Rewrite gallery example for masks to boxes. (#4484)

* start writing example

* Update example

* Add PenFudan Files

* Update example

* Remove unused files

* Update file and adopt changes

* Create links, fix float
Co-authored-by: Nicolas Hug <contact@nicolas-hug.com>

docs/source/ops.rst

+.. _ops:
+
 torchvision.ops
 ===============


docs/source/utils.rst

+.. _utils:
+
 torchvision.utils
 =================


gallery/plot_repurposing_annotations.py

 """
-=======================
-Repurposing annotations
-=======================
-
-The following example illustrates the operations available in the torchvision.ops module for repurposing object
-localization annotations for different tasks (e.g. transforming masks used by instance and panoptic segmentation
+=====================================
+Repurposing masks into bounding boxes
+=====================================
+
+The following example illustrates the operations available
+the :ref:`torchvision.ops <ops>` module for repurposing
+segmentation masks into object localization annotations for different tasks
+(e.g. transforming masks used by instance and panoptic segmentation
 methods into bounding boxes used by object detection methods).
 """
-import os.path

-import PIL.Image
-import matplotlib.patches
-import matplotlib.pyplot
-import numpy
+
+import os
+import numpy as np
 import torch
-from torchvision.ops import masks_to_boxes
+import matplotlib.pyplot as plt
+
+import torchvision.transforms.functional as F
+
+
+ASSETS_DIRECTORY = "assets"

-ASSETS_DIRECTORY = "../test/assets"
+plt.rcParams["savefig.bbox"] = "tight"
+
+
+def show(imgs):
+    if not isinstance(imgs, list):
+        imgs = [imgs]
+    fix, axs = plt.subplots(ncols=len(imgs), squeeze=False)
+    for i, img in enumerate(imgs):
+        img = img.detach()
+        img = F.to_pil_image(img)
+        axs[0, i].imshow(np.asarray(img))
+        axs[0, i].set(xticklabels=[], yticklabels=[], xticks=[], yticks=[])

-matplotlib.pyplot.rcParams["savefig.bbox"] = "tight"

 ####################################
 # Masks
@@ -26,9 +41,9 @@ matplotlib.pyplot.rcParams["savefig.bbox"] = "tight"
 # In tasks like instance and panoptic segmentation, masks are commonly defined, and are defined by this package,
 # as a multi-dimensional array (e.g. a NumPy array or a PyTorch tensor) with the following shape:
 #
-#       (objects, height, width)
+#       (num_objects, height, width)
 #
-# Where objects is the number of annotated objects in the image. Each (height, width) object corresponds to exactly
+# Where num_objects is the number of annotated objects in the image. Each (height, width) object corresponds to exactly
 # one object. For example, if your input image has the dimensions 224 x 224 and has four annotated objects the shape
 # of your masks annotation has the following shape:
 #
@@ -36,40 +51,154 @@ matplotlib.pyplot.rcParams["savefig.bbox"] = "tight"
 #
 # A nice property of masks is that they can be easily repurposed to be used in methods to solve a variety of object
 # localization tasks.
-#
-# Masks to bounding boxes
-# ----------------------------------------
-# For example, the masks to bounding_boxes operation can be used to transform masks into bounding boxes that can be
-# used in methods like Faster RCNN and YOLO.

-with PIL.Image.open(os.path.join(ASSETS_DIRECTORY, "masks.tiff")) as image:
-    masks = torch.zeros((image.n_frames, image.height, image.width), dtype=torch.int)
+####################################
+# Converting Masks to Bounding Boxes
+# -----------------------------------------------
+# For example, the :func:`~torchvision.ops.masks_to_boxes` operation can be used to
+# transform masks into bounding boxes that can be
+# used as input to detection models such as FasterRCNN and RetinaNet.
+# We will take images and masks from the `PenFudan Dataset <https://www.cis.upenn.edu/~jshi/ped_html/>`_.
+
+
+from torchvision.io import read_image
+
+img_path = os.path.join(ASSETS_DIRECTORY, "FudanPed00054.png")
+mask_path = os.path.join(ASSETS_DIRECTORY, "FudanPed00054_mask.png")
+img = read_image(img_path)
+mask = read_image(mask_path)
+
+
+#########################
+# Here the masks are represented as a PNG Image, with floating point values.
+# Each pixel is encoded as different colors, with 0 being background.
+# Notice that the spatial dimensions of image and mask match.
+
+print(mask.size())
+print(img.size())
+print(mask)
+
+############################
+
+# We get the unique colors, as these would be the object ids.
+obj_ids = torch.unique(mask)
+
+# first id is the background, so remove it.
+obj_ids = obj_ids[1:]
+
+# split the color-encoded mask into a set of boolean masks.
+# Note that this snippet would work as well if the masks were float values instead of ints.
+masks = mask == obj_ids[:, None, None]
+
+########################
+# Now the masks are a boolean tensor.
+# The first dimension in this case 3 and denotes the number of instances: there are 3 people in the image.
+# The other two dimensions are height and width, which are equal to the dimensions of the image.
+# For each instance, the boolean tensors represent if the particular pixel
+# belongs to the segmentation mask of the image.
+
+print(masks.size())
+print(masks)
+
+####################################
+# Let us visualize an image and plot its corresponding segmentation masks.
+# We will use the :func:`~torchvision.utils.draw_segmentation_masks` to draw the segmentation masks.
+
+from torchvision.utils import draw_segmentation_masks
+
+drawn_masks = []
+for mask in masks:
+    drawn_masks.append(draw_segmentation_masks(img, mask, alpha=0.8, colors="blue"))
+
+show(drawn_masks)
+
+####################################
+# To convert the boolean masks into bounding boxes.
+# We will use the :func:`~torchvision.ops.masks_to_boxes` from the torchvision.ops module
+# It returns the boxes in ``(xmin, ymin, xmax, ymax)`` format.
+
+from torchvision.ops import masks_to_boxes
+
+boxes = masks_to_boxes(masks)
+print(boxes.size())
+print(boxes)
+
+####################################
+# As the shape denotes, there are 3 boxes and in ``(xmin, ymin, xmax, ymax)`` format.
+# These can be visualized very easily with :func:`~torchvision.utils.draw_bounding_boxes` utility
+# provided in :ref:`torchvision.utils <utils>`.
+
+from torchvision.utils import draw_bounding_boxes
+
+drawn_boxes = draw_bounding_boxes(img, boxes, colors="red")
+show(drawn_boxes)
+
+###################################
+# These boxes can now directly be used by detection models in torchvision.
+# Here is demo with a Faster R-CNN model loaded from
+# :func:`~torchvision.models.detection.fasterrcnn_resnet50_fpn`
+
+from torchvision.models.detection import fasterrcnn_resnet50_fpn
+
+model = fasterrcnn_resnet50_fpn(pretrained=True, progress=False)
+print(img.size())
+
+img = F.convert_image_dtype(img, torch.float)
+target = {}
+target["boxes"] = boxes
+target["labels"] = labels = torch.ones((masks.size(0),), dtype=torch.int64)
+detection_outputs = model(img.unsqueeze(0), [target])
+
+
+####################################
+# Converting Segmentation Dataset to Detection Dataset
+# ----------------------------------------------------
+#
+# With this utility it becomes very simple to convert a segmentation dataset to a detection dataset.
+# With this we can now use a segmentation dataset to train a detection model.
+# One can similarly convert panoptic dataset to detection dataset.
+# Here is an example where we re-purpose the dataset from the
+# `PenFudan Detection Tutorial <https://pytorch.org/tutorials/intermediate/torchvision_tutorial.html>`_.

-    for index in range(image.n_frames):
-        image.seek(index)
+class SegmentationToDetectionDataset(torch.utils.data.Dataset):
+    def __init__(self, root, transforms):
+        self.root = root
+        self.transforms = transforms
+        # load all image files, sorting them to
+        # ensure that they are aligned
+        self.imgs = list(sorted(os.listdir(os.path.join(root, "PNGImages"))))
+        self.masks = list(sorted(os.listdir(os.path.join(root, "PedMasks"))))

-        frame = numpy.array(image)
+    def __getitem__(self, idx):
+        # load images and masks
+        img_path = os.path.join(self.root, "PNGImages", self.imgs[idx])
+        mask_path = os.path.join(self.root, "PedMasks", self.masks[idx])

-        masks[index] = torch.tensor(frame)
+        img = read_image(img_path)
+        mask = read_image(mask_path)

-bounding_boxes = masks_to_boxes(masks)
+        img = F.convert_image_dtype(img, dtype=torch.float)
+        mask = F.convert_image_dtype(mask, dtype=torch.float)

-figure = matplotlib.pyplot.figure()
+        # We get the unique colors, as these would be the object ids.
+        obj_ids = torch.unique(mask)

-a = figure.add_subplot(121)
-b = figure.add_subplot(122)
+        # first id is the background, so remove it.
+        obj_ids = obj_ids[1:]

-labeled_image = torch.sum(masks, 0)
+        # split the color-encoded mask into a set of boolean masks.
+        masks = mask == obj_ids[:, None, None]

-a.imshow(labeled_image)
-b.imshow(labeled_image)
+        boxes = masks_to_boxes(masks)

-for bounding_box in bounding_boxes:
-    x0, y0, x1, y1 = bounding_box
+        # there is only one class
+        labels = torch.ones((masks.shape[0],), dtype=torch.int64)

-    rectangle = matplotlib.patches.Rectangle((x0, y0), x1 - x0, y1 - y0, linewidth=1, edgecolor="r", facecolor="none")
+        target = {}
+        target["boxes"] = boxes
+        target["labels"] = labels

-    b.add_patch(rectangle)
+        if self.transforms is not None:
+            img, target = self.transforms(img, target)

-a.set(xticklabels=[], yticklabels=[], xticks=[], yticks=[])
-b.set(xticklabels=[], yticklabels=[], xticks=[], yticks=[])
+        return img, target
