Initial commit CI/CD

hydit/train.sh

+task_flag="dit_g2_full_1024p"                                 # the task flag is used to identify folders.
+resume_module_root=./ckpts/t2i/model/pytorch_model_distill.pt # checkpoint root for model resume
+resume_ema_root=./ckpts/t2i/model/pytorch_model_ema.pt      # checkpoint root for ema resume
+index_file=dataset/porcelain/jsons/porcelain.json             # index file for dataloader
+results_dir=./log_EXP                                         # save root for results
+batch_size=1                                                  # training batch size
+image_size=1024                                               # training image resolution
+grad_accu_steps=1                                             # gradient accumulation
+warmup_num_steps=0                                            # warm-up steps
+lr=0.0001                                                     # learning rate
+ckpt_every=9999999                                            # create a ckpt every a few steps.
+ckpt_latest_every=9999999                                     # create a ckpt named `latest.pt` every a few steps.
+ckpt_every_n_epoch=2                                          # create a ckpt every a few epochs.
+epochs=8                                                      # total training epochs
+
+
+sh $(dirname "$0")/run_g.sh \
+    --task-flag ${task_flag} \
+    --noise-schedule scaled_linear --beta-start 0.00085 --beta-end 0.018 \
+    --predict-type v_prediction \
+    --uncond-p 0 \
+    --uncond-p-t5 0 \
+    --index-file ${index_file} \
+    --random-flip \
+    --lr ${lr} \
+    --batch-size ${batch_size} \
+    --image-size ${image_size} \
+    --global-seed 999 \
+    --grad-accu-steps ${grad_accu_steps} \
+    --warmup-num-steps ${warmup_num_steps} \
+    --use-flash-attn \
+    --use-fp16 \
+    --extra-fp16 \
+    --results-dir ${results_dir} \
+    --resume \
+    --resume-module-root ${resume_module_root} \
+    --resume-ema-root ${resume_ema_root} \
+    --epochs ${epochs} \
+    --ckpt-every ${ckpt_every} \
+    --ckpt-latest-every ${ckpt_latest_every} \
+    --ckpt-every-n-epoch ${ckpt_every_n_epoch} \
+    --log-every 10 \
+    --deepspeed \
+    --use-zero-stage 2 \
+    --gradient-checkpointing \
+    --cpu-offloading \
+    "$@"

hydit/train_controlnet.sh

+task_flag="canny_controlnet"                                   # the task flag is used to identify folders.
+control_type=canny
+resume_module_root=./ckpts/t2i/model/pytorch_model_distill.pt  # checkpoint root for resume
+index_file=/path/to/your/indexfile                             # index file for dataloader
+results_dir=./log_EXP                                          # save root for results
+batch_size=1                                                   # training batch size
+image_size=1024                                                # training image resolution
+grad_accu_steps=2                                              # gradient accumulation
+warmup_num_steps=0                                             # warm-up steps
+lr=0.0001                                                      # learning rate
+ckpt_every=10000                                               # create a ckpt every a few steps.
+ckpt_latest_every=5000                                         # create a ckpt named `latest.pt` every a few steps.
+epochs=100                                                     # total training epochs
+
+
+sh $(dirname "$0")/run_g_controlnet.sh \
+    --task-flag ${task_flag} \
+    --control-type ${control_type} \
+    --noise-schedule scaled_linear --beta-start 0.00085 --beta-end 0.018 \
+    --predict-type v_prediction \
+    --uncond-p 0.44 \
+    --uncond-p-t5 0.44 \
+    --index-file ${index_file} \
+    --random-flip \
+    --lr ${lr} \
+    --batch-size ${batch_size} \
+    --image-size ${image_size} \
+    --global-seed 999 \
+    --grad-accu-steps ${grad_accu_steps} \
+    --warmup-num-steps ${warmup_num_steps} \
+    --use-flash-attn \
+    --use-fp16 \
+    --results-dir ${results_dir} \
+    --resume \
+    --resume-module-root ${resume_module_root} \
+    --epochs ${epochs} \
+    --ckpt-every ${ckpt_every} \
+    --ckpt-latest-every ${ckpt_latest_every} \
+    --log-every 10 \
+    --deepspeed \
+    --deepspeed-optimizer \
+    --use-zero-stage 2 \
+    --gradient-checkpointing \
+    "$@"

hydit/train_deepspeed.py

+import gc
+import json
+import os
+import random
+import sys
+import time
+from functools import partial
+from glob import glob
+
+import deepspeed
+import numpy as np
+import torch
+import torch.distributed as dist
+from diffusers.models import AutoencoderKL
+from peft import LoraConfig, get_peft_model
+from torch.utils.data import DataLoader
+from transformers import BertModel, BertTokenizer, logging as tf_logging
+
+from IndexKits.index_kits import ResolutionGroup
+from IndexKits.index_kits.sampler import (
+    DistributedSamplerWithStartIndex,
+    BlockDistributedSampler,
+)
+from hydit.config import get_args
+from hydit.constants import VAE_EMA_PATH, TEXT_ENCODER, TOKENIZER, T5_ENCODER
+from hydit.data_loader.arrow_load_stream import TextImageArrowStream
+from hydit.diffusion import create_diffusion
+from hydit.ds_config import deepspeed_config_from_args
+from hydit.lr_scheduler import WarmupLR
+from hydit.modules.ema import EMA
+from hydit.modules.fp16_layers import Float16Module
+from hydit.modules.models import HUNYUAN_DIT_MODELS, HunYuanDiT
+from hydit.modules.text_encoder import MT5Embedder
+from hydit.modules.posemb_layers import init_image_posemb
+from hydit.utils.tools import create_exp_folder, model_resume, get_trainable_params
+
+import bitsandbytes as bnb
+
+
+def deepspeed_initialize(args, logger, model, opt, deepspeed_config):
+    logger.info(f"Initialize deepspeed...")
+    logger.info(f"    Using deepspeed optimizer")
+
+    def get_learning_rate_scheduler(warmup_min_lr, lr, warmup_num_steps, opt):
+        return WarmupLR(opt, warmup_min_lr, lr, warmup_num_steps)
+
+    logger.info(
+        f"    Building scheduler with warmup_min_lr={args.warmup_min_lr}, warmup_num_steps={args.warmup_num_steps}"
+    )
+    model, opt, _, scheduler = deepspeed.initialize(
+        model=model,
+        optimizer=opt,
+        model_parameters=get_trainable_params(model),
+        config_params=deepspeed_config,
+        args=args,
+        lr_scheduler=(
+            partial(
+                get_learning_rate_scheduler,
+                args.warmup_min_lr,
+                args.lr,
+                args.warmup_num_steps,
+            )
+            if args.warmup_num_steps > 0
+            else None
+        ),
+    )
+    return model, opt, scheduler
+
+
+def save_checkpoint(
+    args, rank, logger, model, ema, epoch, train_steps, checkpoint_dir, by="step"
+):
+    def save_lora_weight(checkpoint_dir, client_state, tag=f"{train_steps:07d}.pt"):
+        cur_ckpt_save_dir = f"{checkpoint_dir}/{tag}"
+        if rank == 0:
+            if args.use_fp16:
+                target_module = getattr(model.module, 'module', model.module)
+                target_module.save_pretrained(cur_ckpt_save_dir)
+            else:
+                model.module.save_pretrained(cur_ckpt_save_dir)
+
+    def save_model_weight(client_state, tag):
+        checkpoint_path = f"{checkpoint_dir}/{tag}"
+        try:
+            if args.training_parts == "lora":
+                save_lora_weight(checkpoint_dir, client_state, tag=tag)
+            else:
+                model.save_checkpoint(
+                    checkpoint_dir, client_state=client_state, tag=tag
+                )
+            logger.info(f"Saved checkpoint to {checkpoint_path}")
+        except Exception as e:
+            logger.error(f"Saved failed to {checkpoint_path}. {type(e)}: {e}")
+            return False, ""
+        return True, checkpoint_path
+
+    client_state = {"steps": train_steps, "epoch": epoch, "args": args}
+    if ema is not None:
+        client_state["ema"] = ema.state_dict()
+
+    # Save model weights by epoch or step
+    dst_paths = []
+    if by == "epoch":
+        tag = f"e{epoch:04d}.pt"
+        dst_paths.append(save_model_weight(client_state, tag))
+    elif by == "step":
+        if train_steps % args.ckpt_every == 0:
+            tag = f"{train_steps:07d}.pt"
+            dst_paths.append(save_model_weight(client_state, tag))
+        if (
+            train_steps % args.ckpt_latest_every == 0
+            or train_steps == args.max_training_steps
+        ):
+            tag = "latest.pt"
+            dst_paths.append(save_model_weight(client_state, tag))
+    elif by == "final":
+        tag = "final.pt"
+        dst_paths.append(save_model_weight(client_state, tag))
+    else:
+        raise ValueError(f"Unknown save checkpoint method: {by}")
+
+    saved = any([state for state, _ in dst_paths])
+    if not saved:
+        return False
+
+    # Maybe clear optimizer states
+    if not args.save_optimizer_state:
+        dist.barrier()
+        if rank == 0 and len(dst_paths) > 0:
+            # Delete optimizer states to avoid occupying too much disk space.
+            for dst_path in dst_paths:
+                for opt_state_path in glob(f"{dst_path}/zero_*_optim_states.pt"):
+                    os.remove(opt_state_path)
+
+    return True
+
+
+@torch.no_grad()
+def prepare_model_inputs(
+    args, batch, device, vae, text_encoder, text_encoder_t5, freqs_cis_img
+):
+    (
+        image,
+        text_embedding,
+        text_embedding_mask,
+        text_embedding_t5,
+        text_embedding_mask_t5,
+        kwargs,
+    ) = batch
+
+    # clip & mT5 text embedding
+    text_embedding = text_embedding.to(device)
+    text_embedding_mask = text_embedding_mask.to(device)
+    encoder_hidden_states = text_encoder(
+        text_embedding.to(device),
+        attention_mask=text_embedding_mask.to(device),
+    )[0]
+    text_embedding_t5 = text_embedding_t5.to(device).squeeze(1)
+    text_embedding_mask_t5 = text_embedding_mask_t5.to(device).squeeze(1)
+    with torch.no_grad():
+        output_t5 = text_encoder_t5(
+            input_ids=text_embedding_t5,
+            attention_mask=(
+                text_embedding_mask_t5 if T5_ENCODER["attention_mask"] else None
+            ),
+            output_hidden_states=True,
+        )
+        encoder_hidden_states_t5 = output_t5["hidden_states"][
+            T5_ENCODER["layer_index"]
+        ].detach()
+
+    # additional condition
+    if args.size_cond:
+        image_meta_size = kwargs["image_meta_size"].to(device)
+    else:
+        image_meta_size = None
+    if args.use_style_cond:
+        style = kwargs["style"].to(device)
+    else:
+        style = None
+
+    if args.extra_fp16:
+        image = image.half()
+
+    # Map input images to latent space + normalize latents:
+    image = image.to(device)
+    vae_scaling_factor = vae.config.scaling_factor
+    latents = vae.encode(image).latent_dist.sample().mul_(vae_scaling_factor)
+
+    # positional embedding
+    _, _, height, width = image.shape
+    reso = f"{height}x{width}"
+    cos_cis_img, sin_cis_img = freqs_cis_img[reso]
+
+    # Model conditions
+    model_kwargs = dict(
+        encoder_hidden_states=encoder_hidden_states,
+        text_embedding_mask=text_embedding_mask,
+        encoder_hidden_states_t5=encoder_hidden_states_t5,
+        text_embedding_mask_t5=text_embedding_mask_t5,
+        image_meta_size=image_meta_size,
+        style=style,
+        cos_cis_img=cos_cis_img,
+        sin_cis_img=sin_cis_img,
+    )
+
+    return latents, model_kwargs
+
+
+def main(args):
+    if args.training_parts == "lora":
+        args.use_ema = False
+
+    assert torch.cuda.is_available(), "Training currently requires at least one GPU."
+
+    dist.init_process_group("nccl")
+    world_size = dist.get_world_size()
+    batch_size = args.batch_size
+    grad_accu_steps = args.grad_accu_steps
+    global_batch_size = world_size * batch_size * grad_accu_steps
+
+    rank = dist.get_rank()
+    device = rank % torch.cuda.device_count()
+    seed = args.global_seed * world_size + rank
+    random.seed(seed)
+    np.random.seed(seed)
+    torch.manual_seed(seed)
+    torch.cuda.manual_seed_all(seed)
+    torch.cuda.set_device(device)
+    print(f"Starting rank={rank}, seed={seed}, world_size={world_size}.")
+    deepspeed_config = deepspeed_config_from_args(args, global_batch_size)
+
+    # Setup an experiment folder
+    experiment_dir, checkpoint_dir, logger = create_exp_folder(args, rank)
+
+    # Log all the arguments
+    logger.info(sys.argv)
+    logger.info(str(args))
+    # Save to a json file
+    args_dict = vars(args)
+    args_dict["world_size"] = world_size
+    with open(f"{experiment_dir}/args.json", "w") as f:
+        json.dump(args_dict, f, indent=4)
+
+    # Disable the message "Some weights of the model checkpoint at ... were not used when initializing BertModel."
+    # If needed, just comment the following line.
+    tf_logging.set_verbosity_error()
+
+    # ===========================================================================
+    # Building HYDIT
+    # ===========================================================================
+
+    logger.info("Building HYDIT Model.")
+
+    # ---------------------------------------------------------------------------
+    #   Training sample base size, such as 256/512/1024. Notice that this size is
+    #   just a base size, not necessary the actual size of training samples. Actual
+    #   size of the training samples are correlated with `resolutions` when enabling
+    #   multi-resolution training.
+    # ---------------------------------------------------------------------------
+    image_size = args.image_size
+    if len(image_size) == 1:
+        image_size = [image_size[0], image_size[0]]
+    if len(image_size) != 2:
+        raise ValueError(f"Invalid image size: {args.image_size}")
+    assert image_size[0] % 8 == 0 and image_size[1] % 8 == 0, (
+        "Image size must be divisible by 8 (for the VAE encoder). " f"got {image_size}"
+    )
+    latent_size = [image_size[0] // 8, image_size[1] // 8]
+
+    # initialize model by deepspeed
+    # assert args.deepspeed, f"Must enable deepspeed in this script: train_deepspeed.py"
+    if args.deepspeed:
+        with deepspeed.zero.Init(
+            data_parallel_group=torch.distributed.group.WORLD,
+            remote_device=None if args.remote_device == "none" else args.remote_device,
+            config_dict_or_path=deepspeed_config,
+            mpu=None,
+            enabled=args.zero_stage == 3,
+        ):
+            model = HUNYUAN_DIT_MODELS[args.model](
+                args,
+                input_size=latent_size,
+                log_fn=logger.info,
+            )
+    else:
+        model = HUNYUAN_DIT_MODELS[args.model](
+            args,
+            input_size=latent_size,
+            log_fn=logger.info,
+        )
+        model.to(device)
+    # Multi-resolution / Single-resolution training.
+    if args.multireso:
+        resolutions = ResolutionGroup(
+            image_size[0],
+            align=16,
+            step=args.reso_step,
+            target_ratios=args.target_ratios,
+        ).data
+    else:
+        resolutions = ResolutionGroup(
+            image_size[0], align=16, target_ratios=["1:1"]
+        ).data
+
+    freqs_cis_img = init_image_posemb(
+        args.rope_img,
+        resolutions=resolutions,
+        patch_size=model.patch_size,
+        hidden_size=model.hidden_size,
+        num_heads=model.num_heads,
+        log_fn=logger.info,
+        rope_real=args.rope_real,
+    )
+
+    # Create EMA model and convert to fp16 if needed.
+    ema = None
+    if args.use_ema:
+        ema = EMA(args, model, device, logger)
+
+    # Setup gradient checkpointing
+    if args.gradient_checkpointing:
+        model.enable_gradient_checkpointing()
+
+    # Setup FP16 main model:
+    if args.use_fp16:
+        model = Float16Module(model, args)
+    logger.info(
+        f"    Using main model with data type {'fp16' if args.use_fp16 else 'fp32'}"
+    )
+
+    diffusion = create_diffusion(
+        noise_schedule=args.noise_schedule,
+        predict_type=args.predict_type,
+        learn_sigma=args.learn_sigma,
+        mse_loss_weight_type=args.mse_loss_weight_type,
+        beta_start=args.beta_start,
+        beta_end=args.beta_end,
+        noise_offset=args.noise_offset,
+    )
+
+    # Setup VAE
+    logger.info(f"    Loading vae from {VAE_EMA_PATH}")
+    vae = AutoencoderKL.from_pretrained(VAE_EMA_PATH)
+    # Setup BERT text encoder
+    logger.info(f"    Loading Bert text encoder from {TEXT_ENCODER}")
+    text_encoder = BertModel.from_pretrained(TEXT_ENCODER, False, revision=None)
+    # Setup BERT tokenizer:
+    logger.info(f"    Loading Bert tokenizer from {TOKENIZER}")
+    tokenizer = BertTokenizer.from_pretrained(TOKENIZER)
+    # Setup T5 text encoder
+    mt5_path = T5_ENCODER["MT5"]
+    embedder_t5 = MT5Embedder(
+        mt5_path, torch_dtype=T5_ENCODER["torch_dtype"], max_length=args.text_len_t5
+    )
+    tokenizer_t5 = embedder_t5.tokenizer
+    text_encoder_t5 = embedder_t5.model
+
+    if args.extra_fp16:
+        logger.info(f"    Using fp16 for extra modules: vae, text_encoder")
+        vae = vae.half().to(device)
+        text_encoder = text_encoder.half().to(device)
+        text_encoder_t5 = text_encoder_t5.half().to(device)
+    else:
+        vae = vae.to(device)
+        text_encoder = text_encoder.to(device)
+        text_encoder_t5 = text_encoder_t5.to(device)
+
+    logger.info(
+        f"    Optimizer parameters: lr={args.lr}, weight_decay={args.weight_decay}"
+    )
+
+    logger.info("    Using deepspeed optimizer")
+    opt = None
+
+    # ===========================================================================
+    # Building Dataset
+    # ===========================================================================
+
+    logger.info(f"Building Streaming Dataset.")
+    logger.info(f"    Loading index file {args.index_file} (v2)")
+
+    dataset = TextImageArrowStream(
+        args=args,
+        resolution=image_size[0],
+        random_flip=args.random_flip,
+        log_fn=logger.info,
+        index_file=args.index_file,
+        multireso=args.multireso,
+        batch_size=batch_size,
+        world_size=world_size,
+        random_shrink_size_cond=args.random_shrink_size_cond,
+        merge_src_cond=args.merge_src_cond,
+        uncond_p=args.uncond_p,
+        text_ctx_len=args.text_len,
+        tokenizer=tokenizer,
+        uncond_p_t5=args.uncond_p_t5,
+        text_ctx_len_t5=args.text_len_t5,
+        tokenizer_t5=tokenizer_t5,
+    )
+    if args.multireso:
+        sampler = BlockDistributedSampler(
+            dataset,
+            num_replicas=world_size,
+            rank=rank,
+            seed=args.global_seed,
+            shuffle=False,
+            drop_last=True,
+            batch_size=batch_size,
+        )
+    else:
+        sampler = DistributedSamplerWithStartIndex(
+            dataset,
+            num_replicas=world_size,
+            rank=rank,
+            seed=args.global_seed,
+            shuffle=False,
+            drop_last=True,
+        )
+    loader = DataLoader(
+        dataset,
+        batch_size=batch_size,
+        shuffle=False,
+        sampler=sampler,
+        num_workers=args.num_workers,
+        pin_memory=True,
+        drop_last=True,
+    )
+    logger.info(f"    Dataset contains {len(dataset):,} images.")
+    logger.info(f"    Index file: {args.index_file}.")
+    if args.multireso:
+        logger.info(
+            f"    Using MultiResolutionBucketIndexV2 with step {dataset.index_manager.step} "
+            f"and base size {dataset.index_manager.base_size}"
+        )
+        logger.info(f"\n  {dataset.index_manager.resolutions}")
+
+    # ===========================================================================
+    # Loading parameter
+    # ===========================================================================
+
+    logger.info(f"Loading parameter")
+    start_epoch = 0
+    start_epoch_step = 0
+    train_steps = 0
+    # Resume checkpoint if needed
+    if args.resume:
+        model, ema, start_epoch, start_epoch_step, train_steps = model_resume(
+            args, model, ema, logger, len(loader)
+        )
+
+    if args.training_parts == "lora":
+        loraconfig = LoraConfig(
+            r=args.rank, lora_alpha=args.rank, target_modules=args.target_modules
+        )
+        if args.use_fp16:
+            model.module.enable_input_requires_grad()
+            model.module = get_peft_model(model.module, loraconfig)
+        else:
+            model.enable_input_requires_grad()
+            model = get_peft_model(model, loraconfig)
+
+
+    logger.info(f"    Training parts: {args.training_parts}")
+
+    if args.deepspeed:
+        model, opt, scheduler = deepspeed_initialize(
+            args, logger, model, opt, deepspeed_config
+        )
+
+    # ===========================================================================
+    # Training
+    # ===========================================================================
+
+    model.train()
+    if args.use_ema:
+        ema.eval()
+
+    print(f"    Worker {rank} ready.")
+    dist.barrier()
+
+    iters_per_epoch = len(loader)
+    logger.info(
+        " ****************************** Running training ******************************"
+    )
+    logger.info(f"      Number GPUs:               {world_size}")
+    logger.info(f"      Number training samples:   {len(dataset):,}")
+    logger.info(
+        f"      Number parameters:         {sum(p.numel() for p in model.parameters()):,}"
+    )
+    logger.info(
+        f"      Number trainable params:   {sum(p.numel() for p in get_trainable_params(model)):,}"
+    )
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Iters per epoch:           {iters_per_epoch:,}")
+    logger.info(f"      Batch size per device:     {batch_size}")
+    logger.info(
+        f"      Batch size all device:     {batch_size * world_size * grad_accu_steps:,} (world_size * batch_size * grad_accu_steps)"
+    )
+    logger.info(f"      Gradient Accu steps:       {args.grad_accu_steps}")
+    logger.info(
+        f"      Total optimization steps:  {args.epochs * iters_per_epoch // grad_accu_steps:,}"
+    )
+
+    logger.info(f"      Training epochs:           {start_epoch}/{args.epochs}")
+    logger.info(
+        f"      Training epoch steps:      {start_epoch_step:,}/{iters_per_epoch:,}"
+    )
+    logger.info(
+        f"      Training total steps:      {train_steps:,}/{min(args.max_training_steps, args.epochs * iters_per_epoch):,}"
+    )
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Noise schedule:            {args.noise_schedule}")
+    logger.info(
+        f"      Beta limits:               ({args.beta_start}, {args.beta_end})"
+    )
+    logger.info(f"      Learn sigma:               {args.learn_sigma}")
+    logger.info(f"      Prediction type:           {args.predict_type}")
+    logger.info(f"      Noise offset:              {args.noise_offset}")
+
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Using EMA model:           {args.use_ema} ({args.ema_dtype})")
+    if args.use_ema:
+        logger.info(
+            f"      Using EMA decay:           {ema.max_value if args.use_ema else None}"
+        )
+        logger.info(
+            f"      Using EMA warmup power:    {ema.power if args.use_ema else None}"
+        )
+    logger.info(f"      Using main model fp16:     {args.use_fp16}")
+    logger.info(f"      Using extra modules fp16:  {args.extra_fp16}")
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Experiment directory:      {experiment_dir}")
+    logger.info(
+        "    *******************************************************************************"
+    )
+
+    if args.gc_interval > 0:
+        gc.disable()
+        gc.collect()
+
+    # Variables for monitoring/logging purposes:
+    log_steps = 0
+    running_loss = 0
+    start_time = time.time()
+
+    # Training loop
+    epoch = start_epoch
+    while epoch < args.epochs:
+        # Random shuffle dataset
+        shuffle_seed = args.global_seed + epoch
+        logger.info(f"    Start random shuffle with seed={shuffle_seed}")
+        # Makesure all processors use the same seed to shuffle dataset.
+        dataset.shuffle(seed=shuffle_seed, fast=True)
+        logger.info(f"    End of random shuffle")
+
+        # Move sampler to start_index
+        if not args.multireso:
+            start_index = start_epoch_step * world_size * batch_size
+            if start_index != sampler.start_index:
+                sampler.start_index = start_index
+                # Reset start_epoch_step to zero, to ensure next epoch will start from the beginning.
+                start_epoch_step = 0
+                logger.info(f"      Iters left this epoch: {len(loader):,}")
+
+        logger.info(f"    Beginning epoch {epoch}...")
+        for batch in loader:
+            latents, model_kwargs = prepare_model_inputs(
+                args, batch, device, vae, text_encoder, text_encoder_t5, freqs_cis_img
+            )
+
+            loss_dict = diffusion.training_losses(
+                model=model, x_start=latents, model_kwargs=model_kwargs
+            )
+            loss = loss_dict["loss"].mean()
+            if args.deepspeed:
+                model.backward(loss)
+            else:
+                loss.backward()
+
+            last_batch_iteration = (train_steps + 1) // (
+                global_batch_size // (batch_size * world_size)
+            )
+            if args.deepspeed:
+                model.step(lr_kwargs={"last_batch_iteration": last_batch_iteration})
+            else:
+                opt.step()
+                scheduler.step(last_batch_iteration=last_batch_iteration)
+
+            if args.use_ema:
+                if args.use_fp16:
+                    target_module = getattr(model.module, 'module', model.module)
+                    ema.update(target_module, step=train_steps)
+                else:
+                    ema.update(model.module, step=train_steps)
+
+            # ===========================================================================
+            # Log loss values:
+            # ===========================================================================
+            running_loss += loss.item()
+            log_steps += 1
+            train_steps += 1
+            if train_steps % args.log_every == 0:
+                # Measure training speed:
+                torch.cuda.synchronize()
+                end_time = time.time()
+                steps_per_sec = log_steps / (end_time - start_time)
+                # Reduce loss history over all processes:
+                avg_loss = torch.tensor(running_loss / log_steps, device=device)
+                dist.all_reduce(avg_loss, op=dist.ReduceOp.SUM)
+                avg_loss = avg_loss.item() / world_size
+                # get lr from deepspeed fused optimizer
+                logger.info(
+                    f"(step={train_steps:07d}) "
+                    + (
+                        f"(update_step={train_steps // args.grad_accu_steps:07d}) "
+                        if args.grad_accu_steps > 1
+                        else ""
+                    )
+                    + f"Train Loss: {avg_loss:.4f}, "
+                    f"Lr: {opt.param_groups[0]['lr']:.6g}, "
+                    f"Steps/Sec: {steps_per_sec:.2f}, "
+                    f"Samples/Sec: {steps_per_sec * batch_size * world_size:.2f}"
+                )
+                # Reset monitoring variables:
+                running_loss = 0
+                log_steps = 0
+                start_time = time.time()
+
+            # collect gc:
+            if args.gc_interval > 0 and (train_steps % args.gc_interval == 0):
+                gc.collect()
+
+            if (
+                train_steps % args.ckpt_every == 0
+                or train_steps % args.ckpt_latest_every == 0
+            ) and train_steps > 0:
+                save_checkpoint(
+                    args,
+                    rank,
+                    logger,
+                    model,
+                    ema,
+                    epoch,
+                    train_steps,
+                    checkpoint_dir,
+                    by="step",
+                )
+
+            if train_steps >= args.max_training_steps:
+                logger.info(f"Breaking step loop at train_steps={train_steps}.")
+                break
+
+        if train_steps >= args.max_training_steps:
+            logger.info(f"Breaking epoch loop at epoch={epoch}.")
+            break
+
+        # Finish an epoch
+        if args.ckpt_every_n_epoch > 0 and epoch % args.ckpt_every_n_epoch == 0:
+            save_checkpoint(
+                args,
+                rank,
+                logger,
+                model,
+                ema,
+                epoch,
+                train_steps,
+                checkpoint_dir,
+                by="epoch",
+            )
+
+        epoch += 1
+
+    save_checkpoint(
+        args, rank, logger, model, ema, epoch, train_steps, checkpoint_dir, by="final"
+    )
+
+    dist.destroy_process_group()
+
+
+if __name__ == "__main__":
+    # Start
+    main(get_args())

hydit/train_deepspeed_controlnet.py

+import gc
+import json
+import os
+import random
+import sys
+import time
+from functools import partial
+from glob import glob
+from pathlib import Path
+import numpy as np
+
+import deepspeed
+import torch
+import torch.nn as nn
+import torch.nn.functional as F
+import torch.distributed as dist
+from torch.utils.data import DataLoader
+from torch.distributed.optim import ZeroRedundancyOptimizer
+from torchvision.transforms import functional as TF
+from diffusers.models import AutoencoderKL
+from transformers import BertModel, BertTokenizer, logging as tf_logging
+
+from hydit.config import get_args
+from hydit.constants import VAE_EMA_PATH, TEXT_ENCODER, TOKENIZER, T5_ENCODER
+from hydit.lr_scheduler import WarmupLR
+from hydit.data_loader.arrow_load_stream import TextImageArrowStream
+from hydit.diffusion import create_diffusion
+from hydit.ds_config import deepspeed_config_from_args
+from hydit.modules.ema import EMA
+from hydit.modules.fp16_layers import Float16Module
+from hydit.modules.models import HUNYUAN_DIT_MODELS
+from hydit.modules.controlnet import HunYuanControlNet
+from hydit.modules.posemb_layers import init_image_posemb
+from hydit.utils.tools import (
+    create_logger,
+    set_seeds,
+    create_exp_folder,
+    model_resume,
+    get_trainable_params,
+)
+from IndexKits.index_kits import ResolutionGroup
+from IndexKits.index_kits.sampler import (
+    DistributedSamplerWithStartIndex,
+    BlockDistributedSampler,
+)
+from peft import LoraConfig, get_peft_model
+
+from hydit.annotator.dwpose import DWposeDetector
+
+torch.optim.lr_scheduler.LRScheduler = torch.optim.lr_scheduler._LRScheduler
+from transformers import pipeline
+import cv2
+from PIL import Image
+
+depth_estimator = pipeline(
+    "depth-estimation", device="cuda:{}".format(int(os.getenv("LOCAL_RANK", "0")))
+)
+pose_detector = DWposeDetector()
+
+
+def deepspeed_initialize(args, logger, model, opt, deepspeed_config):
+    logger.info(f"Initialize deepspeed...")
+    logger.info(f"    Using deepspeed optimizer")
+
+    def get_learning_rate_scheduler(warmup_min_lr, lr, warmup_num_steps, opt):
+        return WarmupLR(opt, warmup_min_lr, lr, warmup_num_steps)
+
+    logger.info(
+        f"    Building scheduler with warmup_min_lr={args.warmup_min_lr}, warmup_num_steps={args.warmup_num_steps}"
+    )
+    model, opt, _, scheduler = deepspeed.initialize(
+        model=model,
+        model_parameters=get_trainable_params(model),
+        config_params=deepspeed_config,
+        args=args,
+        lr_scheduler=(
+            partial(
+                get_learning_rate_scheduler,
+                args.warmup_min_lr,
+                args.lr,
+                args.warmup_num_steps,
+            )
+            if args.warmup_num_steps > 0
+            else None
+        ),
+    )
+    return model, opt, scheduler
+
+
+def save_checkpoint(args, rank, logger, model, ema, epoch, train_steps, checkpoint_dir):
+    def save_lora_weight(checkpoint_dir, client_state, tag=f"{train_steps:07d}.pt"):
+        cur_ckpt_save_dir = f"{checkpoint_dir}/{tag}"
+        if rank == 0:
+            if args.use_fp16:
+                model.module.module.save_pretrained(cur_ckpt_save_dir)
+            else:
+                model.module.save_pretrained(cur_ckpt_save_dir)
+
+    checkpoint_path = "[Not rank 0. Disabled output.]"
+
+    client_state = {"steps": train_steps, "epoch": epoch, "args": args}
+    if ema is not None:
+        client_state["ema"] = ema.state_dict()
+
+    dst_paths = []
+    if train_steps % args.ckpt_every == 0:
+        checkpoint_path = f"{checkpoint_dir}/{train_steps:07d}.pt"
+        try:
+            if args.training_parts == "lora":
+                save_lora_weight(
+                    checkpoint_dir, client_state, tag=f"{train_steps:07d}.pt"
+                )
+            else:
+                model.save_checkpoint(
+                    checkpoint_dir,
+                    client_state=client_state,
+                    tag=f"{train_steps:07d}.pt",
+                )
+            dst_paths.append(checkpoint_path)
+            logger.info(f"Saved checkpoint to {checkpoint_path}")
+        except:
+            logger.error(f"Saved failed to {checkpoint_path}")
+
+    if (
+        train_steps % args.ckpt_latest_every == 0
+        or train_steps == args.max_training_steps
+    ):
+        save_name = "latest.pt"
+        checkpoint_path = f"{checkpoint_dir}/{save_name}"
+        try:
+            if args.training_parts == "lora":
+                save_lora_weight(checkpoint_dir, client_state, tag=f"{save_name}")
+            else:
+                model.save_checkpoint(
+                    checkpoint_dir, client_state=client_state, tag=f"{save_name}"
+                )
+            dst_paths.append(checkpoint_path)
+            logger.info(f"Saved checkpoint to {checkpoint_path}")
+        except:
+            logger.error(f"Saved failed to {checkpoint_path}")
+
+    dist.barrier()
+    if rank == 0 and len(dst_paths) > 0:
+        # Delete optimizer states to avoid occupying too much disk space.
+        for dst_path in dst_paths:
+            for opt_state_path in glob(f"{dst_path}/*_00_optim_states.pt"):
+                os.remove(opt_state_path)
+
+    return checkpoint_path
+
+
+def get_canny(np_img, low_threshold=100, high_threshold=200):
+    # tensor = deNormalize()
+    # image = tensor_to_img(tensor)
+    image = cv2.Canny(np_img, low_threshold, high_threshold)
+    image = image[:, :, None]
+    image = np.concatenate([image, image, image], axis=2)
+    # canny_tensor = img_to_norm_tensor(canny_img)
+    return image
+
+
+def get_depth(np_img):
+    pil_img = Image.fromarray(np_img)
+    depth = depth_estimator(pil_img)["depth"]
+    depth = np.array(depth)
+    depth = depth[:, :, None]
+    depth = np.concatenate([depth, depth, depth], axis=2)
+    return depth
+
+
+def get_pose(np_img):
+    return pose_detector(np_img)[0]
+
+
+@torch.no_grad()
+def prepare_model_inputs(
+    args, batch, device, vae, text_encoder, text_encoder_t5, freqs_cis_img
+):
+    (
+        image,
+        text_embedding,
+        text_embedding_mask,
+        text_embedding_t5,
+        text_embedding_mask_t5,
+        kwargs,
+    ) = batch
+
+    # clip & mT5 text embedding
+    text_embedding = text_embedding.to(device)
+    text_embedding_mask = text_embedding_mask.to(device)
+    encoder_hidden_states = text_encoder(
+        text_embedding.to(device),
+        attention_mask=text_embedding_mask.to(device),
+    )[0]
+    text_embedding_t5 = text_embedding_t5.to(device).squeeze(1)
+    text_embedding_mask_t5 = text_embedding_mask_t5.to(device).squeeze(1)
+    with torch.no_grad():
+        output_t5 = text_encoder_t5(
+            input_ids=text_embedding_t5,
+            attention_mask=(
+                text_embedding_mask_t5 if T5_ENCODER["attention_mask"] else None
+            ),
+            output_hidden_states=True,
+        )
+        encoder_hidden_states_t5 = output_t5["hidden_states"][
+            T5_ENCODER["layer_index"]
+        ].detach()
+
+    # additional condition
+    if args.size_cond:
+        image_meta_size = kwargs["image_meta_size"].to(device)
+    else:
+        image_meta_size = None
+    if args.use_style_cond:
+        style = kwargs["style"].to(device)
+    else:
+        style = None
+
+    np_img = (
+        image.squeeze(0)
+        .add(1)
+        .mul(255 / 2)
+        .permute(1, 2, 0)
+        .cpu()
+        .numpy()
+        .astype("uint8")
+    )
+    if args.control_type == "canny":
+        condition = get_canny(np_img)
+    elif args.control_type == "depth":
+        condition = get_depth(np_img)
+    elif args.control_type == "pose":
+        condition = get_pose(np_img)
+    else:
+        raise NotImplementedError
+    condtion = Image.fromarray(condition)
+    condition = TF.to_tensor(condition)
+    condition = TF.normalize(condition, [0.5], [0.5])
+    condition = condition.unsqueeze(0).to(device)
+
+    if args.extra_fp16:
+        image = image.half()
+
+    # Map input images to latent space + normalize latents:
+    image = image.to(device)
+    vae_scaling_factor = vae.config.scaling_factor
+    latents = vae.encode(image).latent_dist.sample().mul_(vae_scaling_factor)
+    condition = vae.encode(condition).latent_dist.sample().mul_(vae_scaling_factor)
+
+    # positional embedding
+    _, _, height, width = image.shape
+    reso = f"{height}x{width}"
+    cos_cis_img, sin_cis_img = freqs_cis_img[reso]
+
+    # Model conditions
+    model_kwargs = dict(
+        encoder_hidden_states=encoder_hidden_states,
+        text_embedding_mask=text_embedding_mask,
+        encoder_hidden_states_t5=encoder_hidden_states_t5,
+        text_embedding_mask_t5=text_embedding_mask_t5,
+        image_meta_size=image_meta_size,
+        style=style,
+        cos_cis_img=cos_cis_img,
+        sin_cis_img=sin_cis_img,
+        condition=condition,
+    )
+
+    return latents, model_kwargs
+
+
+def main(args):
+
+    args.use_ema = False  # EMA usage is discouraged during ControlNet training.
+    assert torch.cuda.is_available(), "Training currently requires at least one GPU."
+
+    dist.init_process_group("nccl")
+    world_size = dist.get_world_size()
+    batch_size = args.batch_size
+    grad_accu_steps = args.grad_accu_steps
+    global_batch_size = world_size * batch_size * grad_accu_steps
+
+    rank = dist.get_rank()
+    device = rank % torch.cuda.device_count()
+    seed = args.global_seed * world_size + rank
+    random.seed(seed)
+    np.random.seed(seed)
+    torch.manual_seed(seed)
+    torch.cuda.manual_seed_all(seed)
+    torch.cuda.set_device(device)
+    print(f"Starting rank={rank}, seed={seed}, world_size={world_size}.")
+    deepspeed_config = deepspeed_config_from_args(args, global_batch_size)
+
+    # Setup an experiment folder
+    experiment_dir, checkpoint_dir, logger = create_exp_folder(args, rank)
+
+    # Log all the arguments
+    logger.info(sys.argv)
+    logger.info(str(args))
+    # Save to a json file
+    args_dict = vars(args)
+    args_dict["world_size"] = world_size
+    with open(f"{experiment_dir}/args.json", "w") as f:
+        json.dump(args_dict, f, indent=4)
+
+    # Disable the message "Some weights of the model checkpoint at ... were not used when initializing BertModel."
+    # If needed, just comment the following line.
+    tf_logging.set_verbosity_error()
+
+    # ===========================================================================
+    # Building HYDIT
+    # ===========================================================================
+
+    logger.info("Building HYDIT Model.")
+
+    # ---------------------------------------------------------------------------
+    #   Training sample base size, such as 256/512/1024. Notice that this size is
+    #   just a base size, not necessary the actual size of training samples. Actual
+    #   size of the training samples are correlated with `resolutions` when enabling
+    #   multi-resolution training.
+    # ---------------------------------------------------------------------------
+    image_size = args.image_size
+    if len(image_size) == 1:
+        image_size = [image_size[0], image_size[0]]
+    if len(image_size) != 2:
+        raise ValueError(f"Invalid image size: {args.image_size}")
+    assert image_size[0] % 8 == 0 and image_size[1] % 8 == 0, (
+        "Image size must be divisible by 8 (for the VAE encoder). " f"got {image_size}"
+    )
+    latent_size = [image_size[0] // 8, image_size[1] // 8]
+
+    # initialize model by deepspeed
+    assert args.deepspeed, f"Must enable deepspeed in this script: train_deepspeed.py"
+    with deepspeed.zero.Init(
+        data_parallel_group=torch.distributed.group.WORLD,
+        remote_device=None if args.remote_device == "none" else args.remote_device,
+        config_dict_or_path=deepspeed_config,
+        mpu=None,
+        enabled=args.zero_stage == 3,
+    ):
+        model = HUNYUAN_DIT_MODELS[args.model](
+            args,
+            input_size=latent_size,
+            log_fn=logger.info,
+        )
+        controlnet = HunYuanControlNet(
+            args,
+            input_size=latent_size,
+            depth=40,
+            hidden_size=1408,
+            patch_size=2,
+            num_heads=16,
+            mlp_ratio=4.3637,
+            log_fn=logger.info,
+        )
+    # Multi-resolution / Single-resolution training.
+    if args.multireso:
+        resolutions = ResolutionGroup(
+            image_size[0],
+            align=16,
+            step=args.reso_step,
+            target_ratios=args.target_ratios,
+        ).data
+    else:
+        resolutions = ResolutionGroup(
+            image_size[0], align=16, target_ratios=["1:1"]
+        ).data
+
+    freqs_cis_img = init_image_posemb(
+        args.rope_img,
+        resolutions=resolutions,
+        patch_size=model.patch_size,
+        hidden_size=model.hidden_size,
+        num_heads=model.num_heads,
+        log_fn=logger.info,
+        rope_real=args.rope_real,
+    )
+
+    # Create EMA model and convert to fp16 if needed.
+    ema = None
+    if args.use_ema:
+        ema = EMA(args, model, device, logger)
+
+    # Setup gradient checkpointing
+    if args.gradient_checkpointing:
+        model.enable_gradient_checkpointing()
+        controlnet.enable_gradient_checkpointing()
+
+    # Setup FP16 main model:
+    if args.use_fp16:
+        model = Float16Module(model, args)
+        controlnet = Float16Module(controlnet, args)
+    logger.info(
+        f"    Using main model with data type {'fp16' if args.use_fp16 else 'fp32'}"
+    )
+
+    diffusion = create_diffusion(
+        noise_schedule=args.noise_schedule,
+        predict_type=args.predict_type,
+        learn_sigma=args.learn_sigma,
+        mse_loss_weight_type=args.mse_loss_weight_type,
+        beta_start=args.beta_start,
+        beta_end=args.beta_end,
+        noise_offset=args.noise_offset,
+    )
+
+    # Setup VAE
+    logger.info(f"    Loading vae from {VAE_EMA_PATH}")
+    vae = AutoencoderKL.from_pretrained(VAE_EMA_PATH)
+    # Setup BERT text encoder
+    logger.info(f"    Loading Bert text encoder from {TEXT_ENCODER}")
+    text_encoder = BertModel.from_pretrained(TEXT_ENCODER, False, revision=None)
+    # Setup BERT tokenizer:
+    logger.info(f"    Loading Bert tokenizer from {TOKENIZER}")
+    tokenizer = BertTokenizer.from_pretrained(TOKENIZER)
+    # Setup T5 text encoder
+    from hydit.modules.text_encoder import MT5Embedder
+
+    mt5_path = T5_ENCODER["MT5"]
+    embedder_t5 = MT5Embedder(
+        mt5_path, torch_dtype=T5_ENCODER["torch_dtype"], max_length=args.text_len_t5
+    )
+    tokenizer_t5 = embedder_t5.tokenizer
+    text_encoder_t5 = embedder_t5.model
+
+    if args.extra_fp16:
+        logger.info(f"    Using fp16 for extra modules: vae, text_encoder")
+        vae = vae.half().to(device)
+        text_encoder = text_encoder.half().to(device)
+        text_encoder_t5 = text_encoder_t5.half().to(device)
+    else:
+        vae = vae.to(device)
+        text_encoder = text_encoder.to(device)
+        text_encoder_t5 = text_encoder_t5.to(device)
+
+    logger.info(
+        f"    Optimizer parameters: lr={args.lr}, weight_decay={args.weight_decay}"
+    )
+    logger.info("    Using deepspeed optimizer")
+    opt = None
+
+    # ===========================================================================
+    # Building Dataset
+    # ===========================================================================
+
+    logger.info(f"Building Streaming Dataset.")
+    logger.info(f"    Loading index file {args.index_file} (v2)")
+
+    dataset = TextImageArrowStream(
+        args=args,
+        resolution=image_size[0],
+        random_flip=args.random_flip,
+        log_fn=logger.info,
+        index_file=args.index_file,
+        multireso=args.multireso,
+        batch_size=batch_size,
+        world_size=world_size,
+        random_shrink_size_cond=args.random_shrink_size_cond,
+        merge_src_cond=args.merge_src_cond,
+        uncond_p=args.uncond_p,
+        text_ctx_len=args.text_len,
+        tokenizer=tokenizer,
+        uncond_p_t5=args.uncond_p_t5,
+        text_ctx_len_t5=args.text_len_t5,
+        tokenizer_t5=tokenizer_t5,
+    )
+    if args.multireso:
+        sampler = BlockDistributedSampler(
+            dataset,
+            num_replicas=world_size,
+            rank=rank,
+            seed=args.global_seed,
+            shuffle=False,
+            drop_last=True,
+            batch_size=batch_size,
+        )
+    else:
+        sampler = DistributedSamplerWithStartIndex(
+            dataset,
+            num_replicas=world_size,
+            rank=rank,
+            seed=args.global_seed,
+            shuffle=False,
+            drop_last=True,
+        )
+    loader = DataLoader(
+        dataset,
+        batch_size=batch_size,
+        shuffle=False,
+        sampler=sampler,
+        num_workers=args.num_workers,
+        pin_memory=True,
+        drop_last=True,
+    )
+    logger.info(f"    Dataset contains {len(dataset):,} images.")
+    logger.info(f"    Index file: {args.index_file}.")
+    if args.multireso:
+        logger.info(
+            f"    Using MultiResolutionBucketIndexV2 with step {dataset.index_manager.step} "
+            f"and base size {dataset.index_manager.base_size}"
+        )
+        logger.info(f"\n  {dataset.index_manager.resolutions}")
+
+    # ===========================================================================
+    # Loading parameter
+    # ===========================================================================
+
+    logger.info(f"Loading parameter")
+    start_epoch = 0
+    start_epoch_step = 0
+    train_steps = 0
+    # Resume checkpoint if needed
+    if args.resume:
+        model, ema, start_epoch, start_epoch_step, train_steps = model_resume(
+            args, model, ema, logger, len(loader)
+        )
+
+    if args.training_parts == "lora":
+        loraconfig = LoraConfig(
+            r=args.rank, lora_alpha=args.rank, target_modules=args.target_modules
+        )
+        if args.use_fp16:
+            model.module = get_peft_model(model.module, loraconfig)
+        else:
+            model = get_peft_model(model, loraconfig)
+
+    logger.info(f"    Training parts: {args.training_parts}")
+
+    if args.use_fp16:
+        controlnet.module.from_dit(model.module)
+        controlnet.module.set_trainable()
+    else:
+        controlnet.from_dit(model)
+        controlnet.set_trainable()
+    logger.info(f"    ControlNet loaded from DIT")
+
+    controlnet, opt, scheduler = deepspeed_initialize(
+        args, logger, controlnet, opt, deepspeed_config
+    )
+
+    # ===========================================================================
+    # Training
+    # ===========================================================================
+
+    model.eval()
+    model.requires_grad_(False)
+    model = model.to(device)
+
+    if args.use_ema:
+        ema.eval()
+
+    print(f"    Worker {rank} ready.")
+    dist.barrier()
+
+    iters_per_epoch = len(loader)
+    logger.info(
+        " ****************************** Running training ******************************"
+    )
+    logger.info(f"      Number GPUs:               {world_size}")
+    logger.info(f"      Number training samples:   {len(dataset):,}")
+    logger.info(
+        f"      Number parameters:         {sum(p.numel() for p in controlnet.parameters()):,}"
+    )
+    logger.info(
+        f"      Number trainable params:   {sum(p.numel() for p in get_trainable_params(controlnet)):,}"
+    )
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Iters per epoch:           {iters_per_epoch:,}")
+    logger.info(f"      Batch size per device:     {batch_size}")
+    logger.info(
+        f"      Batch size all device:     {batch_size * world_size * grad_accu_steps:,} (world_size * batch_size * grad_accu_steps)"
+    )
+    logger.info(f"      Gradient Accu steps:       {args.grad_accu_steps}")
+    logger.info(
+        f"      Total optimization steps:  {args.epochs * iters_per_epoch // grad_accu_steps:,}"
+    )
+
+    logger.info(f"      Training epochs:           {start_epoch}/{args.epochs}")
+    logger.info(
+        f"      Training epoch steps:      {start_epoch_step:,}/{iters_per_epoch:,}"
+    )
+    logger.info(
+        f"      Training total steps:      {train_steps:,}/{min(args.max_training_steps, args.epochs * iters_per_epoch):,}"
+    )
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Noise schedule:            {args.noise_schedule}")
+    logger.info(
+        f"      Beta limits:               ({args.beta_start}, {args.beta_end})"
+    )
+    logger.info(f"      Learn sigma:               {args.learn_sigma}")
+    logger.info(f"      Prediction type:           {args.predict_type}")
+    logger.info(f"      Noise offset:              {args.noise_offset}")
+
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Using EMA model:           {args.use_ema} ({args.ema_dtype})")
+    if args.use_ema:
+        logger.info(
+            f"      Using EMA decay:           {ema.max_value if args.use_ema else None}"
+        )
+        logger.info(
+            f"      Using EMA warmup power:    {ema.power if args.use_ema else None}"
+        )
+    logger.info(f"      Using main model fp16:     {args.use_fp16}")
+    logger.info(f"      Using extra modules fp16:  {args.extra_fp16}")
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Experiment directory:      {experiment_dir}")
+    logger.info(
+        "    *******************************************************************************"
+    )
+
+    if args.gc_interval > 0:
+        gc.disable()
+        gc.collect()
+
+    # Variables for monitoring/logging purposes:
+    log_steps = 0
+    running_loss = 0
+    start_time = time.time()
+
+    # Training loop
+    for epoch in range(start_epoch, args.epochs):
+        logger.info(f"    Start random shuffle with seed={seed}")
+        # Makesure all processors use the same seed to shuffle dataset.
+        dataset.shuffle(seed=args.global_seed + epoch, fast=True)
+        logger.info(f"    End of random shuffle")
+
+        # Move sampler to start_index
+        if not args.multireso:
+            start_index = start_epoch_step * world_size * batch_size
+            if start_index != sampler.start_index:
+                sampler.start_index = start_index
+                # Reset start_epoch_step to zero, to ensure next epoch will start from the beginning.
+                start_epoch_step = 0
+                logger.info(f"      Iters left this epoch: {len(loader):,}")
+
+        logger.info(f"    Beginning epoch {epoch}...")
+        step = 0
+        for batch in loader:
+            step += 1
+
+            latents, model_kwargs = prepare_model_inputs(
+                args, batch, device, vae, text_encoder, text_encoder_t5, freqs_cis_img
+            )
+
+            loss_dict = diffusion.training_losses(
+                model=model,
+                x_start=latents,
+                model_kwargs=model_kwargs,
+                controlnet=controlnet,
+            )
+            loss = loss_dict["loss"].mean()
+            controlnet.backward(loss)
+            last_batch_iteration = (train_steps + 1) // (
+                global_batch_size // (batch_size * world_size)
+            )
+            controlnet.step(lr_kwargs={"last_batch_iteration": last_batch_iteration})
+
+            if args.use_ema:
+                if args.use_fp16:
+                    ema.update(model.module.module, step=step)
+                else:
+                    ema.update(model.module, step=step)
+
+            # ===========================================================================
+            # Log loss values:
+            # ===========================================================================
+            running_loss += loss.item()
+            log_steps += 1
+            train_steps += 1
+            if train_steps % args.log_every == 0:
+                # Measure training speed:
+                torch.cuda.synchronize()
+                end_time = time.time()
+                steps_per_sec = log_steps / (end_time - start_time)
+                # Reduce loss history over all processes:
+                avg_loss = torch.tensor(running_loss / log_steps, device=device)
+                dist.all_reduce(avg_loss, op=dist.ReduceOp.SUM)
+                avg_loss = avg_loss.item() / world_size
+                # get lr from deepspeed fused optimizer
+                logger.info(
+                    f"(step={train_steps:07d}) "
+                    + (
+                        f"(update_step={train_steps // args.grad_accu_steps:07d}) "
+                        if args.grad_accu_steps > 1
+                        else ""
+                    )
+                    + f"Train Loss: {avg_loss:.4f}, "
+                    f"Lr: {opt.param_groups[0]['lr']:.6g}, "
+                    f"Steps/Sec: {steps_per_sec:.2f}, "
+                    f"Samples/Sec: {int(steps_per_sec * batch_size * world_size):d}"
+                )
+                # Reset monitoring variables:
+                running_loss = 0
+                log_steps = 0
+                start_time = time.time()
+
+            # collect gc:
+            if args.gc_interval > 0 and (step % args.gc_interval == 0):
+                gc.collect()
+
+            if (
+                train_steps % args.ckpt_every == 0
+                or train_steps % args.ckpt_latest_every
+                == 0  # or train_steps == args.max_training_steps
+            ) and train_steps > 0:
+                save_checkpoint(
+                    args,
+                    rank,
+                    logger,
+                    controlnet,
+                    ema,
+                    epoch,
+                    train_steps,
+                    checkpoint_dir,
+                )
+
+            if train_steps >= args.max_training_steps:
+                logger.info(f"Breaking step loop at train_steps={train_steps}.")
+                break
+
+        if train_steps >= args.max_training_steps:
+            logger.info(f"Breaking epoch loop at epoch={epoch}.")
+            break
+
+    dist.destroy_process_group()
+
+
+if __name__ == "__main__":
+    # Start
+    main(get_args())

hydit/train_deepspeed_ipadapter.py

+import gc
+import json
+import os
+import random
+import sys
+import time
+from functools import partial
+from glob import glob
+
+import deepspeed
+import numpy as np
+import torch
+import torch.distributed as dist
+from diffusers.models import AutoencoderKL
+from peft import LoraConfig, get_peft_model
+from torch.utils.data import DataLoader
+from transformers import BertModel, BertTokenizer, logging as tf_logging
+
+from IndexKits.index_kits import ResolutionGroup
+from IndexKits.index_kits.sampler import (
+    DistributedSamplerWithStartIndex,
+    BlockDistributedSampler,
+)
+from hydit.config import get_args
+from hydit.constants import VAE_EMA_PATH, TEXT_ENCODER, TOKENIZER, T5_ENCODER
+from hydit.data_loader.arrow_load_stream import TextImageArrowStream
+from hydit.diffusion import create_diffusion
+from hydit.ds_config import deepspeed_config_from_args
+from hydit.lr_scheduler import WarmupLR
+from hydit.modules.ema import EMA
+from hydit.modules.fp16_layers import Float16Module
+from hydit.modules.models import HUNYUAN_DIT_MODELS, HunYuanDiT
+from hydit.modules.text_encoder import MT5Embedder
+from hydit.modules.posemb_layers import init_image_posemb
+from hydit.utils.tools import (
+    create_exp_folder,
+    model_resume,
+    get_trainable_params,
+    get_trainable_params_ipa,
+)
+from hydit.utils.img_clip_emb import ImgClipEmbDetector
+
+
+def deepspeed_initialize(args, logger, model, opt, deepspeed_config):
+    logger.info(f"Initialize deepspeed...")
+    logger.info(f"    Using deepspeed optimizer")
+
+    def get_learning_rate_scheduler(warmup_min_lr, lr, warmup_num_steps, opt):
+        return WarmupLR(opt, warmup_min_lr, lr, warmup_num_steps)
+
+    logger.info(
+        f"    Building scheduler with warmup_min_lr={args.warmup_min_lr}, warmup_num_steps={args.warmup_num_steps}"
+    )
+    model, opt, _, scheduler = deepspeed.initialize(
+        model=model,
+        model_parameters=get_trainable_params_ipa(model, args, freeze_others=True),
+        config_params=deepspeed_config,
+        args=args,
+        lr_scheduler=(
+            partial(
+                get_learning_rate_scheduler,
+                args.warmup_min_lr,
+                args.lr,
+                args.warmup_num_steps,
+            )
+            if args.warmup_num_steps > 0
+            else None
+        ),
+    )
+    return model, opt, scheduler
+
+
+def save_checkpoint(
+    args, rank, logger, model, ema, epoch, train_steps, checkpoint_dir, by="step"
+):
+    def save_lora_weight(checkpoint_dir, client_state, tag=f"{train_steps:07d}.pt"):
+        cur_ckpt_save_dir = f"{checkpoint_dir}/{tag}"
+        if rank == 0:
+            if args.use_fp16:
+                model.module.module.save_pretrained(cur_ckpt_save_dir)
+            else:
+                model.module.save_pretrained(cur_ckpt_save_dir)
+
+    def save_ipadapter_weight(
+        checkpoint_dir, client_state, tag=f"{train_steps:07d}.pt"
+    ):
+        cur_ckpt_save_dir = f"{checkpoint_dir}/{tag}"
+        save_state = {}
+        if rank == 0:
+            if args.use_fp16:
+                for param_tensor in model.module.module.state_dict():
+                    if "ip_adapter" in param_tensor:
+                        save_state.update(
+                            {
+                                param_tensor: model.module.module.state_dict()[
+                                    param_tensor
+                                ]
+                            }
+                        )
+                        torch.save(save_state, cur_ckpt_save_dir)
+
+            else:
+                for param_tensor in model.module.state_dict():
+                    if "ip_adapter" in param_tensor:
+                        save_state.update(
+                            {param_tensor: model.module.state_dict()[param_tensor]}
+                        )
+                        torch.save(save_state, cur_ckpt_save_dir)
+
+    def save_model_weight(client_state, tag):
+        checkpoint_path = f"{checkpoint_dir}/{tag}"
+        try:
+            if args.training_parts == "lora":
+                save_lora_weight(checkpoint_dir, client_state, tag=tag)
+            elif args.training_parts == "ipadapter":
+                save_ipadapter_weight(checkpoint_dir, client_state, tag=tag)
+            else:
+                model.save_checkpoint(
+                    checkpoint_dir, client_state=client_state, tag=tag
+                )
+            logger.info(f"Saved checkpoint to {checkpoint_path}")
+        except Exception as e:
+            logger.error(f"Saved failed to {checkpoint_path}. {type(e)}: {e}")
+            return False, ""
+        return True, checkpoint_path
+
+    client_state = {"steps": train_steps, "epoch": epoch, "args": args}
+    if ema is not None:
+        client_state["ema"] = ema.state_dict()
+
+    # Save model weights by epoch or step
+    dst_paths = []
+    if by == "epoch":
+        tag = f"e{epoch:04d}.pt"
+        dst_paths.append(save_model_weight(client_state, tag))
+    elif by == "step":
+        if train_steps % args.ckpt_every == 0:
+            tag = f"{train_steps:07d}.pt"
+            dst_paths.append(save_model_weight(client_state, tag))
+        if (
+            train_steps % args.ckpt_latest_every == 0
+            or train_steps == args.max_training_steps
+        ):
+            tag = "latest.pt"
+            dst_paths.append(save_model_weight(client_state, tag))
+    elif by == "final":
+        tag = "final.pt"
+        dst_paths.append(save_model_weight(client_state, tag))
+    else:
+        raise ValueError(f"Unknown save checkpoint method: {by}")
+
+    saved = any([state for state, _ in dst_paths])
+    if not saved:
+        return False
+
+    # Maybe clear optimizer states
+    if not args.save_optimizer_state:
+        dist.barrier()
+        if rank == 0 and len(dst_paths) > 0:
+            # Delete optimizer states to avoid occupying too much disk space.
+            for dst_path in dst_paths:
+                for opt_state_path in glob(f"{dst_path}/zero_*_optim_states.pt"):
+                    os.remove(opt_state_path)
+
+    return True
+
+
+@torch.no_grad()
+def prepare_model_inputs(
+    args, batch, device, vae, text_encoder, img_encoder, text_encoder_t5, freqs_cis_img
+):
+    (
+        image,
+        text_embedding,
+        text_embedding_mask,
+        text_embedding_t5,
+        text_embedding_mask_t5,
+        img_for_clip_tensor,
+        kwargs,
+    ) = batch
+
+    # clip & mT5 text embedding
+    text_embedding = text_embedding.to(device)
+    text_embedding_mask = text_embedding_mask.to(device)
+    encoder_hidden_states = text_encoder(
+        text_embedding.to(device),
+        attention_mask=text_embedding_mask.to(device),
+    )[0]
+    text_embedding_t5 = text_embedding_t5.to(device).squeeze(1)
+    text_embedding_mask_t5 = text_embedding_mask_t5.to(device).squeeze(1)
+    with torch.no_grad():
+        output_t5 = text_encoder_t5(
+            input_ids=text_embedding_t5,
+            attention_mask=(
+                text_embedding_mask_t5 if T5_ENCODER["attention_mask"] else None
+            ),
+            output_hidden_states=True,
+        )
+        encoder_hidden_states_t5 = output_t5["hidden_states"][
+            T5_ENCODER["layer_index"]
+        ].detach()
+
+    # additional condition
+    if args.size_cond:
+        image_meta_size = kwargs["image_meta_size"].to(device)
+    else:
+        image_meta_size = None
+    if args.use_style_cond:
+        style = kwargs["style"].to(device)
+    else:
+        style = None
+
+    if args.extra_fp16:
+        image = image.half()
+        image_meta_size = (
+            image_meta_size.half() if image_meta_size is not None else None
+        )
+        style = style.half() if style is not None else None
+
+    # Map input images to latent space + normalize latents:
+    image = image.to(device)
+    vae_scaling_factor = vae.config.scaling_factor
+    latents = vae.encode(image).latent_dist.sample().mul_(vae_scaling_factor)
+
+    # positional embedding
+    _, _, height, width = image.shape
+    reso = f"{height}x{width}"
+    cos_cis_img, sin_cis_img = freqs_cis_img[reso]
+
+    img_clip_embedding = img_encoder(img_for_clip_tensor.to(latents.device))
+
+    # Model conditions
+    model_kwargs = dict(
+        encoder_hidden_states=encoder_hidden_states,
+        text_embedding_mask=text_embedding_mask,
+        img_clip_embedding=img_clip_embedding,
+        encoder_hidden_states_t5=encoder_hidden_states_t5,
+        text_embedding_mask_t5=text_embedding_mask_t5,
+        image_meta_size=image_meta_size,
+        style=style,
+        cos_cis_img=cos_cis_img,
+        sin_cis_img=sin_cis_img,
+        t_scale=1,
+        i_scale=1,
+    )
+
+    return latents, model_kwargs
+
+
+def main(args):
+    if args.training_parts == "lora":
+        args.use_ema = False
+
+    assert torch.cuda.is_available(), "Training currently requires at least one GPU."
+
+    dist.init_process_group("nccl")
+    world_size = dist.get_world_size()
+    batch_size = args.batch_size
+    grad_accu_steps = args.grad_accu_steps
+    global_batch_size = world_size * batch_size * grad_accu_steps
+
+    rank = dist.get_rank()
+    device = rank % torch.cuda.device_count()
+    seed = args.global_seed * world_size + rank
+    random.seed(seed)
+    np.random.seed(seed)
+    torch.manual_seed(seed)
+    torch.cuda.manual_seed_all(seed)
+    torch.cuda.set_device(device)
+    print(f"Starting rank={rank}, seed={seed}, world_size={world_size}.")
+    deepspeed_config = deepspeed_config_from_args(args, global_batch_size)
+
+    # Setup an experiment folder
+    experiment_dir, checkpoint_dir, logger = create_exp_folder(args, rank)
+
+    # Log all the arguments
+    logger.info(sys.argv)
+    logger.info(str(args))
+    # Save to a json file
+    args_dict = vars(args)
+    args_dict["world_size"] = world_size
+    with open(f"{experiment_dir}/args.json", "w") as f:
+        json.dump(args_dict, f, indent=4)
+
+    # Disable the message "Some weights of the model checkpoint at ... were not used when initializing BertModel."
+    # If needed, just comment the following line.
+    tf_logging.set_verbosity_error()
+
+    # ===========================================================================
+    # Building HYDIT
+    # ===========================================================================
+
+    logger.info("Building HYDIT Model.")
+
+    # ---------------------------------------------------------------------------
+    #   Training sample base size, such as 256/512/1024. Notice that this size is
+    #   just a base size, not necessary the actual size of training samples. Actual
+    #   size of the training samples are correlated with `resolutions` when enabling
+    #   multi-resolution training.
+    # ---------------------------------------------------------------------------
+    image_size = args.image_size
+    if len(image_size) == 1:
+        image_size = [image_size[0], image_size[0]]
+    if len(image_size) != 2:
+        raise ValueError(f"Invalid image size: {args.image_size}")
+    assert image_size[0] % 8 == 0 and image_size[1] % 8 == 0, (
+        "Image size must be divisible by 8 (for the VAE encoder). " f"got {image_size}"
+    )
+    latent_size = [image_size[0] // 8, image_size[1] // 8]
+
+    # initialize model by deepspeed
+    assert (
+        args.deepspeed
+    ), f"Must enable deepspeed in this script: train_deepspeed_ipadapter.py"
+    with deepspeed.zero.Init(
+        data_parallel_group=torch.distributed.group.WORLD,
+        remote_device=None if args.remote_device == "none" else args.remote_device,
+        config_dict_or_path=deepspeed_config,
+        mpu=None,
+        enabled=args.zero_stage == 3,
+    ):
+        model = HUNYUAN_DIT_MODELS[args.model](
+            args,
+            input_size=latent_size,
+            log_fn=logger.info,
+        )
+    # Multi-resolution / Single-resolution training.
+    if args.multireso:
+        resolutions = ResolutionGroup(
+            image_size[0],
+            align=16,
+            step=args.reso_step,
+            target_ratios=args.target_ratios,
+        ).data
+    else:
+        resolutions = ResolutionGroup(
+            image_size[0], align=16, target_ratios=["1:1"]
+        ).data
+
+    freqs_cis_img = init_image_posemb(
+        args.rope_img,
+        resolutions=resolutions,
+        patch_size=model.patch_size,
+        hidden_size=model.hidden_size,
+        num_heads=model.num_heads,
+        log_fn=logger.info,
+        rope_real=args.rope_real,
+    )
+
+    # Create EMA model and convert to fp16 if needed.
+    ema = None
+    if args.use_ema:
+        ema = EMA(args, model, device, logger)
+
+    # Setup gradient checkpointing
+    if args.gradient_checkpointing:
+        model.enable_gradient_checkpointing()
+
+    # Setup FP16 main model:
+    if args.use_fp16:
+        model = Float16Module(model, args)
+    logger.info(
+        f"    Using main model with data type {'fp16' if args.use_fp16 else 'fp32'}"
+    )
+
+    diffusion = create_diffusion(
+        noise_schedule=args.noise_schedule,
+        predict_type=args.predict_type,
+        learn_sigma=args.learn_sigma,
+        mse_loss_weight_type=args.mse_loss_weight_type,
+        beta_start=args.beta_start,
+        beta_end=args.beta_end,
+        noise_offset=args.noise_offset,
+    )
+
+    # Setup VAE
+    logger.info(f"    Loading vae from {VAE_EMA_PATH}")
+    vae = AutoencoderKL.from_pretrained(VAE_EMA_PATH)
+    # Setup BERT text encoder
+    logger.info(f"    Loading Bert text encoder from {TEXT_ENCODER}")
+    text_encoder = BertModel.from_pretrained(TEXT_ENCODER, False, revision=None)
+    # Setup BERT tokenizer:
+    logger.info(f"    Loading Bert tokenizer from {TOKENIZER}")
+    tokenizer = BertTokenizer.from_pretrained(TOKENIZER)
+    # Setup T5 text encoder
+    mt5_path = T5_ENCODER["MT5"]
+    embedder_t5 = MT5Embedder(
+        mt5_path, torch_dtype=T5_ENCODER["torch_dtype"], max_length=args.text_len_t5
+    )
+    tokenizer_t5 = embedder_t5.tokenizer
+    text_encoder_t5 = embedder_t5.model
+
+    if args.extra_fp16:
+        logger.info(f"    Using fp16 for extra modules: vae, text_encoder")
+        vae = vae.half().to(device)
+        text_encoder = text_encoder.half().to(device)
+        text_encoder_t5 = text_encoder_t5.half().to(device)
+    else:
+        vae = vae.to(device)
+        text_encoder = text_encoder.to(device)
+        text_encoder_t5 = text_encoder_t5.to(device)
+
+    logger.info(
+        f"    Optimizer parameters: lr={args.lr}, weight_decay={args.weight_decay}"
+    )
+    logger.info("    Using deepspeed optimizer")
+    opt = None
+
+    img_encoder = ImgClipEmbDetector()
+
+    # ===========================================================================
+    # Building Dataset
+    # ===========================================================================
+
+    logger.info(f"Building Streaming Dataset.")
+    logger.info(f"    Loading index file {args.index_file} (v2)")
+
+    dataset = TextImageArrowStream(
+        args=args,
+        resolution=image_size[0],
+        random_flip=args.random_flip,
+        log_fn=logger.info,
+        index_file=args.index_file,
+        multireso=args.multireso,
+        batch_size=batch_size,
+        world_size=world_size,
+        random_shrink_size_cond=args.random_shrink_size_cond,
+        merge_src_cond=args.merge_src_cond,
+        uncond_p=args.uncond_p,
+        text_ctx_len=args.text_len,
+        tokenizer=tokenizer,
+        uncond_p_t5=args.uncond_p_t5,
+        text_ctx_len_t5=args.text_len_t5,
+        tokenizer_t5=tokenizer_t5,
+    )
+    if args.multireso:
+        sampler = BlockDistributedSampler(
+            dataset,
+            num_replicas=world_size,
+            rank=rank,
+            seed=args.global_seed,
+            shuffle=False,
+            drop_last=True,
+            batch_size=batch_size,
+        )
+    else:
+        sampler = DistributedSamplerWithStartIndex(
+            dataset,
+            num_replicas=world_size,
+            rank=rank,
+            seed=args.global_seed,
+            shuffle=False,
+            drop_last=True,
+        )
+    loader = DataLoader(
+        dataset,
+        batch_size=batch_size,
+        shuffle=False,
+        sampler=sampler,
+        num_workers=args.num_workers,
+        pin_memory=True,
+        drop_last=True,
+    )
+    logger.info(f"    Dataset contains {len(dataset):,} images.")
+    logger.info(f"    Index file: {args.index_file}.")
+    if args.multireso:
+        logger.info(
+            f"    Using MultiResolutionBucketIndexV2 with step {dataset.index_manager.step} "
+            f"and base size {dataset.index_manager.base_size}"
+        )
+        logger.info(f"\n  {dataset.index_manager.resolutions}")
+
+    # ===========================================================================
+    # Loading parameter
+    # ===========================================================================
+
+    logger.info(f"Loading parameter")
+    start_epoch = 0
+    start_epoch_step = 0
+    train_steps = 0
+    # Resume checkpoint if needed
+    if args.resume:
+        model, ema, start_epoch, start_epoch_step, train_steps = model_resume(
+            args, model, ema, logger, len(loader)
+        )
+
+    if args.training_parts == "lora":
+        loraconfig = LoraConfig(
+            r=args.rank, lora_alpha=args.rank, target_modules=args.target_modules
+        )
+        if args.use_fp16:
+            model.module = get_peft_model(model.module, loraconfig)
+        else:
+            model = get_peft_model(model, loraconfig)
+
+    logger.info(f"    Training parts: {args.training_parts}")
+
+    model, opt, scheduler = deepspeed_initialize(
+        args, logger, model, opt, deepspeed_config
+    )
+
+    # ===========================================================================
+    # Training
+    # ===========================================================================
+
+    model.train()
+    if args.use_ema:
+        ema.eval()
+
+    print(f"    Worker {rank} ready.")
+    dist.barrier()
+
+    iters_per_epoch = len(loader)
+    logger.info(
+        " ****************************** Running training ******************************"
+    )
+    logger.info(f"      Number GPUs:               {world_size}")
+    logger.info(f"      Number training samples:   {len(dataset):,}")
+    logger.info(
+        f"      Number parameters:         {sum(p.numel() for p in model.parameters()):,}"
+    )
+    logger.info(
+        f"      Number trainable params:   {sum(p.numel() for p in get_trainable_params_ipa(model, args, freeze_others=True)):,}"
+    )
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Iters per epoch:           {iters_per_epoch:,}")
+    logger.info(f"      Batch size per device:     {batch_size}")
+    logger.info(
+        f"      Batch size all device:     {batch_size * world_size * grad_accu_steps:,} (world_size * batch_size * grad_accu_steps)"
+    )
+    logger.info(f"      Gradient Accu steps:       {args.grad_accu_steps}")
+    logger.info(
+        f"      Total optimization steps:  {args.epochs * iters_per_epoch // grad_accu_steps:,}"
+    )
+
+    logger.info(f"      Training epochs:           {start_epoch}/{args.epochs}")
+    logger.info(
+        f"      Training epoch steps:      {start_epoch_step:,}/{iters_per_epoch:,}"
+    )
+    logger.info(
+        f"      Training total steps:      {train_steps:,}/{min(args.max_training_steps, args.epochs * iters_per_epoch):,}"
+    )
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Noise schedule:            {args.noise_schedule}")
+    logger.info(
+        f"      Beta limits:               ({args.beta_start}, {args.beta_end})"
+    )
+    logger.info(f"      Learn sigma:               {args.learn_sigma}")
+    logger.info(f"      Prediction type:           {args.predict_type}")
+    logger.info(f"      Noise offset:              {args.noise_offset}")
+
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Using EMA model:           {args.use_ema} ({args.ema_dtype})")
+    if args.use_ema:
+        logger.info(
+            f"      Using EMA decay:           {ema.max_value if args.use_ema else None}"
+        )
+        logger.info(
+            f"      Using EMA warmup power:    {ema.power if args.use_ema else None}"
+        )
+    logger.info(f"      Using main model fp16:     {args.use_fp16}")
+    logger.info(f"      Using extra modules fp16:  {args.extra_fp16}")
+    logger.info(
+        "    ------------------------------------------------------------------------------"
+    )
+    logger.info(f"      Experiment directory:      {experiment_dir}")
+    logger.info(
+        "    *******************************************************************************"
+    )
+
+    if args.gc_interval > 0:
+        gc.disable()
+        gc.collect()
+
+    # Variables for monitoring/logging purposes:
+    log_steps = 0
+    running_loss = 0
+    start_time = time.time()
+
+    # Training loop
+    epoch = start_epoch
+    while epoch < args.epochs:
+        # Random shuffle dataset
+        shuffle_seed = args.global_seed + epoch
+        logger.info(f"    Start random shuffle with seed={shuffle_seed}")
+        # Makesure all processors use the same seed to shuffle dataset.
+        dataset.shuffle(seed=shuffle_seed, fast=True)
+        logger.info(f"    End of random shuffle")
+
+        # Move sampler to start_index
+        if not args.multireso:
+            start_index = start_epoch_step * world_size * batch_size
+            if start_index != sampler.start_index:
+                sampler.start_index = start_index
+                # Reset start_epoch_step to zero, to ensure next epoch will start from the beginning.
+                start_epoch_step = 0
+                logger.info(f"      Iters left this epoch: {len(loader):,}")
+
+        logger.info(f"    Beginning epoch {epoch}...")
+        for batch in loader:
+            latents, model_kwargs = prepare_model_inputs(
+                args,
+                batch,
+                device,
+                vae,
+                text_encoder,
+                img_encoder,
+                text_encoder_t5,
+                freqs_cis_img,
+            )
+
+            loss_dict = diffusion.training_losses(
+                model=model, x_start=latents, model_kwargs=model_kwargs
+            )
+            loss = loss_dict["loss"].mean()
+            model.backward(loss)
+            last_batch_iteration = (train_steps + 1) // (
+                global_batch_size // (batch_size * world_size)
+            )
+            model.step(lr_kwargs={"last_batch_iteration": last_batch_iteration})
+
+            if args.use_ema:
+                if args.use_fp16:
+                    ema.update(model.module.module, step=train_steps)
+                else:
+                    ema.update(model.module, step=train_steps)
+
+            # ===========================================================================
+            # Log loss values:
+            # ===========================================================================
+            running_loss += loss.item()
+            log_steps += 1
+            train_steps += 1
+            if train_steps % args.log_every == 0:
+                # Measure training speed:
+                torch.cuda.synchronize()
+                end_time = time.time()
+                steps_per_sec = log_steps / (end_time - start_time)
+                # Reduce loss history over all processes:
+                avg_loss = torch.tensor(running_loss / log_steps, device=device)
+                dist.all_reduce(avg_loss, op=dist.ReduceOp.SUM)
+                avg_loss = avg_loss.item() / world_size
+                # get lr from deepspeed fused optimizer
+                logger.info(
+                    f"(step={train_steps:07d}) "
+                    + (
+                        f"(update_step={train_steps // args.grad_accu_steps:07d}) "
+                        if args.grad_accu_steps > 1
+                        else ""
+                    )
+                    + f"Train Loss: {avg_loss:.4f}, "
+                    f"Lr: {opt.param_groups[0]['lr']:.6g}, "
+                    f"Steps/Sec: {steps_per_sec:.2f}, "
+                    f"Samples/Sec: {int(steps_per_sec * batch_size * world_size):d}"
+                )
+                # Reset monitoring variables:
+                running_loss = 0
+                log_steps = 0
+                start_time = time.time()
+
+            # collect gc:
+            if args.gc_interval > 0 and (train_steps % args.gc_interval == 0):
+                gc.collect()
+
+            if (
+                train_steps % args.ckpt_every == 0
+                or train_steps % args.ckpt_latest_every == 0
+            ) and train_steps > 0:
+                save_checkpoint(
+                    args,
+                    rank,
+                    logger,
+                    model,
+                    ema,
+                    epoch,
+                    train_steps,
+                    checkpoint_dir,
+                    by="step",
+                )
+
+            if train_steps >= args.max_training_steps:
+                logger.info(f"Breaking step loop at train_steps={train_steps}.")
+                break
+
+        if train_steps >= args.max_training_steps:
+            logger.info(f"Breaking epoch loop at epoch={epoch}.")
+            break
+
+        # Finish an epoch
+        if args.ckpt_every_n_epoch > 0 and epoch % args.ckpt_every_n_epoch == 0:
+            save_checkpoint(
+                args,
+                rank,
+                logger,
+                model,
+                ema,
+                epoch,
+                train_steps,
+                checkpoint_dir,
+                by="epoch",
+            )
+
+        epoch += 1
+
+    save_checkpoint(
+        args, rank, logger, model, ema, epoch, train_steps, checkpoint_dir, by="final"
+    )
+
+    dist.destroy_process_group()
+
+
+if __name__ == "__main__":
+    # Start
+    main(get_args())

hydit/train_ipadapter.sh

+export NCCL_IB_GID_INDEX=3
+export NCCL_IB_SL=3
+export NCCL_CHECK_DISABLE=1
+export NCCL_P2P_DISABLE=0
+export NCCL_IB_DISABLE=0
+export NCCL_LL_THRESHOLD=16384
+export NCCL_IB_CUDA_SUPPORT=1
+export NCCL_SOCKET_IFNAME=bond1
+export UCX_NET_DEVICES=bond1
+export NCCL_IB_HCA=mlx5_bond_1,mlx5_bond_5,mlx5_bond_3,mlx5_bond_7,mlx5_bond_4,mlx5_bond_8,mlx5_bond_2,mlx5_bond_6
+export NCCL_COLLNET_ENABLE=0
+export SHARP_COLL_ENABLE_SAT=0
+export NCCL_NET_GDR_LEVEL=2
+export NCCL_IB_QPS_PER_CONNECTION=4
+export NCCL_IB_TC=160
+export NCCL_PXN_DISABLE=1
+
+
+
+task_flag="dit_g2_full_1024p"                                # the task flag is used to identify folders.                         # checkpoint root for resume
+resume=ckpts/t2i/model
+results_dir=./log_EXP                                        # save root for results
+batch_size=1                                                 # training batch size
+image_size=1024                                              # training image resolution
+grad_accu_steps=1                                            # gradient accumulation
+warmup_num_steps=0                                           # warm-up steps
+lr=0.0001                                                    # learning rate
+ckpt_every=100                                           # create a ckpt every a few steps.
+ckpt_latest_every=10000                                    # create a ckpt named `latest.pt` every a few steps.
+ckpt_every_n_epoch=2                                         # create a ckpt every a few epochs.
+epochs=8                                                     # total training epochs
+
+PYTHONPATH=. \
+sh $(dirname "$0")/run_g_ipadapter.sh \
+    --task-flag ${task_flag} \
+    --noise-schedule scaled_linear --beta-start 0.00085 --beta-end 0.018 \
+    --predict-type v_prediction \
+    --multireso \
+    --reso-step 64 \
+    --uncond-p 0.22 \
+    --uncond-p-t5 0.22\
+    --uncond-p-img 0.05\
+    --index-file  \
+    your data path \
+    --random-flip \
+    --lr ${lr} \
+    --batch-size ${batch_size} \
+    --image-size ${image_size} \
+    --global-seed 999 \
+    --grad-accu-steps ${grad_accu_steps} \
+    --warmup-num-steps ${warmup_num_steps} \
+    --use-flash-attn \
+    --use-fp16 \
+    --extra-fp16 \
+    --results-dir ${results_dir} \
+    --resume \
+    --resume-module-root ckpts/t2i/model/pytorch_model_module.pt \
+    --epochs ${epochs} \
+    --ckpt-every ${ckpt_every} \
+    --ckpt-latest-every ${ckpt_latest_every} \
+    --ckpt-every-n-epoch ${ckpt_every_n_epoch} \
+    --log-every 10 \
+    --deepspeed \
+    --use-zero-stage 2 \
+    --gradient-checkpointing \
+    --no-strict \
+    --training-parts ipadapter \
+    --is-ipa True \
+    --resume-ipa Ture \
+    --resume-ipa-root ckpts/t2i/model/ipa.pt  \
+    "$@"

hydit/train_v1.1.sh

+task_flag="dit_g2_full_1024p"                                             # the task flag is used to identify folders.
+resume_module_root=./ckpts/t2i/model_v1_1/pytorch_model_distill.pt   # checkpoint root for resume
+index_file=dataset/porcelain/jsons/porcelain.json                         # index file for dataloader
+results_dir=./log_EXP                                                     # save root for results
+batch_size=1                                                              # training batch size
+image_size=1024                                                           # training image resolution
+grad_accu_steps=1                                                         # gradient accumulation
+warmup_num_steps=0                                                        # warm-up steps
+lr=0.0001                                                                 # learning rate
+ckpt_every=9999999                                                        # create a ckpt every a few steps.
+ckpt_latest_every=9999999                                                 # create a ckpt named `latest.pt` every a few steps.
+ckpt_every_n_epoch=2                                                      # create a ckpt every a few epochs.
+epochs=8                                                                  # total training epochs
+
+
+sh $(dirname "$0")/run_g.sh \
+    --task-flag ${task_flag} \
+    --noise-schedule scaled_linear --beta-start 0.00085 --beta-end 0.03 \
+    --predict-type v_prediction \
+    --uncond-p 0.44 \
+    --uncond-p-t5 0.44 \
+    --index-file ${index_file} \
+    --random-flip \
+    --lr ${lr} \
+    --batch-size ${batch_size} \
+    --image-size ${image_size} \
+    --global-seed 999 \
+    --grad-accu-steps ${grad_accu_steps} \
+    --warmup-num-steps ${warmup_num_steps} \
+    --use-flash-attn \
+    --use-fp16 \
+    --extra-fp16 \
+    --results-dir ${results_dir} \
+    --resume \
+    --resume-module-root ${resume_module_root} \
+    --epochs ${epochs} \
+    --ckpt-every ${ckpt_every} \
+    --ckpt-latest-every ${ckpt_latest_every} \
+    --ckpt-every-n-epoch ${ckpt_every_n_epoch} \
+    --log-every 10 \
+    --deepspeed \
+    --use-zero-stage 2 \
+    --gradient-checkpointing \
+    --use-style-cond \
+    --size-cond 1024 1024 \
+    "$@"

hydit/utils/img_clip_emb.py

+# Hunyuan CLIP 模型初始化
+import sys
+import tqdm
+import argparse
+from PIL import Image
+import copy
+import json
+import os
+import numpy as np
+
+sys.path.append(os.getcwd())
+
+from transformers import BertTokenizer
+import torch
+from torchvision.transforms import (
+    Compose,
+    ToTensor,
+    Normalize,
+    Resize,
+    InterpolationMode,
+)
+from collections import OrderedDict
+from typing import Tuple, Union
+from itertools import repeat
+import collections.abc
+
+import math
+import logging
+import numpy as np
+import torch
+import torch.nn.functional as F
+from torch import nn
+from torch.utils.checkpoint import checkpoint
+
+import importlib.util
+
+# if importlib.util.find_spec('flash_attn'):
+#     FlashMHA = importlib.import_module('flash_attn.flash_attention').FlashMHA
+
+
+class Bottleneck(nn.Module):
+    expansion = 4
+
+    def __init__(self, inplanes, planes, stride=1):
+        super().__init__()
+
+        # all conv layers have stride 1. an avgpool is performed after the second convolution when stride > 1
+        self.conv1 = nn.Conv2d(inplanes, planes, 1, bias=False)
+        self.bn1 = nn.BatchNorm2d(planes)
+
+        self.conv2 = nn.Conv2d(planes, planes, 3, padding=1, bias=False)
+        self.bn2 = nn.BatchNorm2d(planes)
+
+        self.avgpool = nn.AvgPool2d(stride) if stride > 1 else nn.Identity()
+
+        self.conv3 = nn.Conv2d(planes, planes * self.expansion, 1, bias=False)
+        self.bn3 = nn.BatchNorm2d(planes * self.expansion)
+
+        self.relu = nn.ReLU(inplace=True)
+        self.downsample = None
+        self.stride = stride
+
+        if stride > 1 or inplanes != planes * Bottleneck.expansion:
+            # downsampling layer is prepended with an avgpool, and the subsequent convolution has stride 1
+            self.downsample = nn.Sequential(
+                OrderedDict(
+                    [
+                        ("-1", nn.AvgPool2d(stride)),
+                        (
+                            "0",
+                            nn.Conv2d(
+                                inplanes,
+                                planes * self.expansion,
+                                1,
+                                stride=1,
+                                bias=False,
+                            ),
+                        ),
+                        ("1", nn.BatchNorm2d(planes * self.expansion)),
+                    ]
+                )
+            )
+
+    def forward(self, x: torch.Tensor):
+        identity = x
+
+        out = self.relu(self.bn1(self.conv1(x)))
+        out = self.relu(self.bn2(self.conv2(out)))
+        out = self.avgpool(out)
+        out = self.bn3(self.conv3(out))
+
+        if self.downsample is not None:
+            identity = self.downsample(x)
+
+        out += identity
+        out = self.relu(out)
+        return out
+
+
+class AttentionPool2d(nn.Module):
+    def __init__(
+        self, spacial_dim: int, embed_dim: int, num_heads: int, output_dim: int = None
+    ):
+        super().__init__()
+        self.positional_embedding = nn.Parameter(
+            torch.randn(spacial_dim**2 + 1, embed_dim) / embed_dim**0.5
+        )
+        self.k_proj = nn.Linear(embed_dim, embed_dim)
+        self.q_proj = nn.Linear(embed_dim, embed_dim)
+        self.v_proj = nn.Linear(embed_dim, embed_dim)
+        self.c_proj = nn.Linear(embed_dim, output_dim or embed_dim)
+        self.num_heads = num_heads
+
+    def forward(self, x):
+        x = x.reshape(x.shape[0], x.shape[1], x.shape[2] * x.shape[3]).permute(
+            2, 0, 1
+        )  # NCHW -> (HW)NC
+        x = torch.cat([x.mean(dim=0, keepdim=True), x], dim=0)  # (HW+1)NC
+        x = x + self.positional_embedding[:, None, :].to(x.dtype)  # (HW+1)NC
+        x, _ = F.multi_head_attention_forward(
+            query=x,
+            key=x,
+            value=x,
+            embed_dim_to_check=x.shape[-1],
+            num_heads=self.num_heads,
+            q_proj_weight=self.q_proj.weight,
+            k_proj_weight=self.k_proj.weight,
+            v_proj_weight=self.v_proj.weight,
+            in_proj_weight=None,
+            in_proj_bias=torch.cat(
+                [self.q_proj.bias, self.k_proj.bias, self.v_proj.bias]
+            ),
+            bias_k=None,
+            bias_v=None,
+            add_zero_attn=False,
+            dropout_p=0,
+            out_proj_weight=self.c_proj.weight,
+            out_proj_bias=self.c_proj.bias,
+            use_separate_proj_weight=True,
+            training=self.training,
+            need_weights=False,
+        )
+
+        return x[0]
+
+
+class ModifiedResNet(nn.Module):
+    """
+    A ResNet class that is similar to torchvision's but contains the following changes:
+    - There are now 3 "stem" convolutions as opposed to 1, with an average pool instead of a max pool.
+    - Performs anti-aliasing strided convolutions, where an avgpool is prepended to convolutions with stride > 1
+    - The final pooling layer is a QKV attention instead of an average pool
+    """
+
+    def __init__(self, layers, output_dim, heads, input_resolution=224, width=64):
+        super().__init__()
+        self.output_dim = output_dim
+        self.input_resolution = input_resolution
+
+        # the 3-layer stem
+        self.conv1 = nn.Conv2d(
+            3, width // 2, kernel_size=3, stride=2, padding=1, bias=False
+        )
+        self.bn1 = nn.BatchNorm2d(width // 2)
+        self.conv2 = nn.Conv2d(
+            width // 2, width // 2, kernel_size=3, padding=1, bias=False
+        )
+        self.bn2 = nn.BatchNorm2d(width // 2)
+        self.conv3 = nn.Conv2d(width // 2, width, kernel_size=3, padding=1, bias=False)
+        self.bn3 = nn.BatchNorm2d(width)
+        self.avgpool = nn.AvgPool2d(2)
+        self.relu = nn.ReLU(inplace=True)
+
+        # residual layers
+        self._inplanes = width  # this is a *mutable* variable used during construction
+        self.layer1 = self._make_layer(width, layers[0])
+        self.layer2 = self._make_layer(width * 2, layers[1], stride=2)
+        self.layer3 = self._make_layer(width * 4, layers[2], stride=2)
+        self.layer4 = self._make_layer(width * 8, layers[3], stride=2)
+
+        embed_dim = width * 32  # the ResNet feature dimension
+        self.attnpool = AttentionPool2d(
+            input_resolution // 32, embed_dim, heads, output_dim
+        )
+
+    def _make_layer(self, planes, blocks, stride=1):
+        layers = [Bottleneck(self._inplanes, planes, stride)]
+
+        self._inplanes = planes * Bottleneck.expansion
+        for _ in range(1, blocks):
+            layers.append(Bottleneck(self._inplanes, planes))
+
+        return nn.Sequential(*layers)
+
+    @torch.jit.ignore
+    def set_grad_checkpointing(self, enable=True):
+        # FIXME support for non-transformer
+        pass
+
+    def forward(self, x):
+        def stem(x):
+            for conv, bn in [
+                (self.conv1, self.bn1),
+                (self.conv2, self.bn2),
+                (self.conv3, self.bn3),
+            ]:
+                x = self.relu(bn(conv(x)))
+            x = self.avgpool(x)
+            return x
+
+        x = x.type(self.conv1.weight.dtype)
+        x = stem(x)
+        x = self.layer1(x)
+        x = self.layer2(x)
+        x = self.layer3(x)
+        x = self.layer4(x)
+        x = self.attnpool(x)
+
+        return x
+
+
+class LayerNorm(nn.LayerNorm):
+    """Subclass torch's LayerNorm to handle fp16."""
+
+    def forward(self, x: torch.Tensor):
+        orig_type = x.dtype
+        ret = super().forward(x.type(torch.float32))
+        return ret.type(orig_type)
+
+
+class QuickGELU(nn.Module):
+    def forward(self, x: torch.Tensor):
+        return x * torch.sigmoid(1.702 * x)
+
+
+class ResidualAttentionBlock(nn.Module):
+    def __init__(
+        self,
+        d_model: int,
+        n_head: int,
+        attn_mask: torch.Tensor = None,
+        use_flash_attention: bool = False,
+    ):
+        super().__init__()
+
+        # self.attn = nn.MultiheadAttention(d_model, n_head) if not use_flash_attention else FlashMHA(d_model, n_head)
+        self.attn = nn.MultiheadAttention(d_model, n_head)
+        self.ln_1 = LayerNorm(d_model)
+        self.mlp = nn.Sequential(
+            OrderedDict(
+                [
+                    ("c_fc", nn.Linear(d_model, d_model * 4)),
+                    ("gelu", QuickGELU()),
+                    ("c_proj", nn.Linear(d_model * 4, d_model)),
+                ]
+            )
+        )
+        self.ln_2 = LayerNorm(d_model)
+        self.attn_mask = attn_mask
+        self.use_flash_attention = use_flash_attention
+
+    def attention(self, x: torch.Tensor):
+        self.attn_mask = (
+            self.attn_mask.to(dtype=x.dtype, device=x.device)
+            if self.attn_mask is not None
+            else None
+        )
+        if self.use_flash_attention:
+            # Batch first is needed for FlashAttention. See https://github.com/HazyResearch/flash-attention/issues/84 for more information.
+            return self.attn(x.transpose(1, 0))[0].transpose(1, 0)
+        else:
+            return self.attn(x, x, x, need_weights=False, attn_mask=self.attn_mask)[0]
+
+    def forward(self, x: torch.Tensor):
+        x = x + self.attention(self.ln_1(x))
+        x = x + self.mlp(self.ln_2(x))
+        return x
+
+
+class Transformer(nn.Module):
+    def __init__(
+        self,
+        width: int,
+        layers: int,
+        heads: int,
+        attn_mask: torch.Tensor = None,
+        use_flash_attention: bool = False,
+    ):
+        super().__init__()
+        self.width = width
+        self.layers = layers
+        self.grad_checkpointing = False
+        self.resblocks = nn.Sequential(
+            *[
+                ResidualAttentionBlock(width, heads, attn_mask, use_flash_attention)
+                for _ in range(layers)
+            ]
+        )
+
+    def forward(self, x: torch.Tensor):
+        if self.grad_checkpointing and not torch.jit.is_scripting():
+            for r in self.resblocks:
+                x = checkpoint(r, x)
+            return x
+        return self.resblocks(x)
+
+
+class VisualTransformer(nn.Module):
+    def __init__(
+        self,
+        input_resolution: int,
+        patch_size: int,
+        width: int,
+        layers: int,
+        heads: int,
+        output_dim: int,
+        use_flash_attention: bool = False,
+    ):
+        super().__init__()
+        self.input_resolution = input_resolution
+        self.grid_size = (
+            self.input_resolution // patch_size,
+            self.input_resolution // patch_size,
+        )
+        self.output_dim = output_dim
+        self.conv1 = nn.Conv2d(
+            in_channels=3,
+            out_channels=width,
+            kernel_size=patch_size,
+            stride=patch_size,
+            bias=False,
+        )
+
+        scale = width**-0.5
+        self.class_embedding = nn.Parameter(scale * torch.randn(width))
+        self.positional_embedding = nn.Parameter(
+            scale * torch.randn((input_resolution // patch_size) ** 2 + 1, width)
+        )
+        self.ln_pre = LayerNorm(width)
+
+        self.transformer = Transformer(
+            width, layers, heads, use_flash_attention=use_flash_attention
+        )
+
+        self.ln_post = LayerNorm(width)
+        self.proj = nn.Parameter(scale * torch.randn(width, output_dim))
+
+    @torch.jit.ignore
+    def set_grad_checkpointing(self, enable=True):
+        self.transformer.grad_checkpointing = enable
+
+    def random_masking(self, x, mask_ratio):
+        N, L, D = x.shape  # batch, length, dim
+        len_keep = int((L - 1) * (1 - mask_ratio))
+
+        noise = torch.rand(N, L - 1, device=x.device)
+        ids_shuffle = torch.argsort(noise, dim=1) + torch.ones(
+            N, L - 1, device=x.device, dtype=int
+        )
+        ids_keep = ids_shuffle[:, :len_keep]
+
+        x_masked = torch.gather(x, dim=1, index=ids_keep.unsqueeze(-1).repeat(1, 1, D))
+
+        x0 = x[:, 0, :]
+        x0 = x0.reshape(N, 1, D)
+        x_masked_add = torch.cat([x0, x_masked], axis=1)
+        return x_masked_add
+
+    def forward(self, x: torch.Tensor, mask_ratio: float = 0.0):
+        x = self.conv1(x)  # shape = [*, width, grid, grid]
+        x = x.reshape(x.shape[0], x.shape[1], -1)  # shape = [*, width, grid ** 2]
+        x = x.permute(0, 2, 1)  # shape = [*, grid ** 2, width]
+        x = torch.cat(
+            [
+                self.class_embedding.to(x.dtype)
+                + torch.zeros(
+                    x.shape[0], 1, x.shape[-1], dtype=x.dtype, device=x.device
+                ),
+                x,
+            ],
+            dim=1,
+        )  # shape = [*, grid ** 2 + 1, width]
+        x = x + self.positional_embedding.to(x.dtype)
+        if mask_ratio != 0:
+            x = self.random_masking(x, mask_ratio)
+        x = self.ln_pre(x)
+
+        x = x.permute(1, 0, 2)  # NLD -> LND
+        x = self.transformer(x)
+        x = x.permute(1, 0, 2)  # LND -> NLD
+
+        x = self.ln_post(x[:, 0, :])
+
+        if self.proj is not None:
+            x = x @ self.proj
+
+        return x
+
+
+class CLIP(nn.Module):
+    def __init__(
+        self,
+        embed_dim: int,
+        # vision
+        image_resolution: int,
+        vision_layers: Union[Tuple[int, int, int, int], int],
+        vision_width: int,
+        vision_patch_size: int,
+        # text
+        vocab_size: int,
+        text_attention_probs_dropout_prob: float,
+        text_hidden_act: str,
+        text_hidden_dropout_prob: float,
+        text_hidden_size: int,
+        text_initializer_range: float,
+        text_intermediate_size: int,
+        text_max_position_embeddings: int,
+        text_num_attention_heads: int,
+        text_num_hidden_layers: int,
+        text_type_vocab_size: int,
+        # tokenizer = _tokenizer,
+        # vision head width, added this param for ViT-H
+        vision_head_width: int = 64,
+        use_flash_attention: bool = False,
+        args={},
+    ):
+        super().__init__()
+        print("use_flash_attention", use_flash_attention)
+
+        if isinstance(vision_layers, (tuple, list)):
+            vision_heads = vision_width * 32 // vision_head_width
+            self.visual = ModifiedResNet(
+                layers=vision_layers,
+                output_dim=embed_dim,
+                heads=vision_heads,
+                input_resolution=image_resolution,
+                width=vision_width,
+            )
+        else:
+            vision_heads = vision_width // vision_head_width
+            self.visual = VisualTransformer(
+                input_resolution=image_resolution,
+                patch_size=vision_patch_size,
+                width=vision_width,
+                layers=vision_layers,
+                heads=vision_heads,
+                output_dim=embed_dim,
+                use_flash_attention=use_flash_attention,
+            )
+
+        # load isogclr loss tempNetwork
+        if (
+            "contrastive_loss_type" in args
+            and args.contrastive_loss_type == "isogclr_loss"
+        ):
+            feat_dim = args.isogclr_loss_feat_dim
+            squeeze_dim = args.isogclr_loss_squeeze_dim
+            tau_min, tau_max = args.isogclr_loss_tau_min, args.isogclr_loss_tau_max
+            if args.isogclr_loss_temp_input == "unimodal":
+                self.image_temp_gen = TempGenerator(
+                    feature_dim=feat_dim,
+                    M=squeeze_dim,
+                    tau_min=tau_min,
+                    tau_max=tau_max,
+                )
+                self.text_temp_gen = TempGenerator(
+                    feature_dim=feat_dim,
+                    M=squeeze_dim,
+                    tau_min=tau_min,
+                    tau_max=tau_max,
+                )
+            else:
+                self.temp_gen = TempGenerator(
+                    feature_dim=feat_dim,
+                    M=squeeze_dim,
+                    tau_min=tau_min,
+                    tau_max=tau_max,
+                )
+        else:
+            self.logit_scale = nn.Parameter(torch.ones([]) * np.log(1 / 0.07))
+        self.args = args
+        self.initialize_parameters()
+
+    def initialize_parameters(self):
+        # self.logit_scale = nn.Parameter(torch.ones([]) * np.log(1 / 0.07))
+        if isinstance(self.visual, ModifiedResNet):
+            if self.visual.attnpool is not None:
+                std = self.visual.attnpool.c_proj.in_features**-0.5
+                nn.init.normal_(self.visual.attnpool.q_proj.weight, std=std)
+                nn.init.normal_(self.visual.attnpool.k_proj.weight, std=std)
+                nn.init.normal_(self.visual.attnpool.v_proj.weight, std=std)
+                nn.init.normal_(self.visual.attnpool.c_proj.weight, std=std)
+
+            for resnet_block in [
+                self.visual.layer1,
+                self.visual.layer2,
+                self.visual.layer3,
+                self.visual.layer4,
+            ]:
+                for name, param in resnet_block.named_parameters():
+                    if name.endswith("bn3.weight"):
+                        nn.init.zeros_(param)
+
+    @torch.jit.ignore
+    def set_grad_checkpointing(self, enable=True):
+        self.visual.set_grad_checkpointing(enable)
+        self.bert.set_grad_checkpointing(enable)
+
+    @property
+    def dtype(self):
+        return self.visual.conv1.weight.dtype
+
+    def encode_image(self, image, mask_ratio=0):
+        if isinstance(self.visual, ModifiedResNet):
+            # mask_ratio > 0 (FLIP strategy) is currently only implemented for VisualTransformer.
+            return self.visual(image.type(self.dtype))
+        return self.visual(image.type(self.dtype), mask_ratio)
+
+
+def convert_models_to_fp32(model):
+    for p in model.parameters():
+        p.data = p.data.float()
+        if p.grad:
+            p.grad.data = p.grad.data.float()
+
+
+def convert_weights(model: nn.Module):
+    """Convert applicable model parameters to fp16"""
+
+    def _convert_weights_to_fp16(l):
+        if isinstance(l, (nn.Conv1d, nn.Conv2d, nn.Linear)):
+            l.weight.data = l.weight.data.half()
+            if l.bias is not None:
+                l.bias.data = l.bias.data.half()
+
+        if isinstance(l, nn.MultiheadAttention):
+            for attr in [
+                *[f"{s}_proj_weight" for s in ["in", "q", "k", "v"]],
+                "in_proj_bias",
+                "bias_k",
+                "bias_v",
+            ]:
+                tensor = getattr(l, attr)
+                if tensor is not None:
+                    tensor.data = tensor.data.half()
+
+        if isinstance(l, BertModel):
+            l.to(torch.half)
+
+        for name in ["text_projection", "proj"]:
+            if hasattr(l, name):
+                attr = getattr(l, name)
+                if attr is not None:
+                    attr.data = attr.data.half()
+
+    model.apply(_convert_weights_to_fp16)
+
+
+def convert_state_dict(state_dict):
+    """Adapt to Flash Attention"""
+    if not state_dict:
+        return state_dict
+
+    prefix = "module." if list(state_dict.keys())[0].startswith("module") else ""
+
+    if f"{prefix}visual.transformer.resblocks.0.attn.in_proj_weight" in state_dict:
+        for k in list(state_dict.keys()):
+            if "attn.in_proj_weight" in k:
+                state_dict[k.replace("attn.in_proj_weight", "attn.Wqkv.weight")] = (
+                    state_dict.pop(k)
+                )
+            elif "attn.in_proj_bias" in k:
+                state_dict[k.replace("attn.in_proj_bias", "attn.Wqkv.bias")] = (
+                    state_dict.pop(k)
+                )
+    elif f"{prefix}visual.transformer.resblocks.0.attn.Wqkv.weight" in state_dict:
+        for k in list(state_dict.keys()):
+            if "attn.Wqkv.weight" in k:
+                state_dict[k.replace("attn.Wqkv.weight", "attn.in_proj_weight")] = (
+                    state_dict.pop(k)
+                )
+            elif "attn.Wqkv.bias" in k:
+                state_dict[k.replace("attn.Wqkv.bias", "attn.in_proj_bias")] = (
+                    state_dict.pop(k)
+                )
+
+    if f"{prefix}bert.encoder.layer.0.attention.self.query.weight" in state_dict:
+        i = 0
+        while (
+            f"{prefix}bert.encoder.layer.{i}.attention.self.query.weight" in state_dict
+        ):
+            state_dict[f"{prefix}bert.encoder.layer.{i}.attention.self.Wqkv.weight"] = (
+                torch.cat(
+                    (
+                        state_dict.pop(
+                            f"{prefix}bert.encoder.layer.{i}.attention.self.query.weight"
+                        ),
+                        state_dict.pop(
+                            f"{prefix}bert.encoder.layer.{i}.attention.self.key.weight"
+                        ),
+                        state_dict.pop(
+                            f"{prefix}bert.encoder.layer.{i}.attention.self.value.weight"
+                        ),
+                    )
+                )
+            )
+            state_dict[f"{prefix}bert.encoder.layer.{i}.attention.self.Wqkv.bias"] = (
+                torch.cat(
+                    (
+                        state_dict.pop(
+                            f"{prefix}bert.encoder.layer.{i}.attention.self.query.bias"
+                        ),
+                        state_dict.pop(
+                            f"{prefix}bert.encoder.layer.{i}.attention.self.key.bias"
+                        ),
+                        state_dict.pop(
+                            f"{prefix}bert.encoder.layer.{i}.attention.self.value.bias"
+                        ),
+                    )
+                )
+            )
+            state_dict[
+                f"{prefix}bert.encoder.layer.{i}.attention.self.out_proj.weight"
+            ] = state_dict.pop(
+                f"{prefix}bert.encoder.layer.{i}.attention.output.dense.weight"
+            )
+            state_dict[
+                f"{prefix}bert.encoder.layer.{i}.attention.self.out_proj.bias"
+            ] = state_dict.pop(
+                f"{prefix}bert.encoder.layer.{i}.attention.output.dense.bias"
+            )
+            i += 1
+    elif f"{prefix}bert.encoder.layer.0.attention.self.Wqkv.weight" in state_dict:
+        i = 0
+        while (
+            f"{prefix}bert.encoder.layer.{i}.attention.self.Wqkv.weight" in state_dict
+        ):
+            (
+                state_dict[
+                    f"{prefix}bert.encoder.layer.{i}.attention.self.query.weight"
+                ],
+                state_dict[f"{prefix}bert.encoder.layer.{i}.attention.self.key.weight"],
+                state_dict[
+                    f"{prefix}bert.encoder.layer.{i}.attention.self.value.weight"
+                ],
+            ) = torch.chunk(
+                state_dict.pop(
+                    f"{prefix}bert.encoder.layer.{i}.attention.self.Wqkv.weight"
+                ),
+                chunks=3,
+            )
+            (
+                state_dict[f"{prefix}bert.encoder.layer.{i}.attention.self.query.bias"],
+                state_dict[f"{prefix}bert.encoder.layer.{i}.attention.self.key.bias"],
+                state_dict[f"{prefix}bert.encoder.layer.{i}.attention.self.value.bias"],
+            ) = torch.chunk(
+                state_dict.pop(
+                    f"{prefix}bert.encoder.layer.{i}.attention.self.Wqkv.bias"
+                ),
+                chunks=3,
+            )
+            state_dict[
+                f"{prefix}bert.encoder.layer.{i}.attention.output.dense.weight"
+            ] = state_dict.pop(
+                f"{prefix}bert.encoder.layer.{i}.attention.self.out_proj.weight"
+            )
+            state_dict[
+                f"{prefix}bert.encoder.layer.{i}.attention.output.dense.bias"
+            ] = state_dict.pop(
+                f"module.bert.encoder.layer.{i}.attention.self.out_proj.bias"
+            )
+            i += 1
+
+    return state_dict
+
+
+# From PyTorch internals
+def _ntuple(n):
+    def parse(x):
+        if isinstance(x, collections.abc.Iterable):
+            return x
+        return tuple(repeat(x, n))
+
+    return parse
+
+
+to_1tuple = _ntuple(1)
+to_2tuple = _ntuple(2)
+to_3tuple = _ntuple(3)
+to_4tuple = _ntuple(4)
+to_ntuple = lambda n, x: _ntuple(n)(x)
+
+
+def _convert_to_rgb(image):
+    return image.convert("RGB")
+
+
+def image_transform(image_size=224):
+    transform = Compose(
+        [
+            Resize((image_size, image_size), interpolation=InterpolationMode.BICUBIC),
+            _convert_to_rgb,
+            ToTensor(),
+            Normalize(
+                (0.48145466, 0.4578275, 0.40821073),
+                (0.26862954, 0.26130258, 0.27577711),
+            ),
+        ]
+    )
+    return transform
+
+
+image_preprocess = image_transform(224)
+
+
+def convert_models_to_fp32(model):
+    for p in model.parameters():
+        p.data = p.data.float()
+        if p.grad:
+            p.grad.data = p.grad.data.float()
+
+
+class ImgClipEmbDetector:
+    def __init__(self):
+
+        # 用于预定于的多分类
+        self.image_preprocess = image_preprocess
+        config = dict()
+        config["vision_config"] = "ipadapter/model_configs/ViT-H-14.json"
+        config["gpu"] = torch.device("cuda" if torch.cuda.is_available() else "cpu")
+        config["text_config"] = (
+            "ipadapter/model_configs/RoBERTa-wwm-ext-large-cn-en.json"
+        )
+        config["precision"] = "amp"
+        config["context_length"] = 77
+        config["resume"] = "ckpts/t2i/clip_img_encoder/clip_img_encoder.pt"
+
+        self.cfg = config
+        self.model = self.build_model()
+
+    def build_model(self):
+        with open(self.cfg["vision_config"], "r") as fv, open(
+            self.cfg["text_config"], "r"
+        ) as ft:
+            model_info = json.load(fv)
+            if isinstance(model_info["vision_layers"], str):
+                model_info["vision_layers"] = eval(model_info["vision_layers"])
+            for k, v in json.load(ft).items():
+                model_info[k] = v
+        model = CLIP(**model_info)
+        if self.cfg["precision"] == "fp16":
+            convert_weights(model)
+        # See https://discuss.pytorch.org/t/valueerror-attemting-to-unscale-fp16-gradients/81372
+        if self.cfg["precision"] == "amp" or self.cfg["precision"] == "fp32":
+            convert_models_to_fp32(model)
+        if self.cfg["precision"] == "fp16":
+            convert_weights(model)
+        checkpoint = torch.load(self.cfg["resume"], map_location="cpu")
+        sd = checkpoint["state_dict"]
+        if next(iter(sd.items()))[0].startswith("module"):
+            sd = {
+                k[len("module.") :]: v for k, v in sd.items() if "bert.pooler" not in k
+            }
+        model.load_state_dict(sd, strict=False)
+        print(
+            f"=> loaded checkpoint {self.cfg['resume']} (epoch {checkpoint['epoch']} @ {checkpoint['step']} steps)"
+        )
+        model.eval()
+        loc = self.cfg["gpu"]
+        model.to(loc)
+        self.cfg["device"] = loc
+        return model
+
+    def __call__(self, images):
+        # texts: must be list-of-str
+        with torch.no_grad():
+            image_features = self.model.encode_image(images)
+            image_features /= image_features.norm(dim=-1, keepdim=True)
+            return image_features

hydit/utils/tools.py

+import random
+import logging
+from pathlib import Path
+import shutil
+
+import numpy as np
+from PIL import Image
+import torch
+import torch.distributed as dist
+from tqdm.auto import tqdm
+import math
+import torch.nn.functional as F
+import os
+
+
+def get_trainable_params(model):
+    params = model.parameters()
+    params = [p for p in params if p.requires_grad]
+    return params
+
+
+def get_trainable_params_ipa(model, args, freeze_others=False):
+    if args.training_parts == "all":
+        params = model.parameters()
+    elif args.training_parts == "time_embedding":
+        params = [p for n, p in model.named_parameters() if "t_embedder" in n]
+        if freeze_others:
+            for n, p in model.named_parameters():
+                if "t_embedder" not in n:
+                    p.requires_grad_(False)
+    elif (
+        args.training_parts == "adapt_concat_to_text_concat"
+    ):  # adapt concat to text_concat
+
+        def valid_name(n):
+            if (
+                "default_modulation" in n
+                or "image_meta_size_embedder" in n
+                or "t_embedder" in n
+            ):
+                return True
+            return False
+
+        params = []
+        for n, p in model.named_parameters():
+            if valid_name(n):
+                params.append(p)
+            elif freeze_others:
+                p.requires_grad_(False)
+    elif args.training_parts == "ipadapter":
+        params = [p for n, p in model.named_parameters() if "ip_adapter" in n]
+        # print('params', params)
+        if freeze_others:
+            for n, p in model.named_parameters():
+                if "ip_adapter" not in n:
+                    p.requires_grad_(False)
+                else:
+                    pass
+    else:
+        raise ValueError(f"Unknown training_parts {args.training_parts}")
+    return params
+
+
+def set_seeds(seed_list, device=None):
+    if isinstance(seed_list, (tuple, list)):
+        seed = sum(seed_list)
+    else:
+        seed = seed_list
+    random.seed(seed)
+    np.random.seed(seed)
+    torch.manual_seed(seed)
+    torch.cuda.manual_seed_all(seed)
+
+    return torch.Generator(device).manual_seed(seed)
+
+
+def get_start_epoch(resume_path, ckpt, steps_per_epoch):
+    if "epoch" in ckpt:
+        start_epoch = ckpt["epoch"]
+    else:
+        start_epoch = 0
+    if "steps" in ckpt:
+        train_steps = ckpt["steps"]
+    else:
+        try:
+            train_steps = int(Path(resume_path).stem)
+        except:
+            train_steps = start_epoch * steps_per_epoch
+
+    start_epoch_step = train_steps % steps_per_epoch + 1
+    return start_epoch, start_epoch_step, train_steps
+
+
+def assert_shape(*args):
+    if len(args) < 2:
+        return
+    cond = True
+    fail_str = f"{args[0] if isinstance(args[0], (list, tuple)) else args[0].shape}"
+    for i in range(1, len(args)):
+        shape1 = args[i] if isinstance(args[i], (list, tuple)) else args[i].shape
+        shape2 = (
+            args[i - 1] if isinstance(args[i - 1], (list, tuple)) else args[i - 1].shape
+        )
+        cond = cond and (shape1 == shape2)
+        fail_str += (
+            f" vs {args[i] if isinstance(args[i], (list, tuple)) else args[i].shape}"
+        )
+    assert cond, fail_str
+
+
+def create_logger(logging_dir=None, logging_file=None, ddp=True):
+    """
+    Create a logger that writes to a log file and stdout.
+    """
+    if not ddp or (ddp and dist.get_rank() == 0):  # real logger
+        if logging_file is not None:
+            file_handler = [logging.FileHandler(logging_file)]
+        elif logging_dir is not None:
+            file_handler = [logging.FileHandler(f"{logging_dir}/log.txt")]
+        else:
+            file_handler = []
+        logging.basicConfig(
+            level=logging.INFO,
+            format="[\033[34m%(asctime)s\033[0m] %(message)s",
+            datefmt="%Y-%m-%d %H:%M:%S",
+            handlers=[logging.StreamHandler()] + file_handler,
+        )
+        logger = logging.getLogger(__name__)
+    else:
+        logger = logging.getLogger(__name__)
+        logger.addHandler(logging.NullHandler())
+    return logger
+
+
+def create_exp_folder(args, rank):
+    if rank == 0:
+        os.makedirs(args.results_dir, exist_ok=True)
+    existed_experiments = list(Path(args.results_dir).glob("*dit*"))
+    if len(existed_experiments) == 0:
+        experiment_index = 1
+    else:
+        existed_experiments.sort()
+        print("existed_experiments", existed_experiments)
+        experiment_index = (
+            max([int(x.stem.split("-")[0]) for x in existed_experiments]) + 1
+        )
+    dist.barrier()
+    model_string_name = (
+        args.task_flag if args.task_flag else args.model.replace("/", "-")
+    )
+    experiment_dir = f"{args.results_dir}/{experiment_index:03d}-{model_string_name}"  # Create an experiment folder
+    checkpoint_dir = f"{experiment_dir}/checkpoints"  # Stores saved model checkpoints
+    if rank == 0:
+        os.makedirs(checkpoint_dir, exist_ok=True)
+        logger = create_logger(experiment_dir)
+        logger.info(f"Experiment directory created at {experiment_dir}")
+    else:
+        logger = create_logger()
+        experiment_dir = ""
+
+    return experiment_dir, checkpoint_dir, logger
+
+
+def model_resume(args, model, ema, logger, len_loader):
+    """
+    Load pretrained weights.
+    """
+    start_epoch = 0
+    start_epoch_step = 0
+    train_steps = 0
+
+    # Resume model
+    if args.resume:
+        resume_path = args.resume_module_root
+        if not Path(resume_path).exists():
+            raise FileNotFoundError(
+                f"    Cannot find model checkpoint from {resume_path}"
+            )
+        logger.info(f"    Resume from checkpoint {resume_path}")
+        resume_ckpt = torch.load(resume_path, map_location=lambda storage, loc: storage)
+        if "module" in resume_ckpt.keys():
+            model.load_state_dict(resume_ckpt["module"], strict=args.strict)
+        else:
+            model.load_state_dict(resume_ckpt, strict=args.strict)
+
+    # Resume EMA model
+    if args.use_ema:
+        resume_ema_path = args.resume_ema_root
+        if not Path(resume_ema_path).exists():
+            raise FileNotFoundError(
+                f"    Cannot find ema checkpoint from {resume_ema_path}"
+            )
+        logger.info(f"    Resume from ema checkpoint {resume_path}")
+        resume_ema_ckpt = torch.load(
+            resume_ema_path, map_location=lambda storage, loc: storage
+        )
+        if "ema" in resume_ema_ckpt.keys():
+            ema.load_state_dict(resume_ema_ckpt["ema"], strict=args.strict)
+        elif "module" in resume_ema_ckpt.keys():
+            ema.load_state_dict(resume_ema_ckpt["module"], strict=args.strict)
+        else:
+            ema.load_state_dict(resume_ema_ckpt, strict=args.strict)
+
+    if not args.reset_loader:
+        start_epoch, start_epoch_step, train_steps = get_start_epoch(
+            args.resume, resume_ckpt, len_loader
+        )
+
+    if args.resume_ipa:
+        if Path(args.resume_ipa_root).exists():
+            logger.info(f"    Resume from ipa checkpoint {args.resume_ipa_root}")
+            ipa_state_dict = torch.load(
+                args.resume_ipa_root, map_location=lambda storage, loc: storage
+            )
+            model.load_state_dict(ipa_state_dict, strict=False)
+        else:
+            raise FileNotFoundError(
+                f"    Cannot find ipa-checkpoint from {args.resume_ipa_root}"
+            )
+
+    return model, ema, start_epoch, start_epoch_step, train_steps

ipadapter/README.md

+## Using HunyuanDiT IP-Adapter
+
+
+### Instructions
+
+ The dependencies and installation are basically the same as the base model, and we use the module weights for training.
+ Download the model using the following commands:
+
+```bash
+cd HunyuanDiT
+# Use the huggingface-cli tool to download the model.
+# We recommend using module weights as the base model for IP-Adapter inference, as our provided pretrained weights are trained on them.
+huggingface-cli download Tencent-Hunyuan/IP-Adapter ipa.pt --local-dir ./ckpts/t2i/model
+huggingface-cli download Tencent-Hunyuan/IP-Adapter clip_img_encoder.pt  --local-dir ./ckpts/t2i/model/clip_img_encoder
+
+# Quick start
+python3 sample_ipadapter.py  --infer-mode fa --ref-image-path ipadapter/asset/input/tiger.png --i-scale 1.0 --prompt 一只老虎在海洋中游泳，背景是海洋。构图方式是居中构图，呈现了动漫风格和文化，营造了平静的氛围。 --infer-steps 100 --is-ipa True --load-key distill
+```
+
+Examples of ref input and IP-Adapter results are as follows:
+<table>
+  <tr>
+    <td colspan="3" align="center">Ref Input</td>
+  </tr>
+
+q
+
+
+
+  <tr>
+    <td align="center"><img src="asset/input/tiger.png" alt="Image 0" width="200"/></td>
+    <td align="center"><img src="asset/input/beauty.png" alt="Image 1" width="200"/></td>
+    <td align="center"><img src="asset/input/xunyicao.png" alt="Image 2" width="200"/></td>
+
+  </tr>
+
+  <tr>
+    <td colspan="3" align="center">IP-Adapter Output</td>
+  </tr>
+
+  <tr>
+    <td align="center">一只老虎在奔跑。<br>（A tiger running.） </td>
+    <td align="center">一个卡通美女，抱着一只小猪。<br>（A cartoon beauty holding a little pig.） </td>
+    <td align="center">一片紫色薰衣草地。<br>（A purple lavender field.） </td>
+  </tr>
+
+  <tr>
+    <td align="center"><img src="asset/output/tiger_run.png" alt="Image 3" width="200"/></td>
+    <td align="center"><img src="asset/output/beauty_pig.png" alt="Image 4" width="200"/></td>
+    <td align="center"><img src="asset/output/xunyicao_res.png" alt="Image 5" width="200"/></td>
+  </tr>
+
+  <tr>
+    <td align="center">一只老虎在看书。<br>（A tiger is reading a book.） </td>
+    <td align="center">一个卡通美女，穿着绿色衣服。<br>（A cartoon beauty wearing green clothes.） </td>
+    <td align="center">一片紫色薰衣草地，有一只可爱的小狗。<br>（A purple lavender field with a cute puppy.） </td>
+  </tr>
+
+  <tr>
+    <td align="center"><img src="asset/output/tiger_book.png" alt="Image 3" width="200"/></td>
+    <td align="center"><img src="asset/output/beauty_green_cloth.png" alt="Image 4" width="200"/></td>
+    <td align="center"><img src="asset/output/xunyicao_dog.png" alt="Image 5" width="200"/></td>
+  </tr>
+
+  <tr>
+    <td align="center">一只老虎在咆哮。<br>（A tiger is roaring.） </td>
+    <td align="center">一个卡通美女，戴着墨镜。<br>（A cartoon beauty wearing sunglasses.） </td>
+    <td align="center">水墨风格,一片紫色薰衣草地。<br>（Ink style. A purple lavender field.） </td>
+  </tr>
+  <tr>
+    <td align="center"><img src="asset/output/tiger_roar.png" alt="Image 3" width="200"/></td>
+    <td align="center"><img src="asset/output/beauty_glass.png" alt="Image 4" width="200"/></td>
+    <td align="center"><img src="asset/output/xunyicao_style.png" alt="Image 5" width="200"/></td>
+  </tr>
+
+
+</table>
+
+
+### Training
+
+We provide base model weights for IP-Adapter training, you can use `module` weights for IP-Adapter training.
+
+Here is an example, we load the `module` weights into the main model and conduct IP-Adapter training.
+
+If apply multiple resolution training, you need to add the `--multireso` and `--reso-step 64` parameter.
+
+```bash
+task_flag="IP_Adapter"                                # the task flag is used to identify folders.                         # checkpoint root for resume
+index_file=path/to/your/index_file
+results_dir=./log_EXP                                        # save root for results
+batch_size=1                                                 # training batch size
+image_size=1024                                              # training image resolution
+grad_accu_steps=1                                            # gradient accumulation
+warmup_num_steps=0                                           # warm-up steps
+lr=0.0001                                                    # learning rate
+ckpt_every=10                                         # create a ckpt every a few steps.
+ckpt_latest_every=10000                                    # create a ckpt named `latest.pt` every a few steps.
+ckpt_every_n_epoch=2                                         # create a ckpt every a few epochs.
+epochs=8                                                     # total training epochs
+
+PYTHONPATH=. \
+sh $(dirname "$0")/run_g_ipadapter.sh \
+    --task-flag ${task_flag} \
+    --noise-schedule scaled_linear --beta-start 0.00085 --beta-end 0.018 \
+    --predict-type v_prediction \
+    --multireso \
+    --reso-step 64 \
+    --uncond-p 0.22 \
+    --uncond-p-t5 0.22\
+    --uncond-p-img 0.05\
+    --index-file ${index_file} \
+    --random-flip \
+    --lr ${lr} \
+    --batch-size ${batch_size} \
+    --image-size ${image_size} \
+    --global-seed 999 \
+    --grad-accu-steps ${grad_accu_steps} \
+    --warmup-num-steps ${warmup_num_steps} \
+    --use-flash-attn \
+    --use-fp16 \
+    --extra-fp16 \
+    --results-dir ${results_dir} \
+    --resume\
+    --resume-module-root ckpts/t2i/model/pytorch_model_module.pt \
+    --epochs ${epochs} \
+    --ckpt-every ${ckpt_every} \
+    --ckpt-latest-every ${ckpt_latest_every} \
+    --ckpt-every-n-epoch ${ckpt_every_n_epoch} \
+    --log-every 10 \
+    --deepspeed \
+    --use-zero-stage 2 \
+    --gradient-checkpointing \
+    --no-strict \
+    --training-parts ipadapter \
+    --is-ipa True \
+    --resume-ipa True \
+    --resume-ipa-root ckpts/t2i/model/ipa.pt  \
+    "$@"
+
+```
+
+Recommended parameter settings
+
+|     Parameter     |  Description  |          Recommended Parameter Value                               | Note|
+|:---------------:|:---------:|:---------------------------------------------------:|:--:|
+|   `--batch-size` |    Training batch size    |        1        | Depends on GPU memory|
+|   `--grad-accu-steps` |    Size of gradient accumulation    |       2        | - |
+|   `--lr` |    Learning rate  |        0.0001        | - |
+|   `--training-parts` |  be trained parameters when training IP-Adapter  |        ipadapter        | - |
+|   `--is-ipa` |  training IP-Adapter or not  |        True       | - |
+|   `--resume-ipa-root` |  resume ipa model or not when training  |        ipa model path       | - |
+
+
+### Inference
+Use the following command line for inference.
+
+a. Use the parameter float i-scale to specify the weight of IP-Adapter reference image. The bigger parameter indicates more relativity to reference image.
+```bash
+python3 sample_ipadapter.py  --infer-mode fa --ref-image-path ipadapter/input/beach.png --i-scale 1.0 --prompt 一只老虎在海洋中游泳，背景是海洋。构图方式是居中构图，呈现了动漫风格和文化，营造了平静的氛围。 --infer-steps 100 --is-ipa True --load-key module
+```
+
