fix conflicts

deploy/android_demo/app/proguard-rules.pro

+# Add project specific ProGuard rules here.
+# You can control the set of applied configuration files using the
+# proguardFiles setting in build.gradle.
+#
+# For more details, see
+#   http://developer.android.com/guide/developing/tools/proguard.html
+
+# If your project uses WebView with JS, uncomment the following
+# and specify the fully qualified class name to the JavaScript interface
+# class:
+#-keepclassmembers class fqcn.of.javascript.interface.for.webview {
+#   public *;
+#}
+
+# Uncomment this to preserve the line number information for
+# debugging stack traces.
+#-keepattributes SourceFile,LineNumberTable
+
+# If you keep the line number information, uncomment this to
+# hide the original source file name.
+#-renamesourcefileattribute SourceFile

deploy/android_demo/app/src/androidTest/java/com/baidu/paddle/lite/demo/ocr/ExampleInstrumentedTest.java

+package com.baidu.paddle.lite.demo.ocr;
+
+import android.content.Context;
+import android.support.test.InstrumentationRegistry;
+import android.support.test.runner.AndroidJUnit4;
+
+import org.junit.Test;
+import org.junit.runner.RunWith;
+
+import static org.junit.Assert.*;
+
+/**
+ * Instrumented test, which will execute on an Android device.
+ *
+ * @see <a href="http://d.android.com/tools/testing">Testing documentation</a>
+ */
+@RunWith(AndroidJUnit4.class)
+public class ExampleInstrumentedTest {
+    @Test
+    public void useAppContext() {
+        // Context of the app under test.
+        Context appContext = InstrumentationRegistry.getTargetContext();
+
+        assertEquals("com.baidu.paddle.lite.demo", appContext.getPackageName());
+    }
+}

deploy/android_demo/app/src/main/AndroidManifest.xml

+<?xml version="1.0" encoding="utf-8"?>
+<manifest xmlns:android="http://schemas.android.com/apk/res/android"
+          package="com.baidu.paddle.lite.demo.ocr">
+
+    <uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE"/>
+    <uses-permission android:name="android.permission.READ_EXTERNAL_STORAGE"/>
+    <uses-permission android:name="android.permission.CAMERA"/>
+
+
+    <application
+            android:allowBackup="true"
+            android:icon="@mipmap/ic_launcher"
+            android:label="@string/app_name"
+            android:roundIcon="@mipmap/ic_launcher_round"
+            android:supportsRtl="true"
+            android:theme="@style/AppTheme">
+        <!-- to test MiniActivity, change this to com.baidu.paddle.lite.demo.ocr.MiniActivity -->
+        <activity android:name="com.baidu.paddle.lite.demo.ocr.MainActivity">
+            <intent-filter>
+                <action android:name="android.intent.action.MAIN"/>
+                <category android:name="android.intent.category.LAUNCHER"/>
+            </intent-filter>
+        </activity>
+        <activity
+                android:name="com.baidu.paddle.lite.demo.ocr.SettingsActivity"
+                android:label="Settings">
+        </activity>
+        <provider
+            android:name="androidx.core.content.FileProvider"
+            android:authorities="com.baidu.paddle.lite.demo.ocr.fileprovider"
+            android:exported="false"
+            android:grantUriPermissions="true">
+            <meta-data
+                android:name="android.support.FILE_PROVIDER_PATHS"
+                android:resource="@xml/file_paths"></meta-data>
+        </provider>
+    </application>
+
+</manifest>
\ No newline at end of file

deploy/android_demo/app/src/main/cpp/CMakeLists.txt

+# For more information about using CMake with Android Studio, read the
+# documentation: https://d.android.com/studio/projects/add-native-code.html
+
+# Sets the minimum version of CMake required to build the native library.
+
+cmake_minimum_required(VERSION 3.4.1)
+
+# Creates and names a library, sets it as either STATIC or SHARED, and provides
+# the relative paths to its source code. You can define multiple libraries, and
+# CMake builds them for you. Gradle automatically packages shared libraries with
+# your APK.
+
+set(PaddleLite_DIR "${CMAKE_CURRENT_SOURCE_DIR}/../../../PaddleLite")
+include_directories(${PaddleLite_DIR}/cxx/include)
+
+set(OpenCV_DIR "${CMAKE_CURRENT_SOURCE_DIR}/../../../OpenCV/sdk/native/jni")
+message(STATUS "opencv dir: ${OpenCV_DIR}")
+find_package(OpenCV REQUIRED)
+message(STATUS "OpenCV libraries: ${OpenCV_LIBS}")
+include_directories(${OpenCV_INCLUDE_DIRS})
+aux_source_directory(. SOURCES)
+set(CMAKE_CXX_FLAGS
+        "${CMAKE_CXX_FLAGS} -ffast-math -Ofast -Os"
+        )
+set(CMAKE_CXX_FLAGS
+        "${CMAKE_CXX_FLAGS} -fvisibility=hidden -fvisibility-inlines-hidden -fdata-sections -ffunction-sections"
+        )
+set(CMAKE_SHARED_LINKER_FLAGS
+        "${CMAKE_SHARED_LINKER_FLAGS} -Wl,--gc-sections -Wl,-z,nocopyreloc")
+
+add_library(
+        # Sets the name of the library.
+        Native
+        # Sets the library as a shared library.
+        SHARED
+        # Provides a relative path to your source file(s).
+        ${SOURCES})
+
+find_library(
+        # Sets the name of the path variable.
+        log-lib
+        # Specifies the name of the NDK library that you want CMake to locate.
+        log)
+
+add_library(
+        # Sets the name of the library.
+        paddle_light_api_shared
+        # Sets the library as a shared library.
+        SHARED
+        # Provides a relative path to your source file(s).
+        IMPORTED)
+
+set_target_properties(
+        # Specifies the target library.
+        paddle_light_api_shared
+        # Specifies the parameter you want to define.
+        PROPERTIES
+        IMPORTED_LOCATION
+        ${PaddleLite_DIR}/cxx/libs/${ANDROID_ABI}/libpaddle_light_api_shared.so
+        # Provides the path to the library you want to import.
+)
+
+
+# Specifies libraries CMake should link to your target library. You can link
+# multiple libraries, such as libraries you define in this build script,
+# prebuilt third-party libraries, or system libraries.
+
+target_link_libraries(
+        # Specifies the target library.
+        Native
+        paddle_light_api_shared
+        ${OpenCV_LIBS}
+        GLESv2
+        EGL
+        jnigraphics
+        ${log-lib}
+)
+
+add_custom_command(
+        TARGET Native
+        POST_BUILD
+        COMMAND
+        ${CMAKE_COMMAND} -E copy
+        ${PaddleLite_DIR}/cxx/libs/${ANDROID_ABI}/libc++_shared.so
+        ${CMAKE_LIBRARY_OUTPUT_DIRECTORY}/libc++_shared.so)
+
+add_custom_command(
+        TARGET Native
+        POST_BUILD
+        COMMAND
+        ${CMAKE_COMMAND} -E copy
+        ${PaddleLite_DIR}/cxx/libs/${ANDROID_ABI}/libpaddle_light_api_shared.so
+        ${CMAKE_LIBRARY_OUTPUT_DIRECTORY}/libpaddle_light_api_shared.so)
+
+add_custom_command(
+        TARGET Native
+        POST_BUILD
+        COMMAND
+        ${CMAKE_COMMAND} -E copy
+        ${PaddleLite_DIR}/cxx/libs/${ANDROID_ABI}/libhiai.so
+        ${CMAKE_LIBRARY_OUTPUT_DIRECTORY}/libhiai.so)
+
+add_custom_command(
+        TARGET Native
+        POST_BUILD
+        COMMAND
+        ${CMAKE_COMMAND} -E copy
+        ${PaddleLite_DIR}/cxx/libs/${ANDROID_ABI}/libhiai_ir.so
+        ${CMAKE_LIBRARY_OUTPUT_DIRECTORY}/libhiai_ir.so)
+
+add_custom_command(
+        TARGET Native
+        POST_BUILD
+        COMMAND
+        ${CMAKE_COMMAND} -E copy
+        ${PaddleLite_DIR}/cxx/libs/${ANDROID_ABI}/libhiai_ir_build.so
+        ${CMAKE_LIBRARY_OUTPUT_DIRECTORY}/libhiai_ir_build.so)
\ No newline at end of file

deploy/android_demo/app/src/main/cpp/common.h

+//
+// Created by fu on 4/25/18.
+//
+
+#pragma once
+#import <numeric>
+#import <vector>
+
+#ifdef __ANDROID__
+
+#include <android/log.h>
+
+#define LOG_TAG "OCR_NDK"
+
+#define LOGI(...) __android_log_print(ANDROID_LOG_INFO, LOG_TAG, __VA_ARGS__)
+#define LOGW(...) __android_log_print(ANDROID_LOG_WARN, LOG_TAG, __VA_ARGS__)
+#define LOGE(...) __android_log_print(ANDROID_LOG_ERROR, LOG_TAG, __VA_ARGS__)
+#else
+#include <stdio.h>
+#define LOGI(format, ...)                                                      \
+  fprintf(stdout, "[" LOG_TAG "]" format "\n", ##__VA_ARGS__)
+#define LOGW(format, ...)                                                      \
+  fprintf(stdout, "[" LOG_TAG "]" format "\n", ##__VA_ARGS__)
+#define LOGE(format, ...)                                                      \
+  fprintf(stderr, "[" LOG_TAG "]Error: " format "\n", ##__VA_ARGS__)
+#endif
+
+enum RETURN_CODE { RETURN_OK = 0 };
+
+enum NET_TYPE { NET_OCR = 900100, NET_OCR_INTERNAL = 991008 };
+
+template <typename T> inline T product(const std::vector<T> &vec) {
+  if (vec.empty()) {
+    return 0;
+  }
+  return std::accumulate(vec.begin(), vec.end(), 1, std::multiplies<T>());
+}

deploy/android_demo/app/src/main/cpp/native.cpp

+//
+// Created by fujiayi on 2020/7/5.
+//
+
+#include "native.h"
+#include "ocr_ppredictor.h"
+#include <algorithm>
+#include <paddle_api.h>
+#include <string>
+
+static paddle::lite_api::PowerMode str_to_cpu_mode(const std::string &cpu_mode);
+
+extern "C" JNIEXPORT jlong JNICALL
+Java_com_baidu_paddle_lite_demo_ocr_OCRPredictorNative_init(
+    JNIEnv *env, jobject thiz, jstring j_det_model_path,
+    jstring j_rec_model_path, jstring j_cls_model_path, jint j_thread_num,
+    jstring j_cpu_mode) {
+  std::string det_model_path = jstring_to_cpp_string(env, j_det_model_path);
+  std::string rec_model_path = jstring_to_cpp_string(env, j_rec_model_path);
+  std::string cls_model_path = jstring_to_cpp_string(env, j_cls_model_path);
+  int thread_num = j_thread_num;
+  std::string cpu_mode = jstring_to_cpp_string(env, j_cpu_mode);
+  ppredictor::OCR_Config conf;
+  conf.thread_num = thread_num;
+  conf.mode = str_to_cpu_mode(cpu_mode);
+  ppredictor::OCR_PPredictor *orc_predictor =
+      new ppredictor::OCR_PPredictor{conf};
+  orc_predictor->init_from_file(det_model_path, rec_model_path, cls_model_path);
+  return reinterpret_cast<jlong>(orc_predictor);
+}
+
+/**
+ * "LITE_POWER_HIGH" convert to paddle::lite_api::LITE_POWER_HIGH
+ * @param cpu_mode
+ * @return
+ */
+static paddle::lite_api::PowerMode
+str_to_cpu_mode(const std::string &cpu_mode) {
+  static std::map<std::string, paddle::lite_api::PowerMode> cpu_mode_map{
+      {"LITE_POWER_HIGH", paddle::lite_api::LITE_POWER_HIGH},
+      {"LITE_POWER_LOW", paddle::lite_api::LITE_POWER_HIGH},
+      {"LITE_POWER_FULL", paddle::lite_api::LITE_POWER_FULL},
+      {"LITE_POWER_NO_BIND", paddle::lite_api::LITE_POWER_NO_BIND},
+      {"LITE_POWER_RAND_HIGH", paddle::lite_api::LITE_POWER_RAND_HIGH},
+      {"LITE_POWER_RAND_LOW", paddle::lite_api::LITE_POWER_RAND_LOW}};
+  std::string upper_key;
+  std::transform(cpu_mode.cbegin(), cpu_mode.cend(), upper_key.begin(),
+                 ::toupper);
+  auto index = cpu_mode_map.find(upper_key);
+  if (index == cpu_mode_map.end()) {
+    LOGE("cpu_mode not found %s", upper_key.c_str());
+    return paddle::lite_api::LITE_POWER_HIGH;
+  } else {
+    return index->second;
+  }
+}
+
+extern "C" JNIEXPORT jfloatArray JNICALL
+Java_com_baidu_paddle_lite_demo_ocr_OCRPredictorNative_forward(
+    JNIEnv *env, jobject thiz, jlong java_pointer, jfloatArray buf,
+    jfloatArray ddims, jobject original_image) {
+  LOGI("begin to run native forward");
+  if (java_pointer == 0) {
+    LOGE("JAVA pointer is NULL");
+    return cpp_array_to_jfloatarray(env, nullptr, 0);
+  }
+  cv::Mat origin = bitmap_to_cv_mat(env, original_image);
+  if (origin.size == 0) {
+    LOGE("origin bitmap cannot convert to CV Mat");
+    return cpp_array_to_jfloatarray(env, nullptr, 0);
+  }
+  ppredictor::OCR_PPredictor *ppredictor =
+      (ppredictor::OCR_PPredictor *)java_pointer;
+  std::vector<float> dims_float_arr = jfloatarray_to_float_vector(env, ddims);
+  std::vector<int64_t> dims_arr;
+  dims_arr.resize(dims_float_arr.size());
+  std::copy(dims_float_arr.cbegin(), dims_float_arr.cend(), dims_arr.begin());
+
+  // 这里值有点大，就不调用jfloatarray_to_float_vector了
+  int64_t buf_len = (int64_t)env->GetArrayLength(buf);
+  jfloat *buf_data = env->GetFloatArrayElements(buf, JNI_FALSE);
+  float *data = (jfloat *)buf_data;
+  std::vector<ppredictor::OCRPredictResult> results =
+      ppredictor->infer_ocr(dims_arr, data, buf_len, NET_OCR, origin);
+  LOGI("infer_ocr finished with boxes %ld", results.size());
+  // 这里将std::vector<ppredictor::OCRPredictResult> 序列化成
+  // float数组，传输到java层再反序列化
+  std::vector<float> float_arr;
+  for (const ppredictor::OCRPredictResult &r : results) {
+    float_arr.push_back(r.points.size());
+    float_arr.push_back(r.word_index.size());
+    float_arr.push_back(r.score);
+    for (const std::vector<int> &point : r.points) {
+      float_arr.push_back(point.at(0));
+      float_arr.push_back(point.at(1));
+    }
+    for (int index : r.word_index) {
+      float_arr.push_back(index);
+    }
+  }
+  return cpp_array_to_jfloatarray(env, float_arr.data(), float_arr.size());
+}
+
+extern "C" JNIEXPORT void JNICALL
+Java_com_baidu_paddle_lite_demo_ocr_OCRPredictorNative_release(
+    JNIEnv *env, jobject thiz, jlong java_pointer) {
+  if (java_pointer == 0) {
+    LOGE("JAVA pointer is NULL");
+    return;
+  }
+  ppredictor::OCR_PPredictor *ppredictor =
+      (ppredictor::OCR_PPredictor *)java_pointer;
+  delete ppredictor;
+}
\ No newline at end of file

deploy/android_demo/app/src/main/cpp/native.h

+//
+// Created by fujiayi on 2020/7/5.
+//
+
+#pragma once
+
+#include "common.h"
+#include <android/bitmap.h>
+#include <jni.h>
+#include <opencv2/opencv.hpp>
+#include <string>
+#include <vector>
+
+inline std::string jstring_to_cpp_string(JNIEnv *env, jstring jstr) {
+  // In java, a unicode char will be encoded using 2 bytes (utf16).
+  // so jstring will contain characters utf16. std::string in c++ is
+  // essentially a string of bytes, not characters, so if we want to
+  // pass jstring from JNI to c++, we have convert utf16 to bytes.
+  if (!jstr) {
+    return "";
+  }
+  const jclass stringClass = env->GetObjectClass(jstr);
+  const jmethodID getBytes =
+      env->GetMethodID(stringClass, "getBytes", "(Ljava/lang/String;)[B");
+  const jbyteArray stringJbytes = (jbyteArray)env->CallObjectMethod(
+      jstr, getBytes, env->NewStringUTF("UTF-8"));
+
+  size_t length = (size_t)env->GetArrayLength(stringJbytes);
+  jbyte *pBytes = env->GetByteArrayElements(stringJbytes, NULL);
+
+  std::string ret = std::string(reinterpret_cast<char *>(pBytes), length);
+  env->ReleaseByteArrayElements(stringJbytes, pBytes, JNI_ABORT);
+
+  env->DeleteLocalRef(stringJbytes);
+  env->DeleteLocalRef(stringClass);
+  return ret;
+}
+
+inline jstring cpp_string_to_jstring(JNIEnv *env, std::string str) {
+  auto *data = str.c_str();
+  jclass strClass = env->FindClass("java/lang/String");
+  jmethodID strClassInitMethodID =
+      env->GetMethodID(strClass, "<init>", "([BLjava/lang/String;)V");
+
+  jbyteArray bytes = env->NewByteArray(strlen(data));
+  env->SetByteArrayRegion(bytes, 0, strlen(data),
+                          reinterpret_cast<const jbyte *>(data));
+
+  jstring encoding = env->NewStringUTF("UTF-8");
+  jstring res = (jstring)(
+      env->NewObject(strClass, strClassInitMethodID, bytes, encoding));
+
+  env->DeleteLocalRef(strClass);
+  env->DeleteLocalRef(encoding);
+  env->DeleteLocalRef(bytes);
+
+  return res;
+}
+
+inline jfloatArray cpp_array_to_jfloatarray(JNIEnv *env, const float *buf,
+                                            int64_t len) {
+  if (len == 0) {
+    return env->NewFloatArray(0);
+  }
+  jfloatArray result = env->NewFloatArray(len);
+  env->SetFloatArrayRegion(result, 0, len, buf);
+  return result;
+}
+
+inline jintArray cpp_array_to_jintarray(JNIEnv *env, const int *buf,
+                                        int64_t len) {
+  jintArray result = env->NewIntArray(len);
+  env->SetIntArrayRegion(result, 0, len, buf);
+  return result;
+}
+
+inline jbyteArray cpp_array_to_jbytearray(JNIEnv *env, const int8_t *buf,
+                                          int64_t len) {
+  jbyteArray result = env->NewByteArray(len);
+  env->SetByteArrayRegion(result, 0, len, buf);
+  return result;
+}
+
+inline jlongArray int64_vector_to_jlongarray(JNIEnv *env,
+                                             const std::vector<int64_t> &vec) {
+  jlongArray result = env->NewLongArray(vec.size());
+  jlong *buf = new jlong[vec.size()];
+  for (size_t i = 0; i < vec.size(); ++i) {
+    buf[i] = (jlong)vec[i];
+  }
+  env->SetLongArrayRegion(result, 0, vec.size(), buf);
+  delete[] buf;
+  return result;
+}
+
+inline std::vector<int64_t> jlongarray_to_int64_vector(JNIEnv *env,
+                                                       jlongArray data) {
+  int data_size = env->GetArrayLength(data);
+  jlong *data_ptr = env->GetLongArrayElements(data, nullptr);
+  std::vector<int64_t> data_vec(data_ptr, data_ptr + data_size);
+  env->ReleaseLongArrayElements(data, data_ptr, 0);
+  return data_vec;
+}
+
+inline std::vector<float> jfloatarray_to_float_vector(JNIEnv *env,
+                                                      jfloatArray data) {
+  int data_size = env->GetArrayLength(data);
+  jfloat *data_ptr = env->GetFloatArrayElements(data, nullptr);
+  std::vector<float> data_vec(data_ptr, data_ptr + data_size);
+  env->ReleaseFloatArrayElements(data, data_ptr, 0);
+  return data_vec;
+}
+
+inline cv::Mat bitmap_to_cv_mat(JNIEnv *env, jobject bitmap) {
+  AndroidBitmapInfo info;
+  int result = AndroidBitmap_getInfo(env, bitmap, &info);
+  if (result != ANDROID_BITMAP_RESULT_SUCCESS) {
+    LOGE("AndroidBitmap_getInfo failed, result: %d", result);
+    return cv::Mat{};
+  }
+  if (info.format != ANDROID_BITMAP_FORMAT_RGBA_8888) {
+    LOGE("Bitmap format is not RGBA_8888 !");
+    return cv::Mat{};
+  }
+  unsigned char *srcData = NULL;
+  AndroidBitmap_lockPixels(env, bitmap, (void **)&srcData);
+  cv::Mat mat = cv::Mat::zeros(info.height, info.width, CV_8UC4);
+  memcpy(mat.data, srcData, info.height * info.width * 4);
+  AndroidBitmap_unlockPixels(env, bitmap);
+  cv::cvtColor(mat, mat, cv::COLOR_RGBA2BGR);
+  /**
+  if (!cv::imwrite("/sdcard/1/copy.jpg", mat)){
+      LOGE("Write image failed " );
+  }
+   */
+  return mat;
+}

deploy/android_demo/app/src/main/cpp/ocr_clipper.hpp

+/*******************************************************************************
+*                                                                              *
+* Author    :  Angus Johnson                                                   *
+* Version   :  6.4.2                                                           *
+* Date      :  27 February 2017                                                *
+* Website   :  http://www.angusj.com                                           *
+* Copyright :  Angus Johnson 2010-2017                                         *
+*                                                                              *
+* License:                                                                     *
+* Use, modification & distribution is subject to Boost Software License Ver 1. *
+* http://www.boost.org/LICENSE_1_0.txt                                         *
+*                                                                              *
+* Attributions:                                                                *
+* The code in this library is an extension of Bala Vatti's clipping algorithm: *
+* "A generic solution to polygon clipping"                                     *
+* Communications of the ACM, Vol 35, Issue 7 (July 1992) pp 56-63.             *
+* http://portal.acm.org/citation.cfm?id=129906                                 *
+*                                                                              *
+* Computer graphics and geometric modeling: implementation and algorithms      *
+* By Max K. Agoston                                                            *
+* Springer; 1 edition (January 4, 2005)                                        *
+* http://books.google.com/books?q=vatti+clipping+agoston                       *
+*                                                                              *
+* See also:                                                                    *
+* "Polygon Offsetting by Computing Winding Numbers"                            *
+* Paper no. DETC2005-85513 pp. 565-575                                         *
+* ASME 2005 International Design Engineering Technical Conferences             *
+* and Computers and Information in Engineering Conference (IDETC/CIE2005)      *
+* September 24-28, 2005 , Long Beach, California, USA                          *
+* http://www.me.berkeley.edu/~mcmains/pubs/DAC05OffsetPolygon.pdf              *
+*                                                                              *
+*******************************************************************************/
+
+#ifndef clipper_hpp
+#define clipper_hpp
+
+#define CLIPPER_VERSION "6.4.2"
+
+// use_int32: When enabled 32bit ints are used instead of 64bit ints. This
+// improve performance but coordinate values are limited to the range +/- 46340
+//#define use_int32
+
+// use_xyz: adds a Z member to IntPoint. Adds a minor cost to perfomance.
+//#define use_xyz
+
+// use_lines: Enables line clipping. Adds a very minor cost to performance.
+#define use_lines
+
+// use_deprecated: Enables temporary support for the obsolete functions
+//#define use_deprecated
+
+#include <cstdlib>
+#include <cstring>
+#include <functional>
+#include <list>
+#include <ostream>
+#include <queue>
+#include <set>
+#include <stdexcept>
+#include <vector>
+
+namespace ClipperLib {
+
+enum ClipType { ctIntersection, ctUnion, ctDifference, ctXor };
+enum PolyType { ptSubject, ptClip };
+// By far the most widely used winding rules for polygon filling are
+// EvenOdd & NonZero (GDI, GDI+, XLib, OpenGL, Cairo, AGG, Quartz, SVG, Gr32)
+// Others rules include Positive, Negative and ABS_GTR_EQ_TWO (only in OpenGL)
+// see http://glprogramming.com/red/chapter11.html
+enum PolyFillType { pftEvenOdd, pftNonZero, pftPositive, pftNegative };
+
+#ifdef use_int32
+typedef int cInt;
+static cInt const loRange = 0x7FFF;
+static cInt const hiRange = 0x7FFF;
+#else
+typedef signed long long cInt;
+static cInt const loRange = 0x3FFFFFFF;
+static cInt const hiRange = 0x3FFFFFFFFFFFFFFFLL;
+typedef signed long long long64; // used by Int128 class
+typedef unsigned long long ulong64;
+
+#endif
+
+struct IntPoint {
+  cInt X;
+  cInt Y;
+#ifdef use_xyz
+  cInt Z;
+  IntPoint(cInt x = 0, cInt y = 0, cInt z = 0) : X(x), Y(y), Z(z){};
+#else
+
+  IntPoint(cInt x = 0, cInt y = 0) : X(x), Y(y){};
+#endif
+
+  friend inline bool operator==(const IntPoint &a, const IntPoint &b) {
+    return a.X == b.X && a.Y == b.Y;
+  }
+
+  friend inline bool operator!=(const IntPoint &a, const IntPoint &b) {
+    return a.X != b.X || a.Y != b.Y;
+  }
+};
+//------------------------------------------------------------------------------
+
+typedef std::vector<IntPoint> Path;
+typedef std::vector<Path> Paths;
+
+inline Path &operator<<(Path &poly, const IntPoint &p) {
+  poly.push_back(p);
+  return poly;
+}
+
+inline Paths &operator<<(Paths &polys, const Path &p) {
+  polys.push_back(p);
+  return polys;
+}
+
+std::ostream &operator<<(std::ostream &s, const IntPoint &p);
+
+std::ostream &operator<<(std::ostream &s, const Path &p);
+
+std::ostream &operator<<(std::ostream &s, const Paths &p);
+
+struct DoublePoint {
+  double X;
+  double Y;
+
+  DoublePoint(double x = 0, double y = 0) : X(x), Y(y) {}
+
+  DoublePoint(IntPoint ip) : X((double)ip.X), Y((double)ip.Y) {}
+};
+//------------------------------------------------------------------------------
+
+#ifdef use_xyz
+typedef void (*ZFillCallback)(IntPoint &e1bot, IntPoint &e1top, IntPoint &e2bot,
+                              IntPoint &e2top, IntPoint &pt);
+#endif
+
+enum InitOptions {
+  ioReverseSolution = 1,
+  ioStrictlySimple = 2,
+  ioPreserveCollinear = 4
+};
+enum JoinType { jtSquare, jtRound, jtMiter };
+enum EndType {
+  etClosedPolygon,
+  etClosedLine,
+  etOpenButt,
+  etOpenSquare,
+  etOpenRound
+};
+
+class PolyNode;
+
+typedef std::vector<PolyNode *> PolyNodes;
+
+class PolyNode {
+public:
+  PolyNode();
+
+  virtual ~PolyNode(){};
+  Path Contour;
+  PolyNodes Childs;
+  PolyNode *Parent;
+
+  PolyNode *GetNext() const;
+
+  bool IsHole() const;
+
+  bool IsOpen() const;
+
+  int ChildCount() const;
+
+private:
+  // PolyNode& operator =(PolyNode& other);
+  unsigned Index; // node index in Parent.Childs
+  bool m_IsOpen;
+  JoinType m_jointype;
+  EndType m_endtype;
+
+  PolyNode *GetNextSiblingUp() const;
+
+  void AddChild(PolyNode &child);
+
+  friend class Clipper; // to access Index
+  friend class ClipperOffset;
+};
+
+class PolyTree : public PolyNode {
+public:
+  ~PolyTree() { Clear(); };
+
+  PolyNode *GetFirst() const;
+
+  void Clear();
+
+  int Total() const;
+
+private:
+  // PolyTree& operator =(PolyTree& other);
+  PolyNodes AllNodes;
+
+  friend class Clipper; // to access AllNodes
+};
+
+bool Orientation(const Path &poly);
+
+double Area(const Path &poly);
+
+int PointInPolygon(const IntPoint &pt, const Path &path);
+
+void SimplifyPolygon(const Path &in_poly, Paths &out_polys,
+                     PolyFillType fillType = pftEvenOdd);
+
+void SimplifyPolygons(const Paths &in_polys, Paths &out_polys,
+                      PolyFillType fillType = pftEvenOdd);
+
+void SimplifyPolygons(Paths &polys, PolyFillType fillType = pftEvenOdd);
+
+void CleanPolygon(const Path &in_poly, Path &out_poly, double distance = 1.415);
+
+void CleanPolygon(Path &poly, double distance = 1.415);
+
+void CleanPolygons(const Paths &in_polys, Paths &out_polys,
+                   double distance = 1.415);
+
+void CleanPolygons(Paths &polys, double distance = 1.415);
+
+void MinkowskiSum(const Path &pattern, const Path &path, Paths &solution,
+                  bool pathIsClosed);
+
+void MinkowskiSum(const Path &pattern, const Paths &paths, Paths &solution,
+                  bool pathIsClosed);
+
+void MinkowskiDiff(const Path &poly1, const Path &poly2, Paths &solution);
+
+void PolyTreeToPaths(const PolyTree &polytree, Paths &paths);
+
+void ClosedPathsFromPolyTree(const PolyTree &polytree, Paths &paths);
+
+void OpenPathsFromPolyTree(PolyTree &polytree, Paths &paths);
+
+void ReversePath(Path &p);
+
+void ReversePaths(Paths &p);
+
+struct IntRect {
+  cInt left;
+  cInt top;
+  cInt right;
+  cInt bottom;
+};
+
+// enums that are used internally ...
+enum EdgeSide { esLeft = 1, esRight = 2 };
+
+// forward declarations (for stuff used internally) ...
+struct TEdge;
+struct IntersectNode;
+struct LocalMinimum;
+struct OutPt;
+struct OutRec;
+struct Join;
+
+typedef std::vector<OutRec *> PolyOutList;
+typedef std::vector<TEdge *> EdgeList;
+typedef std::vector<Join *> JoinList;
+typedef std::vector<IntersectNode *> IntersectList;
+
+//------------------------------------------------------------------------------
+
+// ClipperBase is the ancestor to the Clipper class. It should not be
+// instantiated directly. This class simply abstracts the conversion of sets of
+// polygon coordinates into edge objects that are stored in a LocalMinima list.
+class ClipperBase {
+public:
+  ClipperBase();
+
+  virtual ~ClipperBase();
+
+  virtual bool AddPath(const Path &pg, PolyType PolyTyp, bool Closed);
+
+  bool AddPaths(const Paths &ppg, PolyType PolyTyp, bool Closed);
+
+  virtual void Clear();
+
+  IntRect GetBounds();
+
+  bool PreserveCollinear() { return m_PreserveCollinear; };
+
+  void PreserveCollinear(bool value) { m_PreserveCollinear = value; };
+
+protected:
+  void DisposeLocalMinimaList();
+
+  TEdge *AddBoundsToLML(TEdge *e, bool IsClosed);
+
+  virtual void Reset();
+
+  TEdge *ProcessBound(TEdge *E, bool IsClockwise);
+
+  void InsertScanbeam(const cInt Y);
+
+  bool PopScanbeam(cInt &Y);
+
+  bool LocalMinimaPending();
+
+  bool PopLocalMinima(cInt Y, const LocalMinimum *&locMin);
+
+  OutRec *CreateOutRec();
+
+  void DisposeAllOutRecs();
+
+  void DisposeOutRec(PolyOutList::size_type index);
+
+  void SwapPositionsInAEL(TEdge *edge1, TEdge *edge2);
+
+  void DeleteFromAEL(TEdge *e);
+
+  void UpdateEdgeIntoAEL(TEdge *&e);
+
+  typedef std::vector<LocalMinimum> MinimaList;
+  MinimaList::iterator m_CurrentLM;
+  MinimaList m_MinimaList;
+
+  bool m_UseFullRange;
+  EdgeList m_edges;
+  bool m_PreserveCollinear;
+  bool m_HasOpenPaths;
+  PolyOutList m_PolyOuts;
+  TEdge *m_ActiveEdges;
+
+  typedef std::priority_queue<cInt> ScanbeamList;
+  ScanbeamList m_Scanbeam;
+};
+//------------------------------------------------------------------------------
+
+class Clipper : public virtual ClipperBase {
+public:
+  Clipper(int initOptions = 0);
+
+  bool Execute(ClipType clipType, Paths &solution,
+               PolyFillType fillType = pftEvenOdd);
+
+  bool Execute(ClipType clipType, Paths &solution, PolyFillType subjFillType,
+               PolyFillType clipFillType);
+
+  bool Execute(ClipType clipType, PolyTree &polytree,
+               PolyFillType fillType = pftEvenOdd);
+
+  bool Execute(ClipType clipType, PolyTree &polytree, PolyFillType subjFillType,
+               PolyFillType clipFillType);
+
+  bool ReverseSolution() { return m_ReverseOutput; };
+
+  void ReverseSolution(bool value) { m_ReverseOutput = value; };
+
+  bool StrictlySimple() { return m_StrictSimple; };
+
+  void StrictlySimple(bool value) { m_StrictSimple = value; };
+// set the callback function for z value filling on intersections (otherwise Z
+// is 0)
+#ifdef use_xyz
+  void ZFillFunction(ZFillCallback zFillFunc);
+#endif
+protected:
+  virtual bool ExecuteInternal();
+
+private:
+  JoinList m_Joins;
+  JoinList m_GhostJoins;
+  IntersectList m_IntersectList;
+  ClipType m_ClipType;
+  typedef std::list<cInt> MaximaList;
+  MaximaList m_Maxima;
+  TEdge *m_SortedEdges;
+  bool m_ExecuteLocked;
+  PolyFillType m_ClipFillType;
+  PolyFillType m_SubjFillType;
+  bool m_ReverseOutput;
+  bool m_UsingPolyTree;
+  bool m_StrictSimple;
+#ifdef use_xyz
+  ZFillCallback m_ZFill; // custom callback
+#endif
+
+  void SetWindingCount(TEdge &edge);
+
+  bool IsEvenOddFillType(const TEdge &edge) const;
+
+  bool IsEvenOddAltFillType(const TEdge &edge) const;
+
+  void InsertLocalMinimaIntoAEL(const cInt botY);
+
+  void InsertEdgeIntoAEL(TEdge *edge, TEdge *startEdge);
+
+  void AddEdgeToSEL(TEdge *edge);
+
+  bool PopEdgeFromSEL(TEdge *&edge);
+
+  void CopyAELToSEL();
+
+  void DeleteFromSEL(TEdge *e);
+
+  void SwapPositionsInSEL(TEdge *edge1, TEdge *edge2);
+
+  bool IsContributing(const TEdge &edge) const;
+
+  bool IsTopHorz(const cInt XPos);
+
+  void DoMaxima(TEdge *e);
+
+  void ProcessHorizontals();
+
+  void ProcessHorizontal(TEdge *horzEdge);
+
+  void AddLocalMaxPoly(TEdge *e1, TEdge *e2, const IntPoint &pt);
+
+  OutPt *AddLocalMinPoly(TEdge *e1, TEdge *e2, const IntPoint &pt);
+
+  OutRec *GetOutRec(int idx);
+
+  void AppendPolygon(TEdge *e1, TEdge *e2);
+
+  void IntersectEdges(TEdge *e1, TEdge *e2, IntPoint &pt);
+
+  OutPt *AddOutPt(TEdge *e, const IntPoint &pt);
+
+  OutPt *GetLastOutPt(TEdge *e);
+
+  bool ProcessIntersections(const cInt topY);
+
+  void BuildIntersectList(const cInt topY);
+
+  void ProcessIntersectList();
+
+  void ProcessEdgesAtTopOfScanbeam(const cInt topY);
+
+  void BuildResult(Paths &polys);
+
+  void BuildResult2(PolyTree &polytree);
+
+  void SetHoleState(TEdge *e, OutRec *outrec);
+
+  void DisposeIntersectNodes();
+
+  bool FixupIntersectionOrder();
+
+  void FixupOutPolygon(OutRec &outrec);
+
+  void FixupOutPolyline(OutRec &outrec);
+
+  bool IsHole(TEdge *e);
+
+  bool FindOwnerFromSplitRecs(OutRec &outRec, OutRec *&currOrfl);
+
+  void FixHoleLinkage(OutRec &outrec);
+
+  void AddJoin(OutPt *op1, OutPt *op2, const IntPoint offPt);
+
+  void ClearJoins();
+
+  void ClearGhostJoins();
+
+  void AddGhostJoin(OutPt *op, const IntPoint offPt);
+
+  bool JoinPoints(Join *j, OutRec *outRec1, OutRec *outRec2);
+
+  void JoinCommonEdges();
+
+  void DoSimplePolygons();
+
+  void FixupFirstLefts1(OutRec *OldOutRec, OutRec *NewOutRec);
+
+  void FixupFirstLefts2(OutRec *InnerOutRec, OutRec *OuterOutRec);
+
+  void FixupFirstLefts3(OutRec *OldOutRec, OutRec *NewOutRec);
+
+#ifdef use_xyz
+  void SetZ(IntPoint &pt, TEdge &e1, TEdge &e2);
+#endif
+};
+//------------------------------------------------------------------------------
+
+class ClipperOffset {
+public:
+  ClipperOffset(double miterLimit = 2.0, double roundPrecision = 0.25);
+
+  ~ClipperOffset();
+
+  void AddPath(const Path &path, JoinType joinType, EndType endType);
+
+  void AddPaths(const Paths &paths, JoinType joinType, EndType endType);
+
+  void Execute(Paths &solution, double delta);
+
+  void Execute(PolyTree &solution, double delta);
+
+  void Clear();
+
+  double MiterLimit;
+  double ArcTolerance;
+
+private:
+  Paths m_destPolys;
+  Path m_srcPoly;
+  Path m_destPoly;
+  std::vector<DoublePoint> m_normals;
+  double m_delta, m_sinA, m_sin, m_cos;
+  double m_miterLim, m_StepsPerRad;
+  IntPoint m_lowest;
+  PolyNode m_polyNodes;
+
+  void FixOrientations();
+
+  void DoOffset(double delta);
+
+  void OffsetPoint(int j, int &k, JoinType jointype);
+
+  void DoSquare(int j, int k);
+
+  void DoMiter(int j, int k, double r);
+
+  void DoRound(int j, int k);
+};
+//------------------------------------------------------------------------------
+
+class clipperException : public std::exception {
+public:
+  clipperException(const char *description) : m_descr(description) {}
+
+  virtual ~clipperException() throw() {}
+
+  virtual const char *what() const throw() { return m_descr.c_str(); }
+
+private:
+  std::string m_descr;
+};
+//------------------------------------------------------------------------------
+
+} // ClipperLib namespace
+
+#endif // clipper_hpp

deploy/cpp_infer/src/config.cpp → deploy/android_demo/app/src/main/cpp/ocr_cls_process.cpp

@@ -12,53 +12,35 @@
 // See the License for the specific language governing permissions and
 // limitations under the License.

-#include <include/config.h>
-
-namespace PaddleOCR {
-
-std::vector<std::string> OCRConfig::split(const std::string &str,
-                                          const std::string &delim) {
-  std::vector<std::string> res;
-  if ("" == str)
-    return res;
-  char *strs = new char[str.length() + 1];
-  std::strcpy(strs, str.c_str());
-
-  char *d = new char[delim.length() + 1];
-  std::strcpy(d, delim.c_str());
-
-  char *p = std::strtok(strs, d);
-  while (p) {
-    std::string s = p;
-    res.push_back(s);
-    p = std::strtok(NULL, d);
-  }
-
-  return res;
-}
-
-std::map<std::string, std::string>
-OCRConfig::LoadConfig(const std::string &config_path) {
-  auto config = Utility::ReadDict(config_path);
-
-  std::map<std::string, std::string> dict;
-  for (int i = 0; i < config.size(); i++) {
-    // pass for empty line or comment
-    if (config[i].size() <= 1 || config[i][0] == '#') {
-      continue;
+#include "ocr_cls_process.h"
+#include <cmath>
+#include <cstring>
+#include <fstream>
+#include <iostream>
+#include <iostream>
+#include <vector>
+
+const std::vector<int> CLS_IMAGE_SHAPE = {3, 48, 192};
+
+cv::Mat cls_resize_img(const cv::Mat &img) {
+  int imgC = CLS_IMAGE_SHAPE[0];
+  int imgW = CLS_IMAGE_SHAPE[2];
+  int imgH = CLS_IMAGE_SHAPE[1];
+
+  float ratio = float(img.cols) / float(img.rows);
+  int resize_w = 0;
+  if (ceilf(imgH * ratio) > imgW)
+    resize_w = imgW;
+  else
+    resize_w = int(ceilf(imgH * ratio));
+
+  cv::Mat resize_img;
+  cv::resize(img, resize_img, cv::Size(resize_w, imgH), 0.f, 0.f,
+             cv::INTER_CUBIC);
+
+  if (resize_w < imgW) {
+    cv::copyMakeBorder(resize_img, resize_img, 0, 0, 0, int(imgW - resize_w),
+                       cv::BORDER_CONSTANT, {0, 0, 0});
   }
-    std::vector<std::string> res = split(config[i], " ");
-    dict[res[0]] = res[1];
-  }
-  return dict;
+  return resize_img;
 }
\ No newline at end of file
-
-void OCRConfig::PrintConfigInfo() {
-  std::cout << "=======Paddle OCR inference config======" << std::endl;
-  for (auto iter = config_map_.begin(); iter != config_map_.end(); iter++) {
-    std::cout << iter->first << " : " << iter->second << std::endl;
-  }
-  std::cout << "=======End of Paddle OCR inference config======" << std::endl;
-}
-
-} // namespace PaddleOCR
\ No newline at end of file

deploy/android_demo/app/src/main/cpp/ocr_cls_process.h

+// Copyright (c) 2020 PaddlePaddle Authors. All Rights Reserved.
+//
+// Licensed under the Apache License, Version 2.0 (the "License");
+// you may not use this file except in compliance with the License.
+// You may obtain a copy of the License at
+//
+//     http://www.apache.org/licenses/LICENSE-2.0
+//
+// Unless required by applicable law or agreed to in writing, software
+// distributed under the License is distributed on an "AS IS" BASIS,
+// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+// See the License for the specific language governing permissions and
+// limitations under the License.
+
+#pragma once
+
+#include "common.h"
+#include <opencv2/opencv.hpp>
+#include <vector>
+
+extern const std::vector<int> CLS_IMAGE_SHAPE;
+
+cv::Mat cls_resize_img(const cv::Mat &img);
\ No newline at end of file

deploy/android_demo/app/src/main/cpp/ocr_db_post_process.h

+//
+// Created by fujiayi on 2020/7/2.
+//
+#pragma once
+#include <opencv2/opencv.hpp>
+#include <vector>
+
+std::vector<std::vector<std::vector<int>>>
+boxes_from_bitmap(const cv::Mat &pred, const cv::Mat &bitmap);
+
+std::vector<std::vector<std::vector<int>>>
+filter_tag_det_res(const std::vector<std::vector<std::vector<int>>> &o_boxes,
+                   float ratio_h, float ratio_w, const cv::Mat &srcimg);
\ No newline at end of file
