object_detection/export_inference_graph.py

+# Copyright 2017 The TensorFlow Authors. All Rights Reserved.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+# ==============================================================================
+
+r"""Tool to export an object detection model for inference.
+
+Prepares an object detection tensorflow graph for inference using model
+configuration and an optional trained checkpoint. Outputs either an inference
+graph or a SavedModel (https://tensorflow.github.io/serving/serving_basic.html).
+
+The inference graph contains one of three input nodes depending on the user
+specified option.
+  * `image_tensor`: Accepts a uint8 4-D tensor of shape [1, None, None, 3]
+  * `encoded_image_string_tensor`: Accepts a scalar string tensor of encoded PNG
+    or JPEG image.
+  * `tf_example`: Accepts a serialized TFExample proto. The batch size in this
+    case is always 1.
+
+and the following output nodes returned by the model.postprocess(..):
+  * `num_detections`: Outputs float32 tensors of the form [batch]
+      that specifies the number of valid boxes per image in the batch.
+  * `detection_boxes`: Outputs float32 tensors of the form
+      [batch, num_boxes, 4] containing detected boxes.
+  * `detection_scores`: Outputs float32 tensors of the form
+      [batch, num_boxes] containing class scores for the detections.
+  * `detection_classes`: Outputs float32 tensors of the form
+      [batch, num_boxes] containing classes for the detections.
+  * `detection_masks`: Outputs float32 tensors of the form
+      [batch, num_boxes, mask_height, mask_width] containing predicted instance
+      masks for each box if its present in the dictionary of postprocessed
+      tensors returned by the model.
+
+Note that currently `batch` is always 1, but we will support `batch` > 1 in
+the future.
+
+Optionally, one can freeze the graph by converting the weights in the provided
+checkpoint as graph constants thereby eliminating the need to use a checkpoint
+file during inference.
+
+Note that this tool uses `use_moving_averages` from eval_config to decide
+which weights to freeze.
+
+Example Usage:
+--------------
+python export_inference_graph \
+    --input_type image_tensor \
+    --pipeline_config_path path/to/ssd_inception_v2.config \
+    --checkpoint_path path/to/model-ckpt \
+    --inference_graph_path path/to/inference_graph.pb
+"""
+import tensorflow as tf
+from google.protobuf import text_format
+from object_detection import exporter
+from object_detection.protos import pipeline_pb2
+
+slim = tf.contrib.slim
+flags = tf.app.flags
+
+flags.DEFINE_string('input_type', 'image_tensor', 'Type of input node. Can be '
+                    'one of [`image_tensor`, `encoded_image_string_tensor`, '
+                    '`tf_example`]')
+flags.DEFINE_string('pipeline_config_path', '',
+                    'Path to a pipeline_pb2.TrainEvalPipelineConfig config '
+                    'file.')
+flags.DEFINE_string('checkpoint_path', '', 'Optional path to checkpoint file. '
+                    'If provided, bakes the weights from the checkpoint into '
+                    'the graph.')
+flags.DEFINE_string('inference_graph_path', '', 'Path to write the output '
+                    'inference graph.')
+flags.DEFINE_bool('export_as_saved_model', False, 'Whether the exported graph '
+                  'should be saved as a SavedModel')
+
+FLAGS = flags.FLAGS
+
+
+def main(_):
+  assert FLAGS.pipeline_config_path, 'TrainEvalPipelineConfig missing.'
+  assert FLAGS.inference_graph_path, 'Inference graph path missing.'
+  assert FLAGS.input_type, 'Input type missing.'
+  pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+  with tf.gfile.GFile(FLAGS.pipeline_config_path, 'r') as f:
+    text_format.Merge(f.read(), pipeline_config)
+  exporter.export_inference_graph(FLAGS.input_type, pipeline_config,
+                                  FLAGS.checkpoint_path,
+                                  FLAGS.inference_graph_path,
+                                  FLAGS.export_as_saved_model)
+
+
+if __name__ == '__main__':
+  tf.app.run()

object_detection/exporter.py

+# Copyright 2017 The TensorFlow Authors. All Rights Reserved.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+# ==============================================================================
+
+"""Functions to export object detection inference graph."""
+import logging
+import os
+import tensorflow as tf
+from tensorflow.python import pywrap_tensorflow
+from tensorflow.python.client import session
+from tensorflow.python.framework import graph_util
+from tensorflow.python.framework import importer
+from tensorflow.python.platform import gfile
+from tensorflow.python.saved_model import signature_constants
+from tensorflow.python.training import saver as saver_lib
+from object_detection.builders import model_builder
+from object_detection.core import standard_fields as fields
+from object_detection.data_decoders import tf_example_decoder
+
+slim = tf.contrib.slim
+
+
+# TODO: Replace with freeze_graph.freeze_graph_with_def_protos when
+# newer version of Tensorflow becomes more common.
+def freeze_graph_with_def_protos(
+    input_graph_def,
+    input_saver_def,
+    input_checkpoint,
+    output_node_names,
+    restore_op_name,
+    filename_tensor_name,
+    clear_devices,
+    initializer_nodes,
+    variable_names_blacklist=''):
+  """Converts all variables in a graph and checkpoint into constants."""
+  del restore_op_name, filename_tensor_name  # Unused by updated loading code.
+
+  # 'input_checkpoint' may be a prefix if we're using Saver V2 format
+  if not saver_lib.checkpoint_exists(input_checkpoint):
+    raise ValueError(
+        'Input checkpoint "' + input_checkpoint + '" does not exist!')
+
+  if not output_node_names:
+    raise ValueError(
+        'You must supply the name of a node to --output_node_names.')
+
+  # Remove all the explicit device specifications for this node. This helps to
+  # make the graph more portable.
+  if clear_devices:
+    for node in input_graph_def.node:
+      node.device = ''
+
+  _ = importer.import_graph_def(input_graph_def, name='')
+
+  with session.Session() as sess:
+    if input_saver_def:
+      saver = saver_lib.Saver(saver_def=input_saver_def)
+      saver.restore(sess, input_checkpoint)
+    else:
+      var_list = {}
+      reader = pywrap_tensorflow.NewCheckpointReader(input_checkpoint)
+      var_to_shape_map = reader.get_variable_to_shape_map()
+      for key in var_to_shape_map:
+        try:
+          tensor = sess.graph.get_tensor_by_name(key + ':0')
+        except KeyError:
+          # This tensor doesn't exist in the graph (for example it's
+          # 'global_step' or a similar housekeeping element) so skip it.
+          continue
+        var_list[key] = tensor
+      saver = saver_lib.Saver(var_list=var_list)
+      saver.restore(sess, input_checkpoint)
+      if initializer_nodes:
+        sess.run(initializer_nodes)
+
+    variable_names_blacklist = (variable_names_blacklist.split(',') if
+                                variable_names_blacklist else None)
+    output_graph_def = graph_util.convert_variables_to_constants(
+        sess,
+        input_graph_def,
+        output_node_names.split(','),
+        variable_names_blacklist=variable_names_blacklist)
+
+  return output_graph_def
+
+
+def get_frozen_graph_def(inference_graph_def, use_moving_averages,
+                         input_checkpoint, output_node_names):
+  """Freezes all variables in a graph definition."""
+  saver = None
+  if use_moving_averages:
+    variable_averages = tf.train.ExponentialMovingAverage(0.0)
+    variables_to_restore = variable_averages.variables_to_restore()
+    saver = tf.train.Saver(variables_to_restore)
+  else:
+    saver = tf.train.Saver()
+
+  frozen_graph_def = freeze_graph_with_def_protos(
+      input_graph_def=inference_graph_def,
+      input_saver_def=saver.as_saver_def(),
+      input_checkpoint=input_checkpoint,
+      output_node_names=output_node_names,
+      restore_op_name='save/restore_all',
+      filename_tensor_name='save/Const:0',
+      clear_devices=True,
+      initializer_nodes='')
+  return frozen_graph_def
+
+
+# TODO: Support batch tf example inputs.
+def _tf_example_input_placeholder():
+  tf_example_placeholder = tf.placeholder(
+      tf.string, shape=[], name='tf_example')
+  tensor_dict = tf_example_decoder.TfExampleDecoder().decode(
+      tf_example_placeholder)
+  image = tensor_dict[fields.InputDataFields.image]
+  return tf.expand_dims(image, axis=0)
+
+
+def _image_tensor_input_placeholder():
+  return tf.placeholder(dtype=tf.uint8,
+                        shape=(1, None, None, 3),
+                        name='image_tensor')
+
+
+def _encoded_image_string_tensor_input_placeholder():
+  image_str = tf.placeholder(dtype=tf.string,
+                             shape=[],
+                             name='encoded_image_string_tensor')
+  image_tensor = tf.image.decode_image(image_str, channels=3)
+  image_tensor.set_shape((None, None, 3))
+  return tf.expand_dims(image_tensor, axis=0)
+
+
+input_placeholder_fn_map = {
+    'image_tensor': _image_tensor_input_placeholder,
+    'encoded_image_string_tensor':
+    _encoded_image_string_tensor_input_placeholder,
+    'tf_example': _tf_example_input_placeholder,
+}
+
+
+def _add_output_tensor_nodes(postprocessed_tensors):
+  """Adds output nodes for detection boxes and scores.
+
+  Adds the following nodes for output tensors -
+    * num_detections: float32 tensor of shape [batch_size].
+    * detection_boxes: float32 tensor of shape [batch_size, num_boxes, 4]
+      containing detected boxes.
+    * detection_scores: float32 tensor of shape [batch_size, num_boxes]
+      containing scores for the detected boxes.
+    * detection_classes: float32 tensor of shape [batch_size, num_boxes]
+      containing class predictions for the detected boxes.
+    * detection_masks: (Optional) float32 tensor of shape
+      [batch_size, num_boxes, mask_height, mask_width] containing masks for each
+      detection box.
+
+  Args:
+    postprocessed_tensors: a dictionary containing the following fields
+      'detection_boxes': [batch, max_detections, 4]
+      'detection_scores': [batch, max_detections]
+      'detection_classes': [batch, max_detections]
+      'detection_masks': [batch, max_detections, mask_height, mask_width]
+        (optional).
+      'num_detections': [batch]
+
+  Returns:
+    A tensor dict containing the added output tensor nodes.
+  """
+  label_id_offset = 1
+  boxes = postprocessed_tensors.get('detection_boxes')
+  scores = postprocessed_tensors.get('detection_scores')
+  classes = postprocessed_tensors.get('detection_classes') + label_id_offset
+  masks = postprocessed_tensors.get('detection_masks')
+  num_detections = postprocessed_tensors.get('num_detections')
+  outputs = {}
+  outputs['detection_boxes'] = tf.identity(boxes, name='detection_boxes')
+  outputs['detection_scores'] = tf.identity(scores, name='detection_scores')
+  outputs['detection_classes'] = tf.identity(classes, name='detection_classes')
+  outputs['num_detections'] = tf.identity(num_detections, name='num_detections')
+  if masks is not None:
+    outputs['detection_masks'] = tf.identity(masks, name='detection_masks')
+  return outputs
+
+
+def _write_inference_graph(inference_graph_path,
+                           checkpoint_path=None,
+                           use_moving_averages=False,
+                           output_node_names=(
+                               'num_detections,detection_scores,'
+                               'detection_boxes,detection_classes')):
+  """Writes inference graph to disk with the option to bake in weights.
+
+  If checkpoint_path is not None bakes the weights into the graph thereby
+  eliminating the need of checkpoint files during inference. If the model
+  was trained with moving averages, setting use_moving_averages to true
+  restores the moving averages, otherwise the original set of variables
+  is restored.
+
+  Args:
+    inference_graph_path: Path to write inference graph.
+    checkpoint_path: Optional path to the checkpoint file.
+    use_moving_averages: Whether to export the original or the moving averages
+      of the trainable variables from the checkpoint.
+    output_node_names: Output tensor names, defaults are: num_detections,
+      detection_scores, detection_boxes, detection_classes.
+  """
+  inference_graph_def = tf.get_default_graph().as_graph_def()
+  if checkpoint_path:
+    output_graph_def = get_frozen_graph_def(
+        inference_graph_def=inference_graph_def,
+        use_moving_averages=use_moving_averages,
+        input_checkpoint=checkpoint_path,
+        output_node_names=output_node_names,
+    )
+
+    with gfile.GFile(inference_graph_path, 'wb') as f:
+      f.write(output_graph_def.SerializeToString())
+    logging.info('%d ops in the final graph.', len(output_graph_def.node))
+
+    return
+  tf.train.write_graph(inference_graph_def,
+                       os.path.dirname(inference_graph_path),
+                       os.path.basename(inference_graph_path),
+                       as_text=False)
+
+
+def _write_saved_model(inference_graph_path, inputs, outputs,
+                       checkpoint_path=None, use_moving_averages=False):
+  """Writes SavedModel to disk.
+
+  If checkpoint_path is not None bakes the weights into the graph thereby
+  eliminating the need of checkpoint files during inference. If the model
+  was trained with moving averages, setting use_moving_averages to true
+  restores the moving averages, otherwise the original set of variables
+  is restored.
+
+  Args:
+    inference_graph_path: Path to write inference graph.
+    inputs: The input image tensor to use for detection.
+    outputs: A tensor dictionary containing the outputs of a DetectionModel.
+    checkpoint_path: Optional path to the checkpoint file.
+    use_moving_averages: Whether to export the original or the moving averages
+      of the trainable variables from the checkpoint.
+  """
+  inference_graph_def = tf.get_default_graph().as_graph_def()
+  checkpoint_graph_def = None
+  if checkpoint_path:
+    output_node_names = ','.join(outputs.keys())
+    checkpoint_graph_def = get_frozen_graph_def(
+        inference_graph_def=inference_graph_def,
+        use_moving_averages=use_moving_averages,
+        input_checkpoint=checkpoint_path,
+        output_node_names=output_node_names
+    )
+
+  with tf.Graph().as_default():
+    with session.Session() as sess:
+
+      tf.import_graph_def(checkpoint_graph_def)
+
+      builder = tf.saved_model.builder.SavedModelBuilder(inference_graph_path)
+
+      tensor_info_inputs = {
+          'inputs': tf.saved_model.utils.build_tensor_info(inputs)}
+      tensor_info_outputs = {}
+      for k, v in outputs.items():
+        tensor_info_outputs[k] = tf.saved_model.utils.build_tensor_info(v)
+
+      detection_signature = (
+          tf.saved_model.signature_def_utils.build_signature_def(
+              inputs=tensor_info_inputs,
+              outputs=tensor_info_outputs,
+              method_name=signature_constants.PREDICT_METHOD_NAME))
+
+      builder.add_meta_graph_and_variables(
+          sess, [tf.saved_model.tag_constants.SERVING],
+          signature_def_map={
+              signature_constants.DEFAULT_SERVING_SIGNATURE_DEF_KEY:
+                  detection_signature,
+          },
+      )
+      builder.save()
+
+
+def _export_inference_graph(input_type,
+                            detection_model,
+                            use_moving_averages,
+                            checkpoint_path,
+                            inference_graph_path,
+                            export_as_saved_model=False):
+  """Export helper."""
+  if input_type not in input_placeholder_fn_map:
+    raise ValueError('Unknown input type: {}'.format(input_type))
+  inputs = tf.to_float(input_placeholder_fn_map[input_type]())
+  preprocessed_inputs = detection_model.preprocess(inputs)
+  output_tensors = detection_model.predict(preprocessed_inputs)
+  postprocessed_tensors = detection_model.postprocess(output_tensors)
+  outputs = _add_output_tensor_nodes(postprocessed_tensors)
+  out_node_names = list(outputs.keys())
+  if export_as_saved_model:
+    _write_saved_model(inference_graph_path, inputs, outputs, checkpoint_path,
+                       use_moving_averages)
+  else:
+    _write_inference_graph(inference_graph_path, checkpoint_path,
+                           use_moving_averages,
+                           output_node_names=','.join(out_node_names))
+
+
+def export_inference_graph(input_type, pipeline_config, checkpoint_path,
+                           inference_graph_path, export_as_saved_model=False):
+  """Exports inference graph for the model specified in the pipeline config.
+
+  Args:
+    input_type: Type of input for the graph. Can be one of [`image_tensor`,
+      `tf_example`].
+    pipeline_config: pipeline_pb2.TrainAndEvalPipelineConfig proto.
+    checkpoint_path: Path to the checkpoint file to freeze.
+    inference_graph_path: Path to write inference graph to.
+    export_as_saved_model: If the model should be exported as a SavedModel. If
+                           false, it is saved as an inference graph.
+  """
+  detection_model = model_builder.build(pipeline_config.model,
+                                        is_training=False)
+  _export_inference_graph(input_type, detection_model,
+                          pipeline_config.eval_config.use_moving_averages,
+                          checkpoint_path, inference_graph_path,
+                          export_as_saved_model)

object_detection/exporter_test.py

+# Copyright 2017 The TensorFlow Authors. All Rights Reserved.
+#
+# Licensed under the Apache License, Version 2.0 (the "License");
+# you may not use this file except in compliance with the License.
+# You may obtain a copy of the License at
+#
+#     http://www.apache.org/licenses/LICENSE-2.0
+#
+# Unless required by applicable law or agreed to in writing, software
+# distributed under the License is distributed on an "AS IS" BASIS,
+# WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
+# See the License for the specific language governing permissions and
+# limitations under the License.
+# ==============================================================================
+
+"""Tests for object_detection.export_inference_graph."""
+import os
+import numpy as np
+import six
+import tensorflow as tf
+from object_detection import exporter
+from object_detection.builders import model_builder
+from object_detection.core import model
+from object_detection.protos import pipeline_pb2
+
+if six.PY2:
+  import mock  # pylint: disable=g-import-not-at-top
+else:
+  from unittest import mock  # pylint: disable=g-import-not-at-top
+
+
+class FakeModel(model.DetectionModel):
+
+  def __init__(self, add_detection_masks=False):
+    self._add_detection_masks = add_detection_masks
+
+  def preprocess(self, inputs):
+    return tf.identity(inputs)
+
+  def predict(self, preprocessed_inputs):
+    return {'image': tf.layers.conv2d(preprocessed_inputs, 3, 1)}
+
+  def postprocess(self, prediction_dict):
+    with tf.control_dependencies(prediction_dict.values()):
+      postprocessed_tensors = {
+          'detection_boxes': tf.constant([[0.0, 0.0, 0.5, 0.5],
+                                          [0.5, 0.5, 0.8, 0.8]], tf.float32),
+          'detection_scores': tf.constant([[0.7, 0.6]], tf.float32),
+          'detection_classes': tf.constant([[0, 1]], tf.float32),
+          'num_detections': tf.constant([2], tf.float32)
+      }
+      if self._add_detection_masks:
+        postprocessed_tensors['detection_masks'] = tf.constant(
+            np.arange(32).reshape([2, 4, 4]), tf.float32)
+    return postprocessed_tensors
+
+  def restore_fn(self, checkpoint_path, from_detection_checkpoint):
+    pass
+
+  def loss(self, prediction_dict):
+    pass
+
+
+class ExportInferenceGraphTest(tf.test.TestCase):
+
+  def _save_checkpoint_from_mock_model(self, checkpoint_path,
+                                       use_moving_averages):
+    g = tf.Graph()
+    with g.as_default():
+      mock_model = FakeModel()
+      preprocessed_inputs = mock_model.preprocess(
+          tf.ones([1, 3, 4, 3], tf.float32))
+      predictions = mock_model.predict(preprocessed_inputs)
+      mock_model.postprocess(predictions)
+      if use_moving_averages:
+        tf.train.ExponentialMovingAverage(0.0).apply()
+      saver = tf.train.Saver()
+      init = tf.global_variables_initializer()
+      with self.test_session() as sess:
+        sess.run(init)
+        saver.save(sess, checkpoint_path)
+
+  def _load_inference_graph(self, inference_graph_path):
+    od_graph = tf.Graph()
+    with od_graph.as_default():
+      od_graph_def = tf.GraphDef()
+      with tf.gfile.GFile(inference_graph_path) as fid:
+        serialized_graph = fid.read()
+        od_graph_def.ParseFromString(serialized_graph)
+        tf.import_graph_def(od_graph_def, name='')
+    return od_graph
+
+  def _create_tf_example(self, image_array):
+    with self.test_session():
+      encoded_image = tf.image.encode_jpeg(tf.constant(image_array)).eval()
+    def _bytes_feature(value):
+      return tf.train.Feature(bytes_list=tf.train.BytesList(value=[value]))
+    example = tf.train.Example(features=tf.train.Features(feature={
+        'image/encoded': _bytes_feature(encoded_image),
+        'image/format': _bytes_feature('jpg'),
+        'image/source_id': _bytes_feature('image_id')
+    })).SerializeToString()
+    return example
+
+  def test_export_graph_with_image_tensor_input(self):
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel()
+      inference_graph_path = os.path.join(self.get_temp_dir(),
+                                          'exported_graph.pbtxt')
+
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      pipeline_config.eval_config.use_moving_averages = False
+      exporter.export_inference_graph(
+          input_type='image_tensor',
+          pipeline_config=pipeline_config,
+          checkpoint_path=None,
+          inference_graph_path=inference_graph_path)
+
+  def test_export_graph_with_tf_example_input(self):
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel()
+      inference_graph_path = os.path.join(self.get_temp_dir(),
+                                          'exported_graph.pbtxt')
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      pipeline_config.eval_config.use_moving_averages = False
+      exporter.export_inference_graph(
+          input_type='tf_example',
+          pipeline_config=pipeline_config,
+          checkpoint_path=None,
+          inference_graph_path=inference_graph_path)
+
+  def test_export_graph_with_encoded_image_string_input(self):
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel()
+      inference_graph_path = os.path.join(self.get_temp_dir(),
+                                          'exported_graph.pbtxt')
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      pipeline_config.eval_config.use_moving_averages = False
+      exporter.export_inference_graph(
+          input_type='encoded_image_string_tensor',
+          pipeline_config=pipeline_config,
+          checkpoint_path=None,
+          inference_graph_path=inference_graph_path)
+
+  def test_export_frozen_graph(self):
+    checkpoint_path = os.path.join(self.get_temp_dir(), 'model-ckpt')
+    self._save_checkpoint_from_mock_model(checkpoint_path,
+                                          use_moving_averages=False)
+    inference_graph_path = os.path.join(self.get_temp_dir(),
+                                        'exported_graph.pb')
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel()
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      pipeline_config.eval_config.use_moving_averages = False
+      exporter.export_inference_graph(
+          input_type='image_tensor',
+          pipeline_config=pipeline_config,
+          checkpoint_path=checkpoint_path,
+          inference_graph_path=inference_graph_path)
+
+  def test_export_frozen_graph_with_moving_averages(self):
+    checkpoint_path = os.path.join(self.get_temp_dir(), 'model-ckpt')
+    self._save_checkpoint_from_mock_model(checkpoint_path,
+                                          use_moving_averages=True)
+    inference_graph_path = os.path.join(self.get_temp_dir(),
+                                        'exported_graph.pb')
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel()
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      pipeline_config.eval_config.use_moving_averages = True
+      exporter.export_inference_graph(
+          input_type='image_tensor',
+          pipeline_config=pipeline_config,
+          checkpoint_path=checkpoint_path,
+          inference_graph_path=inference_graph_path)
+
+  def test_export_model_with_all_output_nodes(self):
+    checkpoint_path = os.path.join(self.get_temp_dir(), 'model-ckpt')
+    self._save_checkpoint_from_mock_model(checkpoint_path,
+                                          use_moving_averages=False)
+    inference_graph_path = os.path.join(self.get_temp_dir(),
+                                        'exported_graph.pb')
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel(add_detection_masks=True)
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      exporter.export_inference_graph(
+          input_type='image_tensor',
+          pipeline_config=pipeline_config,
+          checkpoint_path=checkpoint_path,
+          inference_graph_path=inference_graph_path)
+    inference_graph = self._load_inference_graph(inference_graph_path)
+    with self.test_session(graph=inference_graph):
+      inference_graph.get_tensor_by_name('image_tensor:0')
+      inference_graph.get_tensor_by_name('detection_boxes:0')
+      inference_graph.get_tensor_by_name('detection_scores:0')
+      inference_graph.get_tensor_by_name('detection_classes:0')
+      inference_graph.get_tensor_by_name('detection_masks:0')
+      inference_graph.get_tensor_by_name('num_detections:0')
+
+  def test_export_model_with_detection_only_nodes(self):
+    checkpoint_path = os.path.join(self.get_temp_dir(), 'model-ckpt')
+    self._save_checkpoint_from_mock_model(checkpoint_path,
+                                          use_moving_averages=False)
+    inference_graph_path = os.path.join(self.get_temp_dir(),
+                                        'exported_graph.pb')
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel(add_detection_masks=False)
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      exporter.export_inference_graph(
+          input_type='image_tensor',
+          pipeline_config=pipeline_config,
+          checkpoint_path=checkpoint_path,
+          inference_graph_path=inference_graph_path)
+    inference_graph = self._load_inference_graph(inference_graph_path)
+    with self.test_session(graph=inference_graph):
+      inference_graph.get_tensor_by_name('image_tensor:0')
+      inference_graph.get_tensor_by_name('detection_boxes:0')
+      inference_graph.get_tensor_by_name('detection_scores:0')
+      inference_graph.get_tensor_by_name('detection_classes:0')
+      inference_graph.get_tensor_by_name('num_detections:0')
+      with self.assertRaises(KeyError):
+        inference_graph.get_tensor_by_name('detection_masks:0')
+
+  def test_export_and_run_inference_with_image_tensor(self):
+    checkpoint_path = os.path.join(self.get_temp_dir(), 'model-ckpt')
+    self._save_checkpoint_from_mock_model(checkpoint_path,
+                                          use_moving_averages=False)
+    inference_graph_path = os.path.join(self.get_temp_dir(),
+                                        'exported_graph.pb')
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel(add_detection_masks=True)
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      pipeline_config.eval_config.use_moving_averages = False
+      exporter.export_inference_graph(
+          input_type='image_tensor',
+          pipeline_config=pipeline_config,
+          checkpoint_path=checkpoint_path,
+          inference_graph_path=inference_graph_path)
+
+    inference_graph = self._load_inference_graph(inference_graph_path)
+    with self.test_session(graph=inference_graph) as sess:
+      image_tensor = inference_graph.get_tensor_by_name('image_tensor:0')
+      boxes = inference_graph.get_tensor_by_name('detection_boxes:0')
+      scores = inference_graph.get_tensor_by_name('detection_scores:0')
+      classes = inference_graph.get_tensor_by_name('detection_classes:0')
+      masks = inference_graph.get_tensor_by_name('detection_masks:0')
+      num_detections = inference_graph.get_tensor_by_name('num_detections:0')
+      (boxes, scores, classes, masks, num_detections) = sess.run(
+          [boxes, scores, classes, masks, num_detections],
+          feed_dict={image_tensor: np.ones((1, 4, 4, 3)).astype(np.uint8)})
+      self.assertAllClose(boxes, [[0.0, 0.0, 0.5, 0.5],
+                                  [0.5, 0.5, 0.8, 0.8]])
+      self.assertAllClose(scores, [[0.7, 0.6]])
+      self.assertAllClose(classes, [[1, 2]])
+      self.assertAllClose(masks, np.arange(32).reshape([2, 4, 4]))
+      self.assertAllClose(num_detections, [2])
+
+  def _create_encoded_image_string(self, image_array_np, encoding_format):
+    od_graph = tf.Graph()
+    with od_graph.as_default():
+      if encoding_format == 'jpg':
+        encoded_string = tf.image.encode_jpeg(image_array_np)
+      elif encoding_format == 'png':
+        encoded_string = tf.image.encode_png(image_array_np)
+      else:
+        raise ValueError('Supports only the following formats: `jpg`, `png`')
+    with self.test_session(graph=od_graph):
+      return encoded_string.eval()
+
+  def test_export_and_run_inference_with_encoded_image_string_tensor(self):
+    checkpoint_path = os.path.join(self.get_temp_dir(), 'model-ckpt')
+    self._save_checkpoint_from_mock_model(checkpoint_path,
+                                          use_moving_averages=False)
+    inference_graph_path = os.path.join(self.get_temp_dir(),
+                                        'exported_graph.pb')
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel(add_detection_masks=True)
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      pipeline_config.eval_config.use_moving_averages = False
+      exporter.export_inference_graph(
+          input_type='encoded_image_string_tensor',
+          pipeline_config=pipeline_config,
+          checkpoint_path=checkpoint_path,
+          inference_graph_path=inference_graph_path)
+
+    inference_graph = self._load_inference_graph(inference_graph_path)
+    jpg_image_str = self._create_encoded_image_string(
+        np.ones((4, 4, 3)).astype(np.uint8), 'jpg')
+    png_image_str = self._create_encoded_image_string(
+        np.ones((4, 4, 3)).astype(np.uint8), 'png')
+    with self.test_session(graph=inference_graph) as sess:
+      image_str_tensor = inference_graph.get_tensor_by_name(
+          'encoded_image_string_tensor:0')
+      boxes = inference_graph.get_tensor_by_name('detection_boxes:0')
+      scores = inference_graph.get_tensor_by_name('detection_scores:0')
+      classes = inference_graph.get_tensor_by_name('detection_classes:0')
+      masks = inference_graph.get_tensor_by_name('detection_masks:0')
+      num_detections = inference_graph.get_tensor_by_name('num_detections:0')
+      for image_str in [jpg_image_str, png_image_str]:
+        (boxes_np, scores_np, classes_np, masks_np,
+         num_detections_np) = sess.run(
+             [boxes, scores, classes, masks, num_detections],
+             feed_dict={image_str_tensor: image_str})
+        self.assertAllClose(boxes_np, [[0.0, 0.0, 0.5, 0.5],
+                                       [0.5, 0.5, 0.8, 0.8]])
+        self.assertAllClose(scores_np, [[0.7, 0.6]])
+        self.assertAllClose(classes_np, [[1, 2]])
+        self.assertAllClose(masks_np, np.arange(32).reshape([2, 4, 4]))
+        self.assertAllClose(num_detections_np, [2])
+
+  def test_export_and_run_inference_with_tf_example(self):
+    checkpoint_path = os.path.join(self.get_temp_dir(), 'model-ckpt')
+    self._save_checkpoint_from_mock_model(checkpoint_path,
+                                          use_moving_averages=False)
+    inference_graph_path = os.path.join(self.get_temp_dir(),
+                                        'exported_graph.pb')
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel(add_detection_masks=True)
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      pipeline_config.eval_config.use_moving_averages = False
+      exporter.export_inference_graph(
+          input_type='tf_example',
+          pipeline_config=pipeline_config,
+          checkpoint_path=checkpoint_path,
+          inference_graph_path=inference_graph_path)
+
+    inference_graph = self._load_inference_graph(inference_graph_path)
+    with self.test_session(graph=inference_graph) as sess:
+      tf_example = inference_graph.get_tensor_by_name('tf_example:0')
+      boxes = inference_graph.get_tensor_by_name('detection_boxes:0')
+      scores = inference_graph.get_tensor_by_name('detection_scores:0')
+      classes = inference_graph.get_tensor_by_name('detection_classes:0')
+      masks = inference_graph.get_tensor_by_name('detection_masks:0')
+      num_detections = inference_graph.get_tensor_by_name('num_detections:0')
+      (boxes, scores, classes, masks, num_detections) = sess.run(
+          [boxes, scores, classes, masks, num_detections],
+          feed_dict={tf_example: self._create_tf_example(
+              np.ones((4, 4, 3)).astype(np.uint8))})
+      self.assertAllClose(boxes, [[0.0, 0.0, 0.5, 0.5],
+                                  [0.5, 0.5, 0.8, 0.8]])
+      self.assertAllClose(scores, [[0.7, 0.6]])
+      self.assertAllClose(classes, [[1, 2]])
+      self.assertAllClose(masks, np.arange(32).reshape([2, 4, 4]))
+      self.assertAllClose(num_detections, [2])
+
+  def test_export_saved_model_and_run_inference(self):
+    checkpoint_path = os.path.join(self.get_temp_dir(), 'model-ckpt')
+    self._save_checkpoint_from_mock_model(checkpoint_path,
+                                          use_moving_averages=False)
+    inference_graph_path = os.path.join(self.get_temp_dir(),
+                                        'saved_model')
+
+    with mock.patch.object(
+        model_builder, 'build', autospec=True) as mock_builder:
+      mock_builder.return_value = FakeModel(add_detection_masks=True)
+      pipeline_config = pipeline_pb2.TrainEvalPipelineConfig()
+      pipeline_config.eval_config.use_moving_averages = False
+      exporter.export_inference_graph(
+          input_type='tf_example',
+          pipeline_config=pipeline_config,
+          checkpoint_path=checkpoint_path,
+          inference_graph_path=inference_graph_path,
+          export_as_saved_model=True)
+
+    with tf.Graph().as_default() as od_graph:
+      with self.test_session(graph=od_graph) as sess:
+        tf.saved_model.loader.load(
+            sess, [tf.saved_model.tag_constants.SERVING], inference_graph_path)
+        tf_example = od_graph.get_tensor_by_name('import/tf_example:0')
+        boxes = od_graph.get_tensor_by_name('import/detection_boxes:0')
+        scores = od_graph.get_tensor_by_name('import/detection_scores:0')
+        classes = od_graph.get_tensor_by_name('import/detection_classes:0')
+        masks = od_graph.get_tensor_by_name('import/detection_masks:0')
+        num_detections = od_graph.get_tensor_by_name('import/num_detections:0')
+        (boxes, scores, classes, masks, num_detections) = sess.run(
+            [boxes, scores, classes, masks, num_detections],
+            feed_dict={tf_example: self._create_tf_example(
+                np.ones((4, 4, 3)).astype(np.uint8))})
+        self.assertAllClose(boxes, [[0.0, 0.0, 0.5, 0.5],
+                                    [0.5, 0.5, 0.8, 0.8]])
+        self.assertAllClose(scores, [[0.7, 0.6]])
+        self.assertAllClose(classes, [[1, 2]])
+        self.assertAllClose(masks, np.arange(32).reshape([2, 4, 4]))
+        self.assertAllClose(num_detections, [2])
+
+if __name__ == '__main__':
+  tf.test.main()

object_detection/g3doc/configuring_jobs.md

+# Configuring the Object Detection Training Pipeline
+
+## Overview
+
+The Tensorflow Object Detection API uses protobuf files to configure the
+training and evaluation process. The schema for the training pipeline can be
+found in object_detection/protos/pipeline.proto. At a high level, the config
+file is split into 5 parts:
+
+1. The `model` configuration. This defines what type of model will be trained
+(ie. meta-architecture, feature extractor).
+2. The `train_config`, which decides what parameters should be used to train
+model parameters (ie. SGD parameters, input preprocessing and feature extractor
+initialization values).
+3. The `eval_config`, which determines what set of metrics will be reported for
+evaluation (currently we only support the PASCAL VOC metrics).
+4. The `train_input_config`, which defines what dataset the model should be
+trained on.
+5. The `eval_input_config`, which defines what dataset the model will be
+evaluated on. Typically this should be different than the training input
+dataset.
+
+A skeleton configuration file is shown below:
+
+```
+model {
+(... Add model config here...)
+}
+
+train_config : {
+(... Add train_config here...)
+}
+
+train_input_reader: {
+(... Add train_input configuration here...)
+}
+
+eval_config: {
+}
+
+eval_input_reader: {
+(... Add eval_input configuration here...)
+}
+```
+
+## Picking Model Parameters
+
+There are a large number of model parameters to configure. The best settings
+will depend on your given application. Faster R-CNN models are better suited to
+cases where high accuracy is desired and latency is of lower priority.
+Conversely, if processing time is the most important factor, SSD models are
+recommended. Read [our paper](https://arxiv.org/abs/1611.10012) for a more
+detailed discussion on the speed vs accuracy tradeoff.
+
+To help new users get started, sample model configurations have been provided
+in the object_detection/samples/model_configs folder. The contents of these
+configuration files can be pasted into `model` field of the skeleton
+configuration. Users should note that the `num_classes` field should be changed
+to a value suited for the dataset the user is training on.
+
+## Defining Inputs
+
+The Tensorflow Object Detection API accepts inputs in the TFRecord file format.
+Users must specify the locations of both the training and evaluation files.
+Additionally, users should also specify a label map, which define the mapping
+between a class id and class name. The label map should be identical between
+training and evaluation datasets.
+
+An example input configuration looks as follows:
+
+```
+tf_record_input_reader {
+  input_path: "/usr/home/username/data/train.record"
+}
+label_map_path: "/usr/home/username/data/label_map.pbtxt"
+```
+
+Users should substitute the `input_path` and `label_map_path` arguments and
+insert the input configuration into the `train_input_reader` and
+`eval_input_reader` fields in the skeleton configuration. Note that the paths
+can also point to Google Cloud Storage buckets (ie.
+"gs://project_bucket/train.record") for use on Google Cloud.
+
+## Configuring the Trainer
+
+The `train_config` defines parts of the training process:
+
+1. Model parameter initialization.
+2. Input preprocessing.
+3. SGD parameters.
+
+A sample `train_config` is below:
+
+```
+batch_size: 1
+optimizer {
+  momentum_optimizer: {
+    learning_rate: {
+      manual_step_learning_rate {
+        initial_learning_rate: 0.0002
+        schedule {
+          step: 0
+          learning_rate: .0002
+        }
+        schedule {
+          step: 900000
+          learning_rate: .00002
+        }
+        schedule {
+          step: 1200000
+          learning_rate: .000002
+        }
+      }
+    }
+    momentum_optimizer_value: 0.9
+  }
+  use_moving_average: false
+}
+fine_tune_checkpoint: "/usr/home/username/tmp/model.ckpt-#####"
+from_detection_checkpoint: true
+gradient_clipping_by_norm: 10.0
+data_augmentation_options {
+  random_horizontal_flip {
+  }
+}
+```
+
+### Model Parameter Initialization
+
+While optional, it is highly recommended that users utilize other object
+detection checkpoints. Training an object detector from scratch can take days.
+To speed up the training process, it is recommended that users re-use the
+feature extractor parameters from a pre-existing object classification or
+detection checkpoint. `train_config` provides two fields to specify
+pre-existing checkpoints: `fine_tune_checkpoint` and
+`from_detection_checkpoint`. `fine_tune_checkpoint` should provide a path to
+the pre-existing checkpoint
+(ie:"/usr/home/username/checkpoint/model.ckpt-#####").
+`from_detection_checkpoint` is a boolean value. If false, it assumes the
+checkpoint was from an object classification checkpoint. Note that starting
+from a detection checkpoint will usually result in a faster training job than
+a classification checkpoint.
+
+The list of provided checkpoints can be found [here](detection_model_zoo.md).
+
+### Input Preprocessing
+
+The `data_augmentation_options` in `train_config` can be used to specify
+how training data can be modified. This field is optional.
+
+### SGD Parameters
+
+The remainings parameters in `train_config` are hyperparameters for gradient
+descent. Please note that the optimal learning rates provided in these
+configuration files may depend on the specifics of the training setup (e.g.
+number of workers, gpu type).
+
+## Configuring the Evaluator
+
+Currently evaluation is fixed to generating metrics as defined by the PASCAL
+VOC challenge. The parameters for `eval_config` are set to reasonable defaults
+and typically do not need to be configured.

object_detection/g3doc/defining_your_own_model.md

+# So you want to create a new model!
+
+In this section, we discuss some of the abstractions that we use
+for defining detection models. If you would like to define a new model
+architecture for detection and use it in the Tensorflow Detection API,
+then this section should also serve as a high level guide to the files that you
+will need to edit to get your new model working.
+
+## DetectionModels (`object_detection/core/model.py`)
+
+In order to be trained, evaluated, and exported for serving  using our
+provided binaries, all models under the Tensorflow Object Detection API must
+implement the `DetectionModel` interface (see the full definition in `object_detection/core/model.py`).  In particular,
+each of these models are responsible for implementing 5 functions:
+
+* `preprocess`: Run any preprocessing (e.g., scaling/shifting/reshaping) of
+  input values that is necessary prior to running the detector on an input
+  image.
+* `predict`: Produce “raw” prediction tensors that can be passed to loss or
+  postprocess functions.
+* `postprocess`: Convert predicted output tensors to final detections.
+* `loss`: Compute scalar loss tensors with respect to provided groundtruth.
+* `restore`: Load a checkpoint into the Tensorflow graph.
+
+Given a `DetectionModel` at training time, we pass each image batch through
+the following sequence of functions to compute a loss which can be optimized via
+SGD:
+
+```
+inputs (images tensor) -> preprocess -> predict -> loss -> outputs (loss tensor)
+```
+
+And at eval time, we pass each image batch through the following sequence of
+functions to produce a set of detections:
+
+```
+inputs (images tensor) -> preprocess -> predict -> postprocess ->
+  outputs (boxes tensor, scores tensor, classes tensor, num_detections tensor)
+```
+
+Some conventions to be aware of:
+
+* `DetectionModel`s should make no assumptions about the input size or aspect
+  ratio --- they are responsible for doing any resize/reshaping necessary
+  (see docstring for the `preprocess` function).
+* Output classes are always integers in the range `[0, num_classes)`.
+  Any mapping of these integers to semantic labels is to be handled outside
+  of this class.  We never explicitly emit a “background class” --- thus 0 is
+  the first non-background class and any logic of predicting and removing
+  implicit background classes must be handled internally by the implementation.
+* Detected boxes are to be interpreted as being in
+  `[y_min, x_min, y_max, x_max]` format and normalized relative to the
+  image window.
+* We do not specifically assume any kind of probabilistic interpretation of the
+  scores --- the only important thing is their relative ordering. Thus
+  implementations of the postprocess function are free to output logits,
+  probabilities, calibrated probabilities, or anything else.
+
+## Defining a new Faster R-CNN or SSD Feature Extractor
+
+In most cases, you probably will not implement a `DetectionModel` from scratch
+--- instead you might create a new feature extractor to be used by one of the
+SSD or Faster R-CNN meta-architectures.  (We think of meta-architectures as
+classes that define entire families of models using the `DetectionModel`
+abstraction).
+
+Note: For the following discussion to make sense, we recommend first becoming
+familiar with the [Faster R-CNN](https://arxiv.org/abs/1506.01497) paper.
+
+Let’s now imagine that you have invented a brand new network architecture
+(say, “InceptionV100”) for classification and want to see how InceptionV100
+would behave as a feature extractor for detection (say, with Faster R-CNN).
+A similar procedure would hold for SSD models, but we’ll discuss Faster R-CNN.
+
+To use InceptionV100, we will have to define a new
+`FasterRCNNFeatureExtractor` and pass it to our `FasterRCNNMetaArch`
+constructor as input.  See
+`object_detection/meta_architectures/faster_rcnn_meta_arch.py` for definitions
+of `FasterRCNNFeatureExtractor` and `FasterRCNNMetaArch`, respectively.
+A `FasterRCNNFeatureExtractor` must define a few
+functions:
+
+* `preprocess`: Run any preprocessing of input values that is necessary prior
+  to running the detector on an input image.
+* `_extract_proposal_features`: Extract first stage Region Proposal Network
+  (RPN) features.
+* `_extract_box_classifier_features`: Extract second stage Box Classifier
+  features.
+* `restore_from_classification_checkpoint_fn`: Load a checkpoint into the
+  Tensorflow graph.
+
+See the `object_detection/models/faster_rcnn_resnet_v1_feature_extractor.py`
+definition as one example. Some remarks:
+
+* We typically initialize the weights of this feature extractor
+  using those from the
+  [Slim Resnet-101 classification checkpoint](https://github.com/tensorflow/models/tree/master/slim#pre-trained-models),
+  and we know
+  that images were preprocessed when training this checkpoint
+  by subtracting a channel mean from each input
+  image.  Thus, we implement the preprocess function to replicate the same
+  channel mean subtraction behavior.
+* The “full” resnet classification network defined in slim is cut into two
+  parts --- all but the last “resnet block” is put into the
+  `_extract_proposal_features` function and the final block is separately
+  defined in the `_extract_box_classifier_features function`.  In general,
+  some experimentation may be required to decide on an optimal layer at
+  which to “cut” your feature extractor into these two pieces for Faster R-CNN.
+
+## Register your model for configuration
+
+Assuming that your new feature extractor does not require nonstandard
+configuration, you will want to ideally be able to simply change the
+“feature_extractor.type” fields in your configuration protos to point to a
+new feature extractor.  In order for our API to know how to understand this
+new type though, you will first have to register your new feature
+extractor with the model builder (`object_detection/builders/model_builder.py`),
+whose job is to create models from config protos..
+
+Registration is simple --- just add a pointer to the new Feature Extractor
+class that you have defined in one of the SSD or Faster R-CNN Feature
+Extractor Class maps at the top of the
+`object_detection/builders/model_builder.py` file.
+We recommend adding a test in `object_detection/builders/model_builder_test.py`
+to make sure that parsing your proto will work as expected.
+
+## Taking your new model for a spin
+
+After registration you are ready to go with your model!  Some final tips:
+
+* To save time debugging, try running your configuration file locally first
+  (both training and evaluation).
+* Do a sweep of learning rates to figure out which learning rate is best
+  for your model.
+* A small but often important detail: you may find it necessary to disable
+  batchnorm training (that is, load the batch norm parameters from the
+  classification checkpoint, but do not update them during gradient descent).

object_detection/g3doc/detection_model_zoo.md

+# Tensorflow detection model zoo
+
+We provide a collection of detection models pre-trained on the
+[COCO dataset](http://mscoco.org).
+These models can be useful for out-of-the-box inference if you are interested
+in categories already in COCO (e.g., humans, cars, etc).
+They are also useful for initializing your models when training on novel
+datasets.
+
+In the table below, we list each such pre-trained model including:
+
+* a model name that corresponds to a config file that was used to train this
+  model in the `samples/configs` directory,
+* a download link to a tar.gz file containing the pre-trained model,
+* model speed (one of {slow, medium, fast}),
+* detector performance on COCO data as measured by the COCO mAP measure.
+  Here, higher is better, and we only report bounding box mAP rounded to the
+  nearest integer.
+* Output types (currently only `Boxes`)
+
+You can un-tar each tar.gz file via, e.g.,:
+
+```
+tar -xzvf ssd_mobilenet_v1_coco.tar.gz
+```
+
+Inside the un-tar'ed directory, you will find:
+
+* a graph proto (`graph.pbtxt`)
+* a checkpoint
+  (`model.ckpt.data-00000-of-00001`, `model.ckpt.index`, `model.ckpt.meta`)
+* a frozen graph proto with weights baked into the graph as constants
+  (`frozen_inference_graph.pb`) to be used for out of the box inference
+    (try this out in the Jupyter notebook!)
+
+| Model name  | Speed | COCO mAP | Outputs |
+| ------------ | :--------------: | :--------------: | :-------------: |
+| [ssd_mobilenet_v1_coco](http://download.tensorflow.org/models/object_detection/ssd_mobilenet_v1_coco_11_06_2017.tar.gz) | fast | 21 | Boxes |
+| [ssd_inception_v2_coco](http://download.tensorflow.org/models/object_detection/ssd_inception_v2_coco_11_06_2017.tar.gz) | fast | 24 | Boxes |
+| [rfcn_resnet101_coco](http://download.tensorflow.org/models/object_detection/rfcn_resnet101_coco_11_06_2017.tar.gz)  | medium | 30 | Boxes |
+| [faster_rcnn_resnet101_coco](http://download.tensorflow.org/models/object_detection/faster_rcnn_resnet101_coco_11_06_2017.tar.gz) | medium | 32 | Boxes |
+| [faster_rcnn_inception_resnet_v2_atrous_coco](http://download.tensorflow.org/models/object_detection/faster_rcnn_inception_resnet_v2_atrous_coco_11_06_2017.tar.gz) | slow | 37 | Boxes |

object_detection/g3doc/exporting_models.md

+# Exporting a trained model for inference
+
+After your model has been trained, you should export it to a Tensorflow
+graph proto. A checkpoint will typically consist of three files:
+
+* model.ckpt-${CHECKPOINT_NUMBER}.data-00000-of-00001,
+* model.ckpt-${CHECKPOINT_NUMBER}.index
+* model.ckpt-${CHECKPOINT_NUMBER}.meta
+
+After you've identified a candidate checkpoint to export, run the following
+command from tensorflow/models/object_detection:
+
+``` bash
+# From tensorflow/models
+python object_detection/export_inference_graph \
+    --input_type image_tensor \
+    --pipeline_config_path ${PIPELINE_CONFIG_PATH} \
+    --checkpoint_path model.ckpt-${CHECKPOINT_NUMBER} \
+    --inference_graph_path output_inference_graph.pb
+```
+
+Afterwards, you should see a graph named output_inference_graph.pb.

object_detection/g3doc/installation.md

+# Installation
+
+## Dependencies
+
+Tensorflow Object Detection API depends on the following libraries:
+
+* Protobuf 2.6
+* Pillow 1.0
+* lxml
+* tf Slim (which is included in the "tensorflow/models" checkout)
+* Jupyter notebook
+* Matplotlib
+* Tensorflow
+
+For detailed steps to install Tensorflow, follow the
+[Tensorflow installation instructions](https://www.tensorflow.org/install/).
+A typically user can install Tensorflow using one of the following commands:
+
+``` bash
+# For CPU
+pip install tensorflow
+# For GPU
+pip install tensorflow-gpu
+```
+
+The remaining libraries can be installed on Ubuntu 16.04 using via apt-get:
+
+``` bash
+sudo apt-get install protobuf-compiler python-pil python-lxml
+sudo pip install jupyter
+sudo pip install matplotlib
+```
+
+Alternatively, users can install dependencies using pip:
+
+``` bash
+sudo pip install pillow
+sudo pip install lxml
+sudo pip install jupyter
+sudo pip install matplotlib
+```
+
+## Protobuf Compilation
+
+The Tensorflow Object Detection API uses Protobufs to configure model and
+training parameters. Before the framework can be used, the Protobuf libraries
+must be compiled. This should be done by running the following command from
+the tensorflow/models directory:
+
+
+``` bash
+# From tensorflow/models/
+protoc object_detection/protos/*.proto --python_out=.
+```
+
+## Add Libraries to PYTHONPATH
+
+When running locally, the tensorflow/models/ and slim directories should be
+appended to PYTHONPATH. This can be done by running the following from
+tensorflow/models/:
+
+
+``` bash
+# From tensorflow/models/
+export PYTHONPATH=$PYTHONPATH:`pwd`:`pwd`/slim
+```
+
+Note: This command needs to run from every new terminal you start. If you wish
+to avoid running this manually, you can add it as a new line to the end of your
+~/.bashrc file.
+
+# Testing the Installation
+
+You can test that you have correctly installed the Tensorflow Object Detection\
+API by running the following command:
+
+``` bash
+python object_detection/builders/model_builder_test.py
+```

object_detection/g3doc/preparing_inputs.md

+# Preparing Inputs
+
+Tensorflow Object Detection API reads data using the TFRecord file format. Two
+sample scripts (`create_pascal_tf_record.py` and `create_pet_tf_record.py`) are
+provided to convert from the PASCAL VOC dataset and Oxford-IIIT Pet dataset to
+TFRecords.
+
+## Generating the PASCAL VOC TFRecord files.
+
+The raw 2012 PASCAL VOC data set is located
+[here](http://host.robots.ox.ac.uk/pascal/VOC/voc2012/VOCtrainval_11-May-2012.tar).
+To download, extract and convert it to TFRecords, run the following commands
+below:
+
+```bash
+# From tensorflow/models
+wget http://host.robots.ox.ac.uk/pascal/VOC/voc2012/VOCtrainval_11-May-2012.tar
+tar -xvf VOCtrainval_11-May-2012.tar
+python object_detection/create_pascal_tf_record.py \
+    --label_map_path=object_detection/data/pascal_label_map.pbtxt \
+    --data_dir=VOCdevkit --year=VOC2012 --set=train \
+    --output_path=pascal_train.record
+python object_detection/create_pascal_tf_record.py \
+    --label_map_path=object_detection/data/pascal_label_map.pbtxt \
+    --data_dir=VOCdevkit --year=VOC2012 --set=val \
+    --output_path=pascal_val.record
+```
+
+You should end up with two TFRecord files named `pascal_train.record` and
+`pascal_val.record` in the `tensorflow/models` directory.
+
+The label map for the PASCAL VOC data set can be found at
+`object_detection/data/pascal_label_map.pbtxt`.
+
+## Generating the Oxford-IIIT Pet TFRecord files.
+
+The Oxford-IIIT Pet data set is located on
+[their website](http://www.robots.ox.ac.uk/~vgg/data/pets/).
+To download, extract and convert it to TFRecrods, run the following commands
+below:
+
+```bash
+# From tensorflow/models
+wget http://www.robots.ox.ac.uk/~vgg/data/pets/data/images.tar.gz
+wget http://www.robots.ox.ac.uk/~vgg/data/pets/data/annotations.tar.gz
+tar -xvf annotations.tar.gz
+tar -xvf images.tar.gz
+python object_detection/create_pet_tf_record.py \
+    --label_map_path=object_detection/data/pet_label_map.pbtxt \
+    --data_dir=`pwd` \
+    --output_dir=`pwd`
+```
+
+You should end up with two TFRecord files named `pet_train.record` and
+`pet_val.record` in the `tensorflow/models` directory.
+
+The label map for the Pet dataset can be found at
+`object_detection/data/pet_label_map.pbtxt`.

object_detection/g3doc/running_locally.md

+# Running Locally
+
+This page walks through the steps required to train an object detection model
+on a local machine. It assumes the reader has completed the
+following prerequisites:
+
+1. The Tensorflow Object Detection API has been installed as documented in the
+[installation instructions](installation.md). This includes installing library
+dependencies, compiling the configuration protobufs and setting up the Python
+environment.
+2. A valid data set has been created. See [this page](preparing_inputs.md) for
+instructions on how to generate a dataset for the PASCAL VOC challenge or the
+Oxford-IIIT Pet dataset.
+3. A Object Detection pipeline configuration has been written. See
+[this page](configuring_jobs.md) for details on how to write a pipeline configuration.
+
+## Recommended Directory Structure for Training and Evaluation
+
+```
++data
+  -label_map file
+  -train TFRecord file
+  -eval TFRecord file
++models
+  + model
+    -pipeline config file
+    +train
+    +eval
+```
+
+## Running the Training Job
+
+A local training job can be run with the following command:
+
+```bash
+# From the tensorflow/models/ directory
+python object_detection/train.py \
+    --logtostderr \
+    --pipeline_config_path=${PATH_TO_YOUR_PIPELINE_CONFIG} \
+    --train_dir=${PATH_TO_TRAIN_DIR}
+```
+
+where `${PATH_TO_YOUR_PIPELINE_CONFIG}` points to the pipeline config and
+`${PATH_TO_TRAIN_DIR}` points to the directory in which training checkpoints
+and events will be written to. By default, the training job will
+run indefinitely until the user kills it.
+
+## Running the Evaluation Job
+
+Evaluation is run as a separate job. The eval job will periodically poll the
+train directory for new checkpoints and evaluate them on a test dataset. The
+job can be run using the following command:
+
+```bash
+# From the tensorflow/models/ directory
+python object_detection/eval.py \
+    --logtostderr \
+    --pipeline_config_path=${PATH_TO_YOUR_PIPELINE_CONFIG} \
+    --checkpoint_dir=${PATH_TO_TRAIN_DIR} \
+    --eval_dir=${PATH_TO_EVAL_DIR}
+```
+
+where `${PATH_TO_YOUR_PIPELINE_CONFIG}` points to the pipeline config,
+`${PATH_TO_TRAIN_DIR}` points to the directory in which training checkpoints
+were saved (same as the training job) and `${PATH_TO_EVAL_DIR}` points to the
+directory in which evaluation events will be saved. As with the training job,
+the eval job run until terminated by default.
+
+## Running Tensorboard
+
+Progress for training and eval jobs can be inspected using Tensorboard. If
+using the recommended directory structure, Tensorboard can be run using the
+following command:
+
+```bash
+tensorboard --logdir=${PATH_TO_MODEL_DIRECTORY}
+```
+
+where `${PATH_TO_MODEL_DIRECTORY}` points to the directory that contains the
+train and eval directories. Please note it may take Tensorboard a couple
+minutes to populate with data.

object_detection/g3doc/running_notebook.md

+# Quick Start: Jupyter notebook for off-the-shelf inference
+
+If you'd like to hit the ground running and run detection on a few example
+images right out of the box, we recommend trying out the Jupyter notebook demo.
+To run the Jupyter notebook, run the following command from
+`tensorflow/models/object_detection`:
+
+```
+# From tensorflow/models/object_detection
+jupyter notebook
+```
+
+The notebook should open in your favorite web browser. Click the
+[`object_detection_tutorial.ipynb`](../object_detection_tutorial.ipynb) link
+to open the demo.

object_detection/g3doc/running_on_cloud.md

+# Running on Google Cloud Platform
+
+The Tensorflow Object Detection API supports distributed training on Google
+Cloud ML Engine. This section documents instructions on how to train and
+evaluate your model using Cloud ML. The reader should complete the following
+prerequistes:
+
+1. The reader has created and configured a project on Google Cloud Platform.
+See [the Cloud ML quick start guide](https://cloud.google.com/ml-engine/docs/quickstarts/command-line).
+2. The reader has installed the Tensorflow Object Detection API as documented
+in the [installation instructions](installation.md).
+3. The reader has a valid data set and stored it in a Google Cloud Storage
+bucket. See [this page](preparing_inputs.md) for instructions on how to generate
+a dataset for the PASCAL VOC challenge or the Oxford-IIIT Pet dataset.
+4. The reader has configured a valid Object Detection pipeline, and stored it
+in a Google Cloud Storage bucket. See [this page](configuring_jobs.md) for
+details on how to write a pipeline configuration.
+
+Additionally, it is recommended users test their job by running training and
+evaluation jobs for a few iterations
+[locally on their own machines](running_locally.md).
+
+## Packaging
+
+In order to run the Tensorflow Object Detection API on Cloud ML, it must be
+packaged (along with it's TF-Slim dependency). The required packages can be
+created with the following command
+
+``` bash
+# From tensorflow/models/
+python setup.py sdist
+(cd slim && python setup.py sdist)
+```
+
+This will create python packages in dist/object_detection-0.1.tar.gz and
+slim/dist/slim-0.1.tar.gz.
+
+## Running a Multiworker Training Job
+
+Google Cloud ML requires a YAML configuration file for a multiworker training
+job using GPUs. A sample YAML file is given below:
+
+```
+trainingInput:
+  runtimeVersion: "1.0"
+  scaleTier: CUSTOM
+  masterType: standard_gpu
+  workerCount: 9
+  workerType: standard_gpu
+  parameterServerCount: 3
+  parameterServerType: standard
+
+
+```
+
+Please keep the following guidelines in mind when writing the YAML
+configuration:
+
+* A job with n workers will have n + 1 training machines (n workers + 1 master).
+* The number of parameters servers used should be an odd number to prevent
+  a parameter server from storing only weight variables or only bias variables
+  (due to round robin parameter scheduling).
+* The learning rate in the training config should be decreased when using a
+  larger number of workers. Some experimentation is required to find the
+  optimal learning rate.
+
+The YAML file should be saved on the local machine (not on GCP). Once it has
+been written, a user can start a training job on Cloud ML Engine using the
+following command:
+
+``` bash
+# From tensorflow/models/
+gcloud ml-engine jobs submit training object_detection_`date +%s` \
+    --job-dir=gs://${TRAIN_DIR} \
+    --packages dist/object_detection-0.1.tar.gz,slim/dist/slim-0.1.tar.gz \
+    --module-name object_detection.train \
+    --region us-central1 \
+    --config ${PATH_TO_LOCAL_YAML_FILE} \
+    -- \
+    --train_dir=gs://${TRAIN_DIR} \
+    --pipeline_config_path=gs://${PIPELINE_CONFIG_PATH}
+```
+
+Where `${PATH_TO_LOCAL_YAML_FILE}` is the local path to the YAML configuration,
+`gs://${TRAIN_DIR}` specifies the directory on Google Cloud Storage where the
+training checkpoints and events will be written to and
+`gs://${PIPELINE_CONFIG_PATH}` points to the pipeline configuration stored on
+Google Cloud Storage.
+
+Users can monitor the progress of their training job on the [ML Engine
+Dashboard](https://console.cloud.google.com/mlengine/jobs).
+
+## Running an Evaluation Job on Cloud
+
+Evaluation jobs run on a single machine, so it is not necessary to write a YAML
+configuration for evaluation. Run the following command to start the evaluation
+job:
+
+``` bash
+gcloud ml-engine jobs submit training object_detection_eval_`date +%s` \
+    --job-dir=gs://${TRAIN_DIR} \
+    --packages dist/object_detection-0.1.tar.gz,slim/dist/slim-0.1.tar.gz \
+    --module-name object_detection.eval \
+    --region us-central1 \
+    --scale-tier BASIC_GPU \
+    -- \
+    --checkpoint_dir=gs://${TRAIN_DIR} \
+    --eval_dir=gs://${EVAL_DIR} \
+    --pipeline_config_path=gs://${PIPELINE_CONFIG_PATH}
+```
+
+Where `gs://${TRAIN_DIR}` points to the directory on Google Cloud Storage where
+training checkpoints are saved (same as the training job), `gs://${EVAL_DIR}`
+points to where evaluation events will be saved on Google Cloud Storage and
+`gs://${PIPELINE_CONFIG_PATH}` points to where the pipeline configuration is
+stored on Google Cloud Storage.
+
+## Running Tensorboard
+
+You can run Tensorboard locally on your own machine to view progress of your
+training and eval jobs on Google Cloud ML. Run the following command to start
+Tensorboard:
+
+``` bash
+tensorboard --logdir=gs://${YOUR_CLOUD_BUCKET}
+```
+
+Note it may Tensorboard a few minutes to populate with results.

object_detection/g3doc/running_pets.md

+# Quick Start: Distributed Training on the Oxford-IIIT Pets Dataset on Google Cloud
+
+This page is a walkthrough for training an object detector using the Tensorflow
+Object Detection API. In this tutorial, we'll be training on the Oxford-IIIT Pets
+dataset to build a system to detect various breeds of cats and dogs. The output
+of the detector will look like the following:
+
+![](img/oxford_pet.png)
+
+## Setting up a Project on Google Cloud
+
+To accelerate the process, we'll run training and evaluation on [Google Cloud
+ML Engine](https://cloud.google.com/ml-engine/) to leverage multiple GPUs. To
+begin, you will have to set up Google Cloud via the following steps (if you have
+already done this, feel free to skip to the next section):
+
+1. [Create a GCP project](https://cloud.google.com/resource-manager/docs/creating-managing-projects).
+2. [Install the Google Cloud SDK](https://cloud.google.com/sdk/downloads) on
+your workstation or laptop.
+This will provide the tools you need to upload files to Google Cloud Storage and
+start ML training jobs.
+3. [Enable the ML Engine
+APIs](https://console.cloud.google.com/flows/enableapi?apiid=ml.googleapis.com,compute_component&_ga=1.73374291.1570145678.1496689256).
+By default, a new GCP project does not enable APIs to start ML Engine training
+jobs. Use the above link to explicitly enable them.
+4. [Set up a Google Cloud Storage (GCS)
+bucket](https://cloud.google.com/storage/docs/creating-buckets). ML Engine
+training jobs can only access files on a Google Cloud Storage bucket. In this
+tutorial, we'll be required to upload our dataset and configuration to GCS.
+
+Please remember the name of your GCS bucket, as we will reference it multiple
+times in this document. Substitute `${YOUR_GCS_BUCKET}` with the name of
+your bucket in this document. For your convenience, you should define the
+environment variable below:
+
+``` bash
+export YOUR_GCS_BUCKET=${YOUR_GCS_BUCKET}
+```
+
+## Installing Tensorflow and the Tensorflow Object Detection API
+
+Please run through the [installation instructions](installation.md) to install
+Tensorflow and all it dependencies. Ensure the Protobuf libraries are
+compiled and the library directories are added to `PYTHONPATH`.
+
+## Getting the Oxford-IIIT Pets Dataset and Uploading it to Google Cloud Storage
+
+In order to train a detector, we require a dataset of images, bounding boxes and
+classifications. For this demo, we'll use the Oxford-IIIT Pets dataset. The raw
+dataset for Oxford-IIIT Pets lives
+[here](http://www.robots.ox.ac.uk/~vgg/data/pets/). You will need to download
+both the image dataset [`images.tar.gz`](http://www.robots.ox.ac.uk/~vgg/data/pets/data/images.tar.gz)
+and the groundtruth data [`annotations.tar.gz`](http://www.robots.ox.ac.uk/~vgg/data/pets/data/annotations.tar.gz)
+to the `tensorflow/models` directory and unzip them. This may take some time.
+
+``` bash
+# From tensorflow/models/
+wget http://www.robots.ox.ac.uk/~vgg/data/pets/data/images.tar.gz
+wget http://www.robots.ox.ac.uk/~vgg/data/pets/data/annotations.tar.gz
+tar -xvf images.tar.gz
+tar -xvf annotations.tar.gz
+```
+
+After downloading the tarballs, your `tensorflow/models` directory should appear
+as follows:
+
+```lang-none
+- images.tar.gz
+- annotations.tar.gz
++ images/
++ annotations/
++ object_detection/
+... other files and directories
+```
+
+The Tensorflow Object Detection API expects data to be in the TFRecord format,
+so we'll now run the `create_pet_tf_record` script to convert from the raw
+Oxford-IIIT Pet dataset into TFRecords. Run the following commands from the
+`tensorflow/models` directory:
+
+``` bash
+# From tensorflow/models/
+python object_detection/create_pet_tf_record.py \
+    --label_map_path=object_detection/data/pet_label_map.pbtxt \
+    --data_dir=`pwd` \
+    --output_dir=`pwd`
+```
+
+Note: It is normal to see some warnings when running this script. You may ignore
+them.
+
+Two TFRecord files named `pet_train.record` and `pet_val.record` should be generated
+in the `tensorflow/models` directory.
+
+Now that the data has been generated, we'll need to upload it to Google Cloud
+Storage so the data can be accessed by ML Engine. Run the following command to
+copy the files into your GCS bucket (substituting `${YOUR_GCS_BUCKET}`):
+
+``` bash
+# From tensorflow/models/
+gsutil cp pet_train.record gs://${YOUR_GCS_BUCKET}/data/pet_train.record
+gsutil cp pet_val.record gs://${YOUR_GCS_BUCKET}/data/pet_val.record
+gsutil cp object_detection/data/pet_label_map.pbtxt gs://${YOUR_GCS_BUCKET}/data/pet_label_map.pbtxt
+```
+
+Please remember the path where you upload the data to, as we will need this
+information when configuring the pipeline in a following step.
+
+## Downloading a COCO-pretrained Model for Transfer Learning
+
+Training a state of the art object detector from scratch can take days, even
+when using multiple GPUs! In order to speed up training, we'll take an object
+detector trained on a different dataset (COCO), and reuse some of it's
+parameters to initialize our new model.
+
+Download our [COCO-pretrained Faster R-CNN with Resnet-101
+model](http://storage.googleapis.com/download.tensorflow.org/models/object_detection/faster_rcnn_resnet101_coco_11_06_2017.tar.gz).
+Unzip the contents of the folder and copy the `model.ckpt*` files into your GCS
+Bucket.
+
+``` bash
+wget http://storage.googleapis.com/download.tensorflow.org/models/object_detection/faster_rcnn_resnet101_coco_11_06_2017.tar.gz
+tar -xvf faster_rcnn_resnet101_coco_11_06_2017.tar.gz
+gsutil cp faster_rcnn_resnet101_coco_11_06_2017/model.ckpt.* gs://${YOUR_GCS_BUCKET}/data/
+```
+
+Remember the path where you uploaded the model checkpoint to, as we will need it
+in the following step.
+
+## Configuring the Object Detection Pipeline
+
+In the Tensorflow Object Detection API, the model parameters, training
+parameters and eval parameters are all defined by a config file. More details
+can be found [here](configuring_jobs.md). For this tutorial, we will use some
+predefined templates provided with the source code. In the
+`object_detection/samples/configs` folder, there are skeleton object_detection
+configuration files. We will use `faster_rcnn_resnet101_pets.config` as a
+starting point for configuring the pipeline. Open the file with your favourite
+text editor.
+
+We'll need to configure some paths in order for the template to work. Search the
+file for instances of `PATH_TO_BE_CONFIGURED` and replace them with the
+appropriate value (typically `gs://${YOUR_GCS_BUCKET}/data/`). Afterwards
+upload your edited file onto GCS, making note of the path it was uploaded to
+(we'll need it when starting the training/eval jobs).
+
+``` bash
+# From tensorflow/models/
+
+# Edit the faster_rcnn_resnet101_pets.config template. Please note that there
+# are multiple places where PATH_TO_BE_CONFIGURED needs to be set.
+sed -i "s|PATH_TO_BE_CONFIGURED|"gs://${YOUR_GCS_BUCKET}"/data|g" \
+    object_detection/samples/configs/faster_rcnn_resnet101_pets.config
+
+# Copy edited template to cloud.
+gsutil cp object_detection/samples/configs/faster_rcnn_resnet101_pets.config \
+    gs://${YOUR_GCS_BUCKET}/data/faster_rcnn_resnet101_pets.config
+```
+
+## Checking Your Google Cloud Storage Bucket
+
+At this point in the tutorial, you should have uploaded the training/validation
+datasets (including label map), our COCO trained FasterRCNN finetune checkpoint and your job
+configuration to your Google Cloud Storage Bucket. Your bucket should look like
+the following:
+
+```lang-none
++ ${YOUR_GCS_BUCKET}/
+  + data/
+    - faster_rcnn_resnet101_pets.config
+    - model.ckpt.index
+    - model.ckpt.meta
+    - model.ckpt.data-00000-of-00001
+    - pet_label_map.pbtxt
+    - pet_train.record
+    - pet_val.record
+```
+
+You can inspect your bucket using the [Google Cloud Storage
+browser](https://console.cloud.google.com/storage/browser).
+
+## Starting Training and Evaluation Jobs on Google Cloud ML Engine
+
+Before we can start a job on Google Cloud ML Engine, we must:
+
+1. Package the Tensorflow Object Detection code.
+2. Write a cluster configuration for our Google Cloud ML job.
+
+To package the Tensorflow Object Detection code, run the following commands from
+the `tensorflow/models/` directory:
+
+``` bash
+# From tensorflow/models/
+python setup.py sdist
+(cd slim && python setup.py sdist)
+```
+
+You should see two tar.gz files created at `dist/object_detection-0.1.tar.gz`
+and `slim/dist/slim-0.1.tar.gz`.
+
+For running the training Cloud ML job, we'll configure the cluster to use 10
+training jobs (1 master + 9 workers) and three parameters servers. The
+configuration file can be found at `object_detection/samples/cloud/cloud.yml`.
+
+To start training, execute the following command from the `tensorflow/models/`
+directory:
+
+``` bash
+# From tensorflow/models/
+gcloud ml-engine jobs submit training `whoami`_object_detection_`date +%s` \
+    --job-dir=gs://${YOUR_GCS_BUCKET}/train \
+    --packages dist/object_detection-0.1.tar.gz,slim/dist/slim-0.1.tar.gz \
+    --module-name object_detection.train \
+    --region us-central1 \
+    --config object_detection/samples/cloud/cloud.yml \
+    -- \
+    --train_dir=gs://${YOUR_GCS_BUCKET}/train \
+    --pipeline_config_path=gs://${YOUR_GCS_BUCKET}/data/faster_rcnn_resnet101_pets.config
+```
+
+Once training has started, we can run an evaluation concurrently:
+
+``` bash
+# From tensorflow/models/
+gcloud ml-engine jobs submit training `whoami`_object_detection_eval_`date +%s` \
+    --job-dir=gs://${YOUR_GCS_BUCKET}/train \
+    --packages dist/object_detection-0.1.tar.gz,slim/dist/slim-0.1.tar.gz \
+    --module-name object_detection.eval \
+    --region us-central1 \
+    --scale-tier BASIC_GPU \
+    -- \
+    --checkpoint_dir=gs://${YOUR_GCS_BUCKET}/train \
+    --eval_dir=gs://${YOUR_GCS_BUCKET}/eval \
+    --pipeline_config_path=gs://${YOUR_GCS_BUCKET}/data/faster_rcnn_resnet101_pets.config
+```
+
+Note: Even though we're running an evaluation job, the `gcloud ml-engine jobs
+submit training` command is correct. ML Engine does not distinguish between
+training and evaluation jobs.
+
+Users can monitor and stop training and evaluation jobs on the [ML Engine
+Dashboard](https://console.cloud.google.com/mlengine/jobs).
+
+## Monitoring Progress with Tensorboard
+
+You can monitor progress of the training and eval jobs by running Tensorboard on
+your local machine:
+
+``` bash
+# This command needs to be run once to allow your local machine to access your
+# GCS bucket.
+gcloud auth application-default login
+
+tensorboard --logdir=gs://${YOUR_GCS_BUCKET}
+```
+
+Once Tensorboard is running, navigate to `localhost:6006` from your favourite
+web browser. You should something similar see the following:
+
+![](img/tensorboard.png)
+
+You will also want to click on the images tab to see example detections made by
+the model while it trains. After about an hour and a half of training, you can
+expect to see something like this:
+
+![](img/tensorboard2.png)
+
+Note: It takes roughly 10 minutes for a job to get started on ML Engine, and
+roughly an hour for the system to evaluate the validation dataset. It may take
+some time to populate the dashboards. If you do not see any entries after half
+an hour, check the logs from the [ML Engine
+Dashboard](https://console.cloud.google.com/mlengine/jobs).
+
+## Exporting the Tensorflow Graph
+
+After your model has been trained, you should export it to a Tensorflow
+graph proto. First, you need to identify a candidate checkpoint to export. You
+can search your bucket using the [Google Cloud Storage
+Browser](https://console.cloud.google.com/storage/browser). The file should be
+stored under `${YOUR_GCS_BUCKET}/train`. The checkpoint will typically consist of
+three files:
+
+* `model.ckpt-${CHECKPOINT_NUMBER}.data-00000-of-00001`
+* `model.ckpt-${CHECKPOINT_NUMBER}.index`
+* `model.ckpt-${CHECKPOINT_NUMBER}.meta`
+
+After you've identified a candidate checkpoint to export, run the following
+command from `tensorflow/models`:
+
+``` bash
+# From tensorflow/models
+gsutil cp gs://${YOUR_GCS_BUCKET}/train/model.ckpt-${CHECKPOINT_NUMBER}.* .
+python object_detection/export_inference_graph.py \
+    --input_type image_tensor \
+    --pipeline_config_path object_detection/samples/configs/faster_rcnn_resnet101_pets.config \
+    --checkpoint_path model.ckpt-${CHECKPOINT_NUMBER} \
+    --inference_graph_path output_inference_graph.pb
+```
+
+Afterwards, you should see a graph named `output_inference_graph.pb`.
+
+## What's Next
+
+Congratulations, you have now trained an object detector for various cats and
+dogs! There different things you can do now:
+
+1. [Test your exported model using the provided Jupyter notebook.](running_notebook.md)
+2. [Experiment with different model configurations.](configuring_jobs.md)
+3. Train an object detector using your own data.

object_detection/g3doc/using_your_own_dataset.md

+# Preparing Inputs
+
+To use your own dataset in Tensorflow Object Detection API, you must convert it
+into the [TFRecord file format](https://www.tensorflow.org/api_guides/python/python_io#tfrecords_format_details).
+This document outlines how to write a script to generate the TFRecord file.
+
+## Label Maps
+
+Each dataset is required to have a label map associated with it. This label map
+defines a mapping from string class names to integer class Ids. The label map
+should be a `StringIntLabelMap` text protobuf. Sample label maps can be found in
+object_detection/data. Label maps should always start from id 1.
+
+## Dataset Requirements
+
+For every example in your dataset, you should have the following information:
+
+1. An RGB image for the dataset encoded as jpeg or png.
+2. A list of bounding boxes for the image. Each bounding box should contain:
+    1. A bounding box coordinates (with origin in top left corner) defined by 4
+       floating point numbers [ymin, xmin, ymax, xmax]. Note that we store the
+       _normalized_ coordinates (x / width, y / height) in the TFRecord dataset.
+    2. The class of the object in the bounding box.
+
+# Example Image
+
+Consider the following image:
+
+![Example Image](img/example_cat.jpg "Example Image")
+
+with the following label map:
+
+```
+item {
+  id: 1
+  name: 'Cat'
+}
+
+
+item {
+  id: 2
+  name: 'Dog'
+}
+```
+
+We can generate a tf.Example proto for this image using the following code:
+
+```python
+
+def create_cat_tf_example(encoded_cat_image_data):
+   """Creates a tf.Example proto from sample cat image.
+
+  Args:
+    encoded_cat_image_data: The jpg encoded data of the cat image.
+
+  Returns:
+    example: The created tf.Example.
+  """
+
+  height = 1032.0
+  width = 1200.0
+  filename = 'example_cat.jpg'
+  image_format = b'jpg'
+
+  xmins = [322.0 / 1200.0]
+  xmaxs = [1062.0 / 1200.0]
+  ymins = [174.0 / 1032.0]
+  ymaxs = [761.0 / 1032.0]
+  classes_text = ['Cat']
+  classes = [1]
+
+  tf_example = tf.train.Example(features=tf.train.Features(feature={
+      'image/height': dataset_util.int64_feature(height),
+      'image/width': dataset_util.int64_feature(width),
+      'image/filename': dataset_util.bytes_feature(filename),
+      'image/source_id': dataset_util.bytes_feature(filename),
+      'image/encoded': dataset_util.bytes_feature(encoded_image_data),
+      'image/format': dataset_util.bytes_feature(image_format),
+      'image/object/bbox/xmin': dataset_util.float_list_feature(xmins),
+      'image/object/bbox/xmax': dataset_util.float_list_feature(xmaxs),
+      'image/object/bbox/ymin': dataset_util.float_list_feature(ymins),
+      'image/object/bbox/ymax': dataset_util.float_list_feature(ymaxs),
+      'image/object/class/text': dataset_util.bytes_list_feature(classes_text),
+      'image/object/class/label': dataset_util.int64_list_feature(classes),
+  }))
+  return tf_example
+```
+
+## Conversion Script Outline
+
+A typical conversion script will look like the following:
+
+```python
+
+import tensorflow as tf
+
+from object_detection.utils import dataset_util
+
+
+flags = tf.app.flags
+flags.DEFINE_string('output_path', '', 'Path to output TFRecord')
+FLAGS = flags.FLAGS
+
+
+def create_tf_example(example):
+  # TODO(user): Populate the following variables from your example.
+  height = None # Image height
+  width = None # Image width
+  filename = None # Filename of the image. Empty if image is not from file
+  encoded_image_data = None # Encoded image bytes
+  image_format = None # b'jpeg' or b'png'
+
+  xmins = [] # List of normalized left x coordinates in bounding box (1 per box)
+  xmaxs = [] # List of normalized right x coordinates in bounding box
+             # (1 per box)
+  ymins = [] # List of normalized top y coordinates in bounding box (1 per box)
+  ymaxs = [] # List of normalized bottom y coordinates in bounding box
+             # (1 per box)
+  classes_text = [] # List of string class name of bounding box (1 per box)
+  classes = [] # List of integer class id of bounding box (1 per box)
+
+  tf_example = tf.train.Example(features=tf.train.Features(feature={
+      'image/height': dataset_util.int64_feature(height),
+      'image/width': dataset_util.int64_feature(width),
+      'image/filename': dataset_util.bytes_feature(filename),
+      'image/source_id': dataset_util.bytes_feature(filename),
+      'image/encoded': dataset_util.bytes_feature(encoded_image_data),
+      'image/format': dataset_util.bytes_feature(image_format),
+      'image/object/bbox/xmin': dataset_util.float_list_feature(xmins),
+      'image/object/bbox/xmax': dataset_util.float_list_feature(xmaxs),
+      'image/object/bbox/ymin': dataset_util.float_list_feature(ymins),
+      'image/object/bbox/ymax': dataset_util.float_list_feature(ymaxs),
+      'image/object/class/text': dataset_util.bytes_list_feature(classes_text),
+      'image/object/class/label': dataset_util.int64_list_feature(classes),
+  }))
+  return tf_example
+
+
+def main(_):
+  writer = tf.python_io.TFRecordWriter(FLAGS.output_path)
+
+  # TODO(user): Write code to read in your dataset to examples variable
+
+  for example in examples:
+    tf_example = create_tf_example(example)
+    writer.write(tf_example.SerializeToString())
+
+  writer.close()
+
+
+if __name__ == '__main__':
+  tf.app.run()
+
+```
+
+Note: You may notice additional fields in some other datasets. They are
+currently unused by the API and are optional.
