Convert "tensor transforms" notebook into a sphinx-gallery example (#3780)

parent b56f17ae
.. _transforms:
torchvision.transforms
======================
......@@ -33,6 +35,20 @@ images of a given batch, but they will produce different transformations
across calls. For reproducible transformations across calls, you may use
:ref:`functional transforms <functional_transforms>`.
The following examples illustate the use of the available transforms:
* :ref:`sphx_glr_auto_examples_plot_transforms.py`
.. figure:: ../source/auto_examples/images/sphx_glr_plot_transforms_001.png
:align: center
:scale: 65%
* :ref:`sphx_glr_auto_examples_plot_scripted_tensor_transforms.py`
.. figure:: ../source/auto_examples/images/sphx_glr_plot_scripted_tensor_transforms_001.png
:align: center
:scale: 30%
.. warning::
Since v0.8.0 all random transformations are using torch default random generator to sample random parameters.
......
This diff is collapsed.
"""
=========================
Tensor transforms and JIT
=========================
This example illustrates various features that are now supported by the
:ref:`image transformations <transforms>` on Tensor images. In particular, we
show how image transforms can be performed on GPU, and how one can also script
them using JIT compilation.
Prior to v0.8.0, transforms in torchvision have traditionally been PIL-centric
and presented multiple limitations due to that. Now, since v0.8.0, transforms
implementations are Tensor and PIL compatible and we can achieve the following
new features:
- transform multi-band torch tensor images (with more than 3-4 channels)
- torchscript transforms together with your model for deployment
- support for GPU acceleration
- batched transformation such as for videos
- read and decode data directly as torch tensor with torchscript support (for PNG and JPEG image formats)
.. note::
These features are only possible with **Tensor** images.
"""
from pathlib import Path
import matplotlib.pyplot as plt
import numpy as np
import torch
import torchvision.transforms as T
from torchvision.io import read_image
plt.rcParams["savefig.bbox"] = 'tight'
torch.manual_seed(0)
def show(imgs):
fix, axs = plt.subplots(ncols=len(imgs), squeeze=False)
for i, img in enumerate(imgs):
img = T.ToPILImage()(img.to('cpu'))
axs[0, i].imshow(np.asarray(img))
axs[0, i].set(xticklabels=[], yticklabels=[], xticks=[], yticks=[])
####################################
# The :func:`~torchvision.io.read_image` function allows to read an image and
# directly load it as a tensor
dog1 = read_image(str(Path('assets') / 'dog1.jpg'))
dog2 = read_image(str(Path('assets') / 'dog2.jpg'))
show([dog1, dog2])
####################################
# Transforming images on GPU
# --------------------------
# Most transforms natively support tensors on top of PIL images (to visualize
# the effect of the transforms, you may refer to see
# :ref:`sphx_glr_auto_examples_plot_transforms.py`).
# Using tensor images, we can run the transforms on GPUs if cuda is available!
import torch.nn as nn
transforms = torch.nn.Sequential(
T.RandomCrop(224),
T.RandomHorizontalFlip(p=0.3),
)
device = 'cuda' if torch.cuda.is_available() else 'cpu'
dog1 = dog1.to(device)
dog2 = dog2.to(device)
transformed_dog1 = transforms(dog1)
transformed_dog2 = transforms(dog2)
show([transformed_dog1, transformed_dog2])
####################################
# Scriptable transforms for easier deployment via torchscript
# -----------------------------------------------------------
# We now show how to combine image transformations and a model forward pass,
# while using ``torch.jit.script`` to obtain a single scripted module.
#
# Let's define a ``Predictor`` module that transforms the input tensor and then
# applies an ImageNet model on it.
from torchvision.models import resnet18
class Predictor(nn.Module):
def __init__(self):
super().__init__()
self.resnet18 = resnet18(pretrained=True, progress=False).eval()
self.transforms = nn.Sequential(
T.Resize([256, ]), # We use single int value inside a list due to torchscript type restrictions
T.CenterCrop(224),
T.ConvertImageDtype(torch.float),
T.Normalize([0.485, 0.456, 0.406], [0.229, 0.224, 0.225])
)
def forward(self, x: torch.Tensor) -> torch.Tensor:
with torch.no_grad():
x = self.transforms(x)
y_pred = self.resnet18(x)
return y_pred.argmax(dim=1)
####################################
# Now, let's define scripted and non-scripted instances of ``Predictor`` and
# apply it on multiple tensor images of the same size
predictor = Predictor().to(device)
scripted_predictor = torch.jit.script(predictor).to(device)
batch = torch.stack([dog1, dog2]).to(device)
res = predictor(batch)
res_scripted = scripted_predictor(batch)
####################################
# We can verify that the prediction of the scripted and non-scripted models are
# the same:
import json
with open(Path('assets') / 'imagenet_class_index.json', 'r') as labels_file:
labels = json.load(labels_file)
for i, (pred, pred_scripted) in enumerate(zip(res, res_scripted)):
assert pred == pred_scripted
print(f"Prediction for Dog {i + 1}: {labels[str(pred.item())]}")
####################################
# Since the model is scripted, it can be easily dumped on disk an re-used
import tempfile
with tempfile.NamedTemporaryFile() as f:
scripted_predictor.save(f.name)
dumped_scripted_predictor = torch.jit.load(f.name)
res_scripted_dumped = dumped_scripted_predictor(batch)
assert (res_scripted_dumped == res_scripted).all()
......@@ -3,7 +3,8 @@
Illustration of transforms
==========================
This example illustrates the various transforms available in :mod:`torchvision.transforms`.
This example illustrates the various transforms available in :ref:`the
torchvision.transforms module <transforms>`.
"""
from PIL import Image
......
