoder.conv_blocks.0.conv_a.weight"))
+    rename_keys.append(("conv1b.weight", "encoder.conv_blocks.0.conv_b.weight"))
+    rename_keys.append(("conv2a.weight", "encoder.conv_blocks.1.conv_a.weight"))
+    rename_keys.append(("conv2b.weight", "encoder.conv_blocks.1.conv_b.weight"))
+    rename_keys.append(("conv3a.weight", "encoder.conv_blocks.2.conv_a.weight"))
+    rename_keys.append(("conv3b.weight", "encoder.conv_blocks.2.conv_b.weight"))
+    rename_keys.append(("conv4a.weight", "encoder.conv_blocks.3.conv_a.weight"))
+    rename_keys.append(("conv4b.weight", "encoder.conv_blocks.3.conv_b.weight"))
+    rename_keys.append(("conv1a.bias", "encoder.conv_blocks.0.conv_a.bias"))
+    rename_keys.append(("conv1b.bias", "encoder.conv_blocks.0.conv_b.bias"))
+    rename_keys.append(("conv2a.bias", "encoder.conv_blocks.1.conv_a.bias"))
+    rename_keys.append(("conv2b.bias", "encoder.conv_blocks.1.conv_b.bias"))
+    rename_keys.append(("conv3a.bias", "encoder.conv_blocks.2.conv_a.bias"))
+    rename_keys.append(("conv3b.bias", "encoder.conv_blocks.2.conv_b.bias"))
+    rename_keys.append(("conv4a.bias", "encoder.conv_blocks.3.conv_a.bias"))
+    rename_keys.append(("conv4b.bias", "encoder.conv_blocks.3.conv_b.bias"))
+
+    # Keypoint Decoder weights
+    rename_keys.append(("convPa.weight", "keypoint_decoder.conv_score_a.weight"))
+    rename_keys.append(("convPb.weight", "keypoint_decoder.conv_score_b.weight"))
+    rename_keys.append(("convPa.bias", "keypoint_decoder.conv_score_a.bias"))
+    rename_keys.append(("convPb.bias", "keypoint_decoder.conv_score_b.bias"))
+
+    # Descriptor Decoder weights
+    rename_keys.append(("convDa.weight", "descriptor_decoder.conv_descriptor_a.weight"))
+    rename_keys.append(("convDb.weight", "descriptor_decoder.conv_descriptor_b.weight"))
+    rename_keys.append(("convDa.bias", "descriptor_decoder.conv_descriptor_a.bias"))
+    rename_keys.append(("convDb.bias", "descriptor_decoder.conv_descriptor_b.bias"))
+
+    return rename_keys
+
+
+def rename_key(dct, old, new):
+    val = dct.pop(old)
+    dct[new] = val
+
+
+def prepare_imgs():
+    url = "http://images.cocodataset.org/val2017/000000039769.jpg"
+    im1 = Image.open(requests.get(url, stream=True).raw)
+    url = "http://images.cocodataset.org/test-stuff2017/000000004016.jpg"
+    im2 = Image.open(requests.get(url, stream=True).raw)
+    return [im1, im2]
+
+
+@torch.no_grad()
+def convert_superpoint_checkpoint(checkpoint_url, pytorch_dump_folder_path, save_model, push_to_hub, test_mode=False):
+    """
+    Copy/paste/tweak model's weights to our SuperPoint structure.
+    """
+
+    print("Downloading original model from checkpoint...")
+    config = get_superpoint_config()
+
+    # load original state_dict from URL
+    original_state_dict = torch.hub.load_state_dict_from_url(checkpoint_url)
+
+    print("Converting model parameters...")
+    # rename keys
+    rename_keys = create_rename_keys(config, original_state_dict)
+    new_state_dict = original_state_dict.copy()
+    for src, dest in rename_keys:
+        rename_key(new_state_dict, src, dest)
+
+    # Load HuggingFace model
+    model = SuperPointModel(config)
+    model.load_state_dict(new_state_dict)
+    model.eval()
+    print("Successfully loaded weights in the model")
+
+    # Check model outputs
+    preprocessor = SuperPointImageProcessor()
+    inputs = preprocessor(images=prepare_imgs(), return_tensors="pt")
+    outputs = model(**inputs)
+
+    # If test_mode is True, we check that the model outputs match the original results
+    if test_mode:
+        torch.count_nonzero(outputs.mask[0])
+        expected_keypoints_shape = (2, 830, 2)
+        expected_scores_shape = (2, 830)
+        expected_descriptors_shape = (2, 830, 256)
+
+        expected_keypoints_values = torch.tensor([[480.0, 9.0], [494.0, 9.0], [489.0, 16.0]])
+        expected_scores_values = torch.tensor([0.0064, 0.0140, 0.0595, 0.0728, 0.5170, 0.0175, 0.1523, 0.2055, 0.0336])
+        expected_descriptors_value = torch.tensor(-0.1096)
+        assert outputs.keypoints.shape == expected_keypoints_shape
+        assert outputs.scores.shape == expected_scores_shape
+        assert outputs.descriptors.shape == expected_descriptors_shape
+
+        assert torch.allclose(outputs.keypoints[0, :3], expected_keypoints_values, atol=1e-3)
+        assert torch.allclose(outputs.scores[0, :9], expected_scores_values, atol=1e-3)
+        assert torch.allclose(outputs.descriptors[0, 0, 0], expected_descriptors_value, atol=1e-3)
+        print("Model outputs match the original results!")
+
+    if save_model:
+        print("Saving model to local...")
+        # Create folder to save model
+        if not os.path.isdir(pytorch_dump_folder_path):
+            os.mkdir(pytorch_dump_folder_path)
+
+        model.save_pretrained(pytorch_dump_folder_path)
+        preprocessor.save_pretrained(pytorch_dump_folder_path)
+
+        model_name = "superpoint"
+        if push_to_hub:
+            print(f"Pushing {model_name} to the hub...")
+        model.push_to_hub(model_name)
+        preprocessor.push_to_hub(model_name)
+
+
+if __name__ == "__main__":
+    parser = argparse.ArgumentParser()
+    # Required parameters
+    parser.add_argument(
+        "--checkpoint_url",
+        default="https://github.com/magicleap/SuperPointPretrainedNetwork/raw/master/superpoint_v1.pth",
+        type=str,
+        help="URL of the original SuperPoint checkpoint you'd like to convert.",
+    )
+    parser.add_argument(
+        "--pytorch_dump_folder_path",
+        default="model",
+        type=str,
+        help="Path to the output PyTorch model directory.",
+    )
+    parser.add_argument("--save_model", action="store_true", help="Save model to local")
+    parser.add_argument("--push_to_hub", action="store_true", help="Push model and image preprocessor to the hub")
+
+    args = parser.parse_args()
+    convert_superpoint_checkpoint(
+        args.checkpoint_url, args.pytorch_dump_folder_path, args.save_model, args.push_to_hub
+    )

src/transformers/models/superpoint/image_processing_superpoint.py

+# Copyright 2024 The HuggingFace Team. All rights reserved.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+"""Image processor class for SuperPoint."""
+
+from typing import Dict, Optional, Union
+
+import numpy as np
+
+from ... import is_vision_available, requires_backends
+from ...image_processing_utils import BaseImageProcessor, BatchFeature, get_size_dict
+from ...image_transforms import resize, to_channel_dimension_format
+from ...image_utils import (
+    ChannelDimension,
+    ImageInput,
+    infer_channel_dimension_format,
+    is_scaled_image,
+    make_list_of_images,
+    to_numpy_array,
+    valid_images,
+)
+from ...utils import TensorType, logging
+
+
+if is_vision_available():
+    import PIL
+
+logger = logging.get_logger(__name__)
+
+
+def is_grayscale(
+    image: ImageInput,
+    input_data_format: Optional[Union[str, ChannelDimension]] = None,
+):
+    if input_data_format == ChannelDimension.FIRST:
+        return np.all(image[0, ...] == image[1, ...]) and np.all(image[1, ...] == image[2, ...])
+    elif input_data_format == ChannelDimension.LAST:
+        return np.all(image[..., 0] == image[..., 1]) and np.all(image[..., 1] == image[..., 2])
+
+
+def convert_to_grayscale(
+    image: ImageInput,
+    input_data_format: Optional[Union[str, ChannelDimension]] = None,
+) -> ImageInput:
+    """
+    Converts an image to grayscale format using the NTSC formula. Only support numpy and PIL Image. TODO support torch
+    and tensorflow grayscale conversion
+
+    This function is supposed to return a 1-channel image, but it returns a 3-channel image with the same value in each
+    channel, because of an issue that is discussed in :
+    https://github.com/huggingface/transformers/pull/25786#issuecomment-1730176446
+
+    Args:
+        image (Image):
+            The image to convert.
+        input_data_format (`ChannelDimension` or `str`, *optional*):
+            The channel dimension format for the input image.
+    """
+    requires_backends(convert_to_grayscale, ["vision"])
+
+    if isinstance(image, np.ndarray):
+        if input_data_format == ChannelDimension.FIRST:
+            gray_image = image[0, ...] * 0.2989 + image[1, ...] * 0.5870 + image[2, ...] * 0.1140
+            gray_image = np.stack([gray_image] * 3, axis=0)
+        elif input_data_format == ChannelDimension.LAST:
+            gray_image = image[..., 0] * 0.2989 + image[..., 1] * 0.5870 + image[..., 2] * 0.1140
+            gray_image = np.stack([gray_image] * 3, axis=-1)
+        return gray_image
+
+    if not isinstance(image, PIL.Image.Image):
+        return image
+
+    image = image.convert("L")
+    return image
+
+
+class SuperPointImageProcessor(BaseImageProcessor):
+    r"""
+    Constructs a SuperPoint image processor.
+
+    Args:
+        do_resize (`bool`, *optional*, defaults to `True`):
+            Controls whether to resize the image's (height, width) dimensions to the specified `size`. Can be overriden
+            by `do_resize` in the `preprocess` method.
+        size (`Dict[str, int]` *optional*, defaults to `{"height": 480, "width": 640}`):
+            Resolution of the output image after `resize` is applied. Only has an effect if `do_resize` is set to
+            `True`. Can be overriden by `size` in the `preprocess` method.
+        do_rescale (`bool`, *optional*, defaults to `True`):
+            Whether to rescale the image by the specified scale `rescale_factor`. Can be overriden by `do_rescale` in
+            the `preprocess` method.
+        rescale_factor (`int` or `float`, *optional*, defaults to `1/255`):
+            Scale factor to use if rescaling the image. Can be overriden by `rescale_factor` in the `preprocess`
+            method.
+    """
+
+    model_input_names = ["pixel_values"]
+
+    def __init__(
+        self,
+        do_resize: bool = True,
+        size: Dict[str, int] = None,
+        do_rescale: bool = True,
+        rescale_factor: float = 1 / 255,
+        **kwargs,
+    ) -> None:
+        super().__init__(**kwargs)
+        size = size if size is not None else {"height": 480, "width": 640}
+        size = get_size_dict(size, default_to_square=False)
+
+        self.do_resize = do_resize
+        self.size = size
+        self.do_rescale = do_rescale
+        self.rescale_factor = rescale_factor
+
+    def resize(
+        self,
+        image: np.ndarray,
+        size: Dict[str, int],
+        data_format: Optional[Union[str, ChannelDimension]] = None,
+        input_data_format: Optional[Union[str, ChannelDimension]] = None,
+        **kwargs,
+    ):
+        """
+        Resize an image.
+
+        Args:
+            image (`np.ndarray`):
+                Image to resize.
+            size (`Dict[str, int]`):
+                Dictionary of the form `{"height": int, "width": int}`, specifying the size of the output image.
+            data_format (`ChannelDimension` or `str`, *optional*):
+                The channel dimension format of the output image. If not provided, it will be inferred from the input
+                image. Can be one of:
+                - `"channels_first"` or `ChannelDimension.FIRST`: image in (num_channels, height, width) format.
+                - `"channels_last"` or `ChannelDimension.LAST`: image in (height, width, num_channels) format.
+                - `"none"` or `ChannelDimension.NONE`: image in (height, width) format.
+            input_data_format (`ChannelDimension` or `str`, *optional*):
+                The channel dimension format for the input image. If unset, the channel dimension format is inferred
+                from the input image. Can be one of:
+                - `"channels_first"` or `ChannelDimension.FIRST`: image in (num_channels, height, width) format.
+                - `"channels_last"` or `ChannelDimension.LAST`: image in (height, width, num_channels) format.
+                - `"none"` or `ChannelDimension.NONE`: image in (height, width) format.
+        """
+        size = get_size_dict(size, default_to_square=False)
+
+        return resize(
+            image,
+            size=(size["height"], size["width"]),
+            data_format=data_format,
+            input_data_format=input_data_format,
+            **kwargs,
+        )
+
+    def preprocess(
+        self,
+        images,
+        do_resize: bool = None,
+        size: Dict[str, int] = None,
+        do_rescale: bool = None,
+        rescale_factor: float = None,
+        return_tensors: Optional[Union[str, TensorType]] = None,
+        data_format: ChannelDimension = ChannelDimension.FIRST,
+        input_data_format: Optional[Union[str, ChannelDimension]] = None,
+        **kwargs,
+    ) -> BatchFeature:
+        """
+        Preprocess an image or batch of images.
+
+        Args:
+            images (`ImageInput`):
+                Image to preprocess. Expects a single or batch of images with pixel values ranging from 0 to 255. If
+                passing in images with pixel values between 0 and 1, set `do_rescale=False`.
+            do_resize (`bool`, *optional*, defaults to `self.do_resize`):
+                Whether to resize the image.
+            size (`Dict[str, int]`, *optional*, defaults to `self.size`):
+                Size of the output image after `resize` has been applied. If `size["shortest_edge"]` >= 384, the image
+                is resized to `(size["shortest_edge"], size["shortest_edge"])`. Otherwise, the smaller edge of the
+                image will be matched to `int(size["shortest_edge"]/ crop_pct)`, after which the image is cropped to
+                `(size["shortest_edge"], size["shortest_edge"])`. Only has an effect if `do_resize` is set to `True`.
+            do_rescale (`bool`, *optional*, defaults to `self.do_rescale`):
+                Whether to rescale the image values between [0 - 1].
+            rescale_factor (`float`, *optional*, defaults to `self.rescale_factor`):
+                Rescale factor to rescale the image by if `do_rescale` is set to `True`.
+            return_tensors (`str` or `TensorType`, *optional*):
+                The type of tensors to return. Can be one of:
+                    - Unset: Return a list of `np.ndarray`.
+                    - `TensorType.TENSORFLOW` or `'tf'`: Return a batch of type `tf.Tensor`.
+                    - `TensorType.PYTORCH` or `'pt'`: Return a batch of type `torch.Tensor`.
+                    - `TensorType.NUMPY` or `'np'`: Return a batch of type `np.ndarray`.
+                    - `TensorType.JAX` or `'jax'`: Return a batch of type `jax.numpy.ndarray`.
+            data_format (`ChannelDimension` or `str`, *optional*, defaults to `ChannelDimension.FIRST`):
+                The channel dimension format for the output image. Can be one of:
+                - `"channels_first"` or `ChannelDimension.FIRST`: image in (num_channels, height, width) format.
+                - `"channels_last"` or `ChannelDimension.LAST`: image in (height, width, num_channels) format.
+                - Unset: Use the channel dimension format of the input image.
+            input_data_format (`ChannelDimension` or `str`, *optional*):
+                The channel dimension format for the input image. If unset, the channel dimension format is inferred
+                from the input image. Can be one of:
+                - `"channels_first"` or `ChannelDimension.FIRST`: image in (num_channels, height, width) format.
+                - `"channels_last"` or `ChannelDimension.LAST`: image in (height, width, num_channels) format.
+                - `"none"` or `ChannelDimension.NONE`: image in (height, width) format.
+        """
+
+        do_resize = do_resize if do_resize is not None else self.do_resize
+        do_rescale = do_rescale if do_rescale is not None else self.do_rescale
+        rescale_factor = rescale_factor if rescale_factor is not None else self.rescale_factor
+
+        size = size if size is not None else self.size
+        size = get_size_dict(size, default_to_square=False)
+
+        images = make_list_of_images(images)
+
+        if not valid_images(images):
+            raise ValueError(
+                "Invalid image type. Must be of type PIL.Image.Image, numpy.ndarray, "
+                "torch.Tensor, tf.Tensor or jax.ndarray."
+            )
+
+        if do_resize and size is None:
+            raise ValueError("Size must be specified if do_resize is True.")
+
+        if do_rescale and rescale_factor is None:
+            raise ValueError("Rescale factor must be specified if do_rescale is True.")
+
+        # All transformations expect numpy arrays.
+        images = [to_numpy_array(image) for image in images]
+
+        if is_scaled_image(images[0]) and do_rescale:
+            logger.warning_once(
+                "It looks like you are trying to rescale already rescaled images. If the input"
+                " images have pixel values between 0 and 1, set `do_rescale=False` to avoid rescaling them again."
+            )
+
+        if input_data_format is None:
+            # We assume that all images have the same channel dimension format.
+            input_data_format = infer_channel_dimension_format(images[0])
+
+        if do_resize:
+            images = [self.resize(image=image, size=size, input_data_format=input_data_format) for image in images]
+
+        if do_rescale:
+            images = [
+                self.rescale(image=image, scale=rescale_factor, input_data_format=input_data_format)
+                for image in images
+            ]
+
+        if input_data_format is None:
+            # We assume that all images have the same channel dimension format.
+            input_data_format = infer_channel_dimension_format(images[0])
+
+        # Checking if image is RGB or grayscale
+        for i in range(len(images)):
+            if not is_grayscale(images[i], input_data_format):
+                images[i] = convert_to_grayscale(images[i], input_data_format=input_data_format)
+
+        images = [
+            to_channel_dimension_format(image, data_format, input_channel_dim=input_data_format) for image in images
+        ]
+
+        data = {"pixel_values": images}
+
+        return BatchFeature(data=data, tensor_type=return_tensors)

src/transformers/utils/dummy_pt_objects.py

@@ -8026,6 +8026,23 @@ class Starcoder2PreTrainedModel(metaclass=DummyObject):
         requires_backends(self, ["torch"])


+SUPERPOINT_PRETRAINED_MODEL_ARCHIVE_LIST = None
+
+
+class SuperPointModel(metaclass=DummyObject):
+    _backends = ["torch"]
+
+    def __init__(self, *args, **kwargs):
+        requires_backends(self, ["torch"])
+
+
+class SuperPointPreTrainedModel(metaclass=DummyObject):
+    _backends = ["torch"]
+
+    def __init__(self, *args, **kwargs):
+        requires_backends(self, ["torch"])
+
+
 SWIFTFORMER_PRETRAINED_MODEL_ARCHIVE_LIST = None



src/transformers/utils/dummy_vision_objects.py

@@ -485,6 +485,13 @@ class SiglipImageProcessor(metaclass=DummyObject):
         requires_backends(self, ["vision"])


+class SuperPointImageProcessor(metaclass=DummyObject):
+    _backends = ["vision"]
+
+    def __init__(self, *args, **kwargs):
+        requires_backends(self, ["vision"])
+
+
 class Swin2SRImageProcessor(metaclass=DummyObject):
     _backends = ["vision"]


tests/models/superpoint/test_image_processing_superpoint.py

+# Copyright 2024 The HuggingFace Team. All rights reserved.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+import unittest
+
+import numpy as np
+
+from transformers.testing_utils import require_torch, require_vision
+from transformers.utils import is_vision_available
+
+from ...test_image_processing_common import (
+    ImageProcessingTestMixin,
+    prepare_image_inputs,
+)
+
+
+if is_vision_available():
+    from transformers import SuperPointImageProcessor
+
+
+class SuperPointImageProcessingTester(unittest.TestCase):
+    def __init__(
+        self,
+        parent,
+        batch_size=7,
+        num_channels=3,
+        image_size=18,
+        min_resolution=30,
+        max_resolution=400,
+        do_resize=True,
+        size=None,
+    ):
+        size = size if size is not None else {"height": 480, "width": 640}
+        self.parent = parent
+        self.batch_size = batch_size
+        self.num_channels = num_channels
+        self.image_size = image_size
+        self.min_resolution = min_resolution
+        self.max_resolution = max_resolution
+        self.do_resize = do_resize
+        self.size = size
+
+    def prepare_image_processor_dict(self):
+        return {
+            "do_resize": self.do_resize,
+            "size": self.size,
+        }
+
+    def expected_output_image_shape(self, images):
+        return self.num_channels, self.size["height"], self.size["width"]
+
+    def prepare_image_inputs(self, equal_resolution=False, numpify=False, torchify=False):
+        return prepare_image_inputs(
+            batch_size=self.batch_size,
+            num_channels=self.num_channels,
+            min_resolution=self.min_resolution,
+            max_resolution=self.max_resolution,
+            equal_resolution=equal_resolution,
+            numpify=numpify,
+            torchify=torchify,
+        )
+
+
+@require_torch
+@require_vision
+class SuperPointImageProcessingTest(ImageProcessingTestMixin, unittest.TestCase):
+    image_processing_class = SuperPointImageProcessor if is_vision_available() else None
+
+    def setUp(self) -> None:
+        self.image_processor_tester = SuperPointImageProcessingTester(self)
+
+    @property
+    def image_processor_dict(self):
+        return self.image_processor_tester.prepare_image_processor_dict()
+
+    def test_image_processing(self):
+        image_processing = self.image_processing_class(**self.image_processor_dict)
+        self.assertTrue(hasattr(image_processing, "do_resize"))
+        self.assertTrue(hasattr(image_processing, "size"))
+        self.assertTrue(hasattr(image_processing, "do_rescale"))
+        self.assertTrue(hasattr(image_processing, "rescale_factor"))
+
+    def test_image_processor_from_dict_with_kwargs(self):
+        image_processor = self.image_processing_class.from_dict(self.image_processor_dict)
+        self.assertEqual(image_processor.size, {"height": 480, "width": 640})
+
+        image_processor = self.image_processing_class.from_dict(
+            self.image_processor_dict, size={"height": 42, "width": 42}
+        )
+        self.assertEqual(image_processor.size, {"height": 42, "width": 42})
+
+    @unittest.skip(reason="SuperPointImageProcessor is always supposed to return a grayscaled image")
+    def test_call_numpy_4_channels(self):
+        pass
+
+    def test_input_image_properly_converted_to_grayscale(self):
+        image_processor = self.image_processing_class.from_dict(self.image_processor_dict)
+        image_inputs = self.image_processor_tester.prepare_image_inputs()
+        pre_processed_images = image_processor.preprocess(image_inputs)
+        for image in pre_processed_images["pixel_values"]:
+            self.assertTrue(np.all(image[0, ...] == image[1, ...]) and np.all(image[1, ...] == image[2, ...]))

tests/models/superpoint/test_modeling_superpoint.py

+# Copyright 2024 The HuggingFace Team. All rights reserved.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+import inspect
+import unittest
+from typing import List
+
+from transformers.models.superpoint.configuration_superpoint import SuperPointConfig
+from transformers.testing_utils import require_torch, require_vision, slow, torch_device
+from transformers.utils import cached_property, is_torch_available, is_vision_available
+
+from ...test_configuration_common import ConfigTester
+from ...test_modeling_common import ModelTesterMixin, floats_tensor
+
+
+if is_torch_available():
+    import torch
+
+    from transformers import (
+        SUPERPOINT_PRETRAINED_MODEL_ARCHIVE_LIST,
+        SuperPointModel,
+    )
+
+if is_vision_available():
+    from PIL import Image
+
+    from transformers import AutoImageProcessor
+
+
+class SuperPointModelTester:
+    def __init__(
+        self,
+        parent,
+        batch_size=3,
+        image_width=80,
+        image_height=60,
+        encoder_hidden_sizes: List[int] = [32, 32, 64, 64],
+        decoder_hidden_size: int = 128,
+        keypoint_decoder_dim: int = 65,
+        descriptor_decoder_dim: int = 128,
+        keypoint_threshold: float = 0.005,
+        max_keypoints: int = -1,
+        nms_radius: int = 4,
+        border_removal_distance: int = 4,
+    ):
+        self.parent = parent
+        self.batch_size = batch_size
+        self.image_width = image_width
+        self.image_height = image_height
+
+        self.encoder_hidden_sizes = encoder_hidden_sizes
+        self.decoder_hidden_size = decoder_hidden_size
+        self.keypoint_decoder_dim = keypoint_decoder_dim
+        self.descriptor_decoder_dim = descriptor_decoder_dim
+        self.keypoint_threshold = keypoint_threshold
+        self.max_keypoints = max_keypoints
+        self.nms_radius = nms_radius
+        self.border_removal_distance = border_removal_distance
+
+    def prepare_config_and_inputs(self):
+        # SuperPoint expects a grayscale image as input
+        pixel_values = floats_tensor([self.batch_size, 3, self.image_height, self.image_width])
+        config = self.get_config()
+        return config, pixel_values
+
+    def get_config(self):
+        return SuperPointConfig(
+            encoder_hidden_sizes=self.encoder_hidden_sizes,
+            decoder_hidden_size=self.decoder_hidden_size,
+            keypoint_decoder_dim=self.keypoint_decoder_dim,
+            descriptor_decoder_dim=self.descriptor_decoder_dim,
+            keypoint_threshold=self.keypoint_threshold,
+            max_keypoints=self.max_keypoints,
+            nms_radius=self.nms_radius,
+            border_removal_distance=self.border_removal_distance,
+        )
+
+    def create_and_check_model(self, config, pixel_values):
+        model = SuperPointModel(config=config)
+        model.to(torch_device)
+        model.eval()
+        result = model(pixel_values)
+        self.parent.assertEqual(
+            result.last_hidden_state.shape,
+            (
+                self.batch_size,
+                self.encoder_hidden_sizes[-1],
+                self.image_height // 8,
+                self.image_width // 8,
+            ),
+        )
+
+    def prepare_config_and_inputs_for_common(self):
+        config_and_inputs = self.prepare_config_and_inputs()
+        config, pixel_values = config_and_inputs
+        inputs_dict = {"pixel_values": pixel_values}
+        return config, inputs_dict
+
+
+@require_torch
+class SuperPointModelTest(ModelTesterMixin, unittest.TestCase):
+    all_model_classes = (SuperPointModel,) if is_torch_available() else ()
+    all_generative_model_classes = () if is_torch_available() else ()
+
+    fx_compatible = False
+    test_pruning = False
+    test_resize_embeddings = False
+    test_head_masking = False
+    has_attentions = False
+
+    def setUp(self):
+        self.model_tester = SuperPointModelTester(self)
+        self.config_tester = ConfigTester(self, config_class=SuperPointConfig, has_text_modality=False, hidden_size=37)
+
+    def test_config(self):
+        self.create_and_test_config_common_properties()
+        self.config_tester.create_and_test_config_to_json_string()
+        self.config_tester.create_and_test_config_to_json_file()
+        self.config_tester.create_and_test_config_from_and_save_pretrained()
+        self.config_tester.create_and_test_config_with_num_labels()
+        self.config_tester.check_config_can_be_init_without_params()
+        self.config_tester.check_config_arguments_init()
+
+    def create_and_test_config_common_properties(self):
+        return
+
+    @unittest.skip(reason="SuperPointModel does not use inputs_embeds")
+    def test_inputs_embeds(self):
+        pass
+
+    @unittest.skip(reason="SuperPointModel does not support input and output embeddings")
+    def test_model_common_attributes(self):
+        pass
+
+    @unittest.skip(reason="SuperPointModel does not use feedforward chunking")
+    def test_feed_forward_chunking(self):
+        pass
+
+    @unittest.skip(reason="SuperPointModel is not trainable")
+    def test_training(self):
+        pass
+
+    @unittest.skip(reason="SuperPointModel is not trainable")
+    def test_training_gradient_checkpointing(self):
+        pass
+
+    @unittest.skip(reason="SuperPointModel is not trainable")
+    def test_training_gradient_checkpointing_use_reentrant(self):
+        pass
+
+    @unittest.skip(reason="SuperPointModel is not trainable")
+    def test_training_gradient_checkpointing_use_reentrant_false(self):
+        pass
+
+    @unittest.skip(reason="SuperPoint does not output any loss term in the forward pass")
+    def test_retain_grad_hidden_states_attentions(self):
+        pass
+
+    def test_model(self):
+        config_and_inputs = self.model_tester.prepare_config_and_inputs()
+        self.model_tester.create_and_check_model(*config_and_inputs)
+
+    def test_forward_signature(self):
+        config, _ = self.model_tester.prepare_config_and_inputs()
+
+        for model_class in self.all_model_classes:
+            model = model_class(config)
+            signature = inspect.signature(model.forward)
+            # signature.parameters is an OrderedDict => so arg_names order is deterministic
+            arg_names = [*signature.parameters.keys()]
+
+            expected_arg_names = ["pixel_values"]
+            self.assertListEqual(arg_names[:1], expected_arg_names)
+
+    def test_hidden_states_output(self):
+        def check_hidden_states_output(inputs_dict, config, model_class):
+            model = model_class(config)
+            model.to(torch_device)
+            model.eval()
+
+            with torch.no_grad():
+                outputs = model(**self._prepare_for_class(inputs_dict, model_class))
+
+            hidden_states = outputs.hidden_states
+
+            # SuperPoint's feature maps are of shape (batch_size, num_channels, width, height)
+            for i, conv_layer_size in enumerate(self.model_tester.encoder_hidden_sizes[:-1]):
+                self.assertListEqual(
+                    list(hidden_states[i].shape[-3:]),
+                    [
+                        conv_layer_size,
+                        self.model_tester.image_height // (2 ** (i + 1)),
+                        self.model_tester.image_width // (2 ** (i + 1)),
+                    ],
+                )
+
+        config, inputs_dict = self.model_tester.prepare_config_and_inputs_for_common()
+
+        for model_class in self.all_model_classes:
+            inputs_dict["output_hidden_states"] = True
+            check_hidden_states_output(inputs_dict, config, model_class)
+
+            # check that output_hidden_states also work using config
+            del inputs_dict["output_hidden_states"]
+            config.output_hidden_states = True
+
+            check_hidden_states_output(inputs_dict, config, model_class)
+
+    @slow
+    def test_model_from_pretrained(self):
+        for model_name in SUPERPOINT_PRETRAINED_MODEL_ARCHIVE_LIST[:1]:
+            model = SuperPointModel.from_pretrained(model_name)
+            self.assertIsNotNone(model)
+
+    def test_forward_labels_should_be_none(self):
+        config, inputs_dict = self.model_tester.prepare_config_and_inputs_for_common()
+        for model_class in self.all_model_classes:
+            model = model_class(config)
+            model.to(torch_device)
+            model.eval()
+
+            with torch.no_grad():
+                model_inputs = self._prepare_for_class(inputs_dict, model_class)
+                # Provide an arbitrary sized Tensor as labels to model inputs
+                model_inputs["labels"] = torch.rand((128, 128))
+
+                with self.assertRaises(ValueError) as cm:
+                    model(**model_inputs)
+                self.assertEqual(ValueError, cm.exception.__class__)
+
+
+def prepare_imgs():
+    image1 = Image.open("./tests/fixtures/tests_samples/COCO/000000039769.png")
+    image2 = Image.open("./tests/fixtures/tests_samples/COCO/000000004016.png")
+    return [image1, image2]
+
+
+@require_torch
+@require_vision
+class SuperPointModelIntegrationTest(unittest.TestCase):
+    @cached_property
+    def default_image_processor(self):
+        return AutoImageProcessor.from_pretrained("magic-leap-community/superpoint") if is_vision_available() else None
+
+    @slow
+    def test_inference(self):
+        model = SuperPointModel.from_pretrained("magic-leap-community/superpoint").to(torch_device)
+        preprocessor = self.default_image_processor
+        images = prepare_imgs()
+        inputs = preprocessor(images=images, return_tensors="pt").to(torch_device)
+        with torch.no_grad():
+            outputs = model(**inputs)
+        expected_number_keypoints_image0 = 567
+        expected_number_keypoints_image1 = 830
+        expected_max_number_keypoints = max(expected_number_keypoints_image0, expected_number_keypoints_image1)
+        expected_keypoints_shape = torch.Size((len(images), expected_max_number_keypoints, 2))
+        expected_scores_shape = torch.Size(
+            (
+                len(images),
+                expected_max_number_keypoints,
+            )
+        )
+        expected_descriptors_shape = torch.Size((len(images), expected_max_number_keypoints, 256))
+        # Check output shapes
+        self.assertEqual(outputs.keypoints.shape, expected_keypoints_shape)
+        self.assertEqual(outputs.scores.shape, expected_scores_shape)
+        self.assertEqual(outputs.descriptors.shape, expected_descriptors_shape)
+        expected_keypoints_image0_values = torch.tensor([[480.0, 9.0], [494.0, 9.0], [489.0, 16.0]]).to(torch_device)
+        expected_scores_image0_values = torch.tensor(
+            [0.0064, 0.0137, 0.0589, 0.0723, 0.5166, 0.0174, 0.1515, 0.2054, 0.0334]
+        ).to(torch_device)
+        expected_descriptors_image0_value = torch.tensor(-0.1096).to(torch_device)
+        predicted_keypoints_image0_values = outputs.keypoints[0, :3]
+        predicted_scores_image0_values = outputs.scores[0, :9]
+        predicted_descriptors_image0_value = outputs.descriptors[0, 0, 0]
+        # Check output values
+        self.assertTrue(
+            torch.allclose(
+                predicted_keypoints_image0_values,
+                expected_keypoints_image0_values,
+                atol=1e-4,
+            )
+        )
+        self.assertTrue(torch.allclose(predicted_scores_image0_values, expected_scores_image0_values, atol=1e-4))
+        self.assertTrue(
+            torch.allclose(
+                predicted_descriptors_image0_value,
+                expected_descriptors_image0_value,
+                atol=1e-4,
+            )
+        )
+        # Check mask values
+        self.assertTrue(outputs.mask[0, expected_number_keypoints_image0 - 1].item() == 1)
+        self.assertTrue(outputs.mask[0, expected_number_keypoints_image0].item() == 0)
+        self.assertTrue(torch.all(outputs.mask[0, : expected_number_keypoints_image0 - 1]))
+        self.assertTrue(torch.all(torch.logical_not(outputs.mask[0, expected_number_keypoints_image0:])))
+        self.assertTrue(torch.all(outputs.mask[1]))
