create branch for v2.9

docs/extension/patch_autodoc.py

+"""Hack autodoc to get more fine-grained docstring rendering contol.
+
+autodoc and autosummary didn't expose many of their controls to sphinx users via config.
+To customize them, the "correct" approach seems to copy and paste all their code and rewrite some part.
+To avoid doing this, I monkey-patched some of the functions to keep the changes minimal.
+
+Note that some of them are related to sphinx internal APIs, which can be broken when sphinx got upgraded.
+Try to keep them updated, or pin to a particular sphinx version.
+"""
+
+import inspect
+import os
+from typing import List, Tuple, List
+
+import sphinx
+from docutils import nodes
+from docutils.nodes import Node
+
+
+class ClassNewBlacklistPatch:
+    """Force some classes to skip ``__new__`` when generating signature."""
+
+    original = None
+
+    def restore(self, *args, **kwargs):
+        assert self.original is not None
+        sphinx.ext.autodoc._CLASS_NEW_BLACKLIST = self.original
+
+    def patch(self, *args, **kwargs):
+        self.original = sphinx.ext.autodoc._CLASS_NEW_BLACKLIST
+
+        blacklist = []
+
+        import nni.retiarii.nn.pytorch
+        for name in dir(nni.retiarii.nn.pytorch):
+            obj = getattr(nni.retiarii.nn.pytorch, name)
+            if inspect.isclass(obj):
+                new_name = "{0.__module__}.{0.__qualname__}".format(obj.__new__)
+                if new_name not in blacklist:
+                    blacklist.append(new_name)
+
+        sphinx.ext.autodoc._CLASS_NEW_BLACKLIST = self.original + blacklist
+
+
+def disable_trace_patch(*args, **kwargs):
+    """Disable trace by setting an environment variable."""
+    os.environ['NNI_TRACE_FLAG'] = 'DISABLE'
+
+
+def trial_tool_import_patch(*args, **kwargs):
+    """Insert dummy trial tool variable to ensure trial_tool can be imported.
+    See nni/tools/trial_tool/constants.py
+    """
+    os.environ.update({
+        'NNI_OUTPUT_DIR': '/tmp',
+        'NNI_PLATFORM': 'unittest',
+        'NNI_SYS_DIR': '/tmp',
+        'NNI_TRIAL_JOB_ID': 'dummy',
+        'NNI_EXP_ID': 'dummy',
+        'MULTI_PHASE': 'dummy'
+    })
+
+
+class AutoSummaryPatch:
+    """Ignore certain files as they are completely un-importable. It patches:
+
+    - find_autosummary_in_files: Some modules cannot be imported at all due to dependency issues or some special design.
+      They need to skipped when running autosummary generate.
+    - Autosummary.get_table: The original autosummary creates an index for each module, and the module links in autosummary table
+      points to the corresponding generated module page (by using ``:py:module:xxx``). This doesn't work for us,
+      because we have used automodule else (other than autosummary) in our docs, and to avoid duplicate index,
+      we have to set ``:noindex:`` in autosummary template (see docs/templates/autosummary/module.rst).
+      This breaks most of the links, where they fail to link to generated module page by using index.
+      We here update the python domain role, to a general domain role (``:doc:``), and link to the page directly.
+    """
+
+    find_autosummary_original = None
+    get_table_original = None
+
+    def restore(self, *args, **kwargs):
+        assert self.find_autosummary_original is not None and self.get_table_original is not None
+        sphinx.ext.autosummary.generate.find_autosummary_in_files = self.find_autosummary_original
+        sphinx.ext.autosummary.Autosummary.get_table = self.get_table_original
+
+    def patch(self, app, config):
+        from sphinx.ext.autosummary import Autosummary
+        from sphinx.ext.autosummary.generate import AutosummaryEntry
+
+        self.find_autosummary_original = sphinx.ext.autosummary.generate.find_autosummary_in_files
+        self.get_table_original = Autosummary.get_table
+
+        def find_autosummary_in_files(filenames: List[str]) -> List[AutosummaryEntry]:
+            items: List[AutosummaryEntry] = self.find_autosummary_original(filenames)
+            items = [item for item in items if item.name not in config.autosummary_mock_imports]
+            return items
+
+        def get_table(autosummary, items: List[Tuple[str, str, str, str]]) -> List[Node]:
+            col_spec, autosummary_table = self.get_table_original(autosummary, items)
+            if 'toctree' in autosummary.options:
+                # probably within modules
+                table = autosummary_table[0]
+                tgroup = table[0]
+                tbody = tgroup[-1]
+                for row in tbody:
+                    entry = row[0]
+                    paragraph = entry[0]
+                    pending_xref = paragraph[0]
+
+                    # get the reference path and check whether it has been generated
+                    # if path to reference is changed, this should also be changed
+                    reftarget_path = 'reference/_modules/' + pending_xref['reftarget']
+
+                    if reftarget_path in autosummary.env.found_docs:
+                        # make :py:obj:`xxx` looks like a :doc:`xxx`
+                        pending_xref['refdomain'] = 'std'
+                        pending_xref['reftype'] = 'doc'
+                        pending_xref['refexplicit'] = False
+                        pending_xref['refwarn'] = True
+                        pending_xref['reftarget'] = '/' + reftarget_path
+                        # a special tag to enable `ResolveDocPatch`
+                        pending_xref['refkeepformat'] = True
+
+            return [col_spec, autosummary_table]
+
+        sphinx.ext.autosummary.generate.find_autosummary_in_files = find_autosummary_in_files
+        sphinx.ext.autosummary.Autosummary.get_table = get_table
+
+
+class ResolveDocPatch:
+    """Original :doc: role throws away all the format, and keep raw text only.
+    We wish to keep module names literal. This patch is to keep literal format in :doc: resolver."""
+
+    original = None
+
+    def restore(self, *args, **kwargs):
+        assert self.original is not None
+        sphinx.domains.std.StandardDomain._resolve_doc_xref = self.original
+
+    def patch(self, *args, **kwargs):
+        self.original = sphinx.domains.std.StandardDomain._resolve_doc_xref
+
+        def doc_xref_resolver(std_domain, env, fromdocname, builder, typ, target, node, contnode):
+            if not node.get('refkeepformat'):
+                # redirect to original implementation to make it safer
+                return self.original(std_domain, env, fromdocname, builder, typ, target, node, contnode)
+
+            # directly reference to document by source name; can be absolute or relative
+            from sphinx.domains.std import docname_join, make_refnode
+            refdoc = node.get('refdoc', fromdocname)
+            docname = docname_join(refdoc, node['reftarget'])
+            if docname not in env.all_docs:
+                return None
+            else:
+                innernode = node[0]  # no astext here, to keep literal intact
+                return make_refnode(builder, fromdocname, docname, None, innernode)
+
+        sphinx.domains.std.StandardDomain._resolve_doc_xref = doc_xref_resolver
+
+
+def setup(app):
+    # See life-cycle of sphinx app here:
+    # https://www.sphinx-doc.org/en/master/extdev/appapi.html#sphinx-core-events
+    patch = ClassNewBlacklistPatch()
+    app.connect('env-before-read-docs', patch.patch)
+    app.connect('env-merge-info', patch.restore)
+
+    patch = ResolveDocPatch()
+    app.connect('env-before-read-docs', patch.patch)
+    app.connect('env-merge-info', patch.restore)
+
+    app.connect('env-before-read-docs', disable_trace_patch)
+
+    # autosummary generate happens at builder-inited
+    app.connect('config-inited', trial_tool_import_patch)
+
+    autosummary_patch = AutoSummaryPatch()
+    app.connect('config-inited', autosummary_patch.patch)
+    app.connect('env-merge-info', autosummary_patch.restore)

docs/extension/toctree_check.py

+"""
+Make sure pages that contain toctree only has a toctree,
+because, if our theme is used, other contents will not be visible.
+"""
+
+import re
+
+from docutils import nodes
+from sphinx.application import Sphinx
+from sphinx.addnodes import toctree
+from sphinx.util.logging import getLogger
+
+logger = getLogger('toctree_check')
+
+def _strip_compound(node):
+    if isinstance(node, nodes.compound):
+        return _strip_compound(node[0])
+    return node
+
+
+def toctree_check(app: Sphinx, doctree: nodes.document, docname: str):
+    whitelist = app.config.toctree_check_whitelist
+
+    if docname in whitelist:
+        return
+
+    # Scan top-level nodes
+    has_toctree = False
+
+    other_types = []
+
+    for i in range(len(doctree[0])):
+        node = doctree[0][i]
+        if isinstance(_strip_compound(node), toctree):
+            has_toctree = True
+        elif isinstance(_strip_compound(node), nodes.title):
+            # Allow title
+            pass
+        else:
+            other_types.append(type(_strip_compound(node)))
+
+    if has_toctree and other_types:
+        # We don't allow a document with toctree to have other types of contents
+        logger.warning('Expect a toctree document to contain only a toctree, '
+                       'but found other types of contents: %s', str(set(other_types)),
+                       location=docname)
+
+
+def setup(app):
+    app.connect('doctree-resolved', toctree_check)
+
+    app.add_config_value('toctree_check_whitelist', [], True)

docs/extension/tutorial_links.py

+"""Creating hard links for tutorials in each individual topics."""
+
+import os
+import re
+
+HEADER = """.. THIS FILE IS A COPY OF {} WITH MODIFICATIONS.
+.. TO MAKE ONE TUTORIAL APPEAR IN MULTIPLE PLACES.
+
+"""
+
+def flatten_filename(filename):
+    return filename.replace('/', '_').replace('.', '_')
+
+def copy_tutorials(app):
+    # TODO: use sphinx logger
+    print('[tutorial links] copy tutorials...')
+    for src, tar in app.config.tutorials_copy_list:
+        target_path = os.path.join(app.srcdir, tar)
+        content = open(os.path.join(app.srcdir, src)).read()
+
+        # Add a header
+        content = HEADER.format(src) + content
+
+        # Add a prefix to labels to avoid duplicates.
+        label_map = {}
+
+        # find all anchors:   https://www.sphinx-doc.org/en/master/usage/restructuredtext/roles.html
+        # but not hyperlinks: https://www.sphinx-doc.org/en/master/usage/restructuredtext/basics.html#external-links
+        for prefix, label_name in list(re.findall(r'(\.\.\s*_)(.*?)\:\s*\n', content)):
+            label_map[label_name] = flatten_filename(tar) + '_' + label_name
+            # anchor
+            content = content.replace(prefix + label_name + ':', prefix + label_map[label_name] + ':')
+            # :ref:`xxx`
+            content = content.replace(f':ref:`{label_name}`', f':ref:`{label_map[label_name]}')
+            # :ref:`yyy <xxx>`
+            content = re.sub(r"(\:ref\:`.*?\<)" + label_name + r"(\>`)", r'\1' + label_map[label_name] + r'\2', content)
+
+        open(target_path, 'w').write(content)
+
+
+def setup(app):
+    # See life-cycle of sphinx app here:
+    # https://www.sphinx-doc.org/en/master/extdev/appapi.html#sphinx-core-events
+    app.connect('builder-inited', copy_tutorials)
+    app.add_config_value('tutorials_copy_list', [], True, [list])

docs/img/NAS_Bench_201.svg

+<svg id="SvgjsSvg1006" width="709" height="537.0000305175781" xmlns="http://www.w3.org/2000/svg" version="1.1" xmlns:xlink="http://www.w3.org/1999/xlink" xmlns:svgjs="http://svgjs.com/svgjs"><defs id="SvgjsDefs1007"><marker id="SvgjsMarker1034" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1035" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1038" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1039" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1042" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1043" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1046" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1047" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1050" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1051" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1054" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1055" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1080" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1081" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker></defs><g id="SvgjsG1008" transform="translate(25,24.999980449676514)"><path id="SvgjsPath1009" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc00"></path><g id="SvgjsG1010"><text id="SvgjsText1011" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1012" dy="16" x="35"><tspan id="SvgjsTspan1013" style="text-decoration:;">input</tspan></tspan></text></g></g><g id="SvgjsG1014" transform="translate(267,140.9999804496765)"><path id="SvgjsPath1015" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1016"><text id="SvgjsText1017" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1018" dy="16" x="35"><tspan id="SvgjsTspan1019" style="text-decoration:;">node 1</tspan></tspan></text></g></g><g id="SvgjsG1020" transform="translate(25,293.9999804496765)"><path id="SvgjsPath1021" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1022"><text id="SvgjsText1023" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1024" dy="16" x="35"><tspan id="SvgjsTspan1025" style="text-decoration:;">node 2</tspan></tspan></text></g></g><g id="SvgjsG1026" transform="translate(267,441.9999804496765)"><path id="SvgjsPath1027" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1028"><text id="SvgjsText1029" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1030" dy="16" x="35"><tspan id="SvgjsTspan1031" style="text-decoration:;">node 3</tspan></tspan></text></g></g><g id="SvgjsG1032"><path id="SvgjsPath1033" d="M60 94.99998044967651C 45 172.86665678024292 44 214.86665678024292 60 293.9999804496765" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1034)"></path></g><g id="SvgjsG1036"><path id="SvgjsPath1037" d="M60 94.99998044967651C 74.7485647305657 263.5768467107039 316.7485647305658 273.42311418864915 302 441.9999804496765" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1038)"></path></g><g id="SvgjsG1040"><path id="SvgjsPath1041" d="M302 210.9999804496765C 310.0531906298836 303.04837055335383 310.0531906298836 349.9515903459992 302 441.9999804496765" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1042)"></path></g><g id="SvgjsG1044"><path id="SvgjsPath1045" d="M60 363.9999804496765C 68.86407754147842 465.3168503645069 310.8640775414784 340.68311053484615 302 441.9999804496765" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1046)"></path></g><g id="SvgjsG1048"><path id="SvgjsPath1049" d="M60 94.99998044967651C 68.58773798957196 193.15827483289445 310.587737989572 42.841686066458635 302 140.9999804496765" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1050)"></path></g><g id="SvgjsG1052"><path id="SvgjsPath1053" d="M302 210.9999804496765C 310.9190947616536 312.94570006866127 68.91909476165358 192.05426083069176 60 293.9999804496765" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1054)"></path></g><g id="SvgjsG1056" transform="translate(382,279.8666567802429)"><path id="SvgjsPath1057" d="M 0 26C 0 -8.666666666666666 52 -8.666666666666666 52 26C 52 60.666666666666664 0 60.666666666666664 0 26Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1058"><text id="SvgjsText1059" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="32px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="16.55" transform="rotate(0)"></text></g></g><g id="SvgjsG1060" transform="translate(455,295.8666567802429)"><path id="SvgjsPath1061" d="M 0 0L 220 0L 220 20L 0 20Z" stroke="none" fill="none"></path><g id="SvgjsG1062"><text id="SvgjsText1063" font-family="微软雅黑" text-anchor="start" font-size="13px" width="220px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-7.45" transform="rotate(0)"><tspan id="SvgjsTspan1064" dy="16" x="0"><tspan id="SvgjsTspan1065" style="text-decoration:;">choose none/one/multiple input(s) </tspan></tspan><tspan id="SvgjsTspan1066" dy="16" x="0"><tspan id="SvgjsTspan1067" style="text-decoration:;">then add them as output</tspan></tspan></text></g></g><g id="SvgjsG1068" transform="translate(382,210.9999804496765)"><path id="SvgjsPath1069" d="M 0 26C 0 -8.666666666666666 52 -8.666666666666666 52 26C 52 60.666666666666664 0 60.666666666666664 0 26Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc00"></path><g id="SvgjsG1070"><text id="SvgjsText1071" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="32px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="16.55" transform="rotate(0)"></text></g></g><g id="SvgjsG1072" transform="translate(455,226.9999804496765)"><path id="SvgjsPath1073" d="M 0 0L 220 0L 220 20L 0 20Z" stroke="none" fill="none"></path><g id="SvgjsG1074"><text id="SvgjsText1075" font-family="微软雅黑" text-anchor="start" font-size="13px" width="220px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="0.55" transform="rotate(0)"><tspan id="SvgjsTspan1076" dy="16" x="0"><tspan id="SvgjsTspan1077" style="text-decoration:;">the output of the previous cell</tspan></tspan></text></g></g><g id="SvgjsG1078"><path id="SvgjsPath1079" d="M376 374.8666567802429L404.5 374.8666567802429L404.5 374.8666567802429L433 374.8666567802429" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1080)"></path></g><g id="SvgjsG1082" transform="translate(463,363.9999804496765)"><path id="SvgjsPath1083" d="M 0 0L 220 0L 220 20L 0 20Z" stroke="none" fill="none"></path><g id="SvgjsG1084"><text id="SvgjsText1085" font-family="微软雅黑" text-anchor="start" font-size="13px" width="220px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-14.95" transform="rotate(0)"><tspan id="SvgjsTspan1086" dy="16" x="0"><tspan id="SvgjsTspan1087" style="text-decoration:;">choose one operation from </tspan></tspan><tspan id="SvgjsTspan1088" dy="16" x="0"><tspan id="SvgjsTspan1089" style="text-decoration:;">MaxPool, AvgPool,, Conv1x1, </tspan></tspan><tspan id="SvgjsTspan1090" dy="16" x="0"><tspan id="SvgjsTspan1091" style="text-decoration:;">Conv3x3, SkipConnect, Zeroize</tspan></tspan></text></g></g></svg>
\ No newline at end of file

docs/img/NAS_Darts_cell.svg

+<svg id="SvgjsSvg1006" width="825.4666442871094" height="869.1333465576172" xmlns="http://www.w3.org/2000/svg" version="1.1" xmlns:xlink="http://www.w3.org/1999/xlink" xmlns:svgjs="http://svgjs.com/svgjs"><defs id="SvgjsDefs1007"><marker id="SvgjsMarker1046" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1047" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1050" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1051" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1054" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1055" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1058" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1059" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1062" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1063" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1066" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1067" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1070" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1071" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1074" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1075" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1078" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1079" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1082" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1083" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1086" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1087" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1090" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1091" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1094" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1095" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1098" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1099" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1108" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1109" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1112" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1113" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1116" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1117" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1120" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1121" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1134" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1135" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1170" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1171" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker></defs><g id="SvgjsG1008" transform="translate(102.03997802734375,25.008010864257812)"><path id="SvgjsPath1009" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc66"></path><g id="SvgjsG1010"><text id="SvgjsText1011" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1012" dy="16" x="35"><tspan id="SvgjsTspan1013" style="text-decoration:;">input 0</tspan></tspan></text></g></g><g id="SvgjsG1014" transform="translate(346.03997802734375,91.00801086425781)"><path id="SvgjsPath1015" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc66"></path><g id="SvgjsG1016"><text id="SvgjsText1017" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1018" dy="16" x="35"><tspan id="SvgjsTspan1019" style="text-decoration:;">input 1</tspan></tspan></text></g></g><g id="SvgjsG1020" transform="translate(102.03997802734375,247.0080108642578)"><path id="SvgjsPath1021" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1022"><text id="SvgjsText1023" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1024" dy="16" x="35"><tspan id="SvgjsTspan1025" style="text-decoration:;">node 0</tspan></tspan></text></g></g><g id="SvgjsG1026" transform="translate(346.03997802734375,386.24000549316406)"><path id="SvgjsPath1027" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff33"></path><g id="SvgjsG1028"><text id="SvgjsText1029" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1030" dy="16" x="35"><tspan id="SvgjsTspan1031" style="text-decoration:;">node 1</tspan></tspan></text></g></g><g id="SvgjsG1032" transform="translate(102.03997802734375,503.24000549316406)"><path id="SvgjsPath1033" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff33"></path><g id="SvgjsG1034"><text id="SvgjsText1035" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1036" dy="16" x="35"><tspan id="SvgjsTspan1037" style="text-decoration:;">node 2</tspan></tspan></text></g></g><g id="SvgjsG1038" transform="translate(346.03997802734375,660.2400054931641)"><path id="SvgjsPath1039" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff33"></path><g id="SvgjsG1040"><text id="SvgjsText1041" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1042" dy="16" x="35"><tspan id="SvgjsTspan1043" style="text-decoration:;">node 3</tspan></tspan></text></g></g><g id="SvgjsG1044"><path id="SvgjsPath1045" d="M137.03997802734375 95.00801086425781C 142.3390471864014 155.57664850823596 142.3390471864014 186.43937322027966 137.03997802734375 247.0080108642578" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1046)"></path></g><g id="SvgjsG1048"><path id="SvgjsPath1049" d="M137.03997802734375 95.00801086425781C 150.28545233965042 246.404475028805 394.2854523396504 234.84354132861688 381.03997802734375 386.24000549316406" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1050)"></path></g><g id="SvgjsG1052"><path id="SvgjsPath1053" d="M381.03997802734375 161.0080108642578C 388.89208274031125 250.75797842023576 388.89208274031137 296.4900379371861 381.03997802734375 386.24000549316406" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1054)"></path></g><g id="SvgjsG1056"><path id="SvgjsPath1057" d="M381.03997802734375 161.0080108642578C 390.059279443249 264.0990977824248 146.05927944324907 143.91692394609086 137.03997802734375 247.0080108642578" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1058)"></path></g><g id="SvgjsG1060"><path id="SvgjsPath1061" d="M137.03997802734375 317.0080108642578C 143.53245315344782 391.21734113000457 143.53245315344788 429.0306752274173 137.03997802734375 503.24000549316406" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1062)"></path></g><g id="SvgjsG1064"><path id="SvgjsPath1065" d="M137.03997802734375 317.0080108642578C 145.8821637569588 418.0746562244878 389.8821637569588 285.1733601329341 381.03997802734375 386.24000549316406" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1066)"></path></g><g id="SvgjsG1068"><path id="SvgjsPath1069" d="M137.03997802734375 573.2400054931641C 146.07092807311756 676.4642368599839 390.07092807311756 557.0157741263442 381.03997802734375 660.2400054931641" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1070)"></path></g><g id="SvgjsG1072"><path id="SvgjsPath1073" d="M381.03997802734375 456.24000549316406C 388.1518866355526 537.5294928574505 388.1518866355527 578.9505181288777 381.03997802734375 660.2400054931641" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1074)"></path></g><g id="SvgjsG1076"><path id="SvgjsPath1077" d="M137.03997802734375 317.0080108642578C 151.72127748132198 484.81603149573016 395.721277481322 492.4319848616917 381.03997802734375 660.2400054931641" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1078)"></path></g><g id="SvgjsG1080"><path id="SvgjsPath1081" d="M381.03997802734375 456.24000549316406C 389.70275028689764 555.2559455067756 145.7027502868977 404.22406547955256 137.03997802734375 503.24000549316406" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1082)"></path></g><g id="SvgjsG1084"><path id="SvgjsPath1085" d="M381.03997802734375 161.0080108642578C 395.6928772148526 328.491414964573 151.69287721485261 335.7566013928489 137.03997802734375 503.24000549316406" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1086)"></path></g><g id="SvgjsG1088"><path id="SvgjsPath1089" d="M137.03997802734375 95.00801086425781C 24.999984741210938 260.9920015335083 77.99998474121094 362.9920015335083 137.03997802734375 503.24000549316406" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1090)"></path></g><g id="SvgjsG1092"><path id="SvgjsPath1093" d="M137.03997802734375 95.00801086425781C 158.5029026859753 340.33036228264245 402.5029026859754 414.9176540747794 381.03997802734375 660.2400054931641" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1094)"></path></g><g id="SvgjsG1096"><path id="SvgjsPath1097" d="M381.03997802734375 161.0080108642578C 474.99998474121094 357.7520065307617 436.99998474121094 463.7520065307617 381.03997802734375 660.2400054931641" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1098)"></path></g><g id="SvgjsG1100" transform="translate(213.99998474121094,774.1439895629883)"><path id="SvgjsPath1101" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#cc99ff"></path><g id="SvgjsG1102"><text id="SvgjsText1103" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1104" dy="16" x="35"><tspan id="SvgjsTspan1105" style="text-decoration:;">output</tspan></tspan></text></g></g><g id="SvgjsG1106"><path id="SvgjsPath1107" d="M137.03997802734375 317.0080108642578C 153.44780421895462 504.5503224089872 265.40781093282186 586.6016780182589 248.99998474121094 774.1439895629883" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1108)"></path></g><g id="SvgjsG1110"><path id="SvgjsPath1111" d="M137.03997802734375 573.2400054931641C 145.05811339639388 664.8877121320274 257.01812011026107 682.4962829241249 248.99998474121094 774.1439895629883" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1112)"></path></g><g id="SvgjsG1114"><path id="SvgjsPath1115" d="M381.03997802734375 456.24000549316406C 393.0407891056441 593.409903793695 261.0007958195113 636.9740912624574 248.99998474121094 774.1439895629883" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1116)"></path></g><g id="SvgjsG1118"><path id="SvgjsPath1119" d="M381.03997802734375 730.2400054931641C 385.89099114909015 785.6873391961069 253.85099786295734 718.6966558600454 248.99998474121094 774.1439895629883" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1120)"></path></g><g id="SvgjsG1122" transform="translate(543.471981048584,627.2400054931641)"><path id="SvgjsPath1123" d="M 0 0L 255 0L 255 33L 0 33Z" stroke="none" fill="none"></path><g id="SvgjsG1124"><text id="SvgjsText1125" font-family="微软雅黑" text-anchor="start" font-size="13px" width="255px" fill="#323232" font-weight="400" align="top" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-1.95" transform="rotate(0)"><tspan id="SvgjsTspan1126" dy="16" x="0"><tspan id="SvgjsTspan1127" style="text-decoration:;">choose an operation from AvgPool, </tspan></tspan><tspan id="SvgjsTspan1128" dy="16" x="0"><tspan id="SvgjsTspan1129" style="text-decoration:;">MaxPool, 3x3 SepConv, 5x5SepConv, </tspan></tspan><tspan id="SvgjsTspan1130" dy="16" x="0"><tspan id="SvgjsTspan1131" style="text-decoration:;">3x3DilConv, 5x5DilConv, SkipConnect</tspan></tspan></text></g></g><g id="SvgjsG1132"><path id="SvgjsPath1133" d="M473.471981048584 655.6359786987305L523.471981048584 655.6359786987305" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1134)"></path></g><g id="SvgjsG1136" transform="translate(484.471981048584,682.1359786987305)"><path id="SvgjsPath1137" d="M 0 13.104026794433594C 0 -4.368008931477864 29 -4.368008931477864 29 13.104026794433594C 29 30.57606252034505 0 30.57606252034505 0 13.104026794433594Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc00"></path><g id="SvgjsG1138"><text id="SvgjsText1139" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="9px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="3.6540267944335936" transform="rotate(0)"></text></g></g><g id="SvgjsG1140" transform="translate(484.471981048584,720.2400054931641)"><path id="SvgjsPath1141" d="M 0 13.104026794433594C 0 -4.368008931477864 29 -4.368008931477864 29 13.104026794433594C 29 30.57606252034505 0 30.57606252034505 0 13.104026794433594Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1142"><text id="SvgjsText1143" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="9px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="3.6540267944335936" transform="rotate(0)"></text></g></g><g id="SvgjsG1144" transform="translate(484.471981048584,760.2400054931641)"><path id="SvgjsPath1145" d="M 0 13.104026794433594C 0 -4.368008931477864 29 -4.368008931477864 29 13.104026794433594C 29 30.57606252034505 0 30.57606252034505 0 13.104026794433594Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#cc99ff"></path><g id="SvgjsG1146"><text id="SvgjsText1147" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="9px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="3.6540267944335936" transform="rotate(0)"></text></g></g><g id="SvgjsG1148" transform="translate(544.471981048584,684.4480590820312)"><path id="SvgjsPath1149" d="M 0 0L 232 0L 232 35.79194641113281L 0 35.79194641113281Z" stroke="none" fill="none"></path><g id="SvgjsG1150"><text id="SvgjsText1151" font-family="微软雅黑" text-anchor="start" font-size="13px" width="232px" fill="#323232" font-weight="400" align="top" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-1.95" transform="rotate(0)"><tspan id="SvgjsTspan1152" dy="16" x="0"><tspan id="SvgjsTspan1153" style="text-decoration:;">results of previous layers as input</tspan></tspan></text></g></g><g id="SvgjsG1154" transform="translate(544.471981048584,720.2400054931641)"><path id="SvgjsPath1155" d="M 0 0L 251 0L 251 37.79194641113281L 0 37.79194641113281Z" stroke="none" fill="none"></path><g id="SvgjsG1156"><text id="SvgjsText1157" font-family="微软雅黑" text-anchor="start" font-size="13px" width="251px" fill="#323232" font-weight="400" align="top" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-1.95" transform="rotate(0)"><tspan id="SvgjsTspan1158" dy="16" x="0"><tspan id="SvgjsTspan1159" style="text-decoration:;">accept two operations from all inputs, </tspan></tspan><tspan id="SvgjsTspan1160" dy="16" x="0"><tspan id="SvgjsTspan1161" style="text-decoration:;">then add the results as output</tspan></tspan></text></g></g><g id="SvgjsG1162" transform="translate(545.471981048584,763.2400054931641)"><path id="SvgjsPath1163" d="M 0 0L 251 0L 251 37.79194641113281L 0 37.79194641113281Z" stroke="none" fill="none"></path><g id="SvgjsG1164"><text id="SvgjsText1165" font-family="微软雅黑" text-anchor="start" font-size="13px" width="251px" fill="#323232" font-weight="400" align="top" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-1.95" transform="rotate(0)"><tspan id="SvgjsTspan1166" dy="16" x="0"><tspan id="SvgjsTspan1167" style="text-decoration:;">concat all inputs in channels</tspan></tspan></text></g></g><g id="SvgjsG1168"><path id="SvgjsPath1169" d="M472.471981048584 599.6359786987305L522.471981048584 599.6359786987305" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1170)"></path></g><g id="SvgjsG1172" transform="translate(545.471981048584,586.1359786987305)"><path id="SvgjsPath1173" d="M 0 0L 255 0L 255 33L 0 33Z" stroke="none" fill="none"></path><g id="SvgjsG1174"><text id="SvgjsText1175" font-family="微软雅黑" text-anchor="start" font-size="13px" width="255px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-0.95" transform="rotate(0)"><tspan id="SvgjsTspan1176" dy="16" x="0"><tspan id="SvgjsTspan1177" style="text-decoration:;">pass the result directly to the output </tspan></tspan><tspan id="SvgjsTspan1178" dy="16" x="0"><tspan id="SvgjsTspan1179" style="text-decoration:;">node</tspan></tspan></text></g></g></svg>
\ No newline at end of file

docs/img/NAS_ENAS_macro.svg

+<svg id="SvgjsSvg1006" width="837.0800476074219" height="917.6933898925781" xmlns="http://www.w3.org/2000/svg" version="1.1" xmlns:xlink="http://www.w3.org/1999/xlink" xmlns:svgjs="http://svgjs.com/svgjs"><defs id="SvgjsDefs1007"><marker id="SvgjsMarker1022" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1023" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1036" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1037" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1040" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1041" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1044" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1045" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1053" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1054" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1089" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1090" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1141" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1142" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1145" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1146" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1149" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1150" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1153" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1154" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1157" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1158" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1161" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1162" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1165" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1166" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1169" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1170" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1173" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1174" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1177" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1178" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1181" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1182" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1191" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1192" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1205" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1206" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1225" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1226" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1237" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1238" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1241" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1242" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker></defs><g id="SvgjsG1008" transform="translate(74.002685546875,148.85643214220443)"><path id="SvgjsPath1009" d="M 0 133.86033519553072C 0 -44.62011173184357 267.72067039106145 -44.62011173184357 267.72067039106145 133.86033519553072C 267.72067039106145 312.340782122905 0 312.340782122905 0 133.86033519553072Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffffff"></path><g id="SvgjsG1010"><text id="SvgjsText1011" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="248px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="124.41033519553072" transform="rotate(0)"></text></g></g><g id="SvgjsG1012" transform="translate(131.37140063067386,187.10224219807034)"><path id="SvgjsPath1013" d="M 0 31.871508379888265C 0 -10.623836126629422 63.74301675977653 -10.623836126629422 63.74301675977653 31.871508379888265C 63.74301675977653 74.36685288640595 0 74.36685288640595 0 31.871508379888265Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1014"><text id="SvgjsText1015" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="44px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="22.421508379888266" transform="rotate(0)"></text></g></g><g id="SvgjsG1016" transform="translate(209.68424979268502,311.8564321422044)"><path id="SvgjsPath1017" d="M 0 31.871508379888265C 0 -10.623836126629422 63.74301675977653 -10.623836126629422 63.74301675977653 31.871508379888265C 63.74301675977653 74.36685288640595 0 74.36685288640595 0 31.871508379888265Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#cc99ff"></path><g id="SvgjsG1018"><text id="SvgjsText1019" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="44px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="22.421508379888266" transform="rotate(0)"></text></g></g><g id="SvgjsG1020"><path id="SvgjsPath1021" d="M109.51665202732192 96.04078968410386C 131.00715482061798 132.46537068969045 142.81869506835938 152.7813491821289 163.24290901056213 187.10224219807034" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1022)"></path></g><g id="SvgjsG1024" transform="translate(301.6563168317912,25.923471248349685)"><path id="SvgjsPath1025" d="M 0 35.05865921787709C 0 -11.686219739292364 70.11731843575419 -11.686219739292364 70.11731843575419 35.05865921787709C 70.11731843575419 81.80353817504655 0 81.80353817504655 0 35.05865921787709Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc66"></path><g id="SvgjsG1026"><text id="SvgjsText1027" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="51px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="10.108659217877094" transform="rotate(0)"><tspan id="SvgjsTspan1028" dy="16" x="35.5"><tspan id="SvgjsTspan1029" style="text-decoration:;">Layer </tspan></tspan><tspan id="SvgjsTspan1030" dy="16" x="35.5"><tspan id="SvgjsTspan1031" style="text-decoration:;">N-1's</tspan></tspan><tspan id="SvgjsTspan1032" dy="16" x="35.5"><tspan id="SvgjsTspan1033" style="text-decoration:;">output</tspan></tspan></text></g></g><g id="SvgjsG1034"><path id="SvgjsPath1035" d="M336.7149760496683 96.04078968410386C 344.9377251996825 190.02724254125366 249.77850732258764 217.86997928505463 241.5557581725733 311.8564321422044" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1036)"></path></g><g id="SvgjsG1038"><path id="SvgjsPath1039" d="M132.28201515581355 94.21956063382453C 144.66637269771297 131.37263325952284 152.81869506835938 149.7813491821289 163.24290901056213 187.10224219807034" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1040)"></path></g><g id="SvgjsG1042"><path id="SvgjsPath1043" d="M163.24290901056213 93.30894610868489C 163.24290901056213 130.82626454443908 166.51275876473073 149.7276884857523 163.24290901056213 187.10224219807034" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1044)"></path></g><g id="SvgjsG1046" transform="matrix(6.123233995736766e-17,1,-1,6.123233995736766e-17,175.99151428052167,25.012857064188523)"><path id="SvgjsPath1047" d="M 61.9217877094972 0Q 55.729608938547486 0 55.729608938547486 6.73854748603352L 55.729608938547486 26.95418994413408Q 55.729608938547486 33.6927374301676 39.9217877094972 33.6927374301676Q 55.729608938547486 33.6927374301676 55.729608938547486 40.431284916201115L 55.729608938547486 60.646927374301676Q 55.729608938547486 67.3854748603352 61.9217877094972 67.3854748603352" stroke="rgba(50,50,50,1)" stroke-width="2" fill="none"></path><path id="SvgjsPath1048" d="M 0 0L 61.9217877094972 0L 61.9217877094972 67.3854748603352L 0 67.3854748603352Z" stroke="none" fill="none"></path><g id="SvgjsG1049"><text id="SvgjsText1050" font-family="微软雅黑" text-anchor="end" font-size="13px" width="35px" fill="#323232" font-weight="400" align="middle" anchor="end" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="24.242737430167598" transform="rotate(0)"></text></g></g><g id="SvgjsG1051"><path id="SvgjsPath1052" d="M427.321121301065 258.1301751589642L472.8518475580481 258.1301751589642" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1053)"></path></g><g id="SvgjsG1055" transform="translate(489.24290901056213,239.00727013103125)"><path id="SvgjsPath1056" d="M 0 0L 236.75977653631284 0L 236.75977653631284 46.44134078212291L 0 46.44134078212291Z" stroke="none" fill="none"></path><g id="SvgjsG1057"><text id="SvgjsText1058" font-family="微软雅黑" text-anchor="start" font-size="13px" width="237px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-1.7293296089385464" transform="rotate(0)"><tspan id="SvgjsTspan1059" dy="16" x="0"><tspan id="SvgjsTspan1060" style="text-decoration:;">choose an operation from: MaxPool, </tspan></tspan><tspan id="SvgjsTspan1061" dy="16" x="0"><tspan id="SvgjsTspan1062" style="text-decoration:;">AvgPool, SepConvBN3x3, SepConvBN</tspan></tspan><tspan id="SvgjsTspan1063" dy="16" x="0"><tspan id="SvgjsTspan1064" style="text-decoration:;">5x5 and SkipConnect</tspan></tspan></text></g></g><g id="SvgjsG1065" transform="translate(424.58927772564596,293.6441416394111)"><path id="SvgjsPath1066" d="M 0 25.952513966480446C 0 -8.650837988826815 51.90502793296089 -8.650837988826815 51.90502793296089 25.952513966480446C 51.90502793296089 60.555865921787706 0 60.555865921787706 0 25.952513966480446Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1067"><text id="SvgjsText1068" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="32px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="16.502513966480446" transform="rotate(0)"></text></g></g><g id="SvgjsG1069" transform="translate(489.24290901056213,301.3843651030983)"><path id="SvgjsPath1070" d="M 0 0L 236.75977653631284 0L 236.75977653631284 36.42458100558659L 0 36.42458100558659Z" stroke="none" fill="none"></path><g id="SvgjsG1071"><text id="SvgjsText1072" font-family="微软雅黑" text-anchor="start" font-size="13px" width="237px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="8.762290502793295" transform="rotate(0)"><tspan id="SvgjsTspan1073" dy="16" x="0"><tspan id="SvgjsTspan1074" style="text-decoration:;">accept none/one/multiple input(s)</tspan></tspan></text></g></g><g id="SvgjsG1075" transform="translate(425.9551995133554,367.40391817572396)"><path id="SvgjsPath1076" d="M 0 24.58659217877095C 0 -8.195530726256983 49.1731843575419 -8.195530726256983 49.1731843575419 24.58659217877095C 49.1731843575419 57.36871508379888 0 57.36871508379888 0 24.58659217877095Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#cc99ff"></path><g id="SvgjsG1077"><text id="SvgjsText1078" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="30px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="15.13659217877095" transform="rotate(0)"></text></g></g><g id="SvgjsG1079" transform="translate(489.24290901056213,373.7782198517016)"><path id="SvgjsPath1080" d="M 0 0L 236.75977653631284 0L 236.75977653631284 36.42458100558659L 0 36.42458100558659Z" stroke="none" fill="none"></path><g id="SvgjsG1081"><text id="SvgjsText1082" font-family="微软雅黑" text-anchor="start" font-size="13px" width="237px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="0.7622905027932945" transform="rotate(0)"><tspan id="SvgjsTspan1083" dy="16" x="0"><tspan id="SvgjsTspan1084" style="text-decoration:;">add all input as the output of this </tspan></tspan><tspan id="SvgjsTspan1085" dy="16" x="0"><tspan id="SvgjsTspan1086" style="text-decoration:;">layer</tspan></tspan></text></g></g><g id="SvgjsG1087"><path id="SvgjsPath1088" d="M426.41050677592534 208.04637627628261L471.9412330329085 208.04637627628261" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1089)"></path></g><g id="SvgjsG1091" transform="translate(489.24290901056213,184.37039862265135)"><path id="SvgjsPath1092" d="M 0 0L 205.79888268156424 0L 205.79888268156424 43.70949720670391L 0 43.70949720670391Z" stroke="none" fill="none"></path><g id="SvgjsG1093"><text id="SvgjsText1094" font-family="微软雅黑" text-anchor="start" font-size="13px" width="206px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="4.404748603351954" transform="rotate(0)"><tspan id="SvgjsTspan1095" dy="16" x="0"><tspan id="SvgjsTspan1096" style="text-decoration:;">(suppose this layer is the Nth </tspan></tspan><tspan id="SvgjsTspan1097" dy="16" x="0"><tspan id="SvgjsTspan1098" style="text-decoration:;">layer) outputs of all N-2 layers</tspan></tspan></text></g></g><g id="SvgjsG1099" transform="translate(100.41050677592528,33.208387449467)"><path id="SvgjsPath1100" d="M 0 0L 109.27374301675977 0L 109.27374301675977 36.42458100558659L 0 36.42458100558659Z" stroke="none" fill="none"></path><g id="SvgjsG1101"><text id="SvgjsText1102" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="110px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="8.762290502793295" transform="rotate(0)"><tspan id="SvgjsTspan1103" dy="16" x="55"><tspan id="SvgjsTspan1104" style="text-decoration:;">x (N-2)</tspan></tspan></text></g></g><g id="SvgjsG1105" transform="translate(150.49430565860683,439.196758792387)"><path id="SvgjsPath1106" d="M 0 0L 109.27374301675977 0L 109.27374301675977 36.42458100558659L 0 36.42458100558659Z" stroke="none" fill="none"></path><g id="SvgjsG1107"><text id="SvgjsText1108" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="110px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="8.762290502793295" transform="rotate(0)"><tspan id="SvgjsTspan1109" dy="16" x="55"><tspan id="SvgjsTspan1110" style="text-decoration:;">ENASMacroLayer</tspan></tspan></text></g></g><g id="SvgjsG1111" transform="translate(25.002685546875,608.5613342285156)"><path id="SvgjsPath1112" d="M 0 0L 67 0L 67 46.9L 0 46.9Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc66"></path><g id="SvgjsG1113"><text id="SvgjsText1114" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="47px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="14" transform="rotate(0)"><tspan id="SvgjsTspan1115" dy="16" x="33.5"><tspan id="SvgjsTspan1116" style="text-decoration:;">input</tspan></tspan></text></g></g><g id="SvgjsG1117" transform="translate(145.49430565860683,601.7863342285157)"><path id="SvgjsPath1118" d="M 0 29.224999999999966C 0 -9.741666666666655 59.84357541899442 -9.741666666666655 59.84357541899442 29.224999999999966C 59.84357541899442 68.19166666666659 0 68.19166666666659 0 29.224999999999966Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00ffff"></path><g id="SvgjsG1119"><text id="SvgjsText1120" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="40px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="19.774999999999967" transform="rotate(0)"></text></g></g><g id="SvgjsG1121" transform="translate(264.49430565860683,602.7863342285157)"><path id="SvgjsPath1122" d="M 0 29.224999999999966C 0 -9.741666666666655 59.84357541899442 -9.741666666666655 59.84357541899442 29.224999999999966C 59.84357541899442 68.19166666666659 0 68.19166666666659 0 29.224999999999966Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00ffff"></path><g id="SvgjsG1123"><text id="SvgjsText1124" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="40px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="19.774999999999967" transform="rotate(0)"></text></g></g><g id="SvgjsG1125" transform="translate(384.87978051894197,602.7863342285157)"><path id="SvgjsPath1126" d="M 0 29.224999999999966C 0 -9.741666666666655 59.84357541899442 -9.741666666666655 59.84357541899442 29.224999999999966C 59.84357541899442 68.19166666666659 0 68.19166666666659 0 29.224999999999966Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00ffff"></path><g id="SvgjsG1127"><text id="SvgjsText1128" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="40px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="19.774999999999967" transform="rotate(0)"></text></g></g><g id="SvgjsG1129" transform="translate(504.87978051894197,603.7863342285157)"><path id="SvgjsPath1130" d="M 0 29.224999999999966C 0 -9.741666666666655 59.84357541899442 -9.741666666666655 59.84357541899442 29.224999999999966C 59.84357541899442 68.19166666666659 0 68.19166666666659 0 29.224999999999966Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00ffff"></path><g id="SvgjsG1131"><text id="SvgjsText1132" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="40px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="19.774999999999967" transform="rotate(0)"></text></g></g><g id="SvgjsG1133" transform="translate(621.002685546875,610.5613342285156)"><path id="SvgjsPath1134" d="M 0 0L 83 0L 83 44.899999999999864L 0 44.899999999999864Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#cc99ff"></path><g id="SvgjsG1135"><text id="SvgjsText1136" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="63px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="12.999999999999932" transform="rotate(0)"><tspan id="SvgjsTspan1137" dy="16" x="41.5"><tspan id="SvgjsTspan1138" style="text-decoration:;">softmax</tspan></tspan></text></g></g><g id="SvgjsG1139"><path id="SvgjsPath1140" d="M92.002685546875 632.0113342285157L145.49430565860683 631.0113342285156" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1141)"></path></g><g id="SvgjsG1143"><path id="SvgjsPath1144" d="M205.33788107760125 631.0113342285156L264.49430565860683 632.0113342285156" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1145)"></path></g><g id="SvgjsG1147"><path id="SvgjsPath1148" d="M324.3378810776012 632.0113342285156L384.87978051894197 632.0113342285156" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1149)"></path></g><g id="SvgjsG1151"><path id="SvgjsPath1152" d="M444.7233559379365 632.0113342285156L504.87978051894197 633.0113342285156" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1153)"></path></g><g id="SvgjsG1155"><path id="SvgjsPath1156" d="M564.7233559379364 633.0113342285156L621.002685546875 633.0113342285156" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1157)"></path></g><g id="SvgjsG1159"><path id="SvgjsPath1160" d="M205.33788107760125 631.0113342285156C 232.002685546875 616.6213397979736 235.002685546875 606.6213397979736 264.49430565860683 632.0113342285156" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1161)"></path></g><g id="SvgjsG1163"><path id="SvgjsPath1164" d="M205.33788107760125 631.0113342285156C 272.002685546875 564.6213397979736 290.002685546875 572.6213397979736 384.87978051894197 632.0113342285156" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1165)"></path></g><g id="SvgjsG1167"><path id="SvgjsPath1168" d="M205.33788107760125 631.0113342285156C 285.002685546875 531.6213397979736 416.002685546875 545.6213397979736 504.87978051894197 633.0113342285156" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1169)"></path></g><g id="SvgjsG1171"><path id="SvgjsPath1172" d="M324.3378810776012 632.0113342285156C 353.002685546875 653.6213397979736 361.002685546875 652.6213397979736 384.87978051894197 632.0113342285156" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1173)"></path></g><g id="SvgjsG1175"><path id="SvgjsPath1176" d="M324.3378810776012 632.0113342285156C 393.002685546875 696.6213397979736 435.002685546875 690.6213397979736 504.87978051894197 633.0113342285156" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1177)"></path></g><g id="SvgjsG1179"><path id="SvgjsPath1180" d="M444.7233559379365 632.0113342285156C 465.002685546875 613.6213397979736 475.002685546875 615.6213397979736 504.87978051894197 633.0113342285156" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1181)"></path></g><g id="SvgjsG1183" transform="translate(254.42726655246156,734.6213397979736)"><path id="SvgjsPath1184" d="M 0 0L 177.28770949720672 0L 177.28770949720672 43L 0 43Z" stroke="none" fill="none"></path><g id="SvgjsG1185"><text id="SvgjsText1186" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="178px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="12.05" transform="rotate(0)"><tspan id="SvgjsTspan1187" dy="16" x="89"><tspan id="SvgjsTspan1188" style="text-decoration:;">GeneralModel</tspan></tspan></text></g></g><g id="SvgjsG1189"><path id="SvgjsPath1190" d="M513.16190342397 711.1301751589642L558.6926296809531 711.1301751589642" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1191)"></path></g><g id="SvgjsG1193" transform="translate(575.0836911334671,692.0072701310312)"><path id="SvgjsPath1194" d="M 0 0L 236.75977653631284 0L 236.75977653631284 46.44134078212291L 0 46.44134078212291Z" stroke="none" fill="none"></path><g id="SvgjsG1195"><text id="SvgjsText1196" font-family="微软雅黑" text-anchor="start" font-size="13px" width="237px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-1.7293296089385464" transform="rotate(0)"><tspan id="SvgjsTspan1197" dy="16" x="0"><tspan id="SvgjsTspan1198" style="text-decoration:;">choose an operation from: MaxPool, </tspan></tspan><tspan id="SvgjsTspan1199" dy="16" x="0"><tspan id="SvgjsTspan1200" style="text-decoration:;">AvgPool, SepConvBN3x3, SepConvBN</tspan></tspan><tspan id="SvgjsTspan1201" dy="16" x="0"><tspan id="SvgjsTspan1202" style="text-decoration:;">5x5 and SkipConnect</tspan></tspan></text></g></g><g id="SvgjsG1203"><path id="SvgjsPath1204" d="M512.002685546875 764.0113342285156L558.002685546875 764.0113342285156" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1205)"></path></g><g id="SvgjsG1207" transform="translate(575.0836911334671,746.4613342285156)"><path id="SvgjsPath1208" d="M 0 0L 206.91899441340786 0L 206.91899441340786 30L 0 30Z" stroke="none" fill="none"></path><g id="SvgjsG1209"><text id="SvgjsText1210" font-family="微软雅黑" text-anchor="start" font-size="13px" width="207px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="5.55" transform="rotate(0)"><tspan id="SvgjsTspan1211" dy="16" x="0"><tspan id="SvgjsTspan1212" style="text-decoration:;">pass tensor without operation</tspan></tspan></text></g></g><g id="SvgjsG1213" transform="translate(515.2401157144727,840.7024446654088)"><path id="SvgjsPath1214" d="M 0 25.766944781553388C 0 -8.588981593851129 52.76256983240228 -8.588981593851129 52.76256983240228 25.766944781553388C 52.76256983240228 60.122871156957906 0 60.122871156957906 0 25.766944781553388Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00ffff"></path><g id="SvgjsG1215"><text id="SvgjsText1216" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="33px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="16.31694478155339" transform="rotate(0)"></text></g></g><g id="SvgjsG1217" transform="translate(586.4943056586069,848.257098944169)"><path id="SvgjsPath1218" d="M 0 0L 109.27374301675977 0L 109.27374301675977 36.42458100558659L 0 36.42458100558659Z" stroke="none" fill="none"></path><g id="SvgjsG1219"><text id="SvgjsText1220" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="110px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="8.762290502793295" transform="rotate(0)"><tspan id="SvgjsTspan1221" dy="16" x="55"><tspan id="SvgjsTspan1222" style="text-decoration:;">ENASMacroLayer</tspan></tspan></text></g></g><g id="SvgjsG1223"><path id="SvgjsPath1224" d="M515.2401157144727 810.0463762762827L560.7708419714559 810.0463762762827" stroke-dasharray="10,5,3,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1225)"></path></g><g id="SvgjsG1227" transform="translate(578.0725179491095,786.3703986226515)"><path id="SvgjsPath1228" d="M 0 0L 205.79888268156424 0L 205.79888268156424 43.70949720670391L 0 43.70949720670391Z" stroke="none" fill="none"></path><g id="SvgjsG1229"><text id="SvgjsText1230" font-family="微软雅黑" text-anchor="start" font-size="13px" width="206px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="4.404748603351954" transform="rotate(0)"><tspan id="SvgjsTspan1231" dy="16" x="0"><tspan id="SvgjsTspan1232" style="text-decoration:;">(suppose this layer is the Nth </tspan></tspan><tspan id="SvgjsTspan1233" dy="16" x="0"><tspan id="SvgjsTspan1234" style="text-decoration:;">layer) outputs of all N-1 layers</tspan></tspan></text></g></g><g id="SvgjsG1235"><path id="SvgjsPath1236" d="M163.24290901056213 250.84525895784685C 166.7038178979269 290.40362855551774 245.01666705993807 272.29806254453354 241.5557581725733 311.8564321422044" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1237)"></path></g><g id="SvgjsG1239"><path id="SvgjsPath1240" d="M424.41050677592534 163.04637627628261L469.9412330329085 163.04637627628261" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1241)"></path></g><g id="SvgjsG1243" transform="translate(489.24290901056213,136.37039862265135)"><path id="SvgjsPath1244" d="M 0 0L 205.79888268156424 0L 205.79888268156424 43.70949720670391L 0 43.70949720670391Z" stroke="none" fill="none"></path><g id="SvgjsG1245"><text id="SvgjsText1246" font-family="微软雅黑" text-anchor="start" font-size="13px" width="206px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="4.404748603351954" transform="rotate(0)"><tspan id="SvgjsTspan1247" dy="16" x="0"><tspan id="SvgjsTspan1248" style="text-decoration:;">pass the tensor input directly to </tspan></tspan><tspan id="SvgjsTspan1249" dy="16" x="0"><tspan id="SvgjsTspan1250" style="text-decoration:;">the next node</tspan></tspan></text></g></g></svg>
\ No newline at end of file

docs/img/NAS_ENAS_micro.svg

+<svg id="SvgjsSvg1006" width="704.9999694824219" height="824.0800323486328" xmlns="http://www.w3.org/2000/svg" version="1.1" xmlns:xlink="http://www.w3.org/1999/xlink" xmlns:svgjs="http://svgjs.com/svgjs"><defs id="SvgjsDefs1007"><marker id="SvgjsMarker1046" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1047" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1050" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1051" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1054" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1055" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1058" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1059" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1062" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1063" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1066" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1067" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1070" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1071" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1074" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1075" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1078" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1079" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1082" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1083" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1086" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1087" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1090" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1091" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1094" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1095" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1098" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1099" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1134" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1135" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1144" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1145" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1148" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1149" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1152" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1153" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1156" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1157" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker><marker id="SvgjsMarker1160" markerWidth="16" markerHeight="12" refX="16" refY="6" viewBox="0 0 16 12" orient="auto" markerUnits="userSpaceOnUse" stroke-dasharray="0,0"><path id="SvgjsPath1161" d="M0,2 L14,6 L0,11 L0,2" fill="#323232" stroke="#323232" stroke-width="2"></path></marker></defs><g id="SvgjsG1008" transform="translate(67.99998474121094,25.008005142211914)"><path id="SvgjsPath1009" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc66"></path><g id="SvgjsG1010"><text id="SvgjsText1011" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1012" dy="16" x="35"><tspan id="SvgjsTspan1013" style="text-decoration:;">input_0</tspan></tspan></text></g></g><g id="SvgjsG1014" transform="translate(238.99998474121094,111.00800514221191)"><path id="SvgjsPath1015" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc66"></path><g id="SvgjsG1016"><text id="SvgjsText1017" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1018" dy="16" x="35"><tspan id="SvgjsTspan1019" style="text-decoration:;">input_1</tspan></tspan></text></g></g><g id="SvgjsG1020" transform="translate(238.99998474121094,279.0080051422119)"><path id="SvgjsPath1021" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1022"><text id="SvgjsText1023" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1024" dy="16" x="35"><tspan id="SvgjsTspan1025" style="text-decoration:;">node 0</tspan></tspan></text></g></g><g id="SvgjsG1026" transform="translate(238.99998474121094,492.0080051422119)"><path id="SvgjsPath1027" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1028"><text id="SvgjsText1029" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1030" dy="16" x="35"><tspan id="SvgjsTspan1031" style="text-decoration:;">node 2</tspan></tspan></text></g></g><g id="SvgjsG1032" transform="translate(67.99998474121094,372.0080051422119)"><path id="SvgjsPath1033" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1034"><text id="SvgjsText1035" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1036" dy="16" x="35"><tspan id="SvgjsTspan1037" style="text-decoration:;">node 1</tspan></tspan></text></g></g><g id="SvgjsG1038" transform="translate(67.99998474121094,594.0080051422119)"><path id="SvgjsPath1039" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1040"><text id="SvgjsText1041" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1042" dy="16" x="35"><tspan id="SvgjsTspan1043" style="text-decoration:;">node 3</tspan></tspan></text></g></g><g id="SvgjsG1044"><path id="SvgjsPath1045" d="M102.99998474121094 95.00800514221191C 111.75708566874948 195.1021267645375 282.7570856687495 178.91388351988633 273.99998474121094 279.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1046)"></path></g><g id="SvgjsG1048"><path id="SvgjsPath1049" d="M273.99998474121094 181.0080051422119C 277.41648985691916 220.05883730740834 277.41648985691916 239.9571729770155 273.99998474121094 279.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1050)"></path></g><g id="SvgjsG1052"><path id="SvgjsPath1053" d="M273.99998474121094 349.0080051422119C 278.98529322637694 405.9903418730597 278.98529322637705 435.0256684113641 273.99998474121094 492.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1054)"></path></g><g id="SvgjsG1056"><path id="SvgjsPath1057" d="M102.99998474121094 95.00800514221191C 112.65684103765147 205.38637769077735 112.65684103765147 261.6296325936465 102.99998474121094 372.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1058)"></path></g><g id="SvgjsG1060"><path id="SvgjsPath1061" d="M273.99998474121094 349.0080051422119C 280.01512026970283 417.7613188410721 109.01512026970283 303.2546914433517 102.99998474121094 372.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1062)"></path></g><g id="SvgjsG1064"><path id="SvgjsPath1065" d="M102.99998474121094 442.0080051422119C 108.29905390026858 502.57664278619006 108.29905390026858 533.4393674982338 102.99998474121094 594.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1066)"></path></g><g id="SvgjsG1068"><path id="SvgjsPath1069" d="M273.99998474121094 349.0080051422119C 284.41593834944956 468.0628996675149 113.41593834944956 474.95311061690893 102.99998474121094 594.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1070)"></path></g><g id="SvgjsG1072"><path id="SvgjsPath1073" d="M273.99998474121094 181.0080051422119C 212.99998474121094 264.0080051422119 111.93738864405282 269.8530110818261 102.99998474121094 372.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1074)"></path></g><g id="SvgjsG1076"><path id="SvgjsPath1077" d="M102.99998474121094 442.0080051422119C 109.2110530012738 513.0008402107513 280.21105300127385 421.0151700736725 273.99998474121094 492.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1078)"></path></g><g id="SvgjsG1080"><path id="SvgjsPath1081" d="M273.99998474121094 562.0080051422119C 280.06492236717565 631.3305594199732 109.0649223671756 524.6854508644507 102.99998474121094 594.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1082)"></path></g><g id="SvgjsG1084"><path id="SvgjsPath1085" d="M102.99998474121094 95.00800514221191C 24.999984741210938 329.0080051422119 30.999984741210938 425.0080051422119 102.99998474121094 594.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1086)"></path></g><g id="SvgjsG1088"><path id="SvgjsPath1089" d="M273.99998474121094 181.0080051422119C 222.99998474121094 348.0080051422119 118.5834705403015 415.88794739926834 102.99998474121094 594.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1090)"></path></g><g id="SvgjsG1092"><path id="SvgjsPath1093" d="M273.99998474121094 181.0080051422119C 319.99998474121094 315.0080051422119 358.99998474121094 344.0080051422119 273.99998474121094 492.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1094)"></path></g><g id="SvgjsG1096"><path id="SvgjsPath1097" d="M371.99998474121094 529.0080051422119L417.99998474121094 529.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1098)"></path></g><g id="SvgjsG1100" transform="translate(435.99998474121094,504.0080051422119)"><path id="SvgjsPath1101" d="M 0 0L 238 0L 238 46L 0 46Z" stroke="none" fill="none"></path><g id="SvgjsG1102"><text id="SvgjsText1103" font-family="微软雅黑" text-anchor="start" font-size="13px" width="238px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-1.95" transform="rotate(0)"><tspan id="SvgjsTspan1104" dy="16" x="0"><tspan id="SvgjsTspan1105" style="text-decoration:;">choose one operation from MaxPool, </tspan></tspan><tspan id="SvgjsTspan1106" dy="16" x="0"><tspan id="SvgjsTspan1107" style="text-decoration:;">AvgPool, SepConvBN3x3, SepConvBN</tspan></tspan><tspan id="SvgjsTspan1108" dy="16" x="0"><tspan id="SvgjsTspan1109" style="text-decoration:;">5x5, SkipConnect</tspan></tspan></text></g></g><g id="SvgjsG1110" transform="translate(371.99998474121094,562.0080051422119)"><path id="SvgjsPath1111" d="M 0 25.5C 0 -8.5 51 -8.5 51 25.5C 51 59.5 0 59.5 0 25.5Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#ffff00"></path><g id="SvgjsG1112"><text id="SvgjsText1113" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="31px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="16.05" transform="rotate(0)"></text></g></g><g id="SvgjsG1114" transform="translate(371.99998474121094,637.0080051422119)"><path id="SvgjsPath1115" d="M 0 25.5C 0 -8.5 51 -8.5 51 25.5C 51 59.5 0 59.5 0 25.5Z" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#00cc66"></path><g id="SvgjsG1116"><text id="SvgjsText1117" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="31px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="16.05" transform="rotate(0)"></text></g></g><g id="SvgjsG1118" transform="translate(435.99998474121094,566.5080051422119)"><path id="SvgjsPath1119" d="M 0 0L 244 0L 244 42L 0 42Z" stroke="none" fill="none"></path><g id="SvgjsG1120"><text id="SvgjsText1121" font-family="微软雅黑" text-anchor="start" font-size="13px" width="244px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="3.55" transform="rotate(0)"><tspan id="SvgjsTspan1122" dy="16" x="0"><tspan id="SvgjsTspan1123" style="text-decoration:;">accept two operations from all inputs, </tspan></tspan><tspan id="SvgjsTspan1124" dy="16" x="0"><tspan id="SvgjsTspan1125" style="text-decoration:;">then add the results as output</tspan></tspan></text></g></g><g id="SvgjsG1126" transform="translate(435.99998474121094,642.5080051422119)"><path id="SvgjsPath1127" d="M 0 0L 224 0L 224 40L 0 40Z" stroke="none" fill="none"></path><g id="SvgjsG1128"><text id="SvgjsText1129" font-family="微软雅黑" text-anchor="start" font-size="13px" width="224px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="10.55" transform="rotate(0)"><tspan id="SvgjsTspan1130" dy="16" x="0"><tspan id="SvgjsTspan1131" style="text-decoration:;">results of previous layers as input</tspan></tspan></text></g></g><g id="SvgjsG1132"><path id="SvgjsPath1133" d="M102.99998474121094 95.00800514221191C 118.06961340198137 267.2546489180095 289.0696134019814 319.76136136641435 273.99998474121094 492.0080051422119" stroke-dasharray="8,5" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1134)"></path></g><g id="SvgjsG1136" transform="translate(150.99998474121094,729.0880031585693)"><path id="SvgjsPath1137" d="M 0 35C 0 -11.666666666666666 70 -11.666666666666666 70 35C 70 81.66666666666667 0 81.66666666666667 0 35Z" stroke-dasharray="3,4" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#cc99ff"></path><g id="SvgjsG1138"><text id="SvgjsText1139" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="50px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="25.55" transform="rotate(0)"><tspan id="SvgjsTspan1140" dy="16" x="35"><tspan id="SvgjsTspan1141" style="text-decoration:;">output</tspan></tspan></text></g></g><g id="SvgjsG1142"><path id="SvgjsPath1143" d="M102.99998474121094 442.0080051422119C 113.41815075849257 561.0881876185914 196.41815075849257 610.0078206821898 185.99998474121094 729.0880031585693" stroke-dasharray="3,3" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1144)"></path></g><g id="SvgjsG1146"><path id="SvgjsPath1147" d="M102.99998474121094 664.0080051422119C 106.67699141184806 706.0363837051965 189.67699141184806 687.0596245955848 185.99998474121094 729.0880031585693" stroke-dasharray="3,3" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1148)"></path></g><g id="SvgjsG1150"><path id="SvgjsPath1151" d="M273.99998474121094 562.0080051422119C 280.58330524633993 637.2557028416771 192.58330524633993 653.8403054591041 185.99998474121094 729.0880031585693" stroke-dasharray="3,3" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1152)"></path></g><g id="SvgjsG1154"><path id="SvgjsPath1155" d="M273.99998474121094 349.0080051422119C 233.99998474121094 500.92799377441406 199.60096408433088 573.6280978979321 185.99998474121094 729.0880031585693" stroke-dasharray="3,3" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1156)"></path></g><g id="SvgjsG1158"><path id="SvgjsPath1159" d="M369.99998474121094 477.92799377441406L394.49998474121094 477.92799377441406L394.49998474121094 477.92799377441406L418.99998474121094 477.92799377441406" stroke-dasharray="3,3" stroke="#323232" stroke-width="2" fill="none" marker-end="url(#SvgjsMarker1160)"></path></g><g id="SvgjsG1162" transform="translate(435.99998474121094,448.0080051422119)"><path id="SvgjsPath1163" d="M 0 0L 243 0L 243 50.91998863220215L 0 50.91998863220215Z" stroke="none" fill="none"></path><g id="SvgjsG1164"><text id="SvgjsText1165" font-family="微软雅黑" text-anchor="start" font-size="13px" width="243px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="16.009994316101075" transform="rotate(0)"><tspan id="SvgjsTspan1166" dy="16" x="0"><tspan id="SvgjsTspan1167" style="text-decoration:;">pass the result directly to the output</tspan></tspan></text></g></g><g id="SvgjsG1168" transform="translate(371.99998474121094,709.0080051422119)"><path id="SvgjsPath1169" d="M 0 25.5C 0 -8.5 51 -8.5 51 25.5C 51 59.5 0 59.5 0 25.5Z" stroke-dasharray="3,4" stroke="rgba(50,50,50,1)" stroke-width="2" fill-opacity="1" fill="#cc99ff"></path><g id="SvgjsG1170"><text id="SvgjsText1171" font-family="微软雅黑" text-anchor="middle" font-size="13px" width="31px" fill="#323232" font-weight="400" align="middle" anchor="middle" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="16.05" transform="rotate(0)"></text></g></g><g id="SvgjsG1172" transform="translate(438.99998474121094,729.0880031585693)"><path id="SvgjsPath1173" d="M 0 0L 240 0L 240 19.920001983642578L 0 19.920001983642578Z" stroke="none" fill="none"></path><g id="SvgjsG1174"><text id="SvgjsText1175" font-family="微软雅黑" text-anchor="start" font-size="13px" width="240px" fill="#323232" font-weight="400" align="middle" anchor="start" family="微软雅黑" size="13px" weight="400" font-style="" opacity="1" y="-30.48999900817871" transform="rotate(0)"><tspan id="SvgjsTspan1176" dy="16" x="0"><tspan id="SvgjsTspan1177" style="text-decoration:;">(the node does not exist) </tspan><tspan id="SvgjsTspan1178" style="text-decoration:;font-weight: bold;">Only accept </tspan></tspan><tspan id="SvgjsTspan1179" dy="16" x="0"><tspan id="SvgjsTspan1180" style="text-decoration:;font-weight: bold;">input whose starting point is not </tspan></tspan><tspan id="SvgjsTspan1181" dy="16" x="0"><tspan id="SvgjsTspan1182" style="text-decoration:;font-weight: bold;">served as input for any other node.</tspan><tspan id="SvgjsTspan1183" style="text-decoration:;"> </tspan></tspan><tspan id="SvgjsTspan1184" dy="16" x="0"><tspan id="SvgjsTspan1185" style="text-decoration:;">It calculates inputs' average value as </tspan></tspan><tspan id="SvgjsTspan1186" dy="16" x="0"><tspan id="SvgjsTspan1187" style="text-decoration:;">the output of this cell.</tspan></tspan></text></g></g></svg>
\ No newline at end of file
