feat: Image decoder in the frontend (#3971)

Signed-off-by: Alexandre Milesi <milesial@users.noreply.github.com>

.github/workflows/container-validation-dynamo.yml

@@ -26,6 +26,8 @@ jobs:
     steps:
       - name: Checkout repository
         uses: actions/checkout@v4
+        with:
+          lfs: true
       - name: Set up Docker Buildx
         uses: docker/setup-buildx-action@v3
       - name: Login to NGC

.github/workflows/pre-merge-rust.yml

@@ -44,6 +44,8 @@ jobs:
       contents: read
     steps:
     - uses: actions/checkout@v4
+      with:
+        lfs: true
     - name: Set up system dependencies
       run: |
         # Install protoc for Rust build dependencies (NOTE: much faster than apt install)
@@ -94,6 +96,8 @@ jobs:
       contents: read
     steps:
     - uses: actions/checkout@v4
+      with:
+        lfs: true
     - name: Set up system dependencies
       run: |
         # Install protoc for Rust build dependencies (NOTE: much faster than apt install)

Cargo.lock

@@ -2244,6 +2244,7 @@ dependencies = [
  "galil-seiferas",
  "hf-hub",
  "humantime",
+ "image",
  "insta",
  "itertools 0.14.0",
  "json-five",
@@ -2280,6 +2281,7 @@ dependencies = [
  "tmq",
  "tokenizers",
  "tokio",
+ "tokio-rayon",
  "tokio-stream",
  "tokio-util",
  "toktrie 1.2.0",

lib/llm/Cargo.toml

@@ -21,7 +21,7 @@ testing-full = ["testing-cuda", "testing-nixl"]
 testing-cuda = ["dep:cudarc"]
 testing-nixl = ["dep:nixl-sys"]
 testing-etcd = []
-block-manager = ["dep:nixl-sys", "dep:cudarc", "dep:ndarray", "dep:nix", "dep:aligned-vec"]
+block-manager = ["dep:nixl-sys", "dep:cudarc", "dep:nix", "dep:aligned-vec"]
 cuda = ["dep:cudarc"]
 integration = ["dynamo-runtime/integration"]

@@ -97,7 +97,6 @@ dialoguer = { version = "0.11", default-features = false, features = [
 aligned-vec = { version = "0.6.4", optional = true }
 nixl-sys = { version = "=0.7.0", optional = true }
 cudarc = { workspace = true, optional = true }
-ndarray = { version = "0.16", optional = true }
 nix = { version = "0.26", optional = true }


@@ -143,6 +142,9 @@ json-five = { version = "0.3" }
 # media loading in the preprocessor
 reqwest = { workspace = true }
 base64 = { version = "0.22" }
+image = { version = "0.25" }
+tokio-rayon = {version = "2" }
+ndarray = { version = "0.16" }

 # Publishers
 zeromq = "0.4.1"

lib/llm/src/preprocessor.rs

@@ -330,7 +330,7 @@ impl OpenAIPreprocessor {
             let _results = futures::future::join_all(
                 fetch_tasks
                     .iter()
-                    .map(|(_, content_part)| loader.fetch_media_part(content_part)),
+                    .map(|(_, content_part)| loader.fetch_and_decode_media_part(content_part)),
             )
             .await;


lib/llm/src/preprocessor/media.rs

@@ -2,7 +2,9 @@
 // SPDX-License-Identifier: Apache-2.0

 mod common;
+mod decoders;
 mod loader;

 pub use common::EncodedMediaData;
+pub use decoders::{Decoder, ImageDecoder, MediaDecoder};
 pub use loader::MediaLoader;

lib/llm/src/preprocessor/media/decoders.rs

+// SPDX-FileCopyrightText: Copyright (c) 2024-2025 NVIDIA CORPORATION & AFFILIATES. All rights reserved.
+// SPDX-License-Identifier: Apache-2.0
+
+use anyhow::Result;
+
+use super::common::EncodedMediaData;
+use ndarray::{ArrayBase, Dimension, OwnedRepr};
+mod image;
+
+pub use image::{ImageDecoder, ImageMetadata};
+
+#[derive(Debug)]
+pub enum DecodedMediaMetadata {
+    #[allow(dead_code)] // used in followup MR
+    Image(ImageMetadata),
+}
+
+#[derive(Debug, PartialEq, Eq)]
+pub enum DataType {
+    UINT8,
+}
+
+// Decoded media data (image RGB, video frames pixels, ...)
+#[derive(Debug)]
+pub struct DecodedMediaData {
+    #[allow(dead_code)] // used in followup MR
+    pub(crate) data: Vec<u8>,
+    #[allow(dead_code)] // used in followup MR
+    pub(crate) shape: Vec<usize>,
+    #[allow(dead_code)] // used in followup MR
+    pub(crate) dtype: DataType,
+    #[allow(dead_code)] // used in followup MR
+    pub(crate) metadata: Option<DecodedMediaMetadata>,
+}
+
+// convert Array{N}<u8> to DecodedMediaData
+// TODO: Array1<f32> for audio
+impl<D: Dimension> From<ArrayBase<OwnedRepr<u8>, D>> for DecodedMediaData {
+    fn from(array: ArrayBase<OwnedRepr<u8>, D>) -> Self {
+        let shape = array.shape().to_vec();
+        let (data, _) = array.into_raw_vec_and_offset();
+        Self {
+            data,
+            shape,
+            dtype: DataType::UINT8,
+            metadata: None,
+        }
+    }
+}
+
+#[async_trait::async_trait]
+pub trait Decoder: Clone + Send + 'static {
+    fn decode(&self, data: EncodedMediaData) -> Result<DecodedMediaData>;
+
+    async fn decode_async(&self, data: EncodedMediaData) -> Result<DecodedMediaData> {
+        // light clone (only config params)
+        let decoder = self.clone();
+        // compute heavy -> rayon
+        let result = tokio_rayon::spawn(move || decoder.decode(data)).await?;
+        Ok(result)
+    }
+}
+
+#[derive(Clone, Debug, Default, serde::Serialize, serde::Deserialize)]
+pub struct MediaDecoder {
+    #[serde(default)]
+    pub image_decoder: ImageDecoder,
+    // TODO: video, audio decoders
+}

lib/llm/src/preprocessor/media/decoders/image.rs

+// SPDX-FileCopyrightText: Copyright (c) 2024-2025 NVIDIA CORPORATION & AFFILIATES. All rights reserved.
+// SPDX-License-Identifier: Apache-2.0
+
+use std::io::Cursor;
+
+use anyhow::Result;
+use image::{ColorType, GenericImageView, ImageFormat, ImageReader};
+use ndarray::Array3;
+
+use super::super::common::EncodedMediaData;
+use super::super::decoders::{DecodedMediaData, DecodedMediaMetadata};
+use super::Decoder;
+
+const DEFAULT_MAX_ALLOC: u64 = 128 * 1024 * 1024; // 128 MB
+
+#[derive(Clone, Debug, serde::Serialize, serde::Deserialize)]
+#[serde(deny_unknown_fields)]
+pub struct ImageDecoder {
+    #[serde(default)]
+    pub(crate) max_image_width: Option<u32>,
+    #[serde(default)]
+    pub(crate) max_image_height: Option<u32>,
+    // maximum allowed total allocation of the decoder in bytes
+    #[serde(default)]
+    pub(crate) max_alloc: Option<u64>,
+}
+
+impl Default for ImageDecoder {
+    fn default() -> Self {
+        Self {
+            max_image_width: None,
+            max_image_height: None,
+            max_alloc: Some(DEFAULT_MAX_ALLOC),
+        }
+    }
+}
+
+#[allow(clippy::upper_case_acronyms)]
+#[derive(Debug)]
+pub enum ImageLayout {
+    HWC,
+}
+
+#[derive(Debug)]
+pub struct ImageMetadata {
+    #[allow(dead_code)] // used in followup MR
+    pub(crate) format: Option<ImageFormat>,
+    #[allow(dead_code)] // used in followup MR
+    pub(crate) color_type: ColorType,
+    #[allow(dead_code)] // used in followup MR
+    pub(crate) layout: ImageLayout,
+}
+
+impl Decoder for ImageDecoder {
+    fn decode(&self, data: EncodedMediaData) -> Result<DecodedMediaData> {
+        let bytes = data.into_bytes()?;
+
+        let mut reader = ImageReader::new(Cursor::new(bytes)).with_guessed_format()?;
+        let mut limits = image::Limits::no_limits();
+        limits.max_image_width = self.max_image_width;
+        limits.max_image_height = self.max_image_height;
+        limits.max_alloc = self.max_alloc;
+        reader.limits(limits);
+
+        let format = reader.format();
+
+        let img = reader.decode()?;
+        let n_channels = img.color().channel_count();
+
+        let (data, color_type) = match n_channels {
+            1 => (img.to_luma8().into_raw(), ColorType::L8),
+            2 => (img.to_luma_alpha8().into_raw(), ColorType::La8),
+            3 => (img.to_rgb8().into_raw(), ColorType::Rgb8),
+            4 => (img.to_rgba8().into_raw(), ColorType::Rgba8),
+            other => anyhow::bail!("Unsupported channel count {other}"),
+        };
+
+        let (width, height) = img.dimensions();
+        let shape = (height as usize, width as usize, n_channels as usize);
+        let array = Array3::from_shape_vec(shape, data)?;
+        let mut decoded: DecodedMediaData = array.into();
+        decoded.metadata = Some(DecodedMediaMetadata::Image(ImageMetadata {
+            format,
+            color_type,
+            layout: ImageLayout::HWC,
+        }));
+        Ok(decoded)
+    }
+}
+
+#[cfg(test)]
+mod tests {
+    use super::super::super::decoders::DataType;
+    use super::*;
+    use image::{DynamicImage, ImageBuffer};
+    use rstest::rstest;
+    use std::io::Cursor;
+
+    fn create_encoded_media_data(bytes: Vec<u8>) -> EncodedMediaData {
+        EncodedMediaData {
+            bytes,
+            b64_encoded: false,
+        }
+    }
+
+    fn create_test_image(
+        width: u32,
+        height: u32,
+        channels: u32,
+        format: image::ImageFormat,
+    ) -> Vec<u8> {
+        // Create dynamic image based on number of channels with constant values
+        let pixels = vec![128u8; channels as usize].repeat((width * height) as usize);
+        let dynamic_image = match channels {
+            1 => DynamicImage::ImageLuma8(
+                ImageBuffer::from_vec(width, height, pixels).expect("Failed to create image"),
+            ),
+            3 => DynamicImage::ImageRgb8(
+                ImageBuffer::from_vec(width, height, pixels).expect("Failed to create image"),
+            ),
+            4 => DynamicImage::ImageRgba8(
+                ImageBuffer::from_vec(width, height, pixels).expect("Failed to create image"),
+            ),
+            _ => unreachable!("Already validated channel count above"),
+        };
+
+        // Encode to bytes
+        let mut bytes = Vec::new();
+        dynamic_image
+            .write_to(&mut Cursor::new(&mut bytes), format)
+            .expect("Failed to encode test image");
+        bytes
+    }
+
+    #[rstest]
+    #[case(3, image::ImageFormat::Png, 10, 10, 3, "RGB PNG")]
+    #[case(4, image::ImageFormat::Png, 25, 30, 4, "RGBA PNG")]
+    #[case(1, image::ImageFormat::Png, 8, 12, 1, "Grayscale PNG")]
+    #[case(3, image::ImageFormat::Jpeg, 15, 20, 3, "RGB JPEG")]
+    #[case(3, image::ImageFormat::Bmp, 12, 18, 3, "RGB BMP")]
+    #[case(3, image::ImageFormat::WebP, 8, 8, 3, "RGB WebP")]
+    fn test_image_decode(
+        #[case] input_channels: u32,
+        #[case] format: image::ImageFormat,
+        #[case] width: u32,
+        #[case] height: u32,
+        #[case] expected_channels: u32,
+        #[case] description: &str,
+    ) {
+        let decoder = ImageDecoder::default();
+        let image_bytes = create_test_image(width, height, input_channels, format);
+        let encoded_data = create_encoded_media_data(image_bytes);
+
+        let result = decoder.decode(encoded_data);
+        assert!(result.is_ok(), "Failed to decode {}", description);
+
+        let decoded = result.unwrap();
+        assert_eq!(
+            decoded.shape,
+            vec![height as usize, width as usize, expected_channels as usize]
+        );
+        assert_eq!(decoded.dtype, DataType::UINT8);
+    }
+
+    #[rstest]
+    #[case(Some(100), None, 50, 50, ImageFormat::Png, true, "width ok")]
+    #[case(Some(50), None, 100, 50, ImageFormat::Jpeg, false, "width too large")]
+    #[case(None, Some(100), 50, 100, ImageFormat::Png, true, "height ok")]
+    #[case(None, Some(50), 50, 100, ImageFormat::Png, false, "height too large")]
+    #[case(None, None, 2000, 2000, ImageFormat::Png, true, "no limits")]
+    #[case(None, None, 8000, 8000, ImageFormat::Png, false, "alloc too large")]
+    fn test_limits(
+        #[case] max_width: Option<u32>,
+        #[case] max_height: Option<u32>,
+        #[case] width: u32,
+        #[case] height: u32,
+        #[case] format: image::ImageFormat,
+        #[case] should_succeed: bool,
+        #[case] test_case: &str,
+    ) {
+        let decoder = ImageDecoder {
+            max_image_width: max_width,
+            max_image_height: max_height,
+            max_alloc: Some(DEFAULT_MAX_ALLOC),
+        };
+        let image_bytes = create_test_image(width, height, 3, format); // RGB
+        let encoded_data = create_encoded_media_data(image_bytes);
+
+        let result = decoder.decode(encoded_data);
+
+        if should_succeed {
+            assert!(
+                result.is_ok(),
+                "Should decode successfully for case: {} with format {:?}",
+                test_case,
+                format
+            );
+            let decoded = result.unwrap();
+            assert_eq!(decoded.shape, vec![height as usize, width as usize, 3]);
+            assert_eq!(
+                decoded.dtype,
+                DataType::UINT8,
+                "dtype should be uint8 for case: {}",
+                test_case
+            );
+        } else {
+            assert!(
+                result.is_err(),
+                "Should fail for case: {} with format {:?}",
+                test_case,
+                format
+            );
+            let error_msg = result.unwrap_err().to_string();
+            assert!(
+                error_msg.contains("dimensions") || error_msg.contains("limit"),
+                "Error should mention dimension limits, got: {} for case: {}",
+                error_msg,
+                test_case
+            );
+        }
+    }
+
+    #[rstest]
+    #[case(3, image::ImageFormat::Png)]
+    fn test_decode_1x1_image(#[case] input_channels: u32, #[case] format: image::ImageFormat) {
+        let decoder = ImageDecoder::default();
+        let image_bytes = create_test_image(1, 1, input_channels, format);
+        let encoded_data = create_encoded_media_data(image_bytes);
+
+        let result = decoder.decode(encoded_data);
+        assert!(
+            result.is_ok(),
+            "Should decode 1x1 image with {} channels in {:?} format successfully",
+            input_channels,
+            format
+        );
+
+        let decoded = result.unwrap();
+        assert_eq!(decoded.shape.len(), 3, "Should have 3 dimensions");
+        assert_eq!(decoded.shape[0], 1, "Height should be 1");
+        assert_eq!(decoded.shape[1], 1, "Width should be 1");
+        assert_eq!(
+            decoded.dtype,
+            DataType::UINT8,
+            "dtype should be uint8 for {} channels {:?}",
+            input_channels,
+            format
+        );
+    }
+}

lib/llm/src/preprocessor/media/loader.rs

@@ -9,8 +9,10 @@ use anyhow::Result;
 use dynamo_async_openai::types::ChatCompletionRequestUserMessageContentPart;

 use super::common::EncodedMediaData;
+use super::decoders::{DecodedMediaData, Decoder, MediaDecoder};

 const DEFAULT_HTTP_USER_AGENT: &str = "dynamo-ai/dynamo";
+const DEFAULT_HTTP_TIMEOUT: Duration = Duration::from_secs(30);

 #[derive(Clone, Debug, serde::Serialize, serde::Deserialize)]
 pub struct MediaFetcher {
@@ -28,19 +30,20 @@ impl Default for MediaFetcher {
             allow_direct_ip: false,
             allow_direct_port: false,
             allowed_media_domains: None,
-            timeout: None,
+            timeout: Some(DEFAULT_HTTP_TIMEOUT),
         }
     }
 }

 pub struct MediaLoader {
+    media_decoder: MediaDecoder,
     http_client: reqwest::Client,
     media_fetcher: MediaFetcher,
-    // TODO: decoders, NIXL agent
+    // TODO: NIXL agent
 }

 impl MediaLoader {
-    pub fn new(media_fetcher: MediaFetcher) -> Result<Self> {
+    pub fn new(media_decoder: MediaDecoder, media_fetcher: MediaFetcher) -> Result<Self> {
         let mut http_client_builder =
             reqwest::Client::builder().user_agent(&media_fetcher.user_agent);

@@ -51,6 +54,7 @@ impl MediaLoader {
         let http_client = http_client_builder.build()?;

         Ok(Self {
+            media_decoder,
             http_client,
             media_fetcher,
         })
@@ -82,23 +86,25 @@ impl MediaLoader {
         Ok(())
     }

-    pub async fn fetch_media_part(
+    pub async fn fetch_and_decode_media_part(
         &self,
         oai_content_part: &ChatCompletionRequestUserMessageContentPart,
         // TODO: request-level options
-    ) -> Result<EncodedMediaData> {
+    ) -> Result<DecodedMediaData> {
         // fetch the media
         // TODO: decode and NIXL-register
-        let data = match oai_content_part {
+        let decoded = match oai_content_part {
             ChatCompletionRequestUserMessageContentPart::ImageUrl(image_part) => {
                 let url = &image_part.image_url.url;
                 self.check_if_url_allowed(url)?;
-                EncodedMediaData::from_url(url, &self.http_client).await?
+                let data = EncodedMediaData::from_url(url, &self.http_client).await?;
+                self.media_decoder.image_decoder.decode_async(data).await?
             }
             ChatCompletionRequestUserMessageContentPart::VideoUrl(video_part) => {
                 let url = &video_part.video_url.url;
                 self.check_if_url_allowed(url)?;
-                EncodedMediaData::from_url(url, &self.http_client).await?
+                EncodedMediaData::from_url(url, &self.http_client).await?;
+                anyhow::bail!("Video decoding is not supported yet");
             }
             ChatCompletionRequestUserMessageContentPart::AudioUrl(_) => {
                 anyhow::bail!("Audio decoding is not supported yet");
@@ -106,13 +112,63 @@ impl MediaLoader {
             _ => anyhow::bail!("Unsupported media type"),
         };

-        Ok(data)
+        Ok(decoded)
     }
 }

 #[cfg(test)]
 mod tests {
+    use super::super::decoders::DataType;
     use super::*;
+    use dynamo_async_openai::types::{ChatCompletionRequestMessageContentPartImage, ImageUrl};
+
+    #[tokio::test]
+    async fn test_fetch_and_decode() {
+        let test_image_bytes =
+            include_bytes!("../../../tests/data/media/llm-optimize-deploy-graphic.png");
+
+        let mut server = mockito::Server::new_async().await;
+        let mock = server
+            .mock("GET", "/llm-optimize-deploy-graphic.png")
+            .with_status(200)
+            .with_header("content-type", "image/png")
+            .with_body(&test_image_bytes[..])
+            .create_async()
+            .await;
+
+        let media_decoder = MediaDecoder::default();
+        let fetcher = MediaFetcher {
+            allow_direct_ip: true,
+            allow_direct_port: true,
+            ..Default::default()
+        };
+
+        let loader = MediaLoader::new(media_decoder, fetcher).unwrap();
+
+        let image_url = ImageUrl::from(format!("{}/llm-optimize-deploy-graphic.png", server.url()));
+        let content_part = ChatCompletionRequestUserMessageContentPart::ImageUrl(
+            ChatCompletionRequestMessageContentPartImage { image_url },
+        );
+
+        let result = loader.fetch_and_decode_media_part(&content_part).await;
+        assert!(
+            result.is_ok(),
+            "Failed to fetch and decode image: {:?}",
+            result.err()
+        );
+
+        let data = result.unwrap();
+        assert_eq!(data.dtype, DataType::UINT8);
+
+        // Verify image dimensions: 1,999px × 1,125px (width × height)
+        // Shape format is [height, width, channels]
+        assert_eq!(data.shape.len(), 3);
+        assert_eq!(data.shape[0], 1125, "Height should be 1125");
+        assert_eq!(data.shape[1], 1999, "Width should be 1999");
+        assert_eq!(data.shape[2], 4, "RGBA channels should be 4");
+
+        mock.assert_async().await;
+    }

     #[test]
     fn test_direct_ip_blocked() {
@@ -120,7 +176,7 @@ mod tests {
             allow_direct_ip: false,
             ..Default::default()
         };
-        let loader = MediaLoader::new(fetcher).unwrap();
+        let loader = MediaLoader::new(MediaDecoder::default(), fetcher).unwrap();

         let url = url::Url::parse("http://192.168.1.1/image.jpg").unwrap();
         let result = loader.check_if_url_allowed(&url);
@@ -140,7 +196,7 @@ mod tests {
             allow_direct_port: false,
             ..Default::default()
         };
-        let loader = MediaLoader::new(fetcher).unwrap();
+        let loader = MediaLoader::new(MediaDecoder::default(), fetcher).unwrap();

         let url = url::Url::parse("http://example.com:8080/image.jpg").unwrap();
         let result = loader.check_if_url_allowed(&url);
@@ -164,7 +220,7 @@ mod tests {
             allowed_media_domains: Some(allowed_domains),
             ..Default::default()
         };
-        let loader = MediaLoader::new(fetcher).unwrap();
+        let loader = MediaLoader::new(MediaDecoder::default(), fetcher).unwrap();

         // Allowed domain should pass
         let url = url::Url::parse("https://trusted.com/image.jpg").unwrap();

lib/llm/tests/data/media/.gitattributes

+llm-optimize-deploy-graphic.png filter=lfs diff=lfs merge=lfs -text
