Refactor unittests (#241)

* refactor unittests

* split test_video.py to two files
parent b7e8d7d7
Hide whitespace changes
Inline Side-by-side
Showing with 828 additions and 120 deletions
mmcv/image/io.py
View file @ a338d43d
......@@ -38,20 +38,22 @@ def use_backend(backend):
imread_backend = backend
if imread_backend == 'turbojpeg':
if TurboJPEG is None:
raise ValueError('`PyTurboJPEG` is not installed')
raise ImportError('`PyTurboJPEG` is not installed')
global jpeg
if jpeg is None:
jpeg = TurboJPEG()
def _jpegflag(flag='color', channel_order='bgr'):
channel_order = channel_order.lower()
if channel_order not in ['rgb', 'bgr']:
raise ValueError('channel order must be either "rgb" or "bgr"')
if flag == 'color':
if channel_order == 'bgr':
return TJPF_BGR
elif channel_order == 'rgb':
return TJCS_RGB
else:
raise ValueError('channel order must be "rgb" or "bgr"')
elif flag == 'grayscale':
return TJPF_GRAY
else:
......
tests/test_image/test_colorspace.py 0 → 100644
View file @ a338d43d
# Copyright (c) Open-MMLab. All rights reserved.
import cv2
import numpy as np
import pytest
from numpy.testing import assert_array_almost_equal, assert_array_equal
import mmcv
def test_bgr2gray():
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.bgr2gray(in_img)
computed_gray = (
in_img[:, :, 0] * 0.114 + in_img[:, :, 1] * 0.587 +
in_img[:, :, 2] * 0.299)
assert_array_almost_equal(out_img, computed_gray, decimal=4)
out_img_3d = mmcv.bgr2gray(in_img, True)
assert out_img_3d.shape == (10, 10, 1)
assert_array_almost_equal(out_img_3d[..., 0], out_img, decimal=4)
def test_rgb2gray():
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.rgb2gray(in_img)
computed_gray = (
in_img[:, :, 0] * 0.299 + in_img[:, :, 1] * 0.587 +
in_img[:, :, 2] * 0.114)
assert_array_almost_equal(out_img, computed_gray, decimal=4)
out_img_3d = mmcv.rgb2gray(in_img, True)
assert out_img_3d.shape == (10, 10, 1)
assert_array_almost_equal(out_img_3d[..., 0], out_img, decimal=4)
def test_gray2bgr():
in_img = np.random.rand(10, 10).astype(np.float32)
out_img = mmcv.gray2bgr(in_img)
assert out_img.shape == (10, 10, 3)
for i in range(3):
assert_array_almost_equal(out_img[..., i], in_img, decimal=4)
def test_gray2rgb():
in_img = np.random.rand(10, 10).astype(np.float32)
out_img = mmcv.gray2rgb(in_img)
assert out_img.shape == (10, 10, 3)
for i in range(3):
assert_array_almost_equal(out_img[..., i], in_img, decimal=4)
def test_bgr2rgb():
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.bgr2rgb(in_img)
assert out_img.shape == in_img.shape
assert_array_equal(out_img[..., 0], in_img[..., 2])
assert_array_equal(out_img[..., 1], in_img[..., 1])
assert_array_equal(out_img[..., 2], in_img[..., 0])
def test_rgb2bgr():
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.rgb2bgr(in_img)
assert out_img.shape == in_img.shape
assert_array_equal(out_img[..., 0], in_img[..., 2])
assert_array_equal(out_img[..., 1], in_img[..., 1])
assert_array_equal(out_img[..., 2], in_img[..., 0])
def test_bgr2hsv():
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.bgr2hsv(in_img)
argmax = in_img.argmax(axis=2)
computed_hsv = np.empty_like(in_img, dtype=in_img.dtype)
for i in range(in_img.shape[0]):
for j in range(in_img.shape[1]):
b = in_img[i, j, 0]
g = in_img[i, j, 1]
r = in_img[i, j, 2]
v = max(r, g, b)
s = (v - min(r, g, b)) / v if v != 0 else 0
if argmax[i, j] == 0:
h = 240 + 60 * (r - g) / (v - min(r, g, b))
elif argmax[i, j] == 1:
h = 120 + 60 * (b - r) / (v - min(r, g, b))
else:
h = 60 * (g - b) / (v - min(r, g, b))
if h < 0:
h += 360
computed_hsv[i, j, :] = [h, s, v]
assert_array_almost_equal(out_img, computed_hsv, decimal=2)
def test_bgr2hls():
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.bgr2hls(in_img)
argmax = in_img.argmax(axis=2)
computed_hls = np.empty_like(in_img, dtype=in_img.dtype)
for i in range(in_img.shape[0]):
for j in range(in_img.shape[1]):
b = in_img[i, j, 0]
g = in_img[i, j, 1]
r = in_img[i, j, 2]
maxc = max(r, g, b)
minc = min(r, g, b)
_l = (minc + maxc) / 2.0
if minc == maxc:
h = 0.0
s = 0.0
if _l <= 0.5:
s = (maxc - minc) / (maxc + minc)
else:
s = (maxc - minc) / (2.0 - maxc - minc)
if argmax[i, j] == 2:
h = 60 * (g - b) / (maxc - minc)
elif argmax[i, j] == 1:
h = 60 * (2.0 + (b - r) / (maxc - minc))
else:
h = 60 * (4.0 + (r - g) / (maxc - minc))
if h < 0:
h += 360
computed_hls[i, j, :] = [h, _l, s]
assert_array_almost_equal(out_img, computed_hls, decimal=2)
@pytest.mark.parametrize('src,dst,ref', [('bgr', 'gray', cv2.COLOR_BGR2GRAY),
('rgb', 'gray', cv2.COLOR_RGB2GRAY),
('bgr', 'rgb', cv2.COLOR_BGR2RGB),
('rgb', 'bgr', cv2.COLOR_RGB2BGR),
('bgr', 'hsv', cv2.COLOR_BGR2HSV),
('hsv', 'bgr', cv2.COLOR_HSV2BGR),
('bgr', 'hls', cv2.COLOR_BGR2HLS),
('hls', 'bgr', cv2.COLOR_HLS2BGR)])
def test_imconvert(src, dst, ref):
img = np.random.rand(10, 10, 3).astype(np.float32)
assert_array_equal(mmcv.imconvert(img, src, dst), cv2.cvtColor(img, ref))
tests/test_image.py → tests/test_image/test_geometric.py
View file @ a338d43d
# Copyright (c) Open-MMLab. All rights reserved.
import os
import os.path as osp
import tempfile
from pathlib import Path
import cv2
import numpy as np
import pytest
from numpy.testing import assert_array_almost_equal, assert_array_equal
from numpy.testing import assert_array_equal
import mmcv
class TestIO:
@classmethod
def setup_class(cls):
# the test img resolution is 400x300
cls.img_path = osp.join(osp.dirname(__file__), 'data/color.jpg')
cls.img_path_obj = Path(cls.img_path)
cls.gray_img_path = osp.join(
osp.dirname(__file__), 'data/grayscale.jpg')
cls.gray_img_path_obj = Path(cls.gray_img_path)
cls.img = cv2.imread(cls.img_path)
def assert_img_equal(self, img, ref_img, ratio_thr=0.999):
assert img.shape == ref_img.shape
assert img.dtype == ref_img.dtype
area = ref_img.shape[0] * ref_img.shape[1]
diff = np.abs(img.astype('int32') - ref_img.astype('int32'))
assert np.sum(diff <= 1) / float(area) > ratio_thr
def test_imread(self):
# backend cv2
mmcv.use_backend('cv2')
img_cv2_color_bgr = mmcv.imread(self.img_path)
assert img_cv2_color_bgr.shape == (300, 400, 3)
img_cv2_color_rgb = mmcv.imread(self.img_path, channel_order='rgb')
assert img_cv2_color_rgb.shape == (300, 400, 3)
assert_array_equal(img_cv2_color_rgb[:, :, ::-1], img_cv2_color_bgr)
img_cv2_grayscale1 = mmcv.imread(self.img_path, 'grayscale')
assert img_cv2_grayscale1.shape == (300, 400)
img_cv2_grayscale2 = mmcv.imread(self.gray_img_path)
assert img_cv2_grayscale2.shape == (300, 400, 3)
img_cv2_unchanged = mmcv.imread(self.gray_img_path, 'unchanged')
assert img_cv2_unchanged.shape == (300, 400)
img_cv2_unchanged = mmcv.imread(img_cv2_unchanged)
assert_array_equal(img_cv2_unchanged, mmcv.imread(img_cv2_unchanged))
img_cv2_color_bgr = mmcv.imread(self.img_path_obj)
assert img_cv2_color_bgr.shape == (300, 400, 3)
img_cv2_color_rgb = mmcv.imread(self.img_path_obj, channel_order='rgb')
assert img_cv2_color_rgb.shape == (300, 400, 3)
assert_array_equal(img_cv2_color_rgb[:, :, ::-1], img_cv2_color_bgr)
img_cv2_grayscale1 = mmcv.imread(self.img_path_obj, 'grayscale')
assert img_cv2_grayscale1.shape == (300, 400)
img_cv2_grayscale2 = mmcv.imread(self.gray_img_path_obj)
assert img_cv2_grayscale2.shape == (300, 400, 3)
img_cv2_unchanged = mmcv.imread(self.gray_img_path_obj, 'unchanged')
assert img_cv2_unchanged.shape == (300, 400)
with pytest.raises(TypeError):
mmcv.imread(1)
# backend turbojpeg
mmcv.use_backend('turbojpeg')
img_turbojpeg_color_bgr = mmcv.imread(self.img_path)
assert img_turbojpeg_color_bgr.shape == (300, 400, 3)
assert_array_equal(img_turbojpeg_color_bgr, img_cv2_color_bgr)
img_turbojpeg_color_rgb = mmcv.imread(
self.img_path, channel_order='rgb')
assert img_turbojpeg_color_rgb.shape == (300, 400, 3)
assert_array_equal(img_turbojpeg_color_rgb, img_cv2_color_rgb)
with pytest.raises(ValueError):
mmcv.imread(self.img_path, channel_order='unsupport_order')
img_turbojpeg_grayscale1 = mmcv.imread(self.img_path, flag='grayscale')
assert img_turbojpeg_grayscale1.shape == (300, 400)
assert_array_equal(img_turbojpeg_grayscale1, img_cv2_grayscale1)
img_turbojpeg_grayscale2 = mmcv.imread(self.gray_img_path)
assert img_turbojpeg_grayscale2.shape == (300, 400, 3)
assert_array_equal(img_turbojpeg_grayscale2, img_cv2_grayscale2)
img_turbojpeg_grayscale2 = mmcv.imread(img_turbojpeg_grayscale2)
assert_array_equal(img_turbojpeg_grayscale2,
mmcv.imread(img_turbojpeg_grayscale2))
with pytest.raises(ValueError):
mmcv.imread(self.gray_img_path, 'unchanged')
with pytest.raises(TypeError):
mmcv.imread(1)
with pytest.raises(AssertionError):
mmcv.use_backend('unsupport_backend')
mmcv.use_backend('cv2')
def test_imfrombytes(self):
# backend cv2
mmcv.use_backend('cv2')
with open(self.img_path, 'rb') as f:
img_bytes = f.read()
img_cv2 = mmcv.imfrombytes(img_bytes)
assert img_cv2.shape == (300, 400, 3)
# backend turbojpeg
mmcv.use_backend('turbojpeg')
with open(self.img_path, 'rb') as f:
img_bytes = f.read()
img_turbojpeg = mmcv.imfrombytes(img_bytes)
assert img_turbojpeg.shape == (300, 400, 3)
assert_array_equal(img_cv2, img_turbojpeg)
mmcv.use_backend('cv2')
def test_imwrite(self):
img = mmcv.imread(self.img_path)
out_file = osp.join(tempfile.gettempdir(), 'mmcv_test.jpg')
mmcv.imwrite(img, out_file)
rewrite_img = mmcv.imread(out_file)
os.remove(out_file)
self.assert_img_equal(img, rewrite_img)
class TestColorSpace:
def test_bgr2gray(self):
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.bgr2gray(in_img)
computed_gray = (
in_img[:, :, 0] * 0.114 + in_img[:, :, 1] * 0.587 +
in_img[:, :, 2] * 0.299)
assert_array_almost_equal(out_img, computed_gray, decimal=4)
out_img_3d = mmcv.bgr2gray(in_img, True)
assert out_img_3d.shape == (10, 10, 1)
assert_array_almost_equal(out_img_3d[..., 0], out_img, decimal=4)
def test_rgb2gray(self):
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.rgb2gray(in_img)
computed_gray = (
in_img[:, :, 0] * 0.299 + in_img[:, :, 1] * 0.587 +
in_img[:, :, 2] * 0.114)
assert_array_almost_equal(out_img, computed_gray, decimal=4)
out_img_3d = mmcv.rgb2gray(in_img, True)
assert out_img_3d.shape == (10, 10, 1)
assert_array_almost_equal(out_img_3d[..., 0], out_img, decimal=4)
def test_gray2bgr(self):
in_img = np.random.rand(10, 10).astype(np.float32)
out_img = mmcv.gray2bgr(in_img)
assert out_img.shape == (10, 10, 3)
for i in range(3):
assert_array_almost_equal(out_img[..., i], in_img, decimal=4)
def test_gray2rgb(self):
in_img = np.random.rand(10, 10).astype(np.float32)
out_img = mmcv.gray2rgb(in_img)
assert out_img.shape == (10, 10, 3)
for i in range(3):
assert_array_almost_equal(out_img[..., i], in_img, decimal=4)
def test_bgr2rgb(self):
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.bgr2rgb(in_img)
assert out_img.shape == in_img.shape
assert_array_equal(out_img[..., 0], in_img[..., 2])
assert_array_equal(out_img[..., 1], in_img[..., 1])
assert_array_equal(out_img[..., 2], in_img[..., 0])
def test_rgb2bgr(self):
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.rgb2bgr(in_img)
assert out_img.shape == in_img.shape
assert_array_equal(out_img[..., 0], in_img[..., 2])
assert_array_equal(out_img[..., 1], in_img[..., 1])
assert_array_equal(out_img[..., 2], in_img[..., 0])
def test_bgr2hsv(self):
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.bgr2hsv(in_img)
argmax = in_img.argmax(axis=2)
computed_hsv = np.empty_like(in_img, dtype=in_img.dtype)
for i in range(in_img.shape[0]):
for j in range(in_img.shape[1]):
b = in_img[i, j, 0]
g = in_img[i, j, 1]
r = in_img[i, j, 2]
v = max(r, g, b)
s = (v - min(r, g, b)) / v if v != 0 else 0
if argmax[i, j] == 0:
h = 240 + 60 * (r - g) / (v - min(r, g, b))
elif argmax[i, j] == 1:
h = 120 + 60 * (b - r) / (v - min(r, g, b))
else:
h = 60 * (g - b) / (v - min(r, g, b))
if h < 0:
h += 360
computed_hsv[i, j, :] = [h, s, v]
assert_array_almost_equal(out_img, computed_hsv, decimal=2)
def test_bgr2hls(self):
in_img = np.random.rand(10, 10, 3).astype(np.float32)
out_img = mmcv.bgr2hls(in_img)
argmax = in_img.argmax(axis=2)
computed_hls = np.empty_like(in_img, dtype=in_img.dtype)
for i in range(in_img.shape[0]):
for j in range(in_img.shape[1]):
b = in_img[i, j, 0]
g = in_img[i, j, 1]
r = in_img[i, j, 2]
maxc = max(r, g, b)
minc = min(r, g, b)
_l = (minc + maxc) / 2.0
if minc == maxc:
h = 0.0
s = 0.0
if _l <= 0.5:
s = (maxc - minc) / (maxc + minc)
else:
s = (maxc - minc) / (2.0 - maxc - minc)
if argmax[i, j] == 2:
h = 60 * (g - b) / (maxc - minc)
elif argmax[i, j] == 1:
h = 60 * (2.0 + (b - r) / (maxc - minc))
else:
h = 60 * (4.0 + (r - g) / (maxc - minc))
if h < 0:
h += 360
computed_hls[i, j, :] = [h, _l, s]
assert_array_almost_equal(out_img, computed_hls, decimal=2)
@pytest.mark.parametrize('src,dst,ref',
[('bgr', 'gray', cv2.COLOR_BGR2GRAY),
('rgb', 'gray', cv2.COLOR_RGB2GRAY),
('bgr', 'rgb', cv2.COLOR_BGR2RGB),
('rgb', 'bgr', cv2.COLOR_RGB2BGR),
('bgr', 'hsv', cv2.COLOR_BGR2HSV),
('hsv', 'bgr', cv2.COLOR_HSV2BGR),
('bgr', 'hls', cv2.COLOR_BGR2HLS),
('hls', 'bgr', cv2.COLOR_HLS2BGR)])
def test_imconvert(self, src, dst, ref):
img = np.random.rand(10, 10, 3).astype(np.float32)
assert_array_equal(
mmcv.imconvert(img, src, dst), cv2.cvtColor(img, ref))
class TestGeometric:
@classmethod
def setup_class(cls):
cls.data_dir = osp.join(osp.dirname(__file__), '../data')
# the test img resolution is 400x300
cls.img_path = osp.join(osp.dirname(__file__), 'data/color.jpg')
cls.img_path = osp.join(cls.data_dir, 'color.jpg')
cls.img = cv2.imread(cls.img_path)
def test_imresize(self):
......@@ -432,7 +191,7 @@ class TestGeometric:
patch = mmcv.imcrop(self.img, bboxes[0, :])
patches = mmcv.imcrop(self.img, bboxes[[0], :])
assert patch.shape == (100, 100, 3)
patch_path = osp.join(osp.dirname(__file__), 'data/patches')
patch_path = osp.join(self.data_dir, 'patches')
ref_patch = np.load(patch_path + '/0.npy')
assert_array_equal(patch, ref_patch)
assert isinstance(patches, list) and len(patches) == 1
......@@ -442,23 +201,23 @@ class TestGeometric:
patches = mmcv.imcrop(self.img, bboxes)
assert len(patches) == bboxes.shape[0]
for i in range(len(patches)):
ref_patch = np.load(patch_path + f'/{i}.npy')
ref_patch = np.load(patch_path + '/{}.npy'.format(i))
assert_array_equal(patches[i], ref_patch)
# crop with scaling and no padding
patches = mmcv.imcrop(self.img, bboxes, 1.2)
for i in range(len(patches)):
ref_patch = np.load(patch_path + f'/scale_{i}.npy')
ref_patch = np.load(patch_path + '/scale_{}.npy'.format(i))
assert_array_equal(patches[i], ref_patch)
# crop with scaling and padding
patches = mmcv.imcrop(self.img, bboxes, 1.2, pad_fill=[255, 255, 0])
for i in range(len(patches)):
ref_patch = np.load(patch_path + f'/pad_{i}.npy')
ref_patch = np.load(patch_path + '/pad_{}.npy'.format(i))
assert_array_equal(patches[i], ref_patch)
patches = mmcv.imcrop(self.img, bboxes, 1.2, pad_fill=0)
for i in range(len(patches)):
ref_patch = np.load(patch_path + f'/pad0_{i}.npy')
ref_patch = np.load(patch_path + '/pad0_{}.npy'.format(i))
assert_array_equal(patches[i], ref_patch)
def test_impad(self):
......@@ -528,72 +287,3 @@ class TestGeometric:
with pytest.raises(ValueError):
mmcv.imrotate(img, 90, center=(0, 0), auto_bound=True)
class TestPhotometric:
@classmethod
def setup_class(cls):
# the test img resolution is 400x300
cls.img_path = osp.join(osp.dirname(__file__), 'data/color.jpg')
cls.img = cv2.imread(cls.img_path)
cls.mean = np.array([123.675, 116.28, 103.53], dtype=np.float32)
cls.std = np.array([58.395, 57.12, 57.375], dtype=np.float32)
def test_imnormalize(self):
rgb_img = self.img[:, :, ::-1]
baseline = (rgb_img - self.mean) / self.std
img = mmcv.imnormalize(self.img, self.mean, self.std)
assert np.allclose(img, baseline)
assert id(img) != id(self.img)
img = mmcv.imnormalize(rgb_img, self.mean, self.std, to_rgb=False)
assert np.allclose(img, baseline)
assert id(img) != id(rgb_img)
def test_imnormalize_(self):
img_for_normalize = np.float32(self.img)
rgb_img_for_normalize = np.float32(self.img[:, :, ::-1])
baseline = (rgb_img_for_normalize - self.mean) / self.std
img = mmcv.imnormalize_(img_for_normalize, self.mean, self.std)
assert np.allclose(img_for_normalize, baseline)
assert id(img) == id(img_for_normalize)
img = mmcv.imnormalize_(
rgb_img_for_normalize, self.mean, self.std, to_rgb=False)
assert np.allclose(img, baseline)
assert id(img) == id(rgb_img_for_normalize)
def test_imdenormalize(self):
norm_img = (self.img[:, :, ::-1] - self.mean) / self.std
rgb_baseline = (norm_img * self.std + self.mean)
bgr_baseline = rgb_baseline[:, :, ::-1]
img = mmcv.imdenormalize(norm_img, self.mean, self.std)
assert np.allclose(img, bgr_baseline)
img = mmcv.imdenormalize(norm_img, self.mean, self.std, to_bgr=False)
assert np.allclose(img, rgb_baseline)
def test_iminvert(self):
img = np.array([[0, 128, 255], [1, 127, 254], [2, 129, 253]],
dtype=np.uint8)
img_r = np.array([[255, 127, 0], [254, 128, 1], [253, 126, 2]],
dtype=np.uint8)
assert_array_equal(mmcv.iminvert(img), img_r)
def test_solarize(self):
img = np.array([[0, 128, 255], [1, 127, 254], [2, 129, 253]],
dtype=np.uint8)
img_r = np.array([[0, 127, 0], [1, 127, 1], [2, 126, 2]],
dtype=np.uint8)
assert_array_equal(mmcv.solarize(img), img_r)
img_r = np.array([[0, 127, 0], [1, 128, 1], [2, 126, 2]],
dtype=np.uint8)
assert_array_equal(mmcv.solarize(img, 100), img_r)
def test_posterize(self):
img = np.array([[0, 128, 255], [1, 127, 254], [2, 129, 253]],
dtype=np.uint8)
img_r = np.array([[0, 128, 128], [0, 0, 128], [0, 128, 128]],
dtype=np.uint8)
assert_array_equal(mmcv.posterize(img, 1), img_r)
img_r = np.array([[0, 128, 224], [0, 96, 224], [0, 128, 224]],
dtype=np.uint8)
assert_array_equal(mmcv.posterize(img, 3), img_r)
tests/test_image/test_io.py 0 → 100644
View file @ a338d43d
# Copyright (c) Open-MMLab. All rights reserved.
import os
import os.path as osp
import tempfile
from pathlib import Path
from unittest.mock import patch
import cv2
import numpy as np
import pytest
from numpy.testing import assert_array_equal
import mmcv
class TestIO:
@classmethod
def setup_class(cls):
cls.data_dir = osp.join(osp.dirname(__file__), '../data')
# the test img resolution is 400x300
cls.img_path = osp.join(cls.data_dir, 'color.jpg')
cls.img_path_obj = Path(cls.img_path)
cls.gray_img_path = osp.join(cls.data_dir, 'grayscale.jpg')
cls.gray_img_path_obj = Path(cls.gray_img_path)
cls.gray_img_dim3_path = osp.join(cls.data_dir, 'grayscale_dim3.jpg')
cls.img = cv2.imread(cls.img_path)
def assert_img_equal(self, img, ref_img, ratio_thr=0.999):
assert img.shape == ref_img.shape
assert img.dtype == ref_img.dtype
area = ref_img.shape[0] * ref_img.shape[1]
diff = np.abs(img.astype('int32') - ref_img.astype('int32'))
assert np.sum(diff <= 1) / float(area) > ratio_thr
def test_imread(self):
# backend cv2
mmcv.use_backend('cv2')
img_cv2_color_bgr = mmcv.imread(self.img_path)
assert img_cv2_color_bgr.shape == (300, 400, 3)
img_cv2_color_rgb = mmcv.imread(self.img_path, channel_order='rgb')
assert img_cv2_color_rgb.shape == (300, 400, 3)
assert_array_equal(img_cv2_color_rgb[:, :, ::-1], img_cv2_color_bgr)
img_cv2_grayscale1 = mmcv.imread(self.img_path, 'grayscale')
assert img_cv2_grayscale1.shape == (300, 400)
img_cv2_grayscale2 = mmcv.imread(self.gray_img_path)
assert img_cv2_grayscale2.shape == (300, 400, 3)
img_cv2_unchanged = mmcv.imread(self.gray_img_path, 'unchanged')
assert img_cv2_unchanged.shape == (300, 400)
img_cv2_unchanged = mmcv.imread(img_cv2_unchanged)
assert_array_equal(img_cv2_unchanged, mmcv.imread(img_cv2_unchanged))
img_cv2_color_bgr = mmcv.imread(self.img_path_obj)
assert img_cv2_color_bgr.shape == (300, 400, 3)
img_cv2_color_rgb = mmcv.imread(self.img_path_obj, channel_order='rgb')
assert img_cv2_color_rgb.shape == (300, 400, 3)
assert_array_equal(img_cv2_color_rgb[:, :, ::-1], img_cv2_color_bgr)
img_cv2_grayscale1 = mmcv.imread(self.img_path_obj, 'grayscale')
assert img_cv2_grayscale1.shape == (300, 400)
img_cv2_grayscale2 = mmcv.imread(self.gray_img_path_obj)
assert img_cv2_grayscale2.shape == (300, 400, 3)
img_cv2_unchanged = mmcv.imread(self.gray_img_path_obj, 'unchanged')
assert img_cv2_unchanged.shape == (300, 400)
with pytest.raises(TypeError):
mmcv.imread(1)
# backend turbojpeg
mmcv.use_backend('turbojpeg')
img_turbojpeg_color_bgr = mmcv.imread(self.img_path)
assert img_turbojpeg_color_bgr.shape == (300, 400, 3)
assert_array_equal(img_turbojpeg_color_bgr, img_cv2_color_bgr)
img_turbojpeg_color_rgb = mmcv.imread(
self.img_path, channel_order='rgb')
assert img_turbojpeg_color_rgb.shape == (300, 400, 3)
assert_array_equal(img_turbojpeg_color_rgb, img_cv2_color_rgb)
with pytest.raises(ValueError):
mmcv.imread(self.img_path, channel_order='unsupport_order')
img_turbojpeg_grayscale1 = mmcv.imread(self.img_path, flag='grayscale')
assert img_turbojpeg_grayscale1.shape == (300, 400)
assert_array_equal(img_turbojpeg_grayscale1, img_cv2_grayscale1)
img_turbojpeg_grayscale2 = mmcv.imread(self.gray_img_path)
assert img_turbojpeg_grayscale2.shape == (300, 400, 3)
assert_array_equal(img_turbojpeg_grayscale2, img_cv2_grayscale2)
img_turbojpeg_grayscale2 = mmcv.imread(img_turbojpeg_grayscale2)
assert_array_equal(img_turbojpeg_grayscale2,
mmcv.imread(img_turbojpeg_grayscale2))
with pytest.raises(ValueError):
mmcv.imread(self.gray_img_path, 'unchanged')
with pytest.raises(TypeError):
mmcv.imread(1)
with pytest.raises(AssertionError):
mmcv.use_backend('unsupport_backend')
mmcv.use_backend('cv2')
def test_imfrombytes(self):
# backend cv2, channel order: bgr
mmcv.use_backend('cv2')
with open(self.img_path, 'rb') as f:
img_bytes = f.read()
img_cv2 = mmcv.imfrombytes(img_bytes)
assert img_cv2.shape == (300, 400, 3)
# backend cv2, channel order: rgb
mmcv.use_backend('cv2')
with open(self.img_path, 'rb') as f:
img_bytes = f.read()
img_rgb_cv2 = mmcv.imfrombytes(img_bytes, channel_order='rgb')
assert img_rgb_cv2.shape == (300, 400, 3)
assert_array_equal(img_rgb_cv2, img_cv2[:, :, ::-1])
# backend cv2, grayscale, decode as 3 channels
with open(self.gray_img_path, 'rb') as f:
img_bytes = f.read()
gray_img_rgb_cv2 = mmcv.imfrombytes(img_bytes)
assert gray_img_rgb_cv2.shape == (300, 400, 3)
# backend cv2, grayscale
with open(self.gray_img_path, 'rb') as f:
img_bytes = f.read()
gray_img_cv2 = mmcv.imfrombytes(img_bytes, flag='grayscale')
assert gray_img_cv2.shape == (300, 400)
# backend cv2, grayscale dim3
with open(self.gray_img_dim3_path, 'rb') as f:
img_bytes = f.read()
gray_img_dim3_cv2 = mmcv.imfrombytes(img_bytes, flag='grayscale')
assert gray_img_dim3_cv2.shape == (300, 400)
# backend turbojpeg, channel order: bgr
mmcv.use_backend('turbojpeg')
with open(self.img_path, 'rb') as f:
img_bytes = f.read()
img_turbojpeg = mmcv.imfrombytes(img_bytes)
assert img_turbojpeg.shape == (300, 400, 3)
assert_array_equal(img_cv2, img_turbojpeg)
# backend turbojpeg, channel order: rgb
mmcv.use_backend('cv2')
with open(self.img_path, 'rb') as f:
img_bytes = f.read()
img_rgb_turbojpeg = mmcv.imfrombytes(img_bytes, channel_order='rgb')
assert img_rgb_turbojpeg.shape == (300, 400, 3)
assert_array_equal(img_rgb_turbojpeg, img_cv2[:, :, ::-1])
# backend turbojpeg, grayscale, decode as 3 channels
with open(self.gray_img_path, 'rb') as f:
img_bytes = f.read()
gray_img_turbojpeg = mmcv.imfrombytes(img_bytes)
assert gray_img_turbojpeg.shape == (300, 400, 3)
assert_array_equal(gray_img_rgb_cv2, gray_img_turbojpeg)
# backend turbojpeg, grayscale
with open(self.gray_img_path, 'rb') as f:
img_bytes = f.read()
gray_img_turbojpeg = mmcv.imfrombytes(img_bytes, flag='grayscale')
assert gray_img_turbojpeg.shape == (300, 400)
assert_array_equal(gray_img_cv2, gray_img_turbojpeg)
# backend turbojpeg, grayscale dim3
with open(self.gray_img_dim3_path, 'rb') as f:
img_bytes = f.read()
gray_img_dim3_turbojpeg = mmcv.imfrombytes(img_bytes, flag='grayscale')
assert gray_img_dim3_turbojpeg.shape == (300, 400)
assert_array_equal(gray_img_dim3_cv2, gray_img_dim3_turbojpeg)
mmcv.use_backend('cv2')
def test_imwrite(self):
img = mmcv.imread(self.img_path)
out_file = osp.join(tempfile.gettempdir(), 'mmcv_test.jpg')
mmcv.imwrite(img, out_file)
rewrite_img = mmcv.imread(out_file)
os.remove(out_file)
self.assert_img_equal(img, rewrite_img)
ret = mmcv.imwrite(
img, './non_exist_path/mmcv_test.jpg', auto_mkdir=False)
assert ret is False
@patch('mmcv.image.io.TurboJPEG', None)
def test_no_turbojpeg(self):
with pytest.raises(ImportError):
mmcv.use_backend('turbojpeg')
mmcv.use_backend('cv2')
tests/test_image/test_photometric.py 0 → 100644
View file @ a338d43d
# Copyright (c) Open-MMLab. All rights reserved.
import os.path as osp
import cv2
import numpy as np
from numpy.testing import assert_array_equal
import mmcv
class TestPhotometric:
@classmethod
def setup_class(cls):
# the test img resolution is 400x300
cls.img_path = osp.join(osp.dirname(__file__), '../data/color.jpg')
cls.img = cv2.imread(cls.img_path)
cls.mean = np.array([123.675, 116.28, 103.53], dtype=np.float32)
cls.std = np.array([58.395, 57.12, 57.375], dtype=np.float32)
def test_imnormalize(self):
rgb_img = self.img[:, :, ::-1]
baseline = (rgb_img - self.mean) / self.std
img = mmcv.imnormalize(self.img, self.mean, self.std)
assert np.allclose(img, baseline)
assert id(img) != id(self.img)
img = mmcv.imnormalize(rgb_img, self.mean, self.std, to_rgb=False)
assert np.allclose(img, baseline)
assert id(img) != id(rgb_img)
def test_imnormalize_(self):
img_for_normalize = np.float32(self.img)
rgb_img_for_normalize = np.float32(self.img[:, :, ::-1])
baseline = (rgb_img_for_normalize - self.mean) / self.std
img = mmcv.imnormalize_(img_for_normalize, self.mean, self.std)
assert np.allclose(img_for_normalize, baseline)
assert id(img) == id(img_for_normalize)
img = mmcv.imnormalize_(
rgb_img_for_normalize, self.mean, self.std, to_rgb=False)
assert np.allclose(img, baseline)
assert id(img) == id(rgb_img_for_normalize)
def test_imdenormalize(self):
norm_img = (self.img[:, :, ::-1] - self.mean) / self.std
rgb_baseline = (norm_img * self.std + self.mean)
bgr_baseline = rgb_baseline[:, :, ::-1]
img = mmcv.imdenormalize(norm_img, self.mean, self.std)
assert np.allclose(img, bgr_baseline)
img = mmcv.imdenormalize(norm_img, self.mean, self.std, to_bgr=False)
assert np.allclose(img, rgb_baseline)
def test_iminvert(self):
img = np.array([[0, 128, 255], [1, 127, 254], [2, 129, 253]],
dtype=np.uint8)
img_r = np.array([[255, 127, 0], [254, 128, 1], [253, 126, 2]],
dtype=np.uint8)
assert_array_equal(mmcv.iminvert(img), img_r)
def test_solarize(self):
img = np.array([[0, 128, 255], [1, 127, 254], [2, 129, 253]],
dtype=np.uint8)
img_r = np.array([[0, 127, 0], [1, 127, 1], [2, 126, 2]],
dtype=np.uint8)
assert_array_equal(mmcv.solarize(img), img_r)
img_r = np.array([[0, 127, 0], [1, 128, 1], [2, 126, 2]],
dtype=np.uint8)
assert_array_equal(mmcv.solarize(img, 100), img_r)
def test_posterize(self):
img = np.array([[0, 128, 255], [1, 127, 254], [2, 129, 253]],
dtype=np.uint8)
img_r = np.array([[0, 128, 128], [0, 0, 128], [0, 128, 128]],
dtype=np.uint8)
assert_array_equal(mmcv.posterize(img, 1), img_r)
img_r = np.array([[0, 128, 224], [0, 96, 224], [0, 128, 224]],
dtype=np.uint8)
assert_array_equal(mmcv.posterize(img, 3), img_r)
tests/test_optflow.py → tests/test_video/test_optflow.py
View file @ a338d43d
# Copyright (c) Open-MMLab. All rights reserved.
# flake8: noqa
import os
import os.path as osp
import tempfile
import time
import numpy as np
import pytest
......@@ -14,10 +11,11 @@ import mmcv
def test_flowread():
data_dir = osp.join(osp.dirname(__file__), '../data')
flow_shape = (60, 80, 2)
# read .flo file
flow = mmcv.flowread(osp.join(osp.dirname(__file__), 'data/optflow.flo'))
flow = mmcv.flowread(osp.join(data_dir, 'optflow.flo'))
assert flow.shape == flow_shape
# pseudo read
......@@ -26,21 +24,19 @@ def test_flowread():
# read quantized flow concatenated vertically
flow = mmcv.flowread(
osp.join(osp.dirname(__file__), 'data/optflow_concat0.jpg'),
quantize=True,
denorm=True)
osp.join(data_dir, 'optflow_concat0.jpg'), quantize=True, denorm=True)
assert flow.shape == flow_shape
# read quantized flow concatenated horizontally
flow = mmcv.flowread(
osp.join(osp.dirname(__file__), 'data/optflow_concat1.jpg'),
osp.join(data_dir, 'optflow_concat1.jpg'),
quantize=True,
concat_axis=1,
denorm=True)
assert flow.shape == flow_shape
# test exceptions
notflow_file = osp.join(osp.dirname(__file__), 'data/color.jpg')
notflow_file = osp.join(data_dir, 'color.jpg')
with pytest.raises(TypeError):
mmcv.flowread(1)
with pytest.raises(IOError):
......@@ -188,74 +184,74 @@ def test_make_color_wheel():
color_wheel = mmcv.make_color_wheel([2, 2, 2, 2, 2, 2])
# yapf: disable
assert_array_equal(default_color_wheel, np.array(
[[1. , 0. , 0. ],
[1. , 0.06666667, 0. ],
[1. , 0.13333334, 0. ],
[1. , 0.2 , 0. ],
[1. , 0.26666668, 0. ],
[1. , 0.33333334, 0. ],
[1. , 0.4 , 0. ],
[1. , 0.46666667, 0. ],
[1. , 0.53333336, 0. ],
[1. , 0.6 , 0. ],
[1. , 0.6666667 , 0. ],
[1. , 0.73333335, 0. ],
[1. , 0.8 , 0. ],
[1. , 0.8666667 , 0. ],
[1. , 0.93333334, 0. ],
[1. , 1. , 0. ],
[0.8333333 , 1. , 0. ],
[0.6666667 , 1. , 0. ],
[0.5 , 1. , 0. ],
[0.33333334, 1. , 0. ],
[0.16666667, 1. , 0. ],
[0. , 1. , 0. ],
[0. , 1. , 0.25 ],
[0. , 1. , 0.5 ],
[0. , 1. , 0.75 ],
[0. , 1. , 1. ],
[0. , 0.90909094, 1. ],
[0. , 0.8181818 , 1. ],
[0. , 0.72727275, 1. ],
[0. , 0.6363636 , 1. ],
[0. , 0.54545456, 1. ],
[0. , 0.45454547, 1. ],
[0. , 0.36363637, 1. ],
[0. , 0.27272728, 1. ],
[0. , 0.18181819, 1. ],
[0. , 0.09090909, 1. ],
[0. , 0. , 1. ],
[0.07692308, 0. , 1. ],
[0.15384616, 0. , 1. ],
[0.23076923, 0. , 1. ],
[0.30769232, 0. , 1. ],
[0.3846154 , 0. , 1. ],
[0.46153846, 0. , 1. ],
[0.53846157, 0. , 1. ],
[0.61538464, 0. , 1. ],
[0.6923077 , 0. , 1. ],
[0.7692308 , 0. , 1. ],
[0.84615386, 0. , 1. ],
[0.9230769 , 0. , 1. ],
[1. , 0. , 1. ],
[1. , 0. , 0.8333333 ],
[1. , 0. , 0.6666667 ],
[1. , 0. , 0.5 ],
[1. , 0. , 0.33333334],
[1. , 0. , 0.16666667]], dtype=np.float32))
[[1. , 0. , 0. ], # noqa
[1. , 0.06666667, 0. ], # noqa
[1. , 0.13333334, 0. ], # noqa
[1. , 0.2 , 0. ], # noqa
[1. , 0.26666668, 0. ], # noqa
[1. , 0.33333334, 0. ], # noqa
[1. , 0.4 , 0. ], # noqa
[1. , 0.46666667, 0. ], # noqa
[1. , 0.53333336, 0. ], # noqa
[1. , 0.6 , 0. ], # noqa
[1. , 0.6666667 , 0. ], # noqa
[1. , 0.73333335, 0. ], # noqa
[1. , 0.8 , 0. ], # noqa
[1. , 0.8666667 , 0. ], # noqa
[1. , 0.93333334, 0. ], # noqa
[1. , 1. , 0. ], # noqa
[0.8333333 , 1. , 0. ], # noqa
[0.6666667 , 1. , 0. ], # noqa
[0.5 , 1. , 0. ], # noqa
[0.33333334, 1. , 0. ], # noqa
[0.16666667, 1. , 0. ], # noqa
[0. , 1. , 0. ], # noqa
[0. , 1. , 0.25 ], # noqa
[0. , 1. , 0.5 ], # noqa
[0. , 1. , 0.75 ], # noqa
[0. , 1. , 1. ], # noqa
[0. , 0.90909094, 1. ], # noqa
[0. , 0.8181818 , 1. ], # noqa
[0. , 0.72727275, 1. ], # noqa
[0. , 0.6363636 , 1. ], # noqa
[0. , 0.54545456, 1. ], # noqa
[0. , 0.45454547, 1. ], # noqa
[0. , 0.36363637, 1. ], # noqa
[0. , 0.27272728, 1. ], # noqa
[0. , 0.18181819, 1. ], # noqa
[0. , 0.09090909, 1. ], # noqa
[0. , 0. , 1. ], # noqa
[0.07692308, 0. , 1. ], # noqa
[0.15384616, 0. , 1. ], # noqa
[0.23076923, 0. , 1. ], # noqa
[0.30769232, 0. , 1. ], # noqa
[0.3846154 , 0. , 1. ], # noqa
[0.46153846, 0. , 1. ], # noqa
[0.53846157, 0. , 1. ], # noqa
[0.61538464, 0. , 1. ], # noqa
[0.6923077 , 0. , 1. ], # noqa
[0.7692308 , 0. , 1. ], # noqa
[0.84615386, 0. , 1. ], # noqa
[0.9230769 , 0. , 1. ], # noqa
[1. , 0. , 1. ], # noqa
[1. , 0. , 0.8333333 ], # noqa
[1. , 0. , 0.6666667 ], # noqa
[1. , 0. , 0.5 ], # noqa
[1. , 0. , 0.33333334], # noqa
[1. , 0. , 0.16666667]], dtype=np.float32)) # noqa
assert_array_equal(
color_wheel,
np.array([[1., 0. , 0. ],
[1. , 0.5, 0. ],
[1. , 1. , 0. ],
[0.5, 1. , 0. ],
[0. , 1. , 0. ],
[0. , 1. , 0.5],
[0. , 1. , 1. ],
[0. , 0.5, 1. ],
[0. , 0. , 1. ],
[0.5, 0. , 1. ],
[1. , 0. , 1. ],
[1. , 0. , 0.5]], dtype=np.float32))
np.array([[1., 0. , 0. ], # noqa
[1. , 0.5, 0. ], # noqa
[1. , 1. , 0. ], # noqa
[0.5, 1. , 0. ], # noqa
[0. , 1. , 0. ], # noqa
[0. , 1. , 0.5], # noqa
[0. , 1. , 1. ], # noqa
[0. , 0.5, 1. ], # noqa
[0. , 0. , 1. ], # noqa
[0.5, 0. , 1. ], # noqa
[1. , 0. , 1. ], # noqa
[1. , 0. , 0.5]], dtype=np.float32)) # noqa
# yapf: enable
tests/test_video/test_processing.py 0 → 100644
View file @ a338d43d
# Copyright (c) Open-MMLab. All rights reserved.
import os
import os.path as osp
import tempfile
import mmcv
class TestVideoEditor:
@classmethod
def setup_class(cls):
cls.video_path = osp.join(osp.dirname(__file__), '../data/test.mp4')
cls.num_frames = 168
def test_cut_concat_video(self):
part1_file = osp.join(tempfile.gettempdir(), '.mmcv_test1.mp4')
part2_file = osp.join(tempfile.gettempdir(), '.mmcv_test2.mp4')
mmcv.cut_video(self.video_path, part1_file, end=3, vcodec='h264')
mmcv.cut_video(self.video_path, part2_file, start=3, vcodec='h264')
v1 = mmcv.VideoReader(part1_file)
v2 = mmcv.VideoReader(part2_file)
assert len(v1) == 75
assert len(v2) == self.num_frames - 75
out_file = osp.join(tempfile.gettempdir(), '.mmcv_test.mp4')
mmcv.concat_video([part1_file, part2_file], out_file)
v = mmcv.VideoReader(out_file)
assert len(v) == self.num_frames
os.remove(part1_file)
os.remove(part2_file)
os.remove(out_file)
def test_resize_video(self):
out_file = osp.join(tempfile.gettempdir(), '.mmcv_test.mp4')
mmcv.resize_video(self.video_path, out_file, (200, 100), quiet=True)
v = mmcv.VideoReader(out_file)
assert v.resolution == (200, 100)
os.remove(out_file)
mmcv.resize_video(self.video_path, out_file, ratio=2)
v = mmcv.VideoReader(out_file)
assert v.resolution == (294 * 2, 240 * 2)
os.remove(out_file)
mmcv.resize_video(self.video_path, out_file, (1000, 480), keep_ar=True)
v = mmcv.VideoReader(out_file)
assert v.resolution == (294 * 2, 240 * 2)
os.remove(out_file)
mmcv.resize_video(
self.video_path, out_file, ratio=(2, 1.5), keep_ar=True)
v = mmcv.VideoReader(out_file)
assert v.resolution == (294 * 2, 360)
os.remove(out_file)
tests/test_video.py → tests/test_video/test_reader.py
View file @ a338d43d
......@@ -10,7 +10,7 @@ import pytest
import mmcv
class TestCache(object):
class TestCache:
def test_init(self):
with pytest.raises(ValueError):
......@@ -39,11 +39,11 @@ class TestCache(object):
assert cache.get('k1') == 1
class TestVideo(object):
class TestVideoReader:
@classmethod
def setup_class(cls):
cls.video_path = osp.join(osp.dirname(__file__), 'data/test.mp4')
cls.video_path = osp.join(osp.dirname(__file__), '../data/test.mp4')
cls.num_frames = 168
def test_load(self):
......@@ -196,41 +196,3 @@ class TestVideo(object):
os.remove(filename)
shutil.rmtree(frame_dir)
os.remove(out_filename)
def test_cut_concat_video(self):
part1_file = osp.join(tempfile.gettempdir(), '.mmcv_test1.mp4')
part2_file = osp.join(tempfile.gettempdir(), '.mmcv_test2.mp4')
mmcv.cut_video(self.video_path, part1_file, end=3, vcodec='h264')
mmcv.cut_video(self.video_path, part2_file, start=3, vcodec='h264')
v1 = mmcv.VideoReader(part1_file)
v2 = mmcv.VideoReader(part2_file)
assert len(v1) == 75
assert len(v2) == self.num_frames - 75
out_file = osp.join(tempfile.gettempdir(), '.mmcv_test.mp4')
mmcv.concat_video([part1_file, part2_file], out_file)
v = mmcv.VideoReader(out_file)
assert len(v) == self.num_frames
os.remove(part1_file)
os.remove(part2_file)
os.remove(out_file)
def test_resize_video(self):
out_file = osp.join(tempfile.gettempdir(), '.mmcv_test.mp4')
mmcv.resize_video(self.video_path, out_file, (200, 100), quiet=True)
v = mmcv.VideoReader(out_file)
assert v.resolution == (200, 100)
os.remove(out_file)
mmcv.resize_video(self.video_path, out_file, ratio=2)
v = mmcv.VideoReader(out_file)
assert v.resolution == (294 * 2, 240 * 2)
os.remove(out_file)
mmcv.resize_video(self.video_path, out_file, (1000, 480), keep_ar=True)
v = mmcv.VideoReader(out_file)
assert v.resolution == (294 * 2, 240 * 2)
os.remove(out_file)
mmcv.resize_video(
self.video_path, out_file, ratio=(2, 1.5), keep_ar=True)
v = mmcv.VideoReader(out_file)
assert v.resolution == (294 * 2, 360)
os.remove(out_file)
Markdown is supported
0% or .
You are about to add 0 people to the discussion. Proceed with caution.
Finish editing this message first!
Please register or to comment
