Merge branch 'develop' into codegen-enable-hiprtc

example/ck_tile/15_fused_moe/instances/fused_moegemm_bf16_m32.cpp

+// SPDX-License-Identifier: MIT
+// Copyright (c) 2024, Advanced Micro Devices, Inc. All rights reserved.
+
+#include <ck_tile/core.hpp>
+#include "fused_moegemm.hpp"
+#include "fused_moegemm_api_traits.hpp"
+#include "fused_moegemm_api_internal.hpp"
+
+// clang-format off
+template float fused_moegemm_<
+    fmoe_<ck_tile::bf16_t, ck_tile::bf16_t, ck_tile::bf16_t, float, float, float, float, S<32, 512, 128, 128>, S<1, 4, 1>, S<16, 16, 32>, 1, 0>
+>(const ck_tile::stream_config& s, fused_moegemm_args a);
+
+// clang-format on

example/ck_tile/15_fused_moe/instances/fused_moegemm_fp16_m32.cpp

+// SPDX-License-Identifier: MIT
+// Copyright (c) 2024, Advanced Micro Devices, Inc. All rights reserved.
+
+#include <ck_tile/core.hpp>
+#include "fused_moegemm.hpp"
+#include "fused_moegemm_api_traits.hpp"
+#include "fused_moegemm_api_internal.hpp"
+
+// clang-format off
+template float fused_moegemm_<
+    fmoe_<ck_tile::fp16_t, ck_tile::fp16_t, ck_tile::fp16_t, float, float, float, float, S<32, 512, 128, 128>, S<1, 4, 1>, S<16, 16, 32>, 1, 0>
+>(const ck_tile::stream_config& s, fused_moegemm_args a);
+
+// clang-format on

example/ck_tile/15_fused_moe/instances/fused_moesorting_api.cpp

+// SPDX-License-Identifier: MIT
+// Copyright (c) 2024, Advanced Micro Devices, Inc. All rights reserved.
+
+#include "fused_moesorting.hpp"
+
+#define MOE_SORTING_DISPATCH(unroll_num_)                                                   \
+    constexpr ck_tile::index_t unroll_num = unroll_num_;                                    \
+    using ms_problem     = ck_tile::MoeSortingProblem<index_t, ms_weight_type, unroll_num>; \
+    using kernel         = ck_tile::MoeSortingKernel<ms_problem>;                           \
+    auto kargs           = kernel::MakeKargs(a);                                            \
+    const dim3 grids     = kernel::GridSize(a);                                             \
+    const dim3 blocks    = kernel::BlockSize(a);                                            \
+    const auto lds_bytes = kernel::GetSmemSize(a);                                          \
+    float ave_time       = ck_tile::launch_kernel(                                          \
+        s, ck_tile::make_kernel(kernel{}, grids, blocks, lds_bytes, kargs));          \
+    return ave_time;
+
+float fused_moesorting(fused_moesorting_trait t, fused_moesorting_args a, ck_tile::stream_config s)
+{
+    if(t.weight_type == "fp32" && t.index_type == "int32")
+    {
+        if(a.num_experts > 127)
+        {
+            printf("lds size exceed, only support experts <127 \n");
+            return -1;
+        }
+        if(a.moe_buf_bytes % 16)
+        {
+            printf("buf set size %d unaligned, must be multiple of 16\n", a.moe_buf_bytes);
+            return -1;
+        }
+        using index_t              = ck_tile::index_t;
+        using ms_weight_type       = float;
+        index_t smem_io_unroll_num = ck_tile::integer_divide_ceil(a.tokens * a.topk, 64);
+        switch(smem_io_unroll_num)
+        {
+        case(1): {
+            MOE_SORTING_DISPATCH(1);
+        }
+        case(2): {
+            MOE_SORTING_DISPATCH(2);
+        }
+        case(3): {
+            MOE_SORTING_DISPATCH(3);
+        }
+        case(5): {
+            MOE_SORTING_DISPATCH(5);
+        }
+        case(6): {
+            MOE_SORTING_DISPATCH(6);
+        }
+        case(7): {
+            MOE_SORTING_DISPATCH(7);
+        }
+        case(8): {
+            MOE_SORTING_DISPATCH(8);
+        }
+        case(9): {
+            MOE_SORTING_DISPATCH(9);
+        }
+        case(10): {
+            MOE_SORTING_DISPATCH(10);
+        }
+        case(11): {
+            MOE_SORTING_DISPATCH(11);
+        }
+        default: {
+            MOE_SORTING_DISPATCH(4);
+        }
+        }
+    }
+    return -1;
+}

example/ck_tile/15_fused_moe/main.cpp

+#include <algorithm>
+#include <cstring>
+#include <unordered_set>
+#include <vector>
+#include <set>
+
+#include "ck_tile/host.hpp"
+#include "fused_moe.hpp"
+
+// different threshold for different dtype
+template <typename DataType>
+auto get_elimit()
+{
+    double rtol = 1e-2;
+    double atol = 1e-2;
+    return ck_tile::make_tuple(rtol, atol);
+}
+
+template <>
+auto get_elimit<ck_tile::bf16_t>()
+{
+    double rtol = 1e-2;
+    double atol = 1e-2;
+    return ck_tile::make_tuple(rtol, atol);
+}
+
+// mfma_type, 0:32x32, 1:16x16
+// TODO: padding?
+template <typename T>
+auto shuffle_moe_weight(const ck_tile::HostTensor<T>& t, std::string mfma_dtype, int mfma_type = 0)
+{
+    assert(t.get_lengths().size() == 3);
+    int b_ = t.get_lengths()[0];
+    int n_ = t.get_lengths()[1];
+    int k_ = t.get_lengths()[2];
+    if((mfma_dtype == "bf16" || mfma_dtype == "fp16") && mfma_type == 0)
+    {
+        ck_tile::HostTensor<T> t_view({b_, n_ / 32, 32, k_ / 16, 2, 8});
+        std::copy(t.begin(), t.end(), t_view.begin());
+        return ck_tile::reference_permute(t_view, {0, 1, 3, 4, 2, 5});
+    }
+    else if((mfma_dtype == "bf16" || mfma_dtype == "fp16") && mfma_type == 1)
+    {
+        ck_tile::HostTensor<T> t_view({b_, n_ / 16, 16, k_ / 32, 4, 8});
+        std::copy(t.begin(), t.end(), t_view.begin());
+        return ck_tile::reference_permute(t_view, {0, 1, 3, 4, 2, 5});
+    }
+    else if((mfma_dtype == "int8" || mfma_dtype == "fp8") && mfma_type == 0)
+    {
+        ck_tile::HostTensor<T> t_view({b_, n_ / 32, 32, k_ / 32, 2, 16});
+        std::copy(t.begin(), t.end(), t_view.begin());
+        return ck_tile::reference_permute(t_view, {0, 1, 3, 4, 2, 5});
+    }
+    else if((mfma_dtype == "int8" || mfma_dtype == "fp8") && mfma_type == 1)
+    {
+        ck_tile::HostTensor<T> t_view({b_, n_ / 16, 16, k_ / 64, 4, 16});
+        std::copy(t.begin(), t.end(), t_view.begin());
+        return ck_tile::reference_permute(t_view, {0, 1, 3, 4, 2, 5});
+    }
+    return t;
+}
+
+template <typename IndexType>
+void topid_unique_gen(
+    std::vector<IndexType>& host_tensor, int tokens, int topk, int num_expert, int seed)
+{
+    size_t total_size = topk * tokens;
+    std::srand(seed);
+    std::set<IndexType> unique_set;
+    IndexType current_v;
+    for(size_t i = 0; i < total_size; i++)
+    {
+        if(i % topk == 0)
+        {
+            unique_set.clear();
+        }
+        current_v = std::rand() % num_expert;
+        while(unique_set.find(current_v) != unique_set.end())
+        {
+            current_v = std::rand() % num_expert;
+        }
+        unique_set.insert(current_v);
+        host_tensor[i] = current_v;
+    }
+}
+
+auto create_args(int argc, char* argv[])
+{
+    ck_tile::ArgParser arg_parser;
+    arg_parser.insert("t", "128", "num input tokens")
+        .insert("e", "32", "num of experts")
+        .insert("k", "5", "topk")
+        .insert("h", "8192", "hidden_size of this model")
+        .insert("i", "8192", "intermediate_size between 2 gemms of FFN")
+        .insert("stride", "-1", "stride per row, if -1 then equal to hidden_size")
+        .insert("bm", "32", "blocking factor for sorted tokens")
+        .insert("tp", "8", "tensor parallel size")
+        .insert("v", "1", "cpu validation or not")
+        .insert("kname", "1", "print kernel name or not")
+        .insert("prec_i", "bf16", "input precision")
+        .insert("prec_w", "bf16", "weight precision")
+        .insert("prec_o", "bf16", "output precision")
+        .insert("prec_st", "auto", "token scale data type. auto will set to fp32")
+        .insert("prec_sw", "auto", "weight scale data type. auto will set to fp32")
+        .insert("prec_sq", "auto", "(dynamic) smooth quant data type. auto will set to fp32")
+        .insert("prec_kw", "auto", "topk-weight data type. auto will set to fp32")
+        .insert("fquant", "0", "fused-quant, 0:no, 1:smooth-dynamic-quant, 2:dynamic-quant")
+        .insert(
+            "gate_only", "1", "w0(gate/up) style, 0:gate+up will double interm size, 1:only gate")
+        .insert("api", "0", "benchmark api set: 0:fused-moe(moe-gemm+moe-sorting), 1:moe-gemm")
+        .insert("balance",
+                "0",
+                "if set to 1, will try balance the expert in topk-ids(convenient for testing)")
+        .insert("init",
+                "2",
+                "init method. 0:random stepped float(fast). 1: random uniform, 2:rand normalized"
+                "normalized(slow)")
+        .insert("seed", "11939", "seed used to do random")
+        .insert("warmup", "5", "cold iter")
+        .insert("repeat", "20", "hot iter");
+
+    bool result = arg_parser.parse(argc, argv);
+    return std::make_tuple(result, arg_parser);
+}
+
+// I:input-type, W:weight-type, O:output-type, ST:toke-scale-tpye, SW:weight-scale-type,
+// SQ:smooth-quant-type, KW:topk-weight-type
+template <typename I, typename W, typename O, typename ST, typename SW, typename SQ, typename KW>
+bool run(const ck_tile::ArgParser& arg_parser)
+{
+    ck_tile::index_t tokens            = arg_parser.get_int("t");
+    ck_tile::index_t experts           = arg_parser.get_int("e");
+    ck_tile::index_t topk              = arg_parser.get_int("k");
+    ck_tile::index_t hidden_size       = arg_parser.get_int("h");
+    ck_tile::index_t intermediate_size = arg_parser.get_int("i");
+    ck_tile::index_t stride            = arg_parser.get_int("stride");
+    ck_tile::index_t block_m           = arg_parser.get_int("bm");
+    if(stride < 0)
+        stride = hidden_size;
+    std::string prec_i  = arg_parser.get_str("prec_i");
+    std::string prec_w  = arg_parser.get_str("prec_w");
+    std::string prec_o  = arg_parser.get_str("prec_o");
+    std::string prec_st = arg_parser.get_str("prec_st");
+    std::string prec_sw = arg_parser.get_str("prec_sw");
+    std::string prec_sq = arg_parser.get_str("prec_sq");
+    std::string prec_kw = arg_parser.get_str("prec_kw");
+    prec_st             = (prec_st == "auto") ? "fp32" : prec_st;
+    prec_sw             = (prec_sw == "auto") ? "fp32" : prec_sw;
+    prec_sq             = (prec_sq == "auto") ? "fp32" : prec_sq;
+    prec_kw             = (prec_kw == "auto") ? "fp32" : prec_kw;
+    int kname           = arg_parser.get_int("kname");
+    int do_validation   = arg_parser.get_int("v");
+    int warmup          = arg_parser.get_int("warmup");
+    int repeat          = arg_parser.get_int("repeat");
+    int fused_quant     = arg_parser.get_int("fquant");
+    int gate_only       = arg_parser.get_int("gate_only");
+    int api             = arg_parser.get_int("api");
+    int balance         = arg_parser.get_int("balance");
+    int tp              = arg_parser.get_int("tp");
+    int init            = arg_parser.get_int("init");
+    uint32_t seed       = arg_parser.get_uint32("seed");
+
+    // w0 (Gate+Up or Gate only, N size)
+    ck_tile::index_t shared_intermediate_size_0 = intermediate_size * (gate_only ? 1 : 2) / tp;
+    // w1 (Down, N size)
+    ck_tile::index_t shared_intermediate_size_1 = intermediate_size / tp;
+
+    auto prec_str = [&]() {
+        auto base_str = prec_i;
+        if(prec_i != prec_w)
+            base_str += "x" + prec_w;
+        if(prec_i != prec_o)
+            base_str += "=" + prec_o;
+        if(fused_quant != 0)
+        {
+            base_str += std::string("(") + prec_st + "|" + prec_sw + "|" + prec_sq + ")";
+        }
+        return base_str;
+    }();
+    auto api_str = [&]() {
+        if(api == 0)
+            return std::string("fmoe");
+        else if(api == 1)
+            return std::string("moeg");
+        else if(api == 2)
+            return std::string("moes");
+        return std::string("");
+    }();
+
+    auto stride_str = [&]() {
+        if(stride == hidden_size)
+            return std::string("");
+        else
+            return std::string(", st:") + std::to_string(stride);
+    }();
+
+    std::cout << "[" << api_str << "|" << prec_str << "]"
+              << " t:" << tokens << ", e:" << experts << ", k:" << topk << stride_str
+              << ", hidden:" << hidden_size << ", interm:" << intermediate_size << ", tp:" << tp
+              << ", shrd_interm:" << shared_intermediate_size_0 << "|" << shared_intermediate_size_1
+              << ", go:" << gate_only << ", q:" << fused_quant << std::flush;
+
+    using TypeConfig           = FusedMoeGemmTypeConfig<I, W, O, ST, SW, SQ, KW>;
+    using ADataType            = typename TypeConfig::ADataType;
+    using GDataType            = typename TypeConfig::GDataType;
+    using DDataType            = typename TypeConfig::DDataType;
+    using AccDataType          = typename TypeConfig::AccDataType;
+    using ODataType            = typename TypeConfig::ODataType;
+    using AScaleDataType       = typename TypeConfig::AScaleDataType;
+    using GScaleDataType       = typename TypeConfig::GScaleDataType;
+    using DScaleDataType       = typename TypeConfig::DScaleDataType;
+    using YSmoothScaleDataType = typename TypeConfig::YSmoothScaleDataType;
+    using TopkWeightDataType   = typename TypeConfig::TopkWeightDataType;
+    using IndexDataType        = typename TypeConfig::IndexDataType;
+
+    // host verify
+    ck_tile::HostTensor<ADataType> a_host({tokens, hidden_size}, {stride, 1});
+    ck_tile::HostTensor<GDataType> g_host({experts, shared_intermediate_size_0, hidden_size});
+    ck_tile::HostTensor<DDataType> d_host({experts, hidden_size, shared_intermediate_size_1});
+    ck_tile::HostTensor<ODataType> o_host({tokens, hidden_size}, {stride, 1});
+    ck_tile::HostTensor<AScaleDataType> sa_host({tokens});
+    ck_tile::HostTensor<GScaleDataType> sg_host({shared_intermediate_size_0});
+    ck_tile::HostTensor<DScaleDataType> sd_host({shared_intermediate_size_1});
+    ck_tile::HostTensor<YSmoothScaleDataType> sy_host({shared_intermediate_size_1}); // smooth-quant
+    ck_tile::HostTensor<IndexDataType> topk_ids_host({tokens, topk});                // to be sort
+    ck_tile::HostTensor<TopkWeightDataType> topk_weight_host({tokens, topk});        // to be sort
+
+    int max_num_tokens_padded = topk * tokens + experts * block_m - topk;
+    ck_tile::HostTensor<IndexDataType> sorted_token_ids_host({max_num_tokens_padded});
+    ck_tile::HostTensor<TopkWeightDataType> sorted_weight_host({max_num_tokens_padded});
+    ck_tile::HostTensor<IndexDataType> sorted_expert_ids_host(
+        {(max_num_tokens_padded + block_m - 1) / block_m});
+    ck_tile::HostTensor<IndexDataType> num_sorted_tiles_host({1});
+
+    if(init == 0)
+    {
+        ck_tile::FillStepRange<ADataType>{-.5f, .5f, 0.01f}(a_host);
+        ck_tile::FillStepRange<GDataType>{-.5f, .5f, 0.01f}(g_host);
+        ck_tile::FillStepRange<DDataType, false>{.5f, -.5f, -0.01f}(d_host);
+        ck_tile::FillStepRange<AScaleDataType>{0.f, 1.f, 0.01f}(sa_host);
+        ck_tile::FillStepRange<GScaleDataType>{0.f, 1.f, 0.01f}(sg_host);
+        ck_tile::FillStepRange<DScaleDataType>{0.f, 1.f, 0.01f}(sd_host);
+        ck_tile::FillStepRange<YSmoothScaleDataType>{0.f, 1.f, 0.01f}(sy_host);
+        ck_tile::FillStepRange<TopkWeightDataType>{-.5f, .5f, 0.01f}(topk_weight_host);
+    }
+    else if(init == 1)
+    {
+        ck_tile::FillUniformDistribution<ADataType>{-.5f, .5f, seed, true}(a_host);
+        ck_tile::FillUniformDistribution<GDataType>{-.5f, .5f, seed, true}(g_host);
+        ck_tile::FillUniformDistribution<DDataType>{-.5f, .5f, seed, true}(d_host);
+        ck_tile::FillUniformDistribution<AScaleDataType>{-.5f, .5f, seed, true}(sa_host);
+        ck_tile::FillUniformDistribution<GScaleDataType>{-.5f, .5f, seed, true}(sg_host);
+        ck_tile::FillUniformDistribution<DScaleDataType>{-.5f, .5f, seed, true}(sd_host);
+        ck_tile::FillUniformDistribution<YSmoothScaleDataType>{-.5f, .5f, seed, true}(sy_host);
+        ck_tile::FillUniformDistribution<TopkWeightDataType>{-.5f, .5f, seed, true}(
+            topk_weight_host);
+    }
+    else if(init == 2)
+    {
+        ck_tile::FillNormalDistribution<ADataType>{0.f, 1.f, seed, true}(a_host);
+        ck_tile::FillNormalDistribution<GDataType>{0.f, 1.f, seed, true}(g_host);
+        ck_tile::FillNormalDistribution<DDataType>{0.f, 1.f, seed, true}(d_host);
+        ck_tile::FillNormalDistribution<AScaleDataType>{0.f, 1.f, seed, true}(sa_host);
+        ck_tile::FillNormalDistribution<GScaleDataType>{0.f, 1.f, seed, true}(sg_host);
+        ck_tile::FillNormalDistribution<DScaleDataType>{0.f, 1.f, seed, true}(sd_host);
+        ck_tile::FillNormalDistribution<YSmoothScaleDataType>{0.f, 1.f, seed, true}(sy_host);
+        ck_tile::FillNormalDistribution<TopkWeightDataType>{0.f, 1.f, seed, true}(topk_weight_host);
+    }
+
+    // permute weight
+    ck_tile::HostTensor<GDataType> g_perm_host = shuffle_moe_weight(g_host, prec_w, 1);
+    ck_tile::HostTensor<DDataType> d_perm_host = shuffle_moe_weight(d_host, prec_w, 1);
+
+    // do moe sorting
+    if(balance)
+    {
+        int e_cnt = 0;
+        for(int i = 0; i < static_cast<int>(topk_ids_host.mData.size()); i++)
+        {
+            topk_ids_host.mData[i] = e_cnt;
+            e_cnt++;
+            if(e_cnt >= experts)
+                e_cnt = 0;
+        }
+    }
+    else
+    {
+        topid_unique_gen<IndexDataType>(topk_ids_host.mData, tokens, topk, experts, 11913);
+    }
+
+// leave it here for future debug purpose
+#if 0
+    a_host.loadtxt("../../ater/input_torch.txt");
+
+    topk_ids_host.loadtxt("../../ater/topk_ids_torch.txt", "int");
+    // topk_ids_host.savetxt("topk_ids_2.txt");
+    topk_weight_host.loadtxt("../../ater/topk_weights_torch.txt", "float");
+    std::cout << "------- @@@ " << __LINE__ << std::flush << std::endl;
+
+    g_host.loadtxt("../../ater/w1_torch.txt", "float");
+    std::cout << "------- @@@ " << __LINE__ << std::flush << std::endl;
+    d_host.loadtxt("../../ater/w2_torch.txt", "float");
+    std::cout << "------- @@@ " << __LINE__ << std::flush << std::endl;
+
+    ck_tile::HostTensor<GDataType> g_perm_host = shuffle_moe_weight(g_host, prec_w, 1);
+    std::cout << "------- @@@ " << __LINE__ << std::flush << std::endl;
+    ck_tile::HostTensor<DDataType> d_perm_host = shuffle_moe_weight(d_host, prec_w, 1);
+    std::cout << "------- @@@ " << __LINE__ << std::flush << std::endl;
+#endif
+
+#if 0
+    std::cout << "sorted_token_ids_host:" << sorted_token_ids_host << std::endl;
+    std::cout << "num_sorted_tiles_host:" << num_sorted_tiles_host << std::endl;
+    std::cout << "sorted_expert_ids_host:" << sorted_expert_ids_host << std::endl;
+    std::cout << "topk_weight_host:" << topk_weight_host << std::endl;
+    std::cout << "sorted_weight_host:" << sorted_weight_host << std::endl;
+#endif
+    auto cal_tflops = [&](auto ms) {
+        double flop_gemm_0 =
+            2 * static_cast<double>(tokens) * topk * shared_intermediate_size_0 * hidden_size;
+        double flop_gemm_1 =
+            2 * static_cast<double>(tokens) * topk * shared_intermediate_size_1 * hidden_size;
+        return (flop_gemm_0 + flop_gemm_1) / (static_cast<double>(ms) * 1e-3) / 1e12;
+    };
+
+    // TODO: this method we use expert-by-expert view, just for reference
+    auto cal_tbps = [&](auto ms) {
+        double token_bytes =
+            static_cast<double>(tokens) * topk / experts * hidden_size * sizeof(ADataType);
+        double w0_bytes = static_cast<double>(shared_intermediate_size_0) * experts * hidden_size *
+                          sizeof(GDataType);
+        double w1_bytes = static_cast<double>(shared_intermediate_size_1) * experts * hidden_size *
+                          sizeof(DDataType);
+        double o_bytes =
+            static_cast<double>(tokens) * topk / experts * hidden_size * sizeof(ODataType);
+        double topk_weights_bytes = static_cast<double>(tokens) * topk * sizeof(TopkWeightDataType);
+        // ignore index, they are too small
+
+        return (token_bytes + w0_bytes + w1_bytes + o_bytes + topk_weights_bytes) /
+               (static_cast<double>(ms) * 1e-3) / 1e12;
+    };
+
+    if(api == 0)
+    {
+        ck_tile::DeviceMem a_buf(a_host);
+        ck_tile::DeviceMem g_perm_buf(g_perm_host);
+        ck_tile::DeviceMem d_perm_buf(d_perm_host);
+        ck_tile::DeviceMem sa_buf(sa_host);
+        ck_tile::DeviceMem sg_buf(sg_host);
+        ck_tile::DeviceMem sd_buf(sd_host);
+        ck_tile::DeviceMem sy_buf(sy_host);
+        ck_tile::DeviceMem o_buf(o_host.get_element_space_size_in_bytes());
+
+        ck_tile::DeviceMem topk_ids_buf(topk_ids_host);
+        ck_tile::DeviceMem topk_weight_buf(topk_weight_host);
+
+        ck_tile::DeviceMem sorted_token_ids_buf(
+            sorted_token_ids_host.get_element_space_size_in_bytes());
+        ck_tile::DeviceMem sorted_weight_buf(sorted_weight_host.get_element_space_size_in_bytes());
+        ck_tile::DeviceMem sorted_expert_ids_buf(
+            sorted_expert_ids_host.get_element_space_size_in_bytes());
+        ck_tile::DeviceMem num_sorted_tiles_buf(
+            num_sorted_tiles_host.get_element_space_size_in_bytes());
+
+        fused_moe_traits traits{prec_i,
+                                prec_w,
+                                prec_o,
+                                prec_st,
+                                prec_sw,
+                                prec_sq,
+                                prec_kw,
+                                block_m,
+                                gate_only,
+                                fused_quant};
+
+        fused_moe_args args{a_buf.GetDeviceBuffer(),
+                            fused_quant != 0 ? sa_buf.GetDeviceBuffer() : nullptr,
+                            g_perm_buf.GetDeviceBuffer(),
+                            d_perm_buf.GetDeviceBuffer(),
+                            fused_quant != 0 ? sg_buf.GetDeviceBuffer() : nullptr,
+                            fused_quant != 0 ? sd_buf.GetDeviceBuffer() : nullptr,
+                            fused_quant == 1 ? sy_buf.GetDeviceBuffer() : nullptr,
+                            o_buf.GetDeviceBuffer(),
+                            topk_ids_buf.GetDeviceBuffer(),
+                            topk_weight_buf.GetDeviceBuffer(),
+                            sorted_token_ids_buf.GetDeviceBuffer(),
+                            sorted_weight_buf.GetDeviceBuffer(),
+                            sorted_expert_ids_buf.GetDeviceBuffer(),
+                            num_sorted_tiles_buf.GetDeviceBuffer(),
+                            block_m,
+                            hidden_size,
+                            shared_intermediate_size_0,
+                            tokens,
+                            experts,
+                            topk,
+                            stride};
+        float ave_time = fused_moe(
+            traits, args, ck_tile::stream_config{nullptr, true, kname ? 1 : 0, warmup, repeat});
+
+        if(ave_time < 0)
+        {
+            std::cout << " not supported!" << std::endl << std::flush;
+            return false;
+        }
+
+        // float gb_per_sec = num_byte / 1.E6 / ave_time;
+        std::cout << ", " << ave_time * 1.E3 << " us, " << cal_tflops(ave_time) << " tflops, "
+                  << cal_tbps(ave_time) << " TB/s" << std::flush;
+        bool pass = true;
+
+        if(do_validation)
+        {
+            ck_tile::reference_moe_sorting<TopkWeightDataType, IndexDataType>(
+                topk_ids_host,
+                topk_weight_host,
+                sorted_token_ids_host,
+                sorted_weight_host,
+                sorted_expert_ids_host,
+                num_sorted_tiles_host.mData[0],
+                experts,
+                block_m);
+
+            ck_tile::reference_fused_moe<AccDataType, ck_tile::element_wise::Gelu>(
+                a_host,
+                g_host,
+                d_host,
+                sa_host,
+                sg_host,
+                sd_host,
+                sy_host,
+                o_host,
+                sorted_token_ids_host,
+                sorted_weight_host,
+                sorted_expert_ids_host,
+                num_sorted_tiles_host,
+                topk_ids_host,
+                block_m,
+                tokens,
+                experts,
+                hidden_size,
+                shared_intermediate_size_0,
+                topk,
+                gate_only);
+
+            auto o_dev = o_buf.ToHost<ODataType>();
+            // o_dev.savetxt("gpu-out.txt", "float");
+            auto [rtol, atol] = get_elimit<ADataType>();
+            pass &= ck_tile::check_err(
+                o_dev, o_host, std::string("OUT Error: Incorrect results!"), rtol, atol);
+            std::cout << ", valid:" << (pass ? "y" : "n") << std::flush;
+        }
+        std::cout << std::flush << std::endl;
+        return pass;
+    }
+    else if(api == 1)
+    {
+        ck_tile::reference_moe_sorting<TopkWeightDataType, IndexDataType>(
+            topk_ids_host,
+            topk_weight_host,
+            sorted_token_ids_host,
+            sorted_weight_host,
+            sorted_expert_ids_host,
+            num_sorted_tiles_host.mData[0],
+            experts,
+            block_m);
+
+        // done, preparing GPU buffer
+        ck_tile::DeviceMem a_buf(a_host);
+        ck_tile::DeviceMem g_perm_buf(g_perm_host);
+        ck_tile::DeviceMem d_perm_buf(d_perm_host);
+        ck_tile::DeviceMem sa_buf(sa_host);
+        ck_tile::DeviceMem sg_buf(sg_host);
+        ck_tile::DeviceMem sd_buf(sd_host);
+        ck_tile::DeviceMem sy_buf(sy_host);
+        ck_tile::DeviceMem o_buf(o_host);
+
+        // manually clear output buffer for atomic
+        o_buf.SetZero();
+        //
+
+        ck_tile::DeviceMem sorted_token_ids_buf(sorted_token_ids_host);
+        ck_tile::DeviceMem sorted_weight_buf(sorted_weight_host);
+        ck_tile::DeviceMem sorted_expert_ids_buf(sorted_expert_ids_host);
+        ck_tile::DeviceMem num_sorted_tiles_buf(num_sorted_tiles_host);
+
+        fused_moegemm_traits traits{prec_i,
+                                    prec_w,
+                                    prec_o,
+                                    prec_st,
+                                    prec_sw,
+                                    prec_sq,
+                                    prec_kw,
+                                    block_m,
+                                    gate_only,
+                                    fused_quant};
+
+        fused_moegemm_args args{a_buf.GetDeviceBuffer(),
+                                fused_quant != 0 ? sa_buf.GetDeviceBuffer() : nullptr,
+                                g_perm_buf.GetDeviceBuffer(),
+                                d_perm_buf.GetDeviceBuffer(),
+                                fused_quant != 0 ? sg_buf.GetDeviceBuffer() : nullptr,
+                                fused_quant != 0 ? sd_buf.GetDeviceBuffer() : nullptr,
+                                fused_quant == 1 ? sy_buf.GetDeviceBuffer() : nullptr,
+                                o_buf.GetDeviceBuffer(),
+                                sorted_token_ids_buf.GetDeviceBuffer(),
+                                sorted_weight_buf.GetDeviceBuffer(),
+                                sorted_expert_ids_buf.GetDeviceBuffer(),
+                                num_sorted_tiles_buf.GetDeviceBuffer(),
+                                hidden_size,
+                                shared_intermediate_size_0,
+                                tokens,
+                                experts,
+                                topk,
+                                stride};
+
+        float ave_time = fused_moegemm(
+            traits, args, ck_tile::stream_config{nullptr, true, kname ? 1 : 0, warmup, repeat});
+
+        if(ave_time < 0)
+        {
+            std::cout << " not supported!" << std::endl << std::flush;
+            return false;
+        }
+
+        // float gb_per_sec = num_byte / 1.E6 / ave_time;
+        std::cout << ", " << ave_time * 1.E3 << " us, " << cal_tflops(ave_time) << " tflops, "
+                  << cal_tbps(ave_time) << " TB/s" << std::flush;
+        bool pass = true;
+
+        if(do_validation)
+        {
+            ck_tile::reference_fused_moe<AccDataType, ck_tile::element_wise::Gelu>(
+                a_host,
+                g_host,
+                d_host,
+                sa_host,
+                sg_host,
+                sd_host,
+                sy_host,
+                o_host,
+                sorted_token_ids_host,
+                sorted_weight_host,
+                sorted_expert_ids_host,
+                num_sorted_tiles_host,
+                topk_ids_host,
+                block_m,
+                tokens,
+                experts,
+                hidden_size,
+                shared_intermediate_size_0,
+                topk,
+                gate_only);
+
+            auto o_dev = o_buf.ToHost<ODataType>();
+            // o_dev.savetxt("gpu-out.txt", "float");
+            auto [rtol, atol] = get_elimit<ADataType>();
+            pass &= ck_tile::check_err(
+                o_dev, o_host, std::string("OUT Error: Incorrect results!"), rtol, atol);
+            std::cout << ", valid:" << (pass ? "y" : "n") << std::flush;
+        }
+        std::cout << std::flush << std::endl;
+
+        return pass;
+    }
+    return false;
+}
+
+int main(int argc, char* argv[])
+{
+    auto [result, arg_parser] = create_args(argc, argv);
+    if(!result)
+        return -1;
+
+    std::string prec_i  = arg_parser.get_str("prec_i");
+    std::string prec_w  = arg_parser.get_str("prec_w");
+    std::string prec_o  = arg_parser.get_str("prec_o");
+    std::string prec_st = arg_parser.get_str("prec_st");
+    std::string prec_sw = arg_parser.get_str("prec_sw");
+    std::string prec_sq = arg_parser.get_str("prec_sq");
+    std::string prec_kw = arg_parser.get_str("prec_kw");
+    prec_st             = (prec_st == "auto") ? "fp32" : prec_st;
+    prec_sw             = (prec_sw == "auto") ? "fp32" : prec_sw;
+    prec_sq             = (prec_sq == "auto") ? "fp32" : prec_sq;
+    prec_kw             = (prec_kw == "auto") ? "fp32" : prec_kw;
+
+    // no dynamic quant case
+    if(prec_i == "bf16" && prec_w == "bf16" && prec_o == "bf16" && prec_kw == "fp32")
+    {
+        return run<ck_tile::bf16_t, ck_tile::bf16_t, ck_tile::bf16_t, float, float, float, float>(
+                   arg_parser)
+                   ? 0
+                   : -2;
+    }
+    else if(prec_i == "fp16" && prec_w == "fp16" && prec_o == "fp16" && prec_kw == "fp32")
+    {
+        return run<ck_tile::fp16_t, ck_tile::fp16_t, ck_tile::fp16_t, float, float, float, float>(
+                   arg_parser)
+                   ? 0
+                   : -2;
+    }
+
+    return -3;
+}

example/ck_tile/16_batched_gemm/CMakeLists.txt

+add_executable(tile_example_batched_gemm EXCLUDE_FROM_ALL batched_gemm.cpp)

example/ck_tile/16_batched_gemm/README.md

+# Batched GEMM
+
+This folder contains example for batched GEMM using ck_tile tile-programming implementation.
+
+## build
+```
+# in the root of ck_tile
+mkdir build && cd build
+# you can replace <arch> with the appropriate architecture (for example gfx90a or gfx942) or leave it blank
+sh ../script/cmake-ck-dev.sh  ../ <arch>
+make tile_example_batched_gemm -j
+```
+This will result in an executable `build/bin/tile_example_batched_gemm`
+
+## example
+```
+args:
+              -m     m dimension (default:256)
+              -n     n dimension (default:128)
+              -k     k dimension (default:128)
+       -a_layout     A tensor data layout (default:R) (R for Row, C for Col)
+       -b_layout     B tensor data layout (default:R) (R for Row, C for Col)
+       -c_layout     C tensor data layout (default:R) (R for Row, C for Col)
+       -stride_a     Tensor A stride (default:128)
+       -stride_b     Tensor B stride (default:128)
+       -stride_c     Tensor C stride (default:128)
+ -batch_stride_a     Batch A stride (default:32768)
+ -batch_stride_b     Batch B stride (default:16384)
+ -batch_stride_c     Batch C stride (default:32768)
+    -batch_count     Batch count (default:16)
+              -v     0. No validation, 1. Validation on CPU, 2. Validation on GPU (default:2)
+              -e     Absolute error tolerance (default:1e-5)
+           -prec     data type. fp16/bf16/fp8/bf8 (default:fp16)
+         -warmup     number of iterations before benchmark the kernel (default:10)
+         -repeat     number of iterations to benchmark the kernel (default:100)
+          -timer     gpu:gpu timer, cpu:cpu timer (default:gpu)
+```
\ No newline at end of file

example/ck_tile/16_batched_gemm/batched_gemm.cpp

+// SPDX-License-Identifier: MIT
+// Copyright (c) 2024, Advanced Micro Devices, Inc. All rights reserved.
+
+#include <hip/hip_runtime.h>
+
+#include <cstring>
+#include <iostream>
+#include <ostream>
+#include <string>
+#include <tuple>
+
+#include "ck_tile/core.hpp"
+#include "ck_tile/ops/epilogue.hpp"
+#include "ck_tile/ops/gemm.hpp"
+#include "ck_tile/host.hpp"
+#include "batched_gemm.hpp"
+
+template <typename ALayout, typename BLayout, typename CLayout>
+float batched_gemm(const batched_gemm_kargs& args, const ck_tile::stream_config& s)
+{
+    // The kPadM, kPadN, kPadK & kBlockPerCu should also come from the Codegen part.
+    constexpr bool kPadM        = false;
+    constexpr bool kPadN        = false;
+    constexpr bool kPadK        = false;
+    constexpr bool kTilePermute = false;
+    // The rank and permutation will also be generate out by the CodeGen part.
+    constexpr ck_tile::index_t kOutputRank = 2;
+
+    constexpr int kBlockPerCu = 1;
+
+    // This part comes from the Codegen
+    constexpr ck_tile::index_t M_Tile = 128;
+    constexpr ck_tile::index_t N_Tile = 128;
+    constexpr ck_tile::index_t K_Tile = 32;
+
+    constexpr ck_tile::index_t M_Warp = 2;
+    constexpr ck_tile::index_t N_Warp = 2;
+    constexpr ck_tile::index_t K_Warp = 1;
+
+    constexpr ck_tile::index_t M_Warp_Tile = 32;
+    constexpr ck_tile::index_t N_Warp_Tile = 32;
+    constexpr ck_tile::index_t K_Warp_Tile = 8;
+
+    // Whether doing the CShuffle (transpose before the global memory), depending on the output
+    // layout.
+    constexpr bool CShuffleEpilogue =
+        std::is_same_v<CLayout, ck_tile::tensor_layout::gemm::ColumnMajor>;
+
+    using CodegenGemmShape =
+        ck_tile::TileGemmShape<ck_tile::sequence<M_Tile, N_Tile, K_Tile>,
+                               ck_tile::sequence<M_Warp, N_Warp, K_Warp>,
+                               ck_tile::sequence<M_Warp_Tile, N_Warp_Tile, K_Warp_Tile>>;
+
+    using TilePartitioner = ck_tile::GemmTilePartitioner<CodegenGemmShape>;
+
+    using GemmEpilogue = std::conditional_t<
+        CShuffleEpilogue,
+        ck_tile::CShuffleEpilogue<ck_tile::CShuffleEpilogueProblem<AccDataType,
+                                                                   CDataType,
+                                                                   kPadM,
+                                                                   kPadN,
+                                                                   kTilePermute,
+                                                                   kOutputRank,
+                                                                   1,
+                                                                   0,
+                                                                   TilePartitioner::kM,
+                                                                   TilePartitioner::kN>>,
+        ck_tile::Default2DEpilogue<
+            ck_tile::Default2DEpilogueProblem<AccDataType, CDataType, kPadM, kPadN>>>;
+
+    using CodegenGemmTraits =
+        ck_tile::TileGemmTraits<kPadM, kPadN, kPadK, ALayout, BLayout, CLayout>;
+
+    using CodegenPipelineProblem = ck_tile::
+        GemmPipelineProblem<ADataType, BDataType, AccDataType, CodegenGemmShape, CodegenGemmTraits>;
+
+    using CodegenGemmPipeline = ck_tile::GemmPipelineAGmemBGmemCRegV1<CodegenPipelineProblem>;
+    // ToDo: Will add the codegen part to test different pipeline policies in GEMM.
+    // Now we only use the BlockGemmASmemBSmemCRegV1DefaultPolicy.
+    using Kernel = ck_tile::BatchedGemmKernel<TilePartitioner, CodegenGemmPipeline, GemmEpilogue>;
+
+    auto kargs = Kernel::MakeKargs(args);
+
+    const dim3 grids      = Kernel::GridSize(args);
+    constexpr dim3 blocks = Kernel::BlockSize();
+
+    if(s.log_level_ > 0)
+    {
+        std::cout << "Launching kernel with args:"
+                  << " grid: {" << grids.x << ", " << grids.y << ", " << grids.z << "}"
+                  << ", blocks: {" << blocks.x << ", " << blocks.y << ", " << blocks.z << "}"
+                  << std::endl;
+    }
+
+    float ave_time = ck_tile::launch_kernel(
+        s, ck_tile::make_kernel<blocks.x, kBlockPerCu>(Kernel{}, grids, blocks, 0, kargs));
+
+    return ave_time;
+}
+
+#include "run_batched_gemm_example.inc"
+
+int main(int argc, char* argv[]) { return !run_batched_gemm_example(argc, argv); }

example/ck_tile/16_batched_gemm/batched_gemm.hpp

+// SPDX-License-Identifier: MIT
+// Copyright (c) 2024, Advanced Micro Devices, Inc. All rights reserved.
+
+#pragma once
+
+#include <string>
+
+#include "ck_tile/core.hpp"
+#include "ck_tile/host/kernel_launch.hpp"
+#include "ck_tile/ops/gemm/kernel/batched_gemm_kernel.hpp"
+
+template <typename DataType>
+struct BatchedGemmTypeConfig;
+
+template <>
+struct BatchedGemmTypeConfig<ck_tile::half_t>
+{
+    using ADataType   = ck_tile::half_t;
+    using BDataType   = ck_tile::half_t;
+    using AccDataType = float;
+    using CDataType   = ck_tile::half_t;
+};
+
+using Types = BatchedGemmTypeConfig<ck_tile::half_t>;
+
+// Specific type aliases for easy access
+using ADataType   = Types::ADataType;
+using BDataType   = Types::BDataType;
+using AccDataType = Types::AccDataType;
+using CDataType   = Types::CDataType;
+
+struct batched_gemm_kargs : public ck_tile::BatchedGemmHostArgs
+{
+};
+
+auto create_args(int argc, char* argv[])
+{
+    ck_tile::ArgParser arg_parser;
+    arg_parser.insert("m", "256", "m dimension")
+        .insert("n", "128", "n dimension")
+        .insert("k", "128", "k dimension")
+        .insert("stride_a", "0", "Tensor A stride")
+        .insert("stride_b", "0", "Tensor B stride")
+        .insert("stride_c", "0", "Tensor C stride")
+        .insert("a_layout", "R", "A tensor data layout - Row by default")
+        .insert("b_layout", "R", "B tensor data layout - Row by default")
+        .insert("c_layout", "R", "C tensor data layout - Row by default")
+        .insert("batch_stride_a", "32768", "Batch A stride")
+        .insert("batch_stride_b", "16384", "Batch B stride")
+        .insert("batch_stride_c", "32768", "Batch C stride")
+        .insert("batch_count", "16", "Batch count")
+        .insert("v", "2", "0. No validation, 1. Validation on CPU, 2. Validation on GPU")
+        .insert("prec", "fp16", "data type. fp16/bf16/fp8/bf8")
+        .insert("warmup", "50", "number of iterations before benchmark the kernel")
+        .insert("repeat", "100", "number of iterations to benchmark the kernel")
+        .insert("timer", "gpu", "gpu:gpu timer, cpu:cpu timer");
+
+    bool result = arg_parser.parse(argc, argv);
+    return std::make_tuple(result, arg_parser);
+}
+
+// host API
+float batched_gemm(batched_gemm_kargs args, const ck_tile::stream_config& s);

example/ck_tile/16_batched_gemm/run_batched_gemm_example.inc

+// SPDX-License-Identifier: MIT
+// Copyright (c) 2024, Advanced Micro Devices, Inc. All rights reserved.
+
+#pragma once
+
+template <typename ALayout, typename BLayout, typename CLayout>
+float invoke_batched_gemm(ck_tile::DeviceMem& a_m_k_dev_buf,
+                          ck_tile::DeviceMem& b_k_n_dev_buf,
+                          ck_tile::DeviceMem& c_m_n_dev_buf,
+                          ck_tile::index_t M,
+                          ck_tile::index_t N,
+                          ck_tile::index_t K,
+                          ck_tile::index_t stride_A,
+                          ck_tile::index_t stride_B,
+                          ck_tile::index_t stride_C,
+                          ck_tile::index_t batch_stride_A,
+                          ck_tile::index_t batch_stride_B,
+                          ck_tile::index_t batch_stride_C,
+                          ck_tile::index_t batch_count,
+                          int n_warmup,
+                          int n_repeat)
+{
+    batched_gemm_kargs args;
+    args.a_ptr          = a_m_k_dev_buf.GetDeviceBuffer();
+    args.b_ptr          = b_k_n_dev_buf.GetDeviceBuffer();
+    args.c_ptr          = c_m_n_dev_buf.GetDeviceBuffer();
+    args.M              = M;
+    args.N              = N;
+    args.K              = K;
+    args.stride_A       = stride_A;
+    args.stride_B       = stride_B;
+    args.stride_C       = stride_C;
+    args.batch_stride_A = batch_stride_A;
+    args.batch_stride_B = batch_stride_B;
+    args.batch_stride_C = batch_stride_C;
+    args.batch_count    = batch_count;
+
+    float ave_time = batched_gemm<ALayout, BLayout, CLayout>(
+        args, ck_tile::stream_config{nullptr, true, 1, n_warmup, n_repeat});
+
+    std::string op_name{"Batched Gemm"};
+    std::size_t flop     = std::size_t(2) * batch_count * M * N * K;
+    std::size_t num_byte = sizeof(ADataType) * batch_count * M * K +
+                           sizeof(BDataType) * batch_count * N * K +
+                           sizeof(CDataType) * batch_count * M * N;
+    float tflops     = static_cast<float>(flop) / 1.E9 / ave_time;
+    float gb_per_sec = num_byte / 1.E6 / ave_time;
+
+    std::cout << "Run " << op_name << "kernel with M =" << M << " N =" << N << " K =" << K
+              << " StrideA =" << stride_A << " StrideB =" << stride_B << " StrideC =" << stride_C
+              << " batch_stride_A =" << batch_stride_A << " batch_stride_B =" << batch_stride_B
+              << " batch_stride_C =" << batch_stride_C << " batch_count =" << batch_count << " : "
+              << ave_time << " ms, " << tflops << " TFlops, " << gb_per_sec << " GB/s, "
+              << std::endl;
+
+    return ave_time;
+}
+
+template <typename ALayout, typename BLayout, typename CLayout>
+int run_batched_gemm_example_with_layouts(int argc,
+                                          char* argv[],
+                                          const ALayout a_layout                  = ALayout{},
+                                          const BLayout b_layout                  = BLayout{},
+                                          [[maybe_unused]] const CLayout c_layout = CLayout{})
+{
+    auto [result, arg_parser] = create_args(argc, argv);
+    if(!result)
+        return -1;
+
+    ck_tile::index_t M = arg_parser.get_int("m");
+    ck_tile::index_t N = arg_parser.get_int("n");
+    ck_tile::index_t K = arg_parser.get_int("k");
+
+    ck_tile::index_t stride_A = arg_parser.get_int("stride_a");
+    ck_tile::index_t stride_B = arg_parser.get_int("stride_b");
+    ck_tile::index_t stride_C = arg_parser.get_int("stride_c");
+
+    ck_tile::index_t batch_stride_A = arg_parser.get_int("batch_stride_a");
+    ck_tile::index_t batch_stride_B = arg_parser.get_int("batch_stride_b");
+    ck_tile::index_t batch_stride_C = arg_parser.get_int("batch_stride_c");
+    ck_tile::index_t batch_count    = arg_parser.get_int("batch_count");
+
+    int n_warmup = arg_parser.get_int("warmup");
+    int n_repeat = arg_parser.get_int("repeat");
+
+    using namespace ck_tile::literals;
+
+    auto f_host_tensor_descriptor = [](std::size_t batch_count_,
+                                       std::size_t row,
+                                       std::size_t col,
+                                       std::size_t stride,
+                                       std::size_t batch_stride,
+                                       auto layout) {
+        if constexpr(std::is_same_v<decltype(layout), ck_tile::tensor_layout::gemm::RowMajor>)
+        {
+            return ck_tile::HostTensorDescriptor({batch_count_, row, col},
+                                                 {batch_stride, stride, 1_uz});
+        }
+        else
+        {
+            return ck_tile::HostTensorDescriptor({batch_count_, row, col},
+                                                 {batch_stride, 1_uz, stride});
+        }
+    };
+
+    auto f_get_default_stride = [](std::size_t row,
+                                   std::size_t col,
+                                   std::size_t stride,
+                                   auto layout) {
+        if(stride == 0)
+        {
+            // give a chance if stride is zero, return a default packed stride
+            if constexpr(std::is_same_v<decltype(layout), ck_tile::tensor_layout::gemm::RowMajor>)
+            {
+                return col;
+            }
+            else
+            {
+                return row;
+            }
+        }
+        else
+            return stride;
+    };
+
+    stride_A = f_get_default_stride(M, K, stride_A, a_layout);
+    stride_B = f_get_default_stride(K, N, stride_B, b_layout);
+    stride_C = f_get_default_stride(M, N, stride_C, c_layout);
+
+    ck_tile::HostTensor<ADataType> a_m_k(
+        f_host_tensor_descriptor(batch_count, M, K, stride_A, batch_stride_A, a_layout));
+    ck_tile::HostTensor<BDataType> b_k_n(
+        f_host_tensor_descriptor(batch_count, K, N, stride_B, batch_stride_B, b_layout));
+    ck_tile::HostTensor<CDataType> c_m_n_dev_result(
+        f_host_tensor_descriptor(batch_count, M, N, stride_C, batch_stride_C, c_layout));
+
+    ck_tile::FillUniformDistribution<ADataType>{-5.f, 5.f}(a_m_k);
+    ck_tile::FillUniformDistribution<BDataType>{-5.f, 5.f}(b_k_n);
+
+    ck_tile::DeviceMem a_m_k_dev_buf(a_m_k.get_element_space_size_in_bytes());
+    ck_tile::DeviceMem b_k_n_dev_buf(b_k_n.get_element_space_size_in_bytes());
+    ck_tile::DeviceMem c_m_n_dev_buf(c_m_n_dev_result.get_element_space_size_in_bytes());
+
+    a_m_k_dev_buf.ToDevice(a_m_k.data());
+    b_k_n_dev_buf.ToDevice(b_k_n.data());
+    c_m_n_dev_buf.SetZero();
+    c_m_n_dev_result.SetZero();
+
+    invoke_batched_gemm<ALayout, BLayout, CLayout>(a_m_k_dev_buf,
+                                                   b_k_n_dev_buf,
+                                                   c_m_n_dev_buf,
+                                                   M,
+                                                   N,
+                                                   K,
+                                                   stride_A,
+                                                   stride_B,
+                                                   stride_C,
+                                                   batch_stride_A,
+                                                   batch_stride_B,
+                                                   batch_stride_C,
+                                                   batch_count,
+                                                   n_warmup,
+                                                   n_repeat);
+
+    c_m_n_dev_buf.FromDevice(c_m_n_dev_result.data());
+    bool pass = true;
+
+    if(arg_parser.get_int("v") == 1)
+    {
+        ck_tile::HostTensor<CDataType> c_m_n_host_ref(
+            f_host_tensor_descriptor(batch_count, M, N, stride_C, batch_stride_C, CLayout{}));
+        c_m_n_host_ref.SetZero();
+
+        const auto b_n_k = b_k_n.transpose({0, 2, 1});
+
+        ck_tile::reference_batched_gemm<ADataType, BDataType, AccDataType, CDataType>(
+            a_m_k, b_n_k, c_m_n_host_ref);
+
+        pass = ck_tile::check_err(c_m_n_dev_result, c_m_n_host_ref);
+
+        std::cout << "The CPU veification result is:" << (pass ? "correct" : "fail") << std::endl;
+    }
+    else if(arg_parser.get_int("v") == 2)
+    {
+        ck_tile::HostTensor<CDataType> c_m_n_gpu_ref(
+            f_host_tensor_descriptor(batch_count, M, N, stride_C, batch_stride_C, CLayout{}));
+        ck_tile::DeviceMem c_m_n_gpu_buf_ref(c_m_n_gpu_ref.get_element_space_size_in_bytes());
+        c_m_n_gpu_ref.SetZero();
+        c_m_n_gpu_buf_ref.SetZero();
+
+        ck_tile::reference_batched_gemm_gpu<ADataType,
+                                            BDataType,
+                                            AccDataType,
+                                            CDataType,
+                                            ALayout,
+                                            BLayout,
+                                            CLayout>(a_m_k_dev_buf,
+                                                     b_k_n_dev_buf,
+                                                     c_m_n_gpu_buf_ref,
+                                                     M,
+                                                     N,
+                                                     K,
+                                                     stride_A,
+                                                     stride_B,
+                                                     stride_C,
+                                                     batch_stride_A,
+                                                     batch_stride_B,
+                                                     batch_stride_C,
+                                                     batch_count);
+
+        c_m_n_gpu_buf_ref.FromDevice(c_m_n_gpu_ref.data());
+        pass = ck_tile::check_err(c_m_n_dev_result, c_m_n_gpu_ref);
+
+        std::cout << "The GPU verification result is: " << (pass ? "correct" : "fail") << std::endl;
+    }
+
+    return pass;
+}
+
+int run_batched_gemm_example(int argc, char* argv[])
+{
+    auto [result, arg_parser] = create_args(argc, argv);
+    if(!result)
+        return -1;
+
+    using Row = ck_tile::tensor_layout::gemm::RowMajor;
+    using Col = ck_tile::tensor_layout::gemm::ColumnMajor;
+
+    std::string a_layout = arg_parser.get_str("a_layout");
+    std::string b_layout = arg_parser.get_str("b_layout");
+
+    if(a_layout == "R" && b_layout == "R")
+    {
+        return run_batched_gemm_example_with_layouts(argc, argv, Row{}, Row{}, Row{});
+    }
+    else if(a_layout == "R" && b_layout == "C")
+    {
+        return run_batched_gemm_example_with_layouts(argc, argv, Row{}, Col{}, Row{});
+    }
+    // TODO: Fixme: with latest changes to GemmPipelineAGmemBGmemCRegV1DefaultPolicy below do not
+    // work else if(a_layout == "C" && b_layout == "C")
+    // {
+    //     return run_batched_gemm_example_with_layouts(argc, argv, Col{}, Col{}, Row{});
+    // }
+    // else if(a_layout == "C" && b_layout == "R")
+    // {
+    //     return run_batched_gemm_example_with_layouts(argc, argv, Col{}, Row{}, Row{});
+    // }
+    else
+    {
+        throw std::runtime_error("Unsupported data layout configuration for A,B and C tensors!");
+    }
+}

example/ck_tile/CMakeLists.txt

@@ -11,3 +11,8 @@ add_subdirectory(06_permute)
 add_subdirectory(09_topk_softmax)
 add_subdirectory(10_rmsnorm2d)
 add_subdirectory(11_add_rmsnorm2d_rdquant)
+add_subdirectory(12_smoothquant)
+add_subdirectory(13_moe_sorting)
+add_subdirectory(14_moe_smoothquant)
+add_subdirectory(15_fused_moe)
+add_subdirectory(16_batched_gemm)

include/ck/ck.hpp

@@ -61,13 +61,15 @@
 #define __gfx101__
 #endif
 #if defined(__gfx1030__) || defined(__gfx1031__) || defined(__gfx1032__) || \
-    defined(__gfx1034__) || defined(__gfx1035__) || defined(__gfx1036__)
+    defined(__gfx1034__) || defined(__gfx1035__) || defined(__gfx1036__) || \
+    defined(__gfx10_3_generic__)
 #define __gfx103__
 #endif
-#if defined(__gfx1100__) || defined(__gfx1101__) || defined(__gfx1102__) || defined(__gfx1103__)
+#if defined(__gfx1100__) || defined(__gfx1101__) || defined(__gfx1102__) || \
+    defined(__gfx1103__) || defined(__gfx11_generic__)
 #define __gfx11__
 #endif
-#if defined(__gfx1200__) || defined(__gfx1201__)
+#if defined(__gfx1200__) || defined(__gfx1201__) || defined(__gfx12_generic__)
 #define __gfx12__
 #endif


library/include/ck/library/utility/check_err.hpp → include/ck/library/utility/check_err.hpp

@@ -24,7 +24,7 @@ namespace ck {
 namespace utils {

 template <typename ComputeDataType, typename OutDataType, typename AccDataType = ComputeDataType>
-double get_relative_threshold(const int numberOfAccumulations = 1)
+double get_relative_threshold(const int number_of_accumulations = 1)
 {
     using F8   = ck::f8_t;
     using F16  = ck::half_t;
@@ -79,13 +79,13 @@ double get_relative_threshold(const int numberOfAccumulations = 1)
     }
     else
     {
-        acc_error = std::pow(2, -NumericUtils<AccDataType>::mant) * 0.5 * numberOfAccumulations;
+        acc_error = std::pow(2, -NumericUtils<AccDataType>::mant) * 0.5 * number_of_accumulations;
     }
     return std::max(acc_error, midway_error);
 }

 template <typename ComputeDataType, typename OutDataType, typename AccDataType = ComputeDataType>
-double get_absolute_threshold(const double max_possible_num, const int numberOfAccumulations = 1)
+double get_absolute_threshold(const double max_possible_num, const int number_of_accumulations = 1)
 {
     using F8   = ck::f8_t;
     using F16  = ck::half_t;
@@ -142,7 +142,7 @@ double get_absolute_threshold(const double max_possible_num, const int numberOfA
     else
     {
         acc_error =
-            std::pow(2, expo - NumericUtils<AccDataType>::mant) * 0.5 * numberOfAccumulations;
+            std::pow(2, expo - NumericUtils<AccDataType>::mant) * 0.5 * number_of_accumulations;
     }
     return std::max(acc_error, midway_error);
 }
@@ -206,7 +206,7 @@ typename std::enable_if<
 check_err(const Range& out,
           const RefRange& ref,
           const std::string& msg = "Error: Incorrect results!",
-          double rtol            = 1e-3,
+          double rtol            = 1e-1,
           double atol            = 1e-3)
 {
     if(out.size() != ref.size())
