Merge branch 'comfyanonymous:master' into custom-node-socket

comfy/ldm/models/diffusion/ddim.py

@@ -18,7 +18,7 @@ class DDIMSampler(object):
     def register_buffer(self, name, attr):
         if type(attr) == torch.Tensor:
             if attr.device != self.device:
-                attr = attr.to(self.device)
+                attr = attr.float().to(self.device)
         setattr(self, name, attr)

     def make_schedule(self, ddim_num_steps, ddim_discretize="uniform", ddim_eta=0., verbose=True):

comfy/model_management.py

@@ -4,6 +4,7 @@ NO_VRAM = 1
 LOW_VRAM = 2
 NORMAL_VRAM = 3
 HIGH_VRAM = 4
+MPS = 5

 accelerate_enabled = False
 vram_state = NORMAL_VRAM
@@ -76,10 +77,16 @@ if set_vram_to == LOW_VRAM or set_vram_to == NO_VRAM:
     total_vram_available_mb = (total_vram - 1024) // 2
     total_vram_available_mb = int(max(256, total_vram_available_mb))

+try:
+    if torch.backends.mps.is_available():
+        vram_state = MPS
+except:
+    pass
+
 if "--cpu" in sys.argv:
     vram_state = CPU

-print("Set vram state to:", ["CPU", "NO VRAM", "LOW VRAM", "NORMAL VRAM", "HIGH VRAM"][vram_state])
+print("Set vram state to:", ["CPU", "NO VRAM", "LOW VRAM", "NORMAL VRAM", "HIGH VRAM", "MPS"][vram_state])


 current_loaded_model = None
@@ -128,6 +135,10 @@ def load_model_gpu(model):
     current_loaded_model = model
     if vram_state == CPU:
         pass
+    elif vram_state == MPS:
+        mps_device = torch.device("mps")
+        real_model.to(mps_device)
+        pass
     elif vram_state == NORMAL_VRAM or vram_state == HIGH_VRAM:
         model_accelerated = False
         real_model.cuda()
@@ -155,9 +166,10 @@ def load_controlnet_gpu(models):
         if m not in models:
             m.cpu()

+    device = get_torch_device()
     current_gpu_controlnets = []
     for m in models:
-        current_gpu_controlnets.append(m.cuda())
+        current_gpu_controlnets.append(m.to(device))


 def load_if_low_vram(model):
@@ -173,6 +185,8 @@ def unload_if_low_vram(model):
     return model

 def get_torch_device():
+    if vram_state == MPS:
+        return torch.device("mps")
     if vram_state == CPU:
         return torch.device("cpu")
     else:
@@ -195,7 +209,7 @@ def get_free_memory(dev=None, torch_free_too=False):
     if dev is None:
         dev = get_torch_device()

-    if hasattr(dev, 'type') and dev.type == 'cpu':
+    if hasattr(dev, 'type') and (dev.type == 'cpu' or dev.type == 'mps'):
         mem_free_total = psutil.virtual_memory().available
         mem_free_torch = mem_free_total
     else:
@@ -224,8 +238,12 @@ def cpu_mode():
     global vram_state
     return vram_state == CPU

+def mps_mode():
+    global vram_state
+    return vram_state == MPS
+
 def should_use_fp16():
-    if cpu_mode():
+    if cpu_mode() or mps_mode():
         return False #TODO ?

     if torch.cuda.is_bf16_supported():

comfy/samplers.py

@@ -450,7 +450,7 @@ class KSampler:
                 noise_mask = None
                 if denoise_mask is not None:
                     noise_mask = 1.0 - denoise_mask
-                sampler = DDIMSampler(self.model)
+                sampler = DDIMSampler(self.model, device=self.device)
                 sampler.make_schedule_timesteps(ddim_timesteps=timesteps, verbose=False)
                 z_enc = sampler.stochastic_encode(latent_image, torch.tensor([len(timesteps) - 1] * noise.shape[0]).to(self.device), noise=noise, max_denoise=max_denoise)
                 samples, _ = sampler.sample_custom(ddim_timesteps=timesteps,

nodes.py

@@ -241,8 +241,8 @@ class LoraLoader:
         return {"required": { "model": ("MODEL",),
                               "clip": ("CLIP", ),
                               "lora_name": (folder_paths.get_filename_list("loras"), ),
-                              "strength_model": ("FLOAT", {"default": 1.0, "min": 0.0, "max": 10.0, "step": 0.01}),
-                              "strength_clip": ("FLOAT", {"default": 1.0, "min": 0.0, "max": 10.0, "step": 0.01}),
+                              "strength_model": ("FLOAT", {"default": 1.0, "min": -10.0, "max": 10.0, "step": 0.01}),
+                              "strength_clip": ("FLOAT", {"default": 1.0, "min": -10.0, "max": 10.0, "step": 0.01}),
                               }}
     RETURN_TYPES = ("MODEL", "CLIP")
     FUNCTION = "load_lora"
@@ -752,7 +752,7 @@ class SaveImage:

         full_output_folder = os.path.join(self.output_dir, subfolder)

-        if os.path.commonpath((self.output_dir, os.path.realpath(full_output_folder))) != self.output_dir:
+        if os.path.commonpath((self.output_dir, os.path.abspath(full_output_folder))) != self.output_dir:
             print("Saving image outside the output folder is not allowed.")
             return {}

@@ -908,6 +908,69 @@ class ImageInvert:
         return (s,)


+class ImagePadForOutpaint:
+
+    @classmethod
+    def INPUT_TYPES(s):
+        return {
+            "required": {
+                "image": ("IMAGE",),
+                "left": ("INT", {"default": 0, "min": 0, "max": MAX_RESOLUTION, "step": 64}),
+                "top": ("INT", {"default": 0, "min": 0, "max": MAX_RESOLUTION, "step": 64}),
+                "right": ("INT", {"default": 0, "min": 0, "max": MAX_RESOLUTION, "step": 64}),
+                "bottom": ("INT", {"default": 0, "min": 0, "max": MAX_RESOLUTION, "step": 64}),
+                "feathering": ("INT", {"default": 40, "min": 0, "max": MAX_RESOLUTION, "step": 1}),
+            }
+        }
+
+    RETURN_TYPES = ("IMAGE", "MASK")
+    FUNCTION = "expand_image"
+
+    CATEGORY = "image"
+
+    def expand_image(self, image, left, top, right, bottom, feathering):
+        d1, d2, d3, d4 = image.size()
+
+        new_image = torch.zeros(
+            (d1, d2 + top + bottom, d3 + left + right, d4),
+            dtype=torch.float32,
+        )
+        new_image[:, top:top + d2, left:left + d3, :] = image
+
+        mask = torch.ones(
+            (d2 + top + bottom, d3 + left + right),
+            dtype=torch.float32,
+        )
+
+        t = torch.zeros(
+            (d2, d3),
+            dtype=torch.float32
+        )
+
+        if feathering > 0 and feathering * 2 < d2 and feathering * 2 < d3:
+
+            for i in range(d2):
+                for j in range(d3):
+                    dt = i if top != 0 else d2
+                    db = d2 - i if bottom != 0 else d2
+
+                    dl = j if left != 0 else d3
+                    dr = d3 - j if right != 0 else d3
+
+                    d = min(dt, db, dl, dr)
+
+                    if d >= feathering:
+                        continue
+
+                    v = (feathering - d) / feathering
+
+                    t[i, j] = v * v
+
+        mask[top:top + d2, left:left + d3] = t
+
+        return (new_image, mask)
+
+
 NODE_CLASS_MAPPINGS = {
     "KSampler": KSampler,
     "CheckpointLoader": CheckpointLoader,
@@ -926,6 +989,7 @@ NODE_CLASS_MAPPINGS = {
     "LoadImageMask": LoadImageMask,
     "ImageScale": ImageScale,
     "ImageInvert": ImageInvert,
+    "ImagePadForOutpaint": ImagePadForOutpaint,
     "ConditioningCombine": ConditioningCombine,
     "ConditioningSetArea": ConditioningSetArea,
     "KSamplerAdvanced": KSamplerAdvanced,

notebooks/comfyui_colab.ipynb

 {
-  "nbformat": 4,
-  "nbformat_minor": 0,
-  "metadata": {
-    "colab": {
-      "provenance": []
-    },
-    "kernelspec": {
-      "name": "python3",
-      "display_name": "Python 3"
-    },
-    "language_info": {
-      "name": "python"
-    },
-    "accelerator": "GPU",
-    "gpuClass": "standard"
-  },
   "cells": [
     {
       "cell_type": "markdown",
-      "source": [
-        "Git clone the repo and install the requirements. (ignore the pip errors about protobuf)"
-      ],
       "metadata": {
         "id": "aaaaaaaaaa"
-      }
+      },
+      "source": [
+        "Git clone the repo and install the requirements. (ignore the pip errors about protobuf)"
+      ]
     },
     {
       "cell_type": "code",
@@ -33,22 +17,55 @@
       },
       "outputs": [],
       "source": [
-        "!git clone https://github.com/comfyanonymous/ComfyUI\n",
-        "%cd ComfyUI\n",
-        "!pip install xformers -r requirements.txt"
+        "#@title Environment Setup\n",
+        "\n",
+        "from pathlib import Path\n",
+        "\n",
+        "OPTIONS = {}\n",
+        "\n",
+        "USE_GOOGLE_DRIVE = False  #@param {type:\"boolean\"}\n",
+        "UPDATE_COMFY_UI = True  #@param {type:\"boolean\"}\n",
+        "WORKSPACE = 'ComfyUI'\n",
+        "OPTIONS['USE_GOOGLE_DRIVE'] = USE_GOOGLE_DRIVE\n",
+        "OPTIONS['UPDATE_COMFY_UI'] = UPDATE_COMFY_UI\n",
+        "\n",
+        "if OPTIONS['USE_GOOGLE_DRIVE']:\n",
+        "    !echo \"Mounting Google Drive...\"\n",
+        "    %cd /\n",
+        "    \n",
+        "    from google.colab import drive\n",
+        "    drive.mount('/content/drive')\n",
+        "\n",
+        "    WORKSPACE = \"/content/drive/MyDrive/ComfyUI\"\n",
+        "    %cd /content/drive/MyDrive\n",
+        "\n",
+        "![ ! -d $WORKSPACE ] && echo -= Initial setup ComfyUI =- && git clone https://github.com/comfyanonymous/ComfyUI\n",
+        "%cd $WORKSPACE\n",
+        "\n",
+        "if OPTIONS['UPDATE_COMFY_UI']:\n",
+        "  !echo -= Updating ComfyUI =-\n",
+        "  !git pull\n",
+        "\n",
+        "!echo -= Install dependencies =-\n",
+        "!pip -q install xformers -r requirements.txt"
       ]
     },
     {
       "cell_type": "markdown",
-      "source": [
-        "Download some models/checkpoints/vae or custom comfyui nodes (uncomment the commands for the ones you want)"
-      ],
       "metadata": {
         "id": "cccccccccc"
-      }
+      },
+      "source": [
+        "Download some models/checkpoints/vae or custom comfyui nodes (uncomment the commands for the ones you want)"
+      ]
     },
     {
       "cell_type": "code",
+      "execution_count": null,
+      "metadata": {
+        "id": "dddddddddd"
+      },
+      "outputs": [],
       "source": [
         "# Checkpoints\n",
         "\n",
@@ -110,26 +127,26 @@
         "#!wget -c https://huggingface.co/sberbank-ai/Real-ESRGAN/resolve/main/RealESRGAN_x4.pth -P ./models/upscale_models/\n",
         "\n",
         "\n"
-      ],
-      "metadata": {
-        "id": "dddddddddd"
-      },
-      "execution_count": null,
-      "outputs": []
+      ]
     },
     {
       "cell_type": "markdown",
+      "metadata": {
+        "id": "kkkkkkkkkkkkkk"
+      },
       "source": [
         "### Run ComfyUI with localtunnel (Recommended Way)\n",
         "\n",
         "\n"
-      ],
-      "metadata": {
-        "id": "kkkkkkkkkkkkkk"
-      }
+      ]
     },
     {
       "cell_type": "code",
+      "execution_count": null,
+      "metadata": {
+        "id": "jjjjjjjjjjjjj"
+      },
+      "outputs": [],
       "source": [
         "!npm install -g localtunnel\n",
         "\n",
@@ -154,15 +171,13 @@
         "threading.Thread(target=iframe_thread, daemon=True, args=(8188,)).start()\n",
         "\n",
         "!python main.py --dont-print-server"
-      ],
-      "metadata": {
-        "id": "jjjjjjjjjjjjj"
-      },
-      "execution_count": null,
-      "outputs": []
+      ]
     },
     {
       "cell_type": "markdown",
+      "metadata": {
+        "id": "gggggggggg"
+      },
       "source": [
         "### Run ComfyUI with colab iframe (use only in case the previous way with localtunnel doesn't work)\n",
         "\n",
@@ -171,13 +186,15 @@
         "If you want to open it in another window use the link.\n",
         "\n",
         "Note that some UI features like live image previews won't work because the colab iframe blocks websockets."
-      ],
-      "metadata": {
-        "id": "gggggggggg"
-      }
+      ]
     },
     {
       "cell_type": "code",
+      "execution_count": null,
+      "metadata": {
+        "id": "hhhhhhhhhh"
+      },
+      "outputs": [],
       "source": [
         "import threading\n",
         "import time\n",
@@ -198,12 +215,23 @@
         "threading.Thread(target=iframe_thread, daemon=True, args=(8188,)).start()\n",
         "\n",
         "!python main.py --dont-print-server"
-      ],
-      "metadata": {
-        "id": "hhhhhhhhhh"
-      },
-      "execution_count": null,
-      "outputs": []
+      ]
     }
-  ]
-}
+  ],
+  "metadata": {
\ No newline at end of file
+    "accelerator": "GPU",
+    "colab": {
+      "provenance": []
+    },
+    "gpuClass": "standard",
+    "kernelspec": {
+      "display_name": "Python 3",
+      "name": "python3"
+    },
+    "language_info": {
+      "name": "python"
+    }
+  },
+  "nbformat": 4,
+  "nbformat_minor": 0
+}

server.py

@@ -127,7 +127,7 @@ class PromptServer():
                 output_dir = os.path.join(os.path.dirname(os.path.realpath(__file__)), type)
                 if "subfolder" in request.rel_url.query:
                     full_output_dir = os.path.join(output_dir, request.rel_url.query["subfolder"])
-                    if os.path.commonpath((os.path.realpath(full_output_dir), output_dir)) != output_dir:
+                    if os.path.commonpath((os.path.abspath(full_output_dir), output_dir)) != output_dir:
                         return web.Response(status=403)
                     output_dir = full_output_dir


web/extensions/core/widgetInputs.js

+import { ComfyWidgets, addRandomizeWidget } from "/scripts/widgets.js";
+import { app } from "/scripts/app.js";
+
+const CONVERTED_TYPE = "converted-widget";
+const VALID_TYPES = ["STRING", "combo", "number"];
+
+function isConvertableWidget(widget, config) {
+	return VALID_TYPES.includes(widget.type) || VALID_TYPES.includes(config[0]);
+}
+
+function hideWidget(node, widget, suffix = "") {
+	widget.origType = widget.type;
+	widget.origComputeSize = widget.computeSize;
+	widget.origSerializeValue = widget.serializeValue;
+	widget.computeSize = () => [0, -4]; // -4 is due to the gap litegraph adds between widgets automatically
+	widget.type = CONVERTED_TYPE + suffix;
+	widget.serializeValue = () => {
+		// Prevent serializing the widget if we have no input linked
+		const { link } = node.inputs.find((i) => i.widget?.name === widget.name);
+		if (link == null) {
+			return undefined;
+		}
+		return widget.value;
+	};
+
+	// Hide any linked widgets, e.g. seed+randomize
+	if (widget.linkedWidgets) {
+		for (const w of widget.linkedWidgets) {
+			hideWidget(node, w, ":" + widget.name);
+		}
+	}
+}
+
+function showWidget(widget) {
+	widget.type = widget.origType;
+	widget.computeSize = widget.origComputeSize;
+	widget.serializeValue = widget.origSerializeValue;
+
+	delete widget.origType;
+	delete widget.origComputeSize;
+	delete widget.origSerializeValue;
+
+	// Hide any linked widgets, e.g. seed+randomize
+	if (widget.linkedWidgets) {
+		for (const w of widget.linkedWidgets) {
+			showWidget(w);
+		}
+	}
+}
+
+function convertToInput(node, widget, config) {
+	hideWidget(node, widget);
+
+	const { linkType } = getWidgetType(config);
+
+	// Add input and store widget config for creating on primitive node
+	const sz = node.size;
+	node.addInput(widget.name, linkType, {
+		widget: { name: widget.name, config },
+	});
+
+	// Restore original size but grow if needed
+	node.setSize([Math.max(sz[0], node.size[0]), Math.max(sz[1], node.size[1])]);
+}
+
+function convertToWidget(node, widget) {
+	showWidget(widget);
+	const sz = node.size;
+	node.removeInput(node.inputs.findIndex((i) => i.widget?.name === widget.name));
+
+	// Restore original size but grow if needed
+	node.setSize([Math.max(sz[0], node.size[0]), Math.max(sz[1], node.size[1])]);
+}
+
+function getWidgetType(config) {
+	// Special handling for COMBO so we restrict links based on the entries
+	let type = config[0];
+	let linkType = type;
+	if (type instanceof Array) {
+		type = "COMBO";
+		linkType = linkType.join(",");
+	}
+	return { type, linkType };
+}
+
+app.registerExtension({
+	name: "Comfy.WidgetInputs",
+	async beforeRegisterNodeDef(nodeType, nodeData, app) {
+		// Add menu options to conver to/from widgets
+		const origGetExtraMenuOptions = nodeType.prototype.getExtraMenuOptions;
+		nodeType.prototype.getExtraMenuOptions = function (_, options) {
+			const r = origGetExtraMenuOptions ? origGetExtraMenuOptions.apply(this, arguments) : undefined;
+
+			if (this.widgets) {
+				let toInput = [];
+				let toWidget = [];
+				for (const w of this.widgets) {
+					if (w.type === CONVERTED_TYPE) {
+						toWidget.push({
+							content: `Convert ${w.name} to widget`,
+							callback: () => convertToWidget(this, w),
+						});
+					} else {
+						const config = nodeData?.input?.required[w.name] || [w.type, w.options || {}];
+						if (isConvertableWidget(w, config)) {
+							toInput.push({
+								content: `Convert ${w.name} to input`,
+								callback: () => convertToInput(this, w, config),
+							});
+						}
+					}
+				}
+				if (toInput.length) {
+					options.push(...toInput, null);
+				}
+
+				if (toWidget.length) {
+					options.push(...toWidget, null);
+				}
+			}
+
+			return r;
+		};
+
+		// On initial configure of nodes hide all converted widgets
+		const origOnConfigure = nodeType.prototype.onConfigure;
+		nodeType.prototype.onConfigure = function () {
+			const r = origOnConfigure ? origOnConfigure.apply(this, arguments) : undefined;
+
+			if (this.inputs) {
+				for (const input of this.inputs) {
+					if (input.widget) {
+						const w = this.widgets.find((w) => w.name === input.widget.name);
+						if (w) {
+							hideWidget(this, w);
+						} else {
+							convertToWidget(this, input)
+						}
+					}
+				}
+			}
+
+			return r;
+		};
+
+		function isNodeAtPos(pos) {
+			for (const n of app.graph._nodes) {
+				if (n.pos[0] === pos[0] && n.pos[1] === pos[1]) {
+					return true;
+				}
+			}
+			return false;
+		}
+
+		// Double click a widget input to automatically attach a primitive
+		const origOnInputDblClick = nodeType.prototype.onInputDblClick;
+		const ignoreDblClick = Symbol();
+		nodeType.prototype.onInputDblClick = function (slot) {
+			const r = origOnInputDblClick ? origOnInputDblClick.apply(this, arguments) : undefined;
+
+			const input = this.inputs[slot];
+			if (input.widget && !input[ignoreDblClick]) {
+				const node = LiteGraph.createNode("PrimitiveNode");
+				app.graph.add(node);
+
+				// Calculate a position that wont directly overlap another node
+				const pos = [this.pos[0] - node.size[0] - 30, this.pos[1]];
+				while (isNodeAtPos(pos)) {
+					pos[1] += LiteGraph.NODE_TITLE_HEIGHT;
+				}
+
+				node.pos = pos;
+				node.connect(0, this, slot);
+				node.title = input.name;
+
+				// Prevent adding duplicates due to triple clicking
+				input[ignoreDblClick] = true;
+				setTimeout(() => {
+					delete input[ignoreDblClick];
+				}, 300);
+			}
+
+			return r;
+		};
+	},
+	registerCustomNodes() {
+		class PrimitiveNode {
+			constructor() {
+				this.addOutput("connect to widget input", "*");
+				this.serialize_widgets = true;
+				this.isVirtualNode = true;
+			}
+
+			applyToGraph() {
+				if (!this.outputs[0].links?.length) return;
+
+				// For each output link copy our value over the original widget value
+				for (const l of this.outputs[0].links) {
+					const linkInfo = app.graph.links[l];
+					const node = this.graph.getNodeById(linkInfo.target_id);
+					const input = node.inputs[linkInfo.target_slot];
+					const widgetName = input.widget.name;
+					if (widgetName) {
+						const widget = node.widgets.find((w) => w.name === widgetName);
+						if (widget) {
+							widget.value = this.widgets[0].value;
+							if (widget.callback) {
+								widget.callback(widget.value, app.canvas, node, app.canvas.graph_mouse, {});
+							}
+						}
+					}
+				}
+			}
+
+			onConnectionsChange(_, index, connected) {
+				if (connected) {
+					if (this.outputs[0].links?.length) {
+						if (!this.widgets?.length) {
+							this.#onFirstConnection();
+						}
+						if (!this.widgets?.length && this.outputs[0].widget) {
+							// On first load it often cant recreate the widget as the other node doesnt exist yet
+							// Manually recreate it from the output info
+							this.#createWidget(this.outputs[0].widget.config);
+						}
+					}
+				} else if (!this.outputs[0].links?.length) {
+					this.#onLastDisconnect();
+				}
+			}
+
+			onConnectOutput(slot, type, input, target_node, target_slot) {
+				// Fires before the link is made allowing us to reject it if it isn't valid
+
+				// No widget, we cant connect
+				if (!input.widget) return false;
+
+				if (this.outputs[slot].links?.length) {
+					return this.#isValidConnection(input);
+				}
+			}
+
+			#onFirstConnection() {
+				// First connection can fire before the graph is ready on initial load so random things can be missing
+				const linkId = this.outputs[0].links[0];
+				const link = this.graph.links[linkId];
+				if (!link) return;
+
+				const theirNode = this.graph.getNodeById(link.target_id);
+				if (!theirNode || !theirNode.inputs) return;
+
+				const input = theirNode.inputs[link.target_slot];
+				if (!input) return;
+
+				const widget = input.widget;
+				const { type, linkType } = getWidgetType(widget.config);
+
+				// Update our output to restrict to the widget type
+				this.outputs[0].type = linkType;
+				this.outputs[0].name = type;
+				this.outputs[0].widget = widget;
+
+				this.#createWidget(widget.config, theirNode, widget.name);
+			}
+
+			#createWidget(inputData, node, widgetName) {
+				let type = inputData[0];
+
+				if (type instanceof Array) {
+					type = "COMBO";
+				}
+
+				let widget;
+				if (type in ComfyWidgets) {
+					widget = (ComfyWidgets[type](this, "value", inputData, app) || {}).widget;
+				} else {
+					widget = this.addWidget(type, "value", null, () => {}, {});
+				}
+
+				if (node?.widgets && widget) {
+					const theirWidget = node.widgets.find((w) => w.name === widgetName);
+					if (theirWidget) {
+						widget.value = theirWidget.value;
+					}
+				}
+
+				if (widget.type === "number") {
+					addRandomizeWidget(this, widget, "Random after every gen");
+				}
+
+				// When our value changes, update other widgets to reflect our changes
+				// e.g. so LoadImage shows correct image
+				const callback = widget.callback;
+				const self = this;
+				widget.callback = function () {
+					const r = callback ? callback.apply(this, arguments) : undefined;
+					self.applyToGraph();
+					return r;
+				};
+
+				// Grow our node if required
+				const sz = this.computeSize();
+				if (this.size[0] < sz[0]) {
+					this.size[0] = sz[0];
+				}
+				if (this.size[1] < sz[1]) {
+					this.size[1] = sz[1];
+				}
+
+				requestAnimationFrame(() => {
+					if (this.onResize) {
+						this.onResize(this.size);
+					}
+				});
+			}
+
+			#isValidConnection(input) {
+				// Only allow connections where the configs match
+				const config1 = this.outputs[0].widget.config;
+				const config2 = input.widget.config;
+
+				if (config1[0] !== config2[0]) return false;
+
+				for (const k in config1[1]) {
+					if (k !== "default") {
+						if (config1[1][k] !== config2[1][k]) {
+							return false;
+						}
+					}
+				}
+
+				return true;
+			}
+
+			#onLastDisconnect() {
+				// We cant remove + re-add the output here as if you drag a link over the same link
+				// it removes, then re-adds, causing it to break
+				this.outputs[0].type = "*";
+				this.outputs[0].name = "connect to widget input";
+				delete this.outputs[0].widget;
+
+				if (this.widgets) {
+					// Allow widgets to cleanup
+					for (const w of this.widgets) {
+						if (w.onRemove) {
+							w.onRemove();
+						}
+					}
+					this.widgets.length = 0;
+				}
+			}
+		}
+
+		LiteGraph.registerNodeType(
+			"PrimitiveNode",
+			Object.assign(PrimitiveNode, {
+				title: "Primitive",
+			})
+		);
+		PrimitiveNode.category = "utils";
+	},
+});

web/index.html

 <!DOCTYPE html>
 <html lang="en">
 	<head>
+		<meta charset="UTF-8">
+		<meta name="viewport" content="width=device-width, initial-scale=1.0, user-scalable=no">
 		<link rel="stylesheet" type="text/css" href="lib/litegraph.css" />
 		<link rel="stylesheet" type="text/css" href="style.css" />
 		<script type="text/javascript" src="lib/litegraph.core.js"></script>
-
 		<script type="module">
 			import { app } from "/scripts/app.js";
 			await app.setup();

web/jsconfig.json

+{
+	"compilerOptions": {
+		"baseUrl": ".",
+		"paths": {
+			"/*": ["./*"]
+		}
+	},
+	"include": ["."]
+}

web/lib/litegraph.core.js

@@ -108,7 +108,7 @@
 		node_box_coloured_when_on: false, // [true!] this make the nodes box (top left circle) coloured when triggered (execute/action), visual feedback
         node_box_coloured_by_mode: false, // [true!] nodebox based on node mode, visual feedback

-        dialog_close_on_mouse_leave: true, // [false on mobile] better true if not touch device, TODO add an helper/listener to close if false
+        dialog_close_on_mouse_leave: false, // [false on mobile] better true if not touch device, TODO add an helper/listener to close if false
         dialog_close_on_mouse_leave_delay: 500,

         shift_click_do_break_link_from: false, // [false!] prefer false if results too easy to break links - implement with ALT or TODO custom keys
@@ -138,7 +138,7 @@

 		release_link_on_empty_shows_menu: false, //[true!] dragging a link to empty space will open a menu, add from list, search or defaults

-        pointerevents_method: "mouse", // "mouse"|"pointer" use mouse for retrocompatibility issues? (none found @ now)
+        pointerevents_method: "pointer", // "mouse"|"pointer" use mouse for retrocompatibility issues? (none found @ now)
         // TODO implement pointercancel, gotpointercapture, lostpointercapture, (pointerover, pointerout if necessary)

         /**
@@ -5801,7 +5801,7 @@ LGraphNode.prototype.executeAction = function(action)
         var skip_action = false;
         var now = LiteGraph.getTime();
 		var is_primary = (e.isPrimary === undefined || !e.isPrimary);
-        var is_double_click = (now - this.last_mouseclick < 300) && is_primary;
+        var is_double_click = (now - this.last_mouseclick < 300);
 		this.mouse[0] = e.clientX;
 		this.mouse[1] = e.clientY;
         this.graph_mouse[0] = e.canvasX;

web/scripts/app.js

@@ -486,6 +486,27 @@ class ComfyApp {
 		}
 	}

+	/**
+	 * Setup slot colors for types
+	 */
+	setupSlotColors() {
+		let colors = {
+			"CLIP": "#FFD500", // bright yellow
+			"CLIP_VISION": "#A8DADC", // light blue-gray
+			"CLIP_VISION_OUTPUT": "#ad7452", // rusty brown-orange
+			"CONDITIONING": "#FFA931", // vibrant orange-yellow
+			"CONTROL_NET": "#6EE7B7", // soft mint green
+			"IMAGE": "#64B5F6", // bright sky blue
+			"LATENT": "#FF9CF9", // light pink-purple
+			"MASK": "#81C784", // muted green
+			"MODEL": "#B39DDB", // light lavender-purple
+			"STYLE_MODEL": "#C2FFAE", // light green-yellow
+			"VAE": "#FF6E6E", // bright red
+		};
+
+		Object.assign(this.canvas.default_connection_color_byType, colors);
+	}
+
 	/**
 	 * Set up the app on the page
 	 */
@@ -494,13 +515,15 @@ class ComfyApp {

 		// Create and mount the LiteGraph in the DOM
 		const canvasEl = (this.canvasEl = Object.assign(document.createElement("canvas"), { id: "graph-canvas" }));
-		canvasEl.tabIndex = "1"
+		canvasEl.tabIndex = "1";
 		document.body.prepend(canvasEl);

 		this.graph = new LGraph();
 		const canvas = (this.canvas = new LGraphCanvas(canvasEl, this.graph));
 		this.ctx = canvasEl.getContext("2d");

+		this.setupSlotColors();
+
 		this.graph.start();

 		function resizeCanvas() {
@@ -525,7 +548,9 @@ class ComfyApp {
 				this.loadGraphData(workflow);
 				restored = true;
 			}
-		} catch (err) {}
+		} catch (err) {
+			console.error("Error loading previous workflow", err);
+		}

 		// We failed to restore a workflow so load the default
 		if (!restored) {
@@ -572,12 +597,8 @@ class ComfyApp {
 						const type = inputData[0];

 						if (Array.isArray(type)) {
-							// Enums e.g. latent rotation
-							let defaultValue = type[0];
-							if (inputData[1] && inputData[1].default) {
-								defaultValue = inputData[1].default;
-							}
-							this.addWidget("combo", inputName, defaultValue, () => {}, { values: type });
+							// Enums
+							Object.assign(config, widgets.COMBO(this, inputName, inputData, app) || {});
 						} else if (`${type}:${inputName}` in widgets) {
 							// Support custom widgets by Type:Name
 							Object.assign(config, widgets[`${type}:${inputName}`](this, inputName, inputData, app) || {});
@@ -667,11 +688,15 @@ class ComfyApp {
 	async graphToPrompt() {
 		const workflow = this.graph.serialize();
 		const output = {};
-		for (const n of workflow.nodes) {
-			const node = this.graph.getNodeById(n.id);
+		// Process nodes in order of execution
+		for (const node of this.graph.computeExecutionOrder(false)) {
+			const n = workflow.nodes.find((n) => n.id === node.id);

 			if (node.isVirtualNode) {
-				// Don't serialize frontend only nodes
+				// Don't serialize frontend only nodes but let them make changes
+				if (node.applyToGraph) {
+					node.applyToGraph(workflow);
+				}
 				continue;
 			}

@@ -695,7 +720,11 @@ class ComfyApp {
 					let link = node.getInputLink(i);
 					while (parent && parent.isVirtualNode) {
 						link = parent.getInputLink(link.origin_slot);
-						parent = parent.getInputNode(link.origin_slot);
+						if (link) {
+							parent = parent.getInputNode(link.origin_slot);
+						} else {
+							parent = null;
+						}
 					}

 					if (link) {

web/scripts/ui.js

@@ -35,6 +35,54 @@ function $el(tag, propsOrChildren, children) {
 	return element;
 }

+function dragElement(dragEl) {
+	var posDiffX = 0,
+		posDiffY = 0,
+		posStartX = 0,
+		posStartY = 0,
+		newPosX = 0,
+		newPosY = 0;
+	if (dragEl.getElementsByClassName('drag-handle')[0]) {
+		// if present, the handle is where you move the DIV from:
+		dragEl.getElementsByClassName('drag-handle')[0].onmousedown = dragMouseDown;
+	} else {
+		// otherwise, move the DIV from anywhere inside the DIV:
+		dragEl.onmousedown = dragMouseDown;
+	}
+
+	function dragMouseDown(e) {
+		e = e || window.event;
+		e.preventDefault();
+		// get the mouse cursor position at startup:
+		posStartX = e.clientX;
+		posStartY = e.clientY;
+		document.onmouseup = closeDragElement;
+		// call a function whenever the cursor moves:
+		document.onmousemove = elementDrag;
+	}
+
+	function elementDrag(e) {
+		e = e || window.event;
+		e.preventDefault();
+		// calculate the new cursor position:
+		posDiffX = e.clientX - posStartX;
+		posDiffY = e.clientY - posStartY;
+		posStartX = e.clientX;
+		posStartY = e.clientY;
+		newPosX = Math.min((document.body.clientWidth - dragEl.clientWidth), Math.max(0, (dragEl.offsetLeft + posDiffX)));
+		newPosY = Math.min((document.body.clientHeight - dragEl.clientHeight), Math.max(0, (dragEl.offsetTop + posDiffY)));
+		// set the element's new position:
+		dragEl.style.top = newPosY + "px";
+		dragEl.style.left = newPosX + "px";
+	}
+
+	function closeDragElement() {
+		// stop moving when mouse button is released:
+		document.onmouseup = null;
+		document.onmousemove = null;
+	}
+}
+
 class ComfyDialog {
 	constructor() {
 		this.element = $el("div.comfy-modal", { parent: document.body }, [
@@ -253,6 +301,7 @@ export class ComfyUI {

 		this.menuContainer = $el("div.comfy-menu", { parent: document.body }, [
 			$el("div", { style: { overflow: "hidden", position: "relative", width: "100%" } }, [
+				$el("span.drag-handle"),
 				$el("span", { $: (q) => (this.queueSize = q) }),
 				$el("button.comfy-settings-btn", { textContent: "⚙️", onclick: () => this.settings.show() }),
 			]),
@@ -331,6 +380,8 @@ export class ComfyUI {
 			$el("button", { textContent: "Load Default", onclick: () => app.loadGraphData() }),
 		]);

+		dragElement(this.menuContainer);
+
 		this.setStatus({ exec_info: { queue_remaining: "X" } });
 	}


web/scripts/widgets.js

@@ -10,9 +10,8 @@ function getNumberDefaults(inputData, defaultStep) {
 	return { val: defaultVal, config: { min, max, step: 10.0 * step } };
 }

-function seedWidget(node, inputName, inputData) {
-	const seed = ComfyWidgets.INT(node, inputName, inputData);
-	const randomize = node.addWidget("toggle", "Random seed after every gen", true, function (v) {}, {
+export function addRandomizeWidget(node, targetWidget, name, defaultValue = false) {
+	const randomize = node.addWidget("toggle", name, defaultValue, function (v) {}, {
 		on: "enabled",
 		off: "disabled",
 		serialize: false, // Don't include this in prompt.
@@ -20,14 +19,32 @@ function seedWidget(node, inputName, inputData) {

 	randomize.afterQueued = () => {
 		if (randomize.value) {
-			seed.widget.value = Math.floor(Math.random() * 1125899906842624);
+			const min = targetWidget.options?.min;
+			let max = targetWidget.options?.max;
+			if (min != null || max != null) {
+				if (max) {
+					// limit max to something that javascript can handle
+					max = Math.min(1125899906842624, max);
+				}
+				targetWidget.value = Math.floor(Math.random() * ((max ?? 9999999999) - (min ?? 0) + 1) + (min ?? 0));
+			} else {
+				targetWidget.value = Math.floor(Math.random() * 1125899906842624);
+			}
 		}
 	};
+	return randomize;
+}

+function seedWidget(node, inputName, inputData) {
+	const seed = ComfyWidgets.INT(node, inputName, inputData);
+	const randomize = addRandomizeWidget(node, seed.widget, "Random seed after every gen", true);
+
+	seed.widget.linkedWidgets = [randomize];
 	return { widget: seed, randomize };
 }

 const MultilineSymbol = Symbol();
+const MultilineResizeSymbol = Symbol();

 function addMultilineWidget(node, name, opts, app) {
 	const MIN_SIZE = 50;
@@ -95,7 +112,7 @@ function addMultilineWidget(node, name, opts, app) {
 				// Calculate it here instead
 				computeSize(node.size);
 			}
-			const visible = app.canvas.ds.scale > 0.5;
+			const visible = app.canvas.ds.scale > 0.5 && this.type === "customtext";
 			const t = ctx.getTransform();
 			const margin = 10;
 			Object.assign(this.inputEl.style, {
@@ -149,9 +166,22 @@ function addMultilineWidget(node, name, opts, app) {
 		}
 	};

-	if (!(MultilineSymbol in node)) {
-		node[MultilineSymbol] = true;
-		const onResize = node.onResize;
+	widget.onRemove = () => {
+		widget.inputEl?.remove();
+
+		// Restore original size handler if we are the last
+		if (!--node[MultilineSymbol]) {
+			node.onResize = node[MultilineResizeSymbol];
+			delete node[MultilineSymbol];
+			delete node[MultilineResizeSymbol];
+		}
+	};
+
+	if (node[MultilineSymbol]) {
+		node[MultilineSymbol]++;
+	} else {
+		node[MultilineSymbol] = 1;
+		const onResize = (node[MultilineResizeSymbol] = node.onResize);

 		node.onResize = function (size) {
 			computeSize(size);
@@ -199,6 +229,14 @@ export const ComfyWidgets = {
 			return { widget: node.addWidget("text", inputName, defaultVal, () => {}, {}) };
 		}
 	},
+	COMBO(node, inputName, inputData) {
+		const type = inputData[0];
+		let defaultValue = type[0];
+		if (inputData[1] && inputData[1].default) {
+			defaultValue = inputData[1].default;
+		}
+		return { widget: node.addWidget("combo", inputName, defaultValue, () => {}, { values: type }) };
+	},
 	IMAGEUPLOAD(node, inputName, inputData, app) {
 		const imageWidget = node.widgets.find((w) => w.name === "image");
 		let uploadWidget;

web/style.css

@@ -111,6 +111,31 @@ body {
 	width: 50%;
 }

+.comfy-menu span.drag-handle {
+	width: 10px;
+	height: 20px;
+	display: inline-block;
+	overflow: hidden;
+	line-height: 5px;
+	padding: 3px 4px;
+	cursor: move;
+	vertical-align: middle;
+	margin-top: -.4em;
+	margin-left: -.2em;
+	font-size: 12px;
+	font-family: sans-serif;
+	letter-spacing: 2px;
+	color: #cccccc;
+	text-shadow: 1px 0 1px black;
+	position: absolute;
+	top: 0;
+	left: 0;
+}
+
+.comfy-menu span.drag-handle::after {
+	content: '.. .. ..';
+}
+
 .comfy-queue-btn {
 	width: 100%;
 }
