Commit 7c4f76e3 authored by zhuwenwen's avatar zhuwenwen
Browse files

merge v0.4.0

parents 2da0dd3e 51c31bc1
Expand all Hide whitespace changes
Inline Side-by-side
Showing with 399 additions and 269 deletions
csrc/custom_all_reduce.cuh
View file @ 7c4f76e3
......@@ -23,29 +23,17 @@
namespace vllm {
constexpr int kMaxBlocks = 64;
// note: we don't want to use atomics for signals because peer atomics are no
// supported on PCIe links
struct Signal {
alignas(64) union {
uint64_t flag;
unsigned char data[8];
} start;
alignas(64) union {
uint64_t flag;
unsigned char data[8];
} end;
alignas(128) uint32_t start[kMaxBlocks][8];
alignas(128) uint32_t end[kMaxBlocks][8];
};
struct Metadata {
alignas(128) Signal sg;
alignas(128) int counter;
};
static_assert(offsetof(Metadata, counter) == 128);
static_assert(sizeof(Metadata) == 256);
struct __align__(16) RankData { const void *__restrict__ ptrs[8]; };
struct RankSignals {
volatile Signal *signals[8];
};
struct __align__(16) RankSignals { volatile Signal *signals[8]; };
// like std::array, but aligned
template <typename T, int sz>
......@@ -135,70 +123,49 @@ DINLINE O downcast(array_t<float, O::size> val) {
}
}
// compute flag at compile time
__host__ __device__ constexpr uint64_t compute_flag(int ngpus) {
auto m = std::numeric_limits<uint64_t>::max();
return m >> ((8 - ngpus) * 8);
}
// This function is meant to be used as the first synchronization in the all
// reduce kernel. Thus, it doesn't need to make any visibility guarantees for
// prior memory accesses. Note: volatile writes will not be reordered against
// other volatile writes.
template <int ngpus>
DINLINE void start_sync(const RankSignals &sg, volatile Metadata *meta,
DINLINE void start_sync(const RankSignals &sg, volatile Signal *self_sg,
int rank) {
constexpr auto FLAG = compute_flag(ngpus);
if (blockIdx.x == 0) {
if (threadIdx.x < ngpus)
// simultaneously write to the corresponding byte to all other ranks.
// Latency = 1 p2p write
sg.signals[threadIdx.x]->start.data[rank] = 255;
else if (threadIdx.x == 32)
// reset
meta->sg.end.flag = 0;
}
if (threadIdx.x == 0) {
while (meta->sg.start.flag != FLAG)
if (threadIdx.x < ngpus) {
// reset flag for next time
self_sg->end[blockIdx.x][threadIdx.x] = 0;
// simultaneously write to the corresponding flag of all ranks.
// Latency = 1 p2p write
sg.signals[threadIdx.x]->start[blockIdx.x][rank] = 1;
// wait until we got true from all ranks
while (!self_sg->start[blockIdx.x][threadIdx.x])
;
}
__syncthreads();
}
// This function is meant to be used as the second or the final synchronization
// barrier in the all reduce kernel. If it's the final synchronization barrier,
// we don't need to make any visibility guarantees for prior memory accesses.
template <int ngpus, bool final_sync = false>
DINLINE void end_sync(const RankSignals &sg, volatile Metadata *meta,
DINLINE void end_sync(const RankSignals &sg, volatile Signal *self_sg,
int rank) {
constexpr auto FLAG = compute_flag(ngpus);
__syncthreads();
__shared__ int num;
if (threadIdx.x == 0) num = atomicAdd((int *)&meta->counter, 1);
__syncthreads();
// Only the last completing block can perform the end synchronization
// This can ensures when the final busy wait ends, all ranks must have
// finished reading each other's buffer.
if (num == gridDim.x - 1) {
if (threadIdx.x == 32) {
// reset in a different warp
meta->counter = 0;
meta->sg.start.flag = 0;
} else if (threadIdx.x < ngpus) {
// simultaneously write to the corresponding byte to all other ranks.
// Latency = 1 p2p write
sg.signals[threadIdx.x]->end.data[rank] = 255;
}
// if this is the final sync, only one block needs it
// because kernel exit can serve as sync
if constexpr (final_sync) {
if (threadIdx.x == 0) {
while (meta->sg.end.flag != FLAG)
;
}
}
}
if constexpr (!final_sync) {
if (threadIdx.x == 0) {
while (meta->sg.end.flag != FLAG)
;
}
__syncthreads();
// eliminate the case that prior writes are not visible after signals become
// visible. Note that I did not managed to make this happen through a lot of
// testing. Might be the case that hardware provides stronger guarantee than
// the memory model.
if constexpr (!final_sync) __threadfence_system();
if (threadIdx.x < ngpus) {
// reset flag for next time
self_sg->start[blockIdx.x][threadIdx.x] = 0;
// simultaneously write to the corresponding flag of all ranks.
// Latency = 1 p2p write
sg.signals[threadIdx.x]->end[blockIdx.x][rank] = 1;
// wait until we got true from all ranks
while (!self_sg->end[blockIdx.x][threadIdx.x])
;
}
if constexpr (!final_sync) __syncthreads();
}
template <typename P, int ngpus, typename A>
......@@ -214,32 +181,32 @@ DINLINE P packed_reduce(const P *ptrs[], int idx) {
template <typename T, int ngpus>
__global__ void __launch_bounds__(512, 1)
cross_device_reduce_1stage(RankData *_dp, RankSignals sg,
volatile Metadata *meta, T *__restrict__ result,
volatile Signal *self_sg, T *__restrict__ result,
int rank, int size) {
using P = typename packed_t<T>::P;
using A = typename packed_t<T>::A;
// note: we don't reorder the address so the accumulation order is the same
// for all ranks, ensuring bitwise identical results
auto dp = *_dp;
start_sync<ngpus>(sg, meta, rank);
start_sync<ngpus>(sg, self_sg, rank);
// do the actual reduction
for (int idx = blockIdx.x * blockDim.x + threadIdx.x; idx < size;
idx += gridDim.x * blockDim.x) {
((P *)result)[idx] =
packed_reduce<P, ngpus, A>((const P **)&dp.ptrs[0], idx);
}
end_sync<ngpus, true>(sg, meta, rank);
end_sync<ngpus, true>(sg, self_sg, rank);
}
template <typename P>
DINLINE P *get_tmp_buf(volatile Signal *sg) {
return (P *)(((Metadata *)sg) + 1);
return (P *)(((Signal *)sg) + 1);
}
template <typename T, int ngpus>
__global__ void __launch_bounds__(512, 1)
cross_device_reduce_2stage(RankData *_dp, RankSignals sg,
volatile Metadata *meta, T *__restrict__ result,
volatile Signal *self_sg, T *__restrict__ result,
int rank, int size) {
int tid = blockIdx.x * blockDim.x + threadIdx.x;
int stride = gridDim.x * blockDim.x;
......@@ -248,6 +215,7 @@ __global__ void __launch_bounds__(512, 1)
int part = size / ngpus;
int start = rank * part;
int end = rank == ngpus - 1 ? size : start + part;
int largest_part = part + size % ngpus;
const P *ptrs[ngpus];
P *tmps[ngpus];
#pragma unroll
......@@ -257,75 +225,28 @@ __global__ void __launch_bounds__(512, 1)
tmps[i] = get_tmp_buf<P>(sg.signals[target]);
}
auto tmp_out = tmps[0];
start_sync<ngpus>(sg, meta, rank);
start_sync<ngpus>(sg, self_sg, rank);
// stage 1: reduce scatter
for (int idx = start + tid; idx < end; idx += stride) {
tmp_out[idx - start] = packed_reduce<P, ngpus, A>(ptrs, idx);
}
// Maybe TODO: replace this with per-block release-acquire
// can save about 1-2us (not a lot though)
end_sync<ngpus>(sg, meta, rank);
// stage 2: allgather
for (int idx = tid; idx < part; idx += stride) {
end_sync<ngpus>(sg, self_sg, rank);
// stage 2: allgather. Note: it's important to match the tid between
// the two stages, because visibility across devices is only guaranteed
// between threads that have the same tid. If thread i computes the sum of
// start + i in the first stage, then thread i also gathers start + i from all
// ranks.
for (int idx = tid; idx < largest_part; idx += stride) {
#pragma unroll
for (int i = 0; i < ngpus; i++) {
int dst_idx = ((rank + i) % ngpus) * part + idx;
((P *)result)[dst_idx] = tmps[i][idx];
}
}
// process the last larger partition
int remaining = size - part * ngpus;
if (tid < remaining) {
int dst_idx = tid + part * ngpus;
((P *)result)[dst_idx] = get_tmp_buf<P>(sg.signals[ngpus - 1])[part + tid];
}
// faster than this
// for (int idx = tid; idx < size; idx += stride) {
// int target_rank = idx / part;
// if (target_rank == ngpus) target_rank -= 1;
// ((P *)result)[idx] = tmps[target_rank][idx - target_rank * part];
// }
}
template <typename T, int ngpus>
__global__ void __launch_bounds__(512, 1)
cross_device_reduce_half_butterfly(RankData *_dp, RankSignals sg,
volatile Metadata *meta,
T *__restrict__ result, int rank,
int size) {
int tid = blockIdx.x * blockDim.x + threadIdx.x;
int stride = gridDim.x * blockDim.x;
using P = typename packed_t<T>::P;
using A = typename packed_t<T>::A;
auto tmp_out = get_tmp_buf<P>(sg.signals[rank]);
constexpr int hg = ngpus / 2;
// Actually not quite half butterfly.
// This is an all-to-all within each group containing half of the ranks
// followed by cross-group add. Equivalent to half butterfly when there
// are 4 GPUs, a common case for PCIe cards like T4 and A10.
const P *ptrs[hg];
{
int start = rank - rank % hg;
#pragma unroll
for (int i = 0; i < hg; i++) {
ptrs[i] = (const P *)_dp->ptrs[i + start];
int gather_from_rank = ((rank + i) % ngpus);
if (gather_from_rank == ngpus - 1 || idx < part) {
int dst_idx = gather_from_rank * part + idx;
((P *)result)[dst_idx] = tmps[i][idx];
}
}
}
start_sync<ngpus>(sg, meta, rank);
for (int idx = tid; idx < size; idx += stride) {
tmp_out[idx] = packed_reduce<P, hg, A>(ptrs, idx);
}
end_sync<ngpus>(sg, meta, rank);
auto src = get_tmp_buf<P>(sg.signals[(ngpus - 1) - rank % ngpus]);
// do the cross group reduction
for (int idx = tid; idx < size; idx += stride) {
auto tmp = tmp_out[idx];
packed_assign_add(tmp, src[idx]);
((P *)result)[idx] = tmp;
}
}
using IPC_KEY = std::array<uint8_t, sizeof(cudaIpcMemHandle_t)>;
......@@ -341,7 +262,7 @@ class CustomAllreduce {
// below are device pointers
RankSignals sg_;
std::unordered_map<void *, RankData *> buffers_;
Metadata *meta_;
Signal *self_sg_;
// stores the registered device pointers from all ranks
RankData *d_rank_data_base_, *d_rank_data_end_;
......@@ -352,32 +273,32 @@ class CustomAllreduce {
/**
* meta is a pointer to device metadata and temporary buffer for allreduce.
*
* There's a total of sizeof(Metadata) of prefix before the actual data,
* There's a total of sizeof(Signal) of prefix before the actual data,
* so meta + 1 points to actual temporary buffer.
*
* note: this class does not own any device memory. Any required buffers
* are passed in from the constructor
*/
CustomAllreduce(Metadata *meta, void *rank_data, size_t rank_data_sz,
CustomAllreduce(Signal *meta, void *rank_data, size_t rank_data_sz,
const cudaIpcMemHandle_t *handles,
const std::vector<int64_t> &offsets, int rank,
bool full_nvlink = true)
: rank_(rank),
world_size_(offsets.size()),
full_nvlink_(full_nvlink),
meta_(meta),
self_sg_(meta),
d_rank_data_base_(reinterpret_cast<RankData *>(rank_data)),
d_rank_data_end_(d_rank_data_base_ + rank_data_sz / sizeof(RankData)) {
for (int i = 0; i < world_size_; i++) {
Metadata *rank_meta;
Signal *rank_sg;
if (i != rank_) {
char *handle = open_ipc_handle(&handles[i]);
handle += offsets[i];
rank_meta = (Metadata *)handle;
rank_sg = (Signal *)handle;
} else {
rank_meta = meta_;
rank_sg = self_sg_;
}
sg_.signals[i] = &rank_meta->sg;
sg_.signals[i] = rank_sg;
}
}
......@@ -492,6 +413,10 @@ class CustomAllreduce {
"custom allreduce currently requires input length to be multiple "
"of " +
std::to_string(d));
if (block_limit > kMaxBlocks)
throw std::runtime_error("max supported block limit is " +
std::to_string(kMaxBlocks) + ". Got " +
std::to_string(block_limit));
RankData *ptrs;
cudaStreamCaptureStatus status;
......@@ -512,9 +437,9 @@ class CustomAllreduce {
size /= d;
auto bytes = size * sizeof(typename packed_t<T>::P);
int blocks = std::min(block_limit, (size + threads - 1) / threads);
#define KL(ngpus, name) \
name<T, ngpus> \
<<<blocks, threads, 0, stream>>>(ptrs, sg_, meta_, output, rank_, size);
#define KL(ngpus, name) \
name<T, ngpus><<<blocks, threads, 0, stream>>>(ptrs, sg_, self_sg_, output, \
rank_, size);
#define REDUCE_CASE(ngpus) \
case ngpus: { \
if (world_size_ == 2) { \
......@@ -526,8 +451,6 @@ class CustomAllreduce {
} else { \
KL(ngpus, cross_device_reduce_2stage); \
} \
} else { \
KL(ngpus, cross_device_reduce_half_butterfly); \
} \
break; \
}
......@@ -556,7 +479,7 @@ class CustomAllreduce {
/**
* To inspect PTX/SASS, copy paste this header file to compiler explorer and add
a template instantiation:
* template void CustomAllreduce::allreduce<half>(cudaStream_t, half *, half *,
int, int, int);
* template void vllm::CustomAllreduce::allreduce<half>(cudaStream_t, half *,
half *, int, int, int);
*/
} // namespace vllm
csrc/custom_all_reduce_test.cu
View file @ 7c4f76e3
......@@ -92,7 +92,7 @@ __global__ void gen_data(curandState_t *state, T *data, double *ground_truth,
template <typename T>
void run(int myRank, int nRanks, ncclComm_t &comm, int threads, int block_limit,
int data_size) {
int data_size, bool performance_test) {
T *result;
cudaStream_t stream;
CUDACHECK(cudaStreamCreateWithFlags(&stream, cudaStreamNonBlocking));
......@@ -101,7 +101,7 @@ void run(int myRank, int nRanks, ncclComm_t &comm, int threads, int block_limit,
cudaIpcMemHandle_t self_data_handle;
cudaIpcMemHandle_t data_handles[8];
vllm::Metadata *buffer;
vllm::Signal *buffer;
T *self_data_copy;
/**
* Allocate IPC buffer
......@@ -115,9 +115,9 @@ void run(int myRank, int nRanks, ncclComm_t &comm, int threads, int block_limit,
* convenience.
*/
CUDACHECK(
cudaMalloc(&buffer, 2 * data_size * sizeof(T) + sizeof(vllm::Metadata)));
CUDACHECK(cudaMemset(buffer, 0,
2 * data_size * sizeof(T) + sizeof(vllm::Metadata)));
cudaMalloc(&buffer, 2 * data_size * sizeof(T) + sizeof(vllm::Signal)));
CUDACHECK(
cudaMemset(buffer, 0, 2 * data_size * sizeof(T) + sizeof(vllm::Signal)));
CUDACHECK(cudaMalloc(&self_data_copy, data_size * sizeof(T)));
CUDACHECK(cudaIpcGetMemHandle(&self_data_handle, buffer));
......@@ -133,7 +133,7 @@ void run(int myRank, int nRanks, ncclComm_t &comm, int threads, int block_limit,
offsets, myRank);
auto *self_data =
reinterpret_cast<T *>(reinterpret_cast<char *>(buffer) +
sizeof(vllm::Metadata) + data_size * sizeof(T));
sizeof(vllm::Signal) + data_size * sizeof(T));
// hack buffer registration
{
std::vector<std::string> handles;
......@@ -143,8 +143,8 @@ void run(int myRank, int nRanks, ncclComm_t &comm, int threads, int block_limit,
char *end = (char *)&data_handles[i + 1];
handles.emplace_back(begin, end);
}
std::vector<int64_t> offsets(
nRanks, sizeof(vllm::Metadata) + data_size * sizeof(T));
std::vector<int64_t> offsets(nRanks,
sizeof(vllm::Signal) + data_size * sizeof(T));
fa.register_buffer(handles, offsets, self_data);
}
......@@ -169,81 +169,112 @@ void run(int myRank, int nRanks, ncclComm_t &comm, int threads, int block_limit,
} else {
ncclDtype = ncclFloat;
}
double *nccl_result, *my_result;
CUDACHECK(cudaMallocHost(&nccl_result, data_size * sizeof(double)));
CUDACHECK(cudaMallocHost(&my_result, data_size * sizeof(double)));
if (performance_test) {
dummy_kernel<<<1, 1, 0, stream>>>();
constexpr int warmup_iters = 5;
constexpr int num_iters = 100;
// warmup
for (int i = 0; i < warmup_iters; i++) {
NCCLCHECK(ncclAllReduce(result, result, data_size, ncclDtype, ncclSum,
comm, stream));
}
CUDACHECK(cudaEventRecord(start, stream));
for (int i = 0; i < num_iters; i++) {
NCCLCHECK(ncclAllReduce(result, result, data_size, ncclDtype, ncclSum,
comm, stream));
}
CUDACHECK(cudaEventRecord(stop, stream));
CUDACHECK(cudaStreamSynchronize(stream));
float allreduce_ms = 0;
cudaEventElapsedTime(&allreduce_ms, start, stop);
dummy_kernel<<<1, 1, 0, stream>>>();
constexpr int warmup_iters = 5;
constexpr int num_iters = 25;
// warmup
for (int i = 0; i < warmup_iters; i++) {
NCCLCHECK(ncclAllReduce(result, result, data_size, ncclDtype, ncclSum, comm,
stream));
}
CUDACHECK(cudaEventRecord(start, stream));
for (int i = 0; i < num_iters; i++) {
NCCLCHECK(ncclAllReduce(result, result, data_size, ncclDtype, ncclSum, comm,
stream));
}
CUDACHECK(cudaEventRecord(stop, stream));
CUDACHECK(cudaStreamSynchronize(stream));
float allreduce_ms = 0;
cudaEventElapsedTime(&allreduce_ms, start, stop);
// if (myRank == 1) dummy_kernel<<<1, 1, 0, stream>>>();
// set_data<T><<<16, 1024, 0, stream>>>(self_data, data_size, myRank);
dummy_kernel<<<1, 1, 0, stream>>>();
// warm up
for (int i = 0; i < warmup_iters; i++) {
fa.allreduce<T>(stream, self_data, result, data_size, threads, block_limit);
}
CUDACHECK(cudaEventRecord(start, stream));
for (int i = 0; i < num_iters; i++) {
fa.allreduce<T>(stream, self_data, result, data_size, threads, block_limit);
}
CUDACHECK(cudaEventRecord(stop, stream));
CUDACHECK(cudaStreamSynchronize(stream));
float duration_ms = 0;
cudaEventElapsedTime(&duration_ms, start, stop);
if (myRank == 0)
printf(
"Rank %d done, nGPUs:%d, sz (kb): %d, %d, %d, my time:%.2fus, nccl "
"time:%.2fus\n",
myRank, nRanks, data_size * sizeof(T) / 1024, threads, block_limit,
duration_ms * 1e3 / num_iters, allreduce_ms * 1e3 / num_iters);
dummy_kernel<<<1, 1, 0, stream>>>();
// warm up
for (int i = 0; i < warmup_iters; i++) {
fa.allreduce<T>(stream, self_data, result, data_size, threads,
block_limit);
}
CUDACHECK(cudaEventRecord(start, stream));
for (int i = 0; i < num_iters; i++) {
fa.allreduce<T>(stream, self_data, result, data_size, threads,
block_limit);
}
CUDACHECK(cudaEventRecord(stop, stream));
CUDACHECK(cudaStreamSynchronize(stream));
// And wait for all the queued up work to complete
CUDACHECK(cudaStreamSynchronize(stream));
float duration_ms = 0;
cudaEventElapsedTime(&duration_ms, start, stop);
if (myRank == 0)
printf(
"Rank %d done, nGPUs:%d, sz (kb): %d, %d, %d, my time:%.2fus, nccl "
"time:%.2fus\n",
myRank, nRanks, data_size * sizeof(T) / 1024, threads, block_limit,
duration_ms * 1e3 / num_iters, allreduce_ms * 1e3 / num_iters);
NCCLCHECK(ncclAllReduce(self_data_copy, self_data, data_size, ncclDtype,
ncclSum, comm, stream));
// And wait for all the queued up work to complete
CUDACHECK(cudaStreamSynchronize(stream));
double *nccl_result, *my_result;
CUDACHECK(cudaMallocHost(&nccl_result, data_size * sizeof(double)));
CUDACHECK(cudaMallocHost(&my_result, data_size * sizeof(double)));
NCCLCHECK(ncclAllReduce(self_data_copy, self_data, data_size, ncclDtype,
ncclSum, comm, stream));
convert_data<T><<<108, 1024, 0, stream>>>(self_data, result, nccl_result,
my_result, data_size);
CUDACHECK(cudaStreamSynchronize(stream));
convert_data<T><<<108, 1024, 0, stream>>>(self_data, result, nccl_result,
my_result, data_size);
CUDACHECK(cudaStreamSynchronize(stream));
for (unsigned long j = 0; j < data_size; j++) {
auto diff = abs(nccl_result[j] - my_result[j]);
if (diff >= 1e-2) {
printf("Rank %d: Verification mismatch at %lld: %f != (my) %f, gt=%f\n",
myRank, j, nccl_result[j], my_result[j], ground_truth[j]);
break;
for (unsigned long j = 0; j < data_size; j++) {
auto diff = abs(nccl_result[j] - my_result[j]);
if (diff >= 4e-2) {
printf("Rank %d: Verification mismatch at %lld: %f != (my) %f, gt=%f\n",
myRank, j, nccl_result[j], my_result[j], ground_truth[j]);
break;
}
}
}
long double nccl_diffs = 0.0;
long double my_diffs = 0.0;
for (int j = 0; j < data_size; j++) {
nccl_diffs += abs(nccl_result[j] - ground_truth[j]);
my_diffs += abs(my_result[j] - ground_truth[j]);
}
if (myRank == 0)
std::cout << "average abs diffs: nccl: " << nccl_diffs / data_size
<< " me: " << my_diffs / data_size << std::endl;
} else {
for (int i = 0; i < 100; i++) {
fa.allreduce<T>(stream, self_data, result, data_size, threads,
block_limit);
CUDACHECK(cudaStreamSynchronize(stream));
NCCLCHECK(ncclAllReduce(self_data, self_data_copy, data_size, ncclDtype,
ncclSum, comm, stream));
convert_data<T><<<108, 1024, 0, stream>>>(
self_data_copy, result, nccl_result, my_result, data_size);
CUDACHECK(cudaStreamSynchronize(stream));
long double nccl_diffs = 0.0;
long double my_diffs = 0.0;
for (int j = 0; j < data_size; j++) {
nccl_diffs += abs(nccl_result[j] - ground_truth[j]);
my_diffs += abs(my_result[j] - ground_truth[j]);
for (unsigned long j = 0; j < data_size; j++) {
auto diff = abs(nccl_result[j] - my_result[j]);
if (diff >= 4e-2) {
printf(
"Rank %d: Verification mismatch at %lld: %f != (my) %f, gt=%f\n",
myRank, j, nccl_result[j], my_result[j], ground_truth[j]);
break;
}
}
}
if (myRank == 0)
printf("Test passed: nGPUs:%d, sz (kb): %d, %d, %d\n", nRanks,
data_size * sizeof(T) / 1024, threads, block_limit);
// long double nccl_diffs = 0.0;
// long double my_diffs = 0.0;
// for (int j = 0; j < data_size; j++) {
// nccl_diffs += abs(nccl_result[j] - ground_truth[j]);
// my_diffs += abs(my_result[j] - ground_truth[j]);
// }
// if (myRank == 0)
// std::cout << "average abs diffs: nccl: " << nccl_diffs / data_size
// << " me: " << my_diffs / data_size << std::endl;
}
if (myRank == 0)
std::cout << "average abs diffs: nccl: " << nccl_diffs / data_size
<< " me: " << my_diffs / data_size << std::endl;
CUDACHECK(cudaFree(result));
CUDACHECK(cudaFree(self_data_copy));
......@@ -269,14 +300,15 @@ int main(int argc, char **argv) {
MPI_COMM_WORLD));
NCCLCHECK(ncclCommInitRank(&comm, nRanks, id, myRank));
bool performance_test = true;
cudaProfilerStart();
// for (int threads : {256, 512}) {
// for (int block_limit = 16; block_limit < 112; block_limit += 4) {
// run<half>(myRank, nRanks, comm, threads, block_limit, 4096 * 1024);
// }
// }
for (int sz = 512; sz <= (32 << 20); sz *= 2) {
run<half>(myRank, nRanks, comm, 512, 36, sz + 8 * 50);
for (int sz = 512; sz <= (8 << 20); sz *= 2) {
run<half>(myRank, nRanks, comm, 512, 36, sz + 8 * 47, performance_test);
}
cudaProfilerStop();
......
csrc/moe_align_block_size_kernels.cu
View file @ 7c4f76e3
......@@ -7,10 +7,17 @@
#include "cuda_compat.h"
#include "dispatch_utils.h"
const static size_t NUM_MAX_EXPERTS = 64;
#define CEILDIV(x,y) (((x) + (y) - 1) / (y))
namespace vllm {
namespace {
__device__ __forceinline__ int32_t index(int32_t total_col, int32_t row, int32_t col) {
// don't worry about overflow because num_experts is relatively small
return row * total_col + col;
}
}
template <typename scalar_t>
__global__ void moe_align_block_size_kernel(scalar_t *__restrict__ topk_ids,
int32_t *sorted_token_ids,
......@@ -21,10 +28,14 @@ __global__ void moe_align_block_size_kernel(scalar_t *__restrict__ topk_ids,
size_t numel) {
const size_t tokens_per_thread = CEILDIV(numel, blockDim.x);
const size_t start_idx = threadIdx.x * tokens_per_thread;
__shared__ int32_t tokens_cnts[NUM_MAX_EXPERTS + 1][NUM_MAX_EXPERTS];
__shared__ int32_t cumsum[NUM_MAX_EXPERTS + 1];
extern __shared__ int32_t shared_mem[];
int32_t* tokens_cnts = shared_mem; // 2d tensor with shape (num_experts + 1, num_experts)
int32_t* cumsum = shared_mem + (num_experts + 1) * num_experts; // 1d tensor with shape (num_experts + 1)
for (int i = 0; i < num_experts; ++i) {
tokens_cnts[threadIdx.x + 1][i] = 0;
tokens_cnts[index(num_experts, threadIdx.x + 1, i)] = 0;
}
/**
......@@ -33,15 +44,15 @@ __global__ void moe_align_block_size_kernel(scalar_t *__restrict__ topk_ids,
* to expert expert_index.
*/
for (int i = start_idx; i < numel && i < start_idx + tokens_per_thread; ++i) {
++tokens_cnts[threadIdx.x + 1][topk_ids[i]];
++tokens_cnts[index(num_experts, threadIdx.x + 1, topk_ids[i])];
}
__syncthreads();
// For each expert we accumulate the token counts from the different threads.
tokens_cnts[0][threadIdx.x] = 0;
tokens_cnts[index(num_experts, 0, threadIdx.x)] = 0;
for (int i = 1; i <= blockDim.x; ++i) {
tokens_cnts[i][threadIdx.x] += tokens_cnts[i-1][threadIdx.x];
tokens_cnts[index(num_experts, i, threadIdx.x)] += tokens_cnts[index(num_experts, i-1, threadIdx.x)];
}
__syncthreads();
......@@ -50,7 +61,7 @@ __global__ void moe_align_block_size_kernel(scalar_t *__restrict__ topk_ids,
if (threadIdx.x == 0) {
cumsum[0] = 0;
for (int i = 1; i <= num_experts; ++i) {
cumsum[i] = cumsum[i-1] + CEILDIV(tokens_cnts[blockDim.x][i - 1], block_size) * block_size;
cumsum[i] = cumsum[i-1] + CEILDIV(tokens_cnts[index(num_experts, blockDim.x, i - 1)], block_size) * block_size;
}
*total_tokens_post_pad = cumsum[num_experts];
}
......@@ -78,9 +89,9 @@ __global__ void moe_align_block_size_kernel(scalar_t *__restrict__ topk_ids,
* stores the indices of the tokens processed by the expert with expert_id within
* the current thread's token shard.
*/
int32_t rank_post_pad = tokens_cnts[threadIdx.x][expert_id] + cumsum[expert_id];
int32_t rank_post_pad = tokens_cnts[index(num_experts, threadIdx.x, expert_id)] + cumsum[expert_id];
sorted_token_ids[rank_post_pad] = i;
++tokens_cnts[threadIdx.x][expert_id];
++tokens_cnts[index(num_experts, threadIdx.x, expert_id)];
}
}
}
......@@ -93,11 +104,17 @@ void moe_align_block_size(
torch::Tensor experts_ids,
torch::Tensor num_tokens_post_pad) {
const cudaStream_t stream = at::cuda::getCurrentCUDAStream();
assert(num_experts <= NUM_MAX_EXPERTS);
VLLM_DISPATCH_INTEGRAL_TYPES(
topk_ids.scalar_type(), "moe_align_block_size_kernel", [&] {
vllm::moe_align_block_size_kernel<scalar_t><<<1, num_experts, 0, stream>>>(
topk_ids.data_ptr<scalar_t>(),
// calc needed amount of shared mem for `tokens_cnts` and `cumsum` tensors
const int32_t shared_mem = ((num_experts + 1) * num_experts + (num_experts + 1)) * sizeof(int32_t);
// set dynamic shared mem
auto kernel = vllm::moe_align_block_size_kernel<scalar_t>;
AT_CUDA_CHECK(
VLLM_DevFuncAttribute_SET_MaxDynamicSharedMemorySize((void *)kernel, shared_mem));
kernel<<<1, num_experts, shared_mem, stream>>>(
topk_ids.data_ptr<scalar_t>(),
sorted_token_ids.data_ptr<int32_t>(),
experts_ids.data_ptr<int32_t>(),
num_tokens_post_pad.data_ptr<int32_t>(),
......
csrc/ops.h
View file @ 7c4f76e3
......@@ -53,6 +53,16 @@ void rotary_embedding(
torch::Tensor& cos_sin_cache,
bool is_neox);
void batched_rotary_embedding(
torch::Tensor& positions,
torch::Tensor& query,
torch::Tensor& key,
int head_size,
torch::Tensor& cos_sin_cache,
bool is_neox,
int rot_dim,
torch::Tensor& cos_sin_cache_offsets);
void silu_and_mul(
torch::Tensor& out,
torch::Tensor& input);
......@@ -61,6 +71,10 @@ void gelu_and_mul(
torch::Tensor& out,
torch::Tensor& input);
void gelu_tanh_and_mul(
torch::Tensor& out,
torch::Tensor& input);
void gelu_new(
torch::Tensor& out,
torch::Tensor& input);
......
csrc/pos_encoding_kernels.cu
View file @ 7c4f76e3
......@@ -8,7 +8,7 @@
namespace vllm {
template<typename scalar_t, bool IS_NEOX>
inline __device__ void apply_rotary_embedding(
inline __device__ void apply_token_rotary_embedding(
scalar_t* __restrict__ arr,
const scalar_t* __restrict__ cos_ptr,
const scalar_t* __restrict__ sin_ptr,
......@@ -38,22 +38,18 @@ inline __device__ void apply_rotary_embedding(
}
template<typename scalar_t, bool IS_NEOX>
__global__ void rotary_embedding_kernel(
const int64_t* __restrict__ positions, // [batch_size, seq_len] or [num_tokens]
inline __device__ void apply_rotary_embedding(
scalar_t* __restrict__ query, // [batch_size, seq_len, num_heads, head_size] or [num_tokens, num_heads, head_size]
scalar_t* __restrict__ key, // [batch_size, seq_len, num_kv_heads, head_size] or [num_tokens, num_kv_heads, head_size]
const scalar_t* __restrict__ cos_sin_cache, // [max_position, 2, rot_dim // 2]
const int rot_dim,
const int64_t query_stride,
const int64_t key_stride,
const scalar_t* cache_ptr,
const int head_size,
const int num_heads,
const int num_kv_heads,
const int head_size) {
// Each thread block is responsible for one token.
const int token_idx = blockIdx.x;
int64_t pos = positions[token_idx];
const scalar_t* cache_ptr = cos_sin_cache + pos * rot_dim;
const int rot_dim,
const int token_idx,
const int64_t query_stride,
const int64_t key_stride)
{
const int embed_dim = rot_dim / 2;
const scalar_t* cos_ptr = cache_ptr;
const scalar_t* sin_ptr = cache_ptr + embed_dim;
......@@ -63,7 +59,7 @@ __global__ void rotary_embedding_kernel(
const int head_idx = i / embed_dim;
const int64_t token_head = token_idx * query_stride + head_idx * head_size;
const int rot_offset = i % embed_dim;
apply_rotary_embedding<scalar_t, IS_NEOX>(query + token_head, cos_ptr,
apply_token_rotary_embedding<scalar_t, IS_NEOX>(query + token_head, cos_ptr,
sin_ptr, rot_offset, embed_dim);
}
......@@ -72,11 +68,53 @@ __global__ void rotary_embedding_kernel(
const int head_idx = i / embed_dim;
const int64_t token_head = token_idx * key_stride + head_idx * head_size;
const int rot_offset = i % embed_dim;
apply_rotary_embedding<scalar_t, IS_NEOX>(key + token_head, cos_ptr,
apply_token_rotary_embedding<scalar_t, IS_NEOX>(key + token_head, cos_ptr,
sin_ptr, rot_offset, embed_dim);
}
}
template<typename scalar_t, bool IS_NEOX>
__global__ void rotary_embedding_kernel(
const int64_t* __restrict__ positions, // [batch_size, seq_len] or [num_tokens]
scalar_t* __restrict__ query, // [batch_size, seq_len, num_heads, head_size] or [num_tokens, num_heads, head_size]
scalar_t* __restrict__ key, // [batch_size, seq_len, num_kv_heads, head_size] or [num_tokens, num_kv_heads, head_size]
const scalar_t* __restrict__ cos_sin_cache, // [max_position, 2, rot_dim // 2]
const int rot_dim,
const int64_t query_stride,
const int64_t key_stride,
const int num_heads,
const int num_kv_heads,
const int head_size) {
// Each thread block is responsible for one token.
const int token_idx = blockIdx.x;
int64_t pos = positions[token_idx];
const scalar_t* cache_ptr = cos_sin_cache + pos * rot_dim;
apply_rotary_embedding<scalar_t, IS_NEOX>(query, key, cache_ptr, head_size, num_heads, num_kv_heads, rot_dim, token_idx, query_stride, key_stride);
}
template<typename scalar_t, bool IS_NEOX>
__global__ void batched_rotary_embedding_kernel(
const int64_t* __restrict__ positions, // [batch_size, seq_len] or [num_tokens]
scalar_t* __restrict__ query, // [batch_size, seq_len, num_heads, head_size] or [num_tokens, num_heads, head_size]
scalar_t* __restrict__ key, // [batch_size, seq_len, num_kv_heads, head_size] or [num_tokens, num_kv_heads, head_size]
const scalar_t* __restrict__ cos_sin_cache, // [max_position, 2, rot_dim // 2]
const int64_t* __restrict__ cos_sin_cache_offsets, // [batch_size, seq_len] or [num_tokens]
const int rot_dim,
const int64_t query_stride,
const int64_t key_stride,
const int num_heads,
const int num_kv_heads,
const int head_size) {
// Each thread block is responsible for one token.
const int token_idx = blockIdx.x;
int64_t pos = positions[token_idx];
int64_t cos_sin_cache_offset = cos_sin_cache_offsets[token_idx];
const scalar_t* cache_ptr = cos_sin_cache + (cos_sin_cache_offset + pos) * rot_dim;
apply_rotary_embedding<scalar_t, IS_NEOX>(query, key, cache_ptr, head_size, num_heads, num_kv_heads, rot_dim, token_idx, query_stride, key_stride);
}
} // namespace vllm
void rotary_embedding(
......@@ -128,3 +166,61 @@ void rotary_embedding(
}
});
}
/*
Batched version of rotary embedding, pack multiple LoRAs together
and process in batched manner.
*/
void batched_rotary_embedding(
torch::Tensor& positions, // [batch_size, seq_len] or [num_tokens]
torch::Tensor& query, // [batch_size, seq_len, num_heads * head_size] or [num_tokens, num_heads * head_size]
torch::Tensor& key, // [batch_size, seq_len, num_kv_heads * head_size] or [num_tokens, num_kv_heads * head_size]
int head_size,
torch::Tensor& cos_sin_cache, // [max_position, rot_dim]
bool is_neox,
int rot_dim,
torch::Tensor& cos_sin_cache_offsets // [num_tokens]
) {
int64_t num_tokens = cos_sin_cache_offsets.size(0);
int num_heads = query.size(-1) / head_size;
int num_kv_heads = key.size(-1) / head_size;
int64_t query_stride = query.stride(-2);
int64_t key_stride = key.stride(-2);
dim3 grid(num_tokens);
dim3 block(std::min(num_heads * rot_dim / 2, 512));
const at::cuda::OptionalCUDAGuard device_guard(device_of(query));
const cudaStream_t stream = at::cuda::getCurrentCUDAStream();
VLLM_DISPATCH_FLOATING_TYPES(
query.scalar_type(),
"rotary_embedding",
[&] {
if (is_neox) {
vllm::batched_rotary_embedding_kernel<scalar_t, true><<<grid, block, 0, stream>>>(
positions.data_ptr<int64_t>(),
query.data_ptr<scalar_t>(),
key.data_ptr<scalar_t>(),
cos_sin_cache.data_ptr<scalar_t>(),
cos_sin_cache_offsets.data_ptr<int64_t>(),
rot_dim,
query_stride,
key_stride,
num_heads,
num_kv_heads,
head_size);
} else {
vllm::batched_rotary_embedding_kernel<scalar_t, false><<<grid, block, 0, stream>>>(
positions.data_ptr<int64_t>(),
query.data_ptr<scalar_t>(),
key.data_ptr<scalar_t>(),
cos_sin_cache.data_ptr<scalar_t>(),
cos_sin_cache_offsets.data_ptr<int64_t>(),
rot_dim,
query_stride,
key_stride,
num_heads,
num_kv_heads,
head_size);
}
});
}
csrc/punica/bgmv/bgmv_config.h
View file @ 7c4f76e3
This diff is collapsed.
csrc/punica/bgmv/generator.py
View file @ 7c4f76e3
......@@ -10,7 +10,7 @@ TEMPLATE = """
#include "bgmv_impl.cuh"
FOR_BGMV_WIDE_NARROW(INST_BGMV_TWOSIDE, {input_dtype}, {output_dtype}, {weight_dtype})
""".lstrip()
""".lstrip() # noqa: E501
for input_dtype in DTYPES:
for output_dtype in DTYPES:
......
csrc/punica/punica_ops.cc
View file @ 7c4f76e3
This diff is collapsed.
csrc/pybind.cpp
View file @ 7c4f76e3
This diff is collapsed.
csrc/reduction_utils.cuh
View file @ 7c4f76e3
This diff is collapsed.
docs/requirements-docs.txt
View file @ 7c4f76e3
sphinx == 6.2.1
sphinx-book-theme == 1.0.1
sphinx-copybutton == 0.5.2
myst-parser == 2.0.0
sphinx-argparse
# packages to install to build the documentation
pydantic
-f https://download.pytorch.org/whl/cpu
torch
\ No newline at end of file
docs/source/assets/kernel/value.png 0 → 100644
View file @ 7c4f76e3
This diff is collapsed.
docs/source/conf.py
View file @ 7c4f76e3
This diff is collapsed.
docs/source/dev/engine/llm_engine.rst
View file @ 7c4f76e3
This diff is collapsed.
Markdown is supported
0% or .
You are about to add 0 people to the discussion. Proceed with caution.
Finish editing this message first!
Please register or to comment
