Initial commit

examples/run_simple_mcore_train_loop.py

+import os
+import torch
+from torch.optim import Adam
+from torch.utils.data import DataLoader
+from functools import partial
+from pathlib import Path
+
+from megatron.core import parallel_state
+from megatron.core import dist_checkpointing
+from megatron.core.pipeline_parallel.schedules import get_forward_backward_func
+from megatron.core.tensor_parallel.random import model_parallel_cuda_manual_seed
+from megatron.core.transformer.transformer_config import TransformerConfig
+from megatron.core.models.gpt.gpt_model import GPTModel
+from megatron.core.models.gpt.gpt_layer_specs import get_gpt_layer_local_spec
+from megatron.core.datasets.utils import compile_helpers
+from megatron.core.datasets.blended_megatron_dataset_builder import BlendedMegatronDatasetBuilder
+from megatron.core.datasets.gpt_dataset import GPTDatasetConfig, MockGPTDataset
+from megatron.training.tokenizer.tokenizer import _NullTokenizer
+
+
+_SEQUENCE_LENGTH = 64
+
+
+def initialize_distributed(tensor_model_parallel_size=1, pipeline_model_parallel_size=1):
+    parallel_state.destroy_model_parallel()
+
+    # Torch setup for distributed training
+    rank = int(os.environ['LOCAL_RANK'])
+    world_size = torch.cuda.device_count()
+    torch.cuda.set_device(rank)
+    torch.distributed.init_process_group(world_size=world_size, rank=rank)
+
+    # Megatron core distributed training initialization
+    parallel_state.initialize_model_parallel(tensor_model_parallel_size, pipeline_model_parallel_size)
+
+def model_provider():
+    """Build the model."""
+
+    transformer_config = TransformerConfig(
+        num_layers=2,
+        hidden_size=12,
+        num_attention_heads=4,
+        use_cpu_initialization=True,
+        pipeline_dtype=torch.float32,
+    )
+
+    gpt_model = GPTModel(
+        config=transformer_config,
+        transformer_layer_spec=get_gpt_layer_local_spec(),
+        vocab_size=100,
+        max_sequence_length=_SEQUENCE_LENGTH,
+    )
+
+    return gpt_model
+
+def get_train_data_iterator():
+    if torch.distributed.is_available() and torch.distributed.is_initialized():
+        if torch.distributed.get_rank() == 0:
+            compile_helpers()
+        torch.distributed.barrier()
+    else:
+        compile_helpers()
+
+    config = GPTDatasetConfig(
+        random_seed=0,
+        sequence_length=_SEQUENCE_LENGTH,
+        reset_position_ids=False,
+        reset_attention_mask=False,
+        eod_mask_loss=False,
+        tokenizer=_NullTokenizer(vocab_size=_SEQUENCE_LENGTH),
+    )
+
+    datasets = BlendedMegatronDatasetBuilder(
+        MockGPTDataset, [1000, None, None], lambda: True, config
+    ).build()
+
+    train_dataloader = DataLoader(datasets[0], batch_size=8, shuffle=True)
+
+    train_iterator = iter(train_dataloader)
+
+    return train_iterator
+
+def forward_step_func(data_iterator, model):
+
+    def loss_func(loss_mask: torch.Tensor, output_tensor: torch.Tensor):
+
+        losses = output_tensor.float()
+        loss_mask = loss_mask.view(-1).float()
+        loss = torch.sum(losses.view(-1) * loss_mask) / loss_mask.sum()
+        # If you have data parallel reduce loss across data parallel groups.
+        # If pipeline parallel, loss computation is done only in last stage.
+
+        return loss, {'lm loss': loss}
+
+    data = next(data_iterator)
+    tokens = data['tokens'].to(device)
+    attention_mask = data['attention_mask'].to(device)
+    position_ids = data['position_ids'].to(device)
+    labels = data['labels'].to(device)
+    loss_mask = data['loss_mask'].to(device)
+
+    output_tensor = model(tokens, position_ids, attention_mask,
+                          labels=labels)
+
+    return output_tensor, partial(loss_func, loss_mask)
+
+def save_distributed_checkpoint(checkpoint_path, gpt_model):
+    sharded_state_dict = gpt_model.sharded_state_dict(prefix='')
+    dist_checkpointing.save(sharded_state_dict=sharded_state_dict, checkpoint_dir=checkpoint_path)
+
+def load_distributed_checkpoint(checkpoint_path, gpt_model):
+    sharded_state_dict=gpt_model.sharded_state_dict(prefix='')
+    checkpoint = dist_checkpointing.load(sharded_state_dict=sharded_state_dict, checkpoint_dir=checkpoint_path)
+    gpt_model.load_state_dict(checkpoint)
+    return gpt_model
+
+if __name__ == "__main__":
+    initialize_distributed(tensor_model_parallel_size=2, pipeline_model_parallel_size=1)
+    model_parallel_cuda_manual_seed(123)
+
+    gpt_model = model_provider()
+    device = torch.device("cuda")
+    gpt_model.to(device)
+
+    optim = Adam(gpt_model.parameters())
+
+    train_iterator = get_train_data_iterator()
+
+    forward_backward_func = get_forward_backward_func()
+
+    # Running the model for 5 iterations
+    for _ in range(5):
+        optim.zero_grad()
+
+        losses_reduced = forward_backward_func(
+            forward_step_func=forward_step_func,
+            data_iterator=train_iterator,
+            model=gpt_model,
+            num_microbatches=1,
+            seq_length=_SEQUENCE_LENGTH,
+            micro_batch_size=8,
+            decoder_seq_length=_SEQUENCE_LENGTH,
+            forward_only=False)
+
+        optim.step()
+
+        print(f'Losses reduced :  {losses_reduced}')
+
+    # Saving the model
+    ckpt_path = os.getcwd() + '/ckpt'
+    Path(ckpt_path).mkdir(exist_ok=True)
+    save_distributed_checkpoint(gpt_model=gpt_model, checkpoint_path=ckpt_path)
+
+    # Loading the model
+    gpt_model = load_distributed_checkpoint(gpt_model=gpt_model, checkpoint_path=ckpt_path)
+    gpt_model.to(device)
+    print('Successfully loaded the model')
+

examples/t5/README.md

+# T5 MODEL
+
+## Table of contents
+- [1. Training Setup](#1-training-setup)
+- [2. Configurations](#2-configurations)
+- [3. Training Results](#3-training-results)
+
+## 1. Training setup
+<a id="markdown-training-setup" name="training-setup"></a>
+To run the model on a Slurm based cluster
+```
+PYTORCH_IMAGE=nvcr.io/nvidia/pytorch:23.09-py3
+ACCOUNT_NAME=""
+PARTITION=""
+JOB_NAME=""
+NUM_NODES=1
+CHECKPOINT_PATH="" #<Specify path to checkpoint>
+TENSORBOARD_LOGS_PATH=""#<Specify path to tensorboard log>
+VOCAB_FILE="" #<Specify path to file>/bert-large-cased-vocab.txt
+DATA_PATH="" #<Specify path and file prefix>_text_document
+
+srun -N $NUM_NODES --container-image $PYTORCH_IMAGE --container-mounts "/path/to/data:/path/to/data,/path/to/megatron-lm:/workspace/megatron-lm" --account $ACCOUNT -N 1 -J $JOB_NAME  -p $PARTITION --no-container-mount-home  -c "
+  cd /workspace/megatron-lm
+  ./examples/t5/train_t5_220m_distributed.sh $CHECKPOINT_PATH $TENSORBOARD_LOGS_PATH $VOCAB_FILE $DATA_PATH"
+
+```
+
+## 2. Configurations
+<a id="markdown-configurations" name="configurations"></a>
+The architecture arguments below shows configuration for T5 220M model.
+
+### 220M
+```
+       --num-layers 12 \
+       --hidden-size 768 \
+       --num-attention-heads 12 \
+       --kv-channels 64 \
+       --ffn-hidden-size 3072 \
+       --encoder-seq-length 512 \
+       --decoder-seq-length 128 \
+       --max-position-embeddings 512 \
+       --tensor-model-parallel-size 1 \
+       --pipeline-model-parallel-size 1 \
+
+```
+
+
+## 3. Training Results
+<a id="markdown-training-results" name="training-results"></a>
+Below is the training curve for the 220M model on Pile dataset. The training takes 4 days on 32 GPUs, with batch size of 2048.
+
+Finetuning on SQUAD dataset, the validation result is: 63.44\%
+<p align="center">
+<img src="./t5_mcore_train_curve.png"  width="800" height="400">
+</p>

examples/t5/train_t5_220m_distributed.sh

+#!/bin/bash
+
+# Runs the "220M" parameter model
+
+export CUDA_DEVICE_MAX_CONNECTIONS=1
+
+GPUS_PER_NODE=8
+# Change for multinode config
+MASTER_ADDR=localhost
+MASTER_PORT=6000
+NUM_NODES=1
+NODE_RANK=0
+WORLD_SIZE=$(($GPUS_PER_NODE*$NUM_NODES))
+
+CHECKPOINT_PATH=$1 #<Specify path>
+TENSORBOARD_DIR=$2 #<Specify path>
+VOCAB_FILE=$3 #<Specify path to file>/bert-large-cased-vocab.txt
+DATA_PATH=$4 #<Specify path and file prefix>_text_document
+
+DISTRIBUTED_ARGS="
+    --nproc_per_node $GPUS_PER_NODE \
+    --nnodes $NUM_NODES \
+    --node_rank $NODE_RANK \
+    --master_addr $MASTER_ADDR \
+    --master_port $MASTER_PORT
+"
+
+T5_ARGS="
+    --encoder-num-layers 12 \
+    --decoder-num-layers 12 \
+    --hidden-size 768 \
+    --num-attention-heads 12 \
+    --kv-channels 64 \
+    --ffn-hidden-size 3072 \
+    --encoder-seq-length 512 \
+    --decoder-seq-length 128 \
+    --max-position-embeddings 512 \
+    --micro-batch-size 64 \
+    --global-batch-size 512 \
+    --lr 0.0001 \
+    --train-iters 1000000 \
+    --lr-decay-iters 1000000 \
+    --lr-decay-style linear \
+    --min-lr 0.00001 \
+    --weight-decay 1e-2 \
+    --lr-warmup-fraction .01 \
+    --clip-grad 1.0 \
+    --bf16 \
+    --vocab-extra-ids 100 \
+    --init-method-std 0.015 \
+    --transformer-impl transformer_engine \
+    --tensor-model-parallel-size 1 \
+    --pipeline-model-parallel-size 1 \
+"
+
+DATA_ARGS="
+    --data-path $DATA_PATH \
+    --vocab-file $VOCAB_FILE \
+    --tokenizer-type BertWordPieceCase \
+    --split 99982,9,9 \
+"
+
+OUTPUT_ARGS="
+    --log-interval 100 \
+    --tensorboard-dir ${TENSORBOARD_DIR} \
+    --save-interval 500 \
+    --eval-interval 1000 \
+    --eval-iters 10
+"
+
+torchrun $DISTRIBUTED_ARGS pretrain_t5.py \
+    $T5_ARGS \
+    $DATA_ARGS \
+    $OUTPUT_ARGS \
+    --distributed-backend nccl \
+    --save $CHECKPOINT_PATH \
+    --load $CHECKPOINT_PATH \

gpt175b.sh

+#!/bin/bash
+
+# Runs the "7B" parameter model
+export HSA_FORCE_FINE_GRAIN_PCIE=1
+export OMP_NUM_THREADS=1
+export NCCL_P2P_LEVEL=PXB
+
+source /opt/dtk/env.sh
+export LD_LIBRARY_PATH=/mnt/fs/user/llama/dcu/dtk-24.04/rocblas/lib:$LD_LIBRARY_PATH
+#export LD_LIBRARY_PATH=/mnt/fs/user/llama/dcu/rocblas-install_padding/lib:$LD_LIBRARY_PATH
+
+#export HIP_ALLOC_INITIALIZE=0
+#export GPU_MAX_HW_QUEUES=20
+
+export NCCL_ALGO=Ring
+export NCCL_NCHANNELS_PER_PEER=16
+export NCCL_MIN_NCHANNELS=20
+export NCCL_IB_TIMEOUT=22
+export CUDA_DEVICE_MAX_CONNECTIONS=1
+
+export NCCL_IB_HCA=mlx5_1,mlx5_2
+#export NCCL_SOCKET_IFNAME=ibs8
+export NCCL_NET_GDR_LEVEL=SYS
+export NCCL_NET_GDR_READ=0
+#export NCCL_DEBUG=info
+
+lrank=$OMPI_COMM_WORLD_LOCAL_RANK
+RANK=$OMPI_COMM_WORLD_RANK
+WORLD_SIZE=$OMPI_COMM_WORLD_SIZE
+
+CHECKPOINT_PATH=./tmp #$1 #<Specify path>
+TENSORBOARD_LOGS_PATH=./tmp  #$2 #<Specify path>
+DATA_PATH="/mnt/fs/user/llama/dcu/Megatron-LM-main/oscar/my-gpt2_text_document" #<Specify path and file prefix>_text_document
+
+GPT_MODEL_ARGS=(
+    --num-layers 96
+    --hidden-size 12288
+    --num-attention-heads 96
+    --seq-length 2048
+    --max-position-embeddings 2048
+)
+
+TRAINING_ARGS=(
+    --transformer-impl local
+    --use-legacy-models
+    --micro-batch-size 1
+    --global-batch-size 512 #256 1024
+    --train-iters 100
+    --weight-decay 0.1
+    --adam-beta1 0.9
+    --adam-beta2 0.95
+    --init-method-std 0.006
+    --clip-grad 1.0
+    --bf16
+    --disable-bias-linear
+    --no-bias-gelu-fusion
+    --no-gradient-accumulation-fusion
+    --use-distributed-optimizer
+    --use-flash-attn-triton
+    --lr 1.5e-04
+    --use-tp-pp-dp-mapping
+    --lr-decay-style cosine
+    --min-lr 1.5e-05
+    --lr-warmup-iters 1
+)
+#--initial-loss-scale 65536
+#--loss-scale 1024
+#--recompute-granularity full
+#--recompute-method uniform
+#--recompute-num-layers 1
+#--recompute-activations
+#--use-flash-attn
+MODEL_PARALLEL_ARGS=(
+        --sequence-parallel
+	--tensor-model-parallel-size 4   #4
+	--pipeline-model-parallel-size 8 #4   8
+)
+
+DATA_ARGS=(
+    --data-path $DATA_PATH
+    --split 949,50,1
+    --tokenizer-type GPT2BPETokenizer
+    --vocab-file gpt2-vocab.json
+    --merge-file gpt2-merges.txt
+)
+
+EVAL_AND_LOGGING_ARGS=(
+    --log-interval 1
+    --log-throughput
+    --save-interval 10000
+    --eval-interval 1000
+    --save $CHECKPOINT_PATH
+    --load $CHECKPOINT_PATH
+    --eval-iters 10
+    --tensorboard-dir $TENSORBOARD_LOGS_PATH
+)
+
+APP="python3  -u pretrain_gpt.py \
+     ${GPT_MODEL_ARGS[@]} \
+     ${TRAINING_ARGS[@]} \
+     ${MODEL_PARALLEL_ARGS[@]} \
+     ${DATA_ARGS[@]} \
+     ${EVAL_AND_LOGGING_ARGS[@]}
+     --rank ${RANK} \
+     --world_size ${WORLD_SIZE} \
+     --dist_url tcp://${1}:34566 \
+    "
+
+
+case ${lrank} in
+[0])
+  export CUDA_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[1])
+  export CUDA_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[2])
+  export CUDA_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[3])
+  export CUDA_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[4])
+  export CUDA_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[5])
+  export CUDA_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[6])
+  export CUDA_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[7])
+  export CUDA_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+esac
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+

kill.sh

+ps -ef | grep python3 | grep -v grep | awk '{print "kill "$2}' >& .tmp
+bash .tmp

llama2_13b.sh

+#!/bin/bash
+
+#export FLASH_ATTENTION_PRINT_PARAM=1
+# Runs the "7B" parameter model
+export HSA_FORCE_FINE_GRAIN_PCIE=1
+export OMP_NUM_THREADS=1
+export NCCL_P2P_LEVEL=5
+
+#export HIP_ALLOC_INITIALIZE=0
+#export GPU_MAX_HW_QUEUES=16
+
+export NCCL_ALGO=Ring
+export NCCL_NCHANNELS_PER_PEER=16
+export NCCL_MIN_NCHANNELS=20
+export NCCL_IB_TIMEOUT=22
+export CUDA_DEVICE_MAX_CONNECTIONS=1
+
+export NCCL_IB_HCA=mlx5_1,mlx5_2
+#export NCCL_SOCKET_IFNAME=ibs8
+export NCCL_NET_GDR_LEVEL=SYS
+export NCCL_NET_GDR_READ=0
+#export NCCL_DEBUG=info
+
+lrank=$OMPI_COMM_WORLD_LOCAL_RANK
+RANK=$OMPI_COMM_WORLD_RANK
+WORLD_SIZE=$OMPI_COMM_WORLD_SIZE
+
+CHECKPOINT_PATH=./tmp_13b #$1 #<Specify path>
+TENSORBOARD_LOGS_PATH=./tmp_13b  #$2 #<Specify path>
+DATA_PATH="./dataset/my-llama_text_document" #<Specify path and file prefix>_text_document
+TOKENIZER_PATH="./tokenizer.model"
+
+GPT_MODEL_ARGS=(
+    --num-layers 40
+    --hidden-size 5120
+    --num-attention-heads 40
+    --ffn-hidden-size 13824
+    --seq-length 4096
+    --max-position-embeddings 4096
+)
+
+TRAINING_ARGS=(
+    --transformer-impl local
+    --use-legacy-models
+    --micro-batch-size 1
+    --global-batch-size 256 #60
+    --train-iters 100
+    --weight-decay 0.1
+    --adam-beta1 0.9
+    --adam-beta2 0.95
+    --init-method-std 0.006
+    --clip-grad 1.0
+    --bf16
+    --use-flash-attn-triton
+    --recompute-activations
+    --use-distributed-optimizer
+    --disable-bias-linear
+    --attention-dropout 0
+    --hidden-dropout 0
+    --no-gradient-accumulation-fusion
+    --swiglu
+    --lr 3.0e-5
+    --lr-decay-style cosine
+    --min-lr 3.0e-6
+    --lr-warmup-iters 1
+)
+#--recompute-granularity full
+#--recompute-method block
+#--recompute-num-layers 4
+
+#--ddp-average-in-collective
+#--overlap-grad-reduce
+#--use-flash-attn-triton
+MODEL_PARALLEL_ARGS=(
+        --sequence-parallel
+	--tensor-model-parallel-size 1 #2
+	--pipeline-model-parallel-size 8 #4
+)
+#--sequence-parallel
+DATA_ARGS=(
+    --data-path $DATA_PATH
+    --split 949,50,1
+    --untie-embeddings-and-output-weights
+    --use-rotary-position-embeddings
+    --normalization RMSNorm
+    --no-position-embedding
+    --tokenizer-model $TOKENIZER_PATH
+    --tokenizer-type Llama2Tokenizer
+)
+
+EVAL_AND_LOGGING_ARGS=(
+    --log-interval 1
+    --log-throughput
+    --save-interval 10000
+    --eval-interval 1000
+    --save $CHECKPOINT_PATH
+    --load $CHECKPOINT_PATH
+    --eval-iters 10
+    --tensorboard-dir $TENSORBOARD_LOGS_PATH
+)
+
+APP="python3  -u pretrain_gpt.py \
+     ${GPT_MODEL_ARGS[@]} \
+     ${TRAINING_ARGS[@]} \
+     ${MODEL_PARALLEL_ARGS[@]} \
+     ${DATA_ARGS[@]} \
+     ${EVAL_AND_LOGGING_ARGS[@]}
+     --rank ${RANK} \
+     --world_size ${WORLD_SIZE} \
+     --dist_url tcp://${1}:34566 \
+    "
+
+
+case ${lrank} in
+[0])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[1])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[2])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[3])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[4])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[5])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[6])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[7])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+esac
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+

llama2_7b.sh

+#!/bin/bash
+
+# Runs the "7B" parameter model
+export HSA_FORCE_FINE_GRAIN_PCIE=1
+export OMP_NUM_THREADS=1
+export NCCL_P2P_LEVEL=5
+source /opt/dtk/env.sh
+
+#export HIP_DIRECT_DISPATCH=0
+
+#export GPU_FLUSH_ON_EXECUTION=1
+
+#export HIP_ALLOC_INITIALIZE=0
+#export GPU_MAX_HW_QUEUES=20
+export NCCL_ALGO=Ring
+export NCCL_NCHANNELS_PER_PEER=16
+export NCCL_MIN_NCHANNELS=16
+export NCCL_MIN_P2P_NCHANNELS=16
+export NCCL_IB_TIMEOUT=22
+export CUDA_DEVICE_MAX_CONNECTIONS=1
+
+export NCCL_IB_HCA=mlx5_1,mlx5_2
+#export NCCL_SOCKET_IFNAME=ibs8
+export NCCL_NET_GDR_LEVEL=SYS
+#export NCCL_NET_GDR_READ=0
+export NCCL_DEBUG=info
+
+#export FLASH_ATTENTION_PRINT_PARAM=1
+lrank=$OMPI_COMM_WORLD_LOCAL_RANK
+RANK=$OMPI_COMM_WORLD_RANK
+WORLD_SIZE=$OMPI_COMM_WORLD_SIZE
+
+CHECKPOINT_PATH=./tmp_7b #$1 #<Specify path>
+TENSORBOARD_LOGS_PATH=./tmp_7b  #$2 #<Specify path>
+DATA_PATH="./dataset/my-llama_text_document" #<Specify path and file prefix>_text_document
+TOKENIZER_PATH="./tokenizer.model"
+
+GPT_MODEL_ARGS=(
+    --num-layers 32
+    --hidden-size 4096
+    --num-attention-heads 32
+    --ffn-hidden-size 11008
+    --seq-length 4096
+    --max-position-embeddings 4096
+)
+
+TRAINING_ARGS=(
+    --log-throughput
+    --transformer-impl local
+    --use-legacy-models
+    --micro-batch-size 1
+    --global-batch-size 64
+    --train-iters 1000
+    --weight-decay 0.1
+    --adam-beta1 0.9
+    --adam-beta2 0.95
+    --init-method-std 0.006
+    --clip-grad 1.0
+    --bf16
+    --recompute-activations
+    --use-flash-attn-triton
+    --optimizer adam
+    --use-distributed-optimizer
+    --ddp-average-in-collective
+    --overlap-grad-reduce
+    --disable-bias-linear
+    --attention-dropout 0
+    --hidden-dropout 0
+    --no-gradient-accumulation-fusion
+    --swiglu
+    --lr 3.0e-5
+    --lr-decay-style cosine
+    --min-lr 3.0e-6
+    --lr-warmup-iters 1
+)
+
+MODEL_PARALLEL_ARGS=(
+        --sequence-parallel
+	--tensor-model-parallel-size 1
+	--pipeline-model-parallel-size 2
+)
+#--sequence-parallel
+DATA_ARGS=(
+    --data-path $DATA_PATH
+    --split 949,50,1
+    --untie-embeddings-and-output-weights
+    --use-rotary-position-embeddings
+    --normalization RMSNorm
+    --no-position-embedding
+    --tokenizer-model $TOKENIZER_PATH
+    --tokenizer-type Llama2Tokenizer
+)
+
+EVAL_AND_LOGGING_ARGS=(
+    --log-interval 1
+    --log-throughput
+    --save-interval 10000
+    --eval-interval 1000
+    --save $CHECKPOINT_PATH
+    --load $CHECKPOINT_PATH
+    --eval-iters 1000
+    --tensorboard-dir $TENSORBOARD_LOGS_PATH
+)
+
+APP="python3  -u pretrain_gpt.py \
+     ${GPT_MODEL_ARGS[@]} \
+     ${TRAINING_ARGS[@]} \
+     ${MODEL_PARALLEL_ARGS[@]} \
+     ${DATA_ARGS[@]} \
+     ${EVAL_AND_LOGGING_ARGS[@]}
+     --rank ${RANK} \
+     --world_size ${WORLD_SIZE} \
+     --dist_url tcp://${1}:34566 \
+    "
+
+
+case ${lrank} in
+[0])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[1])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[2])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[3])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[4])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[5])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[6])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+[7])
+  export HIP_VISIBLE_DEVICES=0,1,2,3,4,5,6,7
+  ${APP}
+  ;;
+esac
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+
+

megatron/core/QuickStart.md

+## Quick Start
+The following guide will show you how to quickly get started with Megatron Core. It will show you the following
+* We will initalize megatron core on 2 GPUS.
+* We will build a GPT model with tensor model parallel size 2, pipeline parallel size 1
+* We will train it for a few iterations using megatron core schedules
+* We will save the model using the distributed checkpointing format
+* We will load the model saved above.
+
+*NOTE: The following has been testing for megatron core version 0.8.0 and NGC Pytorch Container version 24.02
+
+### Environment Setup
+```
+docker run --ipc=host --shm-size=512m --gpus 2 -it nvcr.io/nvidia/pytorch:24.02-py3
+
+git clone https://github.com/NVIDIA/Megatron-LM.git && cd Megatron-LM
+```
+<br>
+
+### Writing Your First Training Loop
+The following steps will walk you through how you can create a sample GPT model split across tensors (Tensor model parallel ) on 2 GPUS, and run a forward pass through it using a MockGPT dataset helper class that we created in Megatron core.
+
+<br>
+
+**NOTE: All of the following steps are already put into a script [run_simple_mcore_train_loop.py](https://github.com/NVIDIA/Megatron-LM/tree/main/examples/run_simple_mcore_train_loop.py) which you can run as follows**
+```
+PYTHONPATH=$PYTHON_PATH:./megatron torchrun --nproc-per-node 2 examples/run_simple_mcore_train_loop.py
+```
+
+<br>
+
+**STEP 1 - Initialize Distributed Training and Model parallel setup**
+The following utility when called initalizes your distributed setup.
+
+```python
+import os
+import torch
+from megatron.core import parallel_state
+
+def initialize_distributed(tensor_model_parallel_size = 1, pipeline_model_parallel_size = 1):
+    # Torch setup for distributed training
+    rank = int(os.environ['LOCAL_RANK'])
+    world_size = torch.cuda.device_count()
+    torch.cuda.set_device(rank)
+    torch.distributed.init_process_group(world_size=world_size, rank=rank)
+
+    # Megatron core distributed training initialization
+    parallel_state.initialize_model_parallel(tensor_model_parallel_size, pipeline_model_parallel_size)
+```
+<br>
+
+**STEP 2 - GPT Model Setup**
+The following step shows you how you can quickly create a GPT model. For a list of other configs that you can pass into the model look into [transformer_config.py](https://github.com/NVIDIA/Megatron-LM/tree/main/megatron/core/transformer/transformer_config.py)
+```
+from megatron.core.transformer.transformer_config import TransformerConfig
+from megatron.core.models.gpt.gpt_model import GPTModel
+from megatron.core.models.gpt.gpt_layer_specs import get_gpt_layer_local_spec
+
+def model_provider():
+    """Build the model."""
+
+    transformer_config = TransformerConfig(
+        num_layers=2,
+        hidden_size=12,
+        num_attention_heads=4,
+        use_cpu_initialization=True,
+        pipeline_dtype=torch.float32)
+
+    gpt_model = GPTModel(
+        config=transformer_config,
+        transformer_layer_spec=get_gpt_layer_local_spec(),
+        vocab_size=100,
+        max_sequence_length=64)
+
+    return gpt_model
+```
+<br>
+
+**STEP 3 - GPT Mock dataset setup**
+The following shows you how you can quickly get started with a mock dataset utility we created. In order to train with your data, please use the actual GPTDataset class in [gpt_dataset.py](https://github.com/NVIDIA/Megatron-LM/tree/main/megatron/core/datasets/gpt_dataset.py)
+
+To find more information about megatron core data pipeline please refer to [this](https://github.com/NVIDIA/Megatron-LM/tree/main/megatron/core/datasets/readme.md?ref_type=heads)
+
+```
+import torch
+from torch.utils.data import DataLoader
+
+from megatron.core.datasets.blended_megatron_dataset_builder import BlendedMegatronDatasetBuilder
+from megatron.core.datasets.gpt_dataset import GPTDatasetConfig, MockGPTDataset
+from megatron.training.tokenizer.tokenizer import _NullTokenizer
+from megatron.core.datasets.utils import compile_helpers
+
+_SEQUENCE_LENGTH = 64
+
+def get_train_data_iterator():
+    if torch.distributed.is_available() and torch.distributed.is_initialized():
+        if torch.distributed.get_rank() == 0:
+            compile_helpers()
+        torch.distributed.barrier()
+    else:
+        compile_helpers()
+
+    config = GPTDatasetConfig(
+        random_seed=0,
+        sequence_length=_SEQUENCE_LENGTH,
+        reset_position_ids=False,
+        reset_attention_mask=False,
+        eod_mask_loss=False,
+        tokenizer=_NullTokenizer(vocab_size=_SEQUENCE_LENGTH),
+    )
+
+    datasets = BlendedMegatronDatasetBuilder(
+        MockGPTDataset, [1000, None, None], lambda: True, config
+    ).build()
+
+    train_dataloader = DataLoader(datasets[0], batch_size=8, shuffle=True)
+
+    train_iterator = iter(train_dataloader)
+
+    return train_iterator
+
+```
+<br>
+
+**STEP 4 - Forward Step Function**
+In megatron core, we use [schedules.py](https://github.com/NVIDIA/Megatron-LM/tree/main/megatron/core/pipeline_parallel/schedules.py) to run the model. So it is sufficient to define a forward step function which takes as input the data iterator and the model and produces as output the output tensor and a loss function
+
+```python
+from functools import partial
+
+def forward_step_func(data_iterator, model):
+
+    def loss_func(loss_mask: torch.Tensor, output_tensor: torch.Tensor):
+
+        losses = output_tensor.float()
+        loss_mask = loss_mask.view(-1).float()
+        loss = torch.sum(losses.view(-1) * loss_mask) / loss_mask.sum()
+        # If you have data parallel reduce loss across data parallel groups.
+        # If pipeline parallel, loss computation is done only in last stage.
+
+        return loss, {'lm loss': loss}
+
+    data = next(data_iterator)
+    tokens = data['tokens'].to(device)
+    attention_mask = data['attention_mask'].to(device)
+    position_ids = data['position_ids'].to(device)
+    labels = data['labels'].to(device)
+    loss_mask = data['loss_mask'].to(device)
+
+    output_tensor = model(tokens, position_ids, attention_mask,
+                          labels=labels)
+
+    return output_tensor, partial(loss_func, loss_mask)
+```
+<br>
+
+**STEP 5 - Load and Save Distributed Checkpoint**
+Megatron core uses distributed checkpoint for loading and saving model. This gives you the flexiblity to convert model from one model parallel setting to another when you load a model (i.e A model trained with tensor parallel size 2, can now be loaded as tensor model parallel size 4 etc.)
+
+```python
+from megatron.core import dist_checkpointing
+
+def save_distributed_checkpoint(checkpoint_path, gpt_model):
+    sharded_state_dict = gpt_model.sharded_state_dict(prefix='')
+    dist_checkpointing.save(sharded_state_dict=sharded_state_dict, checkpoint_dir=checkpoint_path)
+
+def load_distributed_checkpoint(checkpoint_path, gpt_model):
+    sharded_state_dict=gpt_model.sharded_state_dict(prefix='')
+    checkpoint = dist_checkpointing.load(sharded_state_dict=sharded_state_dict, checkpoint_dir=checkpoint_path)
+    gpt_model.load_state_dict(checkpoint)
+    return gpt_model
+```
+<br>
+
+**STEP 6 - Main Function**
+The following is the main function that needs to go into your script.
+
+```python
+from pathlib import Path
+from torch.optim import Adam
+from megatron.core.pipeline_parallel.schedules import get_forward_backward_func
+from megatron.core.tensor_parallel.random import model_parallel_cuda_manual_seed
+
+if __name__ == "__main__":
+    initialize_distributed(tensor_model_parallel_size=2, pipeline_model_parallel_size=1)
+    model_parallel_cuda_manual_seed(123)
+
+    gpt_model = model_provider()
+    device = torch.device("cuda")
+    gpt_model.to(device)
+
+    optim = Adam(gpt_model.parameters())
+
+    train_iterator = get_train_data_iterator()
+
+    forward_backward_func = get_forward_backward_func()
+
+    # Running the model for 5 iterations
+    for _ in range(5):
+        optim.zero_grad()
+
+        losses_reduced = forward_backward_func(
+            forward_step_func=forward_step_func,
+            data_iterator=train_iterator,
+            model=gpt_model,
+            num_microbatches=1,
+            seq_length=64,
+            micro_batch_size=8,
+            decoder_seq_length=64,
+            forward_only=False)
+
+        optim.step()
+
+        print(f'Losses reduced :  {losses_reduced}')
+
+    # Saving the model
+    save_distributed_checkpoint(gpt_model=gpt_model, checkpoint_path='/workspace/ckpt')
+
+    # Loading the model
+    gpt_model = load_distributed_checkpoint(gpt_model=gpt_model, checkpoint_path='/workspace/ckpt')
+    gpt_model.to(device)
+    print('Successfully loaded the model')
+```
+<br>
+
+
+
+### Extending Further
+The above example introduced you to a basic training loop in MCore. To see more advanced examples please look at [pretrain_gpt.py]. That will show you how you can write more complex training loops, involving pipeline parallel, context parallel, rope embeddings, mixture of experts and all other functionalities present in mcore.

megatron/core/README.md

+Megatron Core is a library for efficient and scalable training of transformer based models.
\ No newline at end of file

megatron/core/README_STRAGGLER.md

+## StragglerDetector for a TP Group
+
+The file `megatron/core/utils.py` has a class named `StragglerDetector` which supports Python Contexts.
+It can be used to find straggling TP group based on the RTT of the ranks in the TP Group. It also collects
+Power/Temp/Utilization for GPUs, which can additionally be used to narrow down to the exact GPU in the TP Group,
+assuming the straggling was caused by hardware anomaly in a given GPU.<br>
+This class supports collecting timing events for various steps of a given iteration. It
+keeps collecting such timing events on a per rank basis, and when the reporter is invoked
+during a logging interval, it computes the min and max of certain metric across all
+ranks and logs the observed metric and the rank as follows
+
+```
+ 0: INFO:megatron.core.utils:[2024-03-14 23:07:56] | MnRtt/Rnk: 3453.08ms/8 | MxRtt/Rnk: 3468.20ms/0 | MnPwr/Rnk: 601796W/8 | MxPwr/Rnk: 683801W/18 | MnTmp/Rnk: 52C/0 | MxTmp/Rnk: 65C/21 | MnUtl/Rnk: 97%/8 | MxUtl/Rnk: 100%/6 | MnClk/Rnk: 1950MHz/28 | MxClk/Rnk: 1980MHz/0 | MnDRtt/Rnk: 14.27ms/23 | MxDRtt/Rnk: 34.65ms/3 | MnEtpt/Rnk: 296.02TF/0 | MxEtpt/Rnk: 297.32TF/8
+```
+<hr>
+
+### Description of the metrics
+
+Each metric is prefixed with `Mn` or `Mx` to represent `Minimum` or `Maximum`. Each metric is also suffixed with the rank where the metric was measured. The metrics are averaged over the logging interval. Between the prefix and the rank is the name of the metric as follows
+
+- Rtt : RoundTrip Time (time spent in all the traced ops per iteration)
+- Pwr : GPU Power
+- Tmp : GPU Temperature
+- Utl : GPU Utilization
+- Clk : GPU Clock
+- DRtt: get_batch latency
+- Etpt: Estimated throughput. This is derived from actual computed throughput dividied by Rtt. Since we do not collect timing for backward pass, the value is further divided by three to come up with estimated throughput.
+<hr>
+
+### Command Line activation
+To start using the StragglerDetector, need to pass the following argument `--log-straggler`. It optionally also takes two additional parameters. Default disabled
+- `--disable-straggler-on-startup` - whether to keept the StragglerDetector disabled on startup and enable later. Default enabled
+- `--straggler-ctrlr-port` - The StragglerDetector can toggle between on/off just by sending `curl Rank0Host:port`. Default port is 65535. Every time it is turned
+- `--straggler-minmax-count` - If set to > 1 (N), it prints N Top and Bottom Etpt/Rank pairs as shown below
+```
+ 0: INFO:megatron.core.utils:^^^^ Bottom 4 Ranks with lowest  Etpt(TF): 296.02/0, 296.17/2, 296.23/1, 296.23/4,
+ 0: INFO:megatron.core.utils:^^^^ Top    4 Ranks with highest Etpt(TF): 297.28/15, 297.28/11, 297.32/12, 297.32/8,
+```
+<hr>
+
+### Programming the StragglerDetector
+The StragglerDetector class supports context, and its implementation is a Singleton.
+- Initialization
+
+```
+ # initialization, where StragglerDetector will be used
+   from megatron.core.utils import StragglerDetector
+   stimer = StragglerDetector()
+```
+
+- One time for each rank
+
+```
+ # one time before the training loop starts
+ stimer.configure(world, rank, enabled=True, port=65545)
+
+ # Arguments to configure
+ #     world   : World Size
+ #     rank    : The rank of this trainer
+ #     mmcnt   : (Optional) Number of ranks to print for showing Min/Max Etpt
+ #     amp     : (Optional) Set to 3.0 if we only use timers in fwd pass
+ #     port    : (Optional) control port, useful only for rank-0
+ #     prefill : (Optional) howmany Events to pre-populate
+ #     enabled : (Optional) whether or not collection is enabled on startup
+```
+
+- To Capture time
+
+```
+ # whereever timing need to be captured
+ with stimer:
+     do_operation()
+
+ # special case for get_batch
+ with stimer(bdata=True):
+      input,... = get_batch(iterator,...)
+```
+
+- Logging in main training loop
+
+```
+ # logging
+   total_flops = 0.0
+   iteration = 0
+   # inside the main training loop
+   while training:
+        iteration += 1
+        do_step()
+        total_flops += get_computed_flops()
+        if iteration % log_interval:
+           stimer.report(total_flops, log_interval)
+           total_flops = 0.0
+```

megatron/core/__init__.py

+import megatron.core.tensor_parallel
+import megatron.core.utils
+from megatron.core import parallel_state
+from megatron.core.distributed import DistributedDataParallel
+from megatron.core.inference_params import InferenceParams
+from megatron.core.model_parallel_config import ModelParallelConfig
+from megatron.core.package_info import (
+    __contact_emails__,
+    __contact_names__,
+    __description__,
+    __download_url__,
+    __homepage__,
+    __keywords__,
+    __license__,
+    __package_name__,
+    __repository_url__,
+    __shortversion__,
+    __version__,
+)
+from megatron.core.timers import Timers
+
+# Alias parallel_state as mpu, its legacy name
+mpu = parallel_state
+
+__all__ = [
+    "parallel_state",
+    "tensor_parallel",
+    "utils",
+    "DistributedDataParallel",
+    "InferenceParams",
+    "ModelParallelConfig",
+    "Timers",
+]
